120,786 used machines on RESALE, but how to find them? Machine Search
maximum number of results exceeded > 1000
please refine your search
used
Linck 700 x 100 edger - German production - hydraulic disc shifting TECHNICAL PARAMETERS: - cutting width max 550 mm - cutting height max 100 mm - element width max 700 mm - engine power 22 kW - feed smoothly adjustable from 10 - 60 m/min - working length of the fixed sleeve 120 mm - working length of the movable sleeve 120 mm - minimum element length 600 mm - disc diameter max 350 mm - spindle diameter 55 mm - sleeve diameter 85 mm - spindle with steady rest - two upper pulling rollers - two lower pulling rollers - two auxiliary rollers in the tabletop - feeder length 3700 mm - feeder width 700 mm - four rollers in the table - adjustment of the disc spacing from the feeder - a row of anti-kickback pawls Transport dimensions 380x220x150 cm weight ~ 2000 kg
used
Welding edge former, edge former, edge chamfering machine TRUMPF chamfers of steel plates for weld seam preparation type TKF 103 Sheet thickness: 4 - 25 mm Bevel length max: 10mm Bevel angle: 30 Power: 2000 Watt Mains connection: 220 Volt, 50 Hz - equipped with guide bracket for 30 bevel angles - regrindable butt steel for high tool utilization - several impact steels - Support plates 6, 8, 10, 12, 14, 16, 18, 20, 22 mm for different material thicknesses For bevelling straight and curved edges with at least 40 mm radius. For bevelling edges on flat and curved workpieces as well as tubes with an inner diameter of at least 80 mm. Weight: 14 kg; used
used
Edge closure for edge banders, edge banding machines -Manufacturer: Homag -for: 2x different edges -Number: 1x edge closure available -Price: per piece -Dimensions: 670/360/H350 mm -Weight: 43 kg/piece
used
Edge magazine for edge banders -Spaces for edges: 5 pieces -Max. Edge width: 60 mm -freestanding -Dimensions: 900/530/H1030 mm -Weight: 208 kg
used
Weld edge former INDUMASCH SIEGEN Type V 12 Masch. No.: 50674 Year of construction 1992 Material thickness max. 40 mm Bevel angle 45 Working speed approx. 3 m/min. Motor power 2 kW Mains connection 400 volts, 50 Hz - Flow / return - Built-in guide roller for bevel angle 45 - Belt guard missing Dimensions L x W x H 650 x 600 x 650 mm Weight 75 kg good condition; used
used
Code: 0233 Brand: MCR - ITALY Model: EASY EDGE/5 - CE Standard Automatic edge bander for edging panels, veneer edges, PVC, solid wood, abs, etc. - CE Standard Technical data: Max edge thickness mm 5 Max panel height mm 80 Min panel height mm 10 Min panel width mm 80 Adjustable feed speed Composition: Gluing unit: Heat regulator glue tank - Heat regulator roller - Automatic strips loader End cutting unit consisting of 2 motors of 0, 37 kW - Blade diameter mm 125 - Blade inclination Fine trimming unit :allows the trimming of the top and the bottom of the applied edge - 2 motors Kw 0,37 - N° 2 combined Vidia cutters with inserts to 30° plus flat sharp Polishing unit - N° 2 motors - Brush diameter mm 160 Control panel Sound-proof cabin Total absorption A 10 Overall dimensions mm 3100 x 1000 x 1640 h Weight kg 950
used
Key data: 20 mm, 60 mm, 8365 mm
I am selling a fully equipped edge banding machine HOMAG EDGETEQ S-500 KAL370 Ambition 2484, built in 2019: Configuration: Input stop servo-motor adjustable Manually adjustable joint milling Edge banding with preheating tanks 2 pcs. Material pressure zone can be adjusted by servo motor Pneumatically adjustable cross-cut saws Heavy milling top + bottom pneumatically adjustable Round unit 4-motor servo motor adjustable R2 / second set R1 included Swivel groove saw unit Radius scraper blade Multiradius servo motor adjustable Scraper blade surface can be pneumatically adjusted Polishing brushes Separator injection at the front Clean injection at the rear Working height adjustable by servo motor Material height 8-60mm Edge material thickness 0.4-12 (20)mm Feed speed 16 to 25m/min. Overall length including feed plate 8365mm Mileage status 833,000 meters. Input appar ...
used
Esterer DKV 1 movable shaft ! feed hydraulically hydraulic and electrically roller lift: hydraulic power: 55 kW Year construction year: approx. 1982 passage: 750mm = width, 160mm = height 2 x directional laser incl. approx. 15 Circularsaws including with Splitter unit screw roll; good
used
Storti RM 500 edger - Italian production - Year of production 1993 - electric spacing of discs TECHNICAL PARAMETERS: - cutting width max 435 mm - cutting height max 170 mm - engine power 2 x 22kW - max element width 600 mm - minimum material length 800 mm - max disc diameter 600 mm - spindle diameter 40 mm - two upper pulling rollers - one upper pressure roller - roller motor power 2 x 1.1 kW - roller pressure with automatic jump - seven bottom pulling toothed rollers - electric disc adjustment - two lasers - feed speed 25 and 50 m/min - feeding table 2950 mm - receiving table 3000 mm - drive rollers D100 mm - power of the roller feed motor 2 x 1.5 kW Transport dimensions 500x240x180 cm weight 3500 kg
used
Multisaw ZLT 500 edger with 500/120 feeders – Czech production – a movable shield with the possibility of installing several shields TECHNICAL PARAMETERS: cutting width 500 mm cutting height 120 mm Min. material length 800 mm .max. disc diameter 450 mm one disc movable sleeve 70 mm fixed sleeve length 100 mm engine power 45 kW two upper pressing rollers four lower pulling ones feed smoothly adjustable on the inverter shaft support two rows of pawls max material width 700 mm length of feed rollers 3000 mm roll width 700 mm roll diameter 70 mm receiving table 6200 mm chain width 60mm seven pressure rollers two bottom pull rollers transport dimensions (length / width / height) 700 / 245 / 180 cm weight 3000 kg
used
Description: Type of edging Thin edge Thick edge Gluing System PUR Combination Squaring Edgebanding Machine First Pass Max Panel Width 3000 mm Max feed speed 40 m/min Operating Units Right Side 10 nr Operating Units Left Side 10 nr Min. panel height 8 mm Max. panel height 60 mm Min. panel width 240 mm Max. panel width 3000 mm Min. edge thickness 0.4 mm Max. edge thickness 3.5 mm Max. forward feed speed 40 m/min Top pressure yes Pressure with rubber belt Panel support guides yes No. Panel Sizing / Milling units Left Side 1 NO. PANEL SIZING / MILLING UNITS LEFT SIDE 1 Unit : double chipper, top and bottom Constructor model : KD 11 motor power : 4.5 KW r.p.m. : 6000 RPM Same technical characteristics on the left side yes Edge coil magazine yes no. positions 12 Gluing system yes glue pot for PUR glue yes premelter for PUR glue yes Roller set to press the edge yes No. Edge Processing Units 8 ...
used
Description: Type of edging Thin edge Thick edge Solid wood Gluing System PUR Premilling Unit yes Corner Rounding Unit yes Grooving Unit yes Max feed speed 24 m/min Maximum panel thickness 60 mm Operating Units 9 nr Min. panel height 12 mm Max. panel height 60 mm Min. edge thickness 0.4 mm Max. edge thickness 20 mm Max. forward feed speed 24 m/min Top pressure yes Pressure with rubber belt Panel support guides yes No. Panel Sizing / Milling units 1 NO. PANEL SIZING / MILLING UNITS 1 Unit : pre-milling unit automatic timed intervention : yes Gluing system yes glue pot for PUR glue yes premelter for PUR glue yes premelter for PUR glue NORDSON Roller set to press the edge yes with positioning by NC yes No. Edge Processing Units 7 NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming no. motors : 2 NO. EDGE PROCESSING UNITS 2 Processing Unit : top a ...
used
Description: Type of edging Thin edge Thick edge Solid wood Gluing System EVA Hotmelt Premilling Unit yes Corner Rounding Unit yes Max feed speed 14 m/min Maximum panel thickness 60 mm Operating Units 8 nr Min. panel height 8 mm Max. panel height 60 mm Min. panel width 70 mm Min. edge thickness 0.3 mm Max. edge thickness 3 mm Max. forward feed speed 14 m/min Top pressure yes Pressure with idle wheels Panel support guides yes with positioning by NC yes No. Panel Sizing / Milling units 1 NO. PANEL SIZING / MILLING UNITS 1 Unit : pre-milling unit automatic timed intervention : yes motor power : 2.2 KW Lamps to preheat the side of the panel yes Edge coil magazine yes no. positions 1 Gluing system yes glue pot for EVA hot melt glue yes premelter for EVA hot melt glue yes Roller set to press the edge yes no. pressure roller 3 with positioning by NC yes No. Edge Processing Units 6 NO. EDGE PROC ...
used
Single sided edge banding machine Brand: IMA Type: COMPACT PC-6220 F Year: 2000 Left hand machine Workpiece transport via a driven transport chain and adjustable top pressure Beckhoff control Need of space LxWxH mm: 7400x1500x2000mm Weight: approx. 3600kg Technical data: Edge material: a) Veneer/coil and strip ware, b) PVC/coil and strip ware c) Solid wood strips min. edge height = approx. 14 mm max. edge height = approx. 55 mm min. edge tickness = approx. 0,4 mm max. edge thickness = approx. 20 mm min. panel thickness = approx. 10 mm min. panel thickness = approx. 16 mm at use of the multi function unit max. panel thickness = approx. 50 mm min. panel width = appprox . 60 mm min. panel length = approx. 150 mm max. strips = approx. 20x50 mm Panel supernatant from the chain conveyor = approx. 35 mm Pneumatic connection: approx. 7 - 8 bar The basic ...
used
Description: Type of edging Thin edge Thick edge Gluing System EVA Hotmelt Premilling Unit yes Corner Rounding Unit yes Max feed speed 11 m/min Maximum panel thickness 50 mm Operating Units 8 nr Min. panel height 8 mm Max. panel height 50 mm Min. edge thickness 0.4 mm Max. edge thickness 3 mm Max. forward feed speed 11 m/min Top pressure yes Panel support guides yes No. Panel Sizing / Milling units 1 NO. PANEL SIZING / MILLING UNITS 1 Unit : pre-milling unit automatic timed intervention : yes motor power : 2.2 KW Edge coil magazine yes no. positions 1 Gluing system yes glue pot for EVA hot melt glue yes Roller set to press the edge yes no. pressure roller 3 No. Edge Processing Units 5 NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming no. motors : 2 motor power : 0.18 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 2 Processing Unit : top and bottom rough trimming no. motors : 2 ...
used
Description: Max. edge thickness 30 mm Max. forward feed speed 20 m/min Pressure with rubber belt Panel support guides , with positioning by NC , NO. PANEL SIZING / MILLING UNITS 1 Unit : pre-milling unit Constructor model : 08.376 automatic timed intervention , motor power : 3 KW r.p.m. : 12000 RPM Edge coil magazine glue pot for EVA hot melt glue premelter for EVA hot melt glue no. pressure roller 9 with positioning by NC , NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming no. motors : 2 NO. EDGE PROCESSING UNITS 2 Processing Unit : top and bottom rough trimming no. motors : 2 motor power : 1.85 KW r.p.m. : 11500 RPM NO. EDGE PROCESSING UNITS 3 Processing Unit : fine trimming to trim and round no. motors : 2 motor power : 1 KW r.p.m. : 11500 RPM NO. EDGE PROCESSING UNITS 4 Processing Unit : Corner rounding no. motors : 2 with positioning by NC , motor ...
used
Description: Max. panel height 50 mm Min. edge thickness 0.4 mm Max. edge thickness 5 mm Max. forward feed speed 12 m/min Pressure with idle wheels NO. PANEL SIZING / MILLING UNITS , Unit : pre-milling unit automatic timed intervention motor power : 1.8 KW Edge coil magazine yes glue pot for EVA hot melt glue , premelter for EVA hot melt glue , Roller set to press the edge , no. pressure roller 4 NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming no. motors : 2 motor power : 0.35 KW NO. EDGE PROCESSING UNITS 2 Processing Unit : top and bottom rough trimming no. motors : 2 motor power : 0.65 KW NO. EDGE PROCESSING UNITS 3 Processing Unit : fine trimming to trim and round no. motors : 2 motor power : 0.65 KW NO. EDGE PROCESSING UNITS 4 Processing Unit : Corner rounding no. motors : 2 motor power : 0.5 KW NO. EDGE PROCESSING UNITS 5 Processing Unit : edge scraping NO ...
used
Description: Min. edge thickness 0.3 mm Max. edge thickness 3 mm , Max. forward feed speed 25 m/min Pressure with rubber belt Panel support guides , with positioning by NC , Infeed panel alignment system , NO. PANEL SIZING / MILLING UNITS , Unit : pre-milling unit automatic timed intervention motor power : 3 KW r.p.m. : 9000 RPM Lamps to preheat the side of the panel , Edge coil magazine , glue pot for EVA hot melt glue premelter for EVA hot melt glue , Roller set to press the edge no. pressure roller 7 with positioning by NC , No. Edge Processing Units 7 NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming no. motors : 2 motor power : 0.8 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 2 Processing Unit : top and bottom rough trimming no. motors : 2 motor power : 1.5 KW r.p.m. : 12000 RPM , NO. EDGE PROCESSING UNITS 3 Processing Unit : Corne ...
used
Description: Type of edging Thin edge Thick edge Solid wood Gluing System EVA Hotmelt Corner Rounding Unit yes Max feed speed 11 m/min Maximum panel thickness 55 mm Operating Units 7 nr Min. panel height 8 mm Max. panel height 50 mm Min. edge thickness 0.4 mm Max. edge thickness 8 mm Max. forward feed speed 11 m/min Top pressure yes Pressure with idle wheels Panel support guides yes No. Panel Sizing / Milling units 1 NO. PANEL SIZING / MILLING UNITS 1 Unit : pre-milling unit automatic timed intervention : yes motor power : 2.2 KW Edge coil magazine yes no. positions 1 Gluing system yes glue pot for EVA hot melt glue yes Roller set to press the edge yes No. Edge Processing Units 5 NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming Constructor model : HL 6130 no. motors : 2 motor power : 0.18 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 2 Processing Unit : fine trimming to trim ...
used
Description: Position: 1 SubFamily: Edgebander BATCH 1 Brand: BIESSE Model: STREAM B1 10.5 MDS Type of edging Thin edge Thick edge Gluing System EVA Hotmelt  ,  ,  ,  ,  ,  ,  ,  ,  ,  ,  ,  ,  ,  ,  ,  ,  ,  , Premilling Unit , Corner Rounding Unit Grooving Unit , Maximum panel thickness 60 mm Max. panel height 60 mm Min. panel length 150 mm Min. panel width 65 mm Min. edge thickness 0.3 mm Max. forward feed speed 25 m/min Pressure with rubber belt Panel support guides , with positioning by NC , Infeed panel alignment system , MDS No. Panel Sizing / Milling units Unit : pre-milling unit automatic timed intervention Edge coil magazine , no. positions 12 glue pot for EVA hot melt glue , premelter for EVA hot melt glue , no. pressure roller 4 with positioning by NC , No. Edge Process ...
used
Description: Max. panel height 50 mm Min. panel width 70 mm Min. edge thickness 0.4 mm Max. edge thickness 3 mm Max. forward feed speed 10 m/min Pressure with idle wheels Panel support guides NO. PANEL SIZING / MILLING UNITS Unit : pre-milling unit Edge coil magazine Gluing system glue pot for EVA hot melt glue Roller set to press the edge no. pressure roller 3 NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming no. motors : 2 motor power : 0.18 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 2 Processing Unit : fine trimming to trim and round no. motors : 2 motor power : 0.27 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 3 Processing Unit : Corner rounding NO. EDGE PROCESSING UNITS 4 Processing Unit : edge scraping NO. EDGE PROCESSING UNITS 5 Processing Unit : glue scraping Control system PLC Safety standard CE mark Approx. Onsite Dimension. (l x w x h): 1 x 1 x 1 mm, weight ap ...
used
Description: Type of edging Thin edge Thick edge Solid wood Gluing System EVA Hotmelt Max feed speed 9 m/min Maximum panel thickness 50 mm Operating Units 4 nr Min. panel height 8 mm Max. panel height 50 mm Min. edge thickness 0.4 mm Max. edge thickness 3 mm Max. forward feed speed 9 m/min Top pressure yes Pressure with idle wheels Panel support guides yes Edge coil magazine yes no. positions 1 Gluing system yes glue pot for EVA hot melt glue yes Roller set to press the edge yes no. pressure roller 3 No. Edge Processing Units 3 NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming no. motors : 2 motor power : 0.18 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 2 Processing Unit : fine trimming to trim and round no. motors : 2 motor power : 0.27 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 3 Processing Unit : glue scraping Safety standard CE mark yes Total installed power 3.5 KW ...
used
Single-sided edge banding machine Make: HOMAG Type: KAL 210 AMBITION 2264 Year of construction: 2014 One-sided edge banding machine for editing of straight workpiece edges and for gluing and post-processing in the longitudinal and transverse pass. Overview of aggregate equipment: - Separating agent spray unit - Joining milling unit - Gluing unit A20 with 2 rolls - end trimming unit HL84 - Pre-milling unit BF10 - Form milling unit FK11 manual - Profile scraper PN10 - Finishing unit Feed 18 - 25 m/min. Feed max. with FK11 20 m/min. Working height 950 mm Pneumatic connection 6 bar Total length 7845mm Workpiece thickness 8 - 60 mm Edge height max. = workpiece thickness + 4 mm Edge material roll 0.3 - 3 mm Edge material strips 0.4 - 20 mm Aggregate equipment: - Separating agent spray unit top/bottom - Joining milling unit 2 motors each 3 kW, 150 Hz ...
used
Technical data (subject to change): Machine: Constant workpiece output from the chain path: 38 mm (incl. edge at edge thicknesses 0.3 - 3 mm) min. throughput width: 65 mm with a maximum workpiece thickness of 25 mm min. workpiece length in feed direction: 150 mm Basic height (upper edge chain track): 960 mm Workpiece: min. workpiece length: 150 mm min. workpiece width: 65 mm min. workpiece thickness: 8 mm workpiece thickness: 40 mm (with copy function) workpiece thickness: 60 mm (without copy function) Smallest workpiece: 150 mm x 150 mm, or 65 mm x 300 mm Lateral protruding coating material: 0 mm Edge material: paper, plastic and veneer min. height: 14 mm height: 65 mm Roll material: min. thickness 0.3 mm thickness 3.0 mm Veneer edges limited possible up to 1.0 mm cross-section 130 mm² min edge length 160 mm upper edge protrusion: 5 mm Equipment: - Drive fo ...
used
Equipment: - Machine stand throughout - Fixed stop side right - Paint finish Grey RDS 240 80 05 - Inlet ruler motorically adjustable, extended by 300 mm - Inlet lock pneumatically controlled - automatic edge feeder - Upper pressure: belt upper pressure - Height adjustment motorized - Position display and input centrally via the controller - Transport chain with rubber support, 80 mm wide - automatic central lubrication for the transport chain - Workpiece support in scissor design, approx. 1000 mm extendable - Noise protection equipment - Hood interior lighting 3 lamps - Control Power Control PC20+ Aggregate technology: - Joining milling unit 2 x 2.2 kW 200 Hz (60 mm joining milling cutter set) - Gluing unit A15 (workpiece preheating, QA34 application unit, infrared adhesive activation, magazine for rolls and fixed lengths, pressure zone with motorized adjustment, driv ...
used
Edge height max. 65 mm Edge thickness max. 20 mm Strip cross-section max. 20 x 55 mm Fixed workpiece protrusion in post-processing incl. Edge material 38 mm (max. edge thickness 8 mm) In the case of strips or edge thickness > 8 mm, the output is in of post-processing 30 mm + strip thickness Post-processing is then only possible with the following units: possible: cross-cut and milling unit 08.055 and grinding unit Feed speed 6 - 30 m/min. Roller support rail extendable up to 700 mm Machine length 9,300 mm IMATRONIC 121/01 with system software for operating the Edge banding machine Compact PC in industrial design Electronic height adjustment of the upper pressure Inlet ruler axis-controlled Milling unit 08.376 with 2 motors of 4.5 kW each, in the Working in sync or counter rotation Infrared emitters for workpiece edge preheating Gluing unit 283.151 ...
used
Description: Max. panel height 60 mm Max. edge thickness 3 mm Pressure with rubber belt NO. PANEL SIZING / MILLING UNITS Unit : pre-milling unit Constructor model : RT20 motor power : 2 KW r.p.m. : 9000 RPM Edge coil magazine no. positions 6 Gluing system yes glue pot for EVA hot melt glue premelter for EVA hot melt glue no. pressure roller 3 No. Edge Processing Units 5 NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming Constructor model : IT90 no. motors : 2 motor power : 0.35 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 2 Processing Unit : top and bottom rough trimming Constructor model : RS10 no. motors : 2 motor power : 0.75 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 3 Processing Unit : fine trimming to trim and round Constructor model : RF10 no. motors : 2 motor power : 0.35 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 4 Processing Unit : edge scraping Constr ...
used
Description: Max. panel height 60 mm Max. edge thickness 3 mm Max. forward feed speed 24 m/min Top pressure , NO. PANEL SIZING / MILLING UNITS , Unit : pre-milling unit Constructor model : RT20 automatic timed intervention : , motor power : 2 KW r.p.m. : 9000 RPM Edge coil magazine , no. positions 6 glue pot for EVA hot melt glue , premelter for EVA hot melt glue , Roller set to press the edge , NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming Constructor model : IT90 no. motors : 2 motor power : 0.35 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 2 Processing Unit : top and bottom rough trimming Constructor model : RS10 no. motors : 2 motor power : 0.75 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 3 Processing Unit : fine trimming to trim and round Constructor model : RF10 no. motors : 2 motor power : 0.37 KW r.p.m. : 12000 RPM NO. EDGE PROCESSI ...
used
Description: Max. panel height 55 mm Min. edge thickness 0.4 mm Max. edge thickness 12 mm Max. forward feed speed 13 m/min Pressure with idle wheels NO. PANEL SIZING / MILLING UNITS Unit : pre-milling unit automatic timed intervention motor power : 2.2 KW Edge coil magazine glue pot for EVA hot melt glue premelter for EVA hot melt glue Roller set to press the edge no. pressure roller 4 NO. EDGE PROCESSING UNITS 1 Processing Unit : end trimming no. motors : 2 automatic timed intervention motor power : 0.35 KW r.p.m. : 12000 RPM NO. EDGE PROCESSING UNITS 2 Processing Unit : fine trimming to trim and round no. motors : 2 motor power : 0.55 KW r.p.m. : 11300 RPM NO. EDGE PROCESSING UNITS 3 Processing Unit : Corner rounding no. motors : 2 motor power : 0.4 KW NO. EDGE PROCESSING UNITS 4 Processing Unit : glue scraping NO. EDGE PROCESSING UNITS 5 Processing Unit : buffing no. motors : 2 motor ...
used
Description: Workpiece and edge parameters Workpiece width min: For workpiece thickness 8-22 mm | 70 mm For workpiece thickness 23-40mm | 120 mm For workpiece thickness 41-60mm , 150 mm depending on the workpiece length Workpiece protrusion | 38 mm Workpiece thickness | 8 - 60 mm Max. edge height = workpiece height, + 6 mm Edge material roll / 0.4 - 3 mm Edge cross-section max. For PVC | 135 mm For veneer | 100 mm Max. roll diameter , 830 mm Edge material strip , 0.4 - 15 mm (or 12 mm) (When using the VKNR 4845 exchange trimming unit, the max. edge thickness is 12 mm!) Max. edge cross-section For strips ' 600 mm If no radius is specified, R=2 mm is retracted and delivered serial number: 0-261-20-5413, workpiece thickness: 8 - 60 mm, feed: 8 - 18 m/min, joint trimming unit: 2 x 2,2 kW, gluing unit: A12, snipping unit: 2 x 0,35 kW, rough trimming unit: 2 x 0,55 kW, ...
used
Ott Edge Banding Machine Profimatik M 257-FÜ with pre-joining used, good condition Make Ott Type Profimatik M 257-FÜ Year of construction 2001 Banding thickness 20 / 25 mm Banding height 60 / 65 mm heated inlet ruler Thick edges up to 20 / 25 mm Caps from the roll up to 3 mm Pre-joining with DIA tools 2 x 1.8 kW Cross-cut unit 0°/20° - 2 x 0.8 kW Flush milling 2 x 2.2 kW Bevel milling 2 x 0.6 kW Radius milling 2 x 0.6 kW Radius Scraper Blade Copy corners 4 x 0.8 kW Grinding unit Edge finishing (buffing) Auto. Edge magazine Feed rate infinitely variable 8 - 24 m with motorized adjustment Granulate high-speed heating basin (EVA) Route control Program control with 98 programs Soundproofing hood Large roller support High-speed heating basin with automatic Synchronization and counter-rotation control of the glue roller Automatic ...
new
Pre-milling unit: yes; Pre-milling unit material removal: 0 - 2 mm; plastic edges: 0,4 - 3 mm; solid wood edges: 0,5 - 5 mm; Workpiece thickness: 8 - 50 mm; Minimum length of workpiece: 120 mm; Min. work piece width: 110 mm; Anti-adhesive spraying unit: yes; Edge preheating device: yes / with ceramic infrared lamp; Bonding unit: granulat / Glue container quick-change kit; Jack knife: yes; Flush trimming unit: yes; Corner copy unit: yes; Flush radius milling unit: yes; Radius scraper unit: yes; Area scraper unit: yes; Buffing unit: yes; Cleaning spray unit: yes; motor power: 5 kW; machine length: 3774mm; machine width: 1546 mm; machine height: 1337mm; weight: 842 kg; Top equipment for high productivity with low space requirements! Intuitive operation with the eye-S control and 10 large touchscreen: - HMI Maestro Active Edge - Graphic display of all processing units ...
used
Single-sided edge banding machine for machining of straight workpiece edges and for banding and post-processing of various edge materials in longitudinal and transverse passing. Automatic conversion from radius to chamfer and different edge and workpiece thicknesses. Control Power Control PC 22 OVERVIEW OF UNIT ASSEMBLY: – RELEASE AGENT SPRAYING UNIT – JOINING MILLING UNIT – GLUING PART A20 WITH 2 ROLLS Application unit PU 65 (Teflon-coated for PU gluing) – CROSS-CUT UNIT HL84 – PRE-MILLING UNIT – FK11 SHAPE MILLING UNIT – FREE SPACE UNI MILLING UNIT UF10 – PROFILE SCRAPER PN10 – FINISHING UNIT (with detergent information) – Feed rate 20 m/min – Total length 8635 mm 2. WORKPIECE AND EDGE PARAMETERS: – Workpiece width min: – For workpiece thickness 12-22 mm ¦ 60 mm – For workpiece thickness 23-40 mm ¦ 105 mm – Workpiece protrusio ...
used
Equipment/technical data: - e-Motion control with 21" smartouch instead of 10" tempora F 800 Ser - Upper pressure beam motor-controlled, adjustable workpiece height 8-60 mm - Chain feed 12 m/min, 1.5 kW, Minimum workpiece length 140 mm - Turntable edge magazine for roll edge material 0.4 - 3 mm and strip magazine for 12 pieces 10 mm edges - Edge feeding for roll and strip material - pneum. Controlled gluing unit, Teflon-coated, for 1.5 kg EVA granules, with synchronized glue roll and quick-change system. (for PUR adhesive processing, taking into account the Adhesive processing guidelines) - Pneumatically operation-controlled pressure unit e-motion (one driven, two conical contact rollers) tempora 60.12/2: 0-12mm - Impact shears for roll material - Cross-cut saw with 2 motors - Joining milling unit 2 x 1.5 kW - Upper and lower combination milling unit, 0.75 kW each, flush a ...
used
Description: HOMAG OPTIMAT KAL 310 / 7 / A20 / S2 Edge Bander with return sistem control - yes edge buffing unit - yes edge magazine with - yes edge sanding unit - no edge thickness - yes feed - 18-20 mts/min fine trimming unit - yes flat scraping unit - yes gluing unit - yes joint trimming unit - yes , profile scraping unit - yes profile trimming unit - yes return system - yes , workpiece overhang - 30 mm workpiece pre heater - yes workpiece thickness - 10-60 mm dimension (l x w x h) and weight approx. (6 packs) 8800 x 1000 x 1900 mm - 5000 Kg 3500 x 1300 ,x 900 mm - 300 Kg 2900 x 1800 x 900 mm - 600 Kg 6400 x 1300 x 900 mm - 1000 Kg 2000 x 1300 x 900 mm - 200 Kg 800 x 500 x 1000 mm - 100 Kg workpiece thickness: 10 - 60 mm, workpiece overhang: 30 mm, feed: 18 - 20 m/min, joint trimming unit: Yes, workpiece pre heater: Yes, gluing unit: Yes, fine trimming u ...
used
Single-sided edge banding machine Brandt type OPTIMAT KDF 650 C edition Specifications: • Feed rate (m/min.): 8 - 18 • Feed max. with form milling machine (m/min.): 14 • Working height (mm): 950 • Pneumatic connection (bar): min. 6 • Overall length (mm): 6,060 Workpiece and edge parameters: • Workpiece width min. at workpiece thickness 8 - 22 mm: 70 mm (depending on workpiece length) • Workpiece width min. for workpiece thickness 23 - 40 mm: 120 mm (depending on workpiece length) • Workpiece width min. at workpiece thickness 41 - 60 mm: 150 mm (depending on workpiece length) • Workpiece protrusion (mm): 38 • Workpiece thickness (mm): 8 - 60 • Edge height max. = workpiece height (mm): + 6 • Edge Material Roll (mm): 0.4 - 3 • Max. edge cross-section for PVC: 135 mm² • Max. edge cross-section for veneer: 100 mm² • Roll diameter max. ( ...
used
AUTOMATIC EDGE BANDING machine SCM OLIMPIC K 1000 second hand machine volt. 380/50 for solid wood max. 10 mm. / PVC / veneers / melamine composed by : technical details : min. panel length mm. 120 min. panel width mm. 70 panel thickness min./max. mm.10/60 edge thickness min./max. mm.0,4/10 total installed power Hp 9 composition machine : 1. lower glue pot 2. motorized roller for automatic feeding 3. edge shear 4. end trimmer unit . motor Hp 0,3 . rpm 12.000 5. top and bottom ( rough ) edge trimmer unit . 2 motors Hp 1,1 . rpm 12.000 6. top and bottom ( fine ) bevel edge trimmer unit . 2 motors Hp 0,3 rpm 12.000 7. edge glue scraper unit integral protection enclosure
used
- CE certification - Complete, original wood Her machine documents and operating instructions - Weight: 720 kg (basic machine), approx. 860 kg (machine with aggregates) Assembly: • Control panel (1888) SK 180 • Fully automatic edge feeding (1903) - Edge thickness striped goods 0.3 - 8 mm - Edge thickness rolled goods 0.3 - 3 mm - max edge height 51 mm • Adhesive application station (1906 M) - with hot melt adhesive cartridge - via sword nozzle with electro-pneumatic control - Temperature selector - Heating time approx. 5 min - Temperature approx. 190 - 240 degrees Celsius - Workpiece thickness 6 - 45 mm • Printing Unit (1912) • Cross-cut unit (1918) • Combino milling unit (1942 M) - for flushing, chamfering and radius milling • Pull blade unit (1929) - Edge thickness max. 3mm • Sandbar unit (1940) • 2 x suction connections 70 mm each • Compre ...
used
Overview of the assembly: - Release agent spray unit top & bottom - Joining milling unit 2 x 4 kW - Glued part with workpiece preheating, 2 rolls, pressure zone C and QA34 application unit for PU with quick clamping system - autom. Adjustment pressure zone - Preparation for Lasertec activation unit - Hl84 cross-cut unit 0.8 KW - pneum. Adjustment pre-milling unit - Pre-milling unit Bf10 1.5 kW - Mould milling unit Fk11 Manual - Autom. Adjustment of chamfer to radius milling machines - Rolling side probe FK - Pneumatic adjustment FA11 for lateral displacement from the working area - Multi-drawing blade MN 21 autom. for a maximum of 5 different profiles. - Finishing unit (glue joint drawing blade and swabbing ridge) - Detergent spray unit top & bottom - powerControl PC22 Workpiece and edge parameters: - Workpiece width without edge min: - For workpiece thickness ...
used
Edge banding machine, edge banding machine, edge banding machine, finishing unit, buffing unit, modular assembly kit, format processing unit, double-end profiler, edge processing machine, sanding unit, edge banding unit -Unit: from edge banding machine BRANDT KM 35 -Motor: Groschopp type PM1 72-35 - Mot 180 V / 54 W. -Individual components: see photos -Dimensions: 425/270 / H260 mm -Weight: 24 kg
used
Hebrock AKV3003DK-F edge banding machine with joints and two scraper blades. Edge thickness roll approx. 0.4 - 2mm Banding up to 8mm Workpiece height approx. 8 - 45mm Feed rate approx. 10m/min Noise protection hood Extendable workpiece support Suction connection 80 +140mm Aggregates: Manual overpressure adjustment with SIKO counter Infeed ruler manual adjustment with SIKO counter Edge thickness manual adjustment with SIKO counter Grooving mills with slide mills Gluing part with automatic edge retraction for rolls up to 3mm, switchable for synchronization and counter-rotation Pressure zone with 4 rollers Cross-cut saw Integrated collection container for edge pieces Combination milling unit, R2 with pneumatic adjustment between thin and thick edge Radius scraper R2, pneumatically retractable Glue joint scraper blade can be pneumatically inserted ...
used
Description: Max. panel height 60 mm Min. panel length 130 mm Min. panel width 65 mm Min. edge thickness 0.4 mm Max. edge thickness 3 mm Max. forward feed speed 30 m/min Pressure with rubber belt No. Panel Sizing / Milling units , Unit : pre-milling unit Constructor model : R3 L20 motor power : 4 KW r.p.m. : 9000 RPM Lamps to preheat the side of the panel , Edge coil magazine , no. positions 2 glue pot for EVA hot melt glue , premelter for PUR glue , Roller set to press the edge , no. pressure roller 5 No. Edge Processing Units 10 Processing Unit : end trimming Constructor model : 8,42/39/B no. motors : 2 Processing Unit : fine trimming to trim and round Constructor model : 08.055 Processing Unit : Corner rounding Constructor model : 08.342 Processing Unit : edge scraping Processing Unit : belt sanding Constructor model : 08.62 Processing Unit : belt sanding Const ...
used
Description: Max. panel width 3300 mm Min. edge thickness 0.4 mm Max. edge thickness 3 mm Max. forward feed speed 30 m/min Conveyor Track with dogs , Pressure with rubber belt NO. PANEL SIZING / MILLING , Unit : scoring unit motor power : 4.4 KW r.p.m. : 6000 RPM NO. PANEL SIZING / MILLING , Unit : double chipper, top and bottom Constructor model : 75.30 NO. PANEL SIZING / MILLING , Unit : miller hogger NO. PANEL SIZING / MILLING , Unit : miller hogger Edge coil magazine , no. positions 2 glue pot for EVA hot melt glue , premelter for EVA hot melt glue , Roller set to press the edge , no. pressure roller 5 No. Edge Processing Units , Processing Unit : end trimming Constructor model : 08.412 no. motors : 2 Processing Unit : fine trimming to trim and round Constructor model : 08.055 no. motors : 2 Processing Unit : Corner rounding Constructor model : ...
used
4-side squaring and edge banding line Machine 1: Fixed side right, moving side left Rolling chain, feed 10 - 40 m/min Controlls NC 21 Panel thickness 8 - 60 mm Max. panel width 1500 mm Edges: coil 0,3 - 3 mm, strips 0,4 - 20 mm Entry fence for veneered panels Equipment: 1+1 Compact-twin hogger, 2 motors 6,6 kW 1+1 Compact hot melt unit A20 with panel edge pre-heating, glue roller Q34, twin coil magazine, lateral pressure rollers C including anti-stick application 1+1 Free space for solid wood edges up to 2,54 m length 1+1 Rough trimming, 2 x 1,5 kW 1+1 Fine- or radius trimming, 2 x 0,4 kW (edges up to 6 mm) 1+1 Universal shaper 8,1 kW 1+1 Universal shaper 8,1 kW 1+1 Edge sander KS 10 1+1 Disc sander DS 40 1+1 Disc sander DS 40 Angular transfer to the right, TWR 24/30/12/S Panel sizes: width 250 - 1200 mm, length 250 - 3000 mm, thickness 8 - 45 mm Machine 2 Machine II + infeed magazine TW ...
used
I sell a new edge banding machine Cormak EBM300, year of construction 2022: LCD touchscreen display for setting the machine parameters and aggregates ON/OFF connection. Top feed belt 6 m/min. Element height 10 - 50 mm Edge thickness 0.4 - 3 mm edge banding, Sawing the final cut Radius R2 Milling Polishing brushes Total weight 400kg Length 2,30m (including edge plate 2,60m)! Feed zone only 1.30m long, convenient for the smallest workshop, or as an additional machine for edge banding the small work stucco quantities. New machine including warranty ratios, possible to try ! Full documentation and CE included. Available the same.
used
Brand 1110F - KDF110 Optimat Brand: Brandt Type: KDF 110 Year of construction: 2015 M-No.: 0-261-20-5386 Control: Easy Control 10+ Non-contact route control Feed controlled with start-stop optic-indicative sensors Screen: LCD, 420 letters, 4 program memories Configuration: Chain conveyor feed: Standard equipment with central lubrication for the transport chain. Top pressure rollers/product guidance: Zentra control, 2 roller conveyors positioned opposite each other Joint milling unit: 2 x 0.75 KW 200 HZ Including joint milling set in DIA design, with manual positioning via Siko counter, max. 3 mm removal and max. 40 mm workpiece thickness Gluing unit: A3 gluing part for hot melt glue and possibility for PU application, magazine, pressure zone with electro-pneumatic 2 point positioning via central control Pressure zone: 1st roller driven and 2 rollers running freely fo ...
used
Brand 1210F - KDF210 Optimat Brand: Brandt Type: KDF 210 -1210F Year of construction: 2014 Control: Easy Control 10+ Non-contact route control Feed controlled with start-stop optic-indicative sensors Screen: LCD, 420 letters, 4 program memories Configuration: Chain conveyor feed: Standard equipment with central lubrication for the transport chain. Top pressure rollers/product guidance: Zentra control, 2 roller conveyors positioned opposite each other Joint milling unit: 2 x 0.75 KW 200 HZ Including joint milling set in DIA design, with manual positioning via Siko counter, max. 3 mm removal and max. 40 mm workpiece thickness Gluing unit A3 gluing part for hot melt glue and possibility for PU application, magazine, pressure zone with electro-pneumatic 2 point positioning via central control Pressure zone: 1st roller driven and 2 rollers running freely for good and con ...
used
Wood Her Auriga 1308 FÜ + PU compact design - edge thickness 0.4 - 8 mm PLC screen control Edge Control PPC 221 color screen Pre-milling unit for joining in front of the gluing part Edge magazine fully automatic for rolls and strip goods Glue Application Station GLU JET Cartridges + PU Gluing - Multisystem + Glue application using nozzle technology Workpiece height 6-65 mm Auto. Glue height adjustment Printing unit 1912-3 pneumatic Cross-cut unit 1918 pneumatic for rolls and strip goods up to 8 mm edge thickness with pneumatic adjustment from 0-10° inclination of the cross-cut saws Milling unit 1827 MOT 4, flush milling 8 mm, radius milling - bevel milling - 15° 1827 MOT NC axes via control panel Mould milling unit 1832 pneum. Rounding of corners up to edge thickness 3mm in the run Drawing blade unit 1929 for chamfers and radii with 2 drawing blade carriers via control p ...
used
Used edge bander HOLZ ER mod. SPRINT 1321 - 4 EC Year of manufacture 2008 "Edge Control" gluable edge thickness from 0.4 to 15 mm in roll mm. 3 max panel height from 6 to 60 mm min. length piece 180 mm min. width piece mm. 60 feed speed from 8 to 18 mt/min variable by CN Pressure bridge with motorized adjustment with controlled axis inlet stop adjustment with CN motorized axis grinding unit with automatic adjustment of the thickness in relation to the thickness of the workpiece and with undercounter exclusion Nr. 2 motors each KW 2 Automatic Edge Charger multi-adhesive group for EVA and PVR adhesives in cartridges and granules pneumatic pressure unit with axis controlled by CN with nr. 3 pressure rollers, one of which is motorized header group with 2 motors of 0.45 KW, revolutions 12,000, pneumatic orientation 0-10 ° Overlapping trimming ...
used
Code: 0226 Brand: FELDER - FORMAT4 Model: PERFECT 710 E-MOTION - CE Standard Automatic edge bander with grinding unit for edgebanding solid wood, chipboard, veneer, PVC, Abs, and melamine panels - CE Standard - Year 2010 Technical data: Min edge thickness 0,4 mm Max edge thickness 10 mm Max panel height mm 60 Max feed speed 12,5 m/min Top pressure bar: workpiece thickness adjustment is carried out electronically from the control panel Operating unit: infeed guide adjustable from control panel Grinding unit: with 2 diamond cutters Gluing unit with glue pot with quick-change system for processing EVA and PUR glue Edge pressure roller unit with 3 rollers with positioning from control panel End cutting unit consisting of 2 independent blades with high-frequency motors 12000 rpm - Tilting from 0 to 15° Multi-function end trimming unit with 2 motors 12000 rpm Edge scraper ...
