new
Single-screw extruder • Type: 120/28 LD • AC Motor - 75 kw • Screw speed: 150 rpm. • Extruder cylinder: Air-cooled • Degassing zone Sieb changer • Strandhead Water bath: 4.5 m Granulator SG 200 Classic sieve Silo with conveyor fans: approx. 1m3
used
Extrusion line for 3D monofilament composed of: - 1-spindle extruder, brand: Bandera, 45 mm diam 25 L/D, motor: 10 hp. With dryer hopper: 100 L, master dispenser. With electrical panel and variable speed drive. - Head for 3D monofilament. - 3 stainless steel bathtubs: 2 m. - Stretching: 4 rollers. With variator. - 2-point monofilament thickness gauge. - Winder: 480x500 mm diam. For large coils. - Large coil unwinder and double rewinder for small coils. - Dehumidifier Brand: Puchades, power: 6.7 KW (9.1 hp), 14 Amp, year: 2014.
used
Key data: 45
Extrusion line for 3D monofilament composed of: - Extruder 1 spindle, brand: Bandera, 45 mm diam 25 L/D, motor: 10 hp. With drying hopper: 100 L, master dispenser. With electrical panel and variable speed drive. - Head for 3D monofilament. - 3 stainless steel bathtubs: 2 m. - Stretch: 4 rollers. With variator. - 2-point monofilament thickness gauge. - Winder: 480x500 mm diam. For large coils. - Large reel unwinder and double rewinder for small reels. Ready to get started? Contact us directly! Send us a WhatsApp message to (+34) 647 590 257 or an email to infogester.es for personalized advice.
used
Key data: 60
Extrusion line for the manufacture of 30 and 40 mm tutors composed of: - 1 spindle extruder: 60 mm Ø Plasticization 25 L/D. Brand: Flag, motor: 32 Kw (45 hp) direct current, year: 1998. With variable speed drive, gearbox and electrical panel. - Cooling bath: 3 m, with caliper, water pump: 3 hp, vacuum pump: 4 Kw (5.5 hp). - Track drag trolley: 1300x130 mm, brand: Weber, model: RA302, motor: 5.5 Kw. - Cutting saw brand: Pericolo, diameter: 300 mm, motor: 2.2 Kw (3 hp).
used
Ribbon Extruder line Barmeg FB9-1300-WS/HT composed of Motorized mixer – 100 kgs mixing capacity Dosing unit – hopper 200 kg , sensor , Main engine – Barmeg, 3 phase, 190KW Screw and tube – approx. 6000 kgs/24h capacity, polypropylene Nozzle – Hanger Type, 1340 mm Plastic Film Width Water Bath – Cooling System, Closed Circuit 1000 L Capacity Cutting unit – 1340 mm plastic film width Furnace – Hot Air Blower, 90KW Goddets – 2 x segmente godet of the stretching unit 4 and 6 x rollers, oil heater, cooling cylinder with cooling system Full Fibrilator system – Needle roller working width 1300mm Winder Part – Sahm Winder 240E 232 Independent Winder Edge control unit – 2 x motor Shredder – 1.9 KW with return to hopper Thickness measurement – Betacontrol (year 2003), Barmeg control system
used
Materials: PP, PS // Film Width (Max): 850 mm
used
Number Of Screws: 155 mm // Screw Diameters: 155-120 600 kg/h
used
We can offer you a complete line of Breathable menbrance extrusion line,manufactured by Colines,Italy in 2009,the line has just installed and adjusted,never used for production,like new line.the products-- breathable menbrance is for making diaper and hygienic materials.the net web width is 2850 mm,2 extruders,a 90 mm and a 150 mm,,serious buyer contact us,please Please visit manufacturer's website: .colines.it to learn more about this line.
used
Key data: 60
Extrusion line for the manufacture of forest protector 80 mm, composed of: -Extruder 1 spindle brand: Covex, 60 mm Ø 25 L/D, motor: 22 Kw (30 hp). With variable speed drive and electrical panel. - Stainless steel cooling tub: 2 m. With vacuum pump: 11 Kw (15 hp). - Towing trolley: 1100x220 mm, motor: 2.2 Kw (3 hp). -Die cutter and shear with hydraulic group: 4 Kw (5.5 hp). Tank: 75 litres.
used
Brand: Davis-standard, width: 1,400 mm, thicknesses: between 0.5 and 8 mm, year: 1999. Composed of: - Extruder 1 spindle brand: Davis-standard, 90 Ø diam, 32 L/D, engine: 250 hp, hydraulic filter degasser and changer and continuous flow gear pump. - Co-extruder 1 spindle brand: Davis-Standardar, 60 Ø diam, 32 L/D, engine: 60 hp, degasser, hydraulic filter changer - Co-extruder 1 spindle brand: Davis-Standardar, 60 Ø diam, 32 L/D, engine: 60 hp, degasser, hydraulic filter changer - Sheet extrusion head brand: IDE, width: 1,400 mm, thicknesses: 0.5 to 8 mm, up to 5 layers. - Calender, width: 1,500 mm, roller diameter: 460 mm. - Stretch and cooling table: 1500 mm. - Cutting shear.
used
Fong Kee (Taiwan) Year of manufacture 2016 Double Head (125mm screw) Accumulator type continue extrusion machine Machine In production Product type 160 Liter Float Dimensions 1188mm x 875mm x 407mm net weight 9kgs gross weight 17kgs estimate production rate 30/32pcs per hour Mold dimensions 1300mm x 1260mm x 860mm
used
see PDF
used
Calibration table See PDF
used
Hollow-chamber plate system Material: PC, PP Extruder: Breyer Screw diameter: 120 mm, L/D: 33 Engine: 200 kW with degassing, Siemens "Simatic OP17" PLC control, vacuum station with water ring pump and condensate pots, sieve changer Gneuß SF75, melt pump Maag 56/56, calibrator OMIPA 2400 mm, 10-fold multi-roll extractor OMIPA, 2 roll extractor OMIPA, protective film laminating station, hot-knife longitudinal separation, OMIPA cross saw 2400 mm R
used
Key data: 30 mm, 28 , 110 U/min
Used Filament Line Single Screw Extruder 30mm 28L/D 2 meter water bath Trigger AB50 Winder W250 Machines from PMH GmbH
used
Key data: 120
Extrusion line for manufacture of PS-PE-ABS-PP sheets etc ... Brand: Siepla Year of manufacture: 2008 Four-cylinder grille with servo-controllers Flat head: Maximum head width: 1000mm Maximum aperture up to: 2mm Minimum aperture: 200 microns Built-in shear for cutting plates. Two single-screw extruders: Ø 120mm and Ø 75mm MAAG melt pump and vertical pump: 1300 m3/h, 1350 rpm. Type: G160A Drag trolley Production capacity: 250 – 350 Kg/h Horizontal hydraulic changer with double cavity: Ø 16 mm. Manuals are available for each machine station as well as for compliance with EC directives.
Extruding Lines 8 unit
used
PET Sheet Extrusion Line Composed of: - Extruder 1 screw, brand: Union, 120 mm, motor: 185 KW (250 hp) double desasifier, year: 2002. - Continuous flow gear pump. - Self-cleaning hydraulic filter changer, brand: Erema, model: SW4/170 RTF. - New replacement spindle. - Head: 1400 mm, brand: EDI. - Calender: 1600 mm wide with 450x600-500 rollers. - 500 mm replacement cylinder - Silicone bath, year: 2017. -Winders. - Working width: 1200 mm. - Thicknesses: 0.2 to 1.2 - Production: 500 Kg/h. - Co-extruder 1 spindle, 80 mm, brand: PTI. -Dehumidifier, brand: Piovan, model: DP-620, year: 2022.
used
Inv. Num. : 7235 Type: 6.5 Producer: Weber Generated: Parameters: Equipment: Calibration table ? Tow strap
used
PVC sheet extrusion line with head: 280mm, composed of: - 2-screw extruder, brand: Weber, model: DS.8.22, motor: 30 Kw (40 hp), load doser, degasser with vacuum pump. Variable speed drive and electrical panel. - Wide blade head: 280 mm. - Calender, width: 300 mm, diameter: 150 mm. 3 water-cooled rollers. With stretching. - Ink baths, dryer, stretch for several coats of paint. - Cutting shear. - 1-reel winder, width: 300 mm. - Various replacement rollers for ironboards, printers and engravings (drawings on foil). Ahem: Wood simulation. Ready to get started? Contact us directly! Send us a WhatsApp message to (+34) 647 590 257 or an email to infogester.es for personalized advice.
