CNC Turning Centers HAAS Super Mini Mill

TRAVELS
X Axis: 406 mm
Y Axis: 305 mm
Z Axis: 254 mm
Spindle Nose to Table (~ max): 356 mm
Spindle Nose to Table (~ min): 102 mm

TABLE
Length: 914 mm
Length (Work Area): 730 mm
Width: 305 mm
T-Slot Width: 16 mm
T-Slot Center Distance: 110.0 mm
Number of Std T-Slots: 3
Max Weight on Table (evenly distributed): 227 kg

SPINDLE
Max Rating: 15 hp 11.2 kW
Max Speed: 10000 rpm
Max Torque: 23 Nm - 4600 rpm
Drive System: Direct Speed Belt Drive
Taper: CT or BT 40
Bearing Lubrication: Air/Oil Injection
Cooling: Air Cooled

FEEDRATES
Rapids on X: 30.5 m/min
Rapids on Y: 30.5 m/min
Rapids on Z: 30.5 m/min
Max Cutting: 21.2 m/min

AXIS MOTORS
Max Thrust X: 8896 N
Max Thrust Y: 8896 N
Max Thrust Z: 8896 N

TOOL CHANGER
Type : Carousel
Capacity: 10
Max Tool Diameter (full): 89 mm
Max Tool Weight: 5.4 kg
Tool-to-Tool (avg): 3.0 sec
Chip-to-Chip (avg): 3.8 sec
seller offer No. resale 169298267
