119,266 used machines on RESALE, but how to find them? Machine Search
used
HELLER MC16 4-axis horizontal milling center YOM 2000 4-Axis SIEMENS CNC Path Control, Model SINUMERIC 840 D Longitudinal X-axis 630 mm Vertical Y-axis 630 mm Cross Z-axis 630 mm NC rotary table Tilting B axis 360.000 x 0,001 ° Pallet size 400 x 500 mm Max. workpiece size Ø x height 720 x 800 mm Max. workpiece weight 500 kg Pallet exchange time 9 sec. Turning Speed B axis 40 rpm/min Tool holder cone HSK 63 Tool size Ø x lg. x weight 150 x 227 x 12 mm/kg Spindle speeds, infinitely variable 45 – 24,000 rpm Feeds / quick feeds XYZ: 1 – 60,000 mm/min Feed force 10.000 nm Spindel torque 48/72 nm Spindle drive 30 kW Total electrical load, approx. 60 kW - 400 V - 50 Hz Total weight 12.5 tons Accessories / Special Features : -Separate standing 80 position Rack-Type tool Magazine with tool placement door and double Swivel gripper, own SIEMENS PC-Control with screen To ...
used
Victor Vturn-X200 CNC Multitasking Turning/Milling Center CNC control Fanuc Series 31i - A Turning diameter 540 mm Turning length 1000 mm Spindle bore diameter 52 mm Spindle nose A 2-6 Speed 4200 rpm Milling head speed 12,000 rpm Travel X-Y-Z axis 600 x ±80 x 1100 mm B-axis travel +110 / +115 mm 360° indexing of the C-axis Tool cone HSK 63 Tools in Magazine 40 If you have any questions about the machine, please do not hesitate to contact us by phone or e-mail. Feel free to check out our other listings for a full overview of our stock.
used
Key data: 650 mm, 650 mm, 680 mm
Heckert CWK 400, Year of construction 2008, Control Siemens 840 D, Travel X/Y/Z 650/650/680 mm, Spindle speed up to 10,000 rpm, HSK A 63, 2-fold pallet, Opm3nm87d9 Tool changer 60 times, Rotary table 400 x 500 mm, Conveyor Suction Belt filter system, Cooling - lubricant preparation Knoll,
used
Control unit Elumatec X-Axis travel 6700 mm Y-Axis travel 350 mm Z-Axis travel 280 mm Table length 6700 mm Spindle speed 24000 rpm Tool holder HSK-F63 Routing spindle with integrated rotation unit (0°, -90°, -180° and -270°) for angle head Dimensions L 8450 x W 3400 x H 2560 mm Weight 3400 kg
used
SECOND-HAND WORKING CENTER 4 AXIS BIESSE MOD. 37 XL - working dimension X 6000 - work dimension Y 1850 - work dimension Z 180 - 1 router - power router Kw 12 - C axis interpolating - tool clamping system HSK F63 - tool changing positions 21 - vertical drilling spindles 20 - horizontal drilling spindles X 6 - horizontal drilling spindles Y 2 - pod and rail table - n. 10 consoles - vacuump pump 250 m3/h - ATS - CE RULES (YEAR 2004)
used
Machine in good technical condition, after agreement possibility of testing. Clamping surface of the table 700x500 mm X axis travel 600 mm Y-axis travel 450 mm Z axis travel 300 mm Spindle speed 0 - 42000 /min. Number of controlled axes 3 Centre cooling no Spindle clamping cone HSK E 40 . Machine weight 6000 kg Max. workpiece weight 800 kg Dimensions d x w x h 3200x2250x2650 mm
used
Obráběcí centrum SPEED 1110 je v dobrém technickém stavu, po dohodě možné vidět pod proudem. Obrobková probe Heidenhain TS740. Automatická výměna nástrojů - 10 pozic, chlezení středem (pouze vzduch). Hmotnost stroje: 15000 kg Podélný pohyb stolu - osa x: 1100 mm Příčný pohyb stolu - osa z: 700 mm Svislý pohyb stolu - bear and: 1000 mm Kužel vřetena: HSK A80 Otáčky vřetena: 30 - 14000 ot / min Rozměry stroje d x š x v: 4400x5500x3810 mm
used
X-Axis travel 3300 mm Y-Axis travel 1280 mm Z-Axis travel 125 mm Motor power 12 kW Drilling head DH24 6H 2S Spindle speed 24000 rpm Tool magazine 12 positions Tool clamping HSK F63 Vacuum pump 1 x 90 m3/h Dimensions L 6230 x W 4235 x H 2250 mm Weight 3600 kg
used
x-travel: 650 mm y-travel: 650 mm z-travel: 680 mm Control: Siemens 840 D sl size of pallet: 500 x 400 mm table load: 500 (600) kg tool taper: HSK-A63 spindle turning speed range: 50 - 10000 U/min rapid travel x/y/z: 65/65/65 m/min no. of tools in the magazine: 80 Stück Tool diameter: 160 mm tool length - max.: 350 (400) mm spindle motor: (S6) 32,4 kW weight of the machine ca.: 12,8 t dimensions of the machine ca.: 6,2 x 3,9 x 3,95 m CNC-control SIEMENS Sinumerik 840 D sl 80-pos. ATC 2-pos. pallet changer NC-rotary table Increased spindle torque up to 259 Nm Coolant equipment with paper band filter Coolant through spindle 80 bar Swarf conveyor Max. workpiece diameter: 750 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
x-travel: 300 mm y-travel: 250 mm z-travel: 250 mm table surface area: 2 x 550 x 300 mm spindle taper: HSK-A 32 spindle taper: DIN 69893 spindle turning speed - stepless: 20 - 15.000 U/min spindle motor: 7,4 kW max. torque on the spindle: max. 23 Nm spindle throat: 200 - 450 mm distance table - lower edge spindle: 170 - 420 mm power feed x/y/z: 2000 / 2000 / 3000 N rapid traverse longitudinal and cross: 40 m/min rapid traverse vertical: 60 m/min coolant tank: 100 l control: SIEMENS, 840 D total power requirement: kW weight of the machine ca.: 2,2 t dimensions of machine L x W x H: 2,75 x 1,45 x 2,25 m Accessories: various tool fixtures, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
x-travel: 3000 mm y-travel: 800 mm z-travel: 1100 mm Control: total power requirement: 60 kW weight of the machine ca.: 15 t dimensions of the machine ca.: 7,0 X 6,0 X 4,0 m For sale is a Matec 30 HV machine number 569 built in 2003. The machine is expected to be released in August 2024 and can be used under Electricity can be visited. The machine has been serviced every year and is technical in a good condition. Manufacturer: Matec Maschinenbau Type: 30HV Machine number: 569 Year of construction: 11/2003 Control: Bosch Type 3 Osa control x-travel 3,000 mm y-travel 800 mm z-travel 1100 mm Main spindle: Type DMS 112 speed range - main spindle max. 12,000 min/-1 Drive power - main spindle 30 kW Max. Torque 190 Nm Tool holder HSK 63 A Drilling capacity steel approx. 60mm Milling capacity approx. 500 cm³ Thread cutting M30 Feeds: Rapid traverse (X / Y / Z) 30 m/min Feed speed 30,000 mm/m ...
used
Description: Contents consisting of tool presetters from PWB and TSCHORN, 3 cordless screwdrivers from BOSCH and an attached machine vice (jaw width: 125 mm) Attention: the HSK A63 holders on the workbench are not included in the scope of delivery weight approx.: 150 kg, Approx. Onsite Dimension. (l x w x h): 1,500 x 1,000 x 1,200 mm
used
Description: Contents consisting of indexable inserts, clamping jaws from SCHUNK and SMW, glass lifters, HSK holders, tool holders for lathes Approx. Onsite Dimension. (l x w x h): 1,000 x 500 x 1,000 mm, weight approx.: 150 kg
used
Stroke main spindle: X 4363 mm, Y 1394 mm, Z 248 mm. Movement speed X 100 m/min, Y 100 m/min, Z 25 m/min 8 workpiece supports Equipment: 24 Spindle drilling head, 10 vertical spindles in X, 8 vertical spindles in Y, 2 double horizontal spindles in X, 1 double horizontal spindle in Y Grooving unit X/Y adjustable Router 6 kW, 1000 - 18000 r/min, HSK-F 63, liquid cooled Toolchanger with 6 places Vacuumpump with 140 m3 capacity PC controlls Campus software (Campus NC Hops, Campus MT Manager)
used
Description: Serial number: 11430000953 Spindle hours: 17445 Feed rate X-, Y-, Z-axis: 20 - 15000 mm/min Rapid traverse X-, Y-, Z-axis: 15 m/min Path measuring system: Resolution X-, Y-, Z-axis: 0.001 mm Position tolerance X-, Y-, Z-axis: 0.01 mm Travel: X-axis: 780 mm Y-axis: 560 mm Z-axis: 560 mm Work spindle: HSK-A63 Number of magazine slots: 60 Max. Tool diameter when all positions are occupied: 80 mm With free adjacent positions: 160 mm Max. Max. tool length from spindle nose: 315 mm Max. tool weight: 8 kg Tool weight: 8 kg Pallet changer: Number of pallets: 2 Permissible load of the pallet changer: One side: 400 kg Both sides: 800 kg With NC rotary table Clamping surface, pallet: 500 x 630 mm With T-slots Permissible load of the table: 400 kg Rotary feed: 7200°/min Max. table plate revolutions: 30 mm Rotations of the table top: 30 rpm Spindle speed: 12000 rpm The accessories or cl ...
used
Description: Serial number: 2786 Control: SIEMENS SINUMERIK 840D/additional program 'Sequence list' Technical data (without guarantee): Travel distances: X-axis: 400 mm Y-axis: 270 mm Z-axis: 250 mm A-axis (dividing head): 360° C-axis (spindle axis) Tool changer: Number of tools: 4 Grinding spindle: HSK 50/12 kW max./8000 rpm Incl. ram handling Incl. the tool clamping device (SK 50 holder) which can be seen in the last pictures Important note: without centrifuge and oil tank Coolant system not included in the scope of sale and delivery Also without the clamping device for workpieces shown in the photos and videos weight approx.: 7,500 kg, Approx. Onsite Dimension. (l x w x h): 2,350 x 1,750 x 2,800 mm
used
The machine is in good technical condition, after prior arrangement it is possible to test it. Longitudinal travel in the X axis 7280 mm Cross travel Y - axis Width 525 mm Z axis travel (height) Diameter 380 mm Turning on the 7 kW spindle Acceptance into milling spindle (ISO) HSK-40E Maximum speed range 24,000 rpm Required power 23 kW Weight 4.8 tons
used
DMG MORI SEIKI NHX4000 CNC machining center made in 2014 in Germany is an ideal combination of functionality, productivity and precision that can handle even the most complex challenges in a wide range of industries. This technologically advanced machine consists of a single-piece bed with sliding column, reliable components and extensive optional equipment. The machining process takes place inside a large work area, which includes an extremely powerful high-speed spindle, a 4-axis rotary table and a two-pallet system. This system allows uninterrupted machining of multiple workpieces, thus significantly increasing production efficiency and reducing machine downtime to a minimum. In addition, all basic machine components are cooled to increase their service life. The DMG MORI SEIKI horizontal machining center is equipped with optional equipment, including measuring probes, tooling and ...
used
Key data: 1050 mm, 800 mm, 560 mm
Machine Type: CNC Vertical Double Column Machining Center Manufacturer: DECKEL-MAHO (DMG) Model: DMC 105 V linear Year of construction: 2008 Condition: very good Offer Type: Used Machine Specifications: Control: Heidenhain iTNC 530 Speed range: 18000 rpm. Spindle holder: HSK-A63 Table: 1200 x 850 mm Travel range: x = 1050 mm y = 800 mm z = 560 mm Rapid traverse speed: in x/y/z = "90m/min." Tool changer: with 60-fold tool magazine Propulsion: 25/35 kW Remark: Heidenhain touch probe for: automatic workpiece measurement, Automatic tool measurement IKZ with high-pressure pump, Spindle cooling, Conveyor electric handwheel Weight: 12000 kg The machine is in a very good condition and ready for immediate use and can be viewed and demonstrated by us. We would be pleased if you are interested in our offer. Errors, modifications and prior sale excepted.
used
Modular cleaning device for cleaning various tool pick-up cones - Stable housing with integrated timer switch to avoid continuous running of the device - Ergonomically designed for safe and easy working - Resistance to rust and cooling lubricants - Fast, gentle and reliable cleaning of heavily soiled or Resinous tool holders What's Included -Drive - Attachment for HSK-63 tool holders Subject to prior sale and technical errors
used
max. wheel diameter: 1600 mm gear width: 700 mm max. module: 25 min. module: 2 x-axis: 875 mm z-axis: 1000 mm control: Siemens 840 C weight: 38 t milling arbors: HSK-B160 table load: 15 to t arbor support: 900 verfahrbar total power requirement: 100 kW weight of the machine ca.: 27 t dimensions of the machine ca.: 7,9 x 7,4 x 4,0 m Sonderfräskopf M2 - Max Fräserdurchmesser 350 mm - Max Fräserlänge 375 mm - Max Fräserverschiebung 300 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Key data: 800 mm, 800 mm, 550 mm
Inv. Num. : 7420 Type: C42U dynamic Producer: Hermle Created: 2020 Parameters: Control system: HEIDENHAIN TNC 640 Duty cycle: 8341 h Hours: 1947 h Work table length: 800 mm Work table width: 630 mm Maximum table load (uniform): 1400 kg Number of synchronized axes: 5 pieces Tool magazine: 42 pieces Maximum vertical spindle speed: 18000 1/min X-axis travel: 800 mm Y-axis travel: 800 mm Z-axis travel: 550 mm Cone: HSK-A63 Max. tool weight: 8 kg Spindle cooling: 80 kG/m² Machine weight: 13000 kg Equipment: Conveyor Workpiece probe Renishaw Spindle cooling Tool Holder Tool probe BLUM Oil mist extraction Zero Clamping Plate SCHUNK
used
Key data: 630 mm, 630 mm, 630 mm
Heller MCI 16 Horizontal Machining Center, Built in 2006, Control Siemens 840 D, Travel X/Y/Z 630/630/630 mm, Tool changer 80 times, Tool holder HSK 63, Spindle speed up to 10,000 rpm, 2-fold pallet 400 x 500 mm, Rotary table 0.001°, IKZ 63 bar, Conveyor Machine weight 11,000 kg,
used
x-travel: 885 mm y-travel: 600 mm z-travel: 600 mm control: iTNC 530 Heidenhain Main spindle:: Max. rpm: 1 - 28.000 min/-1 power capacity - main spindel: 35 / 25 kW max. Torque: 119 / 85 Nm tool taper: HSK A63 Swivel range milling spindle: B: -10° / +110° ° spindle bearing diameter: 80 mm rotary table:: table diameter: 750 mm rotation range: C: 360 ° rotary speed: max. 100 min/-1 max. table load: 600 kg feeds:: feed speeds: 1 - 90.000 mm/min rapid traverse: 90 m/min Feed force: X/Y: 13,8 kN Feed force: Z: 10,35 kN tool magazin:: number of toolpositions: 30 pos. max. tool diameter: 80 mm max. tool-dia with free toolbox: 140 mm max. tool length: 300 mm max. tool weight: 10 kg Workpiece dimension: max. workpiece height: 460 mm Max. Workpiece Area: ca. 750 x 600 mm passage: max. 600 mm total power requirement: 60 kVA weight of the machine ca.: 12 t dimensions of the machine ca.: 4,5 ...
used
Description: SPECIFICATIONS Character: Deckel Maho Type: DMU 60T Control: Heidenhain MillPlus Year of construction: 2001 Table dimensions: 1,000 x 600 mm Displacement: X= 630 mm, Y= 560 mm, Z= 560 mm Top name spindle: HSK 63 Maximum speed: 12,000 rpm Maximum table load: 400 kg Clamping conveyor Machine dimensions: 3,000 x 2,000 x 2,150 mm Machine weight: 7,000 kg Positions in tool magazine: 24 weight approx.: 7,000 kg, Approx. Onsite Dimension. (l x w x h): 3,000 x 2,000 x 2,150 mm
used
Key data: 650 mm, 600 mm, 500 mm
Manufacturer : Hermle Model: C 30 U Number of machines : 1 Control : Heidenhain i TNC 530 Year of construction : 2008 / 2009 Switch-on hours : approx. 95000 h Spindle running time : 28000 h Location : Germany from stock Hultfred - Sweden Specifications Max. spindle speed: 28000 rpm Spindle mount : HSK A 63 Number of synchronously controlled axes : 5 Travel X-axis : 650 mm Y-axis : 600 mm Z-axis: 500 mm A-axis : +/- 115 º MM B-axis : 360° NC serving table diam. 280 mm Tool Locations Pick Up: 32 Positions Additional magazine: 157 lots Total tool slots : 189 lots Loading and unloading area: 8 lots Tool length max.: 300 mm Tool diameter max. 125 mm Tool weight max.: 8 kg Dimensions Length : 3154 MM Width : 2354 MM Height 2892 MM Machine weight : 10500 KG Other equipment features - max. coolant pressure 80 bar possible ( IKZ ) - Touch probe ...
used
Key data: 650 mm, 600 mm, 500 mm
Manufacturer : Hermle Model: C 30 U Number of machines : 2 Control : Heidenhain i TNC 530 Year of construction : 2008 / 2009 Switch-on hours : approx. 115000 h Spindle running time : 24400 h Location : Germany Dismantling in week 5 / 2024 then from warehouse Sweden Specifications Max. spindle speed: 28000 rpm Spindle mount : HSK A 63 Number of synchronously controlled axes : 5 Travel X-axis : 650 mm Y-axis : 600 mm Z-axis: 500 mm A-axis : +/- 115 º MM B-axis : 360° NC serving table diam. 280 mm Tool Locations Pick Up: 32 Positions Additional magazine: 157 lots Total tool slots : 189 lots Loading and unloading area: 8 lots Tool length max.: 300 mm Tool diameter max. 125 mm Tool weight max.: 8 kg Dimensions Length : 3154 MM Width : 2354 MM Height 2892 MM Machine weight : 10500 KG Other equipment features - max. coolant pressure 80 bar poss ...
used
Motor power: 26,0-kW Year of construction:2020 Motor voltage:3x 400 V motor frequency:50 Hz Working field: X= 3090 mm, Y= 2100 mm, Z= 85 mm 3 different vacuum table zone DH8 cutting head 2 vacuum pump with a total suction of: 500 m³/h / 50Hz; Electro-pneumatic shaft 10 kW HSK F63
used
x-travel: 3000 mm y-travel: 2500 mm z-travel: 1000 mm Control: Siemens type: 840 D Feed: 5-30.000 mm/min Table area: 2000x2170 mm table load: 1500 Kg/m² T-slots: 22 H9 distance between uprigths: 2500 mm spindle turning speed range: 6000 U/min spindle drive: 36 kW spindle taper: HSK 100 Tool changer: 30 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: 8x6,4x4,4 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Key data: 670 mm, 830 mm, 600 mm
Control: HEIDENHAIN ITNC 530 Travel: X-axis: 670 mm Y-axis: 830 mm Z-axis: 600 mm A +120° to -120°, C 360° Workspace Turntable diameter 800 mm, 9 T-slots, Table load 1200 kg, Tool changer Tool holder: HSK-A 63 96-fold tool changer Tool length max.: 300 mm Tool diameter max.: 75 mm Tool diameter with adjacent empty station max.: 125 mm Tool weight max.: 7 kg Tool change time: 3 s Rapid traverse and feed Express feed X Y Z 60 m/min, + max. speed A-axis 50 rpm C-axis 100 rpm Acceleration X Y Z max. 7 ms², General data Repeatability/positioning accuracy for new delivery 0.004 mm/0.008 mm (VDI/DGQ 3441) incl. tool holders with tools on the tool changer, Oil mist extraction IKZ Conveyor Nominal power 90 kVA Full load current 125 A max. current load 200 A 400 V 50 Hz
used
Maho DMF 200 - 8 / 5 axles, Year of construction 2021, Control Siemens 840 D sl Operate, Travel X/Y/Z 2000/800/850 mm, NC swivel milling head / B axis, Spindle speed up to 15,000 rpm, HSK A 63, Tool changer 40 fold, double gripper, Table size 2300 x 850 mm, Rotary table integrated into rigid table Ø 800 mm Direct displacement measuring systems, Conveyor Additional control panel, tool input station, High-pressure cooling IKZ 40 bar, paper tape filters, 2 rotating viewing panels, 3D quick set for kinematics checking, Infrared probe PP 60 optical, Blum Laser Tool Measurement, Machine Protection Control - Quick Shutdown, Door drive of the workroom doors, Bl7ab78en09 electr. Handwheel Mode 4, Messenger V 4, Service Camera, Digital Manufacturing Package,
used
Description: Mach. No. 210425108 Operating hours 81886 High-speed spindle HSK E40 6.5 kW, with 90 degree milling head and high-speed tool change milling spindle, 2,000 to 36,000 rot/min Table dimensions 1700 x 6170 mm (2 x) Travel path X 4250 mm Travel distance Y 4350 mm Travel distance Z 1050 mm Pressure consumption approx. 800 liters per hour Pneumatic pressure 6 bar Nominal voltage 400 V, 50 Hz Control voltage 24 V Nominal power 23.5 kW Fuse 63 A Circuit diagram no. 210424 Control system SINUMERIK 840 Installation dimensions approx. (LxWxH) 5300x2600x2300 Installation dimensions approx. (LxWxH) 5300x2350x2300 Weight approx. 9000 Installation dimensions approx. (LxWxH) 1200x800x1000 Weight approx. vacuum pump/cooling unit 300 Installation dimensions approx. (LxWxH) 1600x2300x2200 Control cabinet 1200 kg Weight approx. 10,500 ATTENTION - Tools, drills etc. are N ...
used
Description: Mach. No. 210425408 Operating hours 78805 High-speed spindle HSK E40 6.5 kW, with 90 degree milling head and high-speed tool change milling spindle, 2,000 to 36,000 rot/min Table dimensions 1700 x 6170 mm (2 x) Travel path X 4250 mm Travel distance Y 4350 mm Travel distance Z 1050 mm Pressure consumption approx. 800 liters per hour Pneumatic pressure 6 bar Nominal voltage 400 V, 50 Hz Control voltage 24 V Nominal power 23.5 kW Fuse 63 A Circuit diagram no. 210424 Control system SINUMERIK 840 Installation dimensions approx. (LxWxH) 5300x2600x2300 Installation dimensions approx. (LxWxH) 5300x2350x2300 Weight approx. 9000 Installation dimensions approx. (LxWxH) 1200x800x1000 Weight approx. vacuum pump/cooling unit 300 Installation dimensions approx. (LxWxH) 1600x2300x2200 Control cabinet 1200 kg Weight approx. 10,500 Dimensions approx. 1600 x 2300 x 2200 ...
used
Description: Mach. No. 210425108 Operating hours 80368 High-speed spindle HSK E40 6.5 kW, with 90 degree milling head and high-speed tool change milling spindle, 2,000 to 36,000 rot/min Table dimensions 1700 x 6170 mm (2 x) Travel path X 4250 mm Travel distance Y 4350 mm Travel distance Z 1050 mm Pressure consumption approx. 800 liters per hour Pneumatic pressure 6 bar Nominal voltage 400 V, 50 Hz Control voltage 24 V Nominal power 23.5 kW Fuse 63 A Circuit diagram no. 210424 Control system SINUMERIK 840 Installation dimensions approx. (LxWxH) 5300x2600x2300 Installation dimensions approx. (LxWxH) 5300x2350x2300 Weight approx. 9000 Installation dimensions approx. (LxWxH) 1200x800x1000 Weight approx. vacuum pump/cooling unit 300 Installation dimensions approx. (LxWxH) 1600x2300x2200 Control cabinet 1200 kg Weight approx. 10,500 ATTENTION - Tools, drills etc. are N ...
used
This IBARMIA ZV 58/L7000 EXTREME Vertical Machining center was manufactured in the year 2017 and has under 4500 production hours. It is equipped with a HEIDENHAIN TNC 640 HSCI control unit and has 3 axis. The machine has a spindle speed of 16000 rpm and a HSK 63 spindle tool taper. It comes with 60 tool slots as well as a PDF (FR) with technical benefits.
used
This Rambaudi RC 270 Vertical Machining center was manufactured in the year 2014. It is equipped with a HEIDENHAIN iTNC 530 HSCI control unit and has 5 axis. The spindle speed is at 24000 rpm and runs with a HSK-A63 tool taper. The machine has operated 38428 power on hours and 23655 cutting hours. It stands out for its movable crossbeam which makes the machining centre suitable for high-speed machining with 5 axes. See photo and video gallery for more impressions. Extract of original tech specs (EN) attached as PDF below.
used
This MATEC 30 HV (2003) Universal Machining Centre was manufactured in 2003 in Germany. It is controlled by a BOSCH TYPE 3 OSA Control unit. This CNC traveling column milling machine (3+2 axes) is equipped with a main spindle type DMS 112 with speed range up to max. 12,000 min/-1 and drive power 30 kW. It has a NC swivel head (Sauter) with swiveling +/- 90 ° and graduation +/- 3 arc seconds. In addition it runs with a tool changer with 48 positions and a HSK A63 tool holder. The table is a NC rotary table with a clamping surface of 3,500 x 835 mm and 7 T-slots. IKZ 70 bar, paper belt filter and chip conveyor (ejection height 1200mm) and 3D radio measuring probe come with the machine. The machine is prepared with a 4th axis interface. The condition of the machine is very good - it is still in production and maintenance service has been applied regularly according to manufacturers stand ...
used
CNC Machining Center Scheer Type: BC 2001 Year of construction: 2000 Axle travel: X 3500 mm, Y 1500 mm, Z 220 mm Axis speeds: X 80 m/min., Y 60 m/min., Z 30 m/min. Work table size: 3200 x 1200 mm Minimum part size: 250 mm x 70 mm x 10 mm Max. part size: 3200 mm x 1250 mm x 70 mm In pendulum mode: 800 mm x 1250 mm complete machining 1000 mm x 1250 mm surface processing Vacuum pump 2 x 40 m³/h Vacuum cups 12 pieces 120 x 120, 2 pieces 120 x 65 mm Drilling unit: L-shape, 13 individually controllable spindles, 7 in X-direction, 6 in Y-direction, 32 mm wheelbase, Extension stroke 70 mm, pneumatic Scheer male thread M 10 re+li, 1.5 kW / 6000 rpm Milling unit power 7.5 kW at 12000 to 18000 rpm, Speed 1000 rpm to 20000 rpm electr.adjustable Right-left rotation Hollow shank taper DIN 69893-HSK F63 Tool magazine on the move with 18 places Distance in magazine 88 mm Max. ...
used
This DATRON M8 Cube Milling machine was manufactured in 2014 in Germany. The machine has a Datron CNC intuitive programming system Windows driven with a flat panel monitor. It is equipped with a max. spindle speed of 60,000 rpm and a drive system of digital servo ball screw which is on all axes with feed rates up to 22 m/min. Includes a tool Changer that has 5 fold HSK-E 25 (opt 10). See product brochure (EN) as PDF attached for more details.
used
This POS H800U Universal Machining Centre was manufactured in 2018 in Germany. It has 5 axis (X = 670, Y = 600 mm, Z = 820 mm / Swivel range -100 to +120 degrees, Rotary table 360 degrees endless) and comes with a HSK-A63 spindle with 18,000 rpm. The machine is operated by a iTNC530 HEIDENHAIN control and is equipped with a Heidenhain rotary and linear measuring system X,Y,Z. As extras it features air through spindle, internal coolant supply 20 bar with belt filter unit, a KESSLER table with diameter 800 mm, tool measurement with BLUM laser and operation mode 4. See tech specs overview as PDF (DE) attached.
used
turning diameter: 800 mm turning length: 4500 mm control: Siemens workpiece weight: 4000 kg Revolutions milling spindle: 1-5500 U/min milling spindle: HSk 100 type: 840 D positioning accuracy: 0,01 ° Torque: 3000 Nm transmission ratio: 2 turning speeds: 2430 U/min main drive: 77 kW steady: SMW Diameter: 140-510 mm coolant capacity: 980 l coolant pump: 80 Bar paper filter: 3-jaw-chuck diameter: 610 mm tail stock: Tool changer: swing diameter: 1100 mm total power requirement: kW weight of the machine ca.: 52 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Key data: 800 mm, 800 mm, 800 mm
1Universal machining center DMG-Mori DMC 80 U Duoblock built in 2007 Control Heidenhain Mill-Plus IT Travel X/Y/Z 800 mm x 800 mm x 800 mm Universal milling head with B-axis HSK 63A with 18,000 rpm NC rotary table C-axis with pallet carrier Tool changer with 180 places Rotary pallet changer d 800 mm x 630 mm IKZ with 2 pressure levels 40/80 bar , 980 l Conveyor Infrared Probe Heidenhain TS 640 Rinsing gun, electr. Handwheel , mode 4
used
Key data: 2600 mm, 750 mm, 695 mm
with CNC control, Fabr. HEIDENHAIN, type: ITNC 530, travels: X-axis: 2600 mm, Y-axis: 750 mm, Z-axis: 695 mm, NC rotary table 750 mm with hydraulic clamping, NC-controlled stepless swivel spindle with swivel range -98 degrees to +98 degrees, with autom. Tool changer: 50 tool slots + standby magazine with integrated CNC-controlled mast with 180 tool positions, cone cleaning station, max. 1800 RPM, number of axes: 5, tool holder: HSK A63, 3-D infrared touch probe, with IKZ coolant supply, cooling/filter system, Fabr. HEDELIUS, Type: SKM900, Oil Mist Extraction & Chip Conveyor
used
z-motion: 560 mm, x-motion: 650 mm, y-motion: 650 mm, control: HEIDENHAIN ITNC 530, table surface area l x w : 800x650 mm, taper: HSK 63, toolchanger positions: 60, turning speed range: 18,000 rpm, weight approx.: 10,000 kg, Approx. Onsite Dimension. (l x w x h): 5,000 x 2,800 x 2,900 mm
used
Description: including scraper belt conveyor SIEMENS SINUMERIK 840 D control system Spindle speeds 10500 1/min x-path 550 mm y-path 300 mm z-path 425 mm Rapid traverse: 30m/min Axes 4 Speed range 10500 1/min Spindle holder HSK 63 Tool changer 20 Pl Number of tools in the magazine 20 Pl Approx. Onsite Dimension. (l x w x h): 3,200 x 2,500 x 2,500 mm, weight approx.: 7,000 kg
used
Description: With hinged doors and 6 drawers Contains assembly material , With attached tool holder shelf HSK 63, 6 places with 2 tools Approx. Onsite Dimension. (l x w x h): 720 x 720 x 1,400 mm, weight approx.: 150 kg
used
CNC machining center Biesse Rover A1542 Year of production 2021 Working fields : X = 4140 mm Y = 1560 mm Z = 275 mm C = 360 degrees 8 pcs. of ATS beams - 24 carriages 8 pcs. Rear line bumper, stroke 115 mm, extension 25 mm 8 pcs. Middle line bumper, mounted at 685 mm, stroke 140 mm 8 pcs. Front line bumper, stroke 1348 mm, extension 140 mm. 4 side bumpers with 140 mm stroke (2 left + 2 right) including pneumatic installation. 4 removable center bumpers with 140 mm stroke (2 Left + 2 Right) including pneumatic installation. BUSCH pump with a capacity of 290 m3/h Electro-spindle 13.2 kW (17.7 hp) HSK F63 and air cooling BH 29 2L drilling head with automatic lubrication. 16-position turreted tool magazine mounted on X-axis carriage 8-position magazine for quick tool change In addition, HSD angle aggregates The machine has only 2000 hours of operation
used
Disc eroding machine for complete machining of rotationally symmetrical workpieces with ultra-hard cutting edges cutting materials. The workpieces are picked up flying (hanging vertically). Accesories Mechanical vapor separator N280, Disc changer for up to 6 eroding/grinding discs Adaptation to the A-axis on HSK 63-A-E Test mandrel HSK63A Glass scales on the linear axes X, Y & Z, Software package additional functions for metal working tools, Ex Level Pro Software, 3 grinding wheel changing elements Automatic shutter, Automatic central lubrication, Automatic fire extinguishing device, Coolant system with pump & coolant unit., Workpiece outside diameter: max 320 mm, Workpiece length: Max. 250 mm, workpiece length: max. 250 mm, Tool outside diameter: Max. 200 mm, Bore diameter: Max. 60 mm, bore diameter: Max. 60 mm, Travel X1: 520 mm, Travel path X1: 520 mm, Travel Y1: 970 mm, Travel path Y ...
used
Disc eroding machine for complete machining of rotationally symmetrical workpieces with ultra-hard cutting edges cutting materials. The workpieces are picked up flying (hanging vertically). Accesories: Mechanical vapor separator N280, Disc changer for up to 6 eroding/grinding discs, Adaptation to the A-axis on HSK 63-A-E Test mandrel HSK63A, Glass scales on the linear axes X, Y & Z, Software package additional functions for metal working tools, Ex Level Pro Software, 3 grinding wheel changing elements Automatic closure flap Automatic central lubrication Automatic fire extinguishing device Coolant system with pump & cooling unit, Workpiece outside diameter: max 320 mm, Workpiece length: Max. 250 mm, workpiece length: max. 250 mm, Tool outside diameter: Max. 200 mm, Bore diameter: Max. 60 mm, bore diameter: Max. 60 mm, Travel X1: 520 mm, Travel path X1: 520 mm, Travel Y1: 970 mm, Travel pa ...
used
x-travel: 1.600 mm y-travel: 1.250 mm z-travel: 1.000 mm Control: SIEMENS 8400 Powerline 3D numbers of pallets: 6 size of pallet: 1.250 ×1.000 mm T-slots: DIN 55201-A2 c-axis: 0,001 ° spindle: 85/65 kW spindle (milling):: 0,000 rapid travel x/y/z: 60.000 mm/min tool adaptor: HSK-A 63 DIN 69893 Speed: 20-30.000 U/min turning tools travel - vertical: 40/32 mm tool magazin:: 120 Internal cooling system: 50 bar Chip coveyor: Inkl. handwheel: SIEMENS 840D total power requirement: 139 kWA weight of the machine ca.: 55 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
