GeneralUniversal Milling Machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal650 mmCross520 mmVertical475 mmFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgTechnical DataType of main driveAC Drive power (100% DC)25 kWDrive power (40% DC)35 kWSpeed range20-20000 rpmSpindle taperHSK-63A DIN 69893 Clamping SystemDIN ISO 7388-3-A, AD Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minDirect measuring systemDirect path measuring systemSpindle speed 20.000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 630 x 500mm / 24.8 x 19.6 in swivel ra ...

Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minGeneralUniversal Machining Centre Vertical headstock Tool change system double gripper NC-Swivel rotary table with pallet carrier 3 pallets 500 mm x 500 mm / 19.7 in x 19.7 in T-slots according to DIN 55201-A2 linear pallet changer coolant tank 500 l / 132 gallon chip conveyor with netting band filter integrated, coolant ring jet; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal735 mmCross650 mmVertical560 mmFloor space/WeightWeight approx.16800 KgDirect measuring systemDirect path measuring systemCabineFull protection cabinPackage Mill / Turn HSK-A 63Package Milling / Turning: Upgrade NC-swivel rotary table to Milling - Turning / direct drive Pallet C-axis d 630 mm / 24.9 in Speed C-axis 1.000 rpm Integrated balancing sensor Motor ...

New CNC working machine brand: Cosmec Type: Smart 30, 5 Achsen Configuration example: other equipment possible on request The smart serie: - Flexibility through cantilever construction - Best equipped for door processing - Protection by laser system (instead of step mats) - Especially good for machining light / small workpieces The controlling: OSAI CNC system control + Aspan CAD-CAM software: - Aspan uses simple commands to execute the machining process - By entering dimensions you can precisely position the machining operations - The machining operations are displayed on the virtual workpiece. - Diverse macros facilitate programming (of holes, slots, linear milling, arc milling...) Aspan Doors - Software module for easy creation of programs for door processing. - Different door types are already stored (doors with milled arches, round doors...) - Doors can ...

new CNC working center Brand: Cosmec Type: Smart 30, 4 Axis example configuration: other equipment on request the smart serie: - Flexibility through cantilever construction - Best equipped for door processing - Protection by laser system (instead of step mats) - Especially good for machining light / small workpieces the controlling: OSAI CNC system controlling + Aspan CAD-CAM Software: - Aspan uses simple commands to perform machining - By entering dimensions you can precisely position the machining operations - The machining operations are displayed on the virtual workpiece. - Various macros facilitate programming (of holes, slots, linear milling, arc milling...) Aspan Doors - Software module for easy creation of programs for door processing - Different door types are already stored (doors with milled arches, round doors...) - Doors can be modified individ ...

x-travel: 450 mm y-travel: 400 mm z-travel: 320 mm tool taper: HSK 63 spindle turning speed range: 0 - 10000 U/min rapid traverse: 30 m/min System for processing fittings, valve housings, etc. consisting of 1 used flexible manufacturing cell (transfer machine) make RIELLO, model VERTIFLEX VFX 450-2 / 1-0 / 1-V, YOM 2010, with 2 pcs. 3-axis machining modules, each with 8-pos. tool turret, travel paths module 1: X1 / Y1 / Z1 = 450/400/320 mm, travel paths module 2: X2 / Y2 / Z2 = 450/400/320 mm, tool fixture HSK 63, rotary table with 2 integrated workpiece carriers á 400 mmø (B axis per workpiece carrier 360 x 1 °), coolant through spindle Acc.: chip conveyor, coolant device connected by ABB handling robot with 1 used flexible manufacturing cell (transfer machine) make RIELLO, model VERTIFLEX VFX 450-2 / 2-0 / 1-V, YOM 2003, with 3 pcs. 3-axis machining modules, each with 8-po ...

x-travel: 630 mm y-travel: 700 mm z-travel: 630 mm Control: Meldas M650 tool adaptor: HSK-A63 Table dimensions: 450x450 mm Table load: 400 kg number of spindle speeds: 300 - 20.000 min-1 total power requirement: 30 kW weight of the machine ca.: t dimensions of the machine ca.: m FEED RATE Rapid feed rate X,Y 120 m/min Rapid feed rate Z 60 m/min Rapid feed rate B 120 m/min Cutting feed rate X,Y,Z 0,1 – 60 m/min SPINDLE RPM spindle 300 – 20.000 min-1 Spindle taper HSK-A63 Coolant Through spindle ATC Tool holder Special HSK-A63 2 Face contact tool Tool magazine storage 40 pcs Tool change time 2,5 sec. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Generalin travelling column construction NEW DMG MORI Design swivel head (B-axis) tool clamping according to DIN 69872; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal2600 mmCross1100 mmVertical900 mmTechnical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical80/60/60 m/minTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight15 KgMax. tool length500 mmMax. tool diameter with occupied adjacent pockets115 mmMax. tool dia. with free neighbouring pockets160 mmDirect measuring systemDirect path measuring systemCabineFull protection cabinDynamic package for DMF 260 linear (Y1100)Dynamic package for DMF 260 linear (Y1,100 mm) linear drive X-axis with 80 m/min // 262.48 ft/min rapid move XYZ 80/60/60 m/min // 262.48/196.86 ft/min, Acceleration XYZ 5/6/6 m/s² // 16.4/ ...

GeneralUniversal Machining Centre Vertical headstock Tool change system double gripper NC-Swivel rotary table with pallet carrier 3 pallets 500 mm x 500 mm / 19.7 in x 19.7 in T-slots according to DIN 55201-A2 linear pallet changer coolant tank 500 l / 132 gallon chip conveyor with netting band filter integrated, coolant ring jet; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmFloor space/WeightWeight approx.18300 KgDirect measuring systemDirect path measuring systemCabineFull protection cabinNC swivel rotary table with pallet carrierTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 500 KgMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000  ...

GeneralTravelling column machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal3000 mmCross1100 mmVertical1050 mmFeed drives:Feed rate X / Y / Z80000/80000/80000 mm/minRapid feed X / Y / Z80/80/80 m/minNC-swivel head (B-axis)Controlled NC-swivel milling head (B-axis) with clamping in position. Continuously positioning NC swivel milling head with integrated motor spindle for 4/5 axes positioning and simultaneous machining. Swivel torque: 3,300 / 2,300 Nm // 2,433 / 1,696 ftDynamic package for DMF 300|11 linearDynamic package for DMF 300|11 linear Linear motor X-axis with 80 m/min // 262.48 ft/min Rapid speed XYZ 80 m/min // 262.48 ft/min Acceleration XYZ 8 m/s² // 26.25 ft/s² Active cooling for Linear motorPackage Mill / Turn 12,000 rpm, HSK-A100Package Mill / Turn, 12,000 rpm HSK-A100 (Only available for Siemens 840D solutionline) NC-Mill-Turn-table d 1,050 mm  ...

GeneralVertical Machining Centre; Control: 3D control Heidenhain iTNC 530 Technical DataFeed rate longitudinal/transverse/vertical1-90000/1-90000/1-90000 mm/minRapid traverse longitudinal/transverse/vertical90/90/90 m/minWorking area 1Longitudinal885 mmCross600 mmVertical600 mmMiscellaneousClamping SystemHSK-A 63 Colour Floor space/WeightDimensions (L x W x H)4,9 x 4,3 x 3,2 mWeight approx.12000 KgCabineFull protection cabinDMC 75 V linear in 5-axes-versionAdditional price DMC 75V linear in 5-axes-version - motion in X=885mm und Z=600mm - spindle speed up to 18.000rpm, - tool-taper HSK-A 63, - swiveling range B-axis +10° to -110°, - swiveling speed B-axis 50rpm, - max. torque 750Nm / 553ft/lbs - clampiTool magazine 150 pocketsTool magazine 150 pockets Tower type magazine Only available for HSK Tool holders. (differently from standard)Number of tools 150Preparation measuring probe TS640 ...

GeneralHSC-Precision Centre - Active chiller for main spindle and linear drives - Active chiller for electrical cabinet - Direct absolute measuring system with air purge - scraper-type chip-conveyor and bed-flushing; Control: 3D-control Heidenhain iTNC 530 HSCI Technical DataSpindle taperHSK-A 63 Feed rate longitudinal/transverse/vertical1-90000/1-90000/1-90000 mm/minRapid traverse longitudinal/transverse/vertical90/90/90 m/minWorking area 1Longitudinal750 mmCross600 mmVertical560 mmTool changerApplicationVertical Type of magazineWheel Type of gripperPick up Number of tools30 Floor space/WeightDimensions (L x W x H)6,65 x 7,6 x 3,18 mWeight approx.12000 KgSplash guard equipment/cabinSplash guard equipment/cabin with illumination and sliding doors on operators side and front sideMotor spindle with HSK-A 63Drive power (100% DC) 25 kWDrive power (40% DC) 35 kWSpeed range - 18.000 rpmSpindle ...

x-travel: 3.000 mm y-travel: 1.600 mm z-travel: 1.200 mm control: HEIDENHAIN iTNC530 HSCI B-axis (swivelling head): +/- 100 ° C-axis (milling head rotation axis): +/- 240 ° feed and rapid traverse: : rapid feed Y,X,Z: 40.000 m/min Rapid traverse B- and C-Axis: 50 rpm Accelerations (X, Y and Z): 4 m/s² Machine table:: : Clamping surface: 3.500 x 1.750 mm T-slots: 27 x 22 mm H12 T-slot - distance: 125 mm max. workpiece load: 7.000 kg/m2 Max. distance table to spindle nose: 1.356 mm 2-Axis Fork Milling Head T21C: turning speed range:: 10- 24.000 min-1 Drive power (S1/S6):: 42/50 KW Torque (S1/S6):: 67/84 Nm Tool bore: HSK-A 63 tool magazin:: : number of tools: 50 tool holder: DIN 69873 HSK A63 Max. Ø tool: 115 mm max. tool-Ø adjacent slots free : 125 mm max. tool length: 300 mm max. tool weight: 12 kg coolant equipment: : tank capacity: 1.400 l connected load: voltage: 3x 40 V 50 Hz  ...

YOM 2009 X axis travel 28.000mm Y axis travel 6.500mm W axis travel 2.000mm Z axis travel 1.500mm Table dimensions 25.000X5.000mm Automatic head changer with Nr. 03 heads Nr.10 planos 5.000X2.500X300mm CNC SIEMENS 840 D nr.03 axes automatic head in continuos, spindle speed max 4.000rpm,56 Kw, HSK A 100 Vertical head max spindle speed 3.000rpm,56 Kw, HSK A 100 Angular head max spindle speed 3.000rpm,56 Kw, HSK A 100 High pressure refrigeration trough spindle (50 bar) ATC 120 positions

CNC 5-axis gantry milling machine Jobs JomaX 265 W Year of construction 2016 Siemens 840D SL CNC controller Panel size 25,000 x 5,000 mm (10 panel panels) Plate field load per panel field max. 10,000 kg Rapid traverses X,Y,Z/W 28,000/8,000 mm/min. C/A axis 30°/s Distance spindle nose ~ table max. 3,900 mm Distance between uprights 6,000 mm Travel X 28,000 mm Y 6,500 mm Z 1,500 mm 2-axis NC swivel milling head. C 400 (+/- 200°). A 220° +/- 110° Spindle holder HSK-A100 Spindle drive power 42/53 kW Spindle torque max. 1,337/1,687 Nm Spindle speeds up to 3,000 rpm. 1-axis angle milling head 90° BUSS With C-axis +/-200° Spindle holder HSK-A100 Spindle drive power 30/37 kW Spindle torque max. 955/1,178 Nm Spindle speeds up to 2,800 rpm. Vertical milling head BUSS Spindle holder HSK-A100 Spindle drive power 45/56 kW Spindle torque max.1,433/ ...

x-travel: 31000 mm y-travel: 4310 mm z-travel: 1500 mm column daylight: 4000 mm Main spindle:: turning speed range - main spindle: 16000 U/min power capacity - main spindel: 34 / 44 kW tool taper: HSK A63 c-axis: +/- 360 ° A-Axis: +/- 110 ° Distance table surface - crossbeam bottom: 2570 mm work table:: table surface area: 30000 x 3000 mm max. workpiece weight: 16 t Tool-Presetter:: number of toolpositions: 120 pos. tool taper: HSK A63 rapid traverse ( X / Y / Z ): 20 / 20 / 16 m/min control: Heidenhain iTNC 530 total power requirement: - kVA weight of the machine ca.: 100 t dimensions of the machine ca.: 32 x 7,3 x 6,5 m unused 5 Axis Gantry Machining Center with moving Portal. The direct driving method using a torque motor eliminates precision problems caused by wear over time and by installing encoders on the torque motor side of the A and C axes, the actual turning angle can be  ...

- Description 63 Acon CTS - Spindle 20,000 rpm HSK - APS (Advanced Process System) (only with Heidenhain CNC) - Advanced APS (Extended Advanced Process System) - RNS (Remote Notification System) - Tool magazine ATC 220 HSK A63. - Exchange station - Tilting table with System 3R attachment for Dynafix 280x280 pallets Complete protection booth with transparent ni polycarbonate panels - Transparent scratch-resistant guards - Chip and coolant collection tank - Extended heavy-duty chip conveyor - 580-l paper filter with CTS 18-80 bar - Rotoclear - Oil mist cooler. - Manual workpiece/machine washing device - ITC (Intelligent Thermal Control) - ITC 5AX (Intelligent Thermal Control 5Axis) - Tool control with laser - Air blower for tool cleaning - Provision for workpiece touch probe - Workpiece touch probe with HSK 63 A/B connection - Pallet changing unit for System 3R Dynafix ...

x-travel:1600 mm y-travel:1300 mm z-travel:700 mm distance between columns:1500 mm distance spindle center to table:225-925 mm table-size:1800 x 1300 mm table load:4000 kg T-slot (width-distance-quantity):22x 160 x 8 mm spindle taper:HSK-A 63 spindle speed:24000 U/min spindle drive:25/33 kW Spindle motor torque:72.6/95.8 N.m. rapid traverse in x-y-z axis:30000 mm/min Cutting feed rate X/Y/Z axis:1~20000 mm/min Tool changer:20 fach max. tool diameter:100/130 mm max. tool length:300 mm max. tool weight:8 kg total power requirement:80 kva Weight approx.:22 t Machine size (LxWxH):5660 x 5295 x 3930 mm CNC controller:Heidenhain TNC 620 spindle:IBAG electric spindle 24000rpm HSK-A63 Scales:Heidenhain automatic tool changer:20 fach chip conveyor - auger:2 Stk. Used portal milling machine with extensive accessories at a special introductory price. Important manufacturers of the components used i ...

x-travel:1000 mm y-travel:1150 mm z-travel:700 mm table-size:900 mm table load:1500 kg spindle speeds:10.000 1/min spindle drive:Motorspindel von Cytec CS34-180-A 34&42KW/160&200 Nm spindle taper:A100 HSK T-slots:18mm/7/100 mm milling feed range:20.000 mm/min rapid traverse feeds:X/Y/Z: 24 m/min diameter of tools max.:150 mm workpiece length:300 mm weight of tools max.:20 kg weight of the machine ca.:15 t dimensions of the machine ca.:s. Katalog m CNC controller:Heidenhain iTNC-640 HSCI-Steuerung cnc rotary table:von Cytec; mit Ø900mm; 800 1/min Drehmomenttisch (AS3347) + HSK-T63/100 Spindel & ATC + TNC-640 Fräsdrehzahlregelung B-axis:Fräskopf, 0-180° c-axis:0,001° automatic tool changer:HSK-A/T100; 60 fach Scales:in X/Y/Z von Heidenhain mit Druckluft inner coolant:20

Technische Daten: - Verfahrbereich X - Achse 3700 mm - Verfahrbereich Y - Achse 1600 mm - Verfahrbereich Z - Achse 200 mm - Arbeitsbereich X - Achse 3685 mm - Arbeitsbereich Y - Achse 1550 mm - Arbeitsbereich Z - Achse 70 mm - Lade- Entladegeschindigkeit 15 m/min - Frässpindel luftgekühlt HSD / Italy 9.6 kw, HSK 63 (Option 11 kW HSK 63F) - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler,Karusell 8-fach, mitfahrend - Bohraggragat VERTIKAL 5 + 4 FAM / Italian 5 Spindeln in Y-Richtung, Bohrabstand 32 mm 5 Spindeln in X-Richtung, Bohrabstand 32 mm - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren YASKAWA - hochgenaue THK Linearführungen mit Langzeitschmiereinheit in X, Y, Z Achse - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 80 m/min - max. Arbeitsgeschwindigkeit 25 m/min - Arbeitsgenaui ...

Technische Daten: - Verfahrbereich X - Achse 2900 mm - Verfahrbereich Y - Achse 2160 mm - Verfahrbereich Z - Achse 200 mm - Arbeitsbereich X - Achse 2850 mm - Arbeitsbereich Y - Achse 2130 mm - Arbeitsbereich Z - Achse 70 mm - Lade- Entladegeschindigkeit 15 m/min - Frässpindel luftgekühlt HSD / Italy 9.6 Kw HSK 63 (Option 11 kW HSK 63F) - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler,Karusell 8-fach, mitfahrend - Bohraggragat VERTIKAL 5 + 4 FAM / Italian 5 Spindeln in Y-Richtung, Bohrabstand 32 mm 5 Spindeln in X-Richtung, Bohrabstand 32 mm - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren YASKAWA - hochgenaue THK Linearführungen mit Langzeitschmiereinheit in X, Y, Z Achse - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 80 m/min - max. Arbeitsgeschwindigkeit 25 m/min - Arbeitsgenauig ...

Control type: CNC Sinumerik 840D-SL x-way 1135 mm y-way 1050 mm z-way 750 mm table size 1400 x 1050 mm Table load 2500 kg max. workpiece size LxWxH 1400 x 1240 x 750 mm Speed 10000 rpm feed speeds X/Y/Z Axis 40000 mm/min Expressspeeds x/y/z 40000 mm/min Tool holder HSK-A100 HSK Number of places in the tool magazine 30 places max. tool weight 20 kg max. tool length 395 mm max. tool diameter 110 mm Machine height 3294 mm Drive power - spindle motor 44 kW machine weight approx. 17.9 t Space requirements approx. 15 m2 Information: Universal milling machine in mono BLOCK design (3-axis) - available September 2019 - only 3800 spindle hours, 13400 power-on hours Equipment / Accessories: - Coolant system - High-pressure pump - Chip conveyor - Hand-held panel - BALLUFF option - Documentation

x-travel: 164 mm y-travel: 210 mm z-travel: 70 mm Control: CNC 6000 turning speeds: 40000 U/min tool adaptor: HSK E 25 tool change unit: 7-fach total power requirement: kW weight of the machine ca.: 0,9 t dimensions of the machine ca.: 2,3x1,0x1,9 m HSC Milling Machine Portal stand construction for milling and engraving High-frequency spindle HFS 301 40,000 min-1, 3000 watts, HSK 25 E recording Tool length scan Laser sensor system for measuring the workpiece length and workpiece diameter NC controlled part head CNTK 200 center height: 200 mm Clamping device of a groove table Clamping device for clamping round components Coolant circulation system Collet holder Alpha CAM software (AC Mill 2D) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Center distance: 0 mm Grinding head Z-axis: 0 mm Center height: 0 mm CNC Brand: 0 CNC Model: 0 Control: SIEMENS SINUMERIK 840 D / WINDOWS XP Operating hours: 32767 Technical data Number of axis total: 5 Linear Axes direct driven Rotary axes axes direct drives Direct measuring system X, Y and Z axis X axis: 400 mm Y axis: 250 mm Z axis: 250 mm grinding diameter: 1 - 10 mm Tool lenght Distance from table to A axis: HSK 50E Collet attachment: 15 W Spindle nose: HSK: 50 Grinding spindle speeds: stepless up to: 12000 rpm Grinding spindle motor: 8 kW Total power required: 20 kVA Machine´s weight about: 2800 kg Overall dimensions machine: Length: 1990 mm Width: 1640 mm Height: 1960 mm Various accessories: Grinding wheel changer 5-fold Automatic Workpiece guiding system Central lubrification fire extinctor

FMS SYSTEM: Machining Cell consisting of: Two 5-Axis machining Centres 8-Pool Pallet System(1250 x 1250mm x 3.000kg) Pallet Storage System X= 3.000 mm, Y= 2.000H/1.720V, Z= 2.000mm; A= 175°, B=0,001°; 640 Pos. ATC ; Spindle Taper HSK-A100; Spindle n= 3.000; Motor 50kW; Feeds: X,Y= 40m/min, Z= 30m/min Siemens 840D, Chip-conveyor; Serial No. 1450-03 and 1451-3, both from 2003 FR: À VENDRE MAINTENANTFMS SYSTEME ; 8 Pos. Piscine à palettes (1250 x 1250mm x3.000kg). 2x MCM Jet Five Mirror 5 axes CENTRE D'USINAGE/BEARBEITUNGSZENTREN/MACHINE CENTERS, X= 3.000, Y= 2.000H/1.720V, Z= 2.000mm ; A= 175°, B=0,001° ; 640 Pos. ATC ; Cône de broche HSK-A100 ; Broche n= 3.000 ; Moteur 50kW ; Alimentation : X,Y= 40m/min, Z= 30m/minSiemens 840D, convoyeur à copeaux ; numéros de série 1450-03 et 1451-3, à partir de 2003

FMS SYSTEM; Machining Cell consisting of: Two 5-Axis Machining Centres 12-Pool Pallet System (630 mm X 630 mm); Pallet Storage System X= 750 mm, Y= 860 mm, Z= 850mm; B= 0,001°; 334 Pos. ATC Spindle Taper HSK-A100; Spindle n= 11.000; Spindle 25 kW; Feeds 32.000mm/min; Chip-conveyor; Coolant System Serial No. 1283-01 (2001) Siemens 840D; and Coolant System Serial No. 1024-98 (1999) Siemens 840C FR: À VENDRE MAINTENANTFMS SYSTEME ; 12 Pos. Piscine à palettes (630 X 630mm) ; 2x horloge MCM 5 axes CENTRE D'USINAGE/BEARBEITUNGSZENTREN/MACHINE CENTERS ; X= 750, Y= 860, Z= 850.mm ; A= .. ? ? B= 0,001° ; 334 Pos. ATC ; cône de broche HSK-A100 ; broche n= 11.000 ; broche 25 kW ; avance 32.000mm/min ; convoyeur à copeaux ; système de refroidissement n° 1283-01 (2001)Siemens 840D ; et système de refroidissement n° 1024-98 (1999)Siemens 840C

GeneralPrecision centre - Linear drive package - Active cooling for spindle, linear drives and electrical cabinet - Frame temperatur control - Direct measuring system - Chiptray, coolant/airblast changing - Full cabin including 2nd door; Control: 3D-control Siemens 840D sl Operate Technical DataSpindle taperHSK-A 63 Feed rate longitudinal/transverse/vertical1-80000/1-80000/1-80000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minWorking area 1Longitudinal650 mmCross600 mmVertical380 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools120 Floor space/WeightDimensions (L x W x H)7,28 x 6,63 x 3 mWeight approx.9600 KgRigid tableRigid table clamping area 850 x 600 mm // 33,46 x 23,62 inch loading weight max. 700 kg // 1543,23 lbsSpindle speed up to 28,000rpm Shaft CoolingSpindle speed 20 up to 28,000 rpm within shaft cooling inclusive MPC Machi ...

GeneralPrecision centre - Linear drive package - Active cooling for spindle, linear drives and electrical cabinet - Frame temperatur control - Direct measuring system - Chiptray, coolant/airblast changing - Full cabin including 2nd door; Control: 3D-control Siemens 840D sl Operate Technical DataSpindle taperHSK-A 63 Feed rate longitudinal/transverse/vertical1-80000/1-80000/1-80000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minWorking area 1Longitudinal650 mmCross600 mmVertical380 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools120 Floor space/WeightDimensions (L x W x H)7,28 x 6,63 x 3 mWeight approx.9600 KgRigid tableRigid table clamping area 850 x 600 mm // 33,46 x 23,62 inch loading weight max. 700 kg // 1543,23 lbsSpindle speed up to 28,000rpm Shaft CoolingSpindle speed 20 up to 28,000 rpm within shaft cooling inclusive MPC Machi ...

- X: 4050 mm - Y: 2050 mm - Z: 250 mm - Clamping area: 4200 x 2150 mm - Speed range: 12 kW - 36,000 rpm - Spindle holder: HSK E40 - Control: MDSI 6.0 on XP computer - Tool changer: 10-fold - Tool diameter max.: 13 mm - Switching hours: 23589 h - Spindle On: 7736 h - Total power: 15 kW - Machine weight: 4900 kg - Space requirement (W x D x H): 6.7 x 3.12 x 2.6 m Details Tool length scanning, spindle type: Reckerth type MSPF-125/36-12/FBLP/HSK-F40, frequency converter company Berges type SWPK 400150 H12, vacuum pump company Busch type RA 0255 D 502 Q0ZZ, industrial vacuum cleaner: company Depureco type T22/100, cooling pump: company Chilly 25-5 Accessories overhauled replacement spindle Reckerth with acceptance protocol, 10 holders with collets, 15 more collets, documentation

Working range Diameter of the legs: 350 mm Rotation diameter: 360 mm X-trajectory: 725 mm Z-trajectory: 547 mm Y-trajectory: 307 mm Main spindle Spindle flange in accordance with DIN 55026: size 8 Spinning bearings - ? front: 120 mm Maximum speed: 6000 rpm Main drive AC motor 40% ID: kW 45 Maximum power: 58 kW Full power from spindle speed: 480 rpm Moment 40% ID: 480 Nm Maximum moment: 620 Nm Transport drive High speed X/Y/Z: 45/45/30 m/min Transport force in X/Y/Z: 5,5/11/11 KN Ball roller spindle in X/Y/Z: 40 mm Revolver star Intake cylinder shaft DIN 69880: 4 gang Shaft ? 40 mm Grinding spindle 1: HSK C63, U/min 9.000, kW 19 Grinding spindle 2: HSK C32, U/min 42,000, kW 7.5 hydr. Grinding spindle: U/min 32,000, kW 0.9 Electrical equipment Operating voltage: 400 V Control voltage ? DC: 24 V Control voltage ? AC: 230 V Frequency ? 50 Hz Sizes and weights Length: 5060 mm Width: 1960 mm H ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 14000 mm Cross Y: 1500 mm Vertical Z: 2650 mm Positions ATC: 0   CNC Brand: Fidia CNC Model: M20 / MSG     X-Axis:               14.000mm Y-Axis:               1.500mm Z-Axis:               2.650mm Power on spindle:     28kW Spindle speeds:       4000Rpm Spindle Taper:        50ISO/Bt/Mk Feed rate X-Axis:     20.000mm/min. Feed rate Y-Axis:     20.000mm/min. Feed rate Z-Axis:     20.000mm/min. Millinghead auto-index:2,5 x 2,5 ° Length:               18.000 mm  Width:                4.000 mm   ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 100 mm - B-axis ±110° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 5 bar; 20l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor - USB interface, Ethernet interface; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length750 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmC-Axis Speed-5000 rp ...

Year of manufacture: 2008, Machine No.: 670 - Working range X 300, Y 280, Z 250 mm - Feed speed 0.01 - 16,000 mm/min - Acceleration 8 m/s2 Resolution: 0.1 μm Position spread Ps: ±0.5 μm CNC precision dividing head (4th and 5th axis) - System 3R Macro Chuck - Brushless servo drive, fully digital - Feed speed C/B 7000 / 3000 °/min - Swivel range B from -10 to +120 degrees - Heidenhain iTNC 530 smarT.NC - High frequency coil HSK E25 500 -50'000 rpm - Tool changer 95-fold - Prepared for external workpiece changer - Minimum quantity lubrication -Suction - CO2 extinguishing system - Laser for tool measurement (Blum) - Infrared 3D probe - External dry cooler - External spindle cooling unit - External coolant device with cooling - Vorma machine light Accessories - Shrink device Haimer Power Clamp Nano - HSK E25 mounts (CORE) ø 2 - 6mm (Total 115 pcs; Shri ...

Machine type Machining center universal BAZ Manufacturer Heller Model MCS-H / U 300 Year of construction 2002 Condition good (used) Specifications Bright MCS-H/U 300 Year of construction: 2002 Control: Siemens 840 D Workspace: Longitudinal stroke X-axis 1000 mm Vertical stroke Y-axis 800 mm Transverse stroke Z-axis 1100 mm Lifting position longitudinally to the center of the table MCS-H X-axis +500 to -500 mm Lifting position vertically over. Palettes. MCS-H Y-axis +120 to +920 mm Lifting position transverse to the center of the table MCS-H Z-axis +200 to +1300 mm Guidance system: Linear compact roller guide version Size 55 Transfer elements: Accuracy Ball Screws Diameter x Slope Diameter 50 x 20 mm Feed drive system: Three-phase servo motors Closed design Feed forces: X-axis at ED S3-40% 15000 N Y-axis at ED S3-40% 15000 N Z-axis at ED S3-40% 20000 N Positio ...

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool diameter with occupied adjacent pockets80 mmMax. tool length315 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.12600 KgNC swivel rotary table integrated in rigid tableType of Measuring system Direct measuring systemTable surface 800 x 650 (Ø 650) mmRotation Speed 5. Axis 20 rpm5. Axes (swivelling range) +120/-120 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between T-Slots 63 mmNumber of Slots 9Slot width 1 ...

GeneralUniversal machining centre New DMG MORI Design; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal400 mmCross400 mmVertical375 mmTechnical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmFloor space/WeightWeight approx.6800 KgDimensions (L x W x H)6,21 x 6,58 x 2,69 (6,21 x 7,38 x 2,69) mSpindle speed 28.000 rpm HSK-A63Spindle speed 20 up to 28.000 U/min Motor spindle with shaft cooling power 30/20 kW // 40.23hp/ 26.82 hp (40/100% DC) torque 40/27 Nm (40/100% DC) tool clamping HSK 63 according to DIN69893 (different from standard)Chain-type tool magazine 60 po ...

max. tool diameter: 400 mm : 180 mm operating pressure: 2 bar ROTATHERM chamber washing systems are used in all areas of industry and Craftsmanship for cost-effective cleaning of a wide variety of items to be cleaned and materials used. The parts are cleaned like in a dishwasher. Inserted into one Wire mesh basket they are in the closed device with a hot Lye shower washed from all sides. The machine will be selected after the Temperature and washing time set in operation. A centrifugal pump promotes the Washing water circulates to the nozzle system, which at the same time moves the basket in offset rotation. (Optional electric basket drive) After the cleaning process is complete, the device switches off automatically. the Parts can also be removed beforehand. In this case, when lifting the the pump is automatically put out of operation. ROTATHERM chamber washing systems are available in  ...

Key data: 2100 , 9

CNC milling machine 2132 OPTIMAT 2100x3200 ATC 100% European product New for 2022! CNC milling machine 2132 with a weight of approx. 4100 KG and a working table area of 2100x3200mm, equipped with an automatic 12th tool linear magazine cooperating with the HSD / HITECO 9kW 24000rpm electrospindle (ceramic bearing, HSK F63 interface) enabling the use of tools with a diameter up to 26mm inclusive! Technical parameters: Effective working size: 2100x3200mm - Trouble-free processing of the entire size of the furniture board - Vacuum workbench made of HPL Machine weight: approx. 4100KG - The frame of the machine made of the highest quality alloy is welded in its entirety, then subjected to the stress relieving process in a special chamber with special conditions, and then milled. This process ensures that excellent results of structural rigidity and stability are achieved Z-axis stro ...

x-travel: 2.000 mm y-travel: 1.000 mm z-travel: 800 mm Control: Fidia C20 CNC Main spindle:: turning speed range - main spindle: 3.200 - 32.000 min/-1 power capacity - main spindel: 6 kW tool taper: HSK 40 E swivellable: B: +/- 110 ° indexing: B: 0,001 ° rotatable: C: +/- 361 ° spindle diameter in front bearing: 45 mm distance spindle nose and table: max. 896 mm work table:: table surface area: 2.500 x 1.500 x 300 mm table height: 345 mm max. table load: 10.000 kg T-slots: 6x 22 x 250 mm Tool-Presetter:: number of toolpositions: 20 pos. tool taper: HSK 40 E feeds:: rapid traverse ( X / Y / Z ): 20 m/min Accelaration: 3 m/s² total power requirement: - kW weight of the machine ca.: 9,5 t dimensions of the machine ca.: 6,0 x 4,0 x 3,8 m Documents: spindle oil cooler: hydraulic system: Automatic Tool Changer: tool setting: Laser tool holders: 16x CNC-Machiningcenter Universal FID ...

control: Siemens 840-D tool taper: HSK & VDI 40 - - -: - - - - - - Vertical Turning Machine | EMAG - VTC 250 DUO ED with ITC (7-30 bar) and driven tools Additional equipment: - Workpiece grippers on all 3 turrets, - 6-station end-processing turret with HSK tool holder, - 12-station disc turret for driven tools and VDI 40 tool holder, - 12-position disc revolver with cross slot and VDI 40 tool holder, - NC - clamping head, - NC bezel, self-centering, - EMAG hydraulic double-piston clamping cylinder, - tailstock down, - Hydraulic double-piston clamping cylinder at the top, - chip conveyor, - Knoll plant 1.500 l, - Coolant supply 7-30 bar, - OP20: shaft chuck with retractable jaws and face drivers, - Tool holder with Capto 5, - Artis quick-change system for tool and process monitoring, - Tool pack is included, The machine is in a well-maintained condition and can be inspected at any time  ...

GeneralUniversal machining centre; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minWorking area 1Longitudinal600 mmCross500 mmVertical500 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmDie and Mold Package linear incl. B-/C-TorqueDie and Mold Package linear incl. B-/C-Torque Dynamic package V-type Eagle timing belt for Z axis Torque table B-/C-axis including ATC AVD - Heidenhain or MVC - Heidenhain (starting NC 340590 11) APC and Top Speed - Siemens High End cooling unit for machiSpindle speed 20.000 rpm, HSK-A63Motor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20,000 min- ...

x-travel: 600 mm y-travel: 855 mm z-travel: 750 mm table surface area: 400 x 400 mm clearance diameter: 720 mm pivoting angle: -185 / +45 Grad workpiece weight: 340 kg table rotation speed: 50 U/min tool taper: HSK-A 63 spindle turning speed - stepless: 12000 U/min spindle motor: 40 kW tool diameter: 70 mm tool length - max.: 365 mm weight of tools max.: 8 kg rapid travel range: 70/45/90 m/min control: Heidenhain iTMC 530 total power requirement: 54 kVA weight of the machine ca.: 15 t dimensions of the machine ca.: 6,1 x 2,47 x 3,17 m The 5-axis universal machining center G350 offers nearly unlimited possibilities in the milling of workpieces of various materials. materials. equipped with: - CNC control Heidenhain iTNC 530 - 2-fold Pallet Changer - NC swivel rotary table (A-/B-axis) - tool changer 40 places (HSK A63) - IKZ / coolant system 3-22,5bar - chip conveyor The data for this ad ...

x-travel: 600 mm y-travel: 855 mm z-travel: 750 mm table surface area: 570 mm clearance diameter: 720 mm workpiece weight: 400 kg pivoting angle: -185 / +45 Grad table rotation speed: 50 U/min tool taper: HSK-A 63 spindle turning speed - stepless: 12000 U/min spindle motor: 40 kW tool diameter: 70 mm tool length - max.: 365 mm weight of tools max.: 8 kg rapid travel range: 70/45/90 m/min control: Heidenhain iTMC 530 total power requirement: 47 kVA weight of the machine ca.: 13 t dimensions of the machine ca.: 6,1 x 2,47 x 3,17 m The 5-axis universal machining center G350 offers nearly unlimited possibilities in the milling of workpieces of various materials. materials. equipped with: - CNC control Heidenhain iTNC 530 - NC swivel rotary table (A-/B-axis) - tool changer 40 places (HSK A63) - IKZ / coolant system 3-22,5bar - chip conveyor 2 identic machines available The data for this ad  ...

GeneralUniversal Milling Machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal650 mmCross520 mmVertical475 mmTechnical DataType of main driveAC Drive power (100% DC)16 kWDrive power (40% DC)21 kWSpeed range20 - 15000 rpmSpindle taperSK40 Tool holder DIN ISO 7388-1-A Clamping SystemDIN ISO 7388-3-A, AD Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgDirect measuring systemDirect path measuring systemSpindle speed 15,000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 15,000 min-1 Output 21 kW / 16 kW (28 hp / 21.5 hp) Torque 111 Nm / 85 Nm (82 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 630 x 500mm / 24.8 ...

Control unit Heidenhain iTNC 530 X-Axis travel 800 mm Y-Axis travel 600 mm Z-Axis travel 500 mm X-Y-Z axes speed 20 - 20 - 40 m/min Table length 610 mm Table width 610 mm Table load 120 kg Spindle speed 24000 rpm Spindle taper HSK A 63 - HSK E 50 Motor power 25/21 kW Tool changer 120 positions Dimensions L 6500 x W 5500 x H 3000 mm Weight 8300 kg

x-travel: 800 mm y-travel: 600 mm z-travel: 500 mm control: Sinumerik 840D Siemens distance spindle /table: 100 - 500 mm Main spindle:: turning speeds: 8.000 min/-1 power capacity - main spindel: 10,5 kW tool taper: HSK 63 spindle diameter in front bearing: 70 mm work table:: table surface area: 1.000 x 560 mm max. table load: ca. 1.000 kg Tool-Presetter:: number of toolpositions: 30 pos. tool taper: HSK 63 max. tool diameter: 80 mm max. tool-dia with free toolbox: 125 mm max. tool length: 300 mm max. tool weight: 8 kg feeds:: rapid traverse ( X / Y / Z ): 35 m/min total power requirement: 31 kVA weight of the machine ca.: 7,0 t dimensions of the machine ca.: 3,5 x 3,0 x 3,0 m Documents: Chip conveyor: Coolantsystem: Automatic Tool Changer: elektr. hand wheel: CNC Machining Center Vertical HERMLE - C 800 V - Top-Condition ! - WITHOUT vices / WITHOUT tooling The data for this a ...

Traversal X/Y/Z: 670/820/600mm, swivel range: +/- 120°, tool storage: 120 places. Table load: 1,200kg, spindle speed: 18.00 n/m, rotary table: Ø 800mm, endless 360 degree rotation. Tool holder: HSK 63, Max. Weight tools: 8kg, Pneumatic: 6bar, Control: Heidenhain TNC 640. Machine hours: 12,400h, Spindle running time: 2,340h, Options available: IKZ variable, variety of HSK fixtures as good as new. Dimensions length/width/height: 4150mm/5000mm/3500mm, weight: 20 tons

Vertical Machining Center REALMECA RV-5SP Year of construction: 2002 Travel X: 500 mm Travel Y: 350 mm Travel Z: 400 mm Controller: HEIDENHAIN TNC 426 Spindle: IBAG HF 140 - 30 000 RPM Cone: HSK E 40 Table size: 600 x 350 mm Tools store: 18 Tools - HSK 40 Various: 4th axis + Tailstock centre height: 125 mm Spindle control panel dimensions: L 1200 x W 700 x H 1470 mm Machine dimensions (L x W x H): 2100 x 2400 x 2400 mm Weight: 4,3 T

GF Mikron 500U VMC, 2020- 5-Axis, HSK, Low Hours, Excellent Condition,Probe Year: 2020 X-axis- 19.68 in (500 mm) Y-axis – 17.71 in (450 mm) Z-axis – 15.74 in (400 mm) B-axis – 65°/+120° C-Axis- 360° endless Spindle drive type- Cartridge Spindle max.- 20,000 RPM Spindle Power at S1-30.8 HP (23kW) Spindle Power at S6-48.2 HP (36 kW) Spindle Torque at S6-88.5 ft. lbs. (120 Nm) Spindle tool interface- HSK-A63 Distance from table top to spindle 5.90 – 21.65 in (150 – 550 mm) Rapid traverse X,Y & Z 1,181 min (30 m/min) Acceleration X,Y & Z .3g (3 m/sq. sec.) Rapid speed B/C 32/112 RPM Tool changer capacity- 60 tools Work table size- 19.68 in (500 mm) Maximum payload on table 440 lbs (200 kg) Typical table height 38.58 in (980 mm) Number of T-slots 7 T-slot spacing- 2.48″ in (63 mm) T-slot dimension- 0.55 in (14 mm) Coolant tank capacity- 158 gal (600 L)  ...

Machine Details Stock number 1105-03802 Machine type machining center - vertical Brand MIKRON Type VCP 600 Year of construction 2010 Control type CNC Control heidenhain 430 Storage location FRANCE Country of origin SWITZERLAND Delivery time ready for shipment Freight Base EX WORK Technical details x-travel 600 mm y-travel 450 mm z-travel 450 mm Control heidenhain 430 Table clamping surface 850 x 530 mm Table load 0.40 t Number of T-slots 6 T-slots - distance 63 mm T-slots - width 14H12 mm Spindle speeds - infinitely variable 100 - 20,000 rpm Spindle motor 12,00 kW Tool holder HSK-A63 Tool changing device 30 Tool diameter 90 mm Tool diameter with 2 free spaces 110 mm Tool length - max. 250 mm Tool weight max. 6.00 kg Chip-to-chip time approx. 7.00 sec Feed infinitely variable 0 - 22,000 mm/min Rapid traverse 22.00 m/min Feed force X/Y/Z axis 5000 N Tota ...

CNC vertical machining center HERMLE C 42 V With path control Heidenhain iTNC 530 Year of construction: 2016 Travel : X 800 Y 800 Z 550 Speed range: 20 – 42,000 rpm continuously variable (HSK 40) With the following accessories: Rigid angle table 1050 mm x 805 mm clamping surface Vertical tool changer with 42 magazine slots ( HSK 40) Linear axis dynamics , remote maintenance Blow-off device Coolant equipment , Chip tray Manual cabin door , Manual cabin roof Polycarbonate safety glazing Electronic heat compensation iTNC 530 Electr. Manual operating module HR 410 BLUM Laser A1 rigid table , mod. BLUM A1 with optics BL 104 3 D touch probe Heidenhain Control cabinet cooling unit ( RITTAL) Status light 7-fold media connection rigid table 4 pieces of height-adjustable machine shoes Operating instructions THE MACHINE ONLY MILLED BRASS PARTS Absolutely MINT C ...
