injection moulding machine used for sale

Description Machine available from February 2022.

Description magnetic planes

Description ROTARY TABLE DIAMETER 1500mm MAXIMUM MOLD DIMENSION 400X400mm

Description Rotating Table Diameter: 1000 Table positions: 2 Hot channels: 8

Description SILICONE PRESS Complete with REINHARDT-TECHNIK LSR 200 silicone pumping unit year 1998

Description 13 zone mold heating working hours: 3447

Description MANY LANGUAGES AVAILABLE

Description MAXIMUM MOLD DIMENSION 400X400mm MINIMUM ACTUAL MOLD THICKNESS 320mm MAXIMUM ACTUAL MOLD THICKNESS 479mm 2 WARM ROOMS 2 PNEUMATIC JACKS

Description MANY LANGUAGES AVAILABLE

Description increased floor

Description Rubber molding machine Working hours: 18.000

Description Rubber molding machine Working hours: 27.000

Description Rubber molding machine Working hours: 27.000

Description E 67 robot interface external control unit for hydraulic radials (2 radials)

Description mold holder planes 740 X 680 New screw and barrell Sprue removal robot ENGEL mod. ER-USP 5 year:2006 pieces falling chute with waste selector

Description working hours: 23.000h

EMS-95 single-screw extruder, screw diameter 90mm, throughput approx. 200 kg/h (depending on profile size and material may vary). The output width is about 127 cm. Initially purchased for the production of diffusers of all kinds (transparent, partially transparent) for office LED lighting fixtures. Installed in 2012, produced about 1.500 diffusers and has not been used since then

We have an injection molding system for sale • Netstal Synergy 3500-2700Ε year 2007 machine • incl. Closing Mold 72Cavity 29/25 cap 1.32gr.with /3,5sec. cycle /year 2016 Plastisud • Hot runner year 2016 Plastisud • Controller Custom made • Belts • Packaging unit 5-1-5 The machine is in production in Greece until the end of March 2024 and will be available for sale in May 2024.

Manufacturer: Negri Bossi Model: 160T V 160 – H 820 Year of manufacture: 2005 INJECTION UNIT Screw diameter: 52 mm Calculated injection volume: 480 cm³. Length/diameter ratio: 20 L/D Maximum injection rate: 220 cm³/s Pressure on the material : 1700 bars Screw speed : 250 rpm Number of temperature zones : 4 N CLOSING UNIT Closing force : 1600 kN Opening stroke : 460 mm Thickness of the mould : 170-550 mm Distance between tie-bars: 510 x 450 mm Plates size : 780 x 730 mm GENERAL Heating power : 18 kW Total installed power: 31 kW Dimension : (WxHxD) 5720 x 2150 x 1500 mm. Weight : 6150 Kg

Type of control: SELOGICA Number of hours: 38,000 hours Closing force: 200T Opening stroke: 650mm Between columns: 570 x 570 mm Tray dimensions: 795 x 795mm Mini/maxi mold: 250 mm Max distance between trays: 1400 mm Injection: Screw diameter: 50 mm Screw length: 20D cm3: 392 Bars: 2000 General: Motor power: 19.9 kW Heating power: 8kw Closing weight: 9T Injection weight: Length dimensions: 5.50 m Width dimensions: 2 m Dimensions height: 2.40 m Options: Cores: 1 Robot interface: yes Bi metal: yes

Screw diameter: 40 mm Calculated injection volume: 220 cm³ Length/diameter ratio: 23.5 L/D Maximum injection rate: 251 cm³/s Pressure on the material: 2030 bars Plastification capacity PS: Kg/h Screw Speed: 175 RPM Hydraulic motor torque: Nm Hydraulic motor power: HP Nb Temperature zones: N CLOSING UNIT Closing force: 1000 kN Opening stroke: 175 mm Min/Max Mold Thickness: mm Max distance between tray: mm Passage between columns: 445 x 445 mm Dimensions of the trays: 630 x 630 mm GENERAL Heating power: kW Total installed power: kW Quantity of oil: l. Dimension: (WxHxD) 5.3 x 1.8 x 1.35 m. Weight: 5230 Kg

Screw diameter: 70 mm Calculated injection volume: 1355 cm³ Length/diameter ratio: 20 L/D Pressure on the material: 1959 bars Plasticizing capacity PS: 57 Kg/h Screw Speed: 177 RPM Hydraulic motor torque: 3181 Nm Hydraulic motor power: HP Nb Temperature zones: 4 + 1 N CLOSING UNIT Closing force: 4850 kN Opening stroke: 830 mm Mini /Max Mold Thickness: 250-850 mm Max distance between tray: mm Passage between columns: 740 x 740 mm Dimensions of the trays: 1120 x 1120 mm GENERAL Heating power: 45 kW Total installed power: 68.2 kW

DEMAG Ergotech compact 1500/610 Order: NC4 Closing force: 150 T - 1500 KN Distance between columns: 500 x 500 mm Tray dimensions: 790 x 790 mm Min / max mold thickness: 250 - 560 mm Injectable volume: 323 cm3 Material pressure: 1973 bars Screw diameter: 45 mm L/D ratio: 20 Weight: 6700 kg Dimensions: 5.20 x 2.10 x 1.50 m

Number of hours: 45,000 hours Closing force: 40 T Opening stroke: 200 mm Between columns: 270 x 270 mm Tray dimensions: 380 x 380 mm Mini/maxi mold: 150/350 mm Max distance between trays: 550 mm Injection: Screw diameter: 18 mm Screw length: 24.5/D cm3: 23 Bars: 2500 General: Motor power: 11 kW Heating power: 4.1 kW Closing weight: 1.5 Tons Injection weight: Dimensions length: 3 m Width dimensions: 1m Dimensions height: 1.6 m Options: Cores: Robot interface: YES Bi metal: YES

Screw diameter: 40 mm Calculated injection volume: 217 cm³ Length/diameter ratio: 23 L/D Pressure on the material: 2377 bars Nb Temperature zones: 5 N CLOSING UNIT Closing force: 1500 kN GENERAL Heating power: 13 kW Total installed power: 22 kW Oil quantity: 345 l. Dimension: (WxHxD) 4.47 x 2.19 x 1.51 m. Weight: 6400 Kg

Year: 2008 Type of control: DIXIT II Number of hours: 21800 Place of storage: FRANCE Timeframe: AVAILABLE Closing Closing force: 320 T Opening stroke: 660 mm Between columns: 735 x 735 mm Tray dimensions: 1045 x 1045 mm Mini / maxi mold: 330 x 680 mm Max gap between trays: 1340 mm Injection: Diameter of the screw: 75 mm Length of the screw: 21.50 D cm3: 1259 Bars: 1600 Generalities Engine power: 75 kw Heating power: 27 kw Closing weight: 17 tons Injection weight: Dimensions length: 7.60 m Dimensions width: 2.10 m Dimensions height: 2.60 m Options: Cores: 2 Robot interface: yes Bi metal: yes Accus: yes Blowers: Others:

SANDRETTO series 7 1960/350 Clamping force: 350 T - 3500 KN Distance between columns: 600 x 600 mm Dimensions of the trays: 910 x 910 mm Minimum/maxi thickness of the mold: 200 - 650 mm Opening stroke: 600 mm Volume injected: 1347 cm3 Material pressure: 1450 bars Screw diameter: 70 mm Heating power: 23 KW Weight: 14,500 kg Mounted mixing screw + std screw + one-piece screw

Control type: NC 4 Number of hours: 38,000 hours Closing force: 420 T Opening stroke: 710 mm Between columns: 800 x 710 mm Tray dimensions: 1200 x 1100 mm Mini/maxi mold: 380/820 mm Max distance between trays: 1530 mm Injection: Screw diameter: 60 mm Screw length: 20D cm3: 763 Bars: 1905 General: Motor power: 45 kW Heating power: 23.1 kW Closing weight: 18t Injection weight: Length dimensions: 8 m Width dimensions: 2.20m Height dimensions: 2.50 m Options: Cores: 2 Robot interface: YES Bi metal: YES

Control type: CC200 Number of hours: 8,000 hours Closing Closing force: 110 T Opening stroke: 350 mm Between columns: rotating table: 1,200 mm Plate dimensions: rotating plate: 1,200 mm Mini/maxi mold: 250 mm Max distance between trays: 600 mm Injection: Screw diameter: 18 mm Screw length: 18.7D cm3: 38 Bars: 2060 General: Motor power: 15KW Heating power: 5.3KW Closing weight: 10T Injection weight: Length dimensions: 2.62M Width dimensions: 1.68M Height dimensions: 4M Options: Bi metal: yes

SANDRETTO Serie 8 sef 100 injection molding machine otto 200T E612 Sef 100 series Screw D50 / 392 cm3 / 1560 bar Between columns: 510 x 510 Opening: 550 Mold thickness: min 210 / max 630 Dim trays: 770 x 770 Installed power: 34.8 kW Dimensions: 6.36 x 2.14 x 1.84 Weight: 8800 kg Euromap 12 robot interface Auxiliary cores Top dosage

SANDRETTO series 7 177/60 Clamping force: 60 T - 600 KN Distance between columns: 301 X 301 mm Tray dimensions: 455 X 455 mm Min/max mold thickness: 80-350 mm Volume injected: 125 cm3 Material pressure: 1408 bar Screw diameter: 40 mm Heating power: 6KW Weight: 2900 kg

KRAUSS MAFFEI 125 T injection press in good condition Reference: 125-460 C1 Closing unit: Closing force: 125 tonnes Opening stroke: 900 mm Distance between column: 470 x 470 mm Mold min. : 300mm Max mold: 600 mm Tray dimensions (h x v): 770 x 750 mm Injection unit Screw diameter: 40 mm Injectable weight: 195 g Injection pressure: 2112 bars Measurements and weights Dimensions: 4.5 x 1.5 x 2.2 m Machine weight: 4100 kg Euromap 12 robot interface

Used Negri Bossi V40-150 From 2004 No robot equipped. Machine is functional and in production, can be seen anytime by appointment. PDF attached
