gfa ketsch used for sale

Type: 2SQ4000/1800, circular-swinger, screen area: 1,800 x 4,000 mm, with new semi-mobile steel construction with platform for service and maintenance, sand-blasted and new coloured

Size: 1.800 x 4.000mm - Year of Manufacture: 1998 - With Electrical motor (11 kW/6), Cardan shaft and springs - Will be overhauled, sandblasted and painted.

Deck size: 2.000 x 5000 mm. - 2 Decks (Different deck-angle) - With electrical motors, cardan-shaft and springs - Can be sandblasted and painted.

TECHNICAL SPECIFICATIONS Manufacturer: GFA Name: Banana sieve Type: 1P 4000/1800 Design: Dry screening, stationary Year of construction: 1994 Throughput: approx. 80 t/h Sieve dimensions (length/width): 4,000 x 1,800 mm Separation deck 1 at: 2 mm (Isenmann) Weight: approx. 7,000 kg Drive power: 7.5 kW TECHNICAL SPECIFICATIONS Manufacturer: GFA Description: Banana screen Type: 1P 4000/1800 Version: Dry screening, stationary Year of construction: 1994 Throughput: approx. 80 t/h Screening dimensions: 4,000 x 1,800 mm Separation deck 1 at: 2mm (Isenmann layer) Weight: approx. 7,000 kg Drive power: 7.5 kW

Screening machine Gfa 4200 x 1600 mm - 2 deckers

Screening machine GFA 20/30-1 Brand: GFA Screen area: 3000 x 2000 mm - 1 decker Screen opening: [] 35mm Drive: 11 kW electric motor Incl.: springs and motor.

Screening machine GFA 22,5/60-1 Brand: GFA Screen area : 6000 x 2250 mm – 1 decker Screen opening: [] 8 mm Drive: 30 kW electric motor

Screening machine GFA 25/60-3 Brand: GFA Type: ASA Screen area: length 6000 mm, width 2500 mm - 3 deckers Upper deck: screen opening [] 15 mm Middle deck: screen opening [] 8 mm Lower deck: screen opening [] 4 mm Drive: 37 kW electric motor Incl.: springs.

Gfa / Metso 12/40-1 screening machine Type Grizzly Screen area: 4000 x 1200 mm - 1 decker Screen opening : 70 mm. Propulsion : 18,5 kW. Incl.: springs.

Pusher wagon GFA with bunker Dim.Schubwagen: 3500 x 1150mm Dim.Bunker: 4000 x 2000 x 1400mm Drive 11 kW

GFA feed channel Brand: GFA Length 2000 mm - Width 1200 mm with two vibration motors of 2.3 kW each Incl.: Springs In stock: 4 piece.

TECHNICAL SPECIFICATIONS Manufacturer: GfA Designation: Aquamator / Hydrobandscheider Type: AK 3,5/1600/160 Year of construction: 1984 Feed solids: 60 - 100 t/h Water requirement: < 120 m³/h Drive power: 3 - 4 kW Axle distance: 3,500 mm Belt width: 1,600 mm Weight static: 4,500 kg Dynamic weight: 5,800 kg

TECHNICAL SPECIFICATIONS Manufacturer: GfA Designation: Aquamator / Hydrobandscheider Type: AK 3,5/1600/300 Year of construction: 1979 Feed solids: 60 - 100 t/h Water requirement: < 120 m³/h Drive power: 3 - 4 kW Axle distance: 3,500 mm Belt width: 1,600 mm

Gear motor, electric motor, three-phase motor, door drive, roller door drive, sectional door drive, electric gear motor, electromat -Manufacturer: GfA, Elektromat type SE 3.5.120-25.00 -Speed: 120 rpm -Motor: Siemens, power 0.37 kW -Shaft: Ø 25 mm -Protection class: IP 55 -Dimensions: 375/140/H245 mm -Weight. 12 kg

TECHNICAL SPECIFICATIONS Manafacture: GFA Designation: inclined circular vibrating screen Type:1P 5000/2000 Number of screen decks: 1 pc. Year of construction: 1992 Drive cable: 11 kW Feed capacity: approx. 80 t/h Dimensions (length/width): 5,000 x 2,000 mm Screening area: 10 sqm Screen lining deck 1: metal and synthetic SPECIFIC COMMENT - Good technical condition

Compressor unit on base plate make KAESER type 3300-GFabr. -No: 55585 built in 1980Technical specifications:Stroke volume flow 3300 l / mineffective delivery 2300 l / minpermissible operating pressure 10 barCompressor speed 1220 rpm.Power requirement 18.5 kWExternal dimensions 1600 x 830 x 870 mmAggregate weight 490 kgWe need space!Special price ex warehouse MörsdorfPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

Sheet filter, make Schenk, type: 60x60, for about 30 hl/h, with stationary filter rack, with planetary gear, fit out with 59 filter plates in stainless steel, 2 endplates, with outside lying raising pipes, 2 sight glass armatures with pressure manometer, frame length: ~3,0m

Fully automated sand-lime brick factory. 50,000 tonnes/year. Modernised in 1986, 2000 & 2019. The current plant meets today's high safety standards and has been continuously modernised and modified. The residual steam is reused for heating company buildings. Packaging installation: fully automatic The entire installation is fully automated, with the exception of the manual opening and closing of the autoclave doors. 2x Atlas Krupp Polysius presses (1 with new Bosch Rexroth hydraulic system and controls) Forming boxes for different stone formats Conveyors and silos Primary crusher Gyradisc 36 Jg. 1980 Fine crusher SBM V8 machine nr.12041/2X Vibrating screen GFA sieve 0-3mm Mixer machine factory Gustav Eirich, type DE 22 Machine no. 23104, built in 1984, with vortex device capacity 1500 lt/ 2400 kg Eirich mixer, with agitator 1.5 m or 2.5 t 2 x reactors Namur mixer, with w ...

Production hall hbs780s and warehouse hbs645s, which are to be dismantled in the short term. These are thermally insulated halls whose supporting structure and cladding as well as various accessories can be reused. Production hall hbs780s GFA area: approx. 780 m²; Hall width: approx. 30.00 m AK façade; Hall length: approx. 26.00 m AK façade; Frame spacing: approx. 5.60 m MM truss; Eaves height: approx. 7.75 m OK purlin; STRUCTURE: The primary structure consists of hot-rolled Euro profiles. The secondary structure to accommodate the building envelope consists of cold-formed steel profiles made of galvanized strip steel. ROOFING: Sandwich panels, grey-white, on purlins made of cold-formed and galvanised lightweight profiles. WALL COVERING: Sandwich panels and thermally insulated sheet steel cassettes on wall substructure made of cold-formed and galva ...

Filtration plant, Fabr. Seitz Orion, 100 x 100, for 180 hl/h, factory overhauled in 2002, consisting of: - Diatomaceous earth frame filter, with 29 KG frame in stainless steel, external risers, sight glass fittings with pressure gauge, with KG discharge tray with screw in stainless steel, with KG dosing device - Sheet filter, with 150 VA plates, external risers, sight glass fittings with pressure gauge - Control platform between both filters, step at the KG filter - Control cabinet
