heavy lathe used for sale

Main characteristics: faceplate diameter - 2800 mm, The diameter of the installed product is 3200 mm, Workpiece weight - 16000 kg., The height of the installed product above the faceplate - 1600 mm, Machine weight - 43,000 kg.

Manufacturer Tacchi Model FTC56 Year 1989 capacity 7000 x 1600 mm

Date of overhaul: 2006 Swing over bed: 4000 mm Distance between lathe tips: 30 000 mm Speed: 0,5-80 rpm Workpiece weight:160 t Control system: CNC SIEMENS SINUMERIK 840 D

Length between centers: 10000 mm Weight of workpiece: 25000 kg cutting diameter over bed: 1250 mm; cutting diameter over carriage: 900 mm Limits of rotary speed: 1,6-200 rpm Dimensions: 12200 2400 2070 mm; Power: 90 kwt; Weight: 41 730 kg.

SU 125/3000 Swing over the bed 1250 mm Circular diameter above the 940 mm Tip distance 3000 mm Diameter of clamping plate 1250 mm Maximum workload of the workpiece 6000 kg Machine weight approx. 10,000 kg Delivery items of the accessories : - facing head 710 - 3-jaw chuck 630 - steady rests

Manufacturer UNIVERSAL LATHE POTISJE EXCELLENT CONDITION, USED ONLY FOR SUPERFINISH AFTER GRINDING Model PA-45 Year Condition used Location Slovenia Price 26.500,00 € Category Lathe Subcategories Stock Number Serial Number Max turning lenght 3000mm Turning over bed 600 mm, Spindle bore 140 mm, Turning in cranking 1.200 mm Face plate 800 mm

height of tips 400 length 7 m passage bar 105 YEAR 2001

Distance between lathe tips: 25 000 mm Swing over bed: 1800mm Speed: 0,45-91 rpm Workpiece weight: 70t Control system: CNC SIEMENS Sinumerik 840 Main motor power: 80 kW

Distance between centers 4000 mm Tip height 700 mm Bar passage 150 mm Internal grinding unit Set of bezels Tailstock Turning wagon

Turning diameter: 1200 mm Center distance: 6500 mm Spindle bore: 150 mm Numbers of bed guide ways: 3 Weight between centres maximum: 7000 kg CNC Brand: Siemens CNC latheRavensburg - KV1 - 700 CNC  Work load flying in chuck 2500 Kg Work load supported 10000 Kg 4 Chuck 1000 mm with heavy jaws Clamping inside 200-1120 mm  Clam;ping outside 80-1000 mm  C-Steady rest 100-450 mm x 7000 Kg C-Steady rest 400-600 mmx 7000 kg Sauter 6 position revolver Swing over bed Ø:        1200mm Swing over cross slide Ø:700mm DBC Turning Length:      6500mm Spindle bore:            150mm Spindle power:           80kW Tailstock spindle Ø:     200Ø Stroke pinole:           200mm Spindle taper:        &nbs ...

The machine is in good technical condition, after prior agreement it is possible to test it. Circulating diameter above bed 800 mm Distance between spikes 4000 mm Circulating diameter above support 520 mm Machine weight 6400 kg

Echea A-II-6000 lathe. Distance between centers: 6.000mm. Swing: 820mm. Swing in carriage: 600mm. Swing in gap: 1.140mm. Bed widht: 510mm. Spindle: 82mm. Speeds: 12. (12-850rpm). Motor power: 25cv. Max. weight with 1 steady rest: 7.700Kg. Equipped with chuck and 2 steady rest. Weight: 9.600Kg.

Turning diameter: 1600 mm Center distance: 12000 mm Spindle bore: 120 mm Numbers of bed guide ways: 2 Weight between centres maximum: 20000 kg CNC Brand: Siemens CNC Model: SIEMENS 840D in 2009 retrofitted: New Rittal E-Cabinet New wire & measuring scales New Servo engine New 840D controller New Hydraulics Swing over bed Ø:        1600mm Swing over cross slide Ø:1250mm DBC Turning Length:      12000mm Spindle bore:            120mm Spindle power:           75kW Bed width:               2400mm Speeds / ranges:         224Rpm Feed rate X-Axis:        2500mm/min. Feed rate Z-Axis:        2500mm/min. Length:                & ...

Turning diameter: 2100 mm Center distance: 14500 mm Spindle bore: 150 mm Numbers of bed guide ways: 1 Weight between centres maximum: 100 kg CNC Brand: Siemens CNC Model: Siemens 840 Max. turning Ø:2100mm X-Axis:        14500mm Z-Axis:        1600mm Speedrange:    180Rpm Spindle power: 150kW Length:        22000mm Width:         4500mm Height:        3800mm Weight:        193000kg

Turning diameter: 3000 mm Center distance: 14500 mm Spindle bore: 560 mm Numbers of bed guide ways: 1 Weight between centres maximum: 100000 kg CNC Brand: Siemens CNC Model: Siemens 840 Max. turning Ø:3000mm X-Axis:        14500mm Speedrange:    180Rpm Spindle power: 2 x 75kW Quill Ø:       560mm Length:        24000mm Width:         7000mm Height:        3900mm Weight:        285000kg

Turning diameter: 1400 mm Center distance: 12000 mm Spindle bore: 105 mm Numbers of bed guide ways: 1 Weight between centres maximum: 10000 kg Centre latheGurutzpe - Super BT  Motorized tailstock Work load 10 Ton 3 x closed steady rest Feeds all directions Chip conveyor DBC Turning Length:      12000mm Swing over bed Ø:        1400mm Swing over cross slide Ø:1060mm Spindle bore:            105mm Spindle power:           50kW Bed width:               600mm Tailstock spindle Ø:     130Ø Stroke pinole:           300mm Spindle taper:           6Mk Speeds / ranges:         400Rpm Length:            &nbs ...

Turning diameter: 1550 mm Center distance: 12500 mm Spindle bore: 100 mm Numbers of bed guide ways: 2 Weight between centres maximum: 22000 kg CNC Brand: Siemens CNC Model: SIEMENS 840D Full C-Axis 360.000 Positions Revolver 12 positions with live tools Live tools 22 kW ans 2250 Rpm Capto C6 tool system C-Steady rest 100 -   500  C-Steady rest 500 - 1000 Package tool holders radial and axial Swing over bed Ø:        1550mm Swing over cross slide Ø:1260mm DBC Turning Length:      12500 (15000)mm Workpiece weight:        22000 Power:                   100A Speeds / ranges:         0,05 - 600Rpm Feed rate X-Axis:        6000mm/min. Feed rate Z-Axis:        6000mm/min. Length: ...

milling device for Skoda lathe SUT160

Turning diameter: 1600 mm Center distance: 10000 mm Spindle bore: 110 mm Numbers of bed guide ways: 2 Weight between centres maximum: 30000 kg CNC Brand: Siemens CNC latheGurutzpe - GLX 16.15.7  4 bed way construction Bed width 1350 mm Chip conveyor 4 chuck 1250 mm Filtration / Coolant system 2 x C-Type steady rest Motorized tailstock Max. turning Ø:1600mm Spindle bore:  110mm Speedrange:    800Rpm Spindle power: 71kW ATC / revolver:4 Chip conveyor: Yes Pinole taper:  6Mk Quill Ø:       220mm Length:        12000mm Width:         4000mm Height:        3200mm Weight:        35000kg

turning diameter over bed: 1000 mm turning diameter over slide rest: 710 mm turning length: 7000 mm max. workpiece weight between centres: 10000 kg spindle turning speed range: 1,8-400 U/min tailstock quill taper metric: 80/1:10 tailstock - quill dia: 170 mm tailstock - travel of quill: 200 mm Tailstock quill travel speed: 2150 mm/min main drive motor: 37 kW longitudinal feeds:: 0,125-48 mm/U face feeds: 0,4 der Längsvorschübe weight of the machine ca.: 17 t dimensions of the machine ca.: 11x1,9x2 m machine was mechanically and electrically overhauled in the last years. - taper turning function - 3 lynettes - misc. center points for tailstock - set of change gears The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Max. working diameter: 630mm Distance between tines: 3500mm 5 lunettes fixed and movable.

The machine is in good technical condition. Circulating diameter above the bed: 630mm Distance between points: 4000mm Accessories: chucks, lunettes weight: 3,500 kg Upon prior arrangement, the possibility of inspection while in operation. Year of manufacture/SO/GO: 1979/-/1993

Screw-cutting lathe 1a667, good technical condition, low wear, 100% set.

The massive, one-piece bed is made of high quality Meehanite cast iron. The bed is equipped with an additional guide to ensure greater rigidity, the total width between the guides is 800 mm. The caliper is also equipped with an additional guide for heavy cutting applications. The guides are hardened, carefully ground and coated with Turchite B.

Ref. -No.: 10154 Manufacturer: HEYLIGENSTAEDT Year of construction: 2014 Retrofit: 2015 Type of control: CNC Control: SINUMERIK 840D solution line Storage location: Halberstadt Country of origin: Deutschland Bed width: 2000 mm Feed rate: 1-5000 mm / min Turning Diameter: 2600 mm Turning Length: 10000 mm Centre Distance: 11500 mm Faceplate Diameter: 2000 mm Spindle Speeds: 0,5 - 36 min-1/20 - 140 min-1 RPM Max. Torque: 120 Nm Max. Workpiece Weight: 40000 - 70000 kg Total Power Requirement: 230 kW Cross slide shift (X-axis): 640 mm Further information:

Vertical lathe 1580L The lathe 1580L is designed for turning and boring cylindrical, conical surfaces, as well as for turning ends. On the lathe 1580L, it is possible to drill, ream and ream central holes. The 1580L two-column vertical lathe is used in many industries in enterprises that require the processing of heavy, large-sized workpieces. The largest diameter of the workpiece is 8000mm. Processing height 3200mm, 2 calipers. Weight - 260 tons. Total power - 439.89kW 220\380V. Dimensions: 7600x8615x8315. The machine is equipped with electric motors with a total capacity of 459.22 kW. Electric motors 34pcs.

Machine dimensions 15000x4000 mm Bed width 4300 mm Bed height 800 mm Machine weight 300000 Kg Max. load of a machining part fixed between centers without steady rests 150000 Kg Max. load of a machining part fixed between face plate and steady rests 300000 Kg Max. machining diameter 3700 mm Min. machining diameter 300 mm Face plate diameter 2700 mm Max. machining part length 15000 mm Distance between quill and bed guideways 1900 mm Face plate speed range (on 4 steps) 0.315-100 rpm Max. rotation face plate torque 30000 daNm Max. torque to stress between jaws for max. load of 150000 Kg 70000 daNm Turning support (4 tool holders) : Max. turning force 30000 daN Cross travel (ball screw) 1400 mm Cutting blade max. length 1020 mm Working feed range (longit. and tr ...

Romanian lathe type SNA x 3000 mm, man. 1980 the machine is overhauled. The lathe is fully functional. It has a new electrical system and new position readings. It is equipped with: a ruler for turning cones, a lathe chuck fi 315, left and right jaws, LED lighting, cooling system, DTR. Technical data: - turning diameter over the bed [mm]: - 800 - turning diameter over the slide [mm]: - 392 - spindle bore diameter [mm]: - 82 - engine power [kW]: - 18.5 - overall dimensions [mm]: - length: - 5325 - width: - 1510 - height: - 1560 - weight of the machine tool [kG]: about - 5500

Max. machining part length 15000 mm Max. diameter over bed 3700 mm Max. diameter over turning support 3000 mm Distance between centers axis and bed guideways 1940 mm Max. load of machining part fixed between centers 150000 Kg Max. load of machining part fixed in face plate : on first step of clamping jaw 75000 Kg on second step of clamping jaw 50000 Kg Max. load of machining part fixed in face plate and steady rest: 150000 Kg on first step of clamping jaw 155000 Kg on second step of clamping jaw 130000 Kg Face plate diameter 3050 mm Clamping diameter on first step of clamping jaw without extension 400 - 1700 mm with extension 260 - 400 mm Clamping diameter on second step of clamping jaw 1200-2500 mm Clamping force of one hydraulic clamping jaw 35000 daN Power of main drive motor 125 Kw Face plate speed range (on 4 steps) 0.5 - 120 rpm Max. main shaft torque (for 5.6  ...

Machine dimensions 15000x4000 mm Bed width 4300 mm Bed height 800 mm Machine weight 300000 Kg Max. load of a machining part fixed between centers without steady rests 150000 Kg Max. load of a machining part fixed between face plate and steady rests 300000 Kg Max. machining diameter 3700 mm Min. machining diameter 300 mm Face plate diameter 2700 mm Max. machining part length 15000 mm Distance between quill and bed guideways 1900 mm Face plate speed range (on 4 steps) 0.315-100 rpm Max. rotation face plate torque 30000 daNm Max. torque to stress between jaws for max. load of 150000 Kg 70000 daNm Turning support (4 tool holders) : Max. turning force 30000 daN Cross travel (ball screw) 1400 mm Cutting blade max. length 1020 mm Working feed range (longit. and transv.) 0.1-4000 mm/min Rapid feed range (longit. and transv.) 5000 mm/min Tool holder dimensions 120x60x35 mm Ta ...

Gate Precision lathe G-1120-HD x 3000 Y.O.M. 2013 Almost not used! New price with this options € 150.000,- euro. . Spindle bore 255 mm! Two chucks 630mm. Now available, price €35.000,- ex VAT. See photo's, under power too check.

turning diameter over bed: 1800 mm turning diameter over slide rest: 1200 mm turning length: 16000 mm turning dia. in gap: 2300 mm spindle diameter: 150 mm speed: 1 - 300 U/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Machine is fully functional and has its own cooling and a Heidenhain digital has a three-jaw chuck and a clamping width of 450mm is 3 meters long and 3 tons heavy you can clamp through the jaw chuck so longer workpieces are no problem it has a rotary heart and various cornel and jaws to exchange machine is in a very good condition and machine manuals are included

Point lathe SN 55 / 4000 in good technical condition, including lunette. Total machine input:: 7.5 kW Circulating diameter above the bed: 550 mm Revolving diameter above support: 310 mm Distance between spikes: 4000 mm Spindle drilling: 71 mm Spindle speed - range: 90-1000 Working feed - number of steps: 16 Working feed - range: 38 mm/min

Maximum turning length 5000 mm turning diameter above bed (max) 1000 mm turning diameter above support (max) 710 mm workpiece weight between centers (max) 10 t spindle power 37 kW lathe length 8605 mm lathe width 1920 mm lathe weight 15.2 t Currently disconnected.

Description: Machine number 3317 Including 2 steady rests, tailstock, faceplate diameter 1000 mm Drehlänge: 9,500 mm, turning diameter over bed: 1,500 mm, turning diameter over slide: 1,100 mm, spindle bore: 90 mm, weight approx.: 20,000 kg, Approx. Onsite Dimension. (l x w x h): 18,500 x 3,000 x 1,900 mm

Description: Including faceplate, diameter 1600 mm, tailstock and steady rest , Machine number 3907 Drehlänge: 6,500 mm, turning diameter over bed: 2,400 mm, turning diameter over slide: 2,000 mm, spindle bore: 80 mm, control: SIEMENS SINUMERIK, weight approx.: 15,000 kg, Approx. Onsite Dimension. (l x w x h): 11,000 x 2,450 x 2,750 mm

turning diameter over bed:1630 mm turning diameter over slide rest:1190 mm turning length:5000 mm centre height:800 mm swing in gap:2100 mm bed width:1000 mm max. workpiece weight:12000 (zw. Spitzen) kg number of spindle speeds:16 4 - 242 U/min spindle bore:120 mm tailstock quill diameter:180 mm tailstock quill stroke:350 mm Weight approx.:22 t total power requirement:ca. 25 kw Height of centres: 1350 mm Distance between centres: 5000 mm Swing over cross slide: 2600 mm Spindle power: 30 HP Spindle speed: 0,7 - 70 rpm Longitudinal swift Control on the carriage Chuck: diam. 2050 mm

turning diameter over bed:2600 mm turning diameter over slide rest:2200 mm turning length:5000 mm faceplate:2050 mm number of spindle speeds:0,7 - 70 rpm total power requirement:ca. 22 kw Height of centres: 1350 mm Distance between centres: 5000 mm Swing over cross slide: 2600 mm Spindle power: 30 HP Spindle speed: 0,7 - 70 rpm Longitudinal swift Control on the carriage Chuck: diam. 2050 mm

turning diameter over bed:850 mm turning diameter over slide rest:510 mm turning length:3000 mm travel of cross-slide cross:600 mm movement of the upper support:250 mm bed width:600 (Monoblock) mm spindle bore:100 mm spindle nose:DIN 55029 Größe11 spindle taper:Ø120mm/Konus 1:20 spindle speeds:5~630 1/min metric threading:56,1~120 mm feeds - longitudinal:0,08~9,6 mm/min feeds - cross:0.04~4,8 mm/min rapid traverse longitudinal and cross:3640/1800 mm/min tailstock quill diameter:120 mm tailstock quill stroke:250 mm taper in tailstock:6 MK main drive motor:15 kW max. workpiece weight between centers:4000 kg Weight approx.:6800 kg machine width/height:1500x1500 mm machine length:5150 mm 4-jaw independent chuck:800 mm steady fixed:Ø40~350 (mit Rolleneinsätzen) mm fixed steady:Ø100~520 (mit Rolleneinsätzen) mm follower rest:Ø30~120 mm multifix tool holder:Größe C Factory new heavy  ...

:SDM-1480Z | SDM-1680Z | SDM-1980Z | SDM-2080Z turning diameter over bed:1480|1680|1980|2080 mm turning diameter over slide rest:1000|1200|1500|1600 mm turning length:2000/3000/4000/5000/6000/8000/10000/12000 mm bed width:1100 mm workpiece weight:12 (15 opt.) t spindle bore:130 mm spindle taper:140 spindle speed (3 steps):2,5-250 U/min metrical thread cutting:1~120 (44 Arten) mm longitudinal feeds:0.1 ~ 12 (56 Arten) mm/U face feeds:0.05 ~ 6 (56 Arten) mm/U rapid traverse longitudinal:3400 mm/min rapid traverse cross:1700 mm/min cross way of carriage:760 mm movement of the upper support:300 mm tool size:45 x 45 mm tailstock quill diameter:260 mm stroke:300 mm tailstock-quill conus:80 metrisch spindle motor:30 (50 opt.) kW tool holder:4-fach steady diameter:500-800 mm CNC controls from:Siemens/Fanuc/Fagor payment: 100 % before loading warranty:12 months on parts only BRANDNEW conventiona ...

:SDM 1000E | SDM 1250E | SDM 1400E turning diameter over bed:1000|1250|1400 mm turning diameter over slide rest:650|900|1100 mm turning length:2000/3000/4000/5000/6000/8000/10000/12000 mm max. workpiece weight between centers:8000 kg bed width:755 mm spindle nose:A2-15 spindle bore:130 mm spindle speed (3 steps):3,15-315 U/min metrical thread cutting:1~120 (56 Arten) mm cross way of carriage:520|680|720 mm movement of the upper support:300|300|400 mm tool size:45 x 45 mm tailstock quill diameter:180 mm stroke:300 mm tailstock-quill conus:6 MK weight of the machine ca.:bei 3m: 12 t (jeder weitere Meter ca. 800kg) Machine size (LxWxH):bei 3m: 6100x1900x2000 mm tool holder:4-fach follower rest:50-220 mm 4 jaw chuck:1000 mm steady diameter:50-470 mm CNC controls from:Siemens/Fanuc/Fagor payment: 100 % before loading warranty:12 months on parts only BRANDNEW conventional heavy duty center la ...

:KHL-160 | KHL-180 | KHL-200 | KHL-220 turning diameter over bed:1600|1800|2000|2200 mm turning diameter over slide rest:1250|1450|1650|1850 mm turning length:3000/4000/5000/6000/8000/10000/12000/14000/16000 mm bed width:1600/2100 mm workpiece weight:32t (40t,64t, 80t Option) spindle bore:85 mm spindle taper:120mm taper 1:7 number of spindle speeds:0.86-160 U/min metrical thread cutting:2-40 mm range of module thread:1.5-20 mm longitudinal feed:0.125-4.8 mm :0.063-2.4 mm movement of the upper support:quer: 700mm/900mm movement of the upper support:längs: 600 mm turning tool - shaft cross cut:70x70 diameter tailstock quill:300/500 mm taper of tailstock:100 taper 1:7 quill stroke:300 mm steady rest close/open:400-750/650-1200 mm main drive motor:80/110 kW 4 jaw chuck diameter:1000 - 1600 mm steady rest diameter:400 - 750 mm open steady:650-1200 mm CNC controls from:Siemens/Fanuc/Fagor

Modell:SDM 630 | SDM 800 | SDM 1000 | SDM 1200 turning diameter over bed:630 | 800 | 1000 | 1200 mm turning diameter over slide rest:345|480|680|880 mm turning length:1000,2000,3000,4000,5000,6000,7000,8000~12000 mm travel of cross-slide cross:370|420|520|620 mm movement of the upper support:200 mm bed width:600 (Monoblock) mm spindle bore:105mm (130 oder 155 opt.) mm spindle nose:DIN 55029 Größe11 oder DIN 55027 Größe 11 spindle taper:Ø120mm/Konus 1:20 spindle speeds:7.5~1000|5,5~730|5,5~730|5,5~730 1/min metric threading:1~240 mm feeds - longitudinal:0.1~24,3 mm/min feeds - cross:0.05~12,5 mm/min rapid traverse longitudinal and cross:4000, 2000 mm/min turning tool - shaft cross cut:32 x 32 mm tailstock quill diameter:100 mm tailstock quill stroke:240 mm taper in tailstock:6 MK main drive motor:11 (15 kw opt.) kW max. workpiece weight between centers:3000 kg Weight approx.:4t bei  ...

Modell:5-800 | 5-1000 | 5-1200 | 5-1400 turning diameter over bed:800|1000|1200|1400 mm turning diameter over slide rest:510|710|910|1110 mm turning length:3000~12000 mm Distance between centres:3000~12000 mm centre height:500 mm bed width:900 (opt. 1200) mm spindle bore:155 (A2-11) mm spindle turning speed range:6-800 U/min spindle speed steps:variabel innerhalb der Stufe, 4 Stück tailstock quill taper MT:6 MK diameter of quill:165 mm quill travel:250 mm space requirements approx. LxWxH:10.800x2.200x1925 (8m Spitzenweite) mm machine weight:18200 (8m Spitzenweite) kg spindle drive:30 kW tool holder:manuell schwenkbarer 4-Fach Stahlhalter für Stahlhalterquerschnitte 32x32mm thread chasing dial:keine fixed steady:feststehende Lünette, Durchmesser 60 bis 290mm

:SDM-1460 | SDM-1660 | SDM-1860 | SDM-2060 turning diameter over bed:1460 | 1660 | 1860 | 2060 mm turning diameter over slide rest:960 | 1160 | 1360 | 1560 mm turning length:2000/3000/4000/5000/6000/8000/10000/12000 mm bed width:1180 mm workpiece weight:20 t spindle bore:105 mm spindle taper:140 spindle speed:3-200 1/min, 4 stufig metrical thread cutting:1~60 mm longitudinal feeds:0.1~6 mm/U face feeds:0.05~3 mm/U rapid traverse longitudinal:3400 mm/min rapid traverse cross:1700 mm/min cross way of carriage:750 | 850 | 950 | 1050 mm movement of the upper support:280 mm tool size:45 x 45 mm tailstock quill diameter:280 mm stroke:300 mm tailstock-quill conus:100; 1:7 metrisch spindle motor:55 kW tool holder:4-fach steady diameter:250-600 mm CNC controls from:Siemens/Fanuc/Fagor payment: 100 % before loading warranty:12 months on parts only BRANDNEW conventional heavy duty center lathe

Modell:SDM 850 Varia | SDM 1000 Varia turning diameter over bed:850|1000 mm turning diameter over slide rest:520|720 mm centre distance:2000/3000/4000/5000/6000 mm :1150|1350 mm :350 mm travel of cross-slide cross:600 mm movement of the upper support:250 mm bed width:600 (Monoblock) mm spindle bore:100 mm spindle nose:DIN 55029 Größe11 spindle taper:Ø120mm/Konus 1:20 spindle speeds:5~630 1/min tool holder -shaft diameter:45 mm :90° feeds - longitudinal:0,08~9,6 mm/min feeds - cross:0,04~4,8 mm/min rapid traverse longitudinal and cross:3640/1800 mm/min :900 mm/min metric threading:56, 1~120 mm tailstock quill diameter:120 mm tailstock quill stroke:250 mm taper in tailstock:6 MK main drive motor:15|18,5 kW :16,8|20,3 Kva max. workpiece weight between centers:4000 kg Weight approx.:7200 kg machine width/height:1600x1600 mm machine length:6150 mm (4000 mmSpitzenweite) 4-jaw independent c ...

screw-cutting lathe model 1M65 (RMTs 5000 mm) - Ryazan Machine-Tool Plant. Equipment after a major overhaul with modernization of the electrical and mechanical parts of the machine (a frequency converter is installed, the speed box of the machine is modernized (2-stage), the speed is controlled by a joystick) Specifications: Model 1m65 machines are designed for a variety of turning operations, including turning cones and threading: metric, inch, modular, pitch The largest diameter of the workpiece to be installed and processed, mm: over support, mm 650 over the groove in the bed, mm 1400 The biggest length of the workpiece to be processed, mm 5000, The length of the groove in the bed from the cartridge mirror, mm 390 Headstock spindle end size according to DIN 2-15M Number of spindle speed steps 24 Diameter of the cylindrical bore in the spindle, mm 128 Spindle speed limits,  ...

Description Waldrich Siegen CNC lathe for heavy machining Details Conversion to CNC 2006 Center distance 22,000 mm Maximum turning length Support 1: 20,000 mm Maximum turning length Support 2: 20,500 mm Largest turning diameter over support 1,600 mm Largest turning diameter above bed 2,000 mm Workpiece weight max. 70,000 kg Face plate diameter 2,000 mm Face plate speed, infinitely variable in 4 steps 1.2 - 75 rpm. Maximum torque at speed 5.65: 170,000 Nm Main motor 110 kW Largest clamping diameter on headstock ⌀ 920 mm Mounting in roller block (passable) 2 pieces 600 - 1290 mm Mounting in bezels (passable) 100 - 775 mm Control system Siemens SINUMERIK 840D Support 1 and 2 (to headstock) Displacement of the upper support 550 mm Displacement of the slider 400 mm Quick longitudinal adjustment (rapid traverse) 3,000 mm/min Q ...

Overhauled Poreba 1100 mm x 4000 mm heavy duty lathe Diameter 1100 mm Distance between centers 4000 mm
