haulick roos used for sale

Capacity: 125 ton, Strokes per minute: 85-500 / min, Slide: 870 x 550 mm, Plate width: 260 mm, Year of manufacturing: 1980

pressure: 63 t stroke: 6-60 mm no. of strokes: 90-550 Hub/min : 300 mm table surface area: 780x600 mm ram surface: 807x460 mm tool hole in ram: Ø 40 mm ram - range of adjustment: 80 mm total power requirement: 15 kW weight of the machine ca.: 8 t dimensions of the machine ca.: BxTxH 2900x2000x3000 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 63 t stroke: 4-60 mm no. of strokes: 85-500 Hub/min ram - range of adjustment: 80 mm : 320 mm table surface area: 750x600 mm ram surface: 750x600 mm total power requirement: 31 kW weight of the machine ca.: 8,2 t dimensions of the machine ca.: BxTxH 2900x1900x2900 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 250 t stroke: 37 mm no. of strokes: 30-240 Hub/min ram adjustment: 150 mm table surface area: 1200x1000 mm hole in the table: 500x180 mm tool hole in ram: Ø52 mm total power requirement: 50 kW weight of the machine ca.: 35 t dimensions of the machine ca.: LxBxH 3700x2300x3900 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 125 t stroke: 10-80 mm no. of strokes: 240 Hub/min ram - range of adjustment: 80 mm table surface area: 850x600 mm ram surface: 760x550 mm hole in the table: 850x130 verstellbar mm table height: 1100 mm tool hole in ram: Ø 50 mm total power requirement: kW weight of the machine ca.: 13 t dimensions of the machine ca.: BxTxH: 3000x2000x3300 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 250 t stroke: 37 mm no. of strokes: 30-240 Hub/min ram adjustment: 150 mm table surface area: 1200x1000 mm hole in the table: 500x180 mm tool hole in ram: Ø52 mm total power requirement: 50 kW weight of the machine ca.: 35 t dimensions of the machine ca.: LxBxH 3700x2300x3900 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

- Manufacturer: HAULICK+ROOS - Model : MD 260 SL - Length (mm): 0 – 260 - Material Width (mm): 10 – 260 - Material Thickness (mm): 3 - Band Speed (m/min): 60 - Band Cross-Section (mm): 800 - Year of Manufacture: 1983 The 1983 HAULICK+ROOS MD 260 SL is a mechanical double-column press manufactured by Haulick + Roos, a German company specializing in precision stamping and forming machines. This model is designed for high-speed production and is commonly used in industries requiring precise metal forming, such as automotive and electronics manufacturing. Key Specifications: - Press Force: 260 tons - Stroke Length: Variable, accommodating different production needs - Table Size: Approximately 1,250 mm x 1,000 mm - Slide Adjustment: Motorized, allowing for precise control over the slide position - Drive System: Eccentric or crank mechanism, typical for mechanical presses of this type  ...

Press capacity: 80 ton Ram stroke adjustable: 4 -60 mm Slide adjustment: 0 - 80 mm Shut height (stroke down, adjustment up): 310 mm Free frontal opening L-R: 800 mm Table height over floor: 1150 mm Table surface area : 780 x 640 mm Slide area: 800 x 460 mm Hole in table: 690 x 170 mm Number of strokes: 30 - 300 s.p.m. Required power: 21 kW Height over floor approx.: 2900 mm Weight of machine approx.: 12 ton Control: Siemens S5

Eccentric punching machine HAULICK + ROOS type RVD 125Double column - Eccentric pressMasch. No. 212560 Year of construction 1981Compressive force 125 ton. Table size 880 x 800 mmTable opening 470 x 140 mmStand width 900 mmStand width laterally 415 mmRam stroke 45 mmRam adjustment range 0-80 mmInstallation height in the picture 340 mmStroke rate 50 to 300 strokes/min. Engine power main drive 22 kWNe-connection 380 Volt, 50 Hz- Double connecting rod engine with 4-bearing eccentric shaft for off-center tappet pressure

pressure: t plate thickness: mm no. of strokes: Hub/min total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure:040 t stroke:8 - 50 mm no. of strokes:50 - 300 /min distance between columns:600 mm distance table/ram, max. stroke up, adjustment up:285 mm table surface area:590 x 500 mm hole in the table:590 x 40 - 100 mm table height over floor:860 mm column travel -side:280 mm ram surface:590 x 380 mm ram adjustment:80 mm material width of feeder:150 mm power requirement:7,5 kW clutch:pneumatic ram adjustment:motoric pincer feed:mechanical

pressure:160 t stroke:160 fix mm no. of strokes:30 - 120 /min distance between columns:1190 mm distance table/ram, max. stroke up, adjustment up:735 mm table surface area:1200 x 1000 mm hole in the table:500 x 300 mm table height over floor:900 mm side window:600 mm ram surface:1000 x 800 mm ram adjustment:125 mm material width of feeder:550 mm material thickness of feeder:0 - 6,0 mm feed length:350 mm material cross-cut:1100 mm² Feed speed:50 m/min power requirement:45,0 kW weight:25,0 t dimensions (WxDxH):2,3 x 2,1 x 4,7 m infinitely variable drive:PIV overload protection in ram:hydraulic ram adjustment:motoric ram counterbalance:pneumatic pincer feed:mechanisch, RS 350/550 SL 90

Two slices of bread fit side by side on the conveyor belt. Two separate heating elements. Suitable for continuous toasting of sliced ​​bread. Equipped with a front and back tray. The transit time can be set to 3 minutes. Auction-ID: A7-44746-13

Technical specifications of the accessories Accessories: Press protection grille Manufacturer: LEINHAAS – NILSON, 646 Gelnhausen Type: Nilson Press Guard SDF Factory No.: 1120 Year of manufacture: 03/1979 Configuration Execution: Mechanical press protection grille

Technical data Manufacturer: Haulick-Pressen, Pforzheim (Germany) Type: HPVK 140 Year of Make: 1968 Machine No.: 1007 Printing capacity: 140 t (single lift) / 110 t (continuous operation) Table surface: 440 × 590 mm (T-slots 18 for M16) Plunger area: 320 × 320 mm Stroke: 2–50 mm Stroke rate: 30–150 strokes/min Drive power: 10 hp Weight: approx. 3,800 kg Operating voltage: 380 V / 50 Hz Control voltage: 220 V Configuration Precision Feed: HZY 80 (feed rate 0–80 mm) Material width: up to 190 mm Material thickness: 0.1–2.5 mm Protective shield control: Ph. Schwarz, Wuppertal
