hsk used for sale

Drilling capacity: 1200 mm Drilling depth: 1200 mm Spindle taper: 63   Number of heads: 1   CNC Brand: Heidenhain Designed for mold making also for larger counterpart its machine cubical workpieces both effiently and precisely and uses optimized drilling and milling small, medium and large scale are covered.     Working area and Drilling capacity Table dimensions: 1,100 x 1,100 mm Max. table load: 7,000 kg Drilling depth: 1,100 mm Drill diameter: 4 - 30 mm Thread cutting up to M24 Axis travel X - axis (horizontal): 1,200 mm Y - axis (vertical): 1,1000 mm Z - axis (horizontal): 1,100 mm W - axis (horizontal - swivelling): 1,600 mm A - Axis (swivel axis): +15°/- 30° B - axis (CNC rotary table): 360° Spindle and Tool changer Spindle holder: HSK-A 63 Tool change positions: 32 General data  KNOLL chip conveyor Read off prog ...

Vertical 3-axis CNC machining center with nano precision Kern Pyramid Nano Year of construction: 2013 Heidenhain iTNC 530 Table size: 600 x 600 mm Table load: max. 250 kg Longitudinal travel: X 500 mm Transverse travel: Y 500 mm Vertical travel: Z 400 mm Smallest travel increment: 0.1 μm Feeds up to: X/Y/Z 30,000 mm/min. Rapid traverses up to: X/Y/Z 30,000 mm/min. Acceleration: X/Y/Z 10 m/s² Vector-controlled milling spindle: Spindle mount: HSK-25 Spindle drive power: 6.4 kW AC Spindle speeds: 500 - 50,000 rpm. Spindle torque (S1): max. 1.6 Nm Automatic tool changer: Tool magazine positions: 32-fold Tool holder: HSK-E25 Tool Ø (every second place free): max. 60 mm Tool length: max. 160 mm Tool change time: 3 sec. Chip-to-chip time: 6 sec. Machine weight: approx. 8,000 kg Machine height: LxWxH 2,850 x 3 ...

Number of spindles: 6 St. Working width: 230 mm Working height: 120 mm Length of the planing table: 2500 mm Feed motor: 4 kW Feed speed: 5-30 m/min. Weinig Powermat 400 with HSK/Powerlock, axial/radial CNC controlled ---------------------------------------------------------------------- - Short summary: ---------------------------------------------------------------------- - 6 spindles with 8,000 rpm 5 x HSK/Powerlock Axial and radial CNC adjustment of the spindles via control CNC - controlled adjustment and positioning of the feed Detailed description: ---------------------------------------------------------------------- - Technical specifications: Working width: 20-230 mm Working height: 8-120 mm Number of spindles: 6 1. Tool holder - below ------------------------------------------------ Motor with brake: 5.5 kW Spindle diameter: 40mm Speed: 6,000 rpm Tool flight circle: 93 - 160 mm ...

Table length: 450 mm Table width: 300 mm Longitudinal X: 300 mm Cross Y: 250 mm Vertical Z: 250 mm Positions ATC: 12   Positions APC: 2   CNC Brand: Fanuc 3-axis CNC machine (VMC)CHIRON - FZ08W MACH-ID 7652 Make: CHIRON Type: FZ08W Control: Fanuc 21-M Year: 1998 Pallet changer 2 tables 450 x 300 x 75 Kg Workpiece rotation station 180 Gr Large Tooling package HSK-32 Coolant system 100 Liter X - Travel:              300mm Y - Travel:              250mm Z - Travel:              250mm Table Length:            450mm Table Width:             300mm Table load:              75 Feed rate X-Axis:        40000mm/min. Feed rate Y-Axis:    &nbs ...

CNC vertical machining center HERMLE C 22 U With path control Heidenhain iTNC 530 Year of construction: 2014 Travels : X 450 Y 600 Z 330 Speed range : 20 – 18,000 rpm infinitely variable (HSK 63) With the following accessories: NC swivel rotary table 450 mm x 360 mm clamping surface Vertical tool changer with 55 magazine slots (HSK 63) Linear axes standard version Internal coolant supply (IKZ 80 bar) Scraper belt conveyor left Chip wagon 450 l Coolant device Chip flood gun Oil mist extraction Manual Cabin Door , Automatic Cabin Roof Laminated glass safety pane Rotating transparent window (Rotoclear) Electr. Heat compensation iTNC Electr. Handwheel 3D probe Heidenhain BLUM Wz-bruch/ Vermessung 4 pieces Height adjustable machine shoes Operating instructions

x-travel: 800 mm y-travel: 1020 mm z-travel: 970 mm Control: HEIDENHAIN iTNC 530 : 18000 min/-1 Feeds (X,z,u,w-axis): 29 / 39 kW tool taper: HSK 63 : 60 Pos. rapid travel x/y/z: 65/50/80 mm/min table diameter: 630 x 630 mm table load capacity: 700 kg max. workpiece diameter: 900 mm A-Axis: -185 / +45 ° b-axis: 360 ° total power requirement: 42 kVA weight of the machine ca.: 22 t dimensions of the machine ca.: m 5-axis BAZ Equipped with: - CNC control HEIDENHAIN iTNC 530 - pallet changer 2-fold (630x630mm) - tool changer 60-fold (HSK-A63) - Swivel rotary table (A-/B-axis) - IKZ 4-38 bar - chip conveyor - belt filter system - spindle cooling 6 Machines available The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Manufacturer: Homag Nutsäge mit Winkelgetriebe, Type: 4-00570, Saw blade quantity: 1, Tool diameter mm: ca.160, Used: yes, Anschlussspindel mm: HSk 63, Available: sofort, FREE TEXT: HSK 63 ,

Manufacturer: Weeke, Year: 1996, Type: Frässpindel, Motor mit Getriebe: Werkzeugaufnahme HSK 63, aus Maschine: BP 155, Power kW: 7,5/10, N1-U/min: 750-18000, Motor mit Getriebe: Werkzeugaufnahme HSK 63, FREE TEXT: inkl Drehmotor für C Achse, Year :1996

Key data: 500 mm, 450 mm, 400 mm

Vertical 5-axis machining center DMG DMU 50 eVo Linear Year of construction 2006 Heidenhain MillPlus IT 2-Axis NC Swivel Rotary Table: Table size: 500 x 380 mm Table load: max. 200 kg Travel: Longitudinal travel: X 500 mm Transverse travel: Y 450 mm Vertical travel: Z 400 mm Table rotation axis: C-axis 360° / 0.001° Table Swivel Axis: B Axis +90°/-18° ~ 0.001° Cutting feeds: X,Y,Z 20,000 mm/min. Rapid traverse X linear actuator: X 80,000 mm/min. Rapid traverses: Y, Z 50,000 mm/min. C/B 50 / 40 rpm. Spindle: Spindle drive power: 40%/100% 35/25 kW Spindle speeds: 20 - 18,000 rpm. Spindle torque: 40%/100% 130/87 Nm Tool magazine and automatic tool changer: Tool magazine positions: 120-fold Tool holder: HSK-A63 Tool diameter (all pockets occupied): max. 80 mm Tool diameter with free side slots: max. 130 mm Tool length: max. 300 mm Chip-to-chip time: 5  ...

faceplate diameter: 4500 mm swing diameter: 5000 mm turning height: 2645 mm Control: Siemens 840 D total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Equipment: CNC control Siemens Sinumerik 840 D Direct measuring system C-axis with extension of the workpiece measurement Hydrostatic guidance of the linear axes Workpiece measurement Tool measurement Tool and process monitoring ARTIS CTM system Workroom surveillance with video camera (at the support) Processing heads with automatic tool clamping UWFK 500 Nm, +/- 90° manually pivotable Various tool holders, type 300.2 Tool magazine 24 to 72 Platu magazine pick-up plate Loading crane for the tool magazine, load capacity 500 kg Loading device with HSK, capto-, KM tool holder Machine protection device Automatic cover of the chip chute Working area protection completely closed Preparation for installing a ...

CNC Universal Machining Center DECKEL MAHO DMU 95monoBlock NEW DMG Design With path control CELOS with Heidenhain TNC 640 Year of construction: 2023 ( NEW MACHINE) Travels: X 950 Y 850 Z 650 Speed range: 0 – 20000 rpm infinitely variable (HSK 63) With the following accessories: NC swivel rotary table 0 850 mm x 750 mm integrated in rigid table 1000 mm x 750 mm Vertical tool changer with 60 magazine positions ( HSK 63 ) Full protection cabin with sliding doors and interior lighting Tool measurement in the BLUM Laser DIGILOG work area 3 D Probe Heidenhain TS 460 3 D quick Set Accuracy Package ATC (Application Tuning Cycle) IKZ 40 bar with 600 l tank and paper belt filter Chip rinsing gun with pump 1 bar/40 l Conveyor Digital Manufacturing Package , DMG MORI PLUGIN TOOL , DMG Service Agent Coolant Ring Nozzle Cooling device blowing air Coolant system Oil/Emulsio ...

Control: Mitsubishi Area of application: Production of chassis components made of cast iron in batches Nodular graphite in one clamping position, production of large series or largerones. Quantities, current cycle time

Apec G30/20 5 axis bridge machining center Simultaneous Travel: Feed rate: X axis travel 2000 mm X/Y/Z axis rapid traverse 60/60/40 m/min Y axis travel 3000 mm X/Y/Z axis acceleration 0.5G Z axis travel 1000 mm Cutting feed rate 1-20,000mm/min spindle nose to table surface 330-1330 mm Table: Spindle: (APEC MONO SUPPORTING HEAD) Table size 2,000x3,000 mm Spindle taper HSK 63A Table load 8000 kgs/m2 Spindle speed 24000RPM T-slot size 28 mm Spindle motor (S1) 25/30 KW ATC: Spindle torque (S1) 119/143 NM Capacity 20 pc 2 axis head A-Axis C-Axis Tool shank HSK 63A Rotation speed 30 rpm 30 rpm Max. tool weight 15 kgs Max. torque 760 Nm 800 Nm Max. tool dia. (w. adjacent tool) 150 mm Clamping torque 4000 Nm 4000 Nm Max. tool dia. (w/o adjacent tool) 180 mm Rotation angle ± 125∘ ±360∘ Max. tool length 300mm Others: Machine Weight 39000kgs (around) Mo ...

spindle speed: 16,000 rpm(steptec switzerland) spindle taper: hsk-a63 x axis movement mm : 1020 y axis movement mm : 560 z axis movement mm : 600 x-y axis fast progress(m/min): 40 z axis fast feed (m/min): 40 table dimension (mm): 1000x560 tool magazine: 40 pieces (6 missing ports) controller: hei̇denhai̇n tnc 620 slide structure: lineal slide (glass table reader) maximum table load kg : 1350 it has the feature of watering into the tool, it has the feature of air into the tool, there is a renishaw probe machine spindle working time is 23000 hours. there has not been any release to date. there was no major faults. axis bearings have changed at certain times. the springs inside the spindle have changed. leaf springs have changed. it is original and zero precision like the day it was purchased with spindle. the machine was not into rough chip, precision and finish works ...

For sale a fast and reliable 3-axis CNC milling machine with the possibility of adapting to 5, Erowa robot, fog extractor, spindle cooler, in very good technical condition included. No play in the working area. The spindle is in perfect condition. Data: - year 2008, - Andronic 2060 control, - HSK E 40 spindle (42,000 rpm) , 17KW, with cooling, - 40,000 machine hours, - 22,000 rg of spindle, - a warehouse with 40 places, - X 700 mm, - Y 550 mm, - Z 450 mm, - 3D probe, - BLUM gate for tool measurement and control, - USB, netzwerk and ethernet, - fog extractor, - load capacity 2000 kg, - full documentation. -country of origin Germany. Erowa X / R 50 robot for replacement of finished parts included. Adaptable to replace the second pallet. Additionally: Second cooler for parts, 60 pieces of HSK holders, two Swiss four-jaw chucks. It is adapted to work with CAD-CAM.  ...

A new CTX 1250 TC turning / milling machining center with a milling spindle, counter spindle and bar feeder is on sale. The cost of the machine is discussed and indicated taking into account delivery to the enterprise, it is possible to provide a guarantee up to 6 months, commissioning and training. Basic machine B-A7255 CTX beta 1250 TC Universal lathe The maximum workable length is 1250 mm. - Main spindle: integrated motor spindle ISM 76 - Main AC drive 25/34 kW (100/40% ED), 5000 min-¹. - Open jig (hydr.) With an inner diameter of the draw tube of 67 mm. Clamping force 68 kN at max. P 45 bar. - C-axis with spindle brake (hydr.) - Cross slide with integrated milling and turning motor spindle with hydraulic clamping for turning operations, HSK-63A taper according to DIN 69893 - Y-axis ± 100 mm - B-axis ± 110 ° pneumatic clamping - Disk tool magazine for ...

Technical DataSpindle taperHSK-E 50 Feed rate longitudinal/transverse/vertical1-80000/1-80000/1-80000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minGeneralHSC-Precision Centre - Active chiller for main spindle and linear drives - Active chiller for electrical cabinet - Direct absolute measuring system with air purge - Coolant-airblast changeover - MPC (Machine Protection Control); Control: 3D-control Heidenhain iTNC 530 HSCI Working area 1Longitudinal450 mmCross580 mmVertical460 mmTool changerApplicationVertical Type of magazineChain Type of gripperDouble gripper Number of tools30 Rigid tableRigid table, clamping area 460 x 600 mm / 18,11 x 23,62 inch Loading weight max. 600 kg / 1322 lbsSpindle speed up to 40,000rpm with Shaft CoolingSpindle speed 20 up to 40,000 rpm within shaft cooling for tool taper HSK-E50 DIN 69893 AC-Main drive with 19,5/15 kW (100/40%DC) 14,5 ...

Key data: 750 mm, 600 mm, 520 mm

CNC Vertical Machining Center DECKEL MAHO DMU 70 eVolution With track control Heidenhain TNC 430 Year of construction: 2001 Travels: X 750 Y 600 Z 520 Speed range: 0 – 18000 rpm infinitely variable (HSK 63) With the following accessories: 2-axis NC swivel rotary table 700 mm x 500 mm clamping surface Vertical tool changer with 32 magazine slots ( HSK 63 ) Full protection cabin with sliding doors and interior lighting Electronic handwheel Controlled coolant nozzles BEMA Probe preparation (read head available) Tool measurement in the working area (BLUM Laser) Mode 3 + 4 IKZ 40 bar Conveyor Coolant system Chip Sweeping Gun 4 pcs. Height-adjustable machine shoes Operating instructions

Key data: 600 mm, 450 mm, 450 mm

Machine Details Stock number 1105-03964 Machine Type Machining Center - Vertical Make MIKRON Type VCP 600 Year of construction 2000 CNC control type Control TNC 430M Storage location FRANCE Country of origin: SWITZERLAND Delivery time ready for shipment Cargo base EX WORK Price Technical details x-travel 600 mm y-travel 450 mm z-travel 450 mm Control TNC 430M Table clamping surface 850 x 530 mm Table load 0.40 t Number of T-slots 6 T-slots - spacing 63 mm T-slots - width 14H12 mm Spindle speeds - infinitely variable 100 - 20,000 rpm Spindle motor 12.00 kW Tool holder HSK-A63 Tool changing device 30 Tool diameter 90 mm Tool diameter with 2 free spaces 110 mm Tool length - max. 250 mm Tool weight max. 6.00 kg Chip-to-chip time approx. 7.00 sec Infinitely variable feed 0 - 22,000 mm/min Rapid traverse 22.00 m/min Feed force X/Y/Z axis 5000 N Total power ...

max. wheel diameter: 1200 mm gear width: 350 mm max. module: 16 min. module: 0,5 max. workpiece diameter: 1400 mm table diameter: 1200 mm table hole: 300 mm control: Siemens 840D Powerline total power requirement: 75 kW weight of the machine ca.: 24 t dimensions of the machine ca.: 5x3x3,8 m Gleason-PFAUTER CNC gear shaping machine P 1200 S for the production of internally and externally cylindrical gears with internal and external teeth and other rolling profiles and moulds profiles and moulds that regularly occur on the cylindrical workpiece circumference and for the production of profiles in the single part process. Special version with hydraulic shaping head H1 SCOPE OF EQUIPMENT: - Basic machine P1200S, Siemens 840D Powerline (XP) - Hydraulic shaping head H1 - Signal light (3-colour) - Extended software for fault diagnosis - Telephone diagnosis system - Chip disposal through table b ...

axis stroke (X,Y,Z): 4062, 2,922,660 mm Number of spindle head vertical: 13 St. Number of spindles head horizontal: 6 St. Number of tools: 27 St. Number of milling agregates: 1 St. working dimensions: 3200,1500,200 mm Motor output: 12 kW control: BECKHOFF MASTERWOOD Project 385 (Winner) ------------------------------------- Exhibition machine built in 2021, available immediately! 5-axis CNC machining center in portal design for use for Interior fittings, doors, stairs optionally expandable with solid wood clamps Frame processing and arched windows Short Summary: ----------------------------------------------- Workspace: X = 3200mm , Y = 1500mm, Z = 200mm 1 piece 5-axis high-performance spindle, 12 kW, with HSK 63 F mount 1 piece of permanently installed drill head with 19 spindles with 7 individually accessible vertical drilling spindles in the X direction with 6 individually accessible  ...

Key data: 750 mm, 600 mm, 520 mm

CNC universal milling machine DECKEL MAHO DMU 70 NEW DMG Design With track control Heidenhain iTNC 530 Year of construction: 2013 Travel : X 750 Y 600 Z 520 Speed range : 20 – 14,000 rpm infinitely variable ( HSK 63 ) With the following accessories: Swivel rotary table for 5-axis simultaneous machining Ø 800 mm x 620 mm Electronic handwheel 3 D Probe Heidenhain Mode 3 + 4 Vertical tool changer with 30 magazine positions ( HSK 63 ) Sealing Air for Linear Measuring System Conveyor IKZ 40 bar Rotoclear Chip Sweeping Gun 4 pcs. Height-adjustable machine shoes Coolant system Operating instructions THE MACHINE WAS ONLY USED FOR APPRENTICESHIP TRAINING THE MACHINE HAS ONLY 3218 PROGRAM RUNNING HOURS THE MACHINE IS IN VERY GOOD MINT CONDITION

CNC Universal Milling & Drilling Machine DECKEL MAHO DMU 60 T With MILL PLUS iT path control Year of construction: 2002 Travels: X 630 Y 560 Z 560 Speed range: 0 – 12,000 rpm infinitely variable ( HSK 63 ) With the following accessories: Rigid angle table 1000 mm x 600 mm clamping surface 3 D touch probe Electronic handwheel Mode 3 + 4 Vertical tool changer with 24 magazine positions (HSK 63) Full protection cabin with sliding doors and interior lighting IKZ 40 bar Integrated screw conveyor Rotoclear Chip rinsing gun Coolant system 3-Piece Height-Adjustable Machine Shoes Spindle Oil Cooler Transport device Operating instructions

Key data: 630 mm, 800 mm, 850 mm

Year of construction 2012 Control Siemens 840 Dsl Speed [rpm] 18000 Travel X/Y/Z [mm] 630/800/850 Tools & Tools. HSK-A63 Spindle: Motor Spindle Technology Speed 18,000 rpm Power 34 kW Torque 110 Nm Tool holder HSK-A63 NC Rotary Table: B-axis 0.001° Pallet size 500 x 500 mm Pallet load (max.) 600 kg General: Tool magazine 63 stations Rapid traverse in X/Y/Z 100 m/min Equipment/Accessories: Displacement measuring system directly in X/Y/Z (glass scales) Chip Management Chip Conveyor Coolant management IKZ system with paper belt filter, temperature control and High pressure, 80 bar Automation pallet changer, 2-fold Workpiece Measurement Probe, Renishaw OMP 60 Mechanical tool breakage detection Oil Mist Extraction Mechanical Separator Set-up operation Electronic handwheel Other equipment Rinsing gun

x-travel: 800 mm y-travel: 800 mm z-travel: 800 mm Control: iTNC 530 Heidenhain Main spindle:: Max. rpm: 18.000 min/-1 power capacity - main spindel: 28 / 19 kW max. Torque: 121 / 82 Nm tool taper: HSK A63 swivellable: B: 0 - 190 ° swivle time: 1,2 s NC-Rotary table:: table diameter: 900 x 700 mm max. table load: 1.400 kg rotatable: C: 360 ° tool magazin:: number of toolpositions: 60 pos. tool taper: HSK A63 change-time chip to chip: ca. 5,0 sec feeds:: rapid traverse ( X / Y / Z ): 60 m/min rapid traverse: B: 30 m/min rapid traverse: C: 30 m/min feed speeds: max. 60.000 mm/min total power requirement: 64 kVA weight of the machine ca.: 14,0 t dimensions of the machine ca.: 6,0 x 6,5 x 3,2 m Documents: Coolantsystem: high pressure coolant: through spindle coolant: 40 bar turning milling head: NC-rotary table: Tool Magazine: Chip conveyor: test probe: Heidenhain TS 640 tool mo ...

x-travel: 880 mm y-travel: 630 mm z-travel: 630 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: max. 18.000 min/-1 power capacity - main spindel: 28 / 19 kW max. Torque: 121 / 82 Nm tool taper: HSK-A 63 swivellable: B: +30° / -120 ° NC-Rotary table:: table surface area: Ø 700 / 1.250 x 700 mm max. table load: 650 kg rotatable: C: 360 ° max. workpiecediameter: 850 mm max. workpiece height: 550 mm tool magazin:: number of toolpositions: 32 pos. tool taper: HSK-A 63 max. tool diameter: 80 mm max. tool-dia with free toolbox: 160 mm max. tool weight: 8,0 kg change-time chip to chip: 10 sec feeds:: feed speeds: max. 30.000 mm/min rapid traverse: 30 m/min Accelaration: 5 m/s² total power requirement: 48 kVA weight of the machine ca.: 14,0 t dimensions of the machine ca.: 6,5 x 5,0 x 2,9 m Documents: Chip conveyor: Coolantsystem: test probe: Heidenh ...

x-travel: 1.000 mm y-travel: 1.000 mm z-travel: 1.000 mm Control: iTNC 530 Heidenhain Main spindle:: Max. rpm: 12.000 min/-1 power capacity - main spindel: 28 / 19 kW max. Torque: 121 / 82 Nm tool taper: HSK A63 swivellable: B: 0 - 190 ° swivle time: 1,5 s NC-Rotary table:: table diameter: 1.100 x 900 mm max. table load: 1.400 kg rotatable: C: 360 ° tool magazin:: number of toolpositions: 40 pos. tool taper: HSK A63 change-time chip to chip: ca. 5,0 sec feeds:: rapid traverse ( X / Y / Z ): 60 m/min rapid traverse: B: 30 m/min rapid traverse: C: 30 m/min feed speeds: max. 60.000 mm/min total power requirement: 69 kVA weight of the machine ca.: 16,8 t dimensions of the machine ca.: 6,0 x 6,5 x 3,2 m Documents: Coolantsystem: high pressure coolant: through spindle coolant: 40 bar turning milling head: NC-rotary table: Tool Magazine: 40 pos. Chip conveyor: test probe: Heidenhain ...

x-travel: 1500 mm y-travel: 1500 mm z-travel: 800 mm spindle taper ISO: HSK 63A spindle turning speed range: 18000 U/min spindle motor: 23 kW b-axis: +/- 110 ° c-axis: +/- 220 ° control: Heidenhain iTNC 530 workpiece weight: 5000 kg no. of tools in the magazine: 40 Stück Table dimensions: 1480 x 1440 mm total power requirement: 78 kVA weight of the machine ca.: 15 t dimensions of the machine ca.: 5 x 3,5 x 4,1 m 5-axis machining center equipped with: - CNC control Heidenhain iTNC 530 with HR 420 - movable table - Blum laser tool measurement - chip conveyor - tool changer 40-fold (HSK 63A) - IKZ 40bar - filter system 55000h Machine On, 20760h Program-Run, 23900h Spindle The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Type: Milling Machine/Machining Center Ident Number: 22367 Category: Milling Machines Manufacturer: Mikron Model: HSM 500 Year of construction: 2006 Travel: 500 x 450 x 360 mm [ X x Y x Z ] HSC Machine Number of axles: 3 Control: Heidenhain iTNC 530 Spindle mount: HSK 32 E Spindle speed: 54000 rpm Table size X: 550 mm Table size Y: 450 mm max. workpiece weight: 200 kg Tool changer: 40 speed Conveyor Laser probes for tools Probe PS 32 Infrared / HSK 32 E Minimal lubrication Oil Mist Extraction Device APS Advanced Process System ITC Intelligent Heat Control Mobile handwheel

x-travel: 450 mm y-travel: 600 mm z-travel: 330 mm control: iTNC 530 Heidenhain Main spindle:: turning speeds: max. 18.000 min/-1 power capacity - main spindel: 31 / 17 kW max. Torque: 98 / 54 Nm tool taper: HSK A63 swiveling-rotary-table:: rotary table dia.: 320 mm Swivel range: A: +/- 135 ° rotatable: C: 360 ° max. table load: 300 kg Number of revolutions: A: 25 / C: 40 rpm T-slots: 4x 14H7 Tool-Presetter:: number of toolpositions: 55 pos. tool taper: HSK A63 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 250 mm max. tool weight: 8,0 kg max. total weight: 220 kg change-time chip to chip: 4,5 sec feeds:: Accelaration: 8 m/sec² Feed force: 4,5 kN rapid traverse ( X / Y / Z ): 30 m/min total power requirement: 40 kVA weight of the machine ca.: 9,0 t dimensions of the machine ca.: 6,5 x 6,5 x 3,5 m Documents: NC-Rotary Swiveling Table: Automati ...

Year of manufacture: 2008 - Working range X 300, Y 280, Z 250 mm - Feed speed 0.01 - 16,000 mm/min - Acceleration 8 m/s2 Resolution: 0.1 μm Position spread Ps: ±0.5 μm CNC precision dividing head (4th and 5th axis) - System 3R Macro Chuck - Brushless servo drive, fully digital - Feed speed C/B 7000 / 3000 °/min - Swivelling range B from -10 to +120 degrees a - Heidenhain iTNC 530 smarT.NC - High-frequency spindle HSK E25 500 -50,000 rpm - Tool changer 95-fold - prepared for external workpiece changer - Minimal quantity lubrication - Extraction system - CO2 extinguishing system - Laser for tool measurement (Blum) - Infrared 3D probe - External recooler - External spindle cooling unit - External coolant unit with cooling - Vorma machine light Accessories - Shrinking device Haimer Power Clamp Nano - HSK E25 holders (KERN) ø 2 - 6mm (Total 115 pcs; shrinkin ...

Field of work: cube mm. 600 600 600 Complete with rotating daisy A N. 7 Pallets + 1 Pallet loading / unloading place Electro spindle 27,000 rpm - HSK A / 50 + N.1 connection Spare electrospindle Tool magazine with 260 positions - complete with N. 250 spindle HSK A / 50 with identification Balluf pads

description TECHNICAL DETAILS Support table: 3250 x 1250 mm X-travel: 3860 mm Y-travel: 1822 mm Z1/Z2 travel: 325 / 185 mm Workpiece thickness: max. 125 mm X / Y / Z speed: 100 / 50 / 20 m/min X-travel distance suction nozzle: 4210 mm Tool holder: HSK F63 Number of tools: 14 (disc) Vertical drilling spindle: 19 pieces Horizontal drilling spindle: 6 pieces Milling unit: 2 x HSK F63 collet chuck Drill holder: 10 mm Drill spindle holder: 20 - 35 mm MACHINE DETAILS Loading dimensions: 5800 x 2300 x 2300 mm Installation dimensions: 5830 x 4100 x 2300 Weight: 4.3 tonnes Surface pressure: 1.20 N/sqmm Concrete thickness: min. 200 mm Operating voltage: 3 x 400 V Voltage: 50/60 Hz Rated current: approx. 32 A Total connected load: 17.5 kW Pneumatics: according to ISO 8573-1 Connection: R 1/2 Pressure: 7 bar Consumption: 100 - 200 NL/min Matching s ...

Operating Instructions FMB Machining Center / Version 9. June 2011. Machining centres Software from Schüco installed Software design Special machines Operating instructions 7. technical data 7.1Machine dimensions Total length mm 9,750 Total depth / with LS mm2.750 / 3.300 Total height max. mm4.100 7.2 Axle travel X-axis mm approx. 7,100 Y-axis mm approx. 1,480 Z-axle bucket 710 V-axis (optional)mmca 6,980 A axis (optional)degrees180 ° Gajs30zga C axis (optional)degree360 ° W-axis (optional)mm 7.3Working spindle Spindle drive kW7.5 Spindle speedmin-120.000 Spindle mounting HSK E40 7.4Tools Mounting HSK E40 Wkzg positions 6 (more optional) 12 Wkzg maximum diameter mm 35 Saw blade Ø for milling spindle mm 400

CNC vertical machining center DRILLTEC Type: V-200 Optimat BHX055 Year of construction: 2021 only 564 operating hours Workpiece length 200 - 3050 mm incl. roller conveyor Workpiece width 70 – 850 mm Workpiece thickness 12 – 60 mm Workpiece weight max. 35 kg Speed of axes X/Y 50 m/min., Z 15 m/min. Vertical Drill Gear V13/32 mm High Speed 2 rows of drill bits, each with 5 drill bits in parallel in X-direction 1 row of drill bits with 5 drill bits in Y-direction Total drill length 70 mm Drill diameter max. 35 mm Spindle spacing 32 mm Horizontal drill gear with 4 spindles (2 right, 2 left) in X-direction, can be called up individually, drill spacing 32 mm Horizontal drill gear with 2 spindle (1 right, 1 left) in Y-direction, can be called up individually Groove saw in X-direction, diameter 100 mm Tool change spindle HSK 63 and converter 10 kW Tool diamet ...

Description: Control: MSX-711IV Max. swing diameter: 730 mm Swing diameter over cross slide: 730 mm (turret 2400) Max. Distance between centers: 1,862 mm Max. Turning diameter: Capto C6 tool spindle (600 mm), turret 2: (350 mm) Max. turning length: 1,542 mm Bar diameter: 80/80 mm X-axis (tool spindle): 750 mm (625+125) Y-axis (tool spindle): +/- 210 mm Z-axis (tool spindle): 1,550+100 mm (for ATC) B-axis swivel range: +/- 120 degrees X-axis (turret 2): 195 mm Z-axis (turret 2): 1,525 mm Max spindle speed: 4000 rpm Number of spindle speed ranges: 2 (winding changeover) Spindle bore: 91 mm Min. increase in spindle indexing: 0.0001 degrees Spindle bearing (inner diameter): 140 mm B-axis switching time: 0.65 (0.4) seconds / 90 degrees Max. Tool spindle speed: 12,000 rpm Holder: HSK-A63 Inner diameter: tool spindle 70 mm Number of tool positions: 20 pieces Max. Tool diameter (with adjacent to ...

Machine designed for machining solid wood doors with frame and raised panels Workpiece dimensions Length 150 - 3000 mm Width 40 - 300 mm Thickness 20 - 60 mm Material: hard woods/soft woods Machine equiped with 2 working areas, including - 3 NC-axes X, Y, Z - telephone modem - 1 sawing unit - 1 horizontal boring unit - distance horizontal drill above table (Z):max. 40 mm - fixed workpiece table - central lubrication - CE package - max. workpiece length 2.400 mm KOCH Numeric with 3 NC-axes Positioning control with PC Pentium CPU Operating system Windows XP Professional: english 15? Touchpanel VGA + Touchscreen by means of LVDS connection USB-connection on PC and on Touchpanel Seriel and parallel interface on the PC Hard disk 2,5? Input of machine commands and motor control through the Touchpanel PS2 connection for external keyboard Office PC software Stretched machine bas for max. workp ...

Key data: 1250 mm, 1000 mm, 1000 mm

CNC Universal Milling & Drilling Machine DECKEL MAHO DMU 125 P duoBlock NEW DMG Design With track control Heidenhain iTNC 530 Year of construction: 2008 Travels: X 1250 Y 1000 Z 1000 Speed range: 0 - 18000 rpm ( HSK 63 ) With the following accessories: NC rotary table 1250 mm x 1000 mm clamping surface Universal milling head with controlled B axis Automatic swivel milling head 60 speed tool changer ( HSK 63 ) Full protection cabin with interior lighting Mode 3 + 4 3 D Probe Heidenhain TS 642 Electronic handwheel Spindle Oil Cooler IKZ 40 Bar Rotoclear Conveyor Oil mist extraction Coolant spray gun Control cabinet cooling unit (RITTAL) 3 Height-Adjustable Machine Shoes Operating instructions

This POSMILL E 2050 L HSCI Vertical Machining center machine was manufactured in the year 2015 in Germany and has 2750 spindle hours (since spindle renewal in April 2021). It is equipped with a HEIDENHAIN iTNC 530 control unit and HSK 63. The machine has new inline spindle, new spindle motor and new rotary union (April 2021). It comes with inner cooling through spindle 20Bar with belt filter, tool changer 60 compartment, 3D probe Blum, tool measurement Blum laser, Heidenhain handwheel, blowing air spindle center and operation mode 4. Upon request and for additional cost approx. 250 HSK holders and drill chucks are available (partly new / partly used).

Description: control: SIEMENS Sinumerik 828D  , travels: X-axis: 650 mm Y-axis: 650 mm Z-axis: 800 mm rapid traverse: X-axis: 60 m/min. Y-axis: 60 m/min. Z-axis: 60 m/min. rotational speed B-axis: 50 rpm  , spindle speed range: 17500 rpm spindle torque: 60 ,- 80 Nm spindle power: 26 - ,35 kW  , max. workpiece diameter: 800 mm max workpiece height: 800 mm max. workpiece weight: 800 kg  , toolholder: HSK-A 63 toolchanger ,positions: 40 max. tool length: 450 mm max. tool diameter: 160 mm max. tool weight: 10 kg  , please also have a look at the videos and the PDF documents of this machine z-motion: 800 mm, max. workpiece weight between centers: 800 kg, x-motion: 650 mm, y-motion: 650 mm, control: SIEMENS Sinumerik 828D, taper: HSK-A 63, power capacity - spindle: 26 - 35 kW, spindle torque: 60 - 80 Nm, toolchanger positions: ...

Description: serial number: 2312 control: HEIDENHAIN ,iTNC 530 working hours: approx. 68649 h spindle hours: approx. 40638 h  , number of axes: 5 travels: X-axis: 2300 mm Y-axis: 1300 mm Z-axis: 1000 mm C-axis: 150° (+60/-90) B-axis: 370° (+/-185) table dimensions: 1800 x 1800 mm max. table load: 18000 kg feed rate: 20 mm/min.  , spindle power: 25 ,kW spindle speed range: 10 - 10000 rpm  , toolchanger positions: 10 toolholder: HSK-A100 max. tool diameter: 110 mm max. tool length: 450 mm max. tool weight: 12 kg  , coolant through spindle lubrication unit chip conveyor swivable head  , tables and cabinet in front of/next to the machine are not included in the scope of delivery please also take a look at the PDF document ,of this machine z-motion: 1,000 mm, x-motion: 2,300 mm, y-motion: 1,300 mm, control: HEIDENHAI ...

x-travel: 1.000 mm y-travel: 1.000 mm z-travel: 1.000 mm Control: 840 D Siemens Main spindle:: turning speed range - main spindle: 20 - 18.000 min/-1 power capacity - main spindel: 28 / 19 kW max. Torque: 121 Nm tool taper: HSK-A63 NC-Swivle milling head:: swivellable: B: -30 / +180 ° swivle time: 1,2 s pallet changer:: numbers of pallets: 2 size of pallet: 1.000 x 800 mm max. workpiece weight: 1.500 kg rotatable: C: 360 ° tool magazin:: number of toolpositions: 180 pos. tool taper: HSK-A63 total power requirement: 78 kVA weight of the machine ca.: 20,5 t dimensions of the machine ca.: 8,0 x 7,0 x 3,4 m Documents: Chip conveyor: Coolantsystem: through spindle coolant: pallet changer: Automatic Tool Changer: full splash guard: Rotary screen: elektr. hand wheel: 5 Axis - CNC Machining Center Universal DECKEL MAHO - DMC 100 U duoBLOCK - Swivel-Milling-Head (B-Achse) - NC-Rota ...

Description: Cabinet with sliding door 3 pieces cross beams with stations for Toolholder HSK 63 & SK 40 content consist of 36 pieces toolholder HSK 63 misc. Interfaces like Weldon, Shrink fit, collet and milling arbor Transportdimensions: 1.200 x 800 x 2.100 mm, ca. 180 kg Approx. Onsite Dimension. (l x w x h): 1,000 x 500 x 1,950 mm, weight approx.: 160 kg

x-travel: 1300 mm y-travel: 600 mm z-travel: 800 mm control: Heidenhain TNC 530 table dimensions: 1030 x 630 mm turning speed range: 10000 U/min power capacity at 60% / 100 % load: 30 / 17 KW max. torque at 40% / 100% load: 190 / 120 Nm feeds x/y/z: 30 m/min tool taper: HSK A63 tool magacine with: 80 Plätzen rotary table diameter: 630 mm : 40 bar slewability of milling head: +/- 105 ° table load: 2,50 t total power requirement: - kW weight of the machine ca.: 9,5 t dimensions of the machine ca.: - m 2022 Spindle overhaul 5-axis BAZ With: - HEIDENHAIN iTNC530 control - swivel head +/- 105 - electronic handwheel, - NC rotary table integrated (dia. 630mm) - Coolant system, coolant through the spindle 40bar - paper belt filter - tool changer 80-fold (HSK A63) - direct measuring system in x,y,z - Tool breakage control & length measurement - Machine on: 000h Spindle run: 0h The data for  ...

Key data: 650 mm, 650 mm, 650 mm

Machine: CNC 4-Axis Horizontal Machining Center with pallet station Manufacturer: STARRAG-HECKERT Model: CWK 400 D Dynamic Year of construction: 2003 Condition: very good Offer Type: Used Machine Specifications: Control: Siemens Sinumerik 840 D Speed range: 50 – 15,000 rpm. Spindle mount: HSK 63 Table: 500 x 400 mm Travel range: x = 650 mm y = 650 mm z = 650 mm Propulsion: 24 kW Remark: Pallet station with 6 stations plus a charging station, Tool magazine with 120 slots, 2 workpiece clamping towers with Hespatec hydraulic power unit and 2 workpiece clamping elements, an additional 19 clamping bolts for additional clamping elements, Spindle cooling, coolant and lubricant cooling, Renishaw MP10 Probe for Automatic Workpiece Measurement, Tool Breakage Control, IKZ with high-pressure pump and paper filter system, Conveyor 5 tool holders HSK 63 Total  ...

CNC processing centre Brand: TecnoTeam Type: Enjoy Basic 3 Achsen New machine Save your space: Standing upright means progress for human! - With a vertical CNC machine you save a lot of space: Wether for consuming material or a further machine, you have more space to use in your storage. Easy machine use: - TPA makes the use very easy, you find this software at several well-known machine brands - You see the programmed processings on a virtual display, no matter which process: if circle, bow, linear millings or drillings, - Create job lists in the CAM - Forget the calculator, the machine calculates for you. - For this software several genious tips and tricks are possible. With realiability to success: - Technoteam uses High-Quality components from well-established producers. - We modify the machine exactly to your needs: If you process massive wood, you get a stro ...

CNC drilling machine Make: Alberti Type: Vector SH New machine This CNC drilling machine machines workpieces from above with 29 spindles and has 4 controlled axes. Optionally, the Vector is available as Modulo-SH with a total of two machining heads (top with 30 spindles and bottom with 7 spindles). Machining head, working from above Manual or automatic loading and stacking with longitudinal workpiece transport Monolithic frame in welded strong steel Independent control of all axes with drilling cycle optimisation 4 independent axes X Workpiece transport along the X axis with vacuum suction cup for automatic alignment Y Machining head W Lateral pressure control Z Machining depth control Remark: Max. Workpiece dimensions: 3000x1200x50mm Min. workpiece dimensions: 300x130x12mm Geometry of workpieces: Length > Width / Length = Width / Length < 20% Width Machi ...

new CNC Drilling machine Brand: Alberti Type: Vector DH 6 controlled axes and two large drilling heads ensure high productivity on the Vector DH. This line can be fed manually or automatically. Two machining heads, working from above Manual or automatic loading and unloading with longitudinal workpiece transport Monolithic frame in welded strong steel Independent control of all axes with drilling and optional with fitting cycle optimization 6 independent axes X workpiece transport along the X-axis with vacuum suction cup for autom. alignment Y1 first machining head Z1 control of machining depth, first machining head Y2 second machining head Z2 Machining depth control, second machining head W lateral pressure control Remark: Max. Workpiece dimensions: 3000x1200x50mm Min. workpiece dimensions: 300x130x12mm Geometry of workpieces: Length > Width / Length = Width ...

CONTROLS   CNC controls HEIDENHAIN ITNC 530 WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 5   .. among of them simultaneous CNC axes: 5   X-axis travel: 600 mm   Y-axis travel: 450 mm   Z-axis travel: 450 mm   rotating range B-axis from: -115 °   rotating range B-axis up to: 30 °   rotating range C-axis from: 0 °   rotating range C-axis up to: 360 ° TABLE   clamping surface diameter: 450 mm   workpiece load (max): 200 kg SPINDLE / HEAD   spindle revolutions (max): 42000 /min   tool fixture: HSK E40   drive power: 10 kW TOOL MAGAZINE   number of positions: 36 AUTOMATIC WORKLOAD EQUIPMENT   number of store positions: 7   number of pallets: 3 ELECTRICAL SPECIFICA ...

Description: Well-maintained PAMA Speedmat HP3 Machining Centre with Pallet and Head Changer. Control SIEMENS Sinumerik 840 D sl Working area Workpiece dimensions (Ø x h) max.: 3,000 mm x 3,200 mm , Load capacity of pallet table max.: 8,000 kg Table dimensions: 1,250 x 1250 mm Work spindle diameter: 130 mm Number of interchangeable pallets: 2 Axis travel Axis travel X-axis: 3,000 mm Axis travel Y-axis: 2,000 mm Axis travel Z-axis: 3,200 mm + W-axis max.: 800 mm Table rotation B-axis: 360 Axis speed and Power transmission Table speed (B axis) max.: 7 upm Table torque max.: 48  , Feed rate X, Y, Z axis: 0.5 - 10,000 mm/min Feed force X, Y, Z axis max.: 20,000 N Rapid traverse X, Y, Z axis: 30 m/min Spindle drive speed max.: 6,500 rpm , (the actual speed at the tool varies depending on the machining head) Angle head TS 20 Tool changer Tool  ...
