Catalog No. 6822 TECHNICAL DATA - max width of the workpiece 230mm - max height of the workpiece 130mm 5 spindles: 1) horizontal bottom 230mm 5.5kW 2) vertical right 130mm 3) vertical left 130mm; (2nd and 3rd spindle) 7.5kW 4) horizontal top 230mm 5.5kW 5) universal spindle 230mm, right/left rotation adjustment 5.5kW - all spindles adjustable up / down, right / left - all spindles equipped with an electric brake - spindle diameter 40mm - from above, 4 metal, toothed introductory rollers - 3 pulling rollers from above, rubber, smooth, including 2 double - from the bottom, a rubber roller, pulling - side pressure from below - 2 types of feed speed - feed motor 1.2 kW - electric setting of planing thickness - length of the introductory tabletop 2500mm - locked in the cabin - central lubrication of the countertop - diameters of the extraction spigot 150mm, 4x120mm - ...

Type: 1594 Chamber width: 1400 mm Chamber height: 830 mm Chamber depth: 2500 mm 220V 136 amp 45 kW Max temperature: 400° C Power needed: 45 kW Voltage: 220V

Four-jaw chuck, four-jaw lathe chuck, precision four-jaw chuck, chuck, faceplate, 4-jaw chuck -Manufacturer: Röhm, Precision four-jaw chuck Ø 260 mm -Passage: Ø 70 mm -Bolt circle: Ø 105 mm -Recording: Short cone 5 -Jaws: individually and fully adjustable -Weight: 27.4 kg

– German production – year of manufacture 1990 – for wet wood TECHNICAL PARAMETERS: planing width max. 310 mm planing height on both sides 300 mm planing height four-sided 100 mm spindle diameter 30 mm shaft motor power 2 x 11 kW spindle motor power 2 x 7.5 kW feed speed 14-86 m/min feed speed adjustable on the variator four upper pulling shafts two lower pulling shafts four rollers in the auxiliary countertop brake minimum element length 600 mm machine dimensions (L/W/H) 290 / 170 / 210 cm weight ~ 3500 kg

Four-jaw chuck, four-jaw lathe chuck, 4 jaw chuck -Manufacturer: Rohm, four-jaw chuck Ø 315 mm -Throughout: Ø 105 mm -Pole circle: Ø 235 mm / M20 -Take: short taper 11 -Weight: 56 kg

Four-jaw chuck, four-jaw lathe chuck, 4 jaw chuck -Manufacturer: Rohm, four-jaw chuck Ø 315 mm -Passage: Ø 103 mm -Hole circle: Ø 195 mm -Weight: 56 kg

Four-jaw chuck, four-jaw lathe chuck, 4 jaw chuck -Four-jaw chuck: Chuck size: Ø 250 mm with tube turning device -Throughout: Ø 80 mm -Pitch circle: Ø 226 mm -Weight: 25 kg

Four-jaw chuck, four-jaw lathe chuck, 4 jaw chuck -Manufacturer: Roto Record, four-jaw chuck Ø 315 mm -Throughout: Ø 98 mm -Hole circle: Ø 290 mm -Weight: 30 kg

KUPFERMUHLE four-sided planer with additional table, multi-saw 600x200mm - after technical inspection - German production - DOUBLE-SIDED PLANING HEIGHT 200 mm - ideal for wet wood - electric height adjustment - double feed chain - additional preliminary table with a 340 mm head - additional material feed systems TECHNICAL PARAMETERS: planing width 600 mm cutting height on both sides planing height on four sides 200 mm 100mm power of vertical spindle motors 2 x 5.5 kW lower shaft motor power 7.5 kW upper shaft motor power 11 kW engine power of the first head 4 kW multi-saw engine power 15 kW adjustable vertical heads four upper pulling rollers three lower pulling rollers two receiving pull rollers 4 knives per shaft, shaft diameter 145mm six types of feed speeds 7 / 9 / 11.5 / 14 / 18 / 23 m/min 2 rows of anti-kickback pawls spindle diameter 40 mm disc  ...

Apple Engineering Four head pneumatic depositor Model: MD Serial: MC13611 four head depositor, individual controlled heads, on mobile height adjustable frame

– German production –DTR – for wet wood – hydrohebel TECHNICAL PARAMETERS: planing width 230 mm planing height 160 mm rollers in the countertop pulling spindle diameter 1-4 - 40 mm spindle diameter 5-6 - 50 mm 1 bottom spindle 7.5 kW 2 right spindle 7.5 kW 3 left spindle 7.5 kW 4 upper spindle 7.5 kW 5 bottom spindle 7.5 kW 6 upper spindle 7.5 kW feed motor power 4 kW feed adjustable smoothly on the inverter 5-26 m/min jointers on the last two heads five upper steel pulling rollers four top rollers rubber pulling four rollers in the countertop pulling pneumatic pressure feed on cardan shafts electric brakes electric height adjustment length of the pre-worktop 1950 mm connection diameter 140 mm dimensions of the machine (L/W/H) 685 / 230 / 230 cm weight 4000 kg

Locker, lockers, closet, four locker -Dimensions: W1230/D500/H1850 mm -Four door

Four-sided planer WEINIG PROFIMAT 22N. No 4 –DTR – German production – year of manufacture 1988 – adjustable heads TECHNICAL PARAMETERS: planing width 220 mm planing height 120 mm spindle diameter 40 mm 1) bottom head 5.5 kW 2) head of the law 3) left head 7.5 kW 4) top head 7.5 kW feed engine 2.2 kW feed speed 6 – 20 m/min four steel top pulling rollers one upper rubber pulling roller one pulling roller in the countertop feed on cardan shafts electric height adjustment pre-table top length 1975 mm central lubrication pneumatic clamps dimensions of the machine (length / width / height) 350 / 200 / 170 cm weight ~ 1800 kg

Four-sided planer Weinig Hydromat H25N with feeder 100 m/min - German production - hydraulic feed up to 100 m / min - for wet wood - serving table TECHNICAL PARAMETERS: planing width 250 mm planing height 190 mm spindle diameter 50 mm electric height adjustment 1 bottom spindle 15 kW 2 right spindle 7.5 kW 3 left spindle 15 kW 4 right spindle 7.5 kW 5 upper spindle 7.5 kW 6 upper spindle 15 kW 7 bottom spindle 7.5 kW 8 x universal spindle 1800 7.5 kW infinitely adjustable feed rate up to 100 m/min feed pump motor power 22 kW nine rollers in the pulling countertop, three of which in front of the first head seven steel pulling upper rollers four upper rubber pulling rollers pneumatic clamping 1-6-7 spindle joint automatic countertop lubrication feeding table 3000 mm Speed adjustable smoothly up to 100 m/min two upper pneumatic rollers six bo ...

Precision four-jaw chuck, chuck, face plate, 4-jaw chuck -Manufacturer: WMW Niles, four-jaw chuck type DHK-B/8-250x4 -Chuck size: O 250 mm -Passage: O 80 mm -Bolt circle: O 135 mm -Intake: short taper 6 -Weight: 35kg

Precision four-jaw chuck, chuck, face plate, 4-jaw chuck -Manufacturer: Rohm, precision four-jaw chuck O 260 mm -Throughout: Ø 70 mm -Hole circle: Ø 170 mm -Shot: short taper 8 -Beeks: individually and completely adjustable -Weight: 39 kg

Four-jaw chuck, four-jaw lathe chuck, 4 jaw chuck -Type: DH250x4/TGL30-2332 -Chuck size: Ø 250 mm -Throughout: Ø 80 mm -Rezess: Ø 210 mm -Hole circle: Ø 230 mm -Number: 3x available -Price: per piece -Weight: 18 kg

Four-jaw chuck, four-jaw lathe chuck -Chuck size: Ø 250 mm -Rezess: Ø 210 mm -Hole circle: Ø 230 mm -Throughout: Ø 80 mm -Weight: 19 kg

Four-jaw chuck, four-jaw lathe chuck -Chuck size: Ø 230 mm -Rezess: Ø 195 mm -Hole circle: Ø 210 mm -Passage: Ø 70 mm -Weight: 20 kg

Four-jaw chuck, four-jaw lathe chuck -Lining size: Ø 250 mm -Passage: Ø 80 mm -Weight: 19 kg

Four-jaw chuck, 4-jaw chuck -Four-jaw chuck: chuck size Ø 190 mm -Passage: Ø 60 mm -Hole circle: Ø 170 mm -Weight: 9.3 kg

Four-sided planer REX HOMS-410 – made in Germany – for wet wood TECHNICAL PARAMETERS: planing width max. 410 mm planing height on both sides 200 mm planing height on four sides 200 mm spindle diameter 40 mm shaft motor power 2 x 11 kW spindle motor power 2 x 5.5 kW feed speed infinitely adjustable feed speed adjustable on the inverter three upper pulling rollers three lower pulling rollers two auxiliary rollers in the table top brake minimum workpiece length 450 mm dimensions of the machine (length/width/height) 250 / 220 / 180 cm weight ~ 3500 kg

REX U 41K four-sided planer - German production - DTR - numerical control - year of production 1997 - milling heads - for wet wood - total power 51.5 kW TECHNICAL PARAMETERS: - planing width 410 mm - planing height on 2nd and 4th side 260 mm - electronic adjustment of planing height and width with the possibility of programming fixed dimensions 1 lower shaft 7.5 kW 2 upper shaft 11 kW 3 right spindle 7.5 kW 4 left spindle 11 kW milling units 2 x 1.85 kW - feed smoothly adjustable electrically - feed speed range 5-30 m/min - 3 kW feed motor - five pull rollers in the tabletop - two auxiliary rollers in the tabletop - five upper pulling rollers - four pressure rollers on vertical spindles - pneumatic side pressure of the material - adjustable heads - adjustable lower shaft - minimum material length 400 mm Transport dimensions 420 x 230 x 230 cm weight ~ 5  ...

Weinig Unimat 30 EL four-sided planer - German production - year of production 2001 - for wet wood - pneumatic cushion - counter reading 4808 h - DTR TECHNICAL PARAMETERS: - planing width 300 mm - planing height 200 mm - spindle diameter 50 mm 1 lower spindle 11 kW 2 right spindle 11 kW 3 left spindle 11 kW 4 upper spindle 11 kW cutter adjustable at an angle of 0.75 kW 5 lower spindle 15 kW 6 upper spindle 11 kW - jointer 7 lower spindle 7.5 kW - jointer - spindles with brakes - feed motor 7.5 kW - feed speed smoothly adjustable 6-36 m/min - four pull rollers in the tabletop - six upper steel pulling rollers - three upper rubber pulling rollers - feed on cardan shafts - pneumatic pressure - air cushion in the countertop - automatic central lubrication - minimum element length 700 mm - diameter of connectors 5 x 160 mm, 2 x 140 mm, 1 x 80 mm Machine di ...

FOUR SIDED PLANER model WEINIG PROFIMAT P 23 E with 5 spindles second hand machine working condition : Excellent CE mark : Yes volt. 380/50 grooved table ( removable ) quick tool locking device with tools : Yes , as in video Composed by 5 spindles , 4 motors : 1° spindle : planer . motor power Hp 5,5 ( Kw 4 ) 2° and 3° spindles : right and left vertical . motor power Hp 7,5 ( Kw 5,5 ) 4° spindle : thickness planer . motor power Hp 10 ( Kw 7,5 ) 5° spindle : planer . motor power Hp 5,5 ( Kw 4 ) grooved table ( removable ) quick tool locking device Technical details : forward motor power Hp 4 ( Kw 3 ) shaft rotation speed rpm 6000 feed speed : from 5 to 24 mt./min. max. useful working width mm. 230 max. useful working height mm. 120 shaft diameter mm.40 inlet length mm. 2000 automatic lubrication system electric height adjustment set of service keys / d ...

Four head paper driller Nagel Model Citoborma 480 AB Year 1988 Details 4 head paper driller with adjustable heads with tabulator Operation Electric Available Direct

Doka four-way head H20 - galvanized Ceiling support head for the support and stabilization of doka formwork carriers. Weight 4kg Length 25cm Width 20 Height 33 Doka 4-way head H20 - galvanized Floor-prop head for supporting and stabilising Doka formwork beams. Weight: 4kg Lenght: 25cm Width: 20 cm Height: 33 cm

a hydraulic four-column press Exner, type H4 SP 450, Y.O.M. 1983, pressure 450 to., side windows 475 mm. Installation height 600 mm, table area 1100 x 850 mm, impact area 300 mm, stroke 200 mm. Dimensions 3100mm x 2100 mm, depth 1,980 mm. Weight 13 to. ]

Hydraulic four-roll plate bending machine Fabr. Haeusler type VRM HY 2000-6Machine number: 1186-1968, built in 1968Max. Working width approx. 2040 mmMax. Druchgang approx: 2100 mmMax. Sheet thickness with bend: 6 mmUpper and lower roller diameter each approx: 250 mmSide roller diameter approx.: 200 mmStroke of rollers approx. Each: 220 mm2 working speedsTotal drive power approx: 18 KWWorking height approx: 1300 mmSpace required: L 5450 x D 1900 x H1930 mmWeight approx: 10500 kgWith:- Both side rollers with mot. delivery for bending + conical bending- hydr. Folding bearing for removing the sheet metal- Slip clutch- Right-left purchase- separate control panelused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are ...

Four-sided planing machine Harbs 250 x 150 mm 7 spindles 350 hours of uptime 3 m1 dressing table 8 newly rubberized feed rollers Grooved bed The machine is practically as good as new, ready for operation Changes, errors, intermediate sale reserved ! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system + technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Phone 0041 62 966 18 32 fax 0041 62 966 21 12

Four rollers calander make OMEC Mod. FX4 190 1330 x2.5 / 3.0 Year 2019 NEVER USED - PRACTICALLY NEW Siemens CNC.

I sell the four-side planer Futura P-MAX 23/5+UNIV, built in 2008. 6 Spindle: bottom - right - left - top - bottom - universal Electronic programming for working width, working height and feed speed. Element max. 230x170mm ! All 6 spindles 6000 rpm. Material prints for short elements. Weight 2500kg. 1-zone pneumatic material pressure system for feed Fully operational. Available the same. Exhibition machine, has worked very little !

I sell the four-sided planer FUTURA PRG24/7, Year of construction 2005. Element size max. 260x150mm ! 7 Spindle Configuration: Bottom 7,5kW (10HP) / 6000 rpm Right 7,5kW (10HP) / 6000 rpm Left 7,5kW (10HP) / 6000 rpm Top 7.5kW (10HP) / 6000 rpm Top 6.75kW (9HP) / 6000 rpm Right 6,75kW (9HP) / 6000 rpm Universal 7,5kW (10HP) / 6000 rpm Combined power 62KW / 102 A Weight 4500kg. Element size max. 260x150mm ! 2 FABA planing heads with spiral knife fi.140x260x40mm included in the price. Electronic programming for working width, working height and the height of pressure zone Feed speed adjustable with inverter. 2-zone pneumatic material pressure system for feed Available the same.

Older four-roll round bending machine make unknownTechnical specifications:Working length: 1000 mmRoll diameter: 100 mmmax.sheet thickness: 3-4 mmExternal dimensions L x W x H: 2550 x 1250 x 1250 mmWith:- Swiveling top rollerusedPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

Four-roller bending machine make FACCIN type 4 HCI/V2100X6/4Ser-No: 87100480-0526Technical specifications:max. bending length: 2100 mmBending sheet thickness: 6.0 mmRoller diameter: 185mmDrive power: 5.5 kWWeight approx.: 6000 kgDimensions approx.: 1500 x 1500 x 4000 mmused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

Four-jaw chuck, 4-jaw chuck -Chuck size: Ø 190 mm -Passage: Ø 57 mm -Weight: 10 kg

Four-jaw chuck, 4-jaw chuck -Chuck size: Ø 195 mm -Passage: Ø 62 mm -Weight: 9 kg

Four-jaw chuck, 4-jaw chuck -Chuck size: Ø 153 mm -Passage: Ø 40 mm -Weight: 7 kg

Heavy four-sided combined calibration milling planing machine with additional scratch saw for relief grooves Still in operation at Franz Kirnbauer KG Hauptstrasse 2 AT-2630 Ternitz Detailed technical description in the PDF document (as an attachment in the photo gallery).

Order No. 6716 TECHNICAL DATA - max planing width 510mm - maximum planing height on both sides 190mm - maximum four-sided planing height 130mm from down: - guide rails - preliminary table, adjustable - smooth skid roller - 510mm planing shaft, 4-knife 5.5kW - 2 smooth, sliding shafts - adjustable rollers in the lower table top in advance: - pulling shaft, toothed - pressure - pulling shaft, toothed 2 pcs - pressure - 520mm planing shaft, 4-knife approximately 7.5kW - pressure - pulling shaft, smooth - pressure in the back: - side spindles 2 pieces - 1.right, vertical 130mm 4kW - 2nd left vertical 130mm 4kW - manual spindle feed - diameter of the spindles 40mm - adjustable spindles up / down, right / left - the axes are positioned alternately - side clamp 2 pcs - locking spindles - 2 types of feed speed + smooth about 3kW - diameter of the extraction conn ...

–DTR – German production – electric adjustment of the left head – adjustable spindles TECHNICAL PARAMETERS: planing width 220 mm planing height 120 mm spindle diameter 40 mm 1) bottom head 4 kW 2) right head 3) left head 5.5 kW 4) top head 4 kW 5) universal head 360° 4 kW feed motor 2.2 kW feed speed 5 – 20 m/min four steel pulling rollers two top rollers pulling rubber one pulling roller in the countertop feed on cardan shafts electric height adjustment length of the pre-worktop 1970 mm central lubrication pneumatic clamps dimensions of the machine (L/W/H) 380 / 200 / 170 cm weight ~ 2000 kg

– German production – year of manufacture 2002 –DTR TECHNICAL PARAMETERS: planing width 230 mm planing height 170 mm 1 bottom spindle 7.5 kW 2 right spindle 7.5 kW 3 left spindle 7.5 kW 4 upper spindle 7.5 kW 5 bottom spindle 7.5 kW 6 upper spindle 7.5 kW spindle diameter 40 mm electric height adjustment five steel top rollers four rubber top rollers pneumatic pressure table top length 1980 mm central lubrication feed adjustable on the inverter 6-26 m/min feed on cardan shafts feed motor power 4 kW connection diameter 140 mm machine dimensions (L/W/H) 520 / 210 / 210 cm weight 4000 kg

–DTR – German production – electric adjustment of the left head – adjustable spindles TECHNICAL PARAMETERS: planing width 220 mm planing height 120 mm spindle diameter 40 mm 1) bottom head 5.5 kW 2) right head 3) left head 7.5 kW 4) top head 5.5 kW 5) universal head 360° 5.5 kW feed motor 2.2 kW feed speed 5 – 20 m/min four steel pulling rollers two top rollers pulling rubber one pulling roller in the countertop feed on cardan shafts electric height adjustment length of the pre-worktop 1970 mm central lubrication pneumatic clamps dimensions of the machine (L/W/H) 380 / 200 / 170 cm weight ~ 2000 kg

Four side planer Griggio G240 P/5U for wet Maximum planing width 240mm Maximum planing height 160mm Number of spindles 5 Spindle arrangement Bottom Rights Left Mountain Universal Drive: in the table Infinitely adjustable feed on the inverter Year 2007 Weight: 4060 CE Certificate Net price

Four-sided planer Weinig Profimat 23E Working width 230mm Working height 120mm Number of spindles 6 Bottom Rights Left Mountain Bottom Universal Spindle diameter 40mm Operating speed 24m/min Pneumatic clamps for pulling rollers Electric pressure beam adjustment Worktop lubrication system Year of Build: 1998

Four-side planer / profile milling machine Fabr. Gubisc Model: 172/1K+R Year of construction: 1981 Planer width: 170mm 5 spindles

Four-way planer Weinig Unimat U 23 (Ref. No. 231-2615) with 7 waves Planer width 130 mm Planing height 140 mm Masch. Item no. 023-161 Year of construction 1991 The machine is in good condition, ready for operation. Subject to change, error, prior sale ! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system+technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Phone 0041 62 966 18 32 fax 0041 62 966 21 12

Four-side planer with 4 planing heads •Powerful with 4 motors Hsvwvkytm Voltage 400 V / 3 / 50 Hz Motor power 17,1 kW finished workpiece width 180 mm min. finished workpiece width 25 mm finished workpiece thickness 105 mm min. finished workpiece thickness 10 mm min. length of the workpiece - for single feed 350 mm - at group feed 250 mm Number of working spindles 4 Spindle speed 6000 min-1 Spindle diameter 40 mm Cutterhead diameter 120 mm Length of horizontal spindles 190 mm Length of vertical spindles 120 mm Feed speed 6; 12 m/min Diameter of feed rollers 120 mm Length of feed table 1700 mm Distance of the feed table from the floor 920 mm Quick adjustment of the feed table and ruler 10 mm Weight 1000 kg

Four-sided planer Paolini Master 23 Working width 230mm Working height 120mm Number of spindles 5 Spindle arrangement Bottom 7.5kw Right 7.5kw Left 7.5kw Top 9kw Universal 7.5kw Spindles adjustable in two planes Spindles fi 40mm Pulling rollers on pneumatics Feed rate adjustable on variator up to 35m/min CE Certificate Weight 3000kg
