119,257 used machines on RESALE, but how to find them? Machine Search
maximum number of results exceeded > 1000
please refine your search
Werner & Pfleiderer model GK50UK internal mixer. Chamber volume 85 litre, Net volume: 60 litre (batch size approx 85kg), Tangential type rotors, Year of manufacture: 1971, Pneumatic hopper, Hydraulic drop door discharge with rotary actuator and hydraulic latch. Full unidrive gearbox (August Seegers), with Intermediate selectable 2 speed gearbox, 675 HP rating, rpm 1500/1340, Output 895rpm or 1340rpm. With 550kW, 980A, 1482 rpm motor (fixed speed) Rotor speeds - N895 = 51/47rpm, N1340 = 78/72rpm. Siemens PLC controls.
new
internal diameter:250 mm swing diameter:455 mm workpiece length - max.:1200 mm table rotating:-4/+8 ° table speeds:0-4000 mm/min max. workpiece weight:80 kg workhead - center taper:5 MK Rotation speed of workhead :0 - 400 1/min workhead motor:4 kw 3-jaw chuck:250 (selbstschließend) mm grinding motor:4 kW coolant pump:2,2 kW Weight approx.:2,4 t machine dimensions:3200 x 2100 mm CNC controller:Siemens 840 D oder SPS von Siemens autom. sensing device for grinding wheel:Option linear scales and ballscrew:in allen Achsen face grinding attachement:Durchmesser 125 mm clamping chuck:250 (selbstschließend), 1 Satz harte Backen, 1 Satz weiche Backen, 1 Satz Innen mm frequency control main spindel engine:für die Innenschleifeinrichtung internal grinding spindle:RPM 28.000, diam. 60 mm. Min. diam. cap. 25 mm. x Bohrung 50 mm, Max. diam. cap. 100 mm. x Bohrung 115 mm . internal grinding spindle: ...
new
internal diameter:300 mm swing diameter:300/350 mm workpiece length - max.:2300 mm table rotating:-2/+6 ° table speeds:0-4000 mm/min max. workpiece weight:400 (fliegend, 150mm von der Spindelnase) kg workhead - center taper:6 MK Rotation speed of workhead :0 - 400 1/min workhead motor:4 kw 3-jaw chuck:250 (selbstschließend) mm grinding motor:11 kW coolant pump:2,2 kW CNC controller:Siemens 840 D oder SPS von Siemens autom. sensing device for grinding wheel:Option linear scales and ballscrew:in allen Achsen face grinding attachement:Durchmesser 125 mm clamping chuck:350 (selbst zentrierend) mm frequency control main spindel engine:für die Innenschleifeinrichtung internal grinding spindle:auf Anfrage internal grinding spindle:auf Anfrage fixed steady rests:10-100 mm, 100-170 mm PERFORMANCE AND PRECISION DEGREE Robbi grinding machines are according to the international precision normes ...
used
Internal circular grinding machine with plan grinding equipment, second-hand internal and face grinding machine, used Type / type: SI 6/1 x 315 Manufacturer / make: WMW Year / year of make: 1983 schleifbarer the protection of workpiece diameter / grinding diameter: inner / internal 20... 400 mm; outside / external 500 mm maximum workpiece diameter workpiece protection /. maximum diameter of work piece: 500 mm Max grinding depth / maximum grinding length: 315 mm schleifbarer angle of cone / cone grinding: 60 ° Internal grinding motor power / power drive motor grinding of internal: 7,5 kW Internal grinding spindle speeds / rev's of internal grinding spindle: 2640... 16500 RPM Power cylindrical grinding device / power drive of face grinding attachment: 4 kW Power work-piece motor / power drive of workpiece engine: 1.5 kW Workpiece spindle speeds / rev's piece of work s ...
used
Internal quick stylus, length measuring device, internal precision measuring device, internal measuring device, internal measuring stylus, micrometer screw -Manufacturer: Mauser, internal micrometer internal measuring device -Measurement accuracy: 0.01 mm -Attachments: length 25/50/100/200 mm -Measuring range: approx. 50 - 425 mm -Box dimensions: 230/100/H30 mm -Weight: 0.7 kg
used
Grinding diameter maximum: 0 mm Grinding diameter minimum: 0 mm Turning diameter: 0 mm Grinding depth: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Min. internal grinding diameter: 3.0 mm Max. internal grinding diameter: 50 mm Grinding depth: 80 mm Centre height: 200 mm Workpiece spindle speeds: number (steps): 5 from: 350 rpm up to: 1200 rpm Max. angle: 120 ° Spindle hole: 25 mm Possible grinding-spindle speeds: from: 9000 rpm up to: 120000 rpm Grinding table travel: min.: 2 mm max: 300 mm Table speeds: stepless from: 0.10 m/min up to: 10.00 m/min Voltage 50 Hz 3x: 380 Volt Drive for internal grinding spindle: 15.0 kW Machine´s weight about: 2200 kg Overall dimensions machine: Length: 1800 mm Width: 1500 mm Height: 1600 mm Various accessories: Face grinding attachment Internal grinding spindle:: AIR number: 1 max. speed: 80000 rpm
used
internal diameter: 20/300 mm grinding depth: 250 mm swing diameter: 250 mm workpiece spindle - bore: 45 mm workpiece spindle swivable +/-: 25 ° taper setting angle of the workpiece column: 50 ° work piece spindle speed: 42 - 400 U/min grinding spindle speed: 10.000 U/min table speed -stepless-: 0,1 - 8 m/min grinding spindle drive: 4 kW power capacity: 10 kW weight of the machine ca.: 4.500 kg dimensions of the machine ca.: m : : : : : Internal grinding Æ, min./max. 20 / 300 mm Grinding depth 500 mm Table stroke, min./max. 5 / 800 mm Height of centres above table 250 mm Swing Æ in the table recess 600 mm Workspindle bore 62 / 45 mm Swivability of workpiece wheelhead 25 ° Max. taper angle which can be ground 50 ° Infeed, per stroke 0.0025 - 0.5 mm Worksp ...
used
Internal grinding machine, internal grinding device, internal grinding spindle, drum grinding machine -Manufacturer: Paul Eugen Mayer, internal grinding machine type PMB -Drive motor: Hanning 1.1 kW / 2810 rpm -Grinding spindle: Ø 100 x 140 mm / see photos -Support table: pivoting -Total dimensions: 580/500/H1180 mm -Weight: 99 kg
used
High-performance grinding spindle, internal grinding machine, internal grinding device, internal grinding spindle -Grinding spindle: internal grinding spindle -Drive motor: BBC 1.5 kW / 2870 rpm -Max. Speed: rpm -Shaft axis: height 460 mm -Recording/Dimensions: see photos -Total dimensions: 730/400/H535 mm -Weight: 105 kg
used
Grinding diameter maximum: 0 mm Grinding diameter minimum: 0 mm Turning diameter: 0 mm Grinding depth: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Min. internal grinding diameter: 5.0 mm Max. internal grinding diameter: 200 mm Grinding depth: 250 mm Centre height: 180 mm Distance between centres: 1000 mm Workpiece spindle speeds: number (steps): 6 from: 125 rpm up to: 1000 rpm Spindle hole: 50 mm Grinding spindle speeds: from: 0 rpm up to: 12000 rpm Grinding table travel: min.: 3 mm max: 600 mm Table speeds: stepless from: 0.40 m/min up to: 10.00 m/min Voltage 50 Hz 3x: 380 Volt Workpiece spindle motor: 1.00 kW Drive for internal grinding spindle: 3.7 kW Total power required: 8.7 kW Machine´s weight about: 2700 kg Overall dimensions machine: Length: 1800 mm Width: 900 mm Height: 1500 mm Various accessories: 3-jaw chuck diameter: 200 mm Steady
used
Grinding diameter maximum: 0 mm Grinding diameter minimum: 0 mm Turning diameter: 0 mm Grinding depth: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Min. internal grinding diameter: 1 mm Max. internal grinding diameter: 50 mm Grinding depth: 3 - 200 mm Centre height: 132 mm Workpiece spindle speeds: stepless from: 150 rpm up to: 1500 rpm Max. angle: 90 ° Taper in spindle:: 20 W Grinding spindle speeds: from: 16500 rpm up to: 33000 rpm Table speeds: stepless from: 0 m/min up to: 10 m/min Rotatable grinding spindle head (b-axis): 55 ° Voltage 50 Hz 3x: 380 Volt Workpiece spindle motor: 0.8 kW Drive for internal grinding spindle: 3 kW Machine´s weight about: 2000 kg Overall dimensions machine: Length: 1800 mm Width: 1000 mm Height: 1800 mm Various accessories: Grinding wheel dressing device Frontal grinding device 3-jaw chuck diameter: 125 mm Set of jaws hard Set of jaws Special ba ...
used
Grinding diameter maximum: 0 mm Grinding diameter minimum: 0 mm Turning diameter: 0 mm Grinding depth: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Min. internal grinding diameter: 1 mm Max. internal grinding diameter: 50 mm Grinding depth: 200 mm Centre height: 132 mm Workpiece spindle speeds: from: 150 rpm up to: 1500 rpm Max. angle: 90 ° Possible grinding-spindle speeds: from: 16500 rpm up to: 120000 rpm Table speeds: stepless up to: 10 m/min Voltage 50 Hz 3x: 380 Volt Workpiece spindle motor: 0.8 kW Drive for internal grinding spindle: 3 kW Machine´s weight about: 2000 kg Overall dimensions machine: Length: 1800 mm Width: 1000 mm Height: 1800 mm Various accessories: Grinding wheel dressing device
used
Grinding diameter maximum: 0 mm Grinding diameter minimum: 0 mm Turning diameter: 0 mm Grinding depth: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Min. internal grinding diameter: 5 mm Max. internal grinding diameter: 250 mm Grinding depth: 200 mm Workpiece spindle speeds: stepless from: 15 rpm up to: 1500 rpm Max. angle: +/-15 ° Spindle hole: 50 mm Max. distance from workpiece spindle to grinding spindle holder: 770 mm Table speeds: stepless from: 0 m/min up to: 10 m/min Workpiece spindle motor: 0.5 kW Drive for internal grinding spindle: 3 kW Machine´s weight about: 2250 kg Various accessories: Wheel trueing attachment 3-jaw chuck diameter: 200 mm 3-jaw chuck diameter: 250 mm 4-jaw chuck diameter: 250 mm Set of jaws hard Set of jaws Macnetic chuck diameter: 200 mm Steady Set of collets Set of grinding arbors
used
Grinding diameter maximum: 0 mm Grinding diameter minimum: 0 mm Turning diameter: 0 mm Grinding depth: 0 mm CNC Brand: 0 CNC Model: 0 Operating hours: 0 Technical data Min. internal grinding diameter: 0.5 mm Max. internal grinding diameter: 20 mm Grinding depth: 100 mm Centre height: 60 mm Distance between centres: 150 mm Workpiece spindle speeds: number (steps): 3 from: 560 rpm up to: 1000 rpm Spindle hole: 12 mm Taper in spindle:: 12 W Grinding spindle speeds: from: 90000 rpm up to: 120000 rpm Rotatable grinding spindle head (b-axis): + 45 / - 45 ° Voltage 50 Hz 3x: 380 Volt Machine´s weight about: 250 kg Overall dimensions machine: Length: 900 mm Width: 750 mm Height: 1300 mm Various accessories: Automatic internal grinding support: AMI 25 Set of flanges Set of collets: W 12 Lamp Air spindle Set of service tools
used
Grinding diameter maximum: 0 mm Grinding diameter minimum: 0 mm Turning diameter: 0 mm Grinding depth: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Min. internal grinding diameter: 1.0 mm Max. internal grinding diameter: 50 mm Grinding depth: 200 mm Centre height: 132 mm Workpiece spindle speeds: from: 150 rpm up to: 1500 rpm Max. angle: 90 ° Possible grinding-spindle speeds: from: 16500 rpm up to: 120000 rpm Table speeds: stepless up to: 10.00 m/min Voltage 50 Hz 3x: 380 Volt Workpiece spindle motor: 0.80 kW Drive for internal grinding spindle: 3.0 kW Machine´s weight about: 2000 kg Overall dimensions machine: Length: 1800 mm Width: 1000 mm Height: 1800 mm
used
Grinding diameter maximum: 0 mm Grinding diameter minimum: 0 mm Turning diameter: 0 mm Grinding depth: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Min. internal grinding diameter: 0.5 mm Max. internal grinding diameter: 15 mm Grinding depth: 75 mm Centre height: 60 mm Distance between centres: 125 mm Max. work piece diameter: 80 mm Workpiece spindle speeds: stepless from: 150 rpm up to: 1500 rpm Spindle hole: 12 mm Possible grinding-spindle speeds: up to: 120000 rpm Grinding table travel: max: 225 mm Table speeds: stepless from: 1 m/min up to: 8 m/min Voltage 50 Hz 3x: 380 Volt Workpiece spindle motor: 0.3 kW Machine´s weight about: 650 kg Overall dimensions machine: Length: 1200 mm Width: 1150 mm Height: 1500 mm Various accessories: Wheel trueing attachment 3-jaw chuck: 2x Internal grinding spindle:: JS 80 / JS 120 number: 2 max. speed: 120000 rpm max. speed: 80000 rpm Set of c ...
used
internal diameter: 120 mm grinding depth: 200 mm swing diameter: mm total power requirement: 4 kW weight of the machine ca.: t dimensions of the machine ca.: m Grinding diameter, internal, max., approx. 3 - 120 mm Grinding depth, approx. 200 mm Height of centres above rotating workpiece slide 132 mm Max. swing Ø in front of rotating workpiece slide, approx. 450 mm Work spindle admission 40 mm Table stroke, max. (Z axis) 480 mm Workpiece cross adjustment (X axis) 50 mm Turret head cross adjustment (U axis) 50 mm Workspindle head swivelling (B axis) -30 / +45 ° (manual) Speeds of workspindle, infinitely variable 75 - 1,300 rpm Grinding spindle speeds 9,500 - 150,000 rpm Grinding spindle drive 4 kW Total electrical load, approx. 8 kW - 380 V - 50 Hz Weight, approx. 3,000 kg Accessories / Special Features TRIPET (Bruetsch) CNC Control for 3 axes (Z, X and U) with electric hand wheel, with ...
used
Grinding diameter maximum: 0 mm Grinding diameter minimum: 0 mm Turning diameter: 0 mm Grinding depth: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Min. internal grinding diameter: 5.0 mm Max. internal grinding diameter: 200 mm Grinding depth: 250 mm Centre height: 180 mm Distance between centres: 1000 mm Workpiece spindle speeds: number (steps): 6 from: 125 rpm up to: 1000 rpm Spindle hole: 50 mm Possible grinding-spindle speeds: from: 3600 rpm up to: 40000 rpm Grinding table travel: min.: 3 mm max: 600 mm Table speeds: stepless from: 0.40 m/min up to: 10.00 m/min Voltage 50 Hz 3x: 380 Volt Workpiece spindle motor: 1.00 kW Drive for internal grinding spindle: 3.7 kW Total power required: 8.7 kW Machine´s weight about: 2700 kg Overall dimensions machine: Length: 1800 mm Width: 900 mm Height: 1500 mm
used
Internal micrometers, micrometer screw, internal diameter, internal precision measuring device, cylinder gauge, -Measuring range: 35-60mm -Dimensions: 115/450/H60 mm -Weight 1.6kg
used
Internal micrometers, micrometer screw, internal diameter, internal precision measuring device, cylinder gauge, -Handover: in the current condition as seen -Condition see pictures -Measuring range: 18-150mm -Dimensions: 280/450/H60 mm -Weight 2kg
used
Internal micrometers, micrometer screw, internal diameter, internal precision measuring device, cylinder gauge, -Measuring range: 18-150mm -Dimensions: 280/450/H60 mm -Weight 2kg
used
internal diameter:100 mm grinding depth:160 mm swing diameter:300/450 mm centre height:290 mm max. outer diameter:300/450 mm work piece spindle speed:50-360/90-700 U/min weight of the machine ca.:2900 kg Machine size (LxWxH):2500x1750x1800 mm face grinding attachement:mit Schleifscheibe internal grinding spindle:DKF Typ SLA 60x400 mit 20.000 U/min grinding wheel dresser:auf Tisch 3 jaw chuck Ø:200 mm coolant system with magnet grate:und Wassertank frequency converter:f. stufenlose Spindeldrehzahl f. Innenschleifeinrichtung 100 % before loading warranty: none one used internal grinding machine, make: Jotes, type: SOJ 10M, year of produktion 1986
used
Vertical internal broaching machine, used Vertical internal - broaching machine. used Type / type: RITS 16 x 1500 x 500 Manufacturer / make: Artur Klink year / new: 1995 Biggest tensile strength / maximum pulling power: 16 t Max stroke length / max broaching length: 1500 mm Table width / table width: 500 mm Räumgeschwind. / broaching speed: 1..6, 4 m / min Rücklaufgeschw. / return speed: 19.5 m / min maximum tool length / max length of tool: 1700 mm Power consumption / connected power: 42 kW Size / weight: 16 t Specification: optional spaces right or left, and at the same time right and left / / 2-jobs broaching right or left / right and left at the same time
used
Internal Grinding Machine JOTES SOJ 10 Internal diameter100 mm Grinding depth 160 mm Swing diameter 300/450 mm Max. outer diameter 300/450 mm Weight of the machine ca.:2900 kg Almost unused.
used
Grinding diameter maximum: 0 mm Grinding diameter minimum: 0 mm Turning diameter: 0 mm Grinding depth: 0 mm CNC Brand: 0 CNC Model: 0 Control: GE FANUC Series 18i-T Operating hours: 2755 Technical data Number of axis total: 4 (X/Z/C/B) Number of spindles: 4 Max. grinding diameter: 350 mm Max. grinding depth: 350 mm Max.workpiece length + steady: 1300 mm Swing diameter: Above the workpiece table: 450 mm In front of the workpiece table: 680 mm Axial motion: Longitudinal travel (Z-axis): 500 mm Cross travel (x-axis): 200 mm Resolution: 0.0005 mm Rapid traverse Z: 20 m/min Rapid traverse X: 20 m/min Grinding spindle head: Swivelling range: -10 / + 30 ° Resolution: 2 ° Operating time: 2755 Hour Air connect: 5 bar Voltage 50 Hz 3x: 400 Volt Total power required: 20 kVA Machine´s weight about: 5000 kg Overall dimensions machine: Length: 3500 mm Width: 2700 mm Height: 2150 mm Various ac ...
used
Grinding diameter maximum: 0 mm Grinding diameter minimum: 0 mm Turning diameter: 0 mm Grinding depth: 0 mm CNC Brand: 0 CNC Model: 0 Control: FANUC Series Oi-TD Operating hours: 6000 Technical data Number of spindles: 4 Min. grinding diameter: 3 mm Max. grinding diameter: 200 mm Workpiece length max.: 600 mm Swing diameter: Above the workpiece table: 230 mm In front of the workpiece table: 350 mm Centre height: 130 mm Centre height over slide: 200 mm Axial motion: Longitudinal travel (Z-axis): 500 mm Cross travel (x-axis): 120 mm Spindle head (u axis): 150 mm Feed range: Z axis (longitudinal travel): 0 - 99.99 mm/min X axis (transversal): 0 - 99.99 mm/min Rapid traverse Z: 15 m/min Rapid traverse X: 5 m/min B axis swivelling range: -32 / + 2 ° Resolution: 0.0001 ° Grinding spindle head: Resolution: 0.001 Air connect: 5 bar Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 4.3 ...
used
Grinding diameter maximum: 0 mm Grinding diameter minimum: 0 mm Turning diameter: 0 mm Grinding depth: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Min. internal grinding diameter: 0.5 mm Max. internal grinding diameter: 25 mm Grinding depth: 100 mm Centre height: 125 mm Distance between centres: 160 mm Workpiece spindle speeds: number (steps): 3 from: 350 rpm up to: 750 rpm Spindle hole: 20 mm Grinding table travel: min.: 1 mm max: 100 mm spindle holder: B - 8 mm Table speeds: stepless up to: 5.00 m/min Voltage 50 Hz 3x: 380 Volt Machine´s weight about: 350 kg Overall dimensions machine: Length: 910 mm Width: 500 mm Height: 1600 mm Various accessories: Air spindle
used
Grinding diameter maximum: 0 mm Grinding diameter minimum: 0 mm Turning diameter: 0 mm Grinding depth: 0 mm CNC Brand: 0 CNC Model: 0 Control: Allen Bradley PanelView Plus 1000 Technical data Min. internal grinding diameter: 3 mm Max. internal grinding diameter: 50 mm Centre height: 240 mm Grinding spindle head: speeds: from: 350 rpm up to: 1200 rpm Overall dimensions machine: Length: 1700 mm Width: 1500 mm Height: 2300 mm Dimensions of the control: Length: 450 mm Width: 1000 mm Height: 2400 mm Various accessories: Touch screen Wheel trueing attachment Vibrating / oscillating conveyor Status light Loading attachment Parts catcher Switch cabinet Air conditioner
used
Grinding diameter maximum: 0 mm Grinding diameter minimum: 0 mm Turning diameter: 0 mm Grinding depth: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Min. internal grinding diameter: 0.8 mm Max. internal grinding diameter: 30 mm Grinding depth: 1 - 100 mm Centre height: 185 mm Distance between centres: 200 mm Workpiece spindle speeds: number (steps): 3 from: 550 rpm up to: 800 rpm Spindle hole: 20 mm Taper in spindle:: 25 W Grinding spindle speeds: from: 30000 rpm up to: 45000 rpm Grinding table travel: min.: 1 mm max: 100 mm Table speeds: stepless up to: 5 m/min Voltage 50 Hz 3x: 380 Volt Machine´s weight about: 610 kg Overall dimensions machine: Length: 1450 mm Width: 760 mm Height: 1600 mm Various accessories: Wheel trueing attachment Coolant system
used
Grinding diameter maximum: 0 mm Grinding diameter minimum: 0 mm Turning diameter: 0 mm Grinding depth: 0 mm CNC Brand: 0 CNC Model: 0 Control: SIEMENS SINUMERIK 840 D Technical data Min. grinding diameter: 5 mm Max. grinding diameter: 300 mm Max. grinding depth: 250 mm Max.workpiece length + steady: 1400 mm Axial motion: Longitudinal travel (Z-axis): 600 mm Work piece spindle head: speeds: from: 0 rpm up to: 1000 rpm Voltage 50 Hz 3x: 400 Volt Machine´s weight about: 3400 kg Overall dimensions machine: Length: 4350 mm Width: 1820 mm Height: 1860 mm Various accessories: Wheel trueing attachment Front grinding device redresser Coolant system Set of flanges for internal grinding Lamp Frontal grinding device Steady 3-jaw chuck diameter: (2x) 250 / 200 mm Internal grinding spindle:: ELECTRO number: 4 max. speed: VMS 40-5 40000 rpm max. speed: VMS 60-5 60000 rpm max. speed: VMS 15-5 15 ...
used
Control: SIEMENS SINUMERIK 3 G Technical data Distance between centres: 750 mm Centre height: 175 mm Axial motion: Longitudinal travel (Z-axis): 200 mm Cross travel (x-axis): 120 mm Max. axial speeds: Z axis (longitudinal travel): 0.0003 - 10000 mm/min Revolver grinding spindle head: Number of positions: 4 speeds: from: 45000 rpm from: 60000 rpm from: 80000 rpm Work piece spindle head: stepless from: 30 rpm up to: 750 rpm Spindle hole: 30 mm Voltage 50 Hz 3x: 400 Volt Grinding spindle motor: 4 kW Workpiece spindle motor: 2.2 kW Total power required: 17 kVA Machine´s weight about: 4300 kg Overall dimensions machine: Length: 4000 mm Width: 4000 mm Height: 2130 mm Various accessories: Wheel trueing attachment Coolant system Full splash cabin Door security attachment Internal grinding arbor Lamp Set bell collets: W 25 Quick closing attachment Macnetic chuck diameter: 230 mm Handwheel ...
used
Grinding diameter maximum: 105 mm Grinding diameter minimum: 2 mm Turning diameter: 0 mm Grinding depth: 1500 mm MACH-id 5409 MAKE HENNINGER KG Germany TYPE ZS 150 YOP 1988 SPECIFICATIONS External workpiece Ø Min. 5 Ø Min. External workpiece Ø Max. 105 Ø Max. Internal workpiece Ø Min. 2 Ø Min.Internal workpiece Ø Max. 90 Ø Max. Max. product length 1500 mm Speeds / ranges 24.000 Rpm Max. grinding angle 45 - 120 ° Max. workload weight 145 Kg DIMENSIONS Length 100 mm Width 700 mm Height 2200 mm
used
internal diameter: 120 mm grinding depth: 200 mm swing diameter: mm total power requirement: kW weight of the machine ca.: t CNC Internal Grinder w.2 Station Turret, Chuck The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Grinding diameter maximum: 0 mm Grinding diameter minimum: 0 mm Turning diameter: 0 mm Grinding depth: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Min. internal grinding diameter: 0.5 mm Max. internal grinding diameter: 15 mm Grinding depth: 75 mm Centre height: 60 mm Distance between centres: 125 mm Max. work piece diameter: 80 mm Workpiece spindle speeds: stepless from: 150 rpm up to: 1500 rpm Spindle hole: 12 mm Taper in spindle:: 12 W Possible grinding-spindle speeds: up to: 120000 rpm Grinding table travel: max: 225 mm Table speeds: stepless from: 1 m/min up to: 8 m/min Voltage 50 Hz 3x: 380 Volt Workpiece spindle motor: 0.3 kW Machine´s weight about: 570 kg Overall dimensions machine: Length: 1200 mm Width: 800 mm Height: 1400 mm Various accessories: Grinding wheel dressing device Frontal grinding device 3-jaw chuck diameter: 75 mm 3-jaw chuck diameter: 80 mm 4-jaw chuck d ...
used
Stock number: 3732 INTERNAL CYLINDRICAL GRINDING MACHINE Manufacturer: TRIPET HAUSER HTT CNC , Type: TST 100 CNC-4R Machine NO.: T1000256, Year of construction: 2002 Specifications: Grinding length 300 mm Size internal grinding diameter 0.5-75 mm Center height B axis- 130 mm C-ash main spindle 3" - 100 rpm degree Z ash 340 - 0.0005 mm mm B- Ashes Manuel -30/+60 degree X ash cross slide 50 mm Grinding spindle speeds 4 spindles - 25,000 - 45,000 2x 75000 rpm Resolution 0.0005 mm Tool spindle dock speeds B- axis 10-1500 rpm CNC control. Control Brüsch TPS 3000 Fabr. Accessories: Centering chuck PHM Heyn Pneumatic. 250 mm Ø Papir Filter Knoll Length: 2500 mm, Height: 2300 mm, Width: 2500 mm, Weight: 3500 kg
used
Internal machine only, 60000rpm and 90000rpm internal spindle. Producer MORARA Year 2005
used
JOTES SOH-10 internal grinding machine was built in Poland. The SOH10 grinding machine is used in the finishing process to give the right shape and surface roughness to holes with a diameter from 10 to 100 mm and conical holes with a maximum apex angle of 30°. The high-performance spindle machines workpieces with a maximum diameter of 300 mm (with guard) or 450 mm (without guard). The total weight of the machine is 2900 kg. Technical parameters of the JOTES SOH-10 internal grinding machine - minimum hole diameter: 10 mm - maximum hole diameter: 100 mm - maximum hole length: 160 mm - maximum diameter of grinded workpiece (with guard): 300 mm - maximum diameter of grinded workpiece (without guard): 450 mm - spindle rotation speed: 70-700 rpm - manual spindle feed (1 wheel revolution): 2,5 mm - largest spindle turning angle: 15° - lateral manual feed of spindle (forward): 50 m ...
used
Twist drill with internal cooling RWR SBV 11,65x70x12x118 ( SBV11,65x70x12x118 ) with internal cooling IA52187 Ø 11,65 mm shaft Ø 12 mm spiral length 70 mm Total length 118 mm New ! Dimensions: 125 x 17 x 17 mm
used
Internal measuring device, fine pointer Internal measuring device FEINMESSZEUGFABRIK SUHL 10 - 20 mm in wooden box Dimensions: 305 x 110 x 60 mm
used
Step drill with internal cooling GÜHRING diameter: Ø 25.0 x 14.5 x 17.0 mm solid carbide DK480UF Shank: Ø 25 mm with internal cooling ! New ! Dimensions: 120 x 25 x 25 mm
used
Step drill with internal cooling GESAU diameter: Ø 14.5 x 23.5 / 120° x 25 x 110 ( Ø14.5x23.5/120°x25x110 ) shank: Ø 25 mm with internal cooling ! New ! Dimensions: 110 x 25 x 25 mm
used
Step drill with internal cooling GÜHRING diameter: Ø 25.0 x 14.6 x 17.0 mm ( Ø25.0x14.6x17.0mm ) solid carbide DK480UF shank: Ø 25 mm with internal cooling ! sanded ! Dimensions: 120 x 25 x 25 mm
used
INTERNAL GRINDING MACHINE Make: Wotan Model: RJ 315 internal grinding diameter: 1100 mm external grinding diameter: 1200 mm Other info: The machine is in excellent condition and is complete in all its parts and accessories. In particular, this grinding machine is equipped with the following optionals: -Face grinding attachment -External grinding attachment -DRO
used
Ball valve internal thread -Internal thread: 2 -Full: passage, full ball -Number: 3x available -Price: per piece -Weight: 1 kg
used
Ball valve internal thread -Internal thread: 2 -Full: passage, full ball -Number: 24x available -Price: per piece -Weight: 1 kg
used
Ball valve internal thread -Internal thread: 2 -Full: passage, full ball -Number: 7x available -Price: per piece -Weight: 1 kg
used
Ball valve internal thread -Internal thread: 2 -Full: passage, full ball -Number: 5x available -Price: per piece -Weight: 3 kg
used
Ball valve internal thread -Internal thread: 2 -Full: passage, full ball -Number: 10x available -Price: per piece -Weight: 0.2 kg
used
Ball valve internal thread -Internal thread: 2 -Full passage, full ball -Number: 200 pieces in stock -Packaging unit: 12 pieces -1 box a: 84.00 euros -Price quoted: piece
used
Ball valve, ball valve, internal thread -Pressed brass -Internal thread: 2 inches -full: passage, full ball -Number: 63x ball valves available -Price: per piece -Weight: 2.1 kg
