hollow used for sale

Hollow shaft motor, three-phase electric motor, three-phase motor EX SIEBERT EMP112-B8 Hollow shaft diameter ( inner ): Ø 28 / 32 mm hollow shaft diameter ( outer ): Ø 40 mm Flange diameter: 160 mm used, tested ! very good condition ! Dimensions: 305 x 220 x 280 mm

Hollow section fastener, hollow section fastening, for steel construction, 10 pieces BOXBOLT® BQ1Z12 Clamping range: 5 - 25 mm drilling diameter: Ø 20 mm screw: M12 x 1,75 Screw length: 55 mm Width across flats: 17 / 26 mm Material: Steel, galvanized New Dimensions ( single fastener ): 65 x 30 x 26 mm

Hollow nozzle, nozzle FEUERLÖSCHGERÄTEWERK LUCKENWALDE ( FGL ) Type C with ball valve used, tested ! Dimensions: 570 x 130 x 160 mm

Hollow chamber gasket profile, window profile, push-in SAINT-GOBIAN SIPRO® profile: P1476-724 Length: approx. 55 m Profile width: 26 mm Profile height: 27 mm Material: high-viscosity silicone rubber New ! Dimensions ( packaging ): 600 x 600 x 250 mm

Gebr. Drilling and mortising machine Hollow Mortizing Machine FIELDS MCD Motor power: 1.1 kW (380V) max. chisel insert: 25 mm Table length adjustment: 240 mm Table depth adjustment: 76 mm Vertical stroke: 175 max. wood height: 1,000 mm Drill Center Distance: 82 max. wood width: 160 mm Weight: 185 kg Information according to manufacturer incl. 2 chiseling tools Copy of instruction manual available Good original condition! From private workshop closure Sold in ACTUAL condition and unrefurbished from carpentry dissolution. Fixed price.

Description: Hollow sections: 100x50x4 mm: 49 pcs 50x50x3 mm: 13pcs Material: 1.4301 Approx. Onsite Dimension. (l x w x h): 6,000 x 1,000 x 600 mm, weight approx.: 2,835 kg

Demoor 825-320 oil country lathe. Distance between centers: 3000mm. Swing: 970mm. Swing in carriage: 700mm. Bore: 320mm. New electrical box. Carriage with cone copier. Equipped with chuck.

spindle passage: 230 mm turning diameter over bed: 970 mm turning diameter over slide rest: 720 mm Control: Fanuc OiTD turning length: 2200 mm total power requirement: 37 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Plummer Block Housings, Plummer Block Housings -Hole center height: 40/Ø 10 mm -Base plate: 145 235 x 95 mm -Price: per piece -Number: 2 pieces -Dimensions: 145/95/H approx. 65 mm -Weight: 1.3 kg

Plummer Block Housings, Plummer Block Housings -Hole center height: 70/Ø 16 mm -Base plate: 235 x 147 mm -Dimensions: 235/147/H approx. 100 mm -Weight: 4.3 kg

Description: Point width approx. 1500 mm , Turning diameter over bed approx. 940 mm , Turning diameter above support approx. 740 mm , Rod clearance approx. 200 mm Fabrication number 1-206/59 , Power 30 kW , Voltage 3 x 500 V Nominal current 55 A Frequency 50 Hz Control SIEMENS Sinumerik The machine was modernized in 2001 by the Stork company Approx. Onsite Dimension. (l x w x h): 4,500 x 2,200 x 1,950 mm, weight approx.: 4,500 kg

turning diameter over bed:650 mm turning diameter over slide:450 mm turning length:1435 mm bed width:350 mm spindle bore:155 mm spindle speed:50-800 (3 stufig, stufenlos) U/min spindle taper:A2-11 longitudinal feeds::0,05-1,5 cross feeds::0.025 - 0.752 tailstock quill stroke:220 mm tailstock quill diameter:95 mm tailstock quill taper MT:5 MK tool post size:25x25 mm power requirement:7,5 kW weight of the machine ca.:2400 kg dimensions:3020x1140x1770 mm DRO:von FAGOR 3 Achsen Modell 40iTS mit konstanter Schnittgeschwindigkeit fixed steady:Option follower rest:Option tool holder:4-fach 3 jaw chuck Ø:400mm, vorne und hinten (2 Stück), mit Bohrung 155mm, und 2 Satz weiche Backen splash guard:am Schlitten mit Mikroschalter anti vibration pads:6 Stück Factory new center lathe with 2-axis digital display and variable speed and many more. CHARACTERISTICS: Powerful, flexible and productive With ...

GeneralIntegrated Mill Turn Center; Control: Control F31iB5 with CELOS CharacteristicsSwing- Ø, max.700 mmSpeed max.12000 rpmSlewability of B-Axis±120 degreeMovements X / Z / Y675/1562/300 (±150) mmMilling spindle upper side1 Bar diametre80 mmMax. Turning Length1530 mmSpeed max.4000 rpmMax machining diameter670 mmDrive power tool spindle5,5/3,7 kWDrive power milling spindle28/23 kWDrive power main spindle18,5/15 kWMovements X / Z200/1542 mmLower Turret10 PositionsNumber of Toolmagazine positions38 Weight approx.18500 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and p(Left Spindle) through-spindle hole dia. 91 mm, 4,000min-1 (STD)(Left Spindle) Through-spindle Hol ...

GeneralTurning Center; Control: Control M730UM CharacteristicsMax machining diameter366 mmDimensions (L x W x H)3,84 x 2,36 x 1,80 mDrive power tool spindle7,5/5,3/3,7 kWDrive power main spindle22/11 kWRapid feed X / Z30/30 m/minInput precision of C-axis on Mainspindle0,001 degreeMovements X / Z250/1143 mmRotary tool spindle speed6000 rpmNumber of tool stations12 Speed max.4500 rpmBar diameter max.65 mmSpindle bore73 mmSwing- Ø, max.760 mmMax. Turning Length1085 mmWeight approx.6500 KgSLIMlineSLIMline DMG MORI operating system equipped with MAPPS. The large 15-inch display can reduce the number of switching of the screen as it provides the four-way split screen and allows user to see more information at once. It is also possible to customi(Spindle 1) 22/15/11 kW,4,500 min-1 (Standard)(Spindle 1) Standard Spindle 22/15/11 kW (30/20/15 HP), 4,500 min-1 The ALX2000 adopts a highly reliable ...

GeneralMilling Specification; Control: Control M730UM with CELOS CharacteristicsMax machining diameter278 mmDimensions (L x W x H)2,82 x 2,09 x 2,15 mDrive power tool spindle5,5/5,5/3,7 kWDrive power main spindle11/15/15 kWRapid feed X / Z30/30 m/minInput precision of C-axis on Mainspindle0,001 degreeMovements X / Z260/590 mmRotary tool spindle speed10000 rpmNumber of tool stations12 Speed max.6000 rpmBar diameter max.52 mmSwing- Ø, max.755 mmMax. Turning Length192 mmWeight approx.4900 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and pHigh-output spindle (Left Spindle) 15/ 11 kW, 6,000 min-1(Left Spindle) High-Output Spindle 15/11 kW (20/15 HP), 6,000 min-1 The NLX ...

GeneralCNC Turning Centre with C axis and tool drive; Control: Control M730UM with CELOS CharacteristicsMax machining diameter356 mmDimensions (L x W x H)2,82 x 2,09 x 2,15 mDrive power tool spindle5,5/5,5/3,7 kWDrive power main spindle15/22/22 kWRapid feed X / Z30/30 m/minInput precision of C-axis on Mainspindle0,001 degreeMovements X / Z260/590 mmRotary tool spindle speed10000 rpmNumber of tool stations12 Speed max.-5000 rpmBar diameter max.65 mmSwing- Ø, max.755 mmMax. Turning Length510 mmWeight approx.5000 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and pHigh-output spindle (spindle 1) 22/ 15 kW, 5,000 min-1The NLX 2000 adopts a highly reliable main spindle de ...

GeneralTwo- Spindle Turning Centre; Control: Sinumerik 840C Tool holder 2Shank diametre according to DIN 6988030 mmNumber of tool stations12 Number of driven tools12 Speed max.-4000 rpmPower max. (100% DC)5 kWPower max. (40% DC)6,5 kWTool holder 1Number of tool stations12 Shank diametre according to DIN 6988030 mmNumber of driven tools12 Speed max.-4000 rpmPower max. (100% DC)5 kWPower max. (40% DC)6,5 kWSlide 3 (Spindle 2)Longitudinal stroke600 mmRapid traverse Z30 m/minFeed rate torque (100% DC) in Z700 daNSlide 2Longitudinal stroke555 mmTransverse stroke190 mmRapid traverse X20 m/minRapid traverse Z30 m/minSlide 1Longitudinal stroke555 mmTransverse stroke190 mmY axis, vertical+/- 40 mmRapid traverse in X20 m/minRapid traverse in Z30 m/minRapid traverse in Y7,5 m/minFeed rate torque (100% DC) in X/Y/Z400/700/700 daNMain drive 2Type of main driveAC Drive power (100% DC)14 kWDrive power  ...

GeneralCNC Turning Centre; Control: Control M730UM with CELOS CharacteristicsMax machining diameter920 mmWeight approx.19900 KgRapid feed X / Z20/24 m/minInput precision of C-axis on Mainspindle0,001 degreeMovements X / Z485/2150 mmNumber of tool stations12 Speed max.1600 rpmBar diameter max.116 mmSwing- Ø, max.733 mmMax. Turning Length2000 mmDrive power main spindle45/37 kWCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and p(Left Spindle) Hollow Cylinder set for KITAGAWA 24in. Hollow Chuck B-24A1521D (without chuck body) (SK-OP)(Left Spindle) Hollow Cylinder Set for 24-inch) Chuck B-24A1521D (Bar work capacity dia. 117 mm (4.61 inch)) Hollow cylinder and draw bar are  ...

Tip height over bed top distance of 200 mm 1000-1500 mm Permissible diameter on bed 400 mm Permissible diameter on sled 230 mm bed Bed width 280 mm head Spindle passage 52 mm 6ʺ camlock spindle nose Speed Spindle speed 16 n. Values 36-2000 RPM. Feeding and tapping 72 longitudinal feed 0.05-4.45 mm / rev 72 cross feed 0.025-2.25 mm / rev 54 Whitwort Division 1-56 TPI 54 metric pitch 0.5-28 mm 54 English Division 1-32-1ʺ inch 54 Division of modular 0.25-14 mm 54 pitch Division 2-112 D.P.. Cross slide 470 mm Width 180 mm Maximum stroke 235 mm Cross slide Length 260 mm Width 120 mm Maximum stroke 150 mm Slewing range 360 degrees Counter tailstock Hollow shaft diameter 58 mm Hollow shaft length 265 mm Maximum stroke hollow shaft 120 mm Cone of the hollow shaft 4 C.M.. - MK Motor Power 4 kW

GeneralTurning-milling centre - partial hollow clamping device - drawtube ID 68 mm - C-axis and spindle brake (hydraulically) - upper compound slide with turning-/ milling spindle, reception HSK-A63, DIN 69893 with 3-fold Hirth-coupling 1°-Indexing to lock the spindle during turning operations - Y-axis - B-axis interpolating with hydraulically locking - tool magazine 1 x 60-fold, shelf magazine with tool changer and handling unit, additional 4 tool loading stations; Control: Sinumerik 840D powerline Technical DataDrive power (100% DC)13,2 kWDrive power (40% DC)22 kWTorque (40% DC)100 NmSpeed range20-12000 rpmB axis, slide 1Swivelling range+/- 120 degreeSlide 3Transverse stroke1500 mmRapid traverse Z36 m/minSlide 2Longitudinal stroke1400 mmTransverse stroke225 mmRapid traverse X24 m/minRapid traverse Z40 m/minSlide 1Longitudinal stroke1585 mmTransverse stroke550 mmY axis, vertic ...

Gebr. Ground paver Fabr. Zenith 913, incl. 4 moulds for: Hollow block 49/17.5/17.5 cm, Hollow block 30/24/17.5 cm Hollow block stone 36/24/17.5 cm, hollow block stone 36/24/23.8 cm The machine runs on triangular rails, max. mold width is 131.5 cm, production area thus approx. 120 cm Production depth max. approx. 100 cm

Suitable to sharpen automatically the face and top on carbide tipped circular saw blades in one, set-up. The complete machining hook angle, clearance angle, top and blade body in one single clamping Accessories:, Total enclosure,, Coolant system,, Automatic fire extinguishing device,, Alphanumeric plug-in keyboard for data management,, Machine light,, Extractor,, Measuring probe,, Saw diameter: 80-840mm, Bore diameter: from 10 mm, bore diameter: from 10 mm, sheet thickness:

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 100 mm - B-axis ±110° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 5 bar; 20l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor - USB interface, Ethernet interface; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length750 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmC-Axis Speed-5000 rp ...

Our company offers the SUMAB E-12, which is a movable concrete block machine. The E-12 is a block machine that uses a technique known as egg laying,” where the block machine moves and produces concrete block products on the ground to dry – We offer the machine in fully/semi-automatic modes. With the SUMAB E-12, the following concrete products can be produced in an efficient way: • Hollow block stones • Solid block stones • Chimneys • Light weight blocks • Paving stones [with vibration table option] additional option Production capacity: For hollow blocks 400 x 200 x 200 mm ………. 1.200 blocks/h. For hollow blocks 400 x 200 x 120 mm ………. 2.000 blocks/h.

GeneralTwo spindle turning/milling centre with - Main and counter spindle; Control: CELOS with Siemens 840D sl Operate Tool holder 2Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.4000 rpmPower max. (40% DC)10 kWTool magazineNumber of tools24 Max. tool length230 mmMax. tool diameter80 mmMax. tool weight7 KgTurning-milling spindleSpindle taperHSK-A 63 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22,5 kWTorque (100% DC)85 NmTorque (40% DC)120 Nmlocking moment1000 NmSwivelling range+/-110 degreeSlide 2Longitudinal stroke1200 mmTransverse stroke195 mmSlide 3Longitudinal stroke1200 mmSlide 1Longitudinal stroke1200 mmTransverse stroke490 mmY axis, vertical+/- 100 mmHeadstock, rightClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWDri ...

GeneralTwo spindle turning/milling centre with - Main and counter spindle; Control: CELOS with Siemens 840D sl Operate Tool holder 2Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.4000 rpmPower max. (40% DC)10 kWTurning-milling spindleSpindle taperHSK-A 63 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22,5 kWTorque (100% DC)85 NmTorque (40% DC)120 Nmlocking moment1000 NmSwivelling range+/-110 degreeTool magazineNumber of tools24 Max. tool length230 mmMax. tool diameter80 mmMax. tool weight7 KgSlide 3Longitudinal stroke1200 mmSlide 2Longitudinal stroke1200 mmTransverse stroke195 mmSlide 1Longitudinal stroke1200 mmTransverse stroke490 mmY axis, vertical+/- 100 mmHeadstock, rightClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWDri ...

Short-stroke heavy-duty cylinders, high-pressure hydraulics, compact cylinders, light metal cylinders, high-pressure cylinders, universal cylinders, hydraulic cylinders, straightening cylinders, hydraulic rams, hydraulic pressure cylinders, lifting cylinders, pressure rams, hydraulic short-stroke cylinders, hollow-piston cylinders, hydraulic hollow-piston cylinders -Manufacturer: Bahco, hydraulic cylinder hollow piston cylinder type CR 60-100 -Pressure force 60 ton -Stroke: 100mm -Piston: Ø 80 mm -Pressure: max. 800 bar -Number: 1x cylinder available -Price per piece -Dimensions: 170/130/H210 mm -Weight: 16 kg/pc.

Short-stroke heavy-duty cylinders, high-pressure hydraulics, compact cylinders, light metal cylinders, high-pressure cylinders, universal cylinders, hydraulic cylinders, straightening cylinders, hydraulic rams, hydraulic pressure cylinders, lifting cylinders, pressure rams, hydraulic short-stroke cylinders, hollow-piston cylinders, hydraulic hollow-piston cylinders -Manufacturer: Bahco, hydraulic cylinder hollow piston cylinder type CHB 30-150 -Pressure force 30 ton -Stroke: 150mm -Piston: Ø 63 mm -Pressure: max. 800 bar -Number: 1x cylinder available -Price per piece -Dimensions: 160/120/H320 mm -Weight: 16 kg/pc.

Gear motor, electric motor, electric gear motor -Power: 0.37 kW -Diameter hollow shaft: 24 mm -Speed hollow shaft: 100 rpm -Diameter shaft: 14 mm -Speed shaft: 1500 rpm -Construction: hollow shaft -Protection class: IP 44 -Number: 1x engine available -Price: per piece -Dimensions: 370/210/H175 mm -Weight: 12 kg

Gear motor, electric motor, electric gear motor -Power: 0.55 kW -Diameter hollow shaft: 20 mm -Speed hollow shaft: 120 rpm -Diameter shaft: 8 mm -Speed shaft: 1500 rpm -Construction: hollow shaft -Protection class: IP 44 -Number: 2x motor available -Price: per piece -Dimensions: 490/160/H235 mm -Weight: 19 kg

Gear motor, electric motor, electric gear motor -Power: 0.25 kW -Diameter hollow shaft: 22 mm -Speed: hollow shaft 91 rpm -Diameter shaft: 11 mm -Speed shaft: 380 rpm -Construction: hollow shaft -Protection class: IP 44 -Brake -Number: 1x engine available -Price: per piece -Dimensions: 370/210/H175 mm -Weight: 15 kg

turning diameter:220 mm turning length:200 mm control:Fanuc 0i-TF Manual Guide bar material dia.:26 mm spindle speeds:6000 1/min. spindle drive:7,5/11 kW rapid speed:20 m/min travel -x axis:155 mm travel - z:200 mm CNC controller:Fanuc 0i-TF Manual Guide (Werkstattprogrammierung) + 10,4" LCD turret:12 (hydr.) fach hydraulic unit:mit Lufkühlung hollow chuck:hydraulisch, 150 mm tool holder:4 Stück Innen (Ø32mm), 6 Stück Außen, 2 Stück Plan bar loader:optional Tool setter:manuel soft jaw:1 Satz BORING SLEEVES :6 Stk. (Durchm. 8, 10, 12, 16, 20, 25 mm) Contains: 1.Control system Fanuc 0i-TD (8.4"COLOR LCD) 2.Spindle motor 7.5/11KW Fanuc â8/8000i 3.Spindle speed 6.000 RPM (Bar capacity: Dia 26mm) 4.X/Z-Axis stroke 155/220 mm 5.X/Z Axis rapid traverse 20/20 m/min 6.Hyd.hollow chuck 6" x 3 jaws 7.Hydraulic turret system 12 stations 8.Hyd. Unit for chuck with air cooler 9.Without tails ...

turning diameter over bed:42 mm turning diameter over longitudinal slide:42 mm turning length:110 mm control:FANUC 31 i model B spindle speed::25 - 6000 1/min spindle:5,5 / 7,5 kW spindle hollow:42 mm total power requirement:25 kVA weight:3,3 t space requirements approx. LxWxH:2,95 x 1,55 x 2,15 m CNC-lathe, NEW , from showroom we have 4 new machines in our stock CNC long center lathe with moved spindle and subspindle prepaired for bar loader up to 42 nmm 7 axis ( X Z Y C Z2 X2 C2 ) 5 pcs. toolholder 20 x 20 mm 5 pcs. drill holder 4 pcs. driven tools , max. 6.000 rpm 4 pcs. driven tools from backside , max 5.000 rpm swarf conveyer, high pressure cooling system hollow clamping device, eletr. handwheel hydraulic hollow clamping cylinder front- and backside clamping system on both sides Hainbuch SK 52 0 h "machine on", 0 h "spindle on" !

Planer Brand: Panhans Type: 335/20 New machine Technical data: - Planing width 510mm - Feed table length 1620mm - Delivery table length 1170mm - Total table length 2850mm - Blade shaft speed 5000 rpm. - Extraction nozzle Ø 160mm - Chip removal up to 8mm - Weight approx. 1,050 kg Motor power 5.5kW / 7.5PS Voltage 400V / 50 Hz Required space approx. 2900 x 1500mm Solid German mechanical engineering For dressing and joining, including hollow and pointed joint setting for planing widths up to 510 mm and max. Chip removal up to 8 mm Ergonomic working position directly on the blade shaft PANHANS solid steel blade shaft ø 125 mm with 4 pieces of Tersa reversible blade Finely planed machine tables, total table length 2850 mm Control panel above at eye level with digital display of chip removal, the current delivery table situation (neutral, hollow or pointed joint),  ...

pressure:100 t stroke:1000 mm table surface area:1045 x 1045 mm table extendable:800 mm table speed:50 mm/sec dimensions:ca. 2550 x 2850 x 3620 mm height over floor:600 mm diameter of piston:76 mm ram diameter:110 mm ram hole:40 H7 Cylinder:300 mm total power requirement:5,5 kW pump capacity:24,9 Lt./min Pressure power:250 bar :200 l daylight opening:1600 mm daylight:1200 mm weight of the machine ca.:6,6 t hollow:180 mm hollow:400 mm :1000 kg :1 - 10 mm/sec work stroke:3 mm/sec :1 - 25 mm/sec :33 mm/sec

PLC – controlled high-performance precision cold-circuit sawing machine with loading magazine and unloading magazine of very high quality - equipped with software for industrial production in accordance with Industry 4.0, designed for the precision cutting of rod material – tubes and hollow profiles made of steel and stainless steel Saw blade dimensions up to a maximum of 315 mm x 2 mm to 2.5 mm, maximum cutting range 0° - 12 mm to 80 mm tubes and hollow profiles - 12 mm to 40 mm solid material - saw blades made of TCT material are normally used (TUNGSTEN CARBIDE TIPPED) - this material allows very high cutting speeds and low saw blade thicknesses, which significantly limits material loss, saw blade speeds 20 to 130 rpm - optionally available with different saw blade speeds, controlled unloading unit for four different unloading positions - largest automatically unloadable sectio ...

Doka Alu Framax 127 m2 Good condition of frame and formwork skin (partly new Finply formwork skin or used X-Life formwork skin) Due to its lower weight, the aluminium frame formwork is suitable for shelling with and without a crane. Also seamless in combination with Framax steel formwork suitable. Lightweight and versatile due to sturdy profile frame made of aluminium Reduced workload when shelling by hand due to low element weight, with a high load capacity of 60 kN/m² can be implemented by hand or by crane thanks to frames made of torsion-resistant aluminium hollow sections Division into crane and hand formwork areas 20 x Element 0,90x2,70m 20 x Element 0,75x2,70m 14 x Element 0,60x2,70m 6 x Element 0,45x2,70m 6 x Element 0,30x2,70m 2 x Outer corner 2,70m 2 x Inner corner 2,70m Partial quantities are also possible! Doka Alu Framax 127 m2 Good condition ...

Kistler 2151B30154002 Electromechanical NC joining module List price 19.000 € net The NC joining modules NCFH Type 2151B... consist of a robust housing in which a displacement sensor as absolute encoder and a piezoelectric push-pull force sensor are integrated. The compressive or tensile forces acting on the sensor generate a proportional electrical charge in the piezoelectric measuring element, which is converted into an analog voltage signal by the integrated charge amplifier. The drive motor is an electronically commutated AC hollow servo shaft motor controlled by a servo drive. Constant speed, i.e. constant travel speed, is ensured. Standard functions such as joining on block, position and force-controlled joining as well as processes on intermediate positions are supported. Specifications: with hollow shaft motor and compact design Integrated piezoelectric force sen ...

CEMENT PLANT BATCHING PLANT CONC. BATCH PLANT 210M3/HR-200KW BP210CMPH (Type I Portland Cement shall be used) Make: Hosan Engineering Co.,Ltd.Edit Make Model: HSBP-210MS Cement Plant control panel Silo tank- 2 units compressor water tank - 2 units Cement mixer Crusher plant Crusher 1 conveyor - 3 units crusher w/ wheels control panel Crusher 2 conveyor - 4 units crusher w/ wheels Control panel Concrete Hollow Block Plant Maker: Harex Eng’g Co. Ltd. Model: H212 mixer conveyor - 2 units Hollow block molder/press control panel Capacity: 210 m/ Hr Make: Hosan Engineering Co.,Ltd. Model: HSBP-210MS Capacity: 210 m/ Hr

ROTOX SZK 502 double head welding machine was manufactured in Germany in 2007. The machine designed to weld two 90° angle joints in one working cycle, achieves high process stability and optimum temperature of the welding plates and stop blades made of hardened stainless steel. Hollow PVC bar sections with a maximum length of 2550 mm are welded on a stable structure by two welding heads made of high-quality cast aluminium. The ROTOX double head welding machine weighs 550 kg. Technical specifications of ROTOX welding machine SZK 502 - machined parts: hollow PVC bar sections - maximum section length: 2550 mm - minimum section length: 440 mm - maximum section height: 160 mm - minimum section height: 30 mm - welding angle: 90° - welding stitch limitation: 2 mm - workpiece tensioning: pneumatic - screw spanner with hexagon socket 3 mm - jaw spanner 10/13 mm - control cabinet s ...

Gear, stin gear -Drive shaft: Ø 25 mm hollow shaft -Hollow shaft: Ø 24 mm -Dimensions: 220/190/H185 mm -Weight: 14 kg -Translation: 1:20

GeneralTurn- mill machining centre; Control: Siemens sl Operate3G without ShopTurn appr 2 channel Tool magazineNumber of tools38 Max. tool length250 mmMax. tool diameter70 mmMax. tool weight3 KgB-axis Turning-milling spindleSwivelling range+/- 120 degreeSpeed range B3100 rpmAngular value, min.1 degreeTurning-milling spindleSpindle taperCapto C5 Drive power (100% DC)5,5 kWSpindle speed-20000 rpmDrive power (40% DC)7,5 kWTorque (100% DC)22 NmTorque (40% DC)30 Nmangular value, min.5 degreelocking moment700 NmB-axis counter spindlePositioning angle B3-axis, in 5 degree steps0 - 225 degreeSpeed range B340 rpmSlide 3Longitudinal stroke665 mmRapid traverse Z36 m/minSlide 1Longitudinal stroke454 mmTransverse stroke380 mmRapid traverse in X40 m/minY axis, vertical+/- 105 mmRapid traverse in Z50 m/minRapid traverse in Y40 m/minHeadstock, rightClamping chuck Ø140 mmSpindle bore38 mmSpindle diametr ...

Stationary block machine SUMAB R-500 – automatic control model (with automatic operation equipment, including PLC, sensors, hydraulic valve's switching from manual to electrically operated). Working pallet dimension: 1400 x 700 mm. Useful area Max.: 1250 x 650 mm. With stationary block making machine Sumab R-500 following concrete products are produced on efficient way: hollow blocks, insulated blocks, paving stones, curbstones and others. Production capacity in 8 h/100%: Hollow blocks: 12960 pieces (20x20x40 cm) Paving stone: 864-1016 m2 (10x20x6 cm) For more information, please send a request.

Working width: 530 mm; Planing shaft: tersa; Number of knives: 4; dressing table length: 2900 mm; Dressing table adjustment: lever; Hollow and pointed joint adjustment: no; Display Spahnabnahme: Scala; Hollow and pointed joint display: -; Dressing stop angle adjustable: yes; Motor power: 5.5 kW; Machine length: 2900 mm; Machine width: 1000mm; Weight: 810 kg; made in Italy

CharacteristicsSwing- Ø, max.450 mmWeight approx.10000 KgDrive power milling spindle9,5/5,5 kWDrive power main spindle15/11 kWDrive power second spindle15/11 kWNumber of Toolmagazine positions38 Speed max.12000 rpmSlewability of B-Axis+/-120 degreeMovements X / Z / Y455/800/+-105 mmMilling spindle upper side1 Input precision of C-axis on Counterspindle0,001 degreeSpindle speed 2nd Spindle max.6000 rpmInput precision of C-axis on Mainspindle0,001 degreeBar diametre52 mmSpeed max.6000 rpmMax. Turning Length800 mmMax machining diameter430 mmDimensions (L x W x H)4,17 x 2,5 x 2,5 (4,55 x 2,5 x 2,5) mGeneralTurning-milling centre SZM: Tool spindle, Spindle 1, Spindle 2 and Turret 2 (Milling); Control: CELOS - ERGOline Spindle 1 hobbing functionSpindle 1 hobbing function Gear machining or spline machining is possible by synchronizing the rotary tool spindle rotation on turret 1 with the spind ...

SUMAB R-500 MAX Fully automatic block line with concrete batching plant. Block line is in stock and ready for delivery! Technical details: • Automatic control model (with automatic operation equipment, including PLC, sensors, hydraulic valve's switching from manual to electrically operated) • Working pallet dimension: 1400 x 700 mm. • Operation area Max.: 1300 x 650 mm. With the SUMAB R-500 stationary block machine, the following concrete products can be produced in an efficient way: hollow blocks, insulated blocks, paving stones, curb stones and others. Production capacity in 8 h/100%: Hollow blocks: 12960 pieces (20x20x40 cm) Paving stone: 864-1016 m2 (10x20x6 cm)

GeneralTwo spindle turning centre with - partial hollow clamping device for main spindle and counter spindle internal diameter of draw tube Ø67 mm (2.63 in) x 700 mm (27.55 in) deep - 2 C-axes and spindle brakes (hydr.) - 2 12 fold Sauter star turrets reception VDI 40, DIN 69880-40 with precision interface (Trifix) and tool drive connection/drive acc. DIN 5480 - Y-axis, slide I - Counter spindle slide with NC-cross stroke and tailstock; Control: CELOS with Siemens 840D sl Operate Headstock, leftClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle diametre on front bearing130 mmSpindle bore87 mmDrive power (100% DC)25 kWTorque (100% DC)280 NmC-Axis Speed2000 rpmSpeed range0-5000 rpmHeadstock, rightClamping chuck Ø315 mmSpindle bore87 mmSpindle nose diameter170h5 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWC-Axis Speed2000 rpmTorque (100% DC)280 NmS ...

Key data: 870 mm, 3000 mm, 500 1/min

Stock number: 3861 CNC LATHE Manufacturer: GEMINIS , Type: CNC 5 870 - 3000 Machine NO.: 5852, Year of manufacture: 1996 Specifications: Max. circulation diameter 870 mm dia. Turning length 3000 mm Turning over paddling slide 560 mm dia. Main spindle speed range 40-500 rpm Spindle bore 300 mm dia. Tool turret with 8 stations Total power 47 kW Control Siemens 840C Fabr. Accessories: Chuck Main Spindle SMW BB-630-325 Hollow Air Chuck mm dia Lining Rear SMW BB-630-325 Hollow Air Chuck mm Chip conveying. Tailstock Length: 6000 mm, Height: 2000 mm, Width: 2500 mm, Weight: 7000 kg

SPINNER TTC 300- 52 SMMCY CNC Lathe YOM 2012 Twin-opposed-spindle, twin-turret lathe Control FANUC 31iT Swing diameter 400 mm Max. turning dia ~200-250 mm Max. turning length 400 mm Travels: X1 180 mm, X2 110 mm, Z 450 mm, Y +40/-40 mm Rapid traverse: X1 15 m/min, X2 15 m/min, Z 24 m/min, Y 15 m/min With C-axis Main Spindle 1: Motor spindle with water cooling With hollow shaft measuring system for C-axis drive mounted directly on the spindle shaft Spindle bore 52 mm Spindle speed 0-5000 rpm/ 19 kW Performance Pmax 23,5 kW Torque 150 Nm Spindle nose A6/DIN Sub-Spindle 2: Motor spindle with water cooling With hollow shaft measuring system for C-axis drive mounted directly on the spindle shaft Can be moved on a slide to take over spindle 1 Spindle speed 0-7000 rpm/ 8 kW Performance Pmax 13,8 kW Torque 189 Nm Spindle nose 100 mm Turret 1: At the top of the ...

Angular gears, gearboxes VOGEL MH 23 ( MH23 ) i = 1,0 A. - No.: R 5454 001 Hollow shaft diameter ( drive ): Ø 28 mm Shaft length: 65 mm Groove width: 8 mm Flange diameter (drive): Ø 130 / 200 mm bolt circle diameter: Ø 165 mm hole diameter: Ø 10,5 mm Hollow shaft diameter ( output ): Ø 32 mm Wavelength: 174 mm groove width: 10 mm all hole spacing (housing): 110 mm all threaded holes: M10 x 1.5, Depth: 25 mm used, checked ! Dimensions: 290 x 200 x 200 mm
