embossing used for sale

in 2005 refurbished Still in operation: Yes Available: immediately

in 2005 general overhauled Still in operation: Yes Available: sofort

The small laboratory press MHSP5 can perform very well with the round stamp (70 mm diameter) deformations of many materials. By delivering fine (0.5 mm per wheel revolution), deformations are carried out very accurately. Small punching or stamping operations are possible. The press is driven by a worm gear screw jacks, which requires minimal hand strength by high reduction ratio. The pressing frame consists of stable-dimensioned polyamide PA6G. Here are some technical data:-static force 5 KN (0.5 to) - portable presses frame made of polyamide PA 6 G, very stable design, with FEM program added - spindle manual jacks 20 mm, pitch 5 mm - with Handwheel diameter 120 mm and handle - gear ratio 1:10, per the Handwheel 0.5 mm screw - table size 235 195 mm - clearance width 190 mm - stamp size diameter 70 mm with 4 holes 8 mm for mounting a major stamp Very easy operation with spindle and w ...

Electric spindle press REITZ EHSP100F as laboratory heating press / demonstration machine Laboratory heating press with pressing pressure 40 KN (4 tons), ratio 1 : 16, spindle diameter 45 mm, pitch 8 mm, spindle stroke 0.5 mm per revolution. Gear motor 0.75 KW, 1,500 rpm, 4-pole, with spur gear i = 1:5, Speed 150 mm / min. Max dynamic load 25 kN. With reversible control, emergency stop and motor protection plug. Total weight approx. 100 kg, table surface 600 600 mm, pressing surface approx. 150 250 mm, clear height approx. 60 mm. Base made of high-quality aluminium profiles 4545 mm, the table top is made of glued plywood top. The laboratory heating press has 40 kN pressing pressure (dynamic load). The spindle is self-locking and thus maintains the pressing force for a longer period of time. For an extra charge with heating plate, insulating plate and temperatur ...

Manual Heating Press Reitz MHSP5H - Manual Lifting Screw Press Static Press Force 5 KN (0.5 to) - Portable press frame made of polyamide PA 6G - Manual screw jack with spindle 20 mm, pitch 5 mm - With handwheel diameter 120 mm and handle - Gear reduction ratio 1 : 10, 0.5 mm spindle travel per handwheel revolution, thus only very little hand force required for high pressure. - Table size 100150mm - Clear width 60 mm - Punch size diameter 70 mm with 4 holes 8 mm to attach the Hotplate - Very easy operation due to spindle and worm gear - Total weight approx. 25 kg With 2 electric aluminum heating plates 1200 watts, heating area approx. 150 100 mm to 250°C, connection 230 V. With sensor and temperature control. Pressure-resistant insulating panels at the top and bottom for use in presses. Suitable for pressing, welding and gluing.

Machine type: Spiral conveyor incl. roll embossing machine Manufacturer: Püschel Year of construction: unbek. Condition: used / untested Offer will only be sent if a complete imprint is provided! Price 950 Euro incl. 19% VAT free loaded. Location Warstein , Germany Reference M-PÜS-0124 DESCRIPTION We offer you a used spiral conveyor including roll embossing machine from the manufacturer Püschel. Availability: immediately Our offer is aimed at tradespeople who are registered within the meaning of the Trade Regulation Act according to §14 GewO. The offer is subject to change, subject to prior sale. Please provide your full contact details to receive a quote with our terms and conditions and payment terms. Errors in the descriptions and offers are excepted!

Elegant effects for book covers and packaging For industrial embossing of solid grey board in bookbinding and in the further processing of fine packaging. The stabilized embossing head guarantees precise embossing even with non-centred embossing clichés. For blind, relief or film embossing of rigid, flexible and plastic cases at up to 80 cycles/min. The PE 312 processes the whole bandwidth of cover materials with blind, relief or film embossing. Can be adapted for optimal processing of different materials by stepless adjustment of temperature and embossing pressure and by adjusting embossing time in steps of 10 seconds. Matrix plate with hole grid for attaching embossing blocks. Save make-ready time by preparing the matrix plate offline. Application : • Blind, relief or hot foil stamping • Combination of micro-embossing and structure embossing Technical data : Hardcover 1 ...

Data sheet heating press Oropress Pneumatic press 5 KN / 0.5 tons Press stroke 50 mm Adjustment of the clear height with handwheel and spindle, adjustable from 100 to 220 mm. With top heating plate 120 x 100 mm and temperature control, temperature up to 250 °C. Pneumatic two-hand control with triggering via Festo ZSB. Pneumatic sliding table 180 x 220 mm for loading outside the machine. Machine dimensions W = 1100 mm, L = 700 mm, H = 1850 mm Machine weight approx. 300 kg Movable on castors On request for an extra charge with second heating plate and temperature control at the bottom.

Electric surface press REITZ EHSP522 Pressing surface 200200mm Pressure 5 KN / 0.5 tons Suitable for surface bonding of plastics and composites. On request with: - Heating plate and temperature control - Load cells and gauges for use as test press

we have for sale : Calender embossing machine for the paper model : YW-920C year : 2014 widith of the cylinder : 880 mm min. paper weight : 80g/m2 max speed : 50 m/min very good condition Machine is available immediately

Printing machine, embossing machine, stamping machine -without function, control: defective -pneumatic-hydraulic press - Stroke: 50mm - clearance between columns: 850 mm -Table surface: 400 x 370 mm -Dimensions: 1285/590/H1820 mm -Weight: 416 kg

Fully automatic hot stamping press Oropress Mechanical eccentric press with lift table Lift table as pneumatic sliding table 250 x 250 mm Fully automatic sequence, optionally triggered with foot switch for single stroke Heated press punch 120 x 200 mm up to 250 °C Safety grille Film Feed Unit Built in 1986

We have for sale : Calender embossing machine model : YW-920C year : 2014 widith of the cylinder : 880 mm weight of paper : min 80 g/m2 max speed : 50m/min Machine is in very good condition Available immediately

Working widths: 1800 mm roll surface width: 2000 mm pressure: t Number of rollers: 2 Stück Upper roll: Gravur oder Stahl dia diameter of upper rolls: 210 mm Heating - upper roll: Elektro Lower roll: Gummiert dia diameter of lower rolls: 300 mm Roller covering - soft rubber: 95 Grad shore Clouth speed: m/min required power: kW weight: 2 t dimensions of the machine ca.: 3,0 x 1,5 x 1,8 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Kniehebelprägepresse - Embossing hot stamping press Hans Schilling HSM Serial-No. 18040 Online-Video-Inspection by Skype-Video We would be very pleased with your visit - more machines on Stock Available Immediately - Can be inspect On Stock Emskirchen / Nürnberg - Can be test

Heißpräge - Kniehebelprägepresse - Embossing Hot Stamping Press Krause FNP Serial-No. 4798 Stamping size: 550 x 400 mm Online-Video-Inspection by Skype-Video We would be very pleased with your visit - more machines on Stock Available Immediately - Can be inspect On Stock Emskirchen / Nürnberg - Can be test

pressure: 360 t stroke: 60 mm table surface area: 525x430 mm no. of strokes: 60 Hub/min : 40 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Heißpräge - Kniehebelprägepresse / Embossing Hot Stamping Press  Krause FNP Online-Video-Inspection by Skype-Video We would be very pleased with your visit - more machines on Stock Available Immediately - Can be inspect On Stock Emskirchen / Nürnberg - Can be test

Hydraulic embossing press from WSK

Features: automatic non-stop delivery with conveyor, non-stop feeder with rods, pull mark left, push mark right, quick clamping frame for tooling, lower stripping station, upper stripping station, two exchange frames for lower stripping station. Without die-cutting plates. Processable materials: min. paper 90g/m², max. solid board 2000g/m², max. corrugated board/ with MasterSet 4/ 2mm, max. sheet size 760x1060mm, min. sheet size/with MasterSet 300x350/ 350x400mm, max. cutting pressure: 2.6MN/ 260t, max. machine speed: 8000 sheets/h, max. feeder pile height without non-stop/ in non-stop operation: 1500/ 1200mm, max. feeder pile weight: 1500kg, max. delivery pile height: 1400mm, max. delivery pile weight: 900/ 1340kg. Operating hours: 1525h. An on-site inspection is possible.
