headstock used for sale

Universal tool milling machine make DECKEL type FP 1Mash. -No: 54833/08Longitudinal movement of the table X: 250/245 mmTransverse movement of the headstock Y: 150 mmVertical movement of the table Z: 340/335 mmSpindle mount: MK 412 Hor.-speeds: 60 - 1200 U / min12 Vert.-speeds: 95 x 1900 rpmvertical table slide: 550 x 195 mmQuill stroke of the vertical milling head: 60 mm12 feeds longitudinal and vertical: 9.5 x 475 mm / minDrive power: 1.2 kWDimensions: 700 x 1000 x 1600 mmWeight approx: 560 kgWith- rigid angle table- several tool holders- original vice- separate electrical cabinetused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

Universal CNC lathe BOEHRINGER NG 200 Manufacturer: BOEHRINGER Type [ type]: NG200 CNC double Control unit: Siemens 840D Year of construction[construction year]: 10/2001 Rotating diameter: 290 mm Turning length: 850 mm Control: SIEMENS 840 D Orbital diameter over bed: 600 mm Revolver 1 Revolver 2 Counter spindle Counter headstock Tailstock C-axis Powered tools Automatic machine doors – newly retrofitted Z-axis resolution: 40nm (2nm interpolated) Travel in Z: 740mm Rapid traverse speed in Z: 25 m/min Centering tip SK 30 X-axis resolution: 125nm (8nm interpolated) Travel in Z: 220mm Rapid traverse speed in Z: 25 m/min Distance between main and counter spindle: 1034mm Drive power: 30-72 kW Torque: 662 Nm Speed range max.: 4500 rpm Spindle head: Size 6/8 DIN 55026 Spindle diameter in the front. Bearing [spindle]: 120 mm Chuck diameter: 200-315mm Spindl ...

CATALOG NO. 6901 TECHNICAL DATA - max turning length 1200mm - max turning diameter 210mm - max turning diameter with a standard 90mm steady rest - max dimension of square material for turning with automatic feeding 100mm - 3 hydraulic copiers - additional 3 knives on hydraulic pistons (2 pcs) - 4 types of spindle rotation - automatic or manual operation of the machine - headstock spindle motor 9kW - 3kW hydraulic pump motor - diameter of the exhaust connection 90mm - dimensions for transport length/width/height 3700x2100x2000mm - weight about 3000 kg ADVANTAGES – Italian production – automatic hydraulic copier – original DTR documentation – unpainted – used lathe, very good condition Net price: PLN 69900 Net price: 15032EUR Net price calculated according to the exchange rate of 4.65 PLN/EUR (with larger exchange rate fluctuations, the price may cha ...

- CC controller Siemens 840 D - Year of construction 2002 Specification - Tip width: 600 mm - Tip height: 180 mm grinding Ø: 355 mm Z-axis speed: 15 m/min - min. Z-axis speed: 0.01 m/min - Axis resolution Z-axis: 0.5 μm X-axis speed: 10 m/min - min. X-axis speed: 0.01 m/min - Axis resolution X-axis: 0.5 μm - Grinding wheel left side (Øa x w x Øi): 500 x 80 x 203 mm - Grinding wheel circumference speed: 45 m/s - Power external grinding spindle drive: 10 kW - Speed workpiece spindle: 0 - 1000 m/min - Conical bore workpiece headstock: MK5 - Conical bore tailstock grain tip: MK4 - Cylindricity adjustment: +10° / - 4° - Total connected load: 28 kW - Operating voltage: 3x 400 V / 50 Hz - Total weight of the machine: 5800 kg - Operating sound level: 70 dB(A) according to EN 31201

Ziersch & Baltrusch URS400 Ergonomy Year of construction: 1981 Tip height: 100mm Center width: 400mm Grindable length - max. table stroke: 320mm workpiece Drm: 198mm Speed workpiece headstock: 90-900rpm Speed grinding spindle: 1.800-1.970-2.173U/min Largest grinding wheels Drm: 350mm Smallest grinding wheels Drm: 250mm Width grinding wheel max: 50mm Bore grinding wheel: 127mm Dimensions: 1,5x1,3x1,65m Weight: approx. 1.6to Micrometer stop 1 revolution of the micrometer spindle: 0.2mm 1 tick mark of micrometer spindle: 0.01mm At the machine, the guides were renewed, the table was renewed and all bearings were replaced!

control: Siemens 840-D tool taper: HSK & VDI 40 - - -: - - - - - - Vertical Turning Machine EMAG - VTC 250 DUO DD with ITC (7-30 bar) and driven tools Additional equipment: - Workpiece grippers on all 3 turrets - 12-position disc turret for driven tools and VDI 40 tool holders, - 12-station disc turret with cross-slot and VDI 40 tool holders, - 12-station disc turret for driven tools and VDI 40 tool holders, - NC steady rest, self-centering, - headstock below, - tailstock below, - chip conveyor - Knoll unit 1.500 l, - OP10: Three-jaw chuck Rhöm KFD-N 220/3, - OP20: Hainbuch Spanntop pull-back BZI65, - Live tool for axial and radial machining, - Tool holder with Capto 5 quick change system, - Artis as tool and process monitoring, The machine is in a well-maintained condition and can be inspected at any time under power. A machine video from the production plant will be shared on reques ...

Manufacturer: Maier Type: ML 36 D Year of construction: 2005 Control: GE Fanuc 3li TA Drive power: 16 kw Machining diameter: 36 mm Headstock stroke max.: 220-450 mm Speed: 0-8000 rpm. Number of tool stations: 4 Machine weight: approx. 5 t

bore capacity in steel (diameter): 50 mm arm length: 350 - 1600 mm workpiece height max.: 1250 mm spindle taper MT: 5 spindle turning speed range: 25 - 2000 U/min threading:: 30 mm quill stroke: 315 mm feed range - spindle: 0,04 - 3,2 mm/U slide adjustment -horizontal: 1250 mm table-size: 625 x 500 mm column diameter: 350 mm total power requirement: 4 kW weight of the machine ca.: 3500 kg dimensions of the machine ca.: 2,5 x 1,07 x 2,84 m The Huvema radial drill range is unbeatable in price and performance, the machines are used for drilling, reaming and tapping. The drills frame is made from a high-quality fine-grain cast iron with heavy ribbing to ensure maximum reduction of vibrations. Precision ground gears ensure that the machine runs quietly, and the practical layout of the electrical and mechanical controls at the headstock make for easy operation. The machines are also fitted wit ...

Key data: 660 mm, 2000 mm, 2000 1/min

Working Area Workpiece length (max.) 78 in Turning-D over bed (max.) 26 in Turning-D over support 18 in Turning length (max.) 68 in Travels Travel X-axis 13.8 in Travel Z-axis 75 in Headstock Speed range 60 – 2,000 rpm Spindle mount A2-8 Lathe chuck diameter 12 in Spindle capacity with draw tube 3 in Rapid Feed Rapid feed X-axis 236.22 in/min Rapid feed Z-axis 314.96 in/min Tool Head Number of tool stations 8 positions Accuracies Positioning accuracy X-axis ± 0.0005 in Positioning accuracy Z-axis ± 0.0006 in Repeatability X-axis ± 0,005 in Repeatability Z-axis ± 0,008 in Tailstock Tailstock taper MT 5 Tailstock quill diameter 3 in Tailstock quill stroke 6 in Drive Capacity Motor rating main drive 24.8 Hp Main drive, continuous load 20.11 Hp Torque of drive X 7 ft.lb. Torque of drive Z 11 ft ...

Max. Machining Diameter : 20 mm Max. Headstock Stroke : 205 mm Fedek XT-320SI bar feeder Machine is in good condition Power on : 21017 Operating time : 15223 Cutting time : 12542 Bar feeder

GeneralUniversal Machining Centre in monoBLOCK construction - MPC Machine Protection Control - Chip trough; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal750 mmCross650 mmVertical560 mmTechnical DataDrive power (100% DC)25 kWDrive power (40% DC)35 kWTorque (100% DC)86 NmTorque (40% DC)130 NmSpeed range- 20000 rpmSpindle taperHSK-A 63 Clamping SystemHSK-A 63 Feed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minTool changerTool changer planevertical Type of gripperDouble gripper Number of tools120 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.12300 KgMiscellaneousClamping SystemDIN 69872 NC swivel rotary tableTable surface Ø 650 mm5. Axes (swivelling range) +/- 120 degree4. Axes (swivel ...

Grinding diameter 250 mm Grinding length 650 mm Center width 700 mm Tip height 125 mm Grinding wheel diameter 400/450 mm Grinding wheel width 50/80 mm Workpiece spindle speed up to 675 1/min Workpiece headstock swivel +/- 45 ° Dresser Measuring device Coolant system Grinding wheel

KARATS DH-30 CNC Deep Hole Borer Manufactured year 2017 Main specification ● Height from Bed sliding to center of Chuck 2,900 mm ● Swing over bed 5,800 mm ● Drilling capacity 56~650 mm dia ● Distance between center 25,500 mm ● Max. working length 24,000 mm ● Max. workpiece load capacity (with 2 Steady rest ) 380 tons ● Max. workpiece clamping dia 3,400 mm Bed ● Total length of Bed 53,850 mm ● Width of Bed 2,500 mm ● Height of Bed 700 mm Headstock ● Spindle shaft dia 800 mm ● Spindle rotating speed 160 rpm ● Chuck size 2,500 mm ● The clamping dia on Chuck 600 ~1,600 mm ( Design 480~1,680 mm ) Boring head ( A-axis) ● The feed for working 14,000 mm ● Max. feeding 25,870 mm ● Min. distance from Chuck 21,300 mm ● Max.. distance from Chuck 47,170 mm ● Rapid feeding speed 4,000 mm/min  ...

GeneralUniversal Machining Centre Vertical headstock Tool change system double gripper NC-Swivel rotary table with pallet carrier 3 pallets 500 mm x 500 mm / 19.7 in x 19.7 in T-slots according to DIN 55201-A2 linear pallet changer coolant tank 500 l / 132 gallon chip conveyor with netting band filter integrated, coolant ring jet; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmFloor space/WeightWeight approx.18300 KgDirect measuring systemDirect path measuring systemCabineFull protection cabinNC swivel rotary table with pallet carrierTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 500 KgMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000  ...

Description Very well-preserved high-performance roller lathe WALDRICH SIEGEN. Refurbished in 2012 for € 595,000.00, with R&D control and functional guarantee. Details Type WKDF 900/15 Kop. Machine number 14183 Built in 1971 Bed width 1,610 mm Bed height 670 mm Bed length 7,670 mm Headstock center height 600 mm Face plate Ø 920 mm Clamping range 200 - 630 mm Support max. copying depth with largest turning diameter 250 mm Tailstock quill adjustment 100 mm Quilles Ø 300 mm max. workpiece length 4,000 mm max. workpiece weight 15 tons Additional Accessories Copying Device incl. documentation

Schaudt & Studer Grinding Machines - Premium Overhauled [RETROFIT] - various conventional, cycle-controlled & CNC grinding machines - for various workpiece Ø - with grinding lengths from 200 to 3,000 mm - Control: Siemens Sinumerik ONE or Fanuc - Workpiece weight: according to customer requirements - The attractive alternative to the new machine - We are also happy to overhaul your machine, more information on our homepage Options: (other options also possible) - Balancing & grinding sensors - In-process measuring device for length & Ø - Dressing spindle for diaform roller - B-axis for swivelling grinding headstock - Second / Third External Loop Unit - Internal loop device - Upgrade to non-circular & thread grinding - Automatic door drive - suitable automation - Peak increase - u.v.m. on request / customer request

Loader applicable to all types of CNC lathes, with fixed or sliding head. The TS560 series automatic loaders are characterized by a very silent operation and a large capacity bar magazine. They can be connected to automatic and CNC lathes, with fixed and sliding headstock, and to any machine working the bar (transfer, cutting-off machines, presses, etc.) even with special profiles; they are particularly suitable where large quantities are required. The TS 560 P loaders are equipped with a magazine with 4 eclipsable overlapping shelves (max. Capacity 1800 mm.), L max [mm]: 3.300

SHW Uniforce 5 Travel • X-axis (bed): 5,000 mm • Z-axis (vertical): 1,000 mm • Y-axis (headstock): 1,300 mm Control • CNC control: Siemens SINUMERIK 840D Universal milling head in orthogonal design • Swivel range milling head holder: 360 x 1 degree • Swivel range milling head: 180 x 1 degree • Tool holder: HSK 100 • Speed range: 22 – 4,000 1/min Year of construction 1998 • 2022 – partial overhaul o Inspection of all components -> replacement if necessary o General overhaul milling head o Geometric acceptance takes place after New machine acceptance protocol Clip •Mounting table: Conveyor • Task length: Coolant device • Paper belt filter system • Container capacity: 800 l Automatic tool changer •Tool magazine with 90 magazine slots Reversible clamping device Rückle PKTW 2 About us: MBM Maschinenservice & G ...

Tablе stroke 500 mm Max grinding depth 250 mm Grinding diameter 500 mm max (with water protection 450 mm) To sand bore diameter 300 mm Swivel range of the workpiece headstock 25 max Grindable cone angle 50 Rotational speed of the workpiece spindle U / MIN 20-400 Table speed infinitely einstallbar m / min 0.1-8

Manufacturer GEMINIS Model GHT-4 720 x 3000 Year 2004 CNC FAGOR 8055 TC/B Capacities and feeds Max. swing over bed 720 mm. Max. swing over cross slide 470 mm. Height of centres from flat guide 366 mm. Distance between centres 3.000 mm. C Axis and driven tools INCLUDED Fast feedrate X/Z axis 8.000 mm/min Work feedrate X/Z axis 8.000 mm/min Headstock Main spindle bore diameter 92 mm. Main spindle nose DIN-55027-11 Spindle diameter on front bearing 150 mm. Spindle speed 0-1600 Spindle automatic ranges 2 Main spindle power 17 / 20,5 kW Spindle torque 1590 / 1920 Nm Tailstock Ø Tailstock Quill 100 mm Tailstock travel 200 mm Taper Morse 6 Bed Width 430 mm. Height up to flat guide 775 mm. Turret Turret type Sauter VCI50 Ø400 mm. Driven tool position at turret 8 Driven tool power 5.5 kW Additional equipment 3 jaw auto-centering chuck SHW Autoblock 315 BH  ...

equipped with ATC = automatic toolchanger with 60 positions equipped with AVO = device for automatic pallet/table changer Transversal movement of table (X): 2000 mm Vertical movement of headstock (Y): 1250 mm / 1150 with pallet Horizontal movement of the stand (Z): 1000 mm Movement of spindle (W): 500 mm with Heidenhain measuring probe Longitudinal travel X-axe: 2000 mm Cross travel Y-axe: 1250 mm Travel Z-axe: 1000 mm Dimensions clamping space- table: 1400 x 1250 mm Power on spindle: 37 kW Admission in millinghead (ISO): ISO 50 (dia 125 mm) Max speedrange: 10 > 2800 rpm Control: Heidenhain TNC 426 Power needed (KVA): 78 kVa / 82 kW

Figure shows MIOTAL® TC 180 x 1000 Center width: 750 mm Center height: 165 mm Orbit diameter over bed: Ø 330 mm Bed width: 190 mm Travel cross slide: 160 mm Travel upper carriage: 90 mm Spindle connection: DIN 55029 (Camlock) D 1 - 4 Spindle bore: Ø 40 mm chuck diameter: Ø 200 mm Spindle speed, infinitely variable: 30 - 2000 rpm Mechanical counters: 3 Motor power: 2.2 kW Longitudinal feeds Z: (40) 0.044 - 1.96 mm/rev Feed rates X: (40) 0.022 - 0.98 mm/rev Thread Metric: (32) 0.4 - 7.0 mm Thread inch: (32) 4 - 56 gg/inch Thread module: (32) 0.4 - 7,0 Diametrical thread: (32) 7.5 - 112 Quill diameter tailstock: Ø 40 mm Inner cone of the quill tailstock: MK 3 Quill stroke: 100 mm Lateral adjustment: ± 10 mm Weight, approx.: 650 kg Characteristics: - Acceptance protocol according to DIN - Precise, hardened and ground guides - Robust headstock with circula ...

Center width: 1000 mm Center height: 178 mm Orbit diameter over bed: Ø 356 mm Bed width: 190 mm Travel cross slide: 160 mm Travel upper carriage: 90 mm Spindle connection: DIN 55029 (Camlock) D 1 - 4 Spindle bore: Ø 40 mm chuck diameter: Ø 200 mm Spindle speed, infinitely variable: 30 - 2000 rpm Mechanical counters: 3 Motor power: 2.2 kW Longitudinal feeds Z: (40) 0.044 - 1.96 mm/rev Feed rates X: (40) 0.022 - 0.98 mm/rev Thread Metric: (32) 0.4 - 7.0 mm Thread inch: (32) 4 - 56 gg/inch Thread module: (32) 0.4 - 7,0  Diametrical thread: (32) 7.5 - 112  Quill diameter tailstock: Ø 40 mm Inner cone of the quill tailstock: MK 3 Quill stroke: 100 mm Lateral adjustment: ± 10 mm Weight, approx.: 750 kg Characteristics: - Acceptance protocol according to DIN - Precise, hardened and ground guides - Robust headstock with circulating oil lubrication, precision-be ...

Mitsubishi MAF 240/180B CNC Floor Type HBM, New 1980 (Recontrolled in 1999) Condition: Very Good Type of CNC Control: Gidding & Lewis 8000B CNC Control - Recontrolled 1999 Spindle Diameter: 7.08"(180mm) Milling spindle diameter: 9.44"(240mm) Vertical Head Travel, Y-Axis: 169"(4300mm) Horizontal Column Travel, X-Axis: 1200" (30500mm) Headstock Travel, Z-1 Axis: 47.24"(1200mm) Spindle Travel, Z-2 Axis: 47.24" Total Axial Travel: 94.49"(2400mm) Rapid Traverse, X&Y Axes: 315 IPM Rapid traverse, Z, W and U Axes: 197 IPM Spindle Taper: CAT #50 Spindle Speeds: 6-1200 RPM - (3-Steps) Max. Spindle Thrust: 11,000 Lbs Constant Power Range: 79-1200 RPM Rotary Table Manufacture and Model: Mitsubishi DIT-A21X30 Rotary Table Size: 82" x 118" (2100x3000mm T-Slotted Rotary Table Max. Weight Capacity: 30 Tons Rotary Table Type: Insliding Rotary Inslide Travel: 59" (1500mm) Rotary Ta ...

: gebraucht : 2021 : 3965 : prompt, Zwischenverkauf v : Taiwan : 15600 € : 1 : 42 mm : MK 4 : 280 - 1.100 mm : 44 - 1.500 (12) U/min : Stahl: M 25, Guss: M 38 : 1880 mm : 870 mm : 2210 mm : 1800 kg : 470 - 1.270 mm : 0,05 - 0,15 (3) mm/min : 2.2 kW : 260 mm : 280 mm : 1.725 x 715 x 180 mm : 0,75 kW : 635 x 520 x 415 mm : 2530 mm DEMO MACHINE left/right rotation automatic feed drilling depth limit manual headstock adjustment with mechanical clamping electric height adjustment of extension arm and mechanical clamping mechanical clamping of swivel movement of extension arm central operation panel on the front side power load readout for drilling spindle hand wheel for spindle fine feed coolant equipment machine lamp box table machine and equipment according to the CE-regulations operating manual in GERMAN and ENGLISH The data for this ad was created with ModulMWS - the software solution  ...

bore capacity in steel (diameter): 40 mm arm length: 350 - 1250 mm workpiece height max.: 1250 mm spindle taper MT: 4 spindle turning speed range: 25 - 2000 U/min threading:: 27 mm quill stroke: 315 mm feed range - spindle: 0,04 - 3,2 mm/U slide adjustment -horizontal: 900 mm table-size: 625 x 500 mm column diameter: 350 mm total power requirement: 3,0 kW weight of the machine ca.: 3000 kg dimensions of the machine ca.: 2,15 x 1,07 x 2,84 m The Huvema radial drill range is unbeatable in price and performance, the machines are used for drilling, reaming and tapping. The drills frame is made from a high-quality fine-grain cast iron with heavy ribbing to ensure maximum reduction of vibrations. Precision ground gears ensure that the machine runs quietly, and the practical layout of the electrical and mechanical controls at the headstock make for easy operation. The machines are also fitted w ...

grinding diameter: max. 300 mm grinding length: 400 mm dist. between centers: 150 mm Control: 840 D SL Siemens max. workpiece weight: 50 kg x - axis: travel -x axis: 320 mm max. speed: 15.000 mm/min min. speed: 0,01 mm/min min. increment: 0,001 mm driving force: 1.225 N Z - Axis: travel -z axis: 600 mm max. speed: 15.000 mm/min min. speed: 0,01 mm/min min. increment: 0,001 mm driving force: 1.225 N B - Axis: number of spindles: 2x rotation range: +0 / -210 ° Tool dimension: Ø500 x 25 x Ø203.2 mm cutting speed: 60 m/s output: 25 kW workpiece spindle head:: axis rotation speed: 30 - 5.000 min/-1 taper: MK 5 Torque: 24 Nm Tailstock:: quill stroke: 40 mm taper: MK 4 total power requirement: 79 kW weight of the machine ca.: 6 t dimensions of the machine ca.: 6,0 x 3,0 x 2,5 m Documents: triple signal light: exhaust fan: MultiAir Premium Delbag High Speed and Precision Grinding Machi ...

There are three identical machines available, x-travel: 850mm, z-travel: 160mm, max. workpiece length/ diameter: 80/ 130mm, max. chuck diameter: 160mm, connected load: 48kW, controls: SIEMENS 840D, weight: 9.6t, including one headstock, one of the machines is missing the control cabinet.

DIEDESHEIM vertical lathe Vertifront 120-12 CNC. Electrics and geometry overhauled in 2007 for approx. 290.000,00 €! Former machine of the company Hoesch Rothe Erde Lippstadt, permanently maintained and maintained. Equipped with two turret supports (5-fold), protective hoods against emulsion vapors, housing see pictures, CE compliant. Details: Type 120-12 CNC Machine number L738 Year of construction 1983 Refurbished 2007 Space requirement approx. 20 sqm Weight approx. 20 to Power consumption approx. 110 kW Headstock Main spindle bearingsØ axial 500 mm radial 240 mm Cross Slide Unit Vertical slide stroke 800 mm (Z-axis) Paddling slide stroke 1,000 mm (X-axis) Basic hydraulics complete, system RING 2x2 axis CNC path control SIEMENS Sinumerik 3 TT Optional accessory 6-fold face plate clamping ideal for thin-walled workpieces ...

: neu : ca. 6 Monate ab Auftragse : Taiwan : 27100 € : 547.42 € : 50 mm : MK 5 : 360 - 1.250 mm : 44 - 1.206 (12) U/min : Stahl/Guß: M40/M50 : 2060 mm : 995 mm : 2240 mm : 2300 kg : 441 - 1.345 mm : 0,06 - 0,2 (3) mm/min : 3.7 kW : 300 mm : 270 mm : 1.785 x 785 x 190 mm : 0,75 kW : 635 x 520 x 420 mm : 2645 mm : 0,75 kW left/right rotation automatic feed drilling depth limit manual headstock adjustment with hydraulic clamping electric height adjustment of extension arm andhydraulic clamping hydraulicclamping of swivel movement of extension arm central operation panel on the front side power load readout for drilling spindle hand wheel for spindle fine feed coolant equipment machine lamp box table machine and equipment according to the CE-regulations operating manual in GERMAN and ENGLISH The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: neu : ca. 6 Monate ab Auftragse : Taiwan : 48700 € : 983.74 € : 65 mm : MK 5 : 440 - 1.580 mm : 40 - 1.920 (12) U/min : Stahl/Guß: M50/M60 : 2850 mm : 1400 mm : 2940 mm : 4600 kg : 380 - 1.600 mm : 0,07 - 0,96 (6) mm/min : 5.5 kW : 432 mm : 370 mm : 2.480 x 1.050 x 210 mm : 1,5 kW : 700 x 500 x 400 mm : 3170 mm : 0,75 kW left/right rotation automatic feed drilling depth limit manual headstock adjustment with hydraulic clamping electric height adjustment of extension arm andhydraulic clamping hydraulicclamping of swivel movement of extension arm central operation panel on the front side power load readout for drilling spindle hand wheel for spindle fine feed coolant equipment machine lamp box table machine and equipment according to the CE-regulations operating manual in GERMAN and ENGLISH (sample photo) The data for this ad was created with ModulMWS - the software solution of Log ...

: neu : ca. 6 Monate ab Auftragse : Taiwan : 32200 € : 650.44 € : 50 mm : MK 5 : 350 - 1.600 mm : 56 - 1.450 (12) U/min : Stahl/Guß: M40/M50 : 2670 mm : 1120 mm : 2410 mm : 3300 kg : 465 - 1.420 mm : 0,06 - 0,2 (3) mm/min : 3.7 kW : 320 mm : 270 mm : 2.550 x 970 x 200 mm : 1,5 kW : 630 x 500 x 500 mm : 2760 mm : 0,75 kW left/right rotation automatic feed drilling depth limit manual headstock adjustment with hydraulic clamping electric height adjustment of extension arm andhydraulic clamping hydraulicclamping of swivel movement of extension arm central operation panel on the front side power load readout for drilling spindle hand wheel for spindle fine feed coolant equipment machine lamp box table machine and equipment according to the CE-regulations operating manual in GERMAN and ENGLISH The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: neu : ca. 6 Monate ab Auftragse : Taiwan : 14600 € : 297.84 € : 32 mm : MK 4 : 220 - 950 mm : 73 - 1.247 (6) U/min : Stahl: M 25, Guss: M 32 : 1800 mm : 830 mm : 2190 mm : 1250 kg : 350 - 1.210 mm : 0,05 - 0,15 (3) mm/min : 1.5 kW : 210 mm : 220 mm : 1.260 x 640 x 160 mm : 0,75 kW : 600 x 445 x 380 mm : 2320 mm left/right rotation automatic feed drilling depth limit manual headstock adjustment with mechanical clamping electric height adjustment of extension arm and mechanical clamping mechanical clamping of swivel movement of extension arm central operation panel on the front side power load readout for drilling spindle hand wheel for spindle fine feed coolant equipment machine lamp box table machine and equipment according to the CE-regulations operating manual in GERMAN and ENGLISH The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: neu : ca. 6 Monate ab Auftragse : Taiwan : 18300 € : 373.32 € : 42 mm : MK 4 : 280 - 1.100 mm : 44 - 1.500 (12) U/min : Stahl: M 25, Guss: M 38 : 1880 mm : 870 mm : 2210 mm : 1800 kg : 470 - 1.270 mm : 0,05 - 0,15 (3) mm/min : 2.2 kW : 260 mm : 280 mm : 1.725 x 715 x 180 mm : 635 x 520 x 415 mm : 2530 mm left/right rotation automatic feed drilling depth limit manual headstock adjustment with mechanical clamping electric height adjustment of extension arm and mechanical clamping mechanical clamping of swivel movement of extension arm central operation panel on the front side power load readout for drilling spindle hand wheel for spindle fine feed coolant equipment machine lamp box table machine and equipment according to the CE-regulations operating manual in GERMAN and ENGLISH The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Grinding diameter: 600 mm Grinding length: 5000 mm Workpiece weight: 5000 kg Cylicrical grinder with table inclesment C-Type open steady rest Work load up to 5000 Kg Table speed 1 - 6 M/min Headstock 120 Rp  Centre height:           310mm Grinding Ø:              600mm Grinding length:         5000mm Grinding stone dimensions:750 x 100mm Table inclasement:       0 - 6° Length:                  9900mm Width:                   2300mm Height:                  2200mm Weight:                  19000kg

The scope of delivery includes: 01x Shelf connector, used Manufacturer: Nedcon Type: NS Material color: orange Headstock abm.: approx. 140 x 117 mm for a shelf spacing of: approx. 500 mm Fits a frame profile: 120 mm Profile illustration: approx. 60 x 40 mm Borehole diameter: approx. 10 mm Weight: 1,75 kg/ pcs.

SAACKE UW I D CNC universal grinding machine was manufactured in Germany in 2020. The extremely powerful machine is designed for the fully automatic wet grinding of a wide range of tools, such as knives, cutters or drills. Machining is performed in a single work cycle, which significantly increases production efficiency, saves time and reduces costs. The SAACKE CNC tool grinding machine allows the use of a chain or pallet system for automatic tool feeding and machining of workpieces within it with a maximum diameter of 250 mm and a length of 480 mm. Precision tool grinding is performed in five numerically controlled axes (X,Y,Z,A,B) using grinding wheels housed in a 6-position magazine separated from the workspace with an automatic grinding wheel changing system. In order to guarantee high travel speeds and positioning accuracy, the X,Y and Z axes of the UWID CNC tool grinder are m ...

FMB TURBO 3-26/2100 bar feeder was manufactured in Germany. The compact machine is used to automatically feed bars with a maximum diameter of 26 mm into sliding headstock lathes. Operating on the two-stage feed principle, the machine features an inwardly swivelling pusher that provides significantly increased bar change efficiency Technical specifications of the bar feeder FMB TURBO 3-26/2100 - maximum bar length: 2100 mm - maximum bar diameter: 26 mm - minimum bar diameter: 3 mm

WMW cylindrical grinding machine B0pedtl283 Type SA(U) 200x800 Grinding diameter approx. 220mm Grinding length approx. 800mm Infinitely variable speed regulation/headstock Coolant device Grinding wheel puller Work lamp Various grinding wheels and disc flanges Dimensions approx. LxWxH 3x1.5x1.7 meters Weight approx. 3000kg

Turning diameter: 840 mm Turning length: 3175 mm Turret positions: 12 Positions ATC: 12   Number controlled axis: 4   CNC Brand: Mazatrol CNC Model: Mazatrol Matrix Nexus Ideal for the energy, heavy vehicle, and other large component industries, the Quick Turn Nexus 450-II MY and optional tailstock-mounted Long Vertical Mill, which features a 1,150mm boring bar with a special bolt-on angle head, can deliver deep-hole boring to depths of 1,039mm and perform inside diameter milling operations, such as internal keyways and internal drilling. The machine’s rigid construction also provides high-precision machining over long periods of time.The Quick Turn Nexus 450-II MY’s headstock features a 457mm chuck, mounted on a 40 kW with 2,000rpm integrated spindle motor for heavy-duty metal removal. The spindle also serves as a C-axis, capable of being indexed at 0.0001° increments to accurat ...

Manufacturer: WMW Saalfeld Type: BK 50 AI Stock number: 0986 Drilling capacity in steel (diameter): 50 mm Projection: 355 mm Drilling stroke: 280 mm Spindle holder: MK5 Headstock adjustment: vertical 280 mm motorized Feed: 0.11-1.73/9step mm/rev Speed: 32-1400/12step rpm Table size: 770x640 mm Clamping surface: 630x500 mm Base plate: 490x530 mm Total power requirement: 8.1 kW Machine weight approx.: 1,7 t Machine dimensions approx. LxWxH: 1.25 x 0.8 x 2.75 m

The scope of delivery includes: 01x Shelf connector, used Material color: blue Manufacturer: Feralco for shelf spacing: approx. 200 mm Total length: approx. 200 mm Profile abm.: approx. 20 x 20 mm Headstock: approx. 100 x 40 x 4 mm Borehole Ø: approx. 9 mm (2 pcs per side) Weight: approx. 0.41 kg | Pcs.

SHW UFZ 6 Rigid Stand Travel • X-axis (bed): 3,000 mm • Y-axis (vertical): 1,600 mm • Z-axis (headstock): 1,500 mm Control • CNC control: Heidenhain iTNC 530 Feed rate • X, Y and Z axes: rapid traverse = 8,000 mm/min Universal milling head in orthogonal design • Swivel range milling head mount: 340 x 1 degree • Swivel range milling head: 180 x 1 degree • Tool holder: SK 50 DIN 69871 • Speed range: 25 – 2,240 rpm Overhaul in 2010 • Year of construction 1992 Conveyor • Feed length: 3,000 mm Automatic tool changer • Magazine for 45 tools About us: MBM Maschinenservice & Gebrauchtmaschinen GmbH is an independent specialist for SHW machine tools. Our main focus is in the field of tool milling machines. Our services include, among other things, spare parts deliveries, on-site customer service, machine overhauls and control system m ...

Machine type: Column drilling machine Make: WMW Heckert Type: BS 32 AI Control type: conventional Drilling capacity in steel (diameter): 32 mm Projection: 320 mm Drilling stroke: 200 mm Spindle mount MK: 4 Feed: 0.08.1.25 /9 step Speeds: 63 - 1,000 / 9 step rpm Headstock adjustment: 280 manual mm Table clamping surface: 530 x 450 mm Table adjustable: in height 350 mm Footprint: 490 x 440 mm Weight: 1.03 t

Column, stand PAGUS Height: 2750 mm Column: 300 x 300 mm Base plate: 950 x 600 x 30 mm Headstock: 440 x 320 x 30 mm used, tested ! Dimensions ( standing ): 950 x 600 x 2750 mm

SHW Powerspeed 5 Travel • X-axis (bed): 10,000 mm • Y-axis (headstock): 1,300 mm • Z-axis (vertical): 2,100 mm Control • CNC control: Heidenhain iTNC 530 Feed rate • X, Y and Z axis: 30,000 mm/min • Acceleration: 3.5 m/s² Universal milling head in orthogonal design • Swivel range milling head mount: 360 x 1 degree • Swivel range milling head: 180 x 1 degree • Tool holder: SK 50 DIN 69871 • Speed range: 36 - 6,000 rpm Conveyor • Feed length: 10,000 mm Coolant device • Container capacity: 1,200 litres About us: MBM Maschinenservice & Gebrauchtmaschinen GmbH is an independent specialist for SHW machine tools. Our main focus is in the field of tool milling machines. Our services include, among other things, spare parts deliveries, on-site customer service, machine overhauls and control system modernizations. Performances: -Mach ...

Hydraulic lifting device, machine jack, lifting device with integrated pump MEILI 2006-C load capacity ( piston ): 20000 kg load ( claw ): 8000 kg stroke: 152 mm attachment height ( claw ): 70 mm attachment height ( head plate, without claw ): 260 mm support surface ( claw ) : 65 x 35 mm Support surface( headstock ) : Ø 65 mm Operating rod: 775 x Ø 20 mm used, tested ! Dimensions (lifting device): 320 x 130 x 280 mm

VERSION 10 PNC axes - Control: FANUC PNC DECO - Rod passage 20 mm - movable headstock Z1 - Speed 10,000 1/min - 2x cross slide with 2x5 tool holders - 10 pre-adjustable tool holders - 4 front units - Counter spindle - Backside processing (4x end, 3x landscape) - Workpiece conveyor - Spaenefoerderer - Tool presetting device - Fire extinguishing system - Central lubrication unit - Oil mist extraction, filter mist - Drill quills, base holder and steel holder - various accessories (see photos) - Rod loading magazine Robobar

Nominal weight of the falling parts: 750 kg Max. number of blows per minute: 105 Kinetic energy: 1900 kg Distance from an axis of the slider up to bed: 750 mm Cylinder diameter: 600 mm Diameter of the plunger: 630 mm Max. headstock travel: 835 mm Dimensions: -Left-to-right: 3940 mm -Front-to-back: 1430 mm Height above floor level: 3260 mm Weight: -With an anvil-block: 25600 kg -Without an anvil-block: 16600 kg

DBK 1300 Lathe Center height above machine bed: 220 mm Distance between centers: 1300 mm Center height over palm rest support: 160 mm Spindle speed: 0 to 3000 rpm Headstock, thread holder: M33 Tailstock Morse cone mount: MK2 Pinolenweg/tail spindle travel: 100 mm Motor power S1 (100%) / S6: 1.1kW/1.5kW Mains voltage: 230 V or 400 V Net weight: 160 kg G&HM-DBK1300
