facing used for sale

UNUSED: Facinghead of a Wotan BF 160 Horizontal borer.

Flat slider for drilling rig for mounting in the drilling spindle Tool holder SK50

: 150 mm : 500 mm weight of the machine ca.: 0,75 t Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Diameter: 630 mm. The 4-jaw mini lathe chuck body is made of cast iron, Bayonet cone 8.

General Description Portable in-situ flange facing machine manufactured by MILLAS LTD . Designed for machining and resurfacing flange sealing faces directly on installed pipework, pressure vessels, heat exchangers and similar equipment without dismantling. Suitable for maintenance work in power generation, oil & gas, petrochemical and heavy industrial applications. Technical Details Manufacturer: MILLAS LTD Model: Not identified Machine type: In-situ flange facing machine Year: Not confirmed Drive: Electric geared motors Transport/storage frame included Main flange-facing drive assembly Radial feed mechanism Feed screws and extension bars Gearbox assemblies Cabling and mounting hardware included Marked weight: 3,500 kg Condition Good industrial used condition. The equipment appears complete with electric drive units, feed mechanism, transport frame and accessorie ...

Face plate diameter: 1.250mm Center height above foundation slab: 1,250mm Weight: 19t Power: 55Kw Max. torque on the face plate: 31,500Nm Maximum workpiece mass between centres: 16,000 kg Speed range: 2.24 – 224 rpm

faceplate diameter: 2650 mm turning diameter over slide rest: 2800 mm turning diameter over plate: 3200 mm turning length: 10000 mm upper slide-adjustment: 250 mm spindle diameter in front bearing: 400 mm spindle turning speed range: 0,35 -1,12 / 1,2 - 56 U/min feed: 0,05 - 18 mm/U workpiece weight: 9000 kg spindle motor: 60 kW max. workpiece weight between centres: 20000 kg Control: total power requirement: - kW weight of the machine ca.: 93 t dimensions of the machine ca.: m - CNC control NUM 1060 - 4-jaw face plate - Steel holder device - Tailstock - Base plate - Roller setting vice - Transverse travel of the top slide: 425 mm - Longitudinal displacement of the main slide in the centre section: 150 mm - Transverse displacement of the centre section on the lower section: 700m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Roof joist end mill Auction-ID: A7-47096-229

total power requirement:40 kW Out of valve production

Description HEYLIGENSTEDT face lathe KH35-CNC with control Sinumerik 840 D Details Serial No. 70000134 Turning diameter over bed carriage 900 mm Turning diameter over bed sheets 1,400 mm Center height above floor 1,480 mm Tip height over bed panels 680 mm Bed width 850 mm Bed height 550 mm Control SIN 840 D Main spindle diameter at front bearing 206 mm Main spindle bore 100 mm max. main spindle torque 15,000 Nm Three-phase main spindle motor 40 kW

FZWD 160x1600/1 Sabo Basis 160 Facing & Centering Machine WMW HECKERT Workpiece dia 20-160 mm Length 130-1600 mm Max. Diameter of Milling Cutter 200 mm Facing Spindle's Speeds 112-280 rpm Spindle's Speeds 560-1400 rpm Adjustable feed rate range 15 – 800 mm / min. Spindle ISO 50 Rapid traverse 6000 mm Max. stroke 230 mm Max. Depth of 6 mm Tool holder 4 - 20 mm Max. Feed path 60 mm Total connected load 20 kW Weight 4.5 t

Ravensburger, Type KT 45, built in 1978 Tip height above bed 600 mm Tip width faceplate for support 450 mm Face plate diameter 1,000 mm Turning diameter in the recess max. 1,350 mm with digital display Power 18.5 kW

Milling chuck, boring head, spindle head, drill head, plunge drill head, plunge head, spindle drill head, boring head, universal drill head, boring tool, face head, facing and boring heads -Manufacturer: Komet microbore twinbore, milling heads, facing and boring heads with countersinking tool -Type: various designs, see photos -Comet: Type AB/VD 80 / AB/V 63x85 / AB/FZ 63 / AB/FZ 40 / AB/FZ 25 / FZ 32-100-3 / 2x AB/ISO 40x63x50 -Comet: Type AB/VD 63 / AB/VD 40 / AB/FZ 80 / AB/V 40x60 / AB/VD 50 / AB/V 25x60 / AB/VD 25 ... -twinbore: microbore MTP-75-1 / MTP-75-80 ... -Price/Fee: complete -Dimensions of transport case: 715/365/H210 mm -Total weight: 72 kg

Center height: 700 mm Center width: 1800 mm Gr. Circulation Ø over bed/in offset: 1300/1740 mm Rotary Ø over support slide: 740 mm 12 spindle speeds: 3 - 135 rpm 12 feeds: 0.15 - 2 mm/rev Upper support adjustment: 350 mm electr. Connection: 380 V, 6.6 kW Weight approx.: 5.5 t Space requirement: 3800 x 1600 x 1700 mm

faceplate diameter: 1200 mm turning diameter: 1520 mm turning speeds: . U/min max. workpiece weight -without tailstock: 6000 kg max. workpiece weight between centres: 25000 kg Plate area: mm turning diameter in the pit: 3200 mm Control: Siemens turning length: 1200 mm main drive: 70 kW total power requirement: 70 kW weight of the machine ca.: t dimensions of the machine ca.: 22x5x4 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment.  ...

faceplate diameter: 2000 mm turning diameter: 2500 mm turning speeds: 0,5-100 U/min max. workpiece weight -without tailstock: 6000 kg max. workpiece weight between centres: 25000 kg Plate area: mm turning diameter in the pit: 3200 mm total power requirement: 55 kW weight of the machine ca.: t dimensions of the machine ca.: 22x5x4 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Te ...

faceplate diameter: 3500 mm turning diameter: 4000 mm centre distance: 16000 mm turning speeds: 0,71-33,5 U/min Rest: 2 tailstock quill taper MT: max. workpiece weight -without tailstock: 6300 kg max. workpiece weight between centres: 18000 kg Plate area: mm total power requirement: 31 kW weight of the machine ca.: 60 t dimensions of the machine ca.: 22x5x4 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your ...

turning diameter: 3.200 mm turning diameter: modified: 2.400 mm turning diameter over slide: 3.000 mm turning length: max. 15.000 mm control: Sinumerik 840 D Siemens workpiece weight: max. 80.000 kg work accuracy: (up to) 0,01 mm Main spindle:: turning speed range - main spindle: max. 50 min/-1 total power requirement: - kW weight of the machine ca.: 154,4 t dimensions of the machine ca.: 20,7 x 6,0 m Documents: Heavy Duty Lathe ZERBST - DXP 5 / W15x15000 - measurement precision: < 0,01 mm Retrofit 2009 / 2012: - 2009: Control system upgrade to Sinumerik 840D - 2012: - New main gearbox, incl. main spindle drive - Installation of holding brake, incl. electrical integration - Modification and optimization of cylindrical roller bearings/bearings - Modernization: Control and safety technology The data for this ad was created with ModulMWS - the software solution of LogoTech o ...

faceplate diameter: 1000 mm max. torque on the spindle: 900 total power requirement: 17 kW weight of the machine ca.: 6,1 t dimensions of the machine ca.: m A vertical turning lathe with a fixed cross rail The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

A total of 3 pieces , unused , Art.NR: 12651380520 ; Type: 52-12-IK-Z4 ; see photos for more details Auction-ID: A7-49942-467

A total of 2 pieces, unused ; Art. NO: 12651380540 ; Type: 66-12-IK-Z6 ; see photos for more details Auction-ID: A7-49942-469

max. workpiece diameter:29 mm min. workpiece diameter:26 mm workpiece length:66 mm the system was originally delivered for the following workpiece sizes: diameter 26mm - 29mm length 65mm - 66mm Changing parts in the clamping device, handling, etc. would probably result in diameters of up to approx. Ø50mm Total length will probably be almost 400 mm possible with a few conversions. Also dependent on tool lengths, machining lengths on the component, etc. Workpiece: Piston pin Drawing number: WHT 000 718, WHT 000 718 A Workpiece dimensions (Ø, WxH): Ø26 x 66; Ø29 x 65 Length: 66 or 65 mm Material: 17Cr3 Quantity: xxx parts / year Cycle time: 5 sec. However, workpiece lengths up to 600mm are manageable. The machining diameter can be adjusted if the appropriate tools are available. The clamping station can currently only accommodate this product. However, this can be adapted by changing th ...
