edging used for sale

Type: JHG 60 material edging machine Year of production / SO / GO: 2015 / - / - Description: Machine for edging material edges. Presses ornaments into the web. Machine in good technical condition, after agreement the possibility of testing. Machine dimensions: 1636 x 990 x 1330 mm. Weight 1260 kg. Available in English.

Brand: Bavelloni Type: Straight Line Edging Machine Model: CR 1111 Serial Number: 443041 Construction year: 1988, overhauled 2023 Air pressure 8 bar Weight: 3,5 tons Length mm: 8100 Width mm: 1500 Height mm: 3300 incl. rack increase Transport size L x W x H: 4,5 x 2,49 x 2,4 mtr Min,- max. glass thickness Min. 3 mm, max. 31 mm Min.-max glass size: min. 70 x 70 mm Max. 200 kg/ p.mtr Working speed: 0- 5 mtr/ p.min Electr. Connection: 23,8 Kw Missing parts: None, complete Documentation: Yes, NL Instruction: Yes, NL Electric scheme: Yes Parts list: Yes Number of spindles: 11 spindles Condition machine : Complete overhauled/ modernized Remaining: Complete set of wheels

Press length: 2500mm; Pressing depth: Pressing elements vertical: 4; Horizontal pressing elements: Pressure build-up: pneumatic; Pressing pressure: per cylinder; Cylinder stroke: mm; Hold-down: no; Machine length: 2700mm; Machine width: 1000mm; Machine height: 1400mm; Weight:

Chassis number: 669012 Weight: 1,7 tons Power: 15Kw Air pressure: 6,0 Bar Length mm: 6000 Width mm: 1200 Height mm: 2600 Transport size L x W x H: 2,9 x 2,5 x 1,4 Number of spindles: 8 spindles Condition machine : Working disassembled Control type: Manual Electric. Connection: 32A 400V Documentation: No Instructions: No Electric diagram: No Parts list: On request Photos/film available: Photos and video available

Serial Number: 482 Construction year: Fbr 2000 Weight: +/- 2,1 tons Power: kW 13 Air pressure: 7-8 Bar Length mm: 7300 Width mm: 1200 Height mm: 2400 Working height: 750mm Transport size L x W x H: 2,5 x 1,2 x 1,2 in mm Maximum speed: 4 m/min Min.-max. glass thickness: 3 - 35mm Min.-max glass size: 100 x 100 -2000 x 3000mm Number of spindles: 7 spindles Condition machine : Excellent Control type: Semi-automatic Electric. Connection: 32A 3P+PE Photos/film available: Photo's available

Vecoplan VTH/55/15/2 edging chipper – German production – autoreverse – for the production of technological chips – year of manufacture 1995 TECHNICAL PARAMETERS: inlet width 550 mm inlet height 130 mm two knives engine power 55 kW conveyor belt length 4300 mm sieve 50 x 50 mm toothed upper pulling shaft toothed lower pulling shaft rotor width 560 mm rotor diameter 560 mm hydraulic lifting of the feed shaft transport dimensions (length / width / height) 550 / 230 / 120 cm weight ~ 3000 kg

Technical data for the grating: Manafacture: Gi-Ro Vreden Condition of the goods: new (unobstructed) Reason for return: Wrong order end customer The scope of delivery includes: 01x Press grate, new (unobstructed) Material color: hot-dip galvanized Total depth: 1,033 mm (support rod direction) Total width: 1,230 mm (crossbar direction) Support rod dimensions: 45/1.7 mm S355JR TS anti-slip: no QS anti-slip: no Edging TS-straightening: T-profile 45 mm Edging QS-Richt.: T-profile 60 mm Edging TS-straightening: T-profile 45 mm Edging QA straightening: T-profile 45 mm Mesh size: 60 x 40 mm Weight: approx. 19.10 kg | Pcs. Internal designation: T General information about the item: This item is offered for pickup only. A transport that is also desired or a shipment of this article is associated with additional costs, which separately depending on the place of deliv ...

Complete line for production wooden brushes including: - Machine for cutting and edging filaments is from Marcyn (J. Evans&Sons). It has hot stam logo engraver built in and it is fully refurbished and 100% functional. It can be used for various filament cutting and edging. Also clips could be setup for different sizes of the handles. - Machine for tufting and drilling is from Schlesinger. Machine is produced in the plant in Schönheide in 1969, however before 1955, Schlesinger(nowadays Roth) manufactured machines in Schönheide (an area of eastern Germany). Our machine was made after Friedrich Schlesinger (the owner) moved to West Germany (Burgwald), a group of people continued to produce machines in the factory in East Germany. This machine is fully refurbished and 100% functional. We added computer controlled system with unique own software. It can be used for tufting wooden ...

BOVONE ELB 10/45 glass bevelling machine built in 2004 in Italy, is used in the process of grinding flat and inclined edges made of glass. Glass with a thickness between 3 and 30 mm is processed with the highest precision and accuracy using ten spindles. Exceptional stability during machining is ensured by a structure made of top-quality cast iron. The glass bevelling machine is maintained on an ongoing basis – in 2021, it underwent an extensive service during which components such as bearings on the spindles or cofferdam brushes were replaced. The glass edging machine is equipped with an infeed and outfeed conveyor with a load capacity of 800 kg. The machine weighs 4,200 kg. Technical specifications of the BOVONE ELB 10/45 glass straight line edging machine - number of spindles: 10 - minimum thickness of glass: 3 mm - maximum thickness of glass: 30 mm - minimum dimensions of ...

CNC machining center including laser edge type BIMA / Gx50 / E / 160 / 630 Specifications: IMA gantry machine in real GANTRY design Processing area: • Length in X direction with all aggregates (mm): 6300 • Width in Y-direction with all aggregates (mm): 1600 • Height in Z-direction with all aggregates (mm): 225 maximum clamping height including clamping device - the maximum workpiece thickness depends on equipment/application • Length in X direction with vertically positioned main spindle and tool diameter 20 mm: 6300 mm • Width in Y-direction with vertically positioned main spindle and tool diameter 20 mm: 2000 mm • Width in Y-direction with edging (mm): 1600 • Length in X-direction Single user processing without gluing (mm): 2 x 3050 • Length in X-direction free space center (mm): 200 • Length in X-direction Single user processing with gluing (mm): 2 x 2 ...

Pressure zone turret, softforming interchangeable profiles for softforming machines, double-end tenoners, edging machines, scoring motor, chipper motor, milling motor for edging machines -HOMAG softforming interchangeable profiles for softforming profiles can be quickly converted to straight edges -with heavy leadership -laterally movable -with counter -HOMAG milling unit for joint milling -with heavy dovetail guide -1x engines Perske -Motor type: -Power: 3.0/4.4 kW -Voltage: 220/380/380 volts -Frequency: 50/100 Hz -Speed: 2880/5880 rpm -Other engines with other services in stock for an additional charge -Dimensions: 1800/1400/H1300 mm -Weight: 712 kg

Pressure zone turret, softforming interchangeable profiles for softforming machines, double-end tenoners, edging machines, scoring motor, chipper motor, milling motor for edging machines -HOMAG softforming interchangeable profiles for softforming profiles can be quickly converted to straight edges -with heavy leadership -laterally movable -with counter -Dimensions: 1300/780/H620 mm -Weight: 260 kg

Pressure zone turret, softforming interchangeable profiles for softforming machines, double-end tenoners, edging machines, scoring motor, chipper motor, milling motor for edging machines -HOMAG softforming interchangeable profiles for softforming profiles can be quickly converted to straight edges -with heavy leadership -laterally movable -with counter -HOMAG milling unit for joint milling -with heavy dovetail guide -1x engines Perske -Motor type: -Power: 3.0/4.4 kW -Voltage: 220/380/380 volts -Frequency: 50/100 Hz -Speed: 2860/5860 rpm -Other engines with other services in stock for an additional charge -Dimensions: 1800/1400/H1300 mm -Weight: 712 kg

Paul KME2 edging saw for edging and splitting boards. Sample image, illustration similar., Roller width: 590 mm, engine: 45 kW, adjustment: hydraulic, More technical data: See PDF

Equipment / Product data of the CNC-Fraesen Type High-Z/TRex series / Type 1215 Drive: 3 busiest brand stepper motors with 4.5 amperes. Pushing through long and up to 120mm high materials possible, as no belt drive is in the way at the end of the X axis! linear guides on all axes of HIWIN / THK ! Multiple ball-bearing ball thread spindles on all axes, brand edging! speed speed max. 12,000 mm/min Working speed max. approx. 8,000 mm/min Technical platform X/Y: 0.005mm (1/10 step); Z: 0.0025mm reverse play maximum approx. +/- 10 microns (0.010 mm) Point repeatability: approx. 0.01 mm clamping area 1860 x 1340 mm travel distances: X=1500mm; Y=1200mm; Z= 130 mm contact contactno-point sensors / reference switches / limit switches on all axes Double-secured emergency trigger energy chains for clean cable Total mass with motors : LxWxH approx. 2180 x 1800 x 1420 mm Fra- Sc ...

Equipment / Product data of the CNC-Fraesen Type High-Z/TRex series / Type 1224 Drive: 3 buerstenlose brand stepper motors with 4.5 amperes. Pushing through long and up to 120mm high materials possible, as no belt drive is in the way at the end of the X axis! linear guides on all axes of HIWIN / THK ! Multiple ball-bearing ball thread spindles on all axes, brand edging! speed speed max. 12,000 mm/min Working speed max. approx. 8,000 mm/min Technical platform X/Y: 0.005mm (1/10 step); Z: 0.0025mm reverse clearance maximum approx. +/- 10 microns (0.010 mm) Point repeatability: approx. 0.01 mm clamping area 2800 x 1340 mm travel distances: X=2400mm; Y=1200mm; Z= 130 mm contact sensors / reference switches / limit switches on all axes Double secured emergency trigger energy chains for clean cable flush Total mass with motors : LxWxH approx. 3070 x 1800 x 1420 mm Fraes ...

Type SE-360D Thickness of panel 10-60 mm Edging thickness 0,3-3 mm Feeding speed 13-22 m/min Air pressure 0,6 MPa Voltage 380V/50Hz Total install power 10,5 kW Min. panel dimensions 150(L)x150(W) mm Made in 2017 y. Transport dimensions 4420x900x1560 mm Weight 1400 kg

Used Heuft Empty Bottle Inspector InLine IXs reflexx Device No. 2ZG044698 Condition: very good, ready for use at short notice ·       Commissioning 6 May 2012 ·       Upgrade for later integration of additional ground control using X-ray technology ·       Tape control Heuft Synchronous TX ·       Network Heuft Hlan ·       Haylofts two ways discharge with div. Heuft container transport Convejor ·       Troubleshooting Software Wizard ·       Software assistant guided instructions for the different container changes ·       Power max. 46,000 fl./h ·       5 Variety licenses incl. scope of delivery: ·       Belt control Spectrum TX ·       Measuring bridges for inlet control and discharges incl. height connections ·       2 x Discharge Delta K  ...

Qty. 1 Second-hand steel strip slitter Mfc.: Dai Hyun Built: 1994 Still in operation until end of July 2023 Material to Slit: Hot & cold rolled steel coil, Hot deep galvanized steel, Carbon steel Line Direction: Left to right Strip Width: 1400 mm Thickness: 0.8 - 6.0 mm Max. Coil weight: 24 MT Un-coiler ID with Liner: Ø 480 mm, Ø 600 mm Coil Dia.: Ø 1000 & Ø 2000 mm Re-coiler Inside Dia.: Ø 500 mm, Ø 760 mm Slitting Speed: 50-100 m/min Edging width: 3 mm to 10 mm Electric Power: Input voltage: 400 V, 50 Hz - 220 VAC, 50 Hz,3 Ph. ± l 0% for drive Control Voltage: 110 VAC, 50 Hz, 1 Ph. Slitting capacity Working speed and No. of cuts Min. slit width is 40 mm at thickness 1.0 – 2.5 mm. Strip thickness No. of cuts No. of strips Line speed mm m/min 1.0 - 1.9 16 15 70-90 2.0 - 2.9 14 13 70-80 3.0 – 4.0 12 11 60-70 4.1 – 5.0 7 6 60-70  ...

Type FZ-515 Thickness of panel 10-60 mm Edging thickness 0,4-3 mm Feeding speed 15 m/min Air pressure 0,8 MPa Total install power 6,5 kW Panel width ? 60mm Transport dimensions 3700x900x1700 mm Weight 1200 kg

Used Heuft Glass Empty Bottle Inspector InLine reflexx Device No. 2ZG042943 Condition: very good, ready for use at short notice ·       Original delivery date 12.2011 ·       Power max. 46,000 fl./h ·       Pass direction from left to right ·       Two triggers ·       Secomak blower instead of compressed air ·       Transponder detection for RFID test bottles ·       Discharge monitoring ·       Network Heuft Hlan (Upgrade Optional) ·       Hayt two ways discharge Delta K to the right ·       4 Variety Licenses ·       Tripartite Delta K for band height of 1130 ·       Two fluids for lye detection Not available! ·       inlet control, must be supplemented if necessary ·       Thread edging, must be supplemented if required ·       The documentation is complet ...

full drawer cabinet cca 350 pcs various pinball, thread edging, etc.

Stainless steel sink / double sink completely made of stainless steel 2 basins lower shelf ribbed draining surface on the left Rear edging height-adjustable feet Mixer tap defective Dimensions: Height: 86 cm Width: 150 cm Depth: 55 cm Pool dimensions: Left basin: 400 x 400 x 250 mm Right basin: 400 x 400 x 250 mm

SULAK BTS 01 ALPHA glass beveling machine was manufactured in 2014 in the Czech Republic. The easy-to-use glass grinding machine is designed for levelling and grinding flat or rounded edges of, among others, glass and mirrors. The machining of workpieces with a thickness of 3 to 12 mm is performed with water cooled diamond discs and polishing discs. Depending on the design of the diamond disc, the processed glass edges can have a trapezoidal profile, a flat profile or a C profile. The total weight of the machine is 280 kg. Technical data of the SULAK BTS 01 ALPHA glass edging machine - minimum glass size (L x W): 200 x 200 mm - maximum glass thickness: 12 mm - minimum glass thickness: 3 mm - spindle speed: 2800 rpm - number of spindles: 1 - power supply: 3x 400 V; 50 Hz - power: 1.6 kW - dimensions (L x W x H): 3060 x 750 x 1700 mm - BTS 01 ALPHA machine weight: 280 kg

Hand wash-spout combination made of stainless steel Rear edging 1 wash hand basin on top 1 spout basin below with storage grate Dimensions: Width: 50 cm Height: 105 cm Depth: 70 cm

belt width: 150mm; belt length: 3000mm; table size: 960mm x 350mm; table for rounds: 330mm x 330mm; veneer grinding unit: ja; oszillation: ja; grinding unit tiltable: ja 90° - 45°; suction connection: 120mm; motor power: 3 kW; machine length: 1910mm; machine width: 840mm; weight: 330kg; properties Heavy machine stand in torsion and vibration-free design, extremely stable Grooved feed ruler, ideal for grinding veneer supernatants Double-sided suction connection 80/100 mm for optimum chip removal Oscillating sanding belt ensures a high removal rate and a clean sanding pattern Maintenance-free grinding belt oscillation with separate gearmotor, optionally switchable Height-adjustable sanding table for utilization of the entire sanding belt Standard veneer edging device with fine adjustment Fast conversion from veneer to solid wood sanding possible Height adjustment of the  ...

Brettbesäumer Autojet used Cutting heights 18 - 100 mm, 3 variable axes – 2 variable stems – Re./Li. Additional bushing. Build 3/94 - New laser measurement with PC/software/PC cabinet from Installation 5/2007 A cost-effective solution for a fast trimming machine with modern laser measurement. - Continuous capping with length stops for the cap lengths - Zero cross-cut saw - Addition of swivel saw for tip capping on the opposite side. The waste is disposed of. -Transverse measuring conveyor The boards are conveyed by a measurement curtain in transverse passage. -Laser measurement State-of-the-art surveying with 15 lasers from above. Of course, programs can be stored in all variety, depending on length and width, separation, sharp-edged or forest edge can be mapped in many ways in the program. - Alignment table A computer calculates the ideal orientation of the boa ...

High quality machine housing, 548 x 129 x 200cm hoch, KMS, mint condition -90% Special price ! If you have an UID number, we will gladly issue an invoice without VAT Top condition like a demonstration unit The part was removed from a new machine, which can be proven to have run only about 100 hours. The parts have minor signs of disassembly. High quality machine enclosure, length 5480, width 1285, height 2000mm, Consisting of: - Total 12.24 running metres of enclosure, - High quality frame with removable panels, all top painted, - 2 large double doors without locking system with plexiglass, - The back consists of 7 removable elements of plexiglass and sheet metal - The top is made of plexiglass all round - The roof consists of slide-on frames with plexiglass edging. - The elements are all very strong and of high quality - Incl. the many machine feet and the  ...

Storti wood cutting line - Italian production - edger with a central disc with a pneumatic jump RM 400 S - crosscut saw TP2 - multisaw Multibi R16 - minimum material length 700 mm - maximum element width 500 mm - maximum element height 140 mm - line feed speed 30 m/min - total power 110 kW - space requirement 26 x 5.5 m TECHNICAL PARAMETERS: 1 Strorti RM400 S edger - cutting width max 330 mm - cutting height max 140 mm - element width max 500 mm - maximum element length 5000 mm - engine power 3 x 11 kW - seven steel toothed bottom pulling rollers - two upper toothed pulling rollers - pneumatic material pressure - the jump of the central disc is pneumatic - feed table 5000 mm roll width 500 mm diameter 80 mm - receiving table with edging 5200 mm roll width 500 mm roll diameter 140 mm 2 Storti TP2 crosscut saw - width of the finished element max 1600 mm - wi ...

Complete line for packing, edging and filling boxes. Detailed description

4,350 pieces of grid supports, 1 to. / Pallet, for frame depth 1,10m - New - : Price per piece from location: only 30.- € (net)! Delivery is the result of a wrong order! Manufacturer: MEA Metal Applications GmbH Type: MEAMODUL made of steel S 235 JR hot-dip galvanized in a full bath Mesh pitch [mm] 33 x 66 Support rod [mm] 20 x 2 with U-profile edging and reinforcements 80 x 1.5 For beam width 50 mm (clearance between trusses > 1100 mm) Width TS 520 [mm] Length FS 1200 [mm] 10,03 kg/pcs. Load: 1,000 kg distributed load per Euro pallet mounted longitudinally and transversely Normal original price: 45.-€ (net) Condition: New Available: now Location: 86551 Aichach

Technical data for the grating: Manafacture: Gi-Ro Vreden Condition of the goods: new (unobstructed) Reason for return: Wrong order end customer The scope of delivery includes: 01x Press grate, new (unobstructed) Material color: hot-dip galvanized Ctow7lyof8 Total depth: 1,000 mm (support rod direction) Total width: 980 mm (crossbar direction) Support rod diameter: 35/1.7 mm S355JR TS anti-slip: no QS anti-slip: no Edging: T-profile 35 mm Mesh size: 90 x 50 mm Weight: approx. 9.35 kg | Pcs. Internal designation: R

Multi-saw edger by FOD Bydgoszcz DPPA-II-50-E with electronic blade setting – Polish production – DTR – fixed sleeve – movable dial with the possibility of programming 8 fixed dimensions TECHNICAL PARAMETERS: - cutting height 120 mm - cutting width 500 mm - engine power 30 kW - material width max 730 mm - four types of feed speeds - feed motor power 4 kW - spindle diameter 55 mm - sleeve diameter 90 mm - electronic adjustment of disc spacing with programmable fixed dimensions - fixed edging sleeve 60 mm - one movable disc - two rows of anti-kickback pawls - three lower pulling rollers - two upper pulling rollers - two lasers - shaft support Transport dimensions: 270x165x220 cm weight ~ 2000 kg

Technical data for the grating: Manafacture: Gi-Ro Vreden Condition of the goods: new (unobstructed) Reason for return: Wrong order end customer The scope of delivery includes: 01x Press grate, new (unobstructed) Material color: hot-dip galvanized Total depth: 1,000 mm (support rod direction) Total width: 1,230 mm (crossbar direction) Support rod dimensions: 45/1.7 mm S355JR TS anti-slip: no QS anti-slip: no Edging: T-profile 45 mm Mesh size: 60 x 40 mm Weight: approx. 18.11 kg | Pcs. Internal designation: S Your contacts in our company: Mr. Andre Evering Mr.: Mario Klöver Lord: Falk German General information about the item: This item is offered for pickup only. Any further desired transport or shipment of this item is associated with additional costs, which can be requested separately from us depending on the place of delivery or scope of delivery.

Edging saw – single-blade saw Make Torwegge Type H321 Cutting width 164 mm Chain width 160 mm Main motor approx. 11 kW Cutting height 90 mm Weight approx. 1400 kg

Workpiece thickness: 8 - 90 mm, electronically adjustable Feed rate: 18-32 m/min frequency controlled Edge thickness: 0.3 - 3 mm for roll edges, strips up to 20 mm Equipment: Inlet guide automatically adjustable via the control, extension 500 mm Joint milling unit: 2 x 3.0 KW workpiece preheating Gluing unit A34 edging magazine for roll Pressure zone with 1 driven, 6 non-driven rollers, automatic adjustment from the control Cutting unit WK14, straight, 2 motors 0.8 kW Pre-milling unit: 2 x 1.5 KW, pneumatic adjustment Form milling unit FF 12 automatic, 2 motors 0.4 kW radius/phase milling unit FF12 automatic 4 motors 0.4 KW universal milling aggregate controlled UF11, 4 kW Profile scrapers PN20 Glue scrapers Nozzles for detergent and anti-stick Polishing unit Control: Power Control PC22

Stop for press brake, edging bench, guillotine shears, drive shaft -Drive shafts: for stop, from press brake EHT type EHP 11-40 2 pieces -Length: 515 mm -Socket: Ø 25 mm -Price: complete -Dimension: Ø 50 x 515 mm -Weight 5.1 kg / pc.

Stop for press brake, edging bench, guillotine shears ... -Spare part: stop bar comes from a Dorstener BBM press brake type: APE80-3050 -Servo motor: manufacturer Stromag -Servo motor: Type: FGP311/005-40AA -Stop ruler: 2630 mm -Length unit approx.: 800 mm -Dimensions 2630/800/H340 mm -Weight 480 kg

Digital scale for press brake, edging bench, guillotine shears ... Glass scale, glass measuring stick, rule, digital display, measuring stick, length measuring system, length measuring device, linear scale, positioning display, digital scales, digital scale for digital display -from: Hammerle AP 100 press brake -Length unit: 420 mm -Number: 2x available -Price: complete -Dimensions: 550/80/H40 mm -Weight: 4.4 kg

Worm wheel and gear set, edge grinder, edge grinder, grinder, drawer grinder -a set consisting of: 1 worm wheel and 1 gear wheel for the oscillation -is a: original husband spare part -for: husband edging machine -different form: single-thread or and two-thread available -Multiple sentences: available -Price: for 1 set -Weight per set: 1.4 kg

Hand guillotine shears, guillotine shears, sheet metal shears, sheet metal shears, folding machine, edging bench -Hand guillotine shears combined with: folding machine -Cutting width: 610 mm -Max. Section thickness: 1.0 mm -Swivel bending machine -Max. Working width: 610 mm -Max. Sheet thickness: 1.0 mm -Transport dimensions: 845/910/H1230 mm -Weight: 240 kg

Stop for press brake, edging bench, guillotine shears ... -Recording with: elongated hole -Length unit: approx. 300 mm -Fine adjustment -Number: 2x available -Price: complete -Dimensions: 2x 410/320/H120 mm -Weight: 28 kg

Key data: 2 mm, 50 mm

Edge banding machine Edge banding machine OTT Type: 20S Edge banding with hot melt glue glue basin Plastic edges up to 2 mm Solid wood edging up to 20 mm Flush milling units at the top and bottom Profile milling units at the top and bottom Edge grinding unit rollable The machine originates from the age-related abandonment of a small construction and cabinetmaking workshop and is available now. Dismantling and loading can be organized by us. Settlement by appointment. Buyers can also pick up and test the machine themselves on site. Condition see pictures, or please refer to the item description. Parts can also be picked up by yourself. All measurements are approximate. All information to the best of our knowledge but without warranty. Subject to prior sale. The items can be picked up by yourself or shipped at the expense of the buyer. Shipping c ...

Workpiece thickness: 8 - 50 mm Edge thickness: Coil edges 0.4 - 3 mm Feed speed 10 m/min Equipment: manual height adjustment. Joint milling unit, 2 motors Panel edge heating Gluing area Pressure zone 1 driven and 2 non-driven rollers End trims, 2 x 0,8 kW motors, straight and chamfer 15? Top and bottom trimming Profile scraping unit for PVC edging Glue scrapers

Code: 0233 Brand: MCR - ITALY Model: EASY EDGE/5 - CE Standard Automatic edge bander for edging panels, veneer edges, PVC, solid wood, abs, etc. - CE Standard Technical data: Max edge thickness mm 5 Max panel height mm 80 Min panel height mm 10 Min panel width mm 80 Adjustable feed speed Composition: Gluing unit: Heat regulator glue tank - Heat regulator roller - Automatic strips loader End cutting unit consisting of 2 motors of 0, 37 kW - Blade diameter mm 125 - Blade inclination Fine trimming unit :allows the trimming of the top and the bottom of the applied edge - 2 motors Kw 0,37 - N° 2 combined Vidia cutters with inserts to 30° plus flat sharp Polishing unit - N° 2 motors - Brush diameter mm 160 Control panel Sound-proof cabin Total absorption A 10 Overall dimensions mm 3100 x 1000 x 1640 h Weight kg 950

Multisaw Edger FOD DPPA-II-50-E with lasers – production in Poland – DTR – fixed sleeve - cutting height 120 mm - cutting width 500 mm - engine power 30 kW - material width max 730 mm - four types of feed speed - power of the feed motor 4 kW - spindle diameter 55 mm - sleeve diameter 90 mm - electric disc spacing adjustment - fixed edging sleeve 60 mm - one movable shield - two rows of anti-recoil pawls - three lower pulling rollers - two upper pulling rollers - two lasers - shaft support Transport dimensions: 250x165x220 cm weight ~ 2000 kg Multisaws are machines used in the wood industry mainly for cutting prisms, but not only. Machines of this type can cut boards into smaller elements and cut lamellas. The principle of their operation is very simple, the machine has a spindle located in the central point, in the horizontal axis, on which tools in t ...

Pressing force 300 kN (30 t) Tools A, B, C, D Number of stations in the turret 6 (size D) Number of rotary stations 3 Max. number of tools 60 of which rotary - continuously 360° 30 Maximum punch diameter (size D )– separate 81 mm Maximum punch diameter in XMTE4M magazine 4 x 31.7 mm Maximum punch diameter in XMTE6M magazine 6 x 24.0 mm Maximum punch diameter in XMTE10M magazine 2 x 24.8 x 12.7 mm Working range in Y axis (with Multitool) 1300 mm Working range in the Y axis (single tool) 1250 mm Working range in the X axis (with Multitool) 2550 mm Numerically controlled stroke depth 0.1 – 31 mm Automatic repositioning of clamps in the X axis up to 10,000 mm Max. positioning speed in axis Y+X 80 m/min. Axis acceleration 10 m/sec² Number of strokes – ( step 1.0mm ) 1000/min USB port 6 Weight 7800 kg Max. jaw opening 11 mm Max. stroke 31 mm Power supply 3 x 400 V/50 Hz Machine power 8 ...

Gebr. Edging Press pneumatic 6 pressing units Swivel Chassis incl. heating rail ELKOM: gold anodized Length: 310 cm 220V / 1,500 W up to 100°C

Edge banding installation consisting of the following elements: - feed table TB 10/10/20 - edge bander KAR 610/20/PU/S2 - panel turning station cross/longitudinal TD 51/30/12 - destacking robot KUKA KR 180-2 PA - Ligmatech return system installation specifications: workpiece dimensions length 300 - 3200 mm width 120 - 1200 mm (for dogs), 1800 mm (equal to longitudinal entry) thickness 12 - 60 mm weight max 80 kg edging material 0.4 - 2.0 mm throughput speed 25m/min robot 10 strokes /min Equipment edge bander: Infeed fence automatically adjustable anti adhesive sprayers Squaring device UF20: 2 x 4.0 KW Workpiece preheating Glue application unit PU34 6-fold edge magazine for rolls Pressure zone with 1 driven, 6 non-driven rollers, automatic adjustment End trims HL86, pneumatic adjustment phase/straight, 2 motors 0.22 kW Rough trimming: 2 x 0.55 KW Contour trimming FF12 , 4 motors 0.4 kW Pr ...

Description: Technical data: tape thickness: 0.3 - 3 mm material thickness: 8 - 60 mm conveyor speed: 18 - 25 m / min The edgebander consists of the following aggregates: • 2 pre-milling machines for material processing (3 kW each) • material heating lamp • glue heating vessel • container with roller for applying glue to the material • push rollers • 2 stripping units (each 0.8kw) • 2 units with radial cutters for processing the upper and lower edges (1.5 kw each) • 2 postforming aggregates • 2 cyclings • polishing brushes with liquid injectors The edging is fully automated, which means that the height of the beam, pre-milling machines, rollers and all the settings of the cutter depending on the thickness of the material and the strip are adjusted on the main monitor. serial number: 0-200-19-0792, edge thickness: 0.3 - 3 mm, workpiece thickness: 8 -  ...
