hydraulic hammer used for sale

SINGLE POINT OPEN BACK INCLINABLE POWER PRESS Inv. No. 11.420PC Make IWK Model PEKRON 150Z Machine No. 1501 Capacity 150 tons Ram stroke 200 mm Ram adjustment 100 mm Shut height min/max 370 / 570 mm Strokes per minute 40 Knock out in ram 0 – 70 mm RPM 10 - 815 Throat 290 mm Power inclinable 30 degrees, 4kW Table 1000 x 630 mm Ram 760 x 410 mm Q 12 Volts 230 / 400 Cycles 50 Hz Including: Bolster plate 1.000 x 630 x 80 mm Bolster plate 1.000 x 630 x 90 mm Table opening, diameter 440 mm Updated electrics 2004 CE certified Auction-ID: A1-45737-199

HYDRAULIC PUNCHING PRESS Inv. No. 13.085P1 Make SAHINLER Model HKM40 Capacity 40 Ton Punching Ø 20 in 15mm Stroke 50 mm Radius 175 mm Round cutting 30 mm Square cutting 25 mm Angle bar 80 x 80 x 8 mm Flat bar 200 x 13 mm 300 x 6 mm Blade length 356 mm Motor power 3 KW Weight 580 Kg Auction-ID: A1-45737-140

Power: Hydraulic system; pw. N/C Operating parameters: Loading area 2,500 x 6,900 mm; operating hours ~100 h; dim. 8,000 x 2,500 x 2,000 mm; wt. 4,000 kg Workpiece capacity: Material handling; loading/unloading operations (scrap, timber, bulk materials) Supported edges: Industrial materials, scrap, wood (typ.) Edge types: Lifting; handling; loading Included equipment: Hydraulic arm; superstructure; remote control (included); mounting platform Compliance: Industrial handling equipment; CE N/C Power supply: Hydraulic (vehicle-mounted) Year/Manufacturer: 2023 / Atlas – 126.3E-A3 Remarks: Very low usage (~100 h); complete unit with superstructure and remote control; ready for installation/use Hydraulic loading arm with superstructure, suitable for trucks or stationary handling applications. Auction-ID: A7-40553-20

SINGLE POINT OPEN BACK INCLINABLE POWER PRESS Inv. No. 11.421PC Make IWK Model PEKRON 150Z Machine No. 1512 Capacity 150 tons Ram stroke 200 mm Ram adjustment 100 mm Shut height min/max 370 / 570 mm Strokes per minute 40 Knock out in ram 0 – 70 mm RPM 10 - 815 Throat 290 mm Power inclinable 30 degrees, 4kW Table 1000 x 630 mm Ram 760 x 410 mm Q 12 Volts 230 / 400 Cycles 50 Hz Including: Bolster plate 1.000 x 630 x 80 mm Bolster plate 1.000 x 630 x 90 mm Table opening, diameter 440 mm Updated electrics 2004 CE certified Auction-ID: A1-45737-200

CONTROLS   PLC SIEMENS PRESS DESIGN   drive system: hydraulic SLIDE   total force (nominal): 500 to   stroke: 225 mm   stroke rate (max.): 60 /min SLIDE (HYDR. PRESS)   approximation velocity max.: 200 mm/s   working velocity min.: 15 mm/s   working velocity max.: 44 mm/s   return velocity max.: 200 mm/s COUNTER RAM   nominal force: 100 to   stroke: 30 mm V-RING   nominal force: 200 to TOOL DIMENSIONS   shut height max.: 420 mm   ram adjustment: 100 mm   distance between columns (H-frame): 880 mm   passline opening (free passage in side columns): 470 mm   range of transfer pins - in strip direction: 394 mm DECOILER   design: cradle   sheet width max.: 300 mm LEVELLER UNIT   sheet thickness ...

DISMANTLING AND LOADING COST: EURO XXXXXXXXXX Note: The functionality of the goods has not been verified. They are sold in their existing state, without warranty of operation. Auction-ID: A7-45789-4

The trailer is in good condition with user damage here and there. Has a hydraulic tipper. With ramps and with attachment boards. Auction-ID: A3-43369-34000

Slide size 810x610 mm Slide stroke 550 mm Worktop size 810x610 mm DISMANTLING AND LOADING COST: EURO XXXXXXXXXX The cost does not include any disposal of the oils present in the system, this will be invoiced during disassembly Note: The functionality of the goods has not been verified. They are sold in their existing state, without warranty of operation. Auction-ID: A7-45789-17

MAN TGS 33.540 6x4 BL – Truck with Loading Crane General data: Manufacturer: MAN Model: TGS 33.540 6x4 BL Serial number (VIN): WMA30SZZ9BM567249 Year of manufacture: Unknown Condition: Used Power: approx. 540 HP Drive: 6x4 Gross vehicle weight: approx. 26000 kg Dimensions (L x W x H): approx. 10000 x 2550 x 3800 mm Equipment: Hydraulic loading crane Crane: Kogel, 10 ton-meter, hydraulic telescopic arm + rotor + grab Reach: approx. 9 – 10 m Lifting capacity: approx. 3500 kg (close range) to 1000 kg (full extension) Maximum pulling force: 200 kN Trailer coupling Timber stakes for log transport Reinforced chassis Multi-axle configuration Description: Heavy-duty truck equipped with a hydraulic loading crane, designed for forestry, recycling, and construction applications. The vehicle allows self-loading and unloading of bulky materials such as logs, scrap, or ...

Technical data Note: There was no original machine documentation. All subsequent technical data were read from the nameplate to the best of our knowledge and taken from publicly available sources. Manufacturer: COMCO Type: WE 680/4 Year of Make: 1987 Serial Number: 100 Machine Type: Hydraulic Press Operating voltage: 380 V Frequency: 50 Hz Motor power: 11 kW Max. pressure: 200 bar Press force: 300 kN Air pressure: 6 – 10 bar Machine weight: approx. 3,000 kg Configuration 4-post design Hydraulic power unit Safety Light Curtain (SICK) Protective grille / enclosure Electrical control cabinet with control panel Pressure gauge (pressure gauge) Hydraulic control with valve block Auction-ID: A7-46048-18

With matching spoons of 1.80m. In good working condition. Lifting capacity 3.5 tons. Auction-ID: A3-43520-6044

already equipped with tachograph! - Working reversing camera! - automatic air conditioning - starts with booster (battery probably needs to be replaced, stood still for too long), drives and brakes properly - tow bar - 3 people - working d'Hollandia tailgate - engine light is on, probably due to bad battery Auction-ID: A3-43369-10869

This robust HESS frame press impresses with its stable construction and reliable hydraulic control. It is ideal for professional use in timber frame construction – especially for windows, doors or frame constructions. The vertical and horizontal press cylinders can be controlled individually and enable precise alignment of the workpieces. Auction-ID: 03A-CM1-3

pressure:160 t throat:370 mm stroke:150 mm total power requirement:45 kW weight of the machine ca.:22 t dimensions of the machine ca.:2,75 x 1,85 x x 4,80 m rules for accident prevention:Vorhanden work table::1500 x 700 mm Documents:vorhanden

Technical data Note: There was no original machine documentation. All subsequent technical data were read from the nameplate to the best of our knowledge and taken from publicly available sources. Manufacturer: COMCO Type: WE 680/4 Year of Make: 1988 Serial Number: 119 Machine Type: Hydraulic Press Operating voltage: 380 V Frequency: 50 Hz Motor power: 11 kW Max. pressure: 200 bar Press force: 300 kN Air pressure: 6 – 10 bar Machine weight: approx. 3,000 kg Configuration 4-post design Hydraulic power unit Safety Light Curtain (SICK) Protective grille / enclosure Electrical control cabinet with control panel Pressure gauge (pressure gauge) Hydraulic control with valve block Auction-ID: A7-46048-17

pressure:200 t distance between columns:2100 mm stroke:550 mm Distance table/ram, stroke up:1800 mm table surface area:2000 x 2800 mm table height over floor:760 mm ram surface:2000 x 2000 mm Side window:2000 mm feed down:400 mm/s power requirement:51,0 kW weight:33,0 t dimensions (WxDxH):3,25 x 3,5 x 5,4 m Height above floor:5,4 m foundation pit:not necessary

pressure:200 t distance between columns:2100 mm stroke:550 mm Distance table/ram, stroke up:1800 mm table surface area:2000 x 2800 mm table height over floor:760 mm ram surface:2000 x 2000 mm Side window:2000 mm feed down:400 mm/s power requirement:52,0 kW weight:33,0 t Dimensions (WxDxH):3,25 x 3,5 x 5,4 m Height above floor:5,4 m foundation pit:not necessary

pressure:400 t distance between columns:3250 mm distance table/ram, max. stroke up, adjustment up:1000 mm stroke:800 mm table surface area:3250 x 1400 mm table height over floor:1250 mm die cushion capacity:170 t die cushion stroke:200 mm die cushion area:1800 x 1000 mm distance between cutting impact cushioning:2610 mm side window:800 mm ram surface:3250 x 1400 mm return capacity:51 t speed down:300 mm/s speed up:300 mm/s working speed:16 - 33 mm/s quantity of oil:2900 l power requirement:100,0 kW weight:70,0 t Dimensions (WxDxH):4,9 x 3,1 x 7,6 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact absorption:hydraulic

pressure:250 t distance between columns:930 mm stroke:200 mm Distance table/ram, stroke up:600 mm table surface area:900 x 860 mm die cushion capacity:100 t die cushion stroke:50 mm die cushion area:350 x 400 mm table height over floor:950 mm side window:380 x 380 mm ram surface:850 x 700 mm feed down:400 mm/s feed up:400 mm/s working feed:30 mm/s oil volume:350 l power capacity:45,0 kW weight:11,5 t Dimensions (WxDxH):2,0 x 1,2 x 3,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic depth stop:mechanical foundation pit:not necessary

pressure:1000 t distance between columns:3030 mm stroke:350 mm Distance table/ram, max. stroke up, adjustment up:1400 mm table surface area:3000 x 2000 mm table height over floor:430 mm side window:1450 x 1400 mm ram surface:3000 x 2000 mm speed down:300 mm/s speed up:340 mm/s working speed:18 - 44 mm/s return capacity:120 t oil volume:4400 l width with platform:4950 mm power capacity:2 x 90,0 + 10,0 kW weight:87,0 t Dimensions (WxDxH):4,35 x 3,65 x 7,55 m height over floor:6,05 m height beneath floor:1,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

pressure:200 t distance between columns:1650 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1200 mm table surface area:1600 x 1250 mm die cushion capacity:80 t die cushion stroke:300 mm die cushion area:1300 x 900 mm table height over floor:800 mm ram surface:1600 x 1250 mm oil volume:ca. 2000 l power capacity:43,0 kW weight:25,0 t Dimensions (WxDxH):2,9 x 2,3 x 5,8 m height beneath floor:0,85 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20

pressure:350 t distance between columns:1350 mm stroke:900 mm distance table/ram, max. stroke up, adjustment up:1300 mm table surface area:1300 x 1000 mm pressure of drawing cushion in table:100 t stroke of drawing cushion in table:380 mm die cushion area:350 x 285 mm capacity of ejector in ram:25 t ejector stroke in ram:200 mm table height over floor:750 mm ram surface:1300 x 1000 mm speed down:500 mm/s speed up:160 - 470 mm/s working speed:16 - 44 mm/s drawing speed:57 - 160 mm/s return capacity:32 t oil volume:1700 l power requirement:91,0 kW Dimensions (WxDxH):3,75 x 2,8 x 7,2 m height over floor:5,28 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick drawing cushion in table:hydraulic ejector in ram:hydraulic ram interlocking:in TDC foundation pit:necessary

Pressure:500 t distance between columns:1550 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:900 mm table surface area:1200 x 1300 mm pressure of drawing cushion in table:250 t stroke of drawing cushion in table:150 mm die cushion area:950 x 950 mm table height over floor:1245 mm side window:1250 mm ram surface:1200 x 1300 mm speed down:750 mm/s speed up:780 mm/s working speed:105 mm/s oil volume:4000 l power requirement:263,0 kW weight:45,0 t Dimensions (WxDxH):3,3 x 3,3 x 6,1 m height over floor:6,1 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic cutting impact cushioning:motoric adjustable

Pressure:315 t distance between columns:1350 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1200 x 1300 mm table height over floor:1245 mm side window:1250 mm ram surface:1200 x 1300 mm speed down:750 mm/s speed up:680 mm/s working speed:180 mm/s oil volume:2000 l power requirement:150,0 kW weight:35,0 t Dimensions (WxDxH):3,3 x 3,3 x 5,5 m height over floor:5,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact cushioning:motorisch verstellbar ram interlocking:hydraulisch

pressure:200 t throat:360 mm stroke:560 mm distance table/ram, max. stroke up, adjustment up:780 mm table surface area:740 x 720 mm pressure of drawing cushion in table:80 t stroke of drawing cushion in table:200 mm die cushion area:530 x 530 mm table height over floor:920 mm ram surface:560 x 560 mm slide drill hole x depth:70 mm power requirement:35,0 kW weight:10,0 t dimensions:1,3 x 2,0 x 3,4 m

pressure:160 t distance between columns:1340 mm stroke:300 mm Distance table/ram, max. stroke up, adjustment up:620 mm table surface area:1300 x 900 mm table height over floor:930 mm side window:600 mm ram surface:1300 x 900 mm speed down:367 mm/s speed up:390 mm/s working speed:58 mm/s power requirement:30,0 kW weight:15,0 t Dimensions (WxDxH):2,5 x 2,2 x 4,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary

pressure:100 t throat:380 mm stroke:650 mm distance table/ram, max. stroke up, adjustment up:950 mm table surface area:800 x 700 mm hole in the table:200 mm table height over floor:920 mm ram surface:630 x 600 mm speed down:65 mm/s speed up:375 mm/s working speed:17 mm/s oil volume:350 l power requirement:18,5 kW weight:9,0 t Dimensions (WxDxH):1,5 x 2,5 x 4,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 §20

pressure:250 t distance between columns:1125 mm stroke:250 mm distance table/ram, max. stroke up, adjustment up:800 mm table surface area:1100 x 900 mm pressure of drawing cushion in table:63 t stroke of drawing cushion in table:100 mm die cushion area:700 x 400 mm table height over floor:960 mm side window:700 mm ram surface:1080 x 900 mm oil volume:1000 l power requirement:35,0 kW weight:23,0 t Dimensions (WxDxH):2,5 x 2,3 x 4,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick foundation pit:not necessary

pressure:160 t distance between columns:880 mm stroke:150 mm distance table/ram, max. stroke up, adjustment up:400 mm table surface area:830 x 1000 mm hole in the table:265 x 365 mm table height over floor:850 mm side window:610 mm ram surface:860 x 1000 mm power requirement:55,0 kW weight:14,7 t Dimensions (WxDxH):2,2 x 2,0 x 4,3 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 depth stop:motoric adjustable table:motoric foundation pit:not necessary

pressure:300 t distance between columns:2500 mm stroke:350 mm distance table/ram, max. stroke up, adjustment up:1280 mm table surface area:2500 x 1500 mm table height over floor:850 mm side window:900 mm ram surface:2500 x 1500 mm speed down:300 mm/s speed up:240 - 450 mm/s working speed:23 - 44 mm/s oil volume:3000 l power requirement:132,0 kW weight:54,0 t Dimensions (WxDxH):3,25 x 3,2 x 4,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:SITEMA

pressure:200 t distance between columns:1800 mm stroke:710 mm Distance table/ram, max. stroke up, adjustment up:1100 mm table surface area:1600 x 1300 mm pressure of drawing cushion in table:80 t stroke of drawing cushion in table:250 mm die cushion area:1400 x 1080 mm table height over floor:800 mm side window:1300 mm ram surface:1660 x 1300 mm speed down:400 mm/s speed up:410 mm/s working speed:14,3 - 49,7 mm/s power requirement:46,0 kW weight:25,0 t Dimensions (WxDxH):3,65 x 3,3 x 5,4 m height over floor:5,05 m height beneath floor:0,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard at front and back:Sick drawing cushion in table:hydraulic ejector in ram:hydraulic depth stop:mechanical

pressure:50 t distance between columns:1750 mm stroke:500 mm Distance table/ram, max. stroke up, adjustment up:800 mm table surface area:1700 x 750 mm table height over floor:800 mm side window:650 x 750 mm ram surface:1700 x 750 mm power requirement:11,0 kW weight:11,0 t Dimensions (WxDxH):2,1 x 1,15 x 3,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary

pressure:500 t distance between columns:2240 mm stroke:1180 mm distance table/ram, max. stroke up, adjustment up:1800 mm table surface area:2050 x 1800 mm pressure of drawing cushion in table:250 t stroke of drawing cushion in table:380 mm drawing cushion surface in table:1800 x 1200 mm pressure of drawing cushion in ram:122 t stroke of drawing cushion in ram:200 mm drawing cushion area in ram:1800 x 1200 mm ram surface:2215 x 1800 mm table height over floor:500 mm speed down:400 mm/s speed up:10 - 400 mm/s working speed:10 - 100 mm/s depth of the foundation:3,0 m power requirement:122 + 75 + 64,5 kW weight:110,0 t Dimensions (WxDxH):3,6 x 2,2 x 8,5 m height over floor:6,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table and ram:hydraulic

pressure:500 t distance between columns:3200 mm stroke:1250 mm distance table/ram, max. stroke up, adjustment up:1810 mm table surface area:3000 x 1900 mm pressure of drawing cushion in ram:150 t stroke of drawing cushion in ram:200 mm drawing cushion area in ram:2400 x 1200 mm ram surface:3160 x 1900 mm speed down:400 mm/s speed up:250 mm/s working speed:18 - 58 mm/s height over floor:6,5 m power requirement:90,0 + 36,5 kW weight:110 t German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in ram:hydraulic

pressure:800 t distance between columns:3010 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:1350 mm table surface area:3000 x 1800 mm table height over floor:500 mm side window:1500 x 1400 mm ram surface:3000 x 1800 mm speed down:300 mm/s oil volume:900 l height over floor:5,4 m height beneath floor:2,1 m power requirement:200,0 kW weight:80,0 t Dimensions (WxDxH):5,2 x 2,6 x 7,5 m ram interlocking:in TDC depth stop:mechanical

pressure:100 t distance between columns:1060 mm stroke:700 mm distance table/ram, max. stroke up, adjustment up:1250 mm table surface area:1000 x 700 mm pressure of drawing cushion in table:40 t stroke of drawing cushion in table:200 mm die cushion area:Ø 250 mm table height over floor:950 mm side window:580 x 750 mm ram surface:1000 x 700 mm oil volume:700 l power requirement:47,0 kW weight:13,0 t Dimensions (WxDxH):2,2 x 1,8 x 5,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanical; motoric adjustable ram interlocking:SITEMA

pressure:6,3 t throat:300 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:800 mm table surface area:450 x 400 mm hole in the table:80 mm table height over floor:700 mm ram surface:50 mm oil volume:90 l power requirement:5,5 kW weight:1,35 t dimensions (WxDxH):1,8 x 2,0 x 2,7 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanical

pressure:160 t throat:370 mm stroke:150 mm distance table/ram, max. stroke up, adjustment up:500 mm table surface area:1000 x 700 mm hole in the table:100 mm table height over floor:820 mm ram surface:600 x 520 mm speed down:350 mm/s speed up:350 mm/s working speed:12 - 36 mm/s oil volume:1100 l power requirement:27,0 kW weight:16,5 t dimensions (WxDxH):1,8 x 2,7 x 3,95 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:motoric adjustable

pressure:100 t throat:450 mm stroke:170 mm distance table/ram, max. stroke up, adjustment up:450 mm table surface area:3220 x 800 mm table height over floor:850 mm ram surface:3220 x 800 mm speed down:50 mm/s speed up:150 mm/s working speed:7 mm/s oil volume:600 l power requirement:20,0 kW weight:16,0 t dimensions (WxDxH):3,7 x 2,5 x 2,6 m

pressure:315 t distance between columns:1620 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1600 x 1100 mm pressure of drawing cushion in ram:20 t stroke of drawing cushion in ram:100 mm drawing cushion area in ram:300 x 300 mm side window:600 x 1100 mm table height over floor:750 mm ram surface:1600 x 1100 mm oil volume:1500 l power requirement:110,0 kW weight:35,0 t dimensions (WxDxH):4,65 x 2,61 x 5,5 m height over floor:5,05 m height beneath floor:0,45 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in ram:hydraulic ram interlocking:pneumatic cutting impact cushioning:hydraulic

pressure:60 t distance between columns:650 mm stroke:220 mm distance table/ram, max. stroke up, adjustment up:410 mm table surface area:600 x 525 mm pressure of drawing cushion in table:5 t stroke of drawing cushion in table:80 mm table height over floor:900 mm side window:200 mm ram surface:560 x 490 mm dimensions (WxDxH):1,9 x 1,3 x 2,7 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick FGS 600 drawing cushion in table:hydraulic foundation pit:not necessary

pressure:160 t throat:360 mm stroke:200 mm distance table/ram, max. stroke up, adjustment up:500 mm table surface area:920 x 700 mm Hole in the table:150 mm table height over floor:960 mm passage to the back:590 mm ram surface:620 x 560 mm speed down:390 mm/s speed up:390 mm/s working speed:58 mm/s power requirement:30,0 kW weight:16,0 t dimensions (WxDxH):1,6 x 2,5 x 3,6 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanisch

pressure:2000 t distance between columns:975 mm stroke:400 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1015 x 1050 mm table height over floor:800 mm capacity of ejector in table:6,3 t ejector stroke in table:100 mm capacity of ejector in ram:65 t ejector stroke in ram:100 mm ram surface:975 x 1050 mm return capacity:150 t speed down:235 mm/s speed up:250 mm/s working speed:5 - 20 mm/s oil volume:4000 l height over floor:3,65 m height beneath floor:3,75 m power requirement:194,0 kW weight:105,0 t dimensions (WxDxH):5,0 x 6,5 x 7,4 m

pressure:100 t distance between columns:1000 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:650 mm table surface area:980 x 700 mm pressure of drawing cushion in table:4 x 10 / 1 x 20 t stroke of drawing cushion in table:180 mm table height over floor:800 mm side window:400 mm ram surface:1000 x 700 mm speed down:500 mm/s speed up:450 mm/s working speed:60 mm/s power requirement:40,0 kW dimensions (WxDxH):1,5 x 1,4 x 4,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:4 x 10 t + 1 x 20 t, getrennt einschaltbar foundation pit:nicht erforderlich

pressure:200 t distance between columns:970 mm stroke:360 mm Distance table/ram, max. stroke up, adjustment up:630 mm table surface area:1000 x 800 mm capacity of ejector:10 t ejector stroke in table:160 mm table height over floor:850 mm side window:400 mm ram surface:1000 x 800 mm speed down:420 mm/s speed up:410 mm/s working speed:50 mm/s oil volume:1240 l return capacity:24 t power requirement:45,0 + 15,0 kW weight:16,0 t dimensions (WxDxH):2,7 x 2,5 x 4,3 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:mechanisch foundation pit:nicht erforderlich

pressure:100 t throat:540 mm stroke:560 mm distance table/ram, max. stroke up, adjustment up:800 mm table surface area:1000 x 1000 mm pressure of drawing cushion in table:50 t stroke of drawing cushion in table:200 mm die cushion area:710 x 650 mm table height over floor:910 mm ram surface:1000 x 1000 mm capacity of ejector in ram:2 t ejector stroke in ram:200 mm return capacity:19,5 t speed down:400 mm/s speed up:300 mm/s working speed:57,7 mm/s oil volume:650 l power requirement:37,5 kW weight:15,0 t dimensions (WxDxH):1,5 x 2,5 x 4,45 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion / ejector in table:hydraulisch ejector in ram:hydraulisch depth stop:mechanisch

pressure:40 t throat:360 mm stroke:500 mm distance table/ram, max. stroke up, adjustment up:660 / 1000 mm table surface area:630 x 500 mm hole in the table:200 mm table height over floor:1060 / 720 mm ram surface:450 x 360 mm speed down:60 mm/s speed up:300 mm/s power requirement:7,5 kW weight:2,75 t dimensions (WxDxH):1,0 x 1,8 x 3,05 m additional plate in table:height approx. 340 mm

pressure:150 t distance between columns:300 mm stroke:180 mm distance table/ram, max. stroke up, adjustment up:300 mm table surface area:570x180 / 300x410 mm table height over floor:875 mm side window:180 mm ram surface:180 mm speed down:250 mm/s speed up:160 mm/s working speed:6 - 12 mm/s oil volume:250 l power requirement:11,0 kW weight:2,4 t dimensions (WxDxH):1,3 x 1,3 x 2,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 foundation pit:nicht erforderlich

pressure:40 t throat:360 mm stroke:400 mm distance table/ram, max. stroke up, adjustment up:600 mm table surface area:620 x 500 mm pressure of drawing cushion in table:16 t stroke of drawing cushion in table:150 mm table height over floor:850 mm ram surface:300 x 250 mm speed down:200 mm/s speed up:200 mm/s working speed:40 mm/s power requirement:11,0 kW weight:2,8 t dimensions (WxDxH):1,1 x 1,7 x 3,0 m drawing cushion in table:hydraulisch

pressure:63 t throat:320 mm stroke:200 mm distance table/ram, max. stroke up, adjustment up:450 mm table surface area:750 x 600 mm pressure of drawing cushion in table:6,5 t stroke of drawing cushion in table:80 mm die cushion area:240 mm table height over floor:800 mm ram surface:500 x 450 mm capacity of ejector in ram:0,5 t ejector stroke in ram:70 mm speed down:300 mm/s speed up:300 mm/s working speed:50 mm/s oil volume:380 l power requirement:12,0 kW weight:6,5 t dimensions (WxDxH):1,3 x 2,0 x 2,75 m drawing cushion in table:hydraulic ejector in ram:hydraulic depth stop:mechanical cutting impact cushioning:hydraulic
