fine blanking used for sale

pressure:600 t distance between columns:3640 mm stroke:350 mm no. of strokes:11 - 44 /min Distance table/ram, max. stroke up, adjustment up:1550 mm table surface area:3600 x 2500 mm sliding table:3600 x 2500 mm ram surface:3600 x 2500 mm Side window:2200 mm ram adjustment:400 mm material width coil line:500 - 1950 mm Material thickness at 1200 mm material width:0,6 - 2,5 mm Material thickness at 1850 mm material width:0,6 - 2,0 mm Material thickness at 1950 mm material width:0,6 - 1,75 mm Coil weight:35,0 t coil internal diameter:610 mm coil external diameter:900 - 1900 mm no. of straightening rolls:13 straightening roll diameter:50 mm Stack height:400 mm stacking dimensions - station 1+2 (L x W):150-2000 x 250-2000 mm stations:2 power requirement:112,0 + 35,0 kW Weight:390,0 t Dimensions (WxDxH):7,3 x 5,1 x 15,0 m Height above floor:9,1 m Height below floor:5,9 m clutch-/ brake combinat ...

DMG Mori Seiki LaserTec 50 FineCutting Sauer CNC Laser Precision Machine Year / Model: 2019 Control: Celos with Siemens 840D sl Operate CELOS with Siemens 840D sl Operate including 2l .5 ERGOline Control with multi-touch screen CNC Laser Precision Machine with High Speed Machining LASERTEC 50 FineCutting for laser fine cutting, laser drilling, laser welding NC swivel rotary table highly dynamic and precise Travel: 500 mm x 500 mm x 700 mm travel integrated ytterbium cw fiber laser 450W qcw ytterbium fiber laser with 4500W Pulse peak power and 450 W power Processing head (80 mm focal length), 5-axis transformation 100 working hours (new-new) Kaufpreis neu/Buying price in year 2020: 890.000,- Eur, Made in DMG Germany. Included: Fanuc robot automation + Keller autom. Extraction system solid machine base frame made of mineral casting, Camera through optical path for fib ...

This 3-axis DMG Sauer Lasertec80 FineCutting was manufactured in 2006. It features an X-axis travel of 800 mm, Y-axis travel of 500 mm, and Z-axis travel of 700 mm. The machine is equipped with a Siemens SINUMERIK 840D Powerline control and a high-precision cross table with linear drives. If you are looking to get high-quality laser fine cutting capabilities, consider the DMG Sauer Lasertec80 FineCutting machine we have for sale. Contact us for further details.

ID3642 Nordberg G11 Fine year/Baujahr 2000 Cone crusher, 160 KW electric motor, with spare cone and casing, with inlet trough Cone crusher, 160 KW electric motor, with spare cone and jacket, with inlet tank

General SKU294W552 LocationBarneveld CEcheck MakeAmersham TypeFineLine 200 PL Main Features MaterialStainless steel Specified Features - Miscellaneous filter Filtercheck MaterialStainless steel 1.4404 (316L) General No.20003970 Year of construction2005 Mounted on wheelscheck Floor space0,60 x 0,60 m Total height2,50 m Weight80 kg ATEX designedcheck Extra information Column volume 23 l., allowable pressure 20 bar g, test pressure 28,6 bar g. Inner dia. 200 mm, inner length 700 mm  Powdered foodsGeneric medicinesOintmentsTea, herbs & coffeeFine chemicalsStarchOther chemicalRubberBiotechnologyAgrochemicalsSpicesPlastic & polymersCatalysts & fillersFeed additivesPaper & otherSolventsDetergent & surf.Other pharmaceuticsCosmeticsOrganicsE-waste & metalFood additivesSugarLubricants & oleoDairyAnimal feedOther feedConfectionerySolid pharmaceuticsBeveragesDyes & pigmentsBiop ...

General SKUR0380 MakeAlpine Ultraplex LocationBarneveld Type500 UP beater plate Main Features Motor30 KW Inlet diameter450 mm Width150 mm Specified Features - Fine Impact Mill Grindercheck Grinding room sizedia. 450x150mm Inlet170x100mm Motor30 kW 400 Volt Fine Impact Mills MaterialMild steel General No.141724 Year of construction1970 Floorspace1,1x0,9 M Total height1,1 M Weight1020 KgPowdered foodsGeneric medicinesStarchAgrochemicalsSpicesPlastic & polymersFine Impact MillsCatalysts & fillersFeed additivesDetergent & surf.CosmeticsOrganicsE-waste & metalFood additivesSugarAnimal feedConfectionerySolid pharmaceuticsDyes & pigmentsBiopharmaceuticalPlastic & rubberMinerals & inorganicPaints & coatingsConsumer wasteAlpineIndustries > Food & Feed > Powdered foodsIndustries > Pharmaceutical > Generic medicinesIndustries > Food & Feed > StarchIndustries > Chemical > Agroc ...

General SKUR0378 MakeAlpine Ultraplex LocationBarneveld Type500 UP beater plate Main Features Motor30 KW Inlet diameter450 mm Width150 mm Specified Features - Fine Impact Mill Grindercheck Grinding room sizedia. 450x150mm Inlet170x100mm Motor30 kW 380/660 Volt Speed4500 rpm Fine Impact Mills MaterialMild steel General No.135101 Year of construction1966 Floorspace1,0x0,9 M Total height1,1 M Weight600 kgPowdered foodsGeneric medicinesStarchAgrochemicalsSpicesPlastic & polymersFine Impact MillsCatalysts & fillersFeed additivesDetergent & surf.CosmeticsOrganicsE-waste & metalFood additivesSugarAnimal feedConfectionerySolid pharmaceuticsDyes & pigmentsBiopharmaceuticalPlastic & rubberMinerals & inorganicPaints & coatingsConsumer wasteAlpineIndustries > Food & Feed > Powdered foodsIndustries > Pharmaceutical > Generic medicinesIndustries > Food & Feed > StarchIndustries  ...

General SKU227S107 MakeHosokawa Alpine (D) LocationBarneveld CEcheck TypeLGM 20 ( Long Gap Mill ) Main Features Motor500 KW Specified Features - Fine Impact Mill Grindercheck Rotor sizeDia. 1950x800 mm Grinding room sizeDia. 2000x760 mm With hoppercheck InletScrew (Schneckenbau Prestel) (2x dia. 125mm) Motor500 kW 400 Volt Speed1100 rpm Fine Impact Mills MaterialMild steel General No.P1172095 Year of construction2009 Floorspace4,9x2,4 m Total height3,0 m Weight22000 kg ATEX designedcheck Extra Specificationsincluding Reitz fan type KXE 160-063030-00 (2009) 630 m3/h 2980 rpm 200 kW 400/690 voltsincluding cyclone and heating unit with burner monitoring (as is )Powdered foodsGeneric medicinesStarchAgrochemicalsSpicesPlastic & polymersFine Impact MillsCatalysts & fillersFeed additivesDetergent & surf.CosmeticsOrganicsE-waste & metalFood additivesSugarAnimal feedConf ...

General SKU316X529 LocationBarneveld Main Features Motor30 KW Inlet diameter170 mm Width550 mm Specified Features - Fine Impact Mill Grindercheck Rotor size530 mm (4 rotors stacked) Grinding room sizeDia 540 mm x 700 mm With grinding platenscheck With hopper250x250x240 mm InletDia. 170 mm Feeding with vibro feedercheck Motor30 kW, 400/690 volt, 1465 rpm Speed2500 rpm Fine Impact Mills MaterialMild steel, Stainless steel General MakeJäckering TypeUnknown Year of constructionUnknown Mounted on framecheck With switchcheck Floor space2,10 x 0,80 m Total height1,70 m Weight1800 kg Extra Specifications- With screw conveyor, 0,37 kW, 230/380 volt, 695 rpm- estimated output 150 kg/h: water evaporation ± 60 kg/hPowdered foodsGeneric medicinesStarchAgrochemicalsSpicesPlastic & polymersFine Impact MillsCatalysts & fillersFeed additivesDetergent & surf.CosmeticsOrganic ...

DMG Mori Seiki LaserTec 50 FineCutting Sauer Laser Machine YOC 2010 Control: Siemens 840 D Power Specifications Max. travel X-axis 540 mm Max. travel Y-axis 500 mm Max. travel Z-axis 700 mm 5-axis laser precision machine for machining diamond tools up to Ø 355 mm and 420 mm in length • Linear actuators in X / Y with an acceleration > 1 g • Highly dynamic torque motors in both rotary axes (B and C axis) • Compact machine design with only 4m² floor space + Keller exhaust air extraction system

General SKU312X491 LocationBarneveld CEcheck MakePallmann Main Features Motor33 KW Inlet diameter120 mm Specified Features - Fine Impact Mill Turbo cone millcheck 2 Driven rotorscheck Rotor sizeInner roter ø 396 mm: outer roter 400 mm With grinding trackConidur 1,5: 2: 3 Housing dimensions ø 800 mm Inletø 120 mm Motor22 kW 400 V, 1470 rpm: 11 kW 400 V, 1475 rpm SpeedInner rotor 3000 rpm, outer rotor 1500 rpm Fine Impact Mills MaterialStainless steel 1.4552 General TypePPS 4-120 No.139820170004 Year of construction2018 Mounted on framecheck Floor space0,9 x 2,8 m Total height1,5 m Weight1600 kgPowdered foodsGeneric medicinesStarchAgrochemicalsSpicesPlastic & polymersFine Impact MillsCatalysts & fillersFeed additivesDetergent & surf.CosmeticsOrganicsE-waste & metalFood additivesSugarAnimal feedConfectionerySolid pharmaceuticsDyes & pigmentsBiopharmaceuticalPla ...

General SKU364X863 LocationBarneveld MakeHosokawa Alpine Main Features Motor37 KW Inlet diameter150 mm Specified Features - Fine Impact Mill Grindercheck With sieve cagecheck Housing dimensions ø 1000 mm With hopper(for a milled product) Inletø 150 mm Motor37 kW (400 V, 2960 rpm) With variable speed drivecheck Speed820—4100 rpm Fine Impact Mills MaterialStainless steel 1.4541 (321) General Type500 UPZ No.P1 187094 Year of construction2011 Mounted on framecheck With switch(as is) With control cabinet(as is) Floor space1,35 x 0,95 m Total height1,0 m Weight960 kg Extra SpecificationsWith: dust filter blower: density 1.17 kg/m³: 45 m³/min: speed: 3000 rpm hopper with gear motor: 0.2 kW, 2730 rpmFor the UPZ 500 we have the following additional items on stock AZO Coolable screw conveyor — SKU: 364X866 DMN Machinefabriek – Rotating valve — SKU: 364X914P ...

General SKU337X769 LocationBarneveld Main Features Motor18.5 KW Width375 mm Specified Features - Fine Impact Mill Turbo millcheck Rotor sizeDia. 375x100 mm Grinding room size750x75 mm With sieve cagecheck Inlet170x110 mm Feeding with rotating valvecheck Motor18,5kW, 400/690V, 2955rpm (EX) Speed+- 1350rpm Fine Impact Mills MaterialMild steel, Stainless steel 1.4552 General MakeKek kemutec Year of constructionunknown Mounted on framecheck Floor space2,2x0,7 m Total height1,65 m Weight850 kg Extra SpecificationsThe housing is made of steel, the rotor is made of stainless steel.with:- dinnissen diverter valve.inlet: 170x110.outlet:170x110 and Dia 75mm- additional parts.Powdered foodsGeneric medicinesStarchAgrochemicalsSpicesPlastic & polymersFine Impact MillsCatalysts & fillersFeed additivesDetergent & surf.CosmeticsOrganicsE-waste & metalFood additivesSugarAnimal fe ...

General SKUR0379 MakeAlpine Ultraplex LocationBarneveld Type500 UP beater plate Main Features Motor30 KW Inlet diameter450 mm Width150 mm Specified Features - Fine Impact Mill Grindercheck Grinding room sizedia. 450x150mm Inlet170x100mm Motor30 kW 380/660 Volt Speed4500 rpm Fine Impact Mills MaterialMild steel General No.162166 Year of construction1981 Floorspace1,1x0,9 M Total height1,1 M Weight720 KgPowdered foodsGeneric medicinesStarchAgrochemicalsSpicesPlastic & polymersFine Impact MillsCatalysts & fillersFeed additivesDetergent & surf.CosmeticsOrganicsE-waste & metalFood additivesSugarAnimal feedConfectionerySolid pharmaceuticsDyes & pigmentsBiopharmaceuticalPlastic & rubberMinerals & inorganicPaints & coatingsConsumer wasteAlpineIndustries > Food & Feed > Powdered foodsIndustries > Pharmaceutical > Generic medicinesIndustries > Food & Feed > StarchIndustries  ...

General SKU245P306 LocationBarneveld MakeHosokawa Alpine Type160 UPZ No.6667 Main Features Motor6 KW Inlet diameter160 mm Specified Features - Fine Impact Mill Grinder:plate beater: Rotor sizedia.160mm Moving hammerscheck With grinding trackcheck Feeding with rotating valvecheck Motor4,9/6 KW, 380 Volt Fine Impact Mills MaterialStainless steel General Year of construction1995 Extra SpecificationsComplete size reduction system including Rotary valve Typ 150 V2A, K-Tron Soder S200 dosing screw, dust filter and AERON filterPowdered foodsGeneric medicinesStarchAgrochemicalsSpicesPlastic & polymersFine Impact MillsCatalysts & fillersFeed additivesDetergent & surf.CosmeticsOrganicsE-waste & metalFood additivesSugarAnimal feedConfectionerySolid pharmaceuticsDyes & pigmentsBiopharmaceuticalPlastic & rubberMinerals & inorganicPaints & coatingsConsumer wasteHosokawa AlpineIndu ...

General SKU312X490 LocationBarneveld CEcheck MakeGörgens Mahltechnik GmbH Dormagen Main Features Motor110 KW Width1000 mm Specified Features - Fine Impact Mill Turbo millcheck Rotor sizeø 1300 x 680 mm Grinding room sizeø 1580 x 1000 mm Inlet1000 x 150 mm Motor110 kW 400 V Speed1100—1700 rpm Fine Impact Mills MaterialStainless steel 1.4301 (304) General TypeG-130 No.247 Year of construction2001 With control cabinet(as is) Floor space2,68 x 1,84 m Total height2,08 mPowdered foodsGeneric medicinesStarchAgrochemicalsSpicesPlastic & polymersFine Impact MillsCatalysts & fillersFeed additivesDetergent & surf.CosmeticsOrganicsE-waste & metalFood additivesSugarAnimal feedConfectionerySolid pharmaceuticsDyes & pigmentsBiopharmaceuticalPlastic & rubberMinerals & inorganicPaints & coatingsConsumer wasteGörgens Mahltechnik GmbH DormagenIndustries > Food & Feed > Powdere ...

JEOL JFC 1100 FINE COAT Ionic Sprayer Untested equipment

This 4-axis Finetech SMV 1060 H3L was manufactured in 2024. It features an impressive X-axis travel of 780 mm, Y-axis travel of 600 mm, and Z-axis travel of 650 mm. The machine includes a robust table size of 1100 x 600 mm and a maximum table load of 700 kg. If you are looking to get high-quality machining capabilities, consider the Finetech SMV 1060 H3L vertical machining centre. Contact us for further details.

General SKU160P705 MakePallmann TypePP 4 No.0668145 Year of construction1968 LocationBarneveld Main Features Motor22.5 KW Inlet diameter155 mm Width100 mm Specified Features - Fine Impact Mill Turbo cone millcheck 2 Driven rotorsimpeller &: co-rotating baffle plate Rotor sizeInner roter ø 396 mm: Outer roter 400 mm Grinding room sizeø 600 Inlet155 x 100 mm Motor15 kW + 7,5 kW, 380 V SpeedMax. 4100 rpm: Grinding disc 1450 rpm Fine Impact Mills MaterialMild steel General With switchgear(as is) Floorspace2,1 x 1,1 m Total height0,8 mPowdered foodsGeneric medicinesStarchAgrochemicalsSpicesPlastic & polymersFine Impact MillsCatalysts & fillersFeed additivesDiscountDetergent & surf.CosmeticsOrganicsE-waste & metalFood additivesSugarAnimal feedConfectionerySolid pharmaceuticsDyes & pigmentsBiopharmaceuticalPlastic & rubberMinerals & inorganicPaints & coatingsConsumer  ...

General SKU041Z170 MakeForplex Chateaubriant TypeFL-4 No.562 Year of constructionunknown LocationBarneveld Main Features Motor75 KW Inlet diameter650 mm Specified Features - Fine Impact Mill Grinder(1x) Rotor sizedia. 650mm With grinding trackdia. 665mm With hoppercheck Inlet320x300mm Motor75,0 KW, 400 Volt Fine Impact Mills MaterialMild steel General Floorspace1,2x1,3 M Total height1,5 M Weight1900 KGPowdered foodsGeneric medicinesStarchAgrochemicalsSpicesPlastic & polymersFine Impact MillsCatalysts & fillersFeed additivesDiscountDetergent & surf.CosmeticsOrganicsE-waste & metalFood additivesSugarAnimal feedConfectionerySolid pharmaceuticsDyes & pigmentsBiopharmaceuticalPlastic & rubberMinerals & inorganicPaints & coatingsConsumer wasteForplexIndustries > Food & Feed > Powdered foodsIndustries > Pharmaceutical > Generic medicinesIndustries > Food & Feed > StarchIn ...

General SKU041Z171 MakeForplex Chateaubriant TypeFL-4 No.561 Year of constructionunknown LocationBarneveld Main Features Motor75 KW Inlet diameter650 mm Specified Features - Fine Impact Mill Grinder(1x) Rotor sizedia. 650mm With grinding trackdia. 665mm With hoppercheck Inlet320x300mm Motor75,0 KW, 400 Volt Fine Impact Mills MaterialMild steel General Floorspacemill 1,2x1,3 M Total height1,5 M Weight1900 KGPowdered foodsGeneric medicinesStarchAgrochemicalsSpicesPlastic & polymersFine Impact MillsCatalysts & fillersFeed additivesDiscountDetergent & surf.CosmeticsOrganicsE-waste & metalFood additivesSugarAnimal feedConfectionerySolid pharmaceuticsDyes & pigmentsBiopharmaceuticalPlastic & rubberMinerals & inorganicPaints & coatingsConsumer wasteForplexIndustries > Food & Feed > Powdered foodsIndustries > Pharmaceutical > Generic medicinesIndustries > Food & Feed > Sta ...

Mains voltage: 3x 400V, 50Hz, fuse protection: 125A slow-blow, maximum connected load: 83kVA, cutting current at 100% duty cycle: 80 to 300A, output voltage: 112 to 200V, rated output current: 300A, duty cycle: 100%, maximum input current: 120A, protection class: IP22, insulation class: F, cooling method: AF (air cooling), no-load power consumption: 1.3kW, maximum operating pressure: 0.55MPa (5.5bar), impulse withstand voltage (Up): 17kV, plasma torch: PB-S80 W, compatible plasma gases: O₂, air, Ar, H₂, compatible swirl gases: air, N₂, length: 1375mm, width: 870mm, height: 1505mm, weight: 556kg. Inspection on site is possible.

General SKU253M221 LocationBarneveld MakeBauermeister &: Co. Norderstedt TypeUT-63 Main Features Motor185 KW Inlet diameter1200 mm Width400 mm Specified Features - Fine Impact Mill Turbo millcheck Rotor sizeDia. 1200x400mm Grinding room sizeDia. 1200x400mm With sieve cage(Pore size ø 220 µm) With grinding trackcheck Housing dimensions 2000x0,55x1800 mm InletDia. 400 mm Motor185,0 KW, 415 Volt Fine Impact Mills MaterialMild steel, Stainless steel 1.4462 (Duplex2205) General No.940785 Year of construction1989 Mounted on framecheck Floor space3,9x1,5 m Total height3,0 m Weight8500 kg Extra information Extra Specifications-- RECONDITIONED --Powdered foodsGeneric medicinesStarchReconditionedAgrochemicalsSpicesPlastic & polymersFine Impact MillsCatalysts & fillersFeed additivesDetergent & surf.CosmeticsOrganicsE-waste & metalFood additivesSugarAnimal feedConfecti ...

FINETECH SMV 1370 H3L ist ein 3-Achsen Bearbeitungszenter, ausgelegt für präzise Bearbeitung mit hoher Genauigkeit und Zuverlässigkeit. Tisch 1450×700 mm (5 T-Nuten, Abstand 100 mm, Breite 18 mm), Tragfähigkeit 1500 kg; Verfahrwege X1300 Y700 Z700 mm; Spindelnase-Tisch 130–830 mm; Magazin 30 Plätze. Stufenlose Drehzahl 0–12.000 min-¹, Eilgang 25 m/min, Spindelmotor 18,5 kW, Gesamtleistungsbedarf 45 kVA; Gewicht ~9000 kg; Abmessungen L4188×B2414×H2560 mm. Ausstattung: Kühlmitteleinrichtung 510 l, Kühlmittel durch Spindel 20 bar, Späneförderer, Spindelölkühler, Spindelkühlung, Zentralschmierung, Schaltschrank-Klima. Ermöglicht enge Toleranzen; geeignet für Automotive, Uhrmacherei, Maschinenbau, Luftfahrt und Medizintechnik. Technische Daten ohne Gewähr

General SKULY008 CEcheck Main Features Motor110 KW Specified Features - Fine Impact Mill Pin disc millcheck 2 Driven rotorscheck Rotor sizeø 630 mm Number of pins on house side:148 / 89 (2 pin rows) Number of pins on door side:228 / 137 (3 pin rows) Pin diameter10 mm (head ø 17 mm), length 75 mm Without sieve cage(screening by external Allgaier tumbler screen) Feeding with rotating valvecheck Motor2x 55 kW With variable speed drivecheck Speedhousing side: 700–3,550 rpm: door side: 700–3,150 rpm Fine Impact Mills MaterialStainless steel 1.4404 (316L), Stainless steel 1.4541 (321) General MakeHosokawa Alpine SerialN1 226486 / 1000 TypeContraplex 630 C — high-speed pin (pin-disc) mill, cold-milling capable, pressure-shock resistant 0.5 bar(g) Year of construction2016 Mounted on framecheck With control cabinetcheck With switchgearcheck Floor space2,24 x 1, ...

General SKU291Y511 MakeCondux TypeCUM 100 No.5988 Year of construction1992 Main Features MaterialStainless steel Shell (Material)Stainless steel Specified Features - Fine Impact Mill Grindercheck Rotor sizeø 95 mm Grinding room sizeø 100 mm With sieve cagecheck Housing dimensions ø 100 mm With hoppercheck Inletø 30 mm Feeding with vibro feedercheck Motorcheck With variable speed drivecheck Speed3000/6000 rpm Fine Impact Mills MaterialStainless steel General LocationBarneveld Mounted on wheelscheck With switchcheck Floor space0,90 x 0,60 m Total height1,60 m Weight200 kgPowdered foodsGeneric medicinesStarchAgrochemicalsSpicesPlastic & polymersFine Impact MillsCatalysts & fillersFeed additivesDetergent & surf.CosmeticsOrganicsE-waste & metalFood additivesSugarAnimal feedConfectionerySolid pharmaceuticsDyes & pigmentsBiopharmaceuticalPlastic & rubberMineral ...

General SKU320Y756 MakeRussell Finex Type25070 No.RA463 Year of construction1996 LocationBarneveld Main Features MaterialStainless steel Surface0.38 m2 Sizes diameter700 mm Specified Features - Vibro sieve Vibro sievecheck Sieve surface0,38 m2 Number of sieve decks:2 Sieve sizesDia. 700 mm With covercheck InletDia. 195 mm Outlet2x 145 mm Drive vibro motor1,5 kW (380 V, 1420 rpm) Sieve perforation125 micron With ultra-sone cleaningvibrasonic With extra sieve decks4x (106:90:63:40 micron) General Mounted on mild steel framecheck With switchcheck Floor space1,00 x1,00 m Total height1,40 m Weight350 kg CEcheckPowdered foodsGeneric medicinesTea, herbs & coffeeStarchRubberBiotechnologyAgrochemicalsSpicesPlastic & polymersCatalysts & fillersFeed additivesPaper & otherDetergent & surf.CosmeticsOrganicsE-waste & metalFood additivesSugarAnimal feedOther feedConfection ...

Russell Finex 17240 Vibratory sieve Stainless compact vibratory sieve, 550mm mesh diameter, with magnetic separator, mobile, 3Ph

Capacity: 250 ton V ? Ring nominal force: 30 - 125 ton Counter ram nominal force: 30 - 125 ton Ram stroke: 64 - 67 mm Table surface area : 560 x 600 mm Slide area: 560 x 560 Number of strokes: 80 s.p.m. Weight of machine approx.: 14.000 kg

FEINTOOL GKP F 160 hydraulic press was built in Switzerland. The automatic fine blanking press combines several workpiece machining stages into one precise process and significantly saves time and effort. As a result of fine blanking, parts with a maximum thickness of 6 mm obtain a characteristic even surface and accurately defined edges that cannot be achieved with other machines. The FEINTOOL GKP-F hydraulic punching press features a robust, stable construction and a total force of 160 tonnes. Offered with the machine a sheet metal feeder with a maximum thickness of 6 mm and a width of 210 mm allows for completely automatic machining. The automatic punching press underwent extensive modernisation in 1999. The total weight of the GKP-F 160 press is 9000 kg. Technical data of the FEINTOOL GKP F 160 fine blanking press - maximum sheet metal thickness: 6 mm - maximum sheet metal wi ...

FEINTOOL GKP F 100T fine blanking press was manufactured in Switzerland in 1974. The machine, distinguished by its robust, stable design, can perform several demanding machining steps in one precise process, saving time and labour. Workpieces with a maximum thickness of 6 mm thus achieve an extremely even surface and precisely defined edges that are impossible to achieve on other machines. The machining process can be fully automated when the FEINTOOL GKP F 100/160 hydraulic blanking press is retrofitted with a sheet metal feeder. The total weight of the machine is approximately 9 tonnes. Technical data of the FEINTOOL GKP F 100T hydraulic press - maximum workpiece thickness: 6 mm - maximum sheet metal width: 210 mm - total force including auxiliary functions: 160 t - shearing force: 100 t - hydraulic counterweight force (upper table): 1-40 t - hydraulic force of ring jaw (lower ...

CONTROLS   PC controller BECKHOFF PRESS DESIGN   drive system: knuckle-joint SLIDE   total force (nominal): 250 to   stroke: 61 mm   stroke rate (max.): 60 /min COUNTER RAM   nominal force: 75 to   stroke: 15 mm V-RING   nominal force: 75 to   stroke: 13 mm TOOL DIMENSIONS   lower table (left-right): 540 mm   lower table (front-back): 540 mm   upper table (left-right): 540 mm   upper table (front-back): 540 mm   shut height max.: 320 mm   ram adjustment: 145 mm   distance between columns (H-frame): 560 mm   passline opening (free passage in side columns): 270 mm STRIP-FEEDER   feeder type: roll feeder   sheet width max.: 250 mm   sheet thickness max.: 10 mm   feeding step max.: 999.99 mm   sheet length min: 1900 mm   pilot release system: yes   band lubrication system: yes Complete refurbished fineblanking press: disassembly into indivi ...

CONTROLS   PLC SIEMENS S7 PRESS DESIGN   drive system: link drive   feedstock transport direction: left to right SLIDE   total force (nominal): 80 to   stroke: 50 mm   stroke rate (max.): 80 /min COUNTER RAM   nominal force: 22 to   stroke: 8 mm V-RING   nominal force: 25 to   stroke: 15 mm TOOL DIMENSIONS   lower table (left-right): 420 mm   lower table (front-back): 420 mm   upper table (left-right): 420 mm   upper table (front-back): 420 mm   shut height max.: 220 mm   ram adjustment: 80 mm   distance between columns (H-frame): 450 mm   passline opening (free passage in side columns): 200 mm OVERALL SPECIFICATIONS (COIL LINES)   sheet width max.: 180 mm   sheet thickness max.: 5 mm   feed velocity max.: 999 m/min STRIP-FEEDER   feeder type: roll feeder   sheet width max.: 180 mm   sheet thickness max.: 5 mm   feeding step max.: 999 m ...

Capacity: 250 - 400 ton V ? Ring nominal force: 20 - 200 ton Counter ram nominal force: 10 - 100 ton Ram stroke: 30 - 200 mm V-Ring stroke: 40 mm Counter ram stroke: 40 mm Daylight: 760 mm Ram surface: 800 x 800 mm Table surface: 810 x 1000 mm Max. die size: 765 x 760 x 610 mm Number of strokes: 40 s.p.m. Approach speed: 120 mm / sec Return speed: 135 mm / sec Working speed: 5 - 50 mm / sec Die Weight total: 2400 kg

CONTROLS   PLC BECKHOFF SLIDE   total force (nominal): 880 to   stroke: 305 mm   cutting velocity min.: 5 mm/s   cutting velocity max.: 70 mm/s   closing velocity: 200 mm/s   returning velocity: 200 mm/s V-RING   nominal force: 400 to   stroke: 40 mm COUNTER RAM   nominal force: 200 to   stroke: 40 mm TOOL DIMENSIONS   lower table (left-right): 1010 mm   lower table (front-back): 1600 mm   upper table (left-right): 1000 mm   upper table (front-back): 1000 mm   shut height max.: 460 mm LEVELLER UNIT   sheet width max.: 400 mm   sheet width (min): 100 mm   sheet thickness max.: 12 mm   sheet thickness min.: 1.6 mm STRIP-FEEDER   feeder type: roll feeder   sheet width max.: 450 mm   sheet thickness max.: 16 mm   feeding step min.: 1 mm   feeding step max.: 999.9 mm   sheet length min: 3950 mm   speed max.: 48 m/min   Vertical adjustme ...

CONTROLS   PC controller BECKHOFF Offer for services of complete Overhaul of a Customer-Owned Fineblanking Press FEINTOOL GKP 160 Scope of Overhaul • Complete disassembly into individual components • Inspection of all parts, including crack testing of critical components • Overhaul of the drive system, new motors • Reworking and precise alignment of all guideways • Complete overhaul of the hydraulic cylinders • Overhaul of the clamping tables • Installation of a new hydraulic unit • Renewal of the pneumatic system • Renewal of the electrical system Modernisation / Retrofit • Combined table • Servo feed systems • Central lubrication system • RAZIOL band lubrication • New brake/clutch unit • BECKHOFF PC-based control system with touch panel • PILZ safety control system • Implementation of CE conformity Notes • Special options and customer-specific ext ...

Feindie Press Feintool Ostenwalder Cutting force 100 ton Total force 160ton Hydr. back pressure 0-40 yon Hydr. Hold-down 0-50 ton Stroke rate 18-72

CONTROLS   PC controller BECKHOFF PRESS DESIGN   drive system: knuckle-joint SLIDE   total force (nominal): 160 to   stroke: 60 mm   stroke rate (max.): 70 /min COUNTER RAM   nominal force: 40 to   stroke: 14 mm V-RING   nominal force: 50 to   stroke: 10 mm TOOL DIMENSIONS   lower table (left-right): 480 mm   lower table (front-back): 520 mm   upper table (left-right): 480 mm   upper table (front-back): 520 mm   shut height max.: 314 mm   ram adjustment: 80 mm   distance between columns (H-frame): 500 mm   passline opening (free passage in side columns): 220 mm STRIP-FEEDER   feeder type: roll feeder   sheet width max.: 210 mm   sheet thickness max.: 6 mm   feeding step max.: 999.9 mm   sheet length min: 2000 mm   pilot release system: yes   band lubrication system: yes Complete refurbished fineblanking press: disassembly into individua ...

CONTROLS   PLC LAUER SLIDE   total force (nominal): 320 to   stroke: 200 mm SLIDE (HYDR. PRESS)   approximation velocity max.: 200 mm/s   working velocity min.: 10 mm/s   working velocity max.: 44 mm/s COUNTER RAM   nominal force: 63 to   stroke: 30 mm V-RING   nominal force: 100 to   stroke: 30 mm TOOL DIMENSIONS   lower table (left-right): 500 mm   lower table (front-back): 500 mm   upper table (left-right): 695 mm   upper table (front-back): 730 mm   shut height max.: 650 mm DECOILER   sheet width max.: 250 mm   sheet width (min): 40 mm   coil weight max.: 1250 to   max. diameter of coil: 1300 mm LEVELLER UNIT   sheet width max.: 250 mm   sheet thickness max.: 5 mm   sheet thickness min.: 0.8 mm   number of leveller rolls: 11   feed velocity min.: 4 m/min   feed velocity max.: 12 m/min STRIP-FEEDER   feeder type: grip feeder   she ...

CONTROLS   PLC SIEMENS S7 PRESS DESIGN   drive system: hydraulic   quick die change system: yes   feedstock transport direction: right to left SLIDE   total force (nominal): 400 to   stroke: 200 mm COUNTER RAM   nominal force: 100 to   stroke: 30 mm V-RING   nominal force: 200 to   stroke: 30 mm TOOL DIMENSIONS   lower table (left-right): 650 mm   lower table (front-back): 650 mm   shut height max.: 420 mm   passline opening (free passage in side columns): 420 mm OVERALL SPECIFICATIONS (COIL LINES)   sheet width max.: 500 mm   sheet thickness max.: 12 mm   feed velocity max.: 30 m/min   feedstock transport direction: right to left LEVELLER UNIT   sheet width max.: 500 mm   sheet width (min): 60 mm   sheet thickness max.: 12 mm   sheet thickness min.: 1 mm   integrated feed function: yes STRIP-FEEDER   sheet width max.: 400 mm   sheet  ...

CONTROLS   PLC SIEMENS S7 SLIDE   total force (nominal): 630 to TOOL DIMENSIONS   lower table (left-right): 900 mm   lower table (front-back): 900 mm   shut height max.: 900 mm

CONTROLS   PLC PRESS DESIGN   quick die change system: yes SLIDE   total force (nominal): 630 to   stroke: 125 mm V-RING   nominal force: 320 to TOOL DIMENSIONS   lower table (left-right): 800 mm   lower table (front-back): 800 mm   shut height max.: 420 mm STRIP-FEEDER   band lubrication system: yes ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 6800 mm   space requirements -front/back-: 3300 mm   total height: 3730 mm   height above floor level: 3005 mm   height under floor level: 725 mm   total weight approx.: 26000 kg ATTACHMENTS -FINEBLANKING PRESS-   autom. tool clamping device: yes   light barrier: yes   decoiler: yes   leveller unit: yes Strip levelling machine SCHMID HR12H (YoM 1995) including belt system

CONTROLS   PLC SIEMENS SIMATIC HMI SLIDE   total force (nominal): 320 to   stroke: 200 mm COUNTER RAM   nominal force: 63 to V-RING   nominal force: 100 to TOOL DIMENSIONS   shut height max.: 360 mm DIMENSIONS / WEIGHTS   total weight approx.: 18000 kg The system was fitted with a new control unit approximately 1.5 years ago including belt system Inkl. Decoiler Schmid HR10

CONTROLS   PC controller BECKHOFF PRESS DESIGN   drive system: servohydraulic   frame design: H-frame, tie rod   quick die change system: yes   feedstock transport direction: left to right SLIDE   total force (nominal): 1100 to   stroke: 130 mm   stroke rate (max.): 60 /min COUNTER RAM   nominal force: 330 to   stroke: 40 mm V-RING   nominal force: 500 to   stroke: 40 mm TOOL DIMENSIONS   lower table (left-right): 960 mm   lower table (front-back): 960 mm   upper table (left-right): 960 mm   upper table (front-back): 960 mm   shut height max.: 470 mm OVERALL SPECIFICATIONS (COIL LINES)   sheet width max.: 500 mm   sheet thickness max.: 16 mm   coil weight max.: 8 to   feedstock transport direction: left to right COIL CHAIR   coil weight max.: 8 to   stroke: 700 mm DECOILER   coil weight max.: 8 to   max. diameter of coil: 1800 mm   m ...

PRESS DESIGN   quick die change system: yes SLIDE   total force (nominal): 100 to   stroke: 20 mm   stroke rate (max.): 80 /min TOOL DIMENSIONS   lower table (left-right): 430 mm   shut height max.: 220 mm Approx. 79 million strokes

PRESS DESIGN   drive system: hydraulic SLIDE   total force (nominal): 40 to   stroke: 45 mm   stroke rate (max.): 110 /min TOOL DIMENSIONS   lower table (left-right): 300 mm   lower table (front-back): 280 mm   shut height max.: 90 mm DIMENSIONS / WEIGHTS   space requirements -left/right-: 1835 mm   space requirements -front/back-: 1500 mm   total height: 1800 mm   total weight approx.: 2500 kg

SLIDE   total force (nominal): 40 to   stroke rate (max.): 110 /min TOOL DIMENSIONS   lower table (left-right): 300 mm   lower table (front-back): 280 mm   shut height max.: 180 mm DIMENSIONS / WEIGHTS   space requirements -left/right-: 1835 mm   space requirements -front/back-: 1500 mm   total height: 1800 mm   total weight approx.: 2500 kg

SLIDE   total force (nominal): 80 to   stroke rate (max.): 120 /min V-RING   stroke: 90 mm TOOL DIMENSIONS   lower table (left-right): 420 mm   lower table (front-back): 420 mm   upper table (left-right): 420 mm   upper table (front-back): 420 mm DIMENSIONS / WEIGHTS   space requirements -left/right-: 2970 mm   space requirements -front/back-: 1665 mm   total height: 242 mm   total weight approx.: 6000 kg

A roll punching press for stamping is available up to A3. The die is pulled under the roll.

RASTER HR60 SL-4S blanking line was built in 2009. It has undergone regular technical inspections throughout its service life. The line is designed for the precision machining of sheet metal fed directly from a coil. It is used for the mass production of metal components used in many industries, such as handles, housings and automotive parts. The equipment used ensures high accuracy and repeatability of the produced parts. The coil press blanking line consists of the following components: – RASTER HR60 SL-4S high-speed press – sheet metal decoiler – loop controller before and after the sheet metal straightener – sheet metal straightener – parts collection bin – control panel – control cabinet The process begins with the gradual unwinding of the sheet metal from the coil and feeding it towards the working area. The material then passes through a straightener, ...
