induction furnace used for sale

Hardening furnace Lg.Nr. 26164 Technical data: - Nominal temperature / continuous temperature infinitely variable up to 1200 ° - Three-sided heating ( bottom + side ) - Temperature control via NABERTHERM Controller C 30 - T. max. 120 min - Drive 400 V / 12 kW - Interior dimensions approx. W 350 x H 250 x D 770 mm - Usable volume 41 L - Space requirement approx. W 950 x H 1370 x D 1600 mm - Weight approx. 400 kg

The system consists of two bell furnaces, maximum temperature: 1100°C, annealing chamber: 2x 1000mm, electrical connection: delta, current rating: 433A, connected load: 300kW, equipment: power control, temperature control, process monitoring, safety controller, emergency stop system, motorized drive for bell movement, air conditioning unit, electrical control cabinet, and control system. Inspection on site is possible.

Heating capacity 2 x 35 kW, circulating air volume 2 x 12,000 sqm/h,The dismantling must be carried out by one of the partner companies mentioned. The costs for this are to be inquired by the buyer himself Auction-ID: A1-48512-16

BINDER FD-115 furnace / charging oven with forced convection 300°C Capacity: 115 liters (FD115) Temperature range: Room temperature plus 5°C to 300°C Built-in digital temperature display 2 shelves Cable routing: Ø 30 mm (on the right wall) Power supply: 230 V, Frequency: 50-60 Hz, Power: 1600 W, Internal dimensions: 60 x 40 x 48 cm Overall dimensions: 83.5 x 75 x 70.5 cm Weight: 85 kg Tested at 150°C

Technical details Type: Industrial tooling components (fixture blocks / die holders) Configuration: Cast metal blocks with flange geometry Quantity: 5 units Design: - Oval/rectangular flange shapes - Central bores (single and double configurations) - Multiple bolt holes for mounting Material: Cast iron or cast steel Construction: Thick-walled, designed for high mechanical and thermal loads Application: Fixture bases, die holders, mould supports, or furnace/press tooling Load capability: Suitable for high-temperature and high-stress environments Dimensions and weight (approx.) Length: 300 mm Width: 200 mm Height: 120 mm Weight: 120 kg (total) Auction-ID: A7-48441-129

HINDELAN KVO-800 – Tilting Crucible Furnace General data: Manufacturer: Hindenlang Model: KVO-800 Year of manufacture: 1990 Machine type: Tilting crucible furnace Installation: Pit-mounted system Technical details: Capacity: approx. 600 – 800 kg (aluminium) Tilting system: Mechanical / assisted (pivot arms) Description: Industrial tilting crucible furnace designed for melting and handling aluminium. The pit-mounted configuration ensures stability and efficient operation, while the mechanical tilting system allows safe and controlled pouring of molten metal. Suitable for foundry and die-casting applications. Auction-ID: A7-48441-18

Electrode furnace: Capacity 5 Kg Inner dimensions (LxWxD) 100 x 75 x 450 mm Power 0.4 kw Connection voltage 220 - 240 V Adjustment device 30 - 180 degrees Weight 10 kg Dimensions L x W x H 570 x 200 x 150 mm Condition: never used / new (5) Auction-ID: A7-48486-158

General description Industrial electric crucible melting furnace, designed for melting non-ferrous metals such as aluminum, brass, or bronze. Suitable for small batch foundry and workshop applications. Technical details Type: Electric crucible melting furnace Configuration: Vertical cylindrical design Operation: Electric resistance heating Power: Approx. 28 kW (from nameplate) Voltage: Approx. 380 V Frequency: 50 Hz Year: Approx. 1980 Construction: Steel housing with refractory-lined chamber Loading: Manual top-opening lid with central charging access Access: Side tapping / access port and lower service hatch Application: Batch melting of non-ferrous metals Equipment - Refractory-lined melting chamber - Manual lid system - Side tapping port - Industrial steel structure Condition and remarks Used industrial furnace. External wear and oxidation visible. Internal  ...

General description Industrial gas-fired furnace with refractory-lined chamber, designed for heating, preheating, or thermal processing operations in workshop or foundry environments. Technical details Type: Industrial combustion furnace Configuration: Vertical furnace body with insulated housing Heating system: Gas burner system (MAGRA) Fuel: Likely natural gas or propane Chamber: Refractory-lined (firebrick interior) Exhaust: Chimney / flue connection Burner: MAGRA gas/air control unit (Gas/Luftabschneider) Application: Heat treatment, preheating, burn-off processes, or auxiliary foundry use Build period: Approx. 1980–2000 (estimated) Equipment - Furnace body with refractory lining - Gas burner system (MAGRA) - Exhaust stack connection - Insulated steel housing Condition and remarks Used industrial unit. Shows heavy wear including soot deposits, oxidation, an ...

RAUCH ZSO450E – Zinc Melting Furnace General data: Manufacturer: Rauch Model: ZSO450E Serial number: 7069 Year of manufacture: 1993 Machine type: Zinc melting furnace Condition: Defective – requires new crucible and maintenance Technical details: Heating output: 57.6 kW Voltage: 380 V Nominal temperature: 450 °C Additional equipment: Tilting device (Rauch) Serial number: 7167 Year of manufacture: 1993 Control system: defective Description: Industrial zinc melting furnace designed for foundry applications. The unit includes a tilting mechanism for material handling. Currently not operational and requires refurbishment, including replacement of the crucible and maintenance work. Auction-ID: A7-48441-4

Melting and holding furnace StrikoWestofen MH II-T 6000/3500 G-eg, built in 2021, heating capacity 2,600 kW, capacity 6,000 kg, melting capacity 3,500 kg/h, max. melting pool temperature 760°C, max. furnace room temperature 1,050°C, height approx. 8,043 mm, with Striko K2000E feeder, built in 2021, with elevator for transport boxes

Electrode furnace: Capacity 10 Kg Inner dimensions (LxWxH) 135 x 80 x 480 mm Power 0.5 kw Connection voltage 220 - 240 V Adjustment device 30 - 180 degrees Weight 15 kg Dimensions L x W x H 600 x 250 x 200 mm Condition: never used / new (5) Auction-ID: A7-48486-176

Melting furnace ZPF Therm ST-G3 T 10 CHHTETWWK, built in 2012, loading weight 9,000 kg, with loading lift (No. ZPF Therm 2), plus processing platform, 2 slag storage tanks, preheating chamber for aluminium ZPF VWK5.2, built in 2012, heated by waste heat, with chimney

1 piece gas-heated chamber furnace with air circulation and hearth trolley Type: KLWg 220/180/650 Gas-heated chamber furnace for unsupervised operation, designed for three-phase three-phase current 400 volts / 50 Hz. Suitable for temperatures up to 700°C and for natural gas \"H\". Technical data External dimensions approximately: Width: 3400 mm Width with control cabinet: 3800 mm Height: 3200 mm Length with retracted hearth carriage: 8000 mm Length with extended hearth carriage: 15500 mm Interior clear dimensions approximately: Width: 2400 mm Height above beams: 1800 mm Length: 6500 mm Volume: 25.7 m³ Max. batch dimensions approximately: Width: 2000 mm Height: 1500 mm Length: 6100 mm Max. weight: 20000 kg Equipment / Execution 4 Rule groups 8 burners Total burner power: 720 kW Burner air blower: 5.5 kW Circulating motors: 4 x 22 kW Bogie hearth dri ...
