injection moulding machine used for sale

Clamping force [kN] 3500 Dimensions of mounting plates (hxv) [mm] 1060 x 1095 Clearance between columns (hxv) [mm] 710 x 710 min./ max. mold height [mm] min 380 Maximum opening width [mm] 1300 injection unit Screw diameter [mm] 50 Injection volume [cm3] 432 Injection weight [g] 393 Injection pressure [bar] 2304 Electric-hydraulic equipment Pump motor rated power [kW] 75 Dimensions and weight Net weight with control cabinet [t] 15.5 Dimensions (L x W x H) [m] 6.79 x 2.17 x 2.25

Clamping force [kN] 1100 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 min./ max. mold height [mm] min 300 Maximum opening width [mm] 900 Injection unit Screw diameter [mm] 45 Injection volume [cm3] 275 Injection weight [g] 250 Injection pressure [bar] 1878 Electric-hydraulic equipment Rated power of the pump motor [kW] 18.5 Heater power [kW] 13 Dimensions and weight Net weight with control cabinet [t] 6 Dimensions (length x width x height) [m] 4.48 x 1.51 x 2.19

Krauss Maffei KM 160-750 CX Clamping/injection matrix Clamping force [kN] 1600 Mounting plate dimensions (hxv) [mm] 820 x 845 Clearance between columns (hxv) [mm] 520 x 520 Min./max. mold height [mm] min 300 mm Maximum opening width [mm] 950 Injection unit Screw diameter [mm] 50 Injection volume [cm3] 393 Shot weight [g] 357 Injection pressure [bar] 1892 Electro-hydraulic equipment Power rating of the pump motor [kW] 22 Power rating of barrel heating [kW] 10,97 Dimensions and weight (approximately) Net weight with control cabinet [t] 6 Dimensions (L x W x H) [m] 4,6 x 1,6 x 2,1

Closing unit Clamping force [kN] 1100 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 Min./max. mold height [mm] min 300 Injection unit Screw diameter [mm] 50 Injection volume [cm3] 393 Injection weight [g] 358 Injection pressure [bar] 358 Dimensions and weight Net weight with control cabinet [t] 7.8 Dimensions (length x width x height) [m] 5.0 x 1.6 x 2.0

Closing unit Clamping force [kN] 1100 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 Min./max. mold height [mm] min 300 Maximum opening width [mm] 900 Injection unit Screw diameter [mm] 45 Injection volume [cm3] 275 Injection weight [g] 250 Injection pressure [bar] 1878 Electrical and hydraulic equipment Rated power of the pump motor [kW] 18.5 Heater power [kW] 13 Dimensions and weight Net weight with control cabinet [t] 6 Dimensions (length x width x height) [m] 4.48 x 1.51 x 2.19 Additional equipment: Single-phase plastic feeder Picker

Demag Ergotech Compact 1500-610 Clamping/injection matrix Clamping force [kN] 1500 Mounting plate dimensions (hxv) [mm] 750 x 750 Clearance between columns (hxv) [mm] 500 x 500 Injection unit Screw diameter [mm] 50 Shot weight [g] 330 Injection pressure [bar] 1973 Dimensions and weight (approximately) Net weight with control cabinet [t] 7 Dimensions (L x W x H) [m] 5.20x1.60x2.10

Closing unit Clamping force [kN] 1300 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 Min./max. mold height [mm] min 300 Injection unit Screw diameter [mm] 55 Injection volume [cm3] 475 Injection weight [g] 432 Injection pressure [bar] 1564 Dimensions and weight Net weight with control cabinet [t] 7.8 Dimensions (length x width x height) [m] 5.0 x 1.6 x 2.0

Clamping/injection matrix Clamping force [kN] 3500 Mounting plate dimensions (hxv) [mm] 1060 x 1095 Clearance between columns (hxv) [mm] 710 x 710 Min./max. mold height [mm] min 380 Maximum opening width [mm] 1300 Injection unit Screw diameter [mm] 50 Injection volume [cm3] 432 Shot weight [g] 393 Injection pressure [bar] 2304 Electro-hydraulic equipment Power rating of the pump motor [kW] 75 Dimensions and weight (approximately) Net weight with control cabinet [t] 15,5 Dimensions (L x W x H) [m] 6,79 x 2,17 x 2,25

Clamping force [kN] 3500 Clearance between columns (hxv) [mm] 730 x 730 Injection unit Screw diameter [mm] 62 Injection volume [cm3] 749 Shot weight [g] 718 Injection pressure [bar] 2400 Dimensions and weight (approximately) Net weight with control cabinet [t] 23,5

Krauss Maffei KM 160-380 CX Clamping/injection matrix Clamping force [kN] 1600 Mounting plate dimensions (hxv) [mm] 820 x 845 Clearance between columns (hxv) [mm] 520 x 520 Min./max. mold height [mm] min 300 mm Maximum opening width [mm] 1250 Injection unit Screw diameter [mm] 40 Injection volume [cm3] 201 Shot weight [g] 183 Injection pressure [bar] 1860 Electro-hydraulic equipment Power rating of the pump motor [kW] 22 Power rating of barrel heating [kW] 10,97 Dimensions and weight (approximately) Net weight with control cabinet [t] 6 Dimensions (L x W x H) [m] m 4,6 x 1,6 x 2,1

Closing unit Clamping force [kN] 8000 Dimensions of mounting plates (hxv) [mm] 1610 x 1530 Clearance between columns (hxv) [mm] 1120 x 1000 Min./max. mold height [mm] min 600 Maximum opening width [mm] 2000 Injection unit Screw diameter [mm] 95 Injection volume [cm3] 3367 Injection weight [g] 3064 Injection pressure [bar] 1795 Electrical and hydraulic equipment Rated power of the pump motor [kW] 90 Heater power [kW] 61 Dimensions and weight Net weight with control cabinet [t] 55 Dimensions (length x width x height) [m] 10.5 x 2.65 x 2.4 Hydraulic auger drive with permanent motor (with torque limitation in the upper speed range). The screw drive is adjustable on the monitor screen. For independent and parallel plasticization when opening and closing the mold, a screw drive with an electric motor or a second pump unit is used Single pneumatic valve on movable mold mou ...

Demag System 650/1000-6400 Closing unit Clamping force [kN] 6500 Dimensions of mounting plates (hxv) [mm] 1450 x 1350 Clearance between columns (hxv) [mm] 1000 x 900 Min./max. mold height [mm] 450 - 950 Maximum opening width [mm] 1880 Injection unit Screw diameter [mm] 95 Injection volume [cm3] 3367 Injection weight [g] 3060 Injection pressure [bar] 1895 Dimensions and weight Net weight with control cabinet [t] 33.5 Dimensions (length x width x height) [m] 11 X 2.5 X 2.6

Engel Victory 310-60 Electric Closing unit Clamping force [kN] 600 Dimensions of mounting plates (hxv) [mm] 720 x 600 Injection unit Screw diameter [mm] 35 Injection volume [cm3] 154 Injection weight [g] 140 Injection pressure [bar] 2400 Dimensions and weight Net weight with control cabinet [t] 5.7 Dimensions (length x width x height) [m] 4.7 x 1.4 x 2.7 Number of heating zones: 4 Hydraulic core 2x; 1x air valve; EUROMAP 12 interface

Important Note: The following description provides additional technical details about the Battenfeld TM 1300/525 M Injection Molding Machine beyond the core offer. This information is intended to assist buyers in making an informed decision. Core Offer: For professionals seeking a reliable injection molding machine, the Battenfeld TM 1300/525 M offers exceptional performance. Its specifications include: Clamping Force: 1300 kN Mounting Plate Dimensions (hxv): 670 x 670 mm Clearance Between Columns (hxv): 470 x 470 mm Min./Max. Mold Height: 225-500 mm Maximum Opening Width: 930 mm Injection Unit: Screw Diameter: 40 mm Injection Volume: 251 ccm Injection Weight: 228 g Injection Pressure: 2100 bar Electrical and Hydraulic Equipment: Rated Power of the Pump Motor: 18.5 kW Heater Power: 12.1 kW Dimensions (L x W x H): 4.9m x 1.33m x 2m Net Weight with Control Cabinet: 4.8 ...

Closing unit Clamping force [kN] 1100 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 Min./max. mold height [mm] min 300 Injection unit Screw diameter [mm] 50 Injection volume [cm3] 393 Injection weight [g] 358 Injection pressure [bar] 1892 Dimensions and weight Net weight with control cabinet [t] 7.8 Dimensions (length x width x height) [m] 5.0 x 1.6 x 2.0

Battenfeld TM 3500 / 1900 Closing unit Clamping force [kN] 3500 Dimensions of mounting plates (hxv) [mm] 1010 x 1010 Clearance between columns (hxv) [mm] 710 x 710 Min./max. mold height [mm] 300-710 Maximum opening width [mm] 1380 Injection unit Screw diameter [mm] 65 Injection volume [cm3] 1078 Injection weight [g] 981 Injection pressure [bar] 1777 Dimensions and weight Net weight with control cabinet [t] 15.2 Dimensions (L x W x H) [m] 7.60 x 1.80 x 2.40

Closing unit Clamping force [kN] 1300 Dimensions of mounting plates (hxv) [mm] 745 x 770 Clearance between columns (hxv) [mm] 470 x 470 Min./max. mold height [mm] min 300 Injection unit Screw diameter [mm] 55 Injection volume [cm3] 475 Injection weight [g] 432 Injection pressure [bar] 1564 Dimensions and weight Net weight with control cabinet [t] 7.8 Dimensions (length x width x height) [m] 5.0 x 1.6 x 2.0

Closing unit Clamping force [kN] 4200 Dimensions of mounting plates (hxv) [mm] 1200 x 1100 Clearance between columns (hxv) [mm] 870 x 710 Min./max. mold height [mm] 380/820 Maximum opening width [mm] 1530 Injection unit Screw diameter [mm] 60 Injection volume [cm3] 763 Injection weight [g] 690 Injection pressure [bar] 1905 Electrical and hydraulic equipment Rated power of the pump motor [kW] 45 Heater power [kW] 23 Dimensions and weight Net weight with control cabinet [t] 20 Dimensions (length x width x height) [m] 7.9 x 2.2 x 2.5

Krauss Maffei KM 450-3500 C3 Closing unit Clamping force [kN] 4500 Dimensions of mounting plates (hxv) [mm] 1270 x 1200 Clearance between columns (hxv) [mm] 900 x 800 Min./max. mold height [mm] min 480 Maximum opening width [mm] 1650 Injection unit Screw diameter [mm] 90 Injection volume [cm3] 1953 Injection weight [g] 1777 Injection pressure [bar] 1742 Electrical and hydraulic equipment Rated power of the pump motor [kW] 90 Heater power [kW] 59 Dimensions and weight Net weight with control cabinet [t] 26.3 Dimensions (length x width x height) [m] 7.98 x 2.35 x 2.51m Pressure tank for increased injection power. The screw is driven by an electric motor Air core Hydraulic core 10 x rotameters Euromap 67

Krauss Maffei KM650-5700CM Closing unit Clamping force [kN] 6500 Dimensions of mounting plates (hxv) [mm] 1550 X 1440 Clearance between columns (hxv) [mm] 1000 X 930 Min./max. mold height [mm] min 600 Maximum opening width [mm] 1750 Injection unit Screw diameter [mm] 95 Injection volume [cm3] 2956 Injection weight [g] 2111 Injection pressure [bar] 1795 Electrical and hydraulic equipment Rated power of the pump motor [kW] 110 Heater power [kW] 59 Dimensions and weight Net weight with control cabinet [t] 39.5 Dimensions (L x W x H) [m] 9.36 x 2.65 x 2.43

Clamping/injection matrix Clamping force [kN] 5000 Mounting plate dimensions (hxv) [mm] 1270 x 1310 Clearance between columns (hxv) [mm] 900 x 800 Min./max. mold height [mm] min 480 Maximum opening width [mm] 1650 Injection unit Screw diameter [mm] 80 Injection volume [cm3] 1543 Shot weight [g] 1404 Injection pressure [bar] 2205 Electro-hydraulic equipment Power rating of the pump motor [kW] 90 Power rating of barrel heating [kW] 44 Dimensions and weight (approximately) Net weight with control cabinet [t] 7.9 Dimensions (L x W x H) [m] 7,65 m x 2,55 m x 2,55 m

Clamping force [kN] 3000 Dimensions of mounting plates (hxv) [mm] 995x1050 Clearance between columns (hxv) [mm] 630x630 Min./max. mold height [mm] min 330 Maximum opening width [mm] 1150 Injection unit Screw diameter [mm] 55 Injection volume [cm3] 523 Injection weight [g] 476 Injection pressure [bar] 1904 Dimensions and weight Net weight with control cabinet [t] 12.5 Dimensions (length x width x height) [m] 5.97 x 2.04 x 2.36

Closing unit Clamping force [kN] 500 Dimensions of mounting plates (hxv) [mm] 490 x 440 Clearance between columns (hxv) [mm] 370 x 320 Min./max. mold height [mm] 150 - 450 Maximum opening width [mm] 750 Injection unit Screw diameter [mm] 22 Injection volume [cm3] 38 Injection weight [g] 35 Injection pressure [bar] 2500 Electrical and hydraulic equipment Rated power of the pump motor [kW] 6.1 Heater power [kW] 6.3 Dimensions and weight Net weight with control cabinet [t] 4 Dimensions (length x width x height) [m] 4.2 x 1.44 x 1.85

Closing unit Clamping force [kN] 1200 Dimensions of mounting plates (hxv) [mm] 640 x 590 Clearance between columns (hxv) [mm] 470 x 420 Min./max. mold height [mm] 180 - 550 Maximum opening width [mm] 950 Injection unit Screw diameter [mm] 40 Injection volume [cm3] 201 Injection weight [g] 183 Injection pressure [bar] 1860 Electrical and hydraulic equipment Rated power of the pump motor [kW] 13.8 Heater power [kW] 11.5 Dimensions and weight Net weight with control cabinet [t] 6.9 Dimensions (length x width x height) [m] 5.3 x 1.6 x 1.88

Brand NETSTAL Type Synergy 1000-230 Year of manufacture 2005 Clamping unit Clamping force 100 ton Opening stroke 400 mm Beam dimension (h x v) 460 x 460 mm Installation height min. 250 mm Installation height max. 550 mm Injection unit Screw diameter 35 mm Injection volume 123 cm³ Injection weight PS 118 gr Injection pressure 1890 bar Dimensions and weights Dimensions LxWxH 5,4 x 1,85 x 2,0 m Machine weight 7600 kg Additional information & extras Valve gate 3 pcs.

Producer DEMAG Type Ergotech pro 50-270 Year 1997 Clamping unit Clamping force 50 ton Opening stroke 400 mm Distance between tie bars 355 x 355 mm Mould height min. 210 mm Platen size (h x v) 540 x 540 mm Injection unit Screw diameter 35 mm Injection volume 106 cm³ Shot weight 95 g Injection pressure 2573 bar Measurements and weight Dimensions 3,65 x 1,15 x 1,18 m Machine weight 3600-2500 kg

Producer Battenfeld Type 25/50 Unilog B2 Year 2006 Clamping unit Clamping force 25 ton Opening stroke 450 mm Distance between tie bars 270 X 270 mm Mould height min. 150 mm Injection unit Screw diameter 14 mm Injection volume 15 cm³ Shot weight 7 g Injection pressure 2650 bar Measurements and weight Dimensions 2,25 X 0,90 X 1,30 m Machine weight 1100 kg

Producer Engel Type Victory 750 / 180 tech Year 2004 Clamping unit Clamping force 180 ton Opening stroke 750 mm Distance between tie bars 960 x830 mm Mould height min. 500 mm Opening width 1250 mm Injection unit Screw diameter 45 mm Injection volume 318 cm³ Shot weight 302 g Injection pressure 1769/2360 bar Measurements and weight Machine weight 13500 kg Robot Producer Wittman Type W743 Year 2009

Brand BILLION Type H 80-50 Select Year of manufacture 2011 Clamping unit clamping force 50 ton Opening stroke 250 mm Beam dimension (h x v) 350 x 300 mm Installation height min. 150 mm Installation height max. 400 mm Platen size (h x v) 490 x 440 mm Injection unit Screw diameter 25 mm Injection volume 39 cm³ Injection weight PS 35 gr Injection pressure 2040 bar Dimensions and weights Dimensions LxWxH 3,7 x 1,4 x 1,8 m Machine weight 3200 Kg Additional information & extras Hot runner 6 pcs.

Producer DEMAG Type intElect 50/330-100 NC4 All electric Year 2009 Clamping unit Clamping force 50 ton Opening stroke 260 mm Distance between tie bars 330 x 330 mm Mould height min. 150 mm Mould height max. 350 mm Platen size (h x v) 500 x 490 mm Injection unit Screw diameter 25 mm Injection volume 51 cm³ Shot weight 46 g Injection pressure 2005 bar Measurements and weight Dimensions 3,97 x 1,19 x 2,21 m Machine weight 3300 kg Additional Information: 1 Anguß-Picker Fa. Wittmann W702 year 2008

Producer Engel Type Victory 1350/300 Tech Year 2004 Clamping unit Clamping force 300 ton Opening stroke 900 mm Distance between tie bars 1100 x 1000 mm Mould height min. 400 mm Opening width 1300 mm Platen size (h x v) 1100 X 1000 mm Injection unit Screw diameter 55 mm Injection volume 617 cm³ Shot weight 588 g Injection pressure 1760/2180 bar Measurements and weight Machine weight 19400 kg Robot Producer Wittman Type W843 Year 2015

Producer DEMAG Type 150 /500-610 NC 4 System Year 2005 Clamping unit Clamping force 150 ton Opening stroke 450 mm Distance between tie bars 560 x 460 mm Mould height min. 230 mm Mould height max. 460 mm Platen size (h x v) 690 x 660 mm Injection unit Screw diameter 45 mm Injection volume 323 cm³ Shot weight 29ß g Injection pressure 1973 bar Measurements and weight Dimensions 4,95 x 1,50 x 2,3 m Machine weight 7500 kg Robot Producer Witmann Type W621 Year 2004

Type of control: SELOGICA Closing force: 150 T Between columns: 470 x 470 mm Injection: Screw diameter: 60 mm Bars: 2000 General: Motor power: 45 kW Heating power: 25.9 kW Closing weight: 12 Tons Injection weight: Dimensions length: 7m Width dimensions: 1.70m Dimensions height: 2.2m Options: Cores: 2 Robot interface: yes Bi metal: yes

Closing force: 150 T Between columns: 570 x 570 mm Injection: Screw diameter: 60 mm Bars: 2000 General: Motor power: 45 kW Heating power: 25.9 kW Closing weight: 12 Tons Injection weight: Dimensions length: 7m Width dimensions: 1.70m Dimensions height: 2.2m Options: Cores: 2 Robot interface: yes Bi metal: yes

Injection unit Screw diameter: 80 mm Calculated injection volume: 1608 cm3 Length/diameter ratio: 27 L/D Pressure on the material: 2400 bars Closing unit Closing force: 5000 kN Opening stroke: 901 mm Minimum mold thickness: 600 mm Passage between columns: 1020 x 920 mm General Heating power: 132 kW Other Equipment : Commissioned: 2010 Number of hours: 7000 h Tonnage: 500

Injection unit Screw diameter: 35 mm Calculated injection volume: 170 cm3 Length/diameter ratio: 20 L/D Material pressure: 2100 bar Screw speed: 320 RPM Closing unit Closing force : 1600 kN Opening stroke: 460 mm Min. mold thickness: 170 mm Distance between tie-bars: 510 x 450 mm Platen dimensions: 780 x 730 mm General Heating power: 18 kW Total installed power: 28 kW Dimensions : 5.3 x 2.1 x 1.5 m Weight : 6000 Kg Other Equipment : From 10/2002 Commissioning : 2002 Tonnage: 160

Injection unit Screw diameter: 35 mm Calculated injection volume: 170 cm3 Length/diameter ratio: 20 L/D Material pressure: 2100 bar Nb Temperature zone : 3 N Closing unit Closing force : 1600 kN Opening stroke: 460 mm Min. mold thickness: 170 mm Distance between tie-bars: 510 x 450 mm Platen dimensions: 780 x 730 mm General Heating power: 18 kW Total installed power: 28 kW Dimensions : 5.3 x 2.1 x 1.5 m Weight : 6000 Kg Other Equipment : From 10/2000 Commissioning : 2000 Tonnage: 160

Injection unit Screw diameter: 40 mm Calculated injection volume: 285 cm3 Length/diameter ratio: 20 L/D Material pressure: 2100 bar Screw speed: 320 RPM Nb Temperature zone : 3 N Closing unit Closing force: 2100 kN Opening stroke: 540 mm Min. mold thickness: 200 mm Distance between tie-bars: 570 x 510 mm Platen dimensions: 870 x 790 mm General Heating capacity: 22 kW Total installed power: 35 kW Dimensions : 6 x 2.2 x 1.6 m Weight : 8200 Kg Other Equipment : From 07/2005 Commissioning : 2005 Tonnage: 210

Clamping force [kN] 500 Dimensions of mounting plates (hxv) [mm] 600 x 600 Clearance between columns (hxv) [mm] 370x370 Min./max. mold height [mm] min 200 Maximum opening width [mm] 600 Injection unit Screw diameter [mm] thirty Injection volume [cm3] 85 Injection weight [g] 77 Injection pressure [bar] 2025 Electrical and hydraulic equipment Rated power of the pump motor [kW] 11 Heater power [kW] 8 Dimensions and weight Net weight with control cabinet [t] 2.65 Dimensions (length x width x height) [m] 3.53 x 1.42 x 1.96

unknow A9020411 (12-14)-

Operator Panel

unknow GE.570205.0002.00, part of the set-

Main Rack

BARCO HULPFUNCTIE 16 DIG OUTP

BARCO FLOPamp;KBRD INTF MNC95

CAP.: 10 000 BTLS/H OF 1.5 L,

automatic CUTTING BORING and MOULDING machine BACCI TTF1 2TM . second hand machine working conditions : Excellent hydraulic drive of all the movements volt. 380/50 CE mark : YES Machine suitable for assembling part of chairs, tables, frames, furniture, wheelchair frames, etc. The BACCI TTF1 2TM performs the operations of cutting , milling and drilling at the end of the piece, either singularly or differently combined . the milling unit is composed of n.02 spindle moulders ( anti-splinter system ) machine composed by 3 working units : 1- Cutting unit : circular saw max.diam. mm.400 motor power Hp 3 2- Boring unit : boring head with 5 mandrins motor power Hp 3 3- Moulding unit . with automatic movement of the carriage on recirculating ball bearings n.02 spindle moulders (anti-splinter) motor power Hp 7,5 spindle diam. mm.35 hydraulic unit motor power Hp 2

AUTOMATIC CUTTING , BORING and MOULDING machine type PADE 1000 N Machine suitable for assembling part of chairs, tables, frames, small furniture, wheelchair frames, etc. The PADE 1000 N performs the operations of Cutting , milling and drilling at the end of the piece, either singularly or differently combined. All movements of the machine are controlled by pneumatic devices. composed by 3 working units : 1- Cutting unit circular saw diam. mm.350 motor power hp 3 2- Boring unit boring head with 5 / 7 mandrins motor power Hp 3 max. working stroke of boring unit mm. 130 3- Moulding unit vertical spindle for moulder motor power Hp 5,5 spindle diam. mm.30 pneumatic sliding carriage volt. 380/50

The list of equipment for sale from molding line: 1. Moulding Machine HSP-2D (22kW, 70f / h) 2. Lifting table 3. Pressure plate 4. The dispensing sand tank
