120,835 used machines on RESALE, but how to find them? Machine Search
used
Description: Edgebander with glue pot, edge trimming unit, trimming unit, feed with various speeds, suitable for gluing solid wood up to 3 mm Approx. Onsite Dimension. (l x w x h): 3,000 x 1,500 x 1,400 mm, weight approx.: 780 kg
used
Description: Edgebander with glue pot and the following units: End trimming Roughers Fine trimmers Edge scraping Brushes Complete with bar for holding particularly large workpieces Approx. Onsite Dimension. (l x w x h): 4,000 x 1,800 x 1,600 mm, weight approx.: 1,800 kg
used
Description: Edgebander with glue pot for edge and solid wood End trimmers Edge Trimmer and spindle moulder with programmable intervention 2-speed adjustable feed Approx. Onsite Dimension. (l x w x h): 3,900 x 1,200 x 1,800 mm, weight approx.: 1,050 kg
used
Description: Edgebander for veneers and solid wood, consisting of: End trimming unit Rough Trimming unit Fine Trimming unit Telescopic support for holding large workpieces Approx. Onsite Dimension. (l x w x h): 5,300 x 1,600 x 1,400 mm, weight approx.: 1,650 kg
used
Description: IMA COMPACT PC/F/DV/6220 Edgebander Panel thickness: 10 mm Pre-Milling Unit Edge thickness: 12 mm End trimming unit Rough Milling unit MFA Milling unit (fine trimming + Corner rounding) Profile Scraper + Flat Scraper + Buffing unit Feed advance: 12 m/min Cut shear to: 0.2 - 3 mm Working height: 873 mm Max plate thickness: 45 mm serial number: 07048, control: IMA, Approx. Onsite Dimension. (l x w x h): 7,450 x 1,000 x 2,000 mm, weight approx.: 3,000 kg
used
Description: HOLZ-HER LUMINA 1380 Edgebander Feed rate: 10 - 18 m/min Operating dimensions Minimum workpiece length: 160 mm Minimum workpiece width: 60 mm Workpiece thickness: 8 - 60 mm Edging thickness: 0.4 - 8 (15) mm Approx. Onsite Dimension. (l x w x h): 5,740 x 1,200 x 2,100 mm, weight approx.: 2,000 kg, Serial Number of Manufacturer: 289/1-907
used
Description: GRIGGIO GB 5/8 RA Edgebander Workpiece thickness: 10 - 60 mm Max thickness of the panel: 60 mm Min width of the panel: 60 mm Min length of the panel: 120 mm Min thickness of the panel: 10 mm Edge thickness: 0,4 - 8 mm Edge dimensions in roll: 0,4 - 3 mm serial number: 15E000243900300, control: SIEMENS SMART LINE, Approx. Onsite Dimension. (l x w x h): 5,500 x 1,100 x 1,600 mm, weight approx.: 2,500 kg
used
Description: IMA ADVANTAGE 4612 Edgebander Motor data: 380 V - 50 Hz - 15 Kw - 37 A Suction nozzle: 120 mm Pre-wired for Pre-milling Unit Space Edge thickness: 0.4 - 12 mm Workpiece thickness: 10 - 45 mm Edge material height: 14 - 55 mm End trimming unit Rough Milling unit MFA Milling Unit (Fine Milling + Corner Rounding) Profile Scraper + Flat Scraper + Buffing unit Feed approx.: 12 m/min Compressed air approx.: 7 bar serial number: 02305, edge thickness: 0,4 - 12 mm, workpiece thickness: 50 mm, feed: 12 m/min, control: IMA 1101, Approx. Onsite Dimension. (l x w x h): 6,100 x 1,800 x 2,000 mm, weight approx.: 3,100 kg
used
Description: Technical data: tape thickness: 0.3 - 3 mm material thickness: 8 - 60 mm conveyor speed: 18 - 25 m / min The edgebander consists of the following aggregates: • 2 pre-milling machines for material processing (3 kW each) • material heating lamp • glue heating vessel • container with roller for applying glue to the material • push rollers • 2 stripping units (each 0.8kw) • 2 units with radial cutters for processing the upper and lower edges (1.5 kw each) • 2 postforming aggregates • 2 cyclings • polishing brushes with liquid injectors The edging is fully automated, which means that the height of the beam, pre-milling machines, rollers and all the settings of the cutter depending on the thickness of the material and the strip are adjusted on the main monitor. serial number: 0-200-19-0792, edge thickness: 0.3 - 3 mm, workpiece thickness: 8 - ...
used
Description: Position: 1 SubFamily: Edgebander BATCH 1 Brand: BIESSE Model: STREAM B1 10.5 MDS Type of edging Thin edge Thick edge Gluing System EVA Hotmelt  ,  ,  ,  ,  ,  ,  ,  ,  ,  ,  ,  ,  ,  ,  ,  ,  ,  , Premilling Unit , Corner Rounding Unit Grooving Unit , Maximum panel thickness 60 mm Max. panel height 60 mm Min. panel length 150 mm Min. panel width 65 mm Min. edge thickness 0.3 mm Max. forward feed speed 25 m/min Pressure with rubber belt Panel support guides , with positioning by NC , Infeed panel alignment system , MDS No. Panel Sizing / Milling units Unit : pre-milling unit automatic timed intervention Edge coil magazine , no. positions 12 glue pot for EVA hot melt glue , premelter for EVA hot melt glue , no. pressure roller 4 with positioning by NC , No. Edge Process ...
new
Type HLP Voltage 220 V Power 400 W Length 120 mm Diameter 8 mm Made in Germany Weight 70 g
used
Technical details: - Premilling Unit - Corner Rounding Unit - Max feed speed: 30 m/min - Max panel thickness: 60 mm - Operating Units: 8
used
Technical details: - Premilling Unit - Corner Rounding Unit - Maximum panel thickness: 65 mm - Operating Units: 9
used
Manufacturer: Hebrock, Type: AKV 88 F, Year: 1997, Control: hand, Glue application: no, Edgeband thickness max mm: 3,0, Edgeband height max mm: 50, Edgeband thickness max mm: 3,0, Glue system granulate/cartridge: Wärmedusche, Feeding speed min-max m/min: 0-7, Mitre stations: yes, FREE TEXT: Elektronische Eintellung der Kantenlänge, Year :1997
used
Manufacturer: Brandt, Type: KTD 72, Year: 2002, Control: yes, Glue application: yes, Edgeband thickness max mm: 3, Edgeband height max mm: 50, Edgeband thickness max mm: 3, Thickness of coiled edgeband max mm: 3, Feeding speed max m/min: hand, Thickness of coiled edgeband max mm: 3, Inner circle min mm: yes, Total power kW: 8, Feeding speed max m/min: hand, Compressed air bar: 6, Wight approx. kg: 300, Required space L x W x H mm: 1500 x 1500 x1200, Year :2002
used
Description: Features: Panel protrusion beyond the constant chain guide 38 mm Minimum passage width 65 mm Minimum panel length 150 mm Height from the ground 950mm Panel: Minimum thickness 8 mm Maximum thickness 40 mm (with rounding) 60 mm (without rounding) Edge: Min. Height 14mm Max Height 65mm Min. thickness 0.3mm Max Thickness 3mm Max Section 130 mm2 Min. Edge length 160 mm Strip: Min. thickness 0.8mm Max Thickness 20mm Conveyor chain/with plastic coated plates continuous width approx. 80 mm with automatic central lubrication Top pressure system electronically height adjustable with a 70 mm wide belt and sprung guide rollers System software IMATRONIC 121/01 User interface oriented to the requirements of small machines Integrated SPS software. Fully S5 compatible programming. Integrated line control with max. 64 line functions. Compact PC in industrial version with front panel (p ...
used
Description: For veneers and solid wood Working units with end trimmer, rough trimming unit, fine trimming unit The machine can working up to 4/5 mm edge and solid wood Approx. Onsite Dimension. (l x w x h): 5,000 x 1,800 x 1,600 mm, weight approx.: 1,500 kg
used
Description: serial number: 1000017130 control: BIESSE  , max. glue thickness: 3 mm max. glue-on height: 65 mm max. thickness of roll material: 3 mm min. workpiece length: 100 mm min. workpiece width: 150 mm max. workpiece thickness: 90 mm max. feed rate: 25 m/min.  , comfortable looptec system BIESSE 2 glueing units in the row (exchange of color from panel) CNC set up off all machine from panel maximum thickness of panel: up to 90 mm Nordson system for PUR included (wtih conecton to one gluing unit) airforce system change of glue + tape based on the barcode CNC grooving unit  , please also have a look at the video and the PDF documents of this machine serial number: 1,000,017,130, workpiece thickness: 90 mm, feed: 25 m/min, control: BIESSE, Approx. Onsite Dimension. (l x w x h): 12,000 x 3,500 x 2,000 mm, weight approx.: 12,000 kg
used
Description: machine number: 0-261-20-8279 workpiece thickness: 8 - 50 mm edge material thickness: 0,4 - 3 mm feed speed: 11 m/min extraction diameter: 3x80/1x100 mm pneumatics: 6 bar  , please also have a look at the PDF document of this machine serial number: 0-261-20-8279, edge thickness: 3 mm, workpiece thickness: 8 - 50 mm, feed: 11 m/min, Approx. Onsite Dimension. (l x w x h): 4,153 x 1,525 x 2,182 mm, weight approx.: 1,300 kg
used
Description: supply voltage 3 x 400 (50 Hz) V standard installed power 11 kW, with the airmotion option 16 kW feeding table with air cushion 1050 x 400 mm milling group application group cutting group at the ends rounding group at the ends radia finishing group surface finishing group finishing group with brushes constructive characteristics, standard working dimensions: the minimum width of the processed part - 70 mm the minimum length of the processed part - 140 mm the minimum height of the processed part - 8 mm the maximum height of the processed part - 60 mm the thickness of the applicable PVC/ABS edge film - 0.4 - 3.0 mm applicable thickness of solid wood wand - 0.4 - 12.0 mm compressed air working pressure (min/max) >,7 / 12 bar compressed air system pressure >,8 bar internal diameter of compressed air installation connection: 13 / 1/2' mm for more details ...
used
Description: serial number 209/1-506 series KAM15V3 ordernumber 15506565 control PPC 315 with Touchsreen feed rate: 10 - 18 m/min workpiece length: min. 160 mm workpiece width: min. 60 mm workpiece thickness: 8 - 60 mm edge thickness: 0.4 - 8 mm serial number: 209/1-506, workpiece thickness: 8 - 60 mm, feed: 10-18 m/min, control: PPC 315, Approx. Onsite Dimension. (l x w x h): 5,340 x 1,823 x 2,030 mm, weight approx.: 1,750 kg
used
Description: HOMAG OPTIMAT KAL 310 / 7 / A20 / S2 Edge Bander with return sistem control - yes edge buffing unit - yes edge magazine with - yes edge sanding unit - no edge thickness - yes feed - 18-20 mts/min fine trimming unit - yes flat scraping unit - yes gluing unit - yes joint trimming unit - yes , profile scraping unit - yes profile trimming unit - yes return system - yes , workpiece overhang - 30 mm workpiece pre heater - yes workpiece thickness - 10-60 mm dimension (l x w x h) and weight approx. (6 packs) 8800 x 1000 x 1900 mm - 5000 Kg 3500 x 1300 ,x 900 mm - 300 Kg 2900 x 1800 x 900 mm - 600 Kg 6400 x 1300 x 900 mm - 1000 Kg 2000 x 1300 x 900 mm - 200 Kg 800 x 500 x 1000 mm - 100 Kg workpiece thickness: 10 - 60 mm, workpiece overhang: 30 mm, feed: 18 - 20 m/min, joint trimming unit: Yes, workpiece pre heater: Yes, gluing unit: Yes, fine trimming u ...
used
Description: IMA ADVANTAGE 550 Edge Bander workpiece thickness: 10 - 60 mm, workpiece overhang: 30 mm, workpiece pre heater: Yes, gluing unit: Yes, fine trimming unit: Yes, profile trimming unit: Yes, edge sanding unit: No, flat scraping unit: Yes, profile scraping unit: Yes, edge buffing unit: Yes, control: Yes, Approx. Onsite Dimension. (l x w x h): 7,750 x 1,280 x 1,700 mm, weight approx.: 2,500 kg
used
Description: HOMAG KAL 310 Edge Bander control - yes Joint milling unit - yes edge magazine with - yes End trimming unit - yes edge thickness - yes feed 18 - 20mts / min fine trimming unit - yes flat scraping unit - yes profile trimming unit - yes Buffing unit - yes universal milling unit - no workpiece overhang - 30 mm workpiece pre heater - yes workpiece thickness 10 - 60 mm workpiece thickness: 10 - 60 mm, workpiece overhang: 30 mm, feed: 18 - 20 m/min, workpiece pre heater: Yes, fine trimming unit: Yes, profile trimming unit: Yes, universal milling unit: No, flat scraping unit: Yes, control: Yes, Approx. Onsite Dimension. (l x w x h): 3,830 x 2,390 x 1,980 mm, weight approx.: 1,500 kg
used
Description: The machine will not be available until around May 2024. Basic machine Continuous machine stand for setting up the processing unit Workpiece support with roller rail, extendable approx. 800 mm Glue roller drive for feed stop Glue container lift for feed stop Workpiece-operated glue container clamping Adjustable infeed guide Pneumatically controlled infeed stop Workpiece transport device Transport chain 80 mm wide Precision running and guide surfaces hardened Transport chain magnetically braked Top pressure driven by composite V-belt Manual height adjustment Digital position indicator Technical data Operating voltage: 400 Volt, 50/60 Hz Feed rate: 18 - 25 m/min Feed rate with FK11 profile cutter: max. 20 m/min Working height: 950 mm Working width for workpiece thickness 22 mm: min. 60 mm Working width for workpiece thickness 40 mm: min. 105 mm ...
used
edge thickness: 0,5 - 3 mm, workpiece thickness: 10 - 45 mm, gluing unit: ja / yes, snipping unit: ja / yes, fine trimming unit: ja / yes, Approx. Onsite Dimension. (l x w x h): 3,500 x 1,500 x 1,800 mm, weight approx.: 700 kg
used
Description: Workpiece thickness 6 - 50 mm Min. length 60 mm Maximum width 180 mm Approx. Onsite Dimension. (l x w x h): 4,000 x 1,200 x 1,400 mm, weight approx.: 970 kg
used
Description: Max. board thickness 15 mm, max. solid wood height 50 mm, min. panel length 150 mm, min. workpiece width 50 mm, max. feeding speed 20 m/min, total power 10 KW, Glueing unit complete with edge press rollers End cutting unit Trimmer unit Edge trimming unit Edge scraper unit Brush unit Approx. Onsite Dimension. (l x w x h): 4,500 x 1,200 x 1,450 mm, weight approx.: 1,200 kg
used
Description: Edge height max 51 mm Minimum workpiece length mm: 180 Electro-motor height adjustment: yes  , edge thickness: max 13 mm, workpiece width min.: 60 mm, feed: 11 m/min, gluing unit: YES, snipping unit: YES, rough trimming unit: YES, fine trimming unit: YES, profile scraping unit: YES, edge buffing unit: YES, Approx. Onsite Dimension. (l x w x h): 0 x 0 x 0 mm, weight approx.: 0 x 0 x 0 kg
used
Description: -Edge height: 13 - 50 mm -Max. solid wood cross-section: 15x45 mm -Min panel length: 140 mm -Min panel width (with 150 mm length): 85 mm -Min panel width (with length 250 mm): 50 mm -Three-phase line -Voltage: 380 V -A max: 22 -Frequency: 50 Hz -Max inverter frequency: 200 Hz -Control voltage: 110 V -Motor power: 15 Kw - 53 A - 11 Nl/cycle edge thickness: 0.5 - 15 mm, workpiece thickness: 10 - 45 mm, workpiece overhang: 25 mm, feed: 10 - 20 m/min, Approx. Onsite Dimension. (l x w x h): 6,300 x 1,450 x 1,450 mm, weight approx.: 2,550 kg
used
Description: Min Panel Width 80 mm Max Panel Thickness 60 mm Thickness Min 10 mm Panel Feeding Speed 9-14 m / min 380 V 50 Hz Motor Power 8 Kw Noise 84.8 Db Approx. Onsite Dimension. (l x w x h): 1,400 x 1,100 x 1,200 mm, weight approx.: 800 kg
used
Description: Basic equipment Ribbed steel machine stand with tubular reinforcements for optimum work unit support Pivoting control panel Support roller track with ball bushing guide along the entire length of the machine Protective hood with sound-absorbing material, complete with interior lighting for the cabin and gluing area Extraction nozzle arranged on the sound-absorbing hood Electrical system with lockable main switch and thermomagnetic motor protection switch Emergency/off button in the infeed and outfeed inverter Panel feed system feed chain with rubber sliding shoes, attached to 1' ¼ industrial chain with high friction coefficient the chain slides on chain guides on 2 hardened and ground steel guides, one round and one flat, to ensure straight feed and protect against lateral displacement Automatic central lubrication of the feed chain the upper pressure beam ...
used
Description: machine number 0-261-20-6375 edgeband thickness max 3 mm thickness of coiled edgeband max , ,  ,3 mm feedrate max 10 m/min corner rounding unit 1 motor scraper unit , ,  ,Profile scraper control , ,  ,BRANDT EASYCONTROL EC 10+ edgeband height max , ,  ,54 mm workpiece length min , ,  ,70 mm preheating zone , ,  , glue system granulate glue pot below feeding chain quick-change glue pot , ,  , trimming saw 2 motors flush/radius/chamfer milling units , ,  ,1 buffing unit , ,  , magazine for single strips , ,  , type right-side machine supply 400 V/230 V, 3 phases, 50 Hz max. operating full load current 8 A, fuse 16 A control voltage 24 V , total connection , ,  ,5,5 kW  , serial number: 0-261-20-6375, edge thickness: ...
used
Description: Workpiece and edge parameters Workpiece width min: For workpiece thickness 8-22 mm | 70 mm For workpiece thickness 23-40mm | 120 mm For workpiece thickness 41-60mm , 150 mm depending on the workpiece length Workpiece protrusion | 38 mm Workpiece thickness | 8 - 60 mm Max. edge height = workpiece height, + 6 mm Edge material roll / 0.4 - 3 mm Edge cross-section max. For PVC | 135 mm For veneer | 100 mm Max. roll diameter , 830 mm Edge material strip , 0.4 - 15 mm (or 12 mm) (When using the VKNR 4845 exchange trimming unit, the max. edge thickness is 12 mm!) Max. edge cross-section For strips ' 600 mm If no radius is specified, R=2 mm is retracted and delivered serial number: 0-261-20-5413, workpiece thickness: 8 - 60 mm, feed: 8 - 18 m/min, joint trimming unit: 2 x 2,2 kW, gluing unit: A12, snipping unit: 2 x 0,35 kW, rough trimming unit: 2 x 0,55 kW, ...
used
Description: Type of edging Thin edge Thick edge Gluing System EVA Hotmelt Premilling Unit yes Corner Rounding Unit yes Max feed speed 11 m/min Maximum panel thickness 50 mm Operating Units 8 nr Min. panel height 8 mm Max. panel height 50 mm Min. edge thickness 0.4 mm Max. edge thickness 3 mm Max. forward feed speed 11 m/min Top pressure yes Panel support guides yes No. Panel Sizing / Milling units 1 NO. PANEL SIZING / MILLING UNITS 1 Unit : pre-milling unit automatic timed intervention : yes motor power : 2.2 KW Edge coil magazine yes no. positions 1 Gluing system yes glue pot for EVA hot melt glue yes Roller set to press the edge yes no. pressure roller 3 No. Edge Processing Units 5 NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming no. motors : 2 motor power : 0.18 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 2 Processing Unit : top and bottom rough trimming no. motors : 2 ...
used
Description: Max. panel height 60 mm Min. panel length 130 mm Min. panel width 65 mm Min. edge thickness 0.4 mm Max. edge thickness 3 mm Max. forward feed speed 30 m/min Pressure with rubber belt No. Panel Sizing / Milling units , Unit : pre-milling unit Constructor model : R3 L20 motor power : 4 KW r.p.m. : 9000 RPM Lamps to preheat the side of the panel , Edge coil magazine , no. positions 2 glue pot for EVA hot melt glue , premelter for PUR glue , Roller set to press the edge , no. pressure roller 5 No. Edge Processing Units 10 Processing Unit : end trimming Constructor model : 8,42/39/B no. motors : 2 Processing Unit : fine trimming to trim and round Constructor model : 08.055 Processing Unit : Corner rounding Constructor model : 08.342 Processing Unit : edge scraping Processing Unit : belt sanding Constructor model : 08.62 Processing Unit : belt sanding Const ...
used
Description: Max. panel width 3300 mm Min. edge thickness 0.4 mm Max. edge thickness 3 mm Max. forward feed speed 30 m/min Conveyor Track with dogs , Pressure with rubber belt NO. PANEL SIZING / MILLING , Unit : scoring unit motor power : 4.4 KW r.p.m. : 6000 RPM NO. PANEL SIZING / MILLING , Unit : double chipper, top and bottom Constructor model : 75.30 NO. PANEL SIZING / MILLING , Unit : miller hogger NO. PANEL SIZING / MILLING , Unit : miller hogger Edge coil magazine , no. positions 2 glue pot for EVA hot melt glue , premelter for EVA hot melt glue , Roller set to press the edge , no. pressure roller 5 No. Edge Processing Units , Processing Unit : end trimming Constructor model : 08.412 no. motors : 2 Processing Unit : fine trimming to trim and round Constructor model : 08.055 no. motors : 2 Processing Unit : Corner rounding Constructor model : ...
used
Description: Type of edging Thin edge Thick edge Solid wood Gluing System PUR Premilling Unit yes Corner Rounding Unit yes Grooving Unit yes Max feed speed 24 m/min Maximum panel thickness 60 mm Operating Units 9 nr Min. panel height 12 mm Max. panel height 60 mm Min. edge thickness 0.4 mm Max. edge thickness 20 mm Max. forward feed speed 24 m/min Top pressure yes Pressure with rubber belt Panel support guides yes No. Panel Sizing / Milling units 1 NO. PANEL SIZING / MILLING UNITS 1 Unit : pre-milling unit automatic timed intervention : yes Gluing system yes glue pot for PUR glue yes premelter for PUR glue yes premelter for PUR glue NORDSON Roller set to press the edge yes with positioning by NC yes No. Edge Processing Units 7 NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming no. motors : 2 NO. EDGE PROCESSING UNITS 2 Processing Unit : top a ...
used
Description: Type of edging Thin edge Thick edge Gluing System PUR Combination Squaring Edgebanding Machine First Pass Max Panel Width 3000 mm Max feed speed 40 m/min Operating Units Right Side 10 nr Operating Units Left Side 10 nr Min. panel height 8 mm Max. panel height 60 mm Min. panel width 240 mm Max. panel width 3000 mm Min. edge thickness 0.4 mm Max. edge thickness 3.5 mm Max. forward feed speed 40 m/min Top pressure yes Pressure with rubber belt Panel support guides yes No. Panel Sizing / Milling units Left Side 1 NO. PANEL SIZING / MILLING UNITS LEFT SIDE 1 Unit : double chipper, top and bottom Constructor model : KD 11 motor power : 4.5 KW r.p.m. : 6000 RPM Same technical characteristics on the left side yes Edge coil magazine yes no. positions 12 Gluing system yes glue pot for PUR glue yes premelter for PUR glue yes Roller set to press the edge yes No. Edge Processing Units 8 ...
used
Description: Max. panel height 50 mm Min. edge thickness 0.4 mm Max. edge thickness 5 mm Max. forward feed speed 12 m/min Pressure with idle wheels NO. PANEL SIZING / MILLING UNITS , Unit : pre-milling unit automatic timed intervention motor power : 1.8 KW Edge coil magazine yes glue pot for EVA hot melt glue , premelter for EVA hot melt glue , Roller set to press the edge , no. pressure roller 4 NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming no. motors : 2 motor power : 0.35 KW NO. EDGE PROCESSING UNITS 2 Processing Unit : top and bottom rough trimming no. motors : 2 motor power : 0.65 KW NO. EDGE PROCESSING UNITS 3 Processing Unit : fine trimming to trim and round no. motors : 2 motor power : 0.65 KW NO. EDGE PROCESSING UNITS 4 Processing Unit : Corner rounding no. motors : 2 motor power : 0.5 KW NO. EDGE PROCESSING UNITS 5 Processing Unit : edge scraping NO ...
used
Description: Max. panel height 55 mm Min. edge thickness 0.4 mm Max. edge thickness 12 mm Max. forward feed speed 13 m/min Pressure with idle wheels NO. PANEL SIZING / MILLING UNITS Unit : pre-milling unit automatic timed intervention motor power : 2.2 KW Edge coil magazine glue pot for EVA hot melt glue premelter for EVA hot melt glue Roller set to press the edge no. pressure roller 4 NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming no. motors : 2 automatic timed intervention motor power : 0.35 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 2 Processing Unit : fine trimming to trim and round no. motors : 2 motor power : 0.55 KW r.p.m. : 11300 RPM NO. EDGE PROCESSING UNITS 3 Processing Unit : Corner rounding no. motors : 2 motor power : 0.4 KW NO. EDGE PROCESSING UNITS 4 Processing Unit : glue scraping NO. EDGE PROCESSING UNITS 5 Processing Unit : buffing no. motors : 2 motor ...
used
Description: Type of edging Thin edge Thick edge Solid wood Gluing System EVA Hotmelt Premilling Unit yes Corner Rounding Unit yes Max feed speed 14 m/min Maximum panel thickness 60 mm Operating Units 8 nr Min. panel height 8 mm Max. panel height 60 mm Min. panel width 70 mm Min. edge thickness 0.3 mm Max. edge thickness 3 mm Max. forward feed speed 14 m/min Top pressure yes Pressure with idle wheels Panel support guides yes with positioning by NC yes No. Panel Sizing / Milling units 1 NO. PANEL SIZING / MILLING UNITS 1 Unit : pre-milling unit automatic timed intervention : yes motor power : 2.2 KW Lamps to preheat the side of the panel yes Edge coil magazine yes no. positions 1 Gluing system yes glue pot for EVA hot melt glue yes premelter for EVA hot melt glue yes Roller set to press the edge yes no. pressure roller 3 with positioning by NC yes No. Edge Processing Units 6 NO. EDGE PROC ...
used
Description: Type of edging Thin edge Thick edge Solid wood Gluing System EVA Hotmelt Max feed speed 9 m/min Maximum panel thickness 50 mm Operating Units 4 nr Min. panel height 8 mm Max. panel height 50 mm Min. edge thickness 0.4 mm Max. edge thickness 3 mm Max. forward feed speed 9 m/min Top pressure yes Pressure with idle wheels Panel support guides yes Edge coil magazine yes no. positions 1 Gluing system yes glue pot for EVA hot melt glue yes Roller set to press the edge yes no. pressure roller 3 No. Edge Processing Units 3 NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming no. motors : 2 motor power : 0.18 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 2 Processing Unit : fine trimming to trim and round no. motors : 2 motor power : 0.27 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 3 Processing Unit : glue scraping Safety standard CE mark yes Total installed power 3.5 KW ...
used
Description: Type of edging Thin edge Thick edge Solid wood Gluing System EVA Hotmelt Corner Rounding Unit yes Max feed speed 11 m/min Maximum panel thickness 55 mm Operating Units 7 nr Min. panel height 8 mm Max. panel height 50 mm Min. edge thickness 0.4 mm Max. edge thickness 8 mm Max. forward feed speed 11 m/min Top pressure yes Pressure with idle wheels Panel support guides yes No. Panel Sizing / Milling units 1 NO. PANEL SIZING / MILLING UNITS 1 Unit : pre-milling unit automatic timed intervention : yes motor power : 2.2 KW Edge coil magazine yes no. positions 1 Gluing system yes glue pot for EVA hot melt glue yes Roller set to press the edge yes No. Edge Processing Units 5 NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming Constructor model : HL 6130 no. motors : 2 motor power : 0.18 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 2 Processing Unit : fine trimming to trim ...
used
Description: Complete with Pieces returning system LIGMATECH See more technical detail in the BROCHURE Composition: Infeed grinding Glue pre-melter Glue tank Edge banders Trimming units Corner rounding Edge scraping Edge trimming Brushes Parts return Approx. Onsite Dimension. (l x w x h): 9,000 x 1,800 x 2,000 mm, weight approx.: 1,200 kg
used
Description: COMPOSITION: Anti-adhesive group Grinding group Infrared lamp Glue tank group Pneumatic shear, pressure rollers, edge feeding system Trimming group Edge trimming group Edge scraping group Brush group TECHNICAL DATA Panel height 8 - 45 mm Edge thickness 0.4 - 3 mm (coil) / 0.4 - 5 mm (strips) Minimum panel width 95 mm Minimum panel length (edge side) 210 mm Panel feeding ,speed 7 m/min Infeed grinding motors (each) 200 Hz - 12,000 rpm - 0.75 kW Glue tank resistors 1490 W - 6 cartridges Trimming blade rotation speed 9,000 rpm Trimming motor 50 Hz - 0.18 kW Trimming motors (each) 200 Hz - 12,000 rpm - 0.22 kW Milling tools ,with WIDIA combined knives (radius/chamfer) Ø 75 mm Z4 - shaft ,Ø 16 mm (r=2 - 3 mm) Total installed power approx. 5 kW Approx. Onsite Dimension. (l x w x h): 2,450 x 800 x 1,450 mm, weight approx.: 450 kg
used
Description: Min. edge thickness 0.3 mm Max. edge thickness 3 mm , Max. forward feed speed 25 m/min Pressure with rubber belt Panel support guides , with positioning by NC , Infeed panel alignment system , NO. PANEL SIZING / MILLING UNITS , Unit : pre-milling unit automatic timed intervention motor power : 3 KW r.p.m. : 9000 RPM Lamps to preheat the side of the panel , Edge coil magazine , glue pot for EVA hot melt glue premelter for EVA hot melt glue , Roller set to press the edge no. pressure roller 7 with positioning by NC , No. Edge Processing Units 7 NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming no. motors : 2 motor power : 0.8 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 2 Processing Unit : top and bottom rough trimming no. motors : 2 motor power : 1.5 KW r.p.m. : 12000 RPM , NO. EDGE PROCESSING UNITS 3 Processing Unit : Corne ...
used
Description: - Inlet ruler with automatic adjustment and extension 500 mm - BONDING PART A20 BASIC - Pressure zone C with automatic adjustment - Release agent spray unit - Pre- and profile milling unit with pneumatic adjustment - Edge sanding unit KS10 - Profile sanding unit top/bottom PS41 / PS42 edge magazine with: 2 -fold roller, serial number: 0-200-21-6055, edge thickness: 0,3 - 3 (20) mm, workpiece thickness: 8 - 60 mm, workpiece overhang: 30 mm, feed: 18 - 25 m/min, joint trimming unit: 2 x 3 KW, gluing unit: A20/QA34/C, snipping unit: HL84 (2 x 0,8 KW), rough trimming unit: 2 x 1,5 KW, fine trimming unit: 2 x 0,4 KW, profile trimming unit: FF12 (4 x 0,4 KW), edge sanding unit: KS10 / PS41 / PS42, flat scraping unit: ja / yes, profile scraping unit: MN21 automatic, edge buffing unit: ja / yes, control: Power Control PC 22, return system: Nein / No, Approx. Onsite Dimension. (l x w ...
used
Frequency converter, frequency converter, drive converter, controller, variable speed drive -Input: 380 V 5.5 kW -Output: 133 V 200 Hz -Power: 7.5 KVA -for: edgebander edgebander -Weight: 105 kg
used
Frequency converter, frequency converter, drive converter, controller, variable speed drive -Input: 380 V 4.2 kW -Output: 133 V 200 Hz -Power: 6 KVA -for: edgebander edgebander -Weight: 115 kg
