119,424 used machines on RESALE, but how to find them? Machine Search
maximum number of results exceeded > 1000
please refine your search
used
Jig grinding machine HAUSER S50
used
DRO- ELESTA x-travel 650 mm y-travel 450 mm z-travel 140 mm w-travel (head) 500 mm feed range 0 - 1500 mm/min table surface area 770 x 630 mm spindle speed 4.500- 80.000 rpm spindle speed with turbine 100.000- 160.000 rpm Perfect condition. Just start up and test run, about 200 hours.
used
Code 9602 DESCRIPTION Vertical JIG Grinder Make HAUSER Modell 3 SMO Serial No. 257 Machine No. 1519-2564 Table surface 600 x 320 mm Table movement longitude (X) 400 mm Table movement cross (Y) 250 mm Max. grinding diameter Ø 190 mm Column-Spindle 300 mm Max. height under spindle 500 mm Vertical movement spindle 90 mm Vertical movement grindinghead 500 mm Max. speeds grindingspindle up to 80.000 omw./min Weight 2000 kg Total power 6,6 kW – 380 Volts Accessories Grinding spindles, etc. Condition Machine is in good condition
used
x-travel:400 mm y-travel:250 mm workpiece height:max. 500 mm z-travel:500 mm table clamping surface LxW:550x330 mm power requirement:6 kW Total weight, approx.:2200 kg round table d = 300 mm
used
stroke 700 mm Y stroke 500 mm workpiece height 675 mm table surface area 900 x 770 mm daylight column 840 mm turning speed range - grinding spindle 9 - 45.000 rpm total power consumption 6.5 kW machine weight approx. 5.5 t machine dimensions approx. 3.6 x 5 m digital control With accessories - see photos in the application.
used
It is a very precise and working machine adjustment range X 400 mm, Y 250 mm, W (grinding head) 250 mm, feed X and Y 0 to 1800 mm/min, W 0 to 3000 mm/min, table 600 x 380 mm, maximum table load 200 kg, grinding spindle speeds with electric motor 9 to 45000 rpm, with air turbines up to 100000 and 160000 rpm, planetary rotation stepless 5 to 300 rpm, stroke speed of grinding spindle sleeve with quick stroke 0,5 to 12000 mm/min, stroke of grinding spindle sleeve 110 mm, diameter of grinding spindle sleeve 100 mm, NEW control: ADCOS CNC 800 (Swiss made) - RETROFIT ! http://www.adcos.ch/site/index.cfm?id_art=96324&actMenuItemID=44488&vs prache=DE read operating hours 64940, spindle hours 7633(July 2023) with dressing spindle system: KAISER C 42 DC, magnetic clamping plate , with fire extinguishing device: Kraft Bauer
used
2-axis digital display Travel X/Y/Z: 400/250/500 mm Optical rotary table D 300 mm + adapter plate D 400 mm Swivel rotary table D 200 mm Lots of accessories
used
Description: Year of construction: probably 1979 Serial number: 274 Smallest display unit: 0.001 mm Zero point can be selected as required Guaranteed positioning accuracy: 0.002 mm Power requirement of the machine: 7 kW Suction capacity of the air compressor: approx. 9 m³/h Working area: Usable table surface: 595 x 320 mm Adjustment range of the table: 400 x 250 mm Stroke of the vertical slide: approx. 500 mm Max. Clearance between the sanding motor and table: approx. 480 mm Distance between spindle center and vertical slide: 310 mm Max. Sanding diameter: approx. 220 mm Sanding diameter with intermediate plate: approx. 280 mm Max. included angle for conical sanding: 12° Sanding head: Vertical stroke of the sanding spindle, infinitely variable: 3 - 110 mm Stroke speed, infinitely variable: up to 6 m/min Speed of the planetary movement, infinitely variable: approx. 5 - 330 rpm Speed rang ...
used
Description: Year of construction: probably 1986 Adjustment range: In the X-axis (table slide): 900 mm In the Y-axis (sanding head): 600 mm In the W-axis (moving crossbeam): 635 mm Feed speed: In the X- and Y-axis, direct current drive, infinitely variable: 5 - 2500 mm/min In the W-axis, three-phase drive: approx. 800 mm/min Measured value display: Smallest display unit: 0.001 mm Zero point can be selected as required Positioning accuracy (basic deviation X, Y): 0.004 mm Table: Usable table surface: 1020 x 860 mm Permissible table load: max. 800 kg Width of the T-slots: 14 mm Number of T-slots: 7 Distance between the T-slots: 100 mm Working range of the sanding head: Grinding spindle speeds, infinitely variable with electric motors: 4500 - 80000 rpm With air turbines up to 100000 and 160000 rpm Planetary speed, infinitely variable: 5 - 250 rpm Stroke of the grinding spindle sleeve: max. ...
used
Article code: 14-04-011 Manufacturer: Hauser Very good general condition Machine workshop-tested Shipping time: All rights reserved. Year of construction: ca.1969 L x W x H: approx. 1500x1200x1800mm Weight: approx. 1800kg Digital display: 2-axis Working area: approx. 400x250mm Direct reading accuracy: approx. 0.001mm Accuracy of carriage adjustment: approx. 0.002mm Grinding diameter: approx. Ø220mm Lifting speed: approx. 0-6 m/min Speed: approx. 50000 rpm Accessories Extensive range of accessories / See pictures Other accessories on request Price and other technical data on request
used
Description: Grinding diameter 220 mm Table surface 600 x 320 mm Projection 310 mm Angle range 12° Grinding carriage adjustment - vertical 110 mm Lifting speeds 0 - 6 m/min Grinding spindle speed up to 50,000 rpm Circumferential speed max. 35 m/sec Power consumption approx. 7 kVA Round table d = 300 mm Frequency converter LANDERT SGI x-motion: 400 mm, y-motion: 250 mm, table surface area l x w : 600x320 mm, workpiece height max.: 500 mm, total power requirement: 6 kW, weight approx.: 2,000 kg, Approx. Onsite Dimension. (l x w x h): 3,000 x 3,000 x 3,000 mm
HOT IRON OSCILLATING SAW & OIL HYDRAULIC FEEDING CONTROL SYSTEM
used
Fine jigsaw for pipes up to diameter. 440mm Fine electronic with ASTXE 649 Order Nr. 723408 (l. when buying new catalog) Rated power: 750 Watt 240 volt 50 Hz Power output: 480 Watts Speed: 100-350 / min stepless electronic speed adjusting setting for optimal Schnittgesch. Stroke length: 60 mm Weight: 6.2 kg maximum material thickness: pipes up to 440 mm Profiles-W x H: 290 x 550 mm Accessories: Clamping for tubes up to 440 mm Tool chest, various saw blades good used condition in the camp to test
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data 1 column execution Table length: 400 mm Table width: 300 mm Longitudinal travel (X-axis): 200 mm Transversal travel (y axis): 200 mm Travel of the vertical slide: 250 mm Passage from grinding motor to table: 270 mm Max. grinding diameter: 15 mm Vertical travel of grinding spindle: stepless from: 2 mm up to: 32 mm Travel speeds: steps: 2 from: 4.0 m/min up to: 5.0 m/min Possible grinding-spindle speeds: stepless up to: 120000 rpm Voltage 50 Hz 3x: 380 Volt Machine´s weight about: 750 kg Overall dimensions machine: Length: 1200 mm Width: 900 mm Height: 1600 mm Various accessories: Rotary table diameter: 300 mm Set of clamping tools Air turbine
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data 1 column execution Table length: 400 mm Table width: 300 mm Longitudinal travel (X-axis): 200 mm Transversal travel (y axis): 200 mm Travel of the vertical slide: 250 mm Passage from grinding motor to table: 270 mm Max. grinding diameter: 15 mm Vertical travel of grinding spindle: stepless from: 2 mm up to: 32 mm Travel speeds: steps: 2 from: 4.0 m/min up to: 5.0 m/min Possible grinding-spindle speeds: stepless up to: 120000 rpm Voltage 50 Hz 3x: 380 Volt Machine´s weight about: 750 kg Overall dimensions machine: Length: 1100 mm Width: 1000 mm Height: 1800 mm
used
Ideal CSR Typ. 201 - 21 wire mesh production line CSR Project Jig welding machine Year of manufacture 1996 Switch / control cabinet kVa125 Made in Germany Control: W/Siemens Handheld Computer Control Mounted In Enclosed Wire Cage Safety Structure The coordinate welding machine CSR 201 is used for resisting point welding of sheet metal and wire products in stencils: Work-piece dimensions: Length max.1800 mm Width max. 750 mm Nldw7 Height max. 200 mm X-axis for driving the welding unit according to the work piece length, with a base frame, hardened liner guides, serrated toothed rack system and servomotor with incremental encoder, travel max. 1800mm programmable, max. Travel speed 1500 mm / s Positioning accuracy +/- 0.2mm Y axis for driving the welding unit according to work piece width, with hardened linear guides, rack system and rotary servo motor with incremental ...
used
CNC vertical jig boring machine WMW MIKROMAT Type BKoZ 900x1400/5NC Travel X 1120 mm Travel Y 710 mm Spindle travel Z 315 mm Travel W 630 mm Numerical Command CNC NUM 1060 Spindle Ø 125 mm Cone SA40 Rotation from 36 to 2240 RPM Table size 1400 x 900 mm Distance between colums 1080 mm Maxi distance spindle nose/table from 0 to 900 mm max Maxi eligible load on table 1000 kg max Separate electrical panel Machine renewed in 2000 with CN NUM1060 Voltage 380 V Dimensions (L x W x H) 4000 x 2460 x 3030 mm Weight approx. 9 T MACHINE IN OUR STOCK IN FRANCE.
used
1 BENZ laboratory jigger type LJ 250 TM, roller width 230 mm
used
2 MEZZERA high temperature jiggers type Celsius 143, year 2003, roller width 200 cm, working width 180 cm, electronic jigger, maximum batch diameter 1150 mm, maximum dyeing temperature 140 ºC, SETEX 838 dye cycle controller, with 2 add vats (1 with mixer)
used
1 MCS hydraulic dyeing jigger type Maxi Jigger 3400, roller width 340 cm, working width 320 cm, maximal winding diameter 1400 mm, year 1989, maximal dyeing temperature 98 ºC, dye cycle controller TERMOELETTRONICA type JTronix JP70tc,
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data 1 column execution Table length: 610 mm Table width: 280 mm Longitudinal travel (X-axis): 450 mm Transversal travel (y-axis): 280 mm Vertical travel (z axis): 92 mm Travel of the vertical slide: 320 mm Distance from spindle-center to vertical slide: 250 mm Max. grinding diameter: 127 mm with display-plate: 304 mm Stroke of spindle-nose: 340 mm Voltage 50 Hz 3x: 380 Volt Machine´s weight about: 1900 kg Overall dimensions machine: Length: 2500 mm Width: 1800 mm Height: 2500 mm
used
Technical data 1 column execution Table length: 400 mm Table width: 300 mm Longitudinal travel (X-axis): 200 mm Transversal travel (y-axis): 200 mm Travel of the vertical slide: 250 mm Passage from grinding motor to table: 270 mm Max. grinding diameter: 15 mm Vertical travel of grinding spindle: stepless from: 2 mm up to: 32 mm Travel speeds: steps: 2 from: 4.0 m/min up to: 5.0 m/min Possible grinding-spindle speeds: stepless up to: 120000 rpm Voltage 50 Hz 3x: 380 Volt Machine´s weight about: 750 kg Overall dimensions machine: Length: 1200 mm Width: 900 mm Height: 1600 mm Various accessories: Rotary table diameter: 300 mm Set of clamping tools Air turbine
used
X axis travel 1000 mm Y axis travel 700 mm Spindle travel 300 mm Table dimension 1.100x842 mm Spindle speed 40-2000 rpm Max power input 10 kW Spindle motor 8 HP Total permissible load on worktable 1 ton Machine approximate weight 15 ton
used
Technical data Table length: 550 mm Table width: 320 mm Longitudinal travel (X-axis): 400 mm Transversal travel (y-axis): 250 mm Vertical travel (z axis): 400 mm Table load max.: 400 kg Drill capacity in steel: 20 mm Taper in spindle: MT: 2 Stroke of drilling spindle (Z-axis): 130 mm Bore diameter max.: 75 mm Distance table to spindle: 590 mm Spindle speeds: stepless from: 60 rpm up to: 3000 rpm Feeds: Drill spindle slide: number (steps): 2 from: 0.03 mm/r up to: 0.06 mm/r Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.80 HP Machine´s weight about: 1100 kg Overall dimensions machine: Length: 1200 mm Width: 1150 mm Height: 1650 mm Various accessories: Lamp
used
Jig boring machine make SIP type MP 3 KFabr.-Nr. 9809 year 1981Clamping surface of the worktable: 520 x 380 mmLongitudinal adjustment of the work table: 450 mmTransverse adjustment of the drill spindle slide: 350 mmDistance between table surface max .: 520 mmxa0xa0xa0 and drill spindle: 120 mmPassage between the uprights: 600 mmVertical adjustment of the crossbeam: 400 mmDrill spindle: MK 2Infeed stroke: 150 mmSpindle speeds: 75-2000 rpm.automatic feed: 0.02-0.18 mmDrilling capacity in cast iron Drm.:25 mmxa0xa0xa0 in mild steel Drm.:20 mmGr. boring diameter: 100 mmReading on the auxiliary scale: 1 mmAccuracy: 0.005 mmMain drive motor: 1 hpDimensions L x W x H: 1740 x 1520 x 1880 mmWeight approx: 1680 kgWith- guide arm- Coolant deviceused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are ...
used
Single Column Coordinate Drilling Machine Fabr. WMW Mikromat Type BKoE 400 x 630/1Mash. -No: 1203.14.44for single, small and medium batch production of high quality gauges, fixturesTools and workpieces with tight tolerance requirementsTable size: 630 x 400 mmTable feeds: 63/160/400/1000 mm / min19 spindle speeds: 45 - 2800 rpm.Spindle feed: 0.014 - 0.5 mm / revHeadstock feed: 0.006 - 0.22 mm / revDrilling spindle stroke: 100 mmSpindle diameter: 80 mmTool holder: MK 3Distance between table and spindle: 40 - 560 mmAdjustments along: 400 mmtransverse: 250 mmvertical: 420 mmExternal dimensions approx: 2190 x 2010 x 2330 mm highWeight: 2.3 tWith:- 2-axis digital display- Angle drill head- 1 set of tool holders- 1 microscopeused, in very good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding ...
used
Slingofer vertical coil tong
used
Slingofer vertical coil tong
used
ZM coil hook 30 ton
Type: MXC Capacity: 400 kg
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data 1 column execution Table length: 400 mm Table width: 300 mm Longitudinal travel (X-axis): 200 mm Transversal travel (y axis): 200 mm Travel of the vertical slide: 250 mm Passage from grinding motor to table: 270 mm Max. grinding diameter: 15 mm Vertical travel of grinding spindle: stepless from: 2 mm up to: 32 mm Travel speeds: steps: 2 from: 4.0 m/min up to: 5.0 m/min Possible grinding-spindle speeds: stepless up to: 120000 rpm Voltage 50 Hz 3x: 380 Volt Machine´s weight about: 750 kg Various accessories: Centering microscop Cross table Length: 270 mm Width: 170 mm Lamp
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data 1 column execution Table length: 400 mm Table width: 300 mm Longitudinal travel (X-axis): 200 mm Transversal travel (y axis): 200 mm Travel of the vertical slide: 250 mm Passage from grinding motor to table: 270 mm Max. grinding diameter: 15 mm Vertical travel of grinding spindle: stepless from: 2 mm up to: 32 mm Travel speeds: steps: 2 from: 4.0 m/min up to: 5.0 m/min Possible grinding-spindle speeds: stepless up to: 120000 rpm Voltage 50 Hz 3x: 380 Volt Machine´s weight about: 750 kg Overall dimensions machine: Length: 1100 mm Width: 1000 mm Height: 1800 mm Various accessories: Rotary table diameter: 300 mm Centering microscop Grinding turbines: steps: 1 max. speed: 150000 rpm Grinding contact indicator
used
Saber saw, foxtail, tiger saw, reciprocating saw -Nominal consumption: 400 W -in: case with saw blades -Dimensions: 340/280/H100 mm -Weight: 3.2 kg
used
Deman 33 ton x 27 560 mm Kind of: overhead travelling crane Capacity: 33 ton Span: 27 560 mm Tackle speed: 0,5 > 5 m/min Rotationspeed: 5 > 20 m/min Displacementspeed: 10 Weight: 29 ton Radiocontrol: radio control Numbre of riggers : double rigger
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Control: GE FANUC Series 16-M Technical data 1 column execution Table length: 600 mm Table width: 380 mm Longitudinal travel (X-axis): 500 mm Transversal travel (y axis): 300 mm Travel of the vertical slide: 450 mm Passage from grinding motor to table: 485 mm Max. grinding diameter: 230 mm with display-plate: 360 mm Stroke of spindle-nose: 340 mm Max. angle with taper grinding: up to: 16 ° Vertical travel of grinding spindle: stepless from: 1 mm up to: 110 mm Travel speeds: stepless from: 0.5 m/min up to: 12.0 m/min Planetary motion speeds: c axis stepless from: 5 rpm up to: 250 rpm Voltage 50 Hz 3x: 380 Volt Total power required: 10.2 HP Machine´s weight about: 4000 kg Overall dimensions machine: Length: 2700 mm Width: 1700 mm Height: 2850 mm Various accessories: fi ...
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Control: FANUC O-M Operating hours: 55887 Technical data 2 columns execution Table length: 1320 mm Table width: 860 mm Longitudinal travel (X-axis): 1200 mm Transversal travel (y axis): 600 mm Travel of the vertical slide: 635 mm Passage from grinding motor to table: 750 mm Max. grinding diameter: 230 mm with display-plate: 360 mm Passage between the columns: 950 mm Max. angle with taper grinding: up to: 16 ° Planetary motion speeds: c axis stepless from: 5 rpm up to: 300 rpm Possible grinding-spindle speeds: stepless from: 9000 rpm up to: 80000 rpm With air-turbine max.: 160000 rpm Voltage 50 Hz 3x: 380 Volt Total power required: 8.5 kVA Machine´s weight about: 6300 kg Overall dimensions machine: Length: 3000 mm Width: 2500 mm Height: 2870 mm Various accessories: CN ...
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Control: GE FANUC Series 16i-M Operating hours: 16841 Technical data Table: Table length: 1440 mm Table width: 860 mm Table load max.: 800 kg Carriage: Longitudinal travel (X-axis): 1300 mm Transversal travel (y axis): 800 mm Vertical travel (z axis): 635 mm Passage from grinding motor to table: 0 - 750 mm Max. grinding diameter: 230 mm with display-plate: 360 mm Passage between the columns: 970 mm Max. angle with taper grinding: up to: 16 ° Stroke speed Z-Axis: Alternating stroke mouvement, infinitely adjust. from Vmin.: 0.500 mm/min up to Vmax.: 14000 mm/min Stroke frequency Z: 5 Hz Stroke length Z, infinitely adjustable: 170 mm Radiale fine feed U-axis up to: 5.5 mm Planetary motion speeds: c axis stepless from: 5 rpm up to: 300 rpm Possible grinding-spindle speeds ...
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Control: SIEMENS SINUMERIK 840 M / 6 FC 4101-1MA00-Z Technical data Table length: 1000 mm Table width: 630 mm Longitudinal travel (X-axis): 710 mm Transversal travel (y axis): 400 mm Travel of the vertical slide: 510 mm Max. angle with taper grinding: up to: 7 ° Vertical travel of grinding spindle: up to: 120 mm Travel speeds: stepless up to: 5 m/min Planetary motion speeds: c axis stepless from: 1 rpm up to: 250 rpm Possible grinding-spindle speeds: stepless from: 5000 rpm up to: 120000 rpm Voltage 50 Hz 3x: 380 Volt Total power required: 10 kW Machine´s weight about: 5000 kg Overall dimensions machine: Length: 4200 mm Width: 2800 mm Height: 3150 mm Various accessories: Tool cabinet: 2 Centering device: 2 Vice: width: 2 x 160 mm Dust extractor Coolant system Centeri ...
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Control: GE FANUC Series O-M Technical data 1 column execution Table: Table length: 600 mm Table width: 380 mm T-channel width: 10 mm Number of spline: 6 Distance of the T-slots: 50 mm Table load max.: 200 kg Carriage: Longitudinal travel (X-axis): 500 mm Transversal travel (y-axis): 300 mm Travel of the vertical slide: 450 mm Passage from grinding motor to table: 485 mm Max. grinding diameter: 230 mm with display-plate: 360 mm Stroke of spindle-nose: 340 mm Max. angle with taper grinding: up to: 16 ° Vertical travel of grinding spindle: stepless from: 1 mm up to: 110 mm Travel speeds: stepless from: 0.5 m/min up to: 12 m/min Planetary motion speeds: c axis stepless from: 5 rpm up to: 250 rpm Feeds: X axis: 0 - 12 m/min Y axis: 0 - 12 m/min W axis: 900 mm/min Voltage 50 ...
used
This portal crane can be moved all over your workshop floor thanks to the pneumatic hovering system, the requirement to be able to use this is that the floor needs to be perfectly smooth. Max height under lifting hook: 2000 mm Lifting capacity: 5 ton Kind of: portal crane Capacity: 5 ton Span: 4 meter Drop: 2 meter
used
Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Table length: 0 mm Table width: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 1100 mm Table width: 842 mm Longitudinal travel (X-axis): 1000 mm Transversal travel (y-axis): 795 mm Vertical travel (z axis): 800 mm Table load max.: 800 kg Drill capacity in steel: 55 mm Taper in spindle: MT: 4 Stroke of drilling spindle (Z-axis): 250 mm Bore diameter max.: 300 mm Spindle speeds: number (steps): 18 from: 40 rpm up to: 2000 rpm Feeds: Table: stepless up to: 300 mm/min Drill spindle slide: number (steps): 6 from: 0.04 mm/r up to: 0.35 mm/r Rapid traverse: Table:longitudinal: 2500 mm/min transversal from: 2500 mm/min Distance between columns: 1100 mm Distance between spindle and table: 900 mm Voltage 50 Hz 3x: 380 Volt Spindle motor: 4.00 HP Total power required: 8.0 HP Machine´s weight about: 7500 kg Overall dimensions ma ...
used
Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Table length: 0 mm Table width: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 400 mm Table width: 300 mm Longitudinal travel (X-axis): 200 mm Transversal travel (y-axis): 200 mm Verticla travel (W-axis): 250 mm Drill capacity in steel: 10 mm Drill depth (spindle stroke): 70 mm Distance table to spindle: 320 mm Spindle speeds: stepless from: 150 rpm up to: 3000 rpm Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.5 HP Machine´s weight about: 700 kg Overall dimensions machine: Length: 1200 mm Width: 1000 mm Height: 1800 mm Various accessories: Digital readout number of axis:: 2 Drill chuck Centering microscop Set of collets
used
Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Table length: 0 mm Table width: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 400 mm Table width: 300 mm Longitudinal travel (X-axis): 200 mm Transversal travel (y-axis): 200 mm Verticla travel (W-axis): 250 mm Drill capacity in steel: 10 mm Drill depth (spindle stroke): 70 mm Distance table to spindle: 320 mm Spindle speeds: stepless from: 150 rpm up to: 3000 rpm Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.5 HP Machine´s weight about: 700 kg Overall dimensions machine: Length: 1200 mm Width: 1000 mm Height: 1800 mm Various accessories: Digital readout number of axis:: 2 Manufacturer: HEIDENHAIN Rotary table diameter: 300 mm Drill chuck Boring head Microscope Centering divice with dial indicator Set of collets Lamp
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Technical data 2 columns execution Table: Table length: 1020 mm Table width: 860 mm T-channel width: 14 mm Number of spline: 7 Distance of the T-slots: 100 mm Table load max.: 800 kg Longitudinal travel (X-axis): 900 mm Transversal travel (y-axis): 600 mm Verticla travel (W-axis): 635 mm Feeds: X axis: 5 - 2500 mm/min Y axis: 5 - 2500 mm/min W axis: 800 mm/min Passage from grinding motor to table: 750 mm Max. grinding diameter: 230 mm with display-plate: 360 mm Passage between the columns: 950 mm Max. angle with taper grinding: up to: 16 ° up to grinding depth: 44 mm Vertical travel of grinding spindle: up to: 180 mm Travel speeds: stepless from: 0.015 m/min up to: 7.5 m/min Stroke length Z, infinitely adjustable: 125 mm Radiale fine feed U-axis up to: 6 mm Planetary moti ...
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Control: CNC 311 Technical data Table length: 770 mm Table width: 630 mm Table load max.: 500 kg Longitudinal travel (X-axis): 650 mm Transversal travel (y-axis): 450 mm Verticla travel (W-axis): 500 mm Max. grinding diameter: 230 mm with display-plate: 360 mm Stroke of spindle-nose: 125 mm Max. angle with taper grinding: up to: 16 ° up to grinding depth: 44 mm Alternating stroke mouvement, infinitely adjust. from Vmin.: 0.5 mm/min up to Vmax.: 12000 mm/min Stroke frequency Z: 4 Hz Radiale fine feed U-axis up to: 5.5 mm Planetary motion speeds: c axis stepless from: 5 rpm up to: 250 rpm Possible grinding-spindle speeds: stepless from: 4500 rpm up to: 80000 rpm With air-turbine max.: 160000 rpm Voltage 50 Hz 3x: 380 Volt Machine´s weight about: 5600 kg Overall dim ...
used
Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Table length: 0 mm Table width: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 550 mm Table width: 320 mm Longitudinal travel (X-axis): 400 mm Transversal travel (y-axis): 250 mm Vertical travel (z axis): 400 mm Drill capacity in steel: 20 mm Taper in spindle: MT: 2 Stroke of drilling spindle (Z-axis): 130 mm Bore diameter max.: 75 mm Distance table to spindle: 600 mm Spindle speeds: stepless from: 120 rpm up to: 3000 rpm Feeds: Drill spindle slide: number (steps): 2 from: 0.03 mm/r up to: 0.06 mm/r Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.75 HP Machine´s weight about: 1500 kg Overall dimensions machine: Length: 1400 mm Width: 1500 mm Height: 2100 mm Various accessories: Tool cabinet Drill chuck Set of drills Set of milling cutters
used
Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm CNC Brand: 0 CNC Model: 0 Control: GE FANUC Power Mate Technical data 1 column execution Table: Table length: 600 mm Table width: 380 mm Table load max.: 300 kg Longitudinal travel (X-axis): 400 mm Transversal travel (y-axis): 250 mm Travel of the vertical slide: 450 mm Passage from grinding motor to table: 485 mm Max. grinding diameter: 230 mm with display-plate: 360 mm Stroke of spindle-nose: 340 mm Max. angle with taper grinding: up to: 16 ° Vertical travel of grinding spindle: stepless from: 1 mm up to: 120 mm Travel speeds: stepless from: 0.5 m/min up to: 6 m/min Stroke speed Z-Axis: from Vmin.: 15 mm/min up to Vmax.: 6000 mm/min Planetary motion speeds: c axis stepless from: 5 rpm up to: 250 rpm Voltage 50 Hz 3x: 400 Volt Total power required: 10.2 HP Machine´s weight about: 4000 kg ...
used
Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Table length: 0 mm Table width: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 400 mm Table width: 300 mm Longitudinal travel (X-axis): 200 mm Transversal travel (y-axis): 200 mm Vertical travel (z axis): 250 mm Drill capacity in steel: 10 mm Taper in spindle: MT Drill depth (spindle stroke): 70 mm Distance table to spindle: 320 mm Spindle speeds: stepless from: 150 rpm up to: 3000 rpm Feeds: Drill spindle slide: from: 0.015 mm/r Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.5 HP Machine´s weight about: 700 kg Overall dimensions machine: Length: 1200 mm Width: 1000 mm Height: 1800 mm Various accessories: Digital readout number of axis:: 2 Manufacturer: PHILIPS Drill chuck Set of boring head Centering microscop Set of drills Device for laying out
used
Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Table length: 0 mm Table width: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 400 mm Table width: 300 mm Longitudinal travel (X-axis): 200 mm Transversal travel (y-axis): 200 mm Vertical travel (z axis): 250 mm Drill capacity in steel: 10 mm Taper in spindle: MT: 0 Drill depth (spindle stroke): 70 mm Distance table to spindle: 320 mm Spindle speeds: stepless from: 150 rpm up to: 3000 rpm Feeds: Drill spindle slide: from: 0.015 mm/r Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.5 HP Machine´s weight about: 700 kg Overall dimensions machine: Length: 1200 mm Width: 1000 mm Height: 1800 mm Various accessories: Digital readout number of axis:: 2 Manufacturer: ELESTA Rotary table diameter: (Ref. 0330.2) Ø 300 mm Drill chuck Set of boring head Microscope Centering microscop Centering divice with dial indicator Set of collet ...
used
Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Table length: 0 mm Table width: 0 mm CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN TNC 155 / J200 Technical data Table length: 1020 mm Table width: 860 mm Longitudinal travel (X-axis): 900 mm Transversal travel (y-axis): 600 mm Vertical travel (z axis): 635 mm Table load max.: 800 kg Taper in spindle: ISO: 40 Stroke of drilling spindle (Z-axis): 200 mm Distance table to spindle: 15 - 850 mm Spindle speeds: from: 10 - 800 rpm up to: 800 - 2500 rpm Feeds: Table: from: 5 mm/min up to: 5000 mm/min Drill spindle slide: number (steps): 6 from: 0.03 mm/r up to: 0.33 mm/r Distance between columns: 950 mm Voltage 50 Hz 3x: 380 Volt Spindle motor: 4.5 kW Machine´s weight about: 6500 kg Length: 2930 mm Width: 2370 mm Height: 2690 mm Various accessories: Drill chuck Set of boring head Centering microscop Set of tool holders
