edger used for sale

Linck 700 x 100 edger - German production - hydraulic disc shifting TECHNICAL PARAMETERS: - cutting width max 550 mm - cutting height max 100 mm - element width max 700 mm - engine power 22 kW - feed smoothly adjustable from 10 - 60 m/min - working length of the fixed sleeve 120 mm - working length of the movable sleeve 120 mm - minimum element length 600 mm - disc diameter max 350 mm - spindle diameter 55 mm - sleeve diameter 85 mm - spindle with steady rest - two upper pulling rollers - two lower pulling rollers - two auxiliary rollers in the tabletop - feeder length 3700 mm - feeder width 700 mm - four rollers in the table - adjustment of the disc spacing from the feeder - a row of anti-kickback pawls Transport dimensions 380x220x150 cm weight ~ 2000 kg

Esterer DKV 1 movable shaft ! feed hydraulically hydraulic and electrically roller lift: hydraulic power: 55 kW Year construction year: approx. 1982 passage: 750mm = width, 160mm = height 2 x directional laser incl. approx. 15 Circularsaws including with Splitter unit screw roll; good

Manual Edger Esterer EWD DKV with task table good condition ! Immediately available !; Well

Brand: GME Bavelloni Type: 2x Double Edger Model: MB 12 Linea, incl turning tables Construction year: 1995 Length mm: 4400 Width mm: 2800 Height mm: 2200 Transport size L x W x H: 4,4 x 2,8 x 1,3 Number of spindles: 4 x 12 spindles Condition machine : Working disassembled Photos/film available: Photos and video available Combi with: GME Triulzi Washing Machine Horizontal (23013)

Storti RM 500 edger - Italian production - Year of production 1993 - electric spacing of discs TECHNICAL PARAMETERS: - cutting width max 435 mm - cutting height max 170 mm - engine power 2 x 22kW - max element width 600 mm - minimum material length 800 mm - max disc diameter 600 mm - spindle diameter 40 mm - two upper pulling rollers - one upper pressure roller - roller motor power 2 x 1.1 kW - roller pressure with automatic jump - seven bottom pulling toothed rollers - electric disc adjustment - two lasers - feed speed 25 and 50 m/min - feeding table 2950 mm - receiving table 3000 mm - drive rollers D100 mm - power of the roller feed motor 2 x 1.5 kW Transport dimensions 500x240x180 cm weight 3500 kg

Multisaw ZLT 500 edger with 500/120 feeders – Czech production – a movable shield with the possibility of installing several shields TECHNICAL PARAMETERS: cutting width 500 mm cutting height 120 mm Min. material length 800 mm .max. disc diameter 450 mm one disc movable sleeve 70 mm fixed sleeve length 100 mm engine power 45 kW two upper pressing rollers four lower pulling ones feed smoothly adjustable on the inverter shaft support two rows of pawls max material width 700 mm length of feed rollers 3000 mm roll width 700 mm roll diameter 70 mm receiving table 6200 mm chain width 60mm seven pressure rollers two bottom pull rollers transport dimensions (length / width / height) 700 / 245 / 180 cm weight 3000 kg

Single Slab Reheat Furnace • Type: Walking Beam • Manufacturer: Davy • Capacity: 150 t/h • Inside Refractory Width: 8,35 m • Effective Length: 32,6 m • Slab Thickness: 160 mm • Slab Maximum Length: 7,5 m • Primary Fuel: mixed BFG and COG • Alternate Fuel: N°6 Fuel Oil • Commissioned in 1995 Water Descalers • Primary descaler at slab reheat furnace run out table • Front and back 3 Hi Rougher Mill descalers. • Finishing Mill descaler at run-in table. Water Descaling Pumps • Manufacturer: Union Pump Company • N° of Pumps: Two (one operating, one stand by.) • Power: 5.000 HP (3.730 kW) • Pump Speed: 4.500 rpm • Discharge Pressure: 127 barg (1.840 psig) Rougher Mill • Type: 3 Hi, one stand 22" x 34" x 100" Reversing Mill • Manufactured by Blaw-Knox in 1923. • Ma ...

Storti wood cutting line - Italian production - edger with a central disc with a pneumatic jump RM 400 S - crosscut saw TP2 - multisaw Multibi R16 - minimum material length 700 mm - maximum element width 500 mm - maximum element height 140 mm - line feed speed 30 m/min - total power 110 kW - space requirement 26 x 5.5 m TECHNICAL PARAMETERS: 1 Strorti RM400 S edger - cutting width max 330 mm - cutting height max 140 mm - element width max 500 mm - maximum element length 5000 mm - engine power 3 x 11 kW - seven steel toothed bottom pulling rollers - two upper toothed pulling rollers - pneumatic material pressure - the jump of the central disc is pneumatic - feed table 5000 mm roll width 500 mm diameter 80 mm - receiving table with edging 5200 mm roll width 500 mm roll diameter 140 mm 2 Storti TP2 crosscut saw - width of the finished element max 1600 mm - wi ...

Complete sawmill for production of about 100.000 m³/1 shift operation. Complete mill including infeed, debarking machine, scanner, canter sidebordsaw edger, curve saw equip,ment, waste disposal, stacking machine for main boards. Complete electric including 2 scanner type A-Vector. Simply complete mill

Walter WDPP-410 edger – Polish production – DTR, CE TECHNICAL PARAMETERS: min. length of the cut prism 1100 mm max. thickness of the cut prism 120 mm max. input material width 500 mm max. width of the finished board 140 mm min. width of the finished board 70 mm circular saw diameter 425 mm capacity 20 m3 right vertical spindle motor power 5.5 kW left vertical spindle motor power 5.5 kW engine speed (vertical saw drive) 2850 rpm horizontal saw engine power 18 kW engine speed (horizontal saw drive) 2850 rpm feed motor rotational speed 1450 rpm feed speed (smooth regulation) 0/20 m/min mains voltage (50 Hz) 3×400 V machine dimensions (length/width/height) 6900 / 1400 / 1380 mm machine weight 1300 kg

Very nice good working sawmilling for sale Very nice well maintained sawmill line for sale Consisting of: Log task 4 strands, Isolation, regular users and depositors, Fully hydraulic tensioner Mayerhofer, Sash gang saw EWD GDZ GE 71 (passage 71 cm) Riving knife, Cuttingsaw for boards (automatic) Roller conveyor with pullers, cross conveyor for trimming, Edger PAUL KME II - Spliter unit,, Roller conveyor, Kick-off conveyor . grinders Very well-kept LINE! READY TO WORK

Multisaw Edger FOD DPPA-II-50-E with lasers – production in Poland – DTR – fixed sleeve - cutting height 120 mm - cutting width 500 mm - engine power 30 kW - material width max 730 mm - four types of feed speed - power of the feed motor 4 kW - spindle diameter 55 mm - sleeve diameter 90 mm - electric disc spacing adjustment - fixed edging sleeve 60 mm - one movable shield - two rows of anti-recoil pawls - three lower pulling rollers - two upper pulling rollers - two lasers - shaft support Transport dimensions: 250x165x220 cm weight ~ 2000 kg Multisaws are machines used in the wood industry mainly for cutting prisms, but not only. Machines of this type can cut boards into smaller elements and cut lamellas. The principle of their operation is very simple, the machine has a spindle located in the central point, in the horizontal axis, on which tools in t ...

Multi-saw edger by FOD Bydgoszcz DPPA-II-50-E with electronic blade setting – Polish production – DTR – fixed sleeve – movable dial with the possibility of programming 8 fixed dimensions TECHNICAL PARAMETERS: - cutting height 120 mm - cutting width 500 mm - engine power 30 kW - material width max 730 mm - four types of feed speeds - feed motor power 4 kW - spindle diameter 55 mm - sleeve diameter 90 mm - electronic adjustment of disc spacing with programmable fixed dimensions - fixed edging sleeve 60 mm - one movable disc - two rows of anti-kickback pawls - three lower pulling rollers - two upper pulling rollers - two lasers - shaft support Transport dimensions: 270x165x220 cm weight ~ 2000 kg

Brand: GME Triulzi Type: Washing Machine Horizontal Length mm: 6000 Width mm: 3800 Height mm: 5500 Transport size L x W x H: 6,0 x 3,8 x 1,4 Number of brushes: 4 brushes Condition machine : Working disassembled Remaining: Combi with: GME Bavelloni 2x Double Edger (23010)

Multisaw ZLT 500 edger with 500/120 feeders – Czech production – a movable shield with the possibility of installing several shields cutting width 500 mm cutting height 120 mm min. material length 800 mm max. disc diameter 450 mm one disc movable sleeve 70 mm fixed sleeve length 100 mm engine power 45 kW two upper pressing rollers four lower pulling ones feed smoothly adjustable on the inverter shaft support two rows of pawls max material width 700 mm length of feed rollers 3000 mm roll width 700 mm roll diameter 70 mm receiving table 6200 mm chain width 60mm seven pressure rollers two bottom pull rollers transport dimensions (length / width / height) 700 / 245 / 180 cm weight 3000 kg

Raimann KS 310 BV edger multisaw - year of manufacture 1995 - German production - DTR - automatic spacing of discs with the possibility of programming - two movable discs TECHNICAL PARAMETERS: - track width 340 mm - cutting height max 120 mm - engine power 30 kW - disc diameters 250/360 mm - Possibility to put on a shoe - electric height adjustment - feed continuously adjustable 11-38 m / min - power of the feed motor 1.5 kW - two movable discs - possibility to program 10 dimensions per disc - control 69 P22 - three lasers - max element width 1000 mm - minimum element length 600 mm with a shoe 400 mm - four upper pressure rollers - spindle diameter 65 mm - sleeve diameter 80 mm - spigot diameter 250 mm Dimensions 230x220x230 weight 2500 kg

Multisaw Edger ZLT 500 with feeders 500/140 - Czech production - a movable target TECHNICAL PARAMETERS: cutting width 500 mm cutting height 140 mm min. material length 800 mm max. blade diameter 450 mm one movable target engine power 30 kW four lower pulling shafts two upper pressure shafts feed smoothly regulated on the inverter shaft steady two rows of pawls feed rolls 4 pieces roll length 600 mm roll width 450 mm roll diameter 70 mm receiving table 6200 mm chain width 60 mm seven pressure rollers two lower pulling rollers transport dimensions (length / width / height) 700/245/180 cm weight 3000 kg

Multisaw Edger two floating discs Raimann KS 310 BV - year of manufacture 1995 - German production - DTR - automatic spacing of discs with the possibility of programming - two movable discs TECHNICAL PARAMETERS: - track width 340 mm - cutting height max 120 mm - engine power 30 kW - disc diameters 250/360 mm - Possibility to put on a shoe - electric height adjustment - feed continuously adjustable 11-38 m / min - power of the feed motor 1.5 kW - two movable discs - possibility to program 10 dimensions per disc - control 69 P22 - three lasers - max element width 1000 mm - minimum element length 600 mm with a shoe 400 mm - four upper pressure rollers - spindle diameter 65 mm - sleeve diameter 80 mm - spigot diameter 250 mm Dimensions 230x220x230 weight 2500 kg

Multi-saw Edger PAUL K34V / 1000 / L 900/100 - after the technical review - very good condition - DTR - perfect for cutting boards - German production TECHNICAL PARAMETERS: cutting width 900 mm cutting height 100 mm 55 kW main engine 5 kW hydraulic pump motor hydraulic feed adjustment hydraulic height adjustment six upper pull rollers six lower pull rollers spindle rest max. blade diameter 350 mm spindle diameter 60 mm sleeve diameter 75 mm two rows of pawls transport dimensions (length / width / height) 400/185/170 cm weight ~ 2200 kg

Walter WDPP-410 edger The WDPP-410 flashing machine is widely used in many sawmill plants. The design of the machine and the principles of its operation allow for quick recovery of purchase costs and limiting raw material losses to a minimum. Reliable operation and safe operation of the saw translate into a high efficiency rate. – Polish production – DTR, CE min. length of the cut prism 1100 mm max. thickness of the cut prism 120 mm max. input material width 500 mm max. width of the finished board 140 mm min. width of the finished board 70 mm circular saw diameter 425 mm capacity 20 m3 right vertical spindle motor power 5.5 kW left vertical spindle motor power 5.5 kW engine speed (vertical saw drive) 2850 rpm horizontal saw engine power 18 kW engine speed (horizontal saw drive) 2850 rpm feed motor rotational speed 1450 rpm feed speed (smooth regulation) 0/20 m/m ...

For sale is the SCHIATTI edger, model FPS 10, built in 2009 in very good condition, with only 20,700 meters !

Description: Set  ,of 2 diamond edger cutters , Diameter: 80x50x30 , Axis:  ,Z-3+3 , Spindle  ,speed max. : , , , ,18000 rpm , Approx. Onsite Dimension. (l x w x h): 400 x 400 x 300 mm, weight approx.: 6 kg
