internal grinding si used for sale

220627 Code Description Universal Cylindrical Grinder Make Jones - Shipman Model 1310 ( 8" x 18" ) Serial No. Year ? Grinding length, max. 450 mm Grinding diameter, max. 203 mm Center height 103 mm Weight workpiece kg Table tilting angle - 15 ° till + 15° Diam. Grinding wheel 350 mm Width Grinding wheel, max. 40 mm Motor power grindingwheel 1.5 kW Speeds Grindingwheel 1750 / 2300 rpm Speeds workpieceholder ( 6x ) 30 – 415 rpm Total power 3.5 kVA 380 Volts Machine size L x W x H 1.7 x 1.2 x 1.75 meters Weight 1800 kg Accessories internal grinding ( 10500-16500-24500 rpm ) coolant some tooling Condition Machine is in good condition

3-axis digital display Heidenhain Tip height 150 mm, Center width 680 mm Grinding length 620 mm Grinding wheel r/l 250 x 25x127 mm / 350 x 25x127 mm Spindle speed 12000 min-1 3-axis measuring system Internal grinding device Belt filter system Ultra-Precision Grinding Spindle

Studer S31 Spw.: 1000mm/ Sph.: 175mm Fanuc 16i- TB Control Commissioning 2004 Strokes X-axis 285mm/ Z-axis 1150mm Universal cylindrical grinding machine 2x external and 1x internal grinding

Cylindrical Grinder Model: FM41G-1600CNL45 New in 1988 Control: FM4 CNC Maker: Fortuna (Germany) Ser. No. 15674 Maximum grinding diameter: 275mm Maximum grinding length: 1600mm Additional measurement device

Tablе stroke 500 mm Max grinding depth 250 mm Grinding diameter 500 mm max (with water protection 450 mm) To sand bore diameter 300 mm Swivel range of the workpiece headstock 25 max Grindable cone angle 50 Rotational speed of the workpiece spindle U / MIN 20-400 Table speed infinitely einstallbar m / min 0.1-8

Machine overhaul , Repairs , On-site maintenance at the user's site , Spare parts supply , We specialize in the overhaul and repair of Kellenberger and Strausak universal grinding machines. We have the production and license rights of the company Strausak for the Type 57 U / W the resulting Special machines 82 S , multi-spindle fine milling machines, as well as CNC machines built from type 57 U / W We manufacture special machines especially for the ceramics and carbide industry.

In 2001 we acquired the license and production rights of Strausak. These rights include the entire 57 U / W conventional series as well as the CNC machines of the type U / W CNC in the tool grinding range 3 G / 4 G / 5 G as well as in the universal cylindrical grinding area, the 2 axes / 3 axes and 4 axes CNC machine and special machines 81 CNC. We have an extensive stock of spare parts. Our specialization is the general overhaul of these machines, as well as the new production of the above-mentioned machine types and the production of special machines.

Knuth RSM 1000 CNC B cylindrical grinding machine G-Plus in good condition from 2013 (commissioning 2014) with many accessories Grinding length: 1,000 mm Center height: 180 mm Outer grinding diameter: 8 - 320 mm Z-axis travel (outer): 1,000 mm Inner grinding diameter: 30 - 100 mm Z-axis travel (internal): 125 mm Weight piece: max. 150 kg Table swivel range: -7° ; +3° Table feed: 10 - 5,000 mm/min. Grinding spindle power: 5.5 kW Total engine power: 12.8 kW Weight: 5.3 t Complete operating instructions for the machine and programming (Knuth GPlus 450) Price plus VAT

Technische Daten Technical Data Center height 175 mm Grinding length 600 mm Speed Spindle / Spindle Speed 1500 rpm Grinding wheel 400x50x127 mm If you are interested in this machine, please contact us, we will be happy to send you a detailed offer If you are interested in this machine, please contact us and we will be pleased to send you a detailed offer

documentation: coolant: : internal diameter: mm serial number: 34253 weight of the machine ca.: 5,8 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

internal diameter: mm grinding depth: mm swing diameter:350 mm total power requirement: kW weight of the machine ca.:5 t dimensions of the machine ca.: m

total power requirement:16,5 kW weight of the machine ca.:3,8 t

internal diameter:315 mm grinding depth:315 mm swing diameter:420 mm number of spindle speeds:32 - 360 U-min wheel box:-drehzahl 100 - 8000 U/min face diameter:500 mm total power requirement:12 kW weight of the machine ca.:5900 kg dimensions of the machine ca.:3400 x 1750 x 2000 mm

internal diameter:250 mm swing diameter:455 mm workpiece length - max.:1200 mm table rotating:-4/+8 ° table speeds:0-4000 mm/min max. workpiece weight:80 kg workhead - center taper:5 MK Rotation speed of workhead :0 - 400 1/min workhead motor:4 kw 3-jaw chuck:250 (selbstschließend) mm grinding motor:4 kW coolant pump:2,2 kW Weight approx.:2,4 t machine dimensions:3200 x 2100 mm CNC controller:Siemens 840 D oder SPS von Siemens autom. sensing device for grinding wheel:Option linear scales and ballscrew:in allen Achsen face grinding attachement:Durchmesser 125 mm clamping chuck:250 (selbstschließend), 1 Satz harte Backen, 1 Satz weiche Backen, 1 Satz Innen mm frequency control main spindel engine:für die Innenschleifeinrichtung internal grinding spindle:RPM 28.000, diam. 60 mm. Min. diam. cap. 25 mm. x Bohrung 50 mm, Max. diam. cap. 100 mm. x Bohrung 115 mm . internal grinding spindle: ...

internal diameter:300 mm swing diameter:300/350 mm workpiece length - max.:2300 mm table rotating:-2/+6 ° table speeds:0-4000 mm/min max. workpiece weight:400 (fliegend, 150mm von der Spindelnase) kg workhead - center taper:6 MK Rotation speed of workhead :0 - 400 1/min workhead motor:4 kw 3-jaw chuck:250 (selbstschließend) mm grinding motor:11 kW coolant pump:2,2 kW CNC controller:Siemens 840 D oder SPS von Siemens autom. sensing device for grinding wheel:Option linear scales and ballscrew:in allen Achsen face grinding attachement:Durchmesser 125 mm clamping chuck:350 (selbst zentrierend) mm frequency control main spindel engine:für die Innenschleifeinrichtung internal grinding spindle:auf Anfrage internal grinding spindle:auf Anfrage fixed steady rests:10-100 mm, 100-170 mm PERFORMANCE AND PRECISION DEGREE Robbi grinding machines are according to the international precision normes ...

Internal circular grinding machine with plan grinding equipment, second-hand internal and face grinding machine, used Type / type: SI 6/1 x 315 Manufacturer / make: WMW Year / year of make: 1983 schleifbarer the protection of workpiece diameter / grinding diameter: inner / internal 20... 400 mm; outside / external 500 mm maximum workpiece diameter workpiece protection /. maximum diameter of work piece: 500 mm Max grinding depth / maximum grinding length: 315 mm schleifbarer angle of cone / cone grinding: 60 ° Internal grinding motor power / power drive motor grinding of internal: 7,5 kW Internal grinding spindle speeds / rev's of internal grinding spindle: 2640... 16500 RPM Power cylindrical grinding device / power drive of face grinding attachment: 4 kW Power work-piece motor / power drive of workpiece engine: 1.5 kW Workpiece spindle speeds / rev's piece of work s ...

internal diameter: 120 mm grinding depth: 200 mm swing diameter: mm total power requirement: 4 kW weight of the machine ca.: t dimensions of the machine ca.: m Grinding diameter, internal, max., approx. 3 - 120 mm Grinding depth, approx. 200 mm Height of centres above rotating workpiece slide 132 mm Max. swing Ø in front of rotating workpiece slide, approx. 450 mm Work spindle admission 40 mm Table stroke, max. (Z axis) 480 mm Workpiece cross adjustment (X axis) 50 mm Turret head cross adjustment (U axis) 50 mm Workspindle head swivelling (B axis) -30 / +45 ° (manual) Speeds of workspindle, infinitely variable 75 - 1,300 rpm Grinding spindle speeds 9,500 - 150,000 rpm Grinding spindle drive 4 kW Total electrical load, approx. 8 kW - 380 V - 50 Hz Weight, approx. 3,000 kg Accessories / Special Features TRIPET (Bruetsch) CNC Control for 3 axes (Z, X and U) with electric hand wheel, with ...

internal diameter: 20/300 mm grinding depth: 250 mm swing diameter: 250 mm workpiece spindle - bore: 45 mm workpiece spindle swivable +/-: 25 ° taper setting angle of the workpiece column: 50 ° work piece spindle speed: 42 - 400 U/min grinding spindle speed: 10.000 U/min table speed -stepless-: 0,1 - 8 m/min grinding spindle drive: 4 kW power capacity: 10 kW weight of the machine ca.: 4.500 kg dimensions of the machine ca.: m : : : : : Internal grinding Æ, min./max. 20 / 300 mm Grinding depth 500 mm Table stroke, min./max. 5 / 800 mm Height of centres above table 250 mm Swing Æ in the table recess 600 mm Workspindle bore 62 / 45 mm Swivability of workpiece wheelhead 25 ° Max. taper angle which can be ground 50 ° Infeed, per stroke 0.0025 - 0.5 mm Worksp ...

Internal grinding machine, internal grinding device, internal grinding spindle, drum grinding machine -Manufacturer: Paul Eugen Mayer, internal grinding machine type PMB -Drive motor: Hanning 1.1 kW / 2810 rpm -Grinding spindle: Ø 100 x 140 mm / see photos -Support table: pivoting -Total dimensions: 580/500/H1180 mm -Weight: 99 kg

High-performance grinding spindle, internal grinding machine, internal grinding device, internal grinding spindle -Grinding spindle: internal grinding spindle -Drive motor: BBC 1.5 kW / 2870 rpm -Max. Speed: rpm -Shaft axis: height 460 mm -Recording/Dimensions: see photos -Total dimensions: 730/400/H535 mm -Weight: 105 kg

internal diameter:100 mm grinding depth:160 mm swing diameter:300/450 mm centre height:290 mm max. outer diameter:300/450 mm work piece spindle speed:50-360/90-700 U/min weight of the machine ca.:2900 kg Machine size (LxWxH):2500x1750x1800 mm face grinding attachement:mit Schleifscheibe internal grinding spindle:DKF Typ SLA 60x400 mit 20.000 U/min grinding wheel dresser:auf Tisch 3 jaw chuck Ø:200 mm coolant system with magnet grate:und Wassertank frequency converter:f. stufenlose Spindeldrehzahl f. Innenschleifeinrichtung 100 % before loading warranty: none one used internal grinding machine, make: Jotes, type: SOJ 10M, year of produktion 1986

INTERNAL GRINDING MACHINE Make: Wotan Model: RJ 315 internal grinding diameter: 1100 mm external grinding diameter: 1200 mm Other info: The machine is in excellent condition and is complete in all its parts and accessories. In particular, this grinding machine is equipped with the following optionals: -Face grinding attachment -External grinding attachment -DRO

internal diameter:250 mm grinding depth:250 mm control:SINUMERIK 3 grinding diameter - min.:10 mm center height over grinding table:305 mm center height over floor:1140 mm x-axis:70 mm rapid traverse X-axis:1,50 m/min z-axis:550 mm rapid traverse Z-axis:15 m/min oscillation speed:0 - 10 m/min workpiece spindle swivable +/-:15 ° work piece spindle speed:50 - 10000 U/min spindle head:Gr. 6 / DIN 55021 spindle head:MK 6 face grinding slide:300 mm rapid traverse:7,50 m/min oscillation travel:Planschl. 300 mm oscillation speed:0 - 15 m/min grinding wheel size:500 x 203 x 30 mm weight of the machine ca.:8,00 t dimensions of the machine ca.:5,50 x 4,50 x H2,50 m Internal circular grinding machine CNC SIEMENS SINUMERIK 3 Control

Cylindrical grinding machine, external cylindrical grinding machine, internal cylindrical grinding machine, center grinding machine, center grinding machine -Max. Shaft Diameter: 320mm -Max. Grinding length: 345 mm - Chuck size: Ø 133 mm -Dimensions: 1925/1135/H1755 mm -Weight: 1592 kg -function tested

Stock number: 3732 INTERNAL CYLINDRICAL GRINDING MACHINE Manufacturer: TRIPET HAUSER HTT CNC , Type: TST 100 CNC-4R Machine NO.: T1000256, Year of construction: 2002 Specifications: Grinding length 300 mm Size internal grinding diameter 0.5-75 mm Center height B axis- 130 mm C-ash main spindle 3" - 100 rpm degree Z ash 340 - 0.0005 mm mm B- Ashes Manuel -30/+60 degree X ash cross slide 50 mm Grinding spindle speeds 4 spindles - 25,000 - 45,000 2x 75000 rpm Resolution 0.0005 mm Tool spindle dock speeds B- axis 10-1500 rpm CNC control. Control Brüsch TPS 3000 Fabr. Accessories: Centering chuck PHM Heyn Pneumatic. 250 mm Ø Papir Filter Knoll Length: 2500 mm, Height: 2300 mm, Width: 2500 mm, Weight: 3500 kg

JOTES SOH-10 internal grinding machine was built in Poland. The SOH10 grinding machine is used in the finishing process to give the right shape and surface roughness to holes with a diameter from 10 to 100 mm and conical holes with a maximum apex angle of 30°. The high-performance spindle machines workpieces with a maximum diameter of 300 mm (with guard) or 450 mm (without guard). The total weight of the machine is 2900 kg. Technical parameters of the JOTES SOH-10 internal grinding machine - minimum hole diameter: 10 mm - maximum hole diameter: 100 mm - maximum hole length: 160 mm - maximum diameter of grinded workpiece (with guard): 300 mm - maximum diameter of grinded workpiece (without guard): 450 mm - spindle rotation speed: 70-700 rpm - manual spindle feed (1 wheel revolution): 2,5 mm - largest spindle turning angle: 15° - lateral manual feed of spindle (forward): 50 m ...

Cylindrical grinding machine, external cylindrical grinding machine, internal cylindrical grinding machine, centering grinder, center grinder -Image below: MK5 -grinding wheel mount: -Motor data: 0.3 kW 1380 rpm -Dimensions: 370/180/H480 mm -Weight: 36 kg

Internal Grinding Machine JOTES SOJ 10 Internal diameter100 mm Grinding depth 160 mm Swing diameter 300/450 mm Max. outer diameter 300/450 mm Weight of the machine ca.:2900 kg Almost unused.

Description: Belt and internal grinding machine, oscillating, with several internal grinding inserts. Approx. Onsite Dimension. (l x w x h): 400 x 400 x 500 mm, weight approx.: 13,5 kg

WMW SI 4/1 Internal Grinding Machine YOM 52/1999 VEB Berliner Werkzeugmaschinenfabrik Grinding diameter 5-250 mm Max. grinding length 250 mm Max workpiece dia 370/450 mm (with/without safety cover) Spindle head speed 35-1400/min Work piece spindle speed 70-775 mm Max. table travel 560 mm Table speed stepless 0,5-6 m/min. Total power 16,5 kW Total Dimensions 3300x1440x2000 mm Machine 2200x1400x2000 mm Weight 4.8t.

Internal cylindrical grinding machine, Tripet Swiss, 1991, Grinding slide. 0.5 - 30mm, Grinding Depth: 50, Center Height: 102, Axes: Z , Y, U, B, V, , autom. Chuck...

Internal cylindrical grinding machine with flat grinding device, VOUMARD 404 N2X2/700, See pictures attached

FAG Internal grinding machine VH60

Internal grinding machine very good condition

Description: FANUC control system Two external and one internal grinding spindle Machine must be collected in mid-June 2024 Machine no.: 022.0102.90.017, max. travel of longitudinal slide: 1050 mm, max. speed of longitudinal slide: 10,000 mm/min, max. inclination of table: 8.5 degrees, max. travel of cross slide: 275 mm, max. speed of cross slide: 10,000 mm/min, max. workpiece weight between centres: 130 kg, max. quill travel 35 mm, , Approx. Onsite Dimension. (l x w x h): 1 x 1 x 1 mm, weight approx.: 1 kg

Spindle speed min: 9,000 Umd.min Max: 15.000 Umd.min Tip height min: 230 mm Max: 510 mm Spindle stroke: 210 mm Horiz. Table large: 700 x 1000 mm Table stroke: 1,800 mm Equipped with: - feed table - feed Hor. Grinding movement - coolant equipment - protection doors table

M 1105-02800 Machine type Cylindrical Grinding Machine - Universal Make ZIERSCH & BALTRUSCH Type URS 751 Built in 1982 Control type conventional Storage location HAGUENAU Country of origin Germany Delivery time immediately Freight base from stock Technical details Grinding diameter 270 mm Grinding length 1000 mm Tip height 135 mm Total power requirement 7.5 kW Machine weight approx. 2.8 t Room requirement approx. 3 X 2.7 X 2.5 m Information ZIERSCH & BALTRUSCH Hydraulic Universal ROUND SCHLEIFMASCHINR Type URS 751 1982 built _________________________________________________ Tip height 135 mm Tip width/grinding length 1000 mm Tip width approx. 1100 mm Grinding wheel size: Through. x Width 400 x 50 mm Grinding spindle speeds (belts) 1,800 2,200 rpm Delivery path/rapid path 0.001 / 30 mm Grinding wheels delivery 0.0 ...

internal diameter: 2 - 40 mm grinding depth: - mm swing diameter: 285 mm total power requirement: 5,5 kW weight of the machine ca.: 1,5 t dimensions of the machine ca.: m Max. Distance chuck flange - wheelhead 390 mm Accessories: Grinding spindle, make PRECISE 20.000 - 66.000 rpm, power 1.3 kW Grinding spindle, make PRECISE 60.000 - 120.000 rpm, power 0.23 kW magazine The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

internal diameter: 120 mm grinding depth: 200 mm swing diameter: mm total power requirement: kW weight of the machine ca.: t CNC Internal Grinder w.2 Station Turret, Chuck The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

internal diameter: 340/440 mm grinding depth: 9999999999999999999999999 mm swing diameter: mm grinding diameter: 250,350,450 mm grinding length: 600 mm centre height: 125,175,225 mm bore: 127 mm : MK5 work piece spindle speed: 20-400 U/min workpiece spindle - bore: mm grinding head swivelling: 360 ° grinding spindle head - swivable: 180 + - ° grinding spindle speed: 1500,1700,2200 U/min : 0,001-0,030 mm/Ø : 0-0,95 mm/Ø : ±10 ° longitudinal feed of the table: 900 mm table speeds: 0,02-6 m/min : 130 kg : 130 inkl. Spannugkg kg : mm : 70 mm total power requirement: 6,5 kW weight of the machine ca.: 2,2 t dimensions of the machine ca.: 3,1 x 2,0 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your machines.geometrical overh ...

Inner diameter: 150 mm Grinding depth: 200 mm Table lift: 425 mm large oscillating circuit diameter: 250 / 420 mm Bore: 80 mm Table speed -infinitely-0.5 - 10 m/min Workpiece speeds: 125/176/246/350 rpm Spindle speed: 17000 rpm Total power requirement: 2.2 / 0.5 / 0.9 kW Machine weight ca. 2 t Space requirement approx. 2.40 x 1.20 x 1.45 m Control: conventional

Inner diameter: 150 mm Grinding depth: 200 mm Table stroke: 425 mm gr. oscillating circuit diameter: 250 / 420 mm Bore: 80 mm Table speed -infinitely variable-0.5 - 10 m/min Workpiece speeds: 125/176/246/350 rpm Spindle speed: 17000 rpm Total power requirement: 2.2 / 0.5 / 0.9 kW Machine weight approx. 2 t Space requirement approx. 2.40 x 1.20 x 1.45 m Control: conventional

CNC Inene Grinding Machine with Automatic Loading Arm Year of construction : 2009 CNC 840 D Great Condition

grinding depth:418 mm total power requirement:13,6 kVA grinding length:1500 mm Grinding-wheel diameter:150 mm boring diameter:300 mm

The machine is in good technical condition, testing possible upon agreement. Revolving diameter mm 160 Center distance mm 250 Grinding wheel: diameter x hole x width mm 250 x 76 x 20 The largest width of the grinding wheel mm 40 Cone of the working spindle Morse 3 Cone in the tip socket of the tailstock Morse 2 Diameter of the three-jaw chuck mm 80 Rotation of the grinding spindle number of degrees 60 Rotation of the working spindle number of degrees 90 Rotation of the table on both sides number of degrees 10 Speed ​​of the grinding spindle min - 1 2420.3290 The largest longitudinal movement of the table mm 290 The smallest longitudinal movement of the table mm 1 Transverse movement of the grinding spindle mm 100 Quick adjustment of the grinding spindle mm 16 Total machine power kW 2.5 Maximum weight of the workpiece kg 10 Floor plan of the machine: length x width mm 1900 x 1100 Weig ...

With documentation, has been maintained regularly, an inspection is possible.

Connected load: 9.5kVA, was maintained regularly, an inspection is possible.

Max. grinding depth: 80mm, distance spindle table: 145mm, spindle bore: 28mm, connected load: 7kW, length: 2100mm, width: 1400mm, height: 950mm, weight: 1.6t, with documentation, an inspection is possible.

Description: Serial number 046, control FANUC 16 I-T, ,Machine number: 202552, max. sanding length: 200 mm, max. Z-axis travel: 500 mm, max. speed: 10,000 mm/min, max. X-axis travel: 120 mm, max. speed: 5,000 mm/min, fixed sanding spindle bore 120 mm, speed range: 0-1500 min, spindle clearance: 50 mm, spindle torque: 30 Nm, , Approx. Onsite Dimension. (l x w x h): 1 x 1 x 1 mm, weight approx.: 1 kg
