gleason hurth used for sale

Description: machine number: G0500 control: SIEMENS Sinumerik  , length of clamping surface: 1550 mm number of T-slots: 2 mm width of the T-slots: 18 mm distance between the T-slots: 180 mm centre height (tailstocks): 350 mm swivelling range of the fine wheel head (U-axis): +/- 30° centre distance tailstock/fine wheel: 120 - 225 mm  , travelling distance of infeed slide (Z-axis): 105 mm  , tool: outer diameter: 225 - 275 mm bore diameter: 160 mm width: 60 mm  , workpiece: outer diameter: 40 - 150 mm module: 1.25 - 4.0 mm max. tooth width: 45 mm  , max. tool speed: 2000 rpm feed speeds: Z-axis: 2 m/min. Y-axis: 2 m/min. U-axis: 12°/s  , connected load: 27 kVA  , please also take a look at the PDF documents of this machine workpiece diameter: 45 - 150 mm, control: SIEMENS Sinumerik, weight approx.: 6,000 kg, Approx.  ...

Description: serial number: G0502 control: SIEMENS Sinumerik 840C  , length of clamping surface: 1550 mm number of T-slots: 2 mm width of the T-slots: 18 mm distance between the T-slots: 180 mm centre height (tailstocks): 350 mm swivelling range of the fine wheel head (U-axis): +/- 30° centre distance - tailstock/fine wheel: 120 - 225 mm  , infeed slide: movement range (=travelling distance Z-axis): 105 mm  , tool diameter: 225 - 275 mm bore diameter: 160 mm tool width: 60 mm  , workpiece diameter: 40 - 150 mm module: 1.25 - 4.0 mm max. tooth width: 45  , please also have a look at the PDF documents for this machine workpiece diameter: 40 - 150 mm, control: SIEMENS Sinumerik 840C, weight approx.: 5,500 kg, Approx. Onsite Dimension. (l x w x h): 2,600 x 3,500 x 2,300 mm

Description: serial number: J0146 control: SIEMENS Sinumerik 840D  , travels: X-axis: 160 mm Y-axis: 220 mm Z-axis: 350 mm Z4-axis (counterholder): 350 mm  , largest milling head swivelling angle: +/- 45°  , tool (cylindrical milling cutter): largest permissible tip circle diameter: 100 mm largest toothed length: 240 mm largest length: 317 mm  , workpiece table: outer diameter: 200 mm clamping diameter: 150 mm bore:45 mm max. workpiece weight: 3 kg  , workpiece: max. workpiece diameter: 130 mm max. modul: 3 mm  , feed rate: X-axis: 20 m/min. Y-axis: 10 m/min. Z-axis: 7 m/min.  , connected load: 40 kVA  , including: ASTOS DML 200/1576/1340/60 Chip Conveyor, YOM: 2008, weight: 150 kg REVEN UC Compact 1 Oil Separator  , without conveyor system and tool cabinet  , please also ha ...

Description: serial number: D0043 control: SIEMENS Simatic OP7 working hours: approx. 42802 hrs.  , max. wheel diameter: 300 mm gear width: 100 mm max. module: 5 max. workpiece: 1100 mm spindle bearing diameter: 100 mm diameter of spindle flange: 120 mm tailstock travel: 80 mm  , please also have a look at the PDF documents of this machine control: SIEMENS Simatic OP7, max. module: 5 mm, Approx. Onsite Dimension. (l x w x h): 2,100 x 3,500 x 2,100 mm, weight approx.: 2,500 kg

Description: The Gleason-PFAUTER CNC Gear Shaping Machine P 1200 S offers an extensive working range and impressive technical data. With a nominal workpiece diameter of 1,200 mm for external and internal gears and a maximum workpiece diameter of 1,400 mm without a counterholder, it is extremely versatile. Control and Machine Number Control: SIEMENS Sinumerik 840D Machine number: 30 114 Working area Table diameter: 1200 mm Table bore: Ø 300 Workpiece specifications Max. orbital diameter: 1400 mm Nominal workpiece diameter (external and internal toothing): 1200 mm Nominal module max.: 16 mm Toothing width max.: 350 mm Shaping head specifications Max. stroke rate of shaping head: 80 min-1 Please take a look at the t echnical data and layout plans in the PDF file . max. wheel diameter: max. 1400 mm, module min./max.: max. 16, gear width: 350 mm, control: SIEMENS S ...

Description: serial number: 28788 control: SIEMENS Sinumerik 840D  , max. wheel diameter: 130 mm wheel width: 25 mm min. module: 0.5 max. module: 4 stroke rate: 500 - 2500 strokes/min. stroke: 30 mm shock spindle diameter: 85 mm total power requirement: 48 kVA  , please also have a look at the PDF document of this machine max. wheel diameter: 130 mm, module min./max.: 0.5 / 4, gear width: 25 mm, control: SIEMENS Sinumeric 840D, stroke length max.: 30 mm, no. of strokes: 500 - 2500 rpm, total power requirement: 48 kW, weight approx.: 15,000 kg, Approx. Onsite Dimension. (l x w x h): 3,800 x 3,500 x 3,000 mm

max. wheel diameter:200 mm gear width:250 mm max. module:3 min. module:0,5 total power requirement:45 kW weight of the machine ca.:8,5 t dimensions of the machine ca.:4,4 x 2,4 x 2,7 m Machine out of prototype production Without automation

max. wheel diameter:130 mm gear width:170 mm max. module:3 min. module:0,5 total power requirement:48 kVA weight of the machine ca.:9 t dimensions of the machine ca.:7,64 x 3,14 x 3,25 m For technical data, see PDF-File enclosed

max. wheel diameter:90 mm gear width:300 mm max. module:3 tip circle diameter:max. 65 mm root circle dia. min.:28 mm max. geared Length:150 mm tool length - max.:203 mm tangential ( y-axis ):140 mm axial ( z-axis ):400 mm Tailstock ( z²-axis ):350 mm loading and unloading portal ( z³-axis ):1850 mm milling head -swivable +/-:+ A = 40 / - A = 40 ° working piece table: max. outer diameter / bore hole:120 / 45 mm feeds X-axis:1 - 10000 mm/min feeds Z-axis:1 - 10000 mm/min rapid power traverse in X-and Z direction:10000 m/min rapid motion - y-axis:5000 mm/min fast rapid z²-axis ( tailstock ):10000 mm/min. speeds of tool:300 - 4000 U/min working piece table speed:0 - 1000 1/min. connected load:44 kVA voltage:400 V control voltage:24 kW weight of the machine ca.:7500 kg dimensions of the machine ca.:3170 x 2975 x 2440 mm

Roller burr wheel, burr tool GLEASON - HURTH Ø 203 mm z = 77 1104457-1 ESW / EGW - 326735 bore Ø 40 mm used, tested ! Dimensions: 203 x 203 x 49 mm Dimensions(packaging): 260 x 260 x 120 mm

Rolling burr wheel, burr tool GLEASON - HURTH Ø 203 mm z = 32 6.225.1275.27.79-1 EGW - 351624 bore Ø 40 mm used, tested ! Dimensions: 203 x 203 x 49 mm Dimensions(packaging): 260 x 260 x 120 mm

Roller burr wheel, Rolling burr tool GLEASON - HURTH Ø 203 mm ( Ø203mm ) z = 49 ( z=49 ) 6.6.160.3420.29.113-2 EWG - 352086 bore Ø 40 mm used, tested ! Dimensions: 203 x 203 x 33 mm Dimensions(packaging): 260 x 260 x 120 mm

Wedge groove machine HURTH LF32a - see pictures

max. wheel diameter: 280 mm max. number of teeth: 100 max. module: 6 min. module: 1 total power requirement: 6 kW weight of the machine ca.: 2500 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

groove width: 16 mm x-travel: 16-200 mm table length: 1500 mm table width: 375 mm milling spindle: ISO 40 max. clampable toolpiece shaft diameter: 30 mm max. useable hobs, normal diameter: 40 mm distance between milling spindle and table: 150-250 mm axial move. of milling spindle (auto./manual): 120 mm vertical adjust. of milling slide (manual): 100 mm weight of the machine ca.: 3,1 t dimensions of the machine ca.: 2,00x1,40x2,40 m K4 - TECHDETAIL UK: 0,11 kW K4 - TECHDETAIL UK: 0,6/1,1 kW K4 - TECHDETAIL UK: 3 x 0,012-0,05 mm/U K4 - TECHDETAIL UK: 16x60 mm K4 - TECHDETAIL UK: 12 x 280 - 3550 U/min K4 - TECHDETAIL UK: 0,85 kW K4 - TECHDETAIL UK: 0-2,0 mm K4 - TECHDETAIL UK: 250 mm Condition: ready for production The machine is suitable for the manufacture of flutes and slots using undersize cutters with hydraulic adjustment. Roughing and finishing can be done in one single clamping.  ...

Groove milling machine Fab. HURTH Type LFV 3Masch. -No: 3566 estimated year of construction 1963Groove width max.30.35 mmTravel X: 550 mmTravel Y: 300 mmTravel distance Z: 400 mmSpindle mount ISO: SK 40Milling carriage travel: 240 mmDepth feed screw stroke: 0-110 mmTable size: 300 x 1200 mmTable width: 350 mmProjection: 415 mm8 spindle speeds: 90-1000 rpm9 crank feeds: 1.4-22.4 p. minute9 table feeds lengthwise: 10.9-163 mm / minTable drive: 0.37 kWSpindle drive: approx. 2.5 kWSpindle deflection: 410 mmCutter diameter: max. 50 mmCutter head diameter: max. 110 mmSpindle drive approx: 2.5 kWOutside dimensions approx: 1.5 x 1.45 x 1.95 mmWeight approx: 2,2 tWith:- Deep milling device- Crank drive of the milling carriage- autom. longitudinal feedused, despite year of construction in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover  ...

diameter:500 mm workpiece weight:30 kg test dia. min.:200 mm total power requirement:0,03 kW weight of the machine ca.:1000 kg dimensions of the machine ca.:1x0,5x1,06 m

max. wheel diameter: 0 mm max. number of teeth: 0 max. module: min. module: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC controlled milling machine for synchronous rings The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. grinding diameter: 400 mm grinding width: 0 mm max. module: min. module: total power requirement: 3 kW weight of the machine ca.: 4,2 t dimensions of the machine ca.: m Shaver cutter Ø, min./max. 64 - 320 mm Module range 1 - 12 Shaver cutter width, max. 40 mm No. of teeth 13 - 240 Pitch block Ø 73 - 320 mm Speeds of workpiece slide 5 / 20 / 30 / 40 teeth per min. Grinding slide speed 690 rpm Grinding slide Ø 762 mm Grinding wheel swivelling (pressure angle) 5 - 21 ° Grinding slide swivelling (helical angle) 2 x 35 ° Grinding slide adjustment, vertical 240 mm Cutting speed 1 / 0.5 / 0.25 m/min Spindle drive 1.1 kW Total electrical load, approx. 3 kW - 500 V - 50 Hz Weight, approx. 4,200 kg Accessories / Special Features Machine is suitable for grinding internal and external shaver cutters. It is also suitable for master gears as well as cutters for gear shapers. Unfortunat ...

Chip centrifuge, Speed ​​variator for the shaver, 2 points 1 hydraulic for small Ø and another manual for Ø up to 550mm / Centrifuge chips, Variable speed for shaver, 2 points for small or 1 Hydraulic and a manual for Ø up to 550mm, High: 2200 mm, Long: 1650 mm, Width: 1450 mm, Module: 8, Weight: 6,500 Kg., Voltage: 220/380 W., Total power: 6.5 Kw., Cutter ø max / min: 260/180 mm, Cutter length max / min: 30/20 mm, Maximum length workpiece: 250 mm, Ø max. / min. workpiece: 550/20 mm., Specification: Universal

GEAR NOISE TESTER Make : HURTH Model : ZP320 B THE MACHINE IS IN EXCELLENT CONDITIONS AND COMPLETE IN ALL ITS PARTS

max. grinding diameter: 400 mm : 18010 shaving cutter - diameter: 64 - 320 mm indexing: schleifbar 1 -12 Modul shaving wheel width: max. 40 mm number of teeth: 13 - 240 roller bend diameter min./max.: 73 - 320 mm slide speeds: 5-20-30-40 Zähne/min. max. dia. of grinding wheel: 762 mm grinding wheel - swivable: 5-21 ° grinding slide swivable +/-: 2 x 35 ° total power requirement: 3 kW weight of the machine ca.: 4,2 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

amount: 49 STK weight: 10 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Workpiece dimensions: 360 mm max. workpiece diameter: 360 mm module: 8 mm x-travel: 400 mm y-travel: 240 mm z-travel: 360 mm milling head -swivable +/-: 45 ° diameter of hob: max. 175 mm milling spindle turning speed range:: 75-600 U/min. : 40 KVA control: 840C Siemens dimensions of the machine ca.: 3,10 x 2,40 x 2,70 m weight: 9 t total power requirement: 25 kW work piece revolutions: zweigänig 0,2-60 U/min counter-stay slide: 450 mm Verfahrweg Siemens Sinumerik 880 M - control partial gearbox double threaded, automatic workpiece feeding, conversational programm Video link: https://www.youtube.com/watch?v=GkQs8lfeNYk The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Hydraulic pump, oil pump, hydraulic power pack, hydraulic pump, hydraulic pump, electric motor, DC motor, traction motor, drive motor -Manufacturer: ZF/hurth forklift drive HFK 250 -Admission wheel: dimensions see pictures -Hole circle: Ø 270 mm M12 -Dimensions: 700/330/H285 mm -Weight: 69 kg

T-slot nut, 13 pieces GLEASON - PFAUTER 604560 for groove width: 18 mm width: 28 / 17.7 mm length: 28 mm height: 10 / 10 mm thread: M12 x 1.75 New ! Dimensions ( Packaging ): 100 x 60 x 40 mm

Assortment of tool carriers with accessories, 8 pieces GLEASON 6x W576008 650569 1x W1158168-0001 1698464 1x W1158168-0002 < br /> 1698465 1x W576004 651219 1x W576004 651221 1x W1150422-0001 1674597 used, tested ! Dimensions ( packaging ): 400 x 300 x 120 mm

workpiece diameter with ratio 1:10: 300 mm workpiece diameter with ratio 1:1: 212 mm max. number of teeth: 200 min. number of teeth: 6 x-travel: 300 mm X - Axis speed: 0,1-5.000 mm/sec. y-travel: 400 mm Y - Axis speed: 0,1-5.000 mm/sec. A - axis: -170 / +170 ° control: Siemens Sinumerik 840 C total power requirement: 38 kW weight of the machine ca.: 10 t dimensions of the machine ca.: 4,20 x 2,20 x 2,10 m incl. suction The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

General SKU279P427 LocationBarneveld MakeVollrath Hurth (DE) TypeEWTHV 0.5 No.23.993 Year of construction1992 Main Features MaterialMild steel Motor0.3 KW Specified Features - Dissolver MaterialMild steel Dissolvercheck Shaft length(no shaft) Motor0,3 KW, 230/400 Volt (Ex) With variable speed drivecheck Speed mixing shaft260-1820rpm With mechanical liftingcheck Information With switchcheck Floorspace0,5x0,4 M Total height0,8 M Weight100 KG ATEX compatiblecheckDissolversVollrathMixers > DissolversBrand > Vollrath What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome to inspect the machine in Barneveld, The Netherlands. Please visit us in Barneveld for many more machines!

Wheel diameter - max. 300 mm Spindle speeds 250 - 2800 rpm Feed min/max 45/125 mm Module 8 Taper spindle ISO 40 Partial head angle 110º Total power requirement 3 kW Machine weight approx. 1.5 t Space requirement approx. 1.5 x 1.4 x 1.9 m

Horizontal spline shaft milling machine HURTH KF 32 AH

Spline milling machine Hurth LF 32

Description: for workpiece clamping on lathes, grinding machines and dividing heads with high concentricity and holding force, for workpiece clamping (bar or chuck work) in conventional single-spindle lathes and CNC lathes directly in the spindle or in the collet chuck, smooth bores are mainly used in the counter spindle of CNC lathes . - including accessories according to pictures, quantity= 49 PCS weight approx.: 10 kg, Approx. Onsite Dimension. (l x w x h): 350 x 220 x 250 mm

weight of the machine ca.: 5 t working width: max. 300 mm : 6 extensive accessories: viele Wechselräder The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 19147 weight of the machine ca.: 4 t working width: max. 300 mm extensive accessories: viele Wechselräder max. module: 7 Module The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: Control type: CNC, control name: Siemens Sinumerik 840 C Technical details: Workpiece diameter at ratio 1:10 300 mm, workpiece diameter at ratio 1:1 212 mm, number of teeth - max. 200, number of teeth - min. 6, x-travel 300 mm, X - axis speed 0.1-5,000 mm/ sec., y-travel 400 mm, Y - axis speed 0.1-5,000 mm/sec., A - axis -170 / +170 °, total power requirement 38 kW, machine weight approx. 10 t, space requirement approx. 4.20 x 2.20 x 2.10 m weight approx.: 10,000 kg, Approx. Onsite Dimension. (l x w x h): 4,200 x 2,200 x 2,100 mm

Description: serial number: 44742 control: SIEMENS Sinumerik  , max. wheel diameter: 150 mm min. module: 1.25 max. module: 3.5 tooth width: 45 mm bore diameter: 100 mm clamping surface: 1300 x 300 mm  , including: IFE IFS 2000 Suction Filter, YOM: 1998, power: 0.75 kW conveyor/transportation system  , please also have a look at the PDF documents of this machine control: SIEMENS Sinumerik, max. module: 3.5 mm, Approx. Onsite Dimension. (l x w x h): 2,800 x 2,500 x 2,800 mm, weight approx.: 7,000 kg

Description: serial number: 45641 control: SIEMENS Sinumerik  , clamping surface area: 1475 x 300 mm number of T-slots: 2 T-slot width: 18 mm T-slot distance: 180 mm guide rail width: 59 mm max. outside diameter: 300 mm drilling diameter: ,63.5 - 100 mm connected load: 16 kVA  , please also have a look at the PDF documents of this machine control: SIEMENS Sinumerik, Approx. Onsite Dimension. (l x w x h): 3,500 x 3,000 x 2,200 mm, weight approx.: 5,500 kg
