120,334 used machines on RESALE, but how to find them? Machine Search
maximum number of results exceeded > 1000
please refine your search
used
Well-preserved horizontal pillow-pack packaging machine. Very well suited for cylindrical or other elongated products. Was used to extract a sausage in foil. Please see the video. Fully functional, there is some evidence of second-hand. Price on request machine is immediately available.
used
Horizontal Milling Machine DIXI, Type 350 Mach. No. 350-16 Control: Dixi CNC 4400 Table dimensions: 810 x 810 mm table load: 2000 kg X/Y/Z: 1000 / 1000/1000 mm B-axis rotating table C-axis vertical round rotating table RPM: 10-3000 U / min Power: 18 kWh Table with 7 T-slots: 18 mm rapid traverse: 20-10000 mm / min taper ISO 50 Weight: 17 tons Accessories: Vertical milling head, vertical round table, angle rack, holders, etc.
used
Surface grinders - horizontal ELB-SCHLIFF perfect B-10 SPS Second-hand machine Grinding length: 1000 mm Grinding width: 400 mm Workpiece height: 450 mm Table size: 1000 x 400 mm Grinding wheel dimensions: 300 x 50 mm Grinding spindle motor: 3.5 kW Table speed: 2-30 m / min Grinding wheel speed: 1500 rpm Magnetic plate size: 1200 x 500 mm Total power: 15 kW Machine weight approx.: 4,5 t Space requirement approx.: 3.5 x 2.5 x 2.5 m General overhauled by 2015 with 12 month warranty Paper machine Magnetic clamping plate 1000 x 400 Automatic dressing device with compensation 1 flange Items put up
used
Many thanks for your interest on our second hand machines, please find follow our offer: Manufacturer : SIG Type : SB horizontal flow-pack YOM : 1988 Package size range : min. 60 x 30 x 5 mm (lxbxh) max. 410 x 180 x 75 mm (lxbxh) Trigger length : between 90 and 470 mm depending on the format range Roll width : up to 590 mm Output : up to 250 pcs./minute; infinitely adjustable Electricity : 220-380 V; 3 ph; 50 Hz supply chain length : ca. 5000 mm different: double foil roll holder automatic film splicer PLC Control date printer good Condition Nagema wafer cutter 5m long belt infeed We offer this machine in 'as is' condition, without warranty ex Warehouse Hess. Lichtenau, unpacked
used
unused counter-holder for horizontal fraesening for WMW FQ400CNC The gnholder has a counter bearing for the reception of the long fraesdorne. Special price
used
Horizontal fraesing machine with swivel vertical frescent head (3510.3), table 315 x 1000 mm, x/y/z = 710/260/420 mm, Sk 40, speed range 45-2000 rpm, feed range 16-800 mm/min, eilgaenge 4 m/min, weight approx. 1.5 t
used
Horizontal grinding machine ELB, magnet 500/350 mm, table 840/350 mm, mesh. No. 140030676
used
Many thanks for your interest on our second hand machines, please find follow our offer: Manufacturer : SIG Type : SB horizontal flow-pack YOM : 1988 Package size range : min. 60 x 30 x 5 mm (lxbxh) max. 410 x 180 x 75 mm (lxbxh) Trigger length : between 90 and 470 mm depending on the format range Roll width : up to 590 mm Output : up to 250 pcs./minute; infinitely adjustable Electricity : 220-380 V; 3 ph; 50 Hz supply chain length : ca. 5000 mm different: double foil roll holder automatic film splicer PLC Control date printer good Condition 5m long belt infeed We offer this machine in 'as is' condition, without warranty ex Warehouse Hess. Lichtenau, unpacked
used
MORI SEIKI SH-500/40 Horizontal Machining Center was built in Japan in 1999 by MORI SEIKI CO., LTD. The machine is equipped with a numerical control type MORI SEIKI MSC-502. The milling machine has a table size of 500 x 500 mm and processes workpieces weighing up to 500 kg. The travel range of its X, Y, Z axes is 630 x 600 x 650 mm, respectively. The machine spindle rotates at 12,000 revolutions per minute. The milling machine is equipped with a magazine for forty tools with a maximum tool diameter of 150 mm, length 360 mm and a weight of 12 kg. The milling center is offered at a price with different types of holders. Technical parameters of the MORI SEIKI SH-500/40 CNC milling machine - CNC control: MORI SEIKI MSC-502 Travel range: - X axis (table travel length): 630 mm - Y axis (vertical movement of the spindle head): 600 mm - Z axis (cross table movement): 650 mm - distan ...
used
HORIZONTAL MIXER
used
Capacity round maximum diameter: 0 mm Angle degrees maximum: 0 Capacity square: 0 mm Workpiece height: 0 mm Workpiece width: 0 mm Capacity rectangle: 0 mm Technical data Cut range: round up to: 400 mm Square: 400 x 400 mm Execution: Horizontal hydraulic Cut length: min.: 6 mm max: 750 mm Max. automatic forward feed length: 750 mm Cutting speed: stepless from: 20 m/min up to: 110 m/min Band length: 5090 mm Band width: 34 mm Sheet thickness: 1.1 mm Vice pressure max.: 20 - 60 bar Voltage 50 Hz 3x: 400 Volt Power: 8 kW Machine´s weight about: 2150 kg Overall dimensions machine: Length: 2420 mm Width: 2240 mm Height: 1915 mm Various accessories: Automatic forward feed Coolant system: 100 l Chip conveyor
used
MCM Clock 600 14 pallet 500x500 CNC FANUC 16iM 15000 RPM Jfmx Supervisor centro di lavoro multipallet FMS multipallet horizontal machining center in FMS under power in our warehouse Mimu machine tools (Italy)
used
HORIZONTAL MACHINING CENTER NR. 2 KITAMURA HX500I WITH FATESYSTEM SHUTTLE Features: X-AXIS STROKE: 870 MM Y-AXIS STROKE: 710 MM Z-AXIS STROKE: 660 MM 4TH AXLE (ROTARY TABLE): 0.001-360 ° TABLE: 500 X 500 MM MAX PERMISSIBLE LOAD ON THE BOARD: 800 KG SPINDLE CONE: ISO50 ROTATION SPEED: 12,000 RPM GAMMA CHANGE: 2 GEAR RANGES FAST FEEDS: 50,000 MM/MIN TOOL CHANGE KITAMURA 1:100 SEATS TOOL CHANGE KITAMURA 2:50 SEATS CONTROL: FANUC 16 iM SHUTTLE FASTEM SYSTEM TO 16 STATIONS
used
Pallet length: 0 mm Pallet width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Number of pallets: 0 Positions ATC: 0 CNC Brand: 0 CNC Model: 0 Control: GE FANUC Series 31i-Model AB Technical data Table length: 400 mm Table width: 400 mm Table load max.: 400 kg Maximum swing circle of up to: 600 mm Longitudinal travel (X-axis): 650 mm Transversal travel (y-axis): 560 mm Vertical travel (z axis): 560 mm Pallets chanching device: number: 12 Length: 400 mm Width: 400 mm Maximum workpiece weight: 400 kg Transport weight: 100 kg Tool magazine number of tools: 120 Spindle nose: BT: 40 Distance from horizontal spindle to table: 90 - 650 mm Spindle speeds: stepless from: 12 rpm up to: 12000 rpm Work feed rate: 20 m/min Rapid traverse:: 60 m/min Air connect: 6 bar Voltage 50 Hz 3x: 380 Volt Spindle power: 22 kW Total power required: 65 kW Total power required: 380 kVA Machi ...
horizontal conveyor belt with hydromotor
new
ISITAN BENDING MACHINE HORIZONTAL TYPE HP 22 - Capaciteite 22 ton - Hydraulic - Slag 200 mm - Digital uitlezing - Digital slag instelling - Table 1100 x 625 mm - Twee hands bediening of voetbediening - Centraal smeersysteem - Materiaalaanslag - Noodstop - Documentatie - 400V DUTCHMACH Metalworking machines ENSCHEDE - NETHERLANDS (3 km from the German border)
used
Pallet length: 0 mm Pallet width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Number of pallets: 0 Positions ATC: 0 CNC Brand: 0 CNC Model: 0 Control: GE FANUC Technical data Longitudinal travel (X-axis): 700 mm Transversal travel (y-axis): 500 mm Vertical travel (z axis): 700 mm Table divisions (B): 360´000x0.001 ° Table speeds: up to: 15 rpm Pallets: number: 9 Length: 500 mm Width: 400 mm Time of changing palets: 14 sec Transport weight: 500 kg Tool changer: Number of tools: 144 (2x72) Max. tool-weight: 12 kg Time of tool changing: 6 - 8 sec Spindle nose: ISO: 45 Horizontal spindle speeds: stepless from: 40 rpm up to: 10000 rpm Feeds: stepless longitudinal from: 1 mm/min up to: 10000 mm/min transversal from: 1 mm/min up to: 10000 mm/min vertical from: 1 mm/min up to: 10000 mm/min Rapid traverse:: 15 m/min Voltage 50 Hz 3x: 380 Volt Spindle motor: 15 kW Total ...
used
Capacity round maximum diameter: 0 mm Angle degrees maximum: 0 Capacity square: 0 mm Workpiece height: 0 mm Workpiece width: 0 mm Capacity rectangle: 0 mm Technical data Cut range: round up to: 250 mm Square: 250 mm Execution: Horizontal hydraulic Automatic Cut length: min.: 3 mm max: 2 X 400 mm Cutting speed: stepless from: 14 m/min up to: 116 m/min Roll diameter: 460 mm Band length: 4100 mm Voltage 50 Hz 3x: 380 Volt Power: 4.00 kW Machine´s weight about: 1500 kg Overall dimensions machine: Length: 1700 mm Width: 1500 mm Height: 1350 mm Various accessories: Coolant system
used
Control: FANUC 21I-MA Technical data Longitudinal travel (X-axis): 500 mm Transversal travel (y-axis): 400 mm Vertical travel (z axis): 400 mm Table divisions (B): 360000 ° Pallets: number: 2 Length: 400 mm Width: 400 mm Time of changing palets: 8 sec Tool changer: Number of tools: 20 Tool diameter: 100 mm Tool lenght: 250 mm Max. tool-weight: 5 kg Time of tool changing: 1.5 / 3.0 sec Spindle nose:: BT 40 Horizontal spindle speeds: stepless from: 160 rpm up to: 8000 rpm Feed range: 1 - 10000 mm/min Rapid traverse:: 48 m/min Spindle motor: 5.5 / 3.7 kW Machine´s weight about: 4000 kg Overall dimensions machine: Length: 3550 mm Width: 1600 mm Height: 2600 mm Various accessories: Tool changer: with double gripper Number of tools: 20 Full splash cabin Coolant system Chip conveyor Lamp
used
Control: FANUC 18 M Technical data Longitudinal travel (X-axis): 600 mm Transversal travel (y-axis): 560 mm Vertical travel (z axis): 560 mm Table divisions (B): 1 ° Pallets: Length: 450 mm Width: 450 mm Time of changing palets: 12.5 sec Transport weight: 300 kg Tool changer: Number of tools: 40 Tool diameter: 100 mm Tool lenght: 300 mm Max. tool-weight: 6 kg Time of tool changing: 1.6 / 4 sec Spindle nose:: MAS BT 40 Horizontal spindle speeds: number (steps): 2 stepless from: 120-3000 rpm up to: 3000-12000 rpm Feed range: 1 - 15000 mm/min Rapid traverse: long.: 40 m/min Rapid traverse: transversal: 40 m/min Rapid traverse: vertical: 30 m/min Spindle motor: AC 22/18.5 kW Feed motor: 3.8 kW Total power required: 45 kVA Machine´s weight about: 9000 kg Overall dimensions machine: Length: 3048 mm Width: 4051 mm Height: 3180 mm Various accessories: Internal coolant supply (cts): 20 bars ...
used
No. 4428: 1 gebr. Horizontal band saw Fabr. SAMUR, type S-1000 V, Bauj. 1966 Arb.-Ber.: 800 mm throughlet width, Accessories: Table Dimensions: 610 x 610 mm Table extension on the left with welding device Other: Cutting height 350 mm Cutting speed 20-800 mm Sheet length: 4,550 mm. Blade width: 4 to 15 mm. Speed infinitely variable Cutting speed: 23-711 m / min Electric motor 380 V
used
HORIZONTAL MULTIPALLET MANDELLI M7 WORK CENTRE CNC Model: Plasma Tool attachment: iso 50 Spindle power: 25Kw Spindle Rpm: 4000 Number of tools: 100 X-Axis Stroke: 1000mm Y-Axis Stroke: 800mm Z Axis Stroke: 1050mm Guides: flats Pallet size: 630x630mm Pallet type: indexed Pallet grades: 0.001 Multipallet: yes Multipallet pallet number: 6 Pallet system: Carousel Maximum load allowed: 1500Kg High refrigerant pressure: yes Chip evacuator: carpeted Presetting: yes Other technical data: MAXIMUM DIAMETER OF MOVING PIECE mm 1100 MEASURING SYSTEM X Y Z B OPTICAL LINE , ENCODER TOOL DIAMETER MAX mm 450 MAX TOOL LENGTH mm 600 MAXIMUM TOOL WEIGHT DAN 35 Machine equipment: PRESETTING SPURS OMP 60 RENISHAW CONTROL SYSTEM
new
Automatic horizontal packaging machines Model:NT-250 Voltage:AC 220/50 Film width:Max.250mm Power:2.4KW Bag length:65~190mm or 120~280mm Bag width:30~110mm Product height:Max.40mm Film diameter:Max.320mm Pack speed:60~120bags/min Machine size:37706701450mm Weight:480kg
used
Horizontal flow pack machine. This Flow Pack packaging machine consists main machine, coil unwinding group, conveyor belts for loading and unloading the products and control panel.
used
cutting diameter: 250 mm saw band length: 0 mm cutting width: mm workpiece dia.: 150 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Horizontal band saw The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
new
cutting diameter: 360 mm saw band length: 5200 x 34 x 1,1 mm cutting width: 700 mm work height max.: 690 mm Capacity 90° rectangular: 700 x 360 mm : 360 mm : 360 mm Capacity 45° rectangular: 450 x 360 mm : 360 mm : 360 mm : 590 x 360 mm speeds steplessly adjustable: 20 - 100 m/min total power requirement: 3,67 kW weight of the machine ca.: 1,46 t dimensions of the machine ca.: 2850 x 1,3 x 1800 m Horizontal band saw with linear guideways, ideal for mitre cuts between 90° and +30°. Auto height adjustment sensors ensure that the bow can approach the material at high speed. The hydraulic cutting control makes the bow rise up again after a cut has been made. This process is controlled by a digital counter on the control panel. The bow angle is shown in the digital display. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
new
cutting diameter: 320 mm saw band length: 4160 mm cutting width: 610 mm : 320 x 320 mm Capacity 90° rectangular: 610 x 320 mm dimensions of saw-band: 4160 x 34 x 1,1 mm : 320 mm : 320 x 320 mm Capacity 45° rectangular: 355 x 320 mm : 280 mm : 280 mm : 280 x 280 mm capacity 60 degrees: round: 320 mm capacity 60 degrees: square: 320 x 320 mm capacity 60 degrees: flat: 510 x 320 mm speed: 20 -100 m/min total power requirement: 2,7 kW weight of the machine ca.: 1,2 t dimensions of the machine ca.: 2,1 x 1,2 x 1,35 m Beka-Mak Lineer Sledge horizontal bandsaws have been designed to give a low cost compact and rugged machines.The bow is constructed in heavy gauge steel and mounted two chromed and grinding pillars offer a strong rigid sawframe, providing a high degree of accurancy when cutting. The machines are fitted with a removable coolant tank incorporating a submerged electric coolant pum ...
new
cutting diameter: 90° / 810 mm saw band length: 8200 mm cutting width: 850 mm : 810 x 810 mm : 850 x 810 mm : 480 mm : 480 x 480 mm Capacity 45° rectangular: 480 x 810 mm table height: 585 mm cutting speed: 20 - 100 m/min dimensions of saw-band: 8200 x 41 x 1,3 mm speeds steplessly adjustable: 20 - 100 m/min total power requirement: 5,5 kW weight of the machine ca.: 3,8 t dimensions of the machine ca.: 3,9 x 1,2 x 2,35 m Horizontal band saw. The bow is made of heavy steel and the two pillars constitute a strong and rigid saw frame. This ensures high accuracy when cutting. The machines are fitted with an integrated coolant pump that supplies oolant to both guide assemblies. Blade guides with rollers and carbide pads provide precise support for the blade. The machines switch off automatically at the end of the cutting proces and the saw arm is lifted hydraulically. ?inverter ?hydromechan ...
used
MORI SEIKI SH-400 Horizontal Machining Center was manufactured in 2000 in Japan by Mori Seiki CO., LTD. The CNC milling machine is equipped with Mori Seiki MSC-501 numerical control. The price of the machine includes various types of frames. Technical data of the MORI SEIKI SH-400 CNC milling machine - CNC control: MORI SEIKI MSC-501 - machine weight: 10100 kg
new
cutting diameter: 380 mm saw band length: 4800 mm cutting width: 520 mm : 380 x 380 mm Capacity 90° rectangular: 520 x 380 mm : 300 mm : 300 x 300 mm Capacity 45° rectangular: 300 x 380 mm dimensions of saw-band: 4800 x 34 x 1,1 mm speeds steplessly adjustable: 20 - 100 m/min total power requirement: 3,67 kW weight of the machine ca.: 1,33 t dimensions of the machine ca.: 2,85 x 0,93 x 1,66 m Product Description Beka-Mak Lineer Sledge horizontal bandsaws have been designed to give a low cost compact and rugged machines.The bow is constructed in heavy gauge steel and mounted two chromed and grinding pillars offer a strong rigid sawframe, providing a high degree of accurancy when cutting. The machines are fitted with a removable coolant tank incorporating a submerged electric coolant pump which supplies coolant to both guide assemblies. These models can cope with most types of material.B ...
new
cutting diameter: 320 mm saw band length: 3660 mm cutting width: 440 mm Capacity 90° rectangular: 440 x 220 mm : 320 mm speed: 20 -100 m/min main drive: 1,5 kW hydraulic pump: 0,37 kW coolant pump: 0,12 kW dimensions of saw-band: 3660 x 27 x 0,9 mm total power requirement: 2,0 kW weight of the machine ca.: 670 kg dimensions of the machine ca.: 1,9 x 0,85 x 1,3 m Beka-Mak Lineer Sledge horizontal bandsaws have been designed to give a low cost compact and rugged machines.The bow is constructed in heavy gauge steel and mounted two chromed and grinding pillars offer a strong rigid sawframe, providing a high degree of accurancy when cutting. The machines are fitted with a removable coolant tank incorporating a submerged electric coolant pump which supplies coolant to both guide assemblies. These models can cope with most types of material.Blade guides with rollers and carbide pads provide pr ...
new
cutting diameter: 1110 mm saw band length: 10500 x 67 x 1,6 mm cutting width: 1110 mm : 1110 mm : 1110 x 1110 mm table height: 545 mm speeds steplessly adjustable: 20 x 100 m/min total power requirement: 15,5 kW weight of the machine ca.: 10,44 t dimensions of the machine ca.: 4800 x 1500 x 2975 m Horizontal band saw. The bow is made of heavy steel and the two pillars constitute a strong and rigid saw frame. This ensures high accuracy when cutting. The machines are fitted with an integrated coolant pump that supplies coolant to both guide assemblies. Blade guides with rollers and carbide pads provide precise support for the blade. The machines switch off automatically at the end of the cutting proces and the saw arm is lifted hydraulically. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
new
cutting diameter: 450 mm saw band length: 5400 x 41 x 1,3 mm cutting width: 695 mm : 425 x 425 mm Capacity 90° rectangular: 560 x 425 mm capacity 45 degrees: round: 430 mm : 425 x 425 mm Capacity 45° rectangular: 430 x 425 mm : 450 mm : 425 x 425 mm : 560 x 425 mm capacity 60 degrees: round: 320 mm capacity 60 degrees: square: 290 x 290 mm capacity 60 degrees: flat: 260 x 425 mm table height: 690 mm speeds steplessly adjustable: 20 - 100 m/min dimensions of saw-blade: 5400 x 41 x 1,3 mm total power requirement: 4,67 kW weight of the machine ca.: 1,63 t dimensions of the machine ca.: 2,85 x 1,3 x 1,8 m Horizontal band saw with linear guideways, ideal for mitre cuts between 90° and +30°. Auto height adjustment sensors ensure that the bow can approach the material at high speed. The hydraulic cutting control allows the bow rise up again after a cut has been made. This process is control ...
new
cutting diameter: 560 mm saw band length: 6000 mm cutting width: 750 mm table height: 590 mm : 560 mm Capacity 90° rectangular: 410 x 560 mm : 410 mm : 410 mm Capacity 45° rectangular: 410 x 560 mm speeds steplessly adjustable: 20 - 100 m/min dimensions of saw-band: 6000 x 41 x 1,3 mm total power requirement: 5,22 kW weight of the machine ca.: 2,045 t dimensions of the machine ca.: 3,4 x 1,0 x 2,05 m Horizontal band saw. The bow is made of heavy steel and the two pillars constitute a strong and rigid saw frame. This ensures high accuracy when cutting. The machines are fitted with an integrated coolant pump that supplies oolant to both guide assemblies. Blade guides with rollers and carbide pads provide precise support for the blade. The machines switch off automatically at the end of the cutting proces and the saw arm is lifted hydraulically. ?inverter ?hydromechanic blade tension ?swa ...
used
spindle diameter: 225 mm x-travel: 8000 mm y-travel: 5600 mm z-travel: 2100 mm w-axis: 1400 mm spindle turning speed - stepless: 0-650 U/min spindle taper ISO: 60 feed stepless: 5 - 3000 mm/min rapid traverse: 5 m/min weight of the machine ca.: 150 t dimensions of the machine ca.: 12 x 5 x 8 m total power requirement: 120 kW Ram type horizontal boring machine was reconditioned and modernized in 2006, original yom was 1972. Control Siemens 840 C. Machine will come with tools and a vertical milling head. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 Kg4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmNumber of Slots 5Slot width 14 mmSpindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)Tool magazine, cha ...
used
GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 Kg4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmNumber of Slots 5Slot width 14 mmSpindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)Tool magazine, cha ...
used
GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 KgRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmNumber of Slots 5Slot width 14 mm4. Axes (swivelling range) 360 x 0,001 degreeSpindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)Tool magazine, cha ...
used
GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 KgRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmNumber of Slots 5Slot width 14 mm4. Axes (swivelling range) 360 x 0,001 degreeSpindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)Tool magazine, cha ...
used
Horizontal band saw make PEHAKA type HS 260Year of construction 1981Cutting area around 90 °: 260 mmCutting area flat 90 °: 400 x 155/370 x 180 mmCutting area square 90 °: 220 x 220 mmCutting area around 45 °: 170 mmCutting area flat 45 °: 160 x 145 mmCutting area IPE 45 °: NP 24stepless saw blade speed: 20 - 60 mm / min.Saw band size: 3650 - 3700 x 25 x 0.9 mmDrive power: 0.75 kWWeight approx: 360 kgOutside dimensions approx: 2200 x 1000 x 1300 mmWith- Returning deviceused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Horizontal band saw machine make PEHAKA type HS 340Machine -No: 27354 for semi-automatic workflowTechnical specifications:Working space 90 ° round: 340 mmWorking area 90 ° flat: 340 x 500 mmWorking space 45 ° round: 230 mmWorking area 45 ° flat: 200 x 300 mmControl range: 12 - 80 m / minSaw drive: 4 kWSaw band: 4860 x 32 x 1.1 mmRoll diameter: 500 mmRequired space: 2700 x 1600 x 1900 mm highWeight: 1050 kgWith- Infinitely variable cutting speed- hydr. Raising and lowering the saw frame- Control panel on the saw armused, in good working conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
spindle diameter: 130 mm x-travel: 3000 mm y-travel: 2000 mm total power requirement: 4,5 kW weight of the machine ca.: 30 t Spindle Ø 130 mm Spindle taper SK 50 Working range: X = column, longitudinal 3,000 mm Y = headstock, vertical 2,000 mm Z = spindle stroke 1,000 mm Lower table 3,300 x 2.400 mm Max. weight on table 10 tons/m² Min./ max position of work spindle above table 770 / 2,770 mm Feeds 0.9 - 2,000 mm/min Quick feed for headstock and column 5,000 mm/min Quill feed 0.5 - 1,200 mm/min Speed range, partially infinitely variable 4.5 - 1,250 rpm Weight, approx. 30,000 kg Accessories / Special Features HEIDENHAIN Digital Display for 3 axes. Hardened guideways. Ball screw spindles. Infinitely variable spindle speeds and feeds. Feeds can be individually driven with motor. Moving operating platform. Hanging control panel. Manual operati ...
used
x-travel: 800 mm y-travel: 630 mm z-travel: 560 mm total power requirement: 60 kW weight of the machine ca.: 12.5 t dimensions of the machine ca.: m H E L L E R (Germany) 5 Axis - CNC Controlled Horizontal Machining Centre Model FST- MC 160 / 800 / E Year 1998 Only approx. 500 hours in operation _______________________________________________________ Working range: Longitudinal stroke X axis 800 mm Vertical stroke Y axis 630 mm Cross stroke Z axis 560 mm NC rotary table Tilting A axis 180 ° Turning B axis 360 ° Size of pallet, approx. 250 x 620 mm Tool holder HSK 63A Spindle speeds, infinitely variable 63 - 20,000 rpm Feeds / quick feeds XYZ 1 - 70,000 mm/min Spindle drive 24 kW Total electrical load, approx. 60 kW - 400 V - 50 Hz Weight, approx. 12,500 kg Accessories / Special Features 5-Axis SIEMENS CNC Path Control, Mode ...
used
Horizontal band saw machine make HESKA type HES 260Fabr. -No: 20709.01, year of construction 2001Tehnical data:cutting areaaround 90 °: 260 mmaround 45 °: 160 mmflat 90 °: 525 x 120 mmflat 45 °: 160 x 260 mmSquare 90 °: 260 x 260 mmflat 45 °: 160 x 160 mmMiter adjustment required by turning the jawsSaw engine approx. 0.6 / 0.8 kWCoolant engine approx.: 0.09 kWCutting speed: 15-90 m / minSaw blade dimensions: 3660x25x0.85 mmNet weight approx: 360 kgSpace required approx.: 1900 x 800 mmusedPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Horizontal band saw make JAESPA type W 260Fabr. -No: 14759 built in 1989Technical specifications:Cutting areas90 ° round: 260 mm90 ° flat: 410 x 200 mm90 ° square: 260 x 260 mm45 ° round: 250 mm45 ° flat: 220 x 220 mm45 ° square: 245 x 210 mmSaw band speed continuously: 17 - 106 m / minSaw band dimensions: 3660 x 25 x 0.9 mmDrive power: 1.1 kWExternal dimensions approx .: 1950 x 950 x 1600 mmWeight approx: 520 kgused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
spindle diameter: 225 mm x-travel: 8000 mm y-travel: 5600 mm z-travel: 2100 mm w-axis: 1400 mm spindle turning speed - stepless: 0-650 U/min spindle taper ISO: 60 feed stepless: 5 - 3000 mm/min rapid traverse: 5 m/min weight of the machine ca.: 150 t dimensions of the machine ca.: 12 x 5 x 8 m total power requirement: 120 kW Ram type horizontal boring machine was reconditioned and modernized in 2006, original yom was 1972. Control Siemens 840 C. Machine will come with tools and a vertical milling head. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
new
cutting diameter: 360 mm saw band length: 5000 mm cutting width: 610 mm speed: 20 -100 m/min main drive: 3 kW hydraulic pump: 0,55 kW coolant pump: 0,12 kW dimensions of saw-band: 5000 x 34 x 1,1 mm : 360 mm : 360 x 360 mm Capacity 90° rectangular: 610 x 360 mm : 360 x 360 mm : 360 x 360 mm Capacity 45° rectangular: 490 x 360 mm : 360 mm : 360 mm : 610 x 360 mm capacity 60 degrees: round: 3,67 mm capacity 60 degrees: square: 360 x 360 mm capacity 60 degrees: flat: 360 x 360 mm band speed: stufenlos 20 - 100 m/min total power requirement: 3,67 kW weight of the machine ca.: 1,47 t dimensions of the machine ca.: 2,75 x 1,21 x 1,87 m This twin-pillar horizontal bandsaws have been designed to provide a low cost, compact and rigid machine.The bow is constructed in heavy gauge steel. It is mounted at two chromed and grinded pillars offering a strong rigid sawframe. This design provides a high ...
new
cutting diameter: 350 mm saw band length: 4160 mm cutting width: 400 mm : 350 mm : 350 x 350 mm Capacity 90° rectangular: 400 x 350 mm speed: 20 -100 m/min main drive: 2,2 kW hydraulic pump: 0,37 kW coolant pump: 0,12 kW dimensions of saw-band: 4160 x 34 x 1,1 mm work height max.: 860 mm total power requirement: 2,9 kW weight of the machine ca.: 1030 kg dimensions of the machine ca.: 2,23 x 0,88 x 1,89 m Description: • Fully automatic miter band saw for sawing thick-walled Profiles and solid materials • Motorized roll feed of the material with electrical contact stop • Delta touch screen controls • Miter cutting, up to 45 ° • 1 program with 10 steps • Length accuracy 0.5 mm The feed length of the material is manually adjustable via an Microswitches selected that • Robustly constructed monoblock saw frame with hydraulic vertical movement and linear guide • Rapid advanc ...
new
cutting diameter: 540 mm saw band length: 6000 mm cutting width: 750 mm table height: 695 mm cutting speed: 20 - 100 m/min : 540 mm : 540 x 540 mm Capacity 90° rectangular: 750 x 540 mm : 540 mm : 540 mm : 600 x 540 mm : 510 mm : 450 mm Capacity 45° rectangular: 450 x 540 mm capacity 60 degrees: round: 270 mm capacity 60 degrees: square: 250 mm capacity 60 degrees: flat: 250 x 540 mm total power requirement: 4 kW weight of the machine ca.: 2,45 t dimensions of the machine ca.: 3,0 x 1,3 x 2,13 m Horizontal band saw. The bow is made of heavy steel and the two pillars constitute a strong and rigid saw frame. This ensures high accuracy when cutting. The machines are fitted with an integrated coolant pump that supplies oolant to both guide assemblies. Blade guides with rollers and carbide pads provide precise support for the blade. The machines switch off automatically at the end of the cu ...
used
GeneralHorizontal universal machining center; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal650 mmCross700 mmVertical950 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minCabineFull protection cabinMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Taper cleaning brushesTaper cleaning unit with rotating brushes for spindle taper HSKNC swivel rotary table DirectDriveNC swivel rotary table direct drive Table plate: d 650 mm / 25.6 in 1 x T-slot 14 H7 / 0.55 H7 (alignment groove, table centre) 8 x T-slot 14 H12 / 0.55 H7 (clamping grooves) Permissible load: 600 kg / 1,323 lbs Rotary-axis: 80 min-1 direct drive Swivel-aKinematics a ...
