fritz mueller used for sale

pressure:315 t distance between columns:1620 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1600 x 1100 mm pressure of drawing cushion in ram:20 t stroke of drawing cushion in ram:100 mm drawing cushion area in ram:300 x 300 mm side window:600 x 1100 mm table height over floor:750 mm ram surface:1600 x 1100 mm oil volume:1500 l power requirement:110,0 kW weight:35,0 t dimensions (WxDxH):4,65 x 2,61 x 5,5 m height over floor:5,05 m height beneath floor:0,45 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in ram:hydraulic ram interlocking:pneumatic cutting impact cushioning:hydraulic

pressure:160 t throat:360 mm stroke:200 mm distance table/ram, max. stroke up, adjustment up:500 mm table surface area:920 x 700 mm Hole in the table:150 mm table height over floor:960 mm passage to the back:590 mm ram surface:620 x 560 mm speed down:390 mm/s speed up:390 mm/s working speed:58 mm/s power requirement:30,0 kW weight:16,0 t dimensions (WxDxH):1,6 x 2,5 x 3,6 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanisch

pressure:2000 t distance between columns:975 mm stroke:400 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1015 x 1050 mm table height over floor:800 mm capacity of ejector in table:6,3 t ejector stroke in table:100 mm capacity of ejector in ram:65 t ejector stroke in ram:100 mm ram surface:975 x 1050 mm return capacity:150 t speed down:235 mm/s speed up:250 mm/s working speed:5 - 20 mm/s oil volume:4000 l height over floor:3,65 m height beneath floor:3,75 m power requirement:194,0 kW weight:105,0 t dimensions (WxDxH):5,0 x 6,5 x 7,4 m

pressure:125 t throat:340 mm stroke:20 - 160 mm no. of strokes:55 /min distance table/ram, max. stroke up, adjustment up:480 mm table surface area:1000 x 660 mm table height over floor:730 mm ram surface:600 x 300 mm ram adjustment:75 mm power requirement:8,5 kW weight:7,8 t dimensions (WxDxH):1,4 x 2,8 x 2,7 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical

pressure:160 t throat:500 mm stroke:200 mm distance table/ram, max. stroke up, adjustment up:500 mm table surface area:1140 x 980 mm hole in the table:180 mm table height over floor:860 mm ram surface:1000 x 800 mm oil volume:1000 l power requirement:50,0 kW weight:18,0 t dimensions (WxDxH):1,3 x 2,6 x 3,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanical cutting impact cushioning:hydraulic

pressure:200 t distance between columns:1100 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1100 mm table surface area:1000 x 1000 mm pressure of drawing cushion in table:63 t stroke of drawing cushion in table:250 mm die cushion area:800 x 750 mm table height over floor:800 mm ram surface:1000 x 1000 mm Speed down:400 mm/s speed up:250 mm/s working speed:22 - 56 mm/s power requirement:45,0 kW weight:24,0 t dimensions (WxDxH):2,4 x 1,5 x 5,9 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic

pressure:035 t throat:240 mm stroke:4 - 70 mm no. of strokes:120 /min distance table/ram, max. stroke up, adjustment up:400 mm table surface area:580 x 440 mm hole in the table:200 x 170 mm table height over floor:670 - 820 mm table adjustable:150 mm ram surface:300 x 175 mm ram adjustment:50 mm power requirement:3,0 kW weight:2,3 t dimensions (WxDxH):1,2 x 1,4 x 2,1 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:hydraulic overload protection in ram:mechanical

pressure:63 t throat:325 mm stroke:560 mm distance table/ram, max. stroke up, adjustment up:700 mm table surface area:640 x 640 mm pressure of drawing cushion in table:25 t stroke of drawing cushion in table:200 mm die cushion area:450 x 450 mm table height over floor:800 mm ram surface:560 x 560 mm oil volume:450 l power requirement:15,0 kW weight:7,0 t dimensions (WxDxH):1,2 x 2,0 x 3,1 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic

pressure:100 t throat:320 mm stroke:160 mm distance table/ram, max. stroke up, adjustment up:480 mm table surface area:630 x 550 mm hole in the table:200 mm table height over floor:860 mm ram surface:560 x 450 mm oil volume:500 l power requirement:30,5 kW weight:6,4 t dimensions (WxDxH):1,6 x 2,0 x 2,9 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact cushioning:hydraulic depth stop:mechanical

pressure:500 t distance between columns:1220 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1600 x 1200 mm pressure of drawing cushion in table:320 t stroke of drawing cushion in table:150 mm drawing cushion surface in table:750 x 625 mm pressure of drawing cushion in ram:180 t stroke of drawing cushion in ram:100 mm drawing cushion area in ram:750 x 625 mm ram surface:1600 x 1200 mm table height over floor:800 mm speed down:665 mm/s speed up:530 mm/s working speed:34 - 100 mm/s quantity of oil:2000 l power requirement:180,0 kW weight:40,0 t Dimensions (WxDxH):3,2 x 2,4 x 7,5 m Depth of foundation pit:4,1 m Height above floor:5,55 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

pressure:63 t throat:280 mm stroke:160 mm Distance table/ram, max. stroke up, adjustment up:360 mm table surface area:560 x 490 mm hole in the table:125 mm table height above floor:860 mm ram surface:280 x 280 mm power requirement:22,0 kW weight:3,6 t dimensions (W x D x H):0,8 x 1,7 x 2,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

pressure:315 t distance between columns:1750 mm stroke:700 mm distance table/ram, max. stroke up, adjustment up:1200 mm table surface area:1600 x 1500 mm pressure of drawing cushion in table:125 t stroke of drawing cushion in table:200 mm die cushion area:1200 x 1400 mm table height over floor:750 mm ram surface:1640 x 1500 mm power requirement:55,0 + 11,0 kW weight:29,5 t dimensions (WxDxH):3,2 x 4,5 x 5,8 m Height above floor:5,1 m German Safety: permitted for manual loading:CE-Norm - EN 692, BGR 500 drawing cushion in table:hydraulisch cutting impact absorption:hydraulic

pressure:315 t distance between columns:1800 mm stroke:400 mm Distance table/ram, max. stroke up, adjustment up:650 mm table surface area:1800 x 1000 mm table height over floor:900 mm die cushion pressure in table:80 t die cushion stroke in table:100 mm Die cushion area in table:1300 x 600 mm side window:600 mm ram surface:1800 x 1000 mm speed down:400 mm/s speed up:300 mm/s working speed:15 - 80 mm/s oil volume:1700 l power requirement:55,0 kW weight:27,5 t dimensions (WxDxH):3,1 x 2,2 x 4,6 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 die cushion in table:hydraulic foundation pit:not necessary

pressure:63 t throat:270 mm stroke:160 mm Distance table/ram, max. stroke up, adjustment up:360 mm table surface area:560 x 490 mm hole in the table:280 x 190 mm table height above floor:850 mm ram surface:450 x 360 mm oil volume:360 l power requirement:23,0 kW weight:4,6 t dimensions (W x D x H):1,2 x 1,8 x 2,9 m

pressure:40 t throat:285 mm stroke:500 mm Distance table/ram, stroke up:630 mm table surface area:560 x 560 mm pressure of drawing cushion in table:16 t stroke of drawing cushion in table:200 mm die cushion area:425 x 425 mm table height over floor:800 mm ram surface:450 x 450 mm power requirement:11,0 kW weight:4,0 t dimensions (WxDxH):1,15 x 1,8 x 2,85 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 light guard:Sick

pressure:160 t distance between columns:1360 mm stroke:300 mm Distance table/ram, max. stroke up, adjustment up:620 mm table surface area:1300 x 900 mm table height over floor:950 mm side window:640 mm ram surface:1300 x 900 mm power requirement:45,0 kW weight:16,0 t Dimensions (WxDxH):2,5 x 2,1 x 4,1 m cutting impact cushioning:hydraulic

pressure:315 t distance between columns:1290 mm stroke:700 mm distance table/ram, max. stroke up, adjustment up:950 mm table surface area:1250 x 1100 mm pressure of drawing cushion in table:125 t stroke of drawing cushion in table:300 mm die cushion area:900 x 900 mm Capacity of ejector in ram:20 t Stroke of ejector in ram:250 mm table height over floor:800 mm ram surface:1250 x 1100 mm oil volume:1200 l power requirement:40,0 kW weight:22,0 t dimensions (WxDxH):2,6 x 1,6 x 5,2 m height over floor:4,05 m drawing cushion in table:hydraulic ejector in ram:hydraulic cutting impact cushioning:hydraulic

Universal horizontal milling machine – FRITZ WERNER German-made machine tool renowned for its robustness. Universal horizontal milling machine ideal for surfacing, grooving and tooling work. Heavy cast iron construction for excellent stability. Features: Brand: Fritz Werner Type: Universal horizontal milling machine 3-axis cross-table with rotation Horizontal spindle with cutter holder Prismatic slides Integrated mechanical feed box (gears visible in photo) Siemens motor with 400–500 V power supply Manual handwheel controls Disassembled side cover supplied with the machine Complete machine with levers, handwheels and guards Estimated dimensions: Table: approx. 700 × 250 mm Estimated weight: 900 – 1200 kg Status: Antique but functional machine, ideal for mechanical workshop, restoration, or machine tool collector. Wear consistent with age.
