Sell EFS ratioLift equipment type L30 K incl. column slewing crane and
grab (see pictures)
(Description according to the manufacturer's instructions :
The ratioLIFT L is a pneumatic wire rope balancer for variable
connection to a rail system, column slewing crane or articulated boom.
This means that a wide range of applications can be covered.
Depending on the requirements, the ratioLIFT L is assembled due to its
variable modular design. Whether pneumatic balance control and
optionally available control such as throttle grip, up and down
control, automatic control and control of the throttle. Weight
detection; the ratioLIFT L solves many handling tasks. The pulley
principle covers large lifting heights and the 2-rope design ensures a
high level of safety.
The main area of application of the ratioLIFT L is the correct,
weightless transfer of products. Due to the lightweight design of the
ratioLIFT L, fast cycle times can be achieved, enabling the operator
to work economically and efficiently.
Special features
Particularly easy running for up and down movement
for loads up to 30 kg
Easy maintenance, easy rope change
Double rope design
Variable design due to the modular design
--> Load capacity with gripper 30Kg
--> Lifting N6164696 height range in mm: 1600mm
--> Operating pressure in bar: 6
--> Noise development approx. in dB: 70
Weight without base plate approx. 200KG
Base plate approx. 250KG 1.2x1.2m
Height approx. 2.85m
Grab h 1,1b0,75m d 0,37m
Application examples
Cardboard handling
Vehicle battery handling
Seat handling
Cockpit Bracket Gauge
Soft top compartment lid handling
7-Joint Handling
Wheel carrier handling
Crank Roller Handling
mechanical assemblies
Panel handling
Glass pane handling
Tank handling
Germany
15366 Neuenhagen
