emag karstens used for sale

CONTROLS   CNC controls FANUC BASIC FUNCTIONS   number of spindles: 1   number of turrets: 1 WORKING RANGE TURNING   turning diameter (max): 220 mm   worpiece length max.: 175 mm MAIN SPINDLE   spindle revolutions (max): 6000 /min X/Z SLIDE   Z-axis travel: 300 mm   X-axis travel: 660 mm ELECTRICAL SPECIFICATIONS   total power consumption: 36 kW   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 3820 mm   space requirements -front/back-: 2040 mm   total height: 2400 mm   total weight approx.: 6500 kg

EMAG VL 4 ist eine Bearbeitungszelle / Vertikaldrehmaschine für hochpräzise Fertigung, hohe Genauigkeit und zuverlässigen Dauerbetrieb. Kapazitäten: 2 Maschinen, 2 Achsen; Max. Werkstückdimension 200 mm; Z-Achse 400 mm; X-Achse 750 mm; Revolver 12 Positionen, 12 angetriebene Werkzeuge. Technische Daten: Spindeldrehzahlen bis 6000 t/min, stufenlos bis 4500 t/min; Spindelleistung 25/18 kW; Drehmoment 280/202 Nm; Anschluss 3x400V 50Hz; Gesamtbedarf 36 kW; Abmessungen L5300×B2300×H3650 mm. Zubehör: Späneförderer, automatische Be-/Entladeeinrichtung, Satz Werkzeughalter, Zustandsleuchte, Ersatzteile. Erreicht enge Toleranzen; typisch für Automobil, Luftfahrt, Werkzeugmaschinen und Medizintechnik. Technische Daten ohne Gewähr

Manufacturer: EMAG Model: VSC 250 Year: 2003 Condition: Used Stock number: 9420 Control system: SIEMENS Max. workpiece diameter: 250 mm Max. length of the workpiece: 175 mm Lathe chuck diameter: 315 mm Weight: 6500 kg

CONTROLS   CNC controls SIEMENS BASIC FUNCTIONS   number of spindles: 2   number of turrets: 1   number of c-axes: 2 WORKING RANGE TURNING   turning diameter (max): 100 mm   worpiece length max.: 150 mm MAIN SPINDLE   spindle revolutions (max): 6000 /min TOOL MAGAZINE   number of positions: 12 ELECTRICAL SPECIFICATIONS   total power consumption: 36 kW   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   total weight approx.: 7000 kg ATTACHMENTS (TURNING)   hydraulic system: yes   European CE standards: yes Machines in good condition: - Integrated pick-up automation - Two EMAG machines configured in a line are for sale. - A robot destacking unit with 100% parts inspection can also be purchased.

swing diameter: 210 mm x-travel: 400 mm z-travel: 200 mm control: FANUC Series 18i TB weight of the machine ca.: ~ 5.500 kg Vertical Turning Machine | EMAG - VL 3 mLT with driven tools The machine is in a well-maintained condition. Please note that the technical details were added from comparable machines. We ask for your understanding ! - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VL3 | VL3mLT | VL-3 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

swing diameter: 210 mm x-travel: 400 mm z-travel: 200 mm control: FANUC Series 32i Model A weight of the machine ca.: ~ 5.500 kg Vertical Turning Machine | EMAG - VL 3 + VL 3 The machine is in a well-maintained condition. Please note that the technical details were added from comparable machines. We ask for your understanding ! - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VL3 | VL-3 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

swing diameter: 210 mm x-travel: 400 mm z-travel: 200 mm control: SIEMENS SINUMERIK 840D sl weight of the machine ca.: ~ 5.500 kg Vertical Turning Machine | EMAG - VL 3 + VL 3 Y The machine is in a well-maintained condition. Please note that the technical details were added from comparable machines. We ask for your understanding ! - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VL3 | VL-3 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Center height: 150 mm Center length: approx. 600 mm Grinding wheel diameter: approx. 300 mm Grinding wheel width: approx. 35 mm incl. a pallet with matching machine accessories such as grinding wheels, collets and other accessories Reference: Option - Lot 77 Auction-ID: A7-49056-114

CNC Control: Siemens Sinumerik Machine length: 5,000 mm Machine width: approx. 2,400 mm Weight: approx. 14,500 kg Tip height: 360 mm Maximum grinding diameter: 715 mm Maximum grinding length: 2,000 mm X-axis travel: 500 mm X-axis speed: 0.01 to 15,000 mm/min X-axis measurement resolution: 0.0001 mm Z-axis travel: 2,700 mm Z-axis speed: 0.01 to 15,000 mm/min Z-axis measurement resolution: 0.0001 mm B-axis travel: 280° B-axis speed: 3,600°/min B-axis resolution: 0.00005° Orientation of the external grinding spindle: right, from 0° to 30° Maximum wheel diameter: 610 mm Grinding spindle power: 15 kW Peripheral speed: 50 m/s Workpiece Spindle Speed Range: 1 to 450 RPM Workpiece spindle power: 4.2 kW Torque: 90 Nm Inner cone: MK 6 Tip diameter: 92 mm Maximum cantilevered workpiece weight: 500 kg Maximum workpiece weight between spikes: 650 kg Taper of the tails ...
