Spindle cone MK 4 Machine weight approx. 2.5 t Space requirements approx. 2.2 x 0.7 x 2.5 m
Line boring machine Ayen with 32 mm grid Bahvy3bjt2 with attacks Pneum.. Holders Motor 0.55 kW L x W x H: 250 x 80 x 200 cm Weight 420 kg Year of construction 1983 The machine is in good condition, ready to use. Subject to changes, errors, prior sale! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system + technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Tel. 0041 62 966 18 32 Fax 0041 62 966 21 12
GeneralCNC Turning Centre; Control: Control M730UM with CELOS CharacteristicsMax machining diameter406 mmDimensions (L x W x H)3,35 x 2,11 x 2,2 (3,99 x 2,11 x 2,2) mDrive power main spindle22/18,5 kWRapid feed X / Z30/30 m/minMovements X / Z260/795 mmRotary tool spindle speed10000 rpmNumber of tool stations12 Speed max.2500 rpmBar diameter max.102 mmSpindle bore111 mmMax. Turning Length705 mmWeight approx.6400 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and pLeft Spindle through-spindle hole dia. 111 mm (spindle speed 2,500 min-1, 22/ 18.5 kW)(Left Spindle) Through-Spindle Hole Dia. 111 mm (4.37-inch) (Spindle Speed 2,500 min-1, 22/18.5 kW) The NLX 2500 adopts a h ...
Double-sided fully automatic hydraulic cutting - milling - drilling machine PADE NST double-sided fully automatic hydraulic cutting - milling - drilling machine Production of chairs, tables, frames, and furniture parts Max work length 2100 mm Tilt-10° â +45° Rotation-10° â +50° 2 saw blades diameter 400 mm 2 drilling heads left, right can be rotated through 360 °, 8 spindle cross-shaped grid M2fi2 2 additional horizontal drilling heads from behind can be rotated by 360 °, 8 spindle cross-shaped grid 2 milling spindles bore wave 30 mm 1 motor for longitudinal adjustment of 1.5 kW 2 Saegemotore 2.2 kW 4 boring Motors 2.2 kW
Saling drill BLUTHARDT in robust performance, drilling capacity 50 mm, holder Mk 4
with FESTO rotary table 360 mm numbers of drilling units: 29433, 29616. 29617, 29797 and 29798
Column drilling machine Super Condor 30 ATTENTION: Control Panel is missing. Has not been tested. NEED OF REPAIR. All information without guarantee
Machine to the dowel, drill and saw the company EKM spezialmaschinen connection value: 4,4 kW 1 pneum. Workpiece clamping system 1 drill head with 5 spindles in row spacing 25 mm / 40 mm / 40 mm / 25 mm 4 piece glue - and plugs Tools 4 piece adjustable on width 220 mm Under table saw Control PLC Siemens Simatic Fully functional replacement for PLC program on CD,. Shipping dimensions: L 1500 mm x W 1500 mm x H 2400 mm Machine weight: 1000 kg Condition good, fully functional
Deep Hole Drilling Machines Kramatorsk KJ1910 used machine but very good mechanical condition. Machine can be inspected in our warehouse in Gussago BS (Italy) Deep hole boring machine - heavy duty deep hole boring machine Kramatorsk KJ 1910 Year of manufacture 1986 Maximum boring diameter, mm 600 Maximum use of lenght mm 10000 (10 meters) Max 25 ton Spindle diameter hole mm 700, Main motor power, kW 85 Counter rotation motor is 95kW Machine overall dimensions, mm 25550 x 3000 x 2290 Machine weight, kg 83000 Mimu machine tools (Italy) machine tools
Key data: 40 mm
Demonstration article Condition: Used Premium quality MADE IN SWEDEN The gearbox is built with the traditional and tested technology for the highest possible torque. Helical gears in combination with steel against reinforced fiber material provide a high degree of efficiency, a low noise level, as well as a long service life and an almost maintenance-free transmission. Specifications: Drilling capacity in steel: 40 mm Threading capacity M28 Spindle holder (turning spindle) MK 4 Speed range 90 - 1500 rpm Speed levels 8 Quill stroke 190 mm Quill feed stages 4 Column diameter 140 mm Quill feed 0.10/0.16/0.24/0.33 mm/rev T-slots, width M14 mm Drilling table stroke 830 mm Spindle projection 330 mm Drilling table rotatable ± 360° Quill spacing base 1210 mm Quill spacing table 215 - 830 mm Drilling table area 500x400 mm Motor power (2-stage) 2200 / 2600 W M ...
Key data: 16 mm, 150 mm
KBM 16 T VARIO SET action Composed of: V-belt bench drill Model KBM 16 T VARIO 1 pcs vise 3' / 75 mm 2 pcs clamping screws T12mm 1 pcs.HSS twist drill cassette 1-13mm, 25 pcs. 1 pc. cutting oil spray 350 ml Specifications Drilling capacity in steel 16 mm Spindle holder (rotary spindle) MK 2 Speed range 340 - 2200 rpm Speed levels infinitely variable Quill stroke 90 mm Column diameter 60 mm T-slots, width 14 mm Drilling table stroke 275 mm Spindle projection 150 mm Drilling table swivel ± 45° Drilling table rotatable ± 180 ° Quill spacing table 360 mm Drill table area 243x243 mm Motor power 550 W Mains connection 230/50 V/Hz Cubature 195x195x360 mm Base plate area (lxw) 250x415 mm Height (total) 910 mm Weight 42 kg
ID3598 Geotec Rotomax L year/Baujahr 2012 Crawler drilling rig, drilling mast stroke length 4300 mm, pulling force 46.5 kN, contact pressure 25 kN, mast telescopic travel 500 mm, gearbox flushing passage 100 mm - 5 gears, clamping head diameter 178 mm, clamping and breaking device 0-400 mm, shock tongs, support clamp 50-324 mm diameter, cable winch, centrifugal pump, mast extension 810 mm Crawler drilling rig, drilling mast stroke length 4300 mm, tractive force 46.5 KN, pressure 25 kN, mast telescopic travel 500 mm, gearbox flushing passage 100 mm - 5 gears, clamping head diameter 178 mm, clamping and breaking device 0-400 mm, shocking pliers, interceptor clamp 50-324 mm diameter, winch, centrifugal pump, mast extension 810 mm
Technical data: -Drilling capacity in steel ST 60 28 mm -Drilling capacity in steel ST 60 32 mm -Spindle mount MT 3 -Right - left rotation -Drilling spindle stroke 150 mm -Spindle speed continuously variable 80-1170 U/min -2 feed 0,1 / 0,2 mm / Rev -Throat depth 290 mm -max distance table - spindle 780 mm -Table with 2 T-slots 480 x 400 mm -Height-adjustable via rack and pinion with hand crank -Drive: 400 V / 0.9 / 1,3 kW -Space requirement approx. B 600 x H 2100 X 900 mm -Weight approx. 420 kg -with:-coolant system -Keyless drill Chuck 1-13 - lighting
used, good condition radial drilling machine / Kesselradiale of Collet and Engelhardt, type BUV 1000 Head is rotating and swiveling. The machine is fully moveable. Technical data Spindle retainer 4 MK Drilling capacity approx. 40 mm RADIUS approx. 900 mm Dimensions L x W H approx. 2100 x 1000 x 2500 mm Weight approx. 2500 kg
GeneralCNC Turning Centre with C axis and tool drive; Control: CELOS with Siemens 840D sl Operate Work spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmWorking areaSwing diameter over guide ways700 mmTurning diameter410 mmTransverse stroke300 mmLongitudinal stroke850 mmClamping chuck diameter max.315 mmMax. Turning Length800 mmBar diameter max.65 mmMain drive 1Drive power (100% DC)33 kWSpeed range20 - 4000 rpmTorque (100% DC)580 NmC-Axis Speed-200 rpmTorque of C-Axis (holding torque)225 NmAccuracy at point stopping0,01 degreeTool holder 1Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.-4000 rpmPower max. (40% DC)11,3 kWFloor space/WeightDimensions (L x W x H)3,99 x 2,69 x 1,99 mWeight approx.6500 KgTechnologie cycle alternating speedTechnology cycle for the ...
KOTEC PSD-4520 CNC drilling machine was built in 2020 in South Korea by KOTEC Co., Ltd. The machine, which is designed for drilling precision holes and threading, is an excellent choice for companies specialising in, among others, the construction of machinery or the production of steel structures. The machining process is performed in three axes (X,Y,Z) on a large work area with a length of 4500 mm and a width of 2000 mm. A number of state-of-the-art components, combined with an extremely stable design, guarantee the best results, even during the most intensive machining. All this is complemented by an advanced CNC control with an intuitive interface and all the necessary functions. The KOTEC PSD 4520 CNC beam drilling machine weighs approximately 8900 kg. Technical specifications of the KOTEC PSD-4520 CNC metal drilling machine - number of axes: 3 (X,Y,Z) - feed in the X/Y axis: 4 ...
Specifications: Manufacturer: MB Maschinenbau / EDM Drilling Machine Type: ECO DRILL F DK703F Control: SINO SDS 32 – 3 EC Year of Make: 2007 Travel X, Y: X 250 mm, Y 200 mm Travel Z (servo automatic): 360 mm Travel W (head movement manual): 250 mm Pump: Piston High Pressure Pump Clamping table L/W: 300 x 400 mm Working tank: 440 x 540 mm Workbench Max. distance table to electrode guide: 300 mm Electrode diameter: 0.3 – 3.0 mm Max. workpiece weight: 250 kg Generator Connected load: 3.5 kVA Connection: AC 3x 230 V, 50.60 Hz Max. Output Power: 25 amp Dimensions and weight Dimensions L/W/H: 1,300 x 900 x 1,900 mm Weight: 850 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Additional flushing, DC servo motor
) for double pot MAKO-DT/130 ) with two drills ) incl. automatic Mittelbohreinstellung ) Cycle time per frame is less than 15 seconds ) Clamping and centering device with pneumatic cylinders, which are vertically and horizontally ) this machine streamlines the beating of wood window
The VT1250 is a double-sided glass drilling machine from Bavelloni , designed for precision and durability in the glass processing industry. Here are the key specifications and features: ⚙️Technical Specifications VT1250 Machine type : Double-sided glass drilling machine (top and bottom) Maximum glass thickness : Up to 25 mm Maximum drill diameter : 130 mm Range (X-axis) : 1250 mm Machine dimensions : Length: approx. 2200 mm Width: approx. 1000 mm Height: approx. 1900 mm Transport dimensions: 2.5 x 2.2 x 1.9 m Year of manufacture : Varies per model (for example 1995 for reconditioned models) Extras : Equipped with laser for positioning Double-sided drill heads (top and bottom) Automatic programming of drill heads based on glass thickness Air-controlled rack for glass positioning Why popular? Reliability : Used worldwide by glass companies because of its robust ...
ID3679 Atlas Copco Mustang A66 CBT-HD year/Baujahr 2000 approx. 16.310 hours/hours 15 t Drilling rig, carriage BMI 6.7 (length 8750 mm, travel 6700 mm), drill head S1300, engine Deutz BF4M1013, diesel engine replaced at 10200 hours, hydraulic pump is new (drive wheel still needs replacing), generally good condition, regularly serviced (service records available) Drilling rig, mount BMI 6.7 (length 8750 mm, 6700 mm travel), drill head S1300, engine Deutz BF4M1013, at 10200 hours the diesel engine was renewed, hydraulic pump is new (drive wheel still needs to be replaced), generally good condition, service has always been done (service certificates are available)
Condition: Very good condition Available: Immediately
Duration / ALB ear power 30/35 mm thread cutting capacity Max M24 (Steigungsabhängig) hand-reversing switch for forward link. Undervoltage, thermal overload protection, spindle MK 3 drilling depth 180 mm throat depth 260 mm column diameter of 110 mm-usable table surface [BxL] 420 x 340 mm speed display scale drilling depth indicator scale drill depth stop with fine adjustment Table height with rack and pinion motor three-phase of 400 V pole changing bar 1,5/2 kW spindle speed continuously 125-2000 1 / min including drilling package consisting: taper mandrel, Chuck, Vice and T - Groove set. Warranty: 3 years delivery: immediately, free delivery loaded: free House including packaging not the right machine? WE DO ALSO OTHER AFLOAT PRODUCTS - ASK FOR A QUOTE! FLOTT BASE PARTNER .
ear-deep and speed display - digital thread cutter M20 (gradient-dependent) variable speed 125-4000 U/Mon in two stages, stage change of belt apportionment. Drilling capacity 525/30 mm of thread cutting capacity (depending on elevation) M20 spindle MK 3 drilling depth 125 mm projection of 280 mm-usable table surface (pivoting) 420 x 340 mm Feed rate of hand table height with rack machines dimensions (W x D x H) 520 x 820 x 1900 mm motor three-phase 400 V pole changing bar 0.9 / 1.45 kW weight 275 kg
Thread cutting device Freischneiden Setup Drilling depth shut off programmable Drilling depth and speed display - digital Thread cutter M20 (depending on elevation) variable speed of 125-4000 U/mon in two stages, stage change of belt apportionment. Drilling capacity 25/30 mm Spindle MK 3 Drilling depth 125 mm Projection 280 mm Usable surface (pivoting) 420 x 340 mm Feed 0-300 mm / min stepless Table height with rack and pinion Machine dimensions (W x D x H) 520 x 820 x 1900 mm Motor three-phase 400 V pole changing bar 0.9 / 1.45 kW Weight 300 kg Including drilling package consisting: taper mandrel, Chuck, Vice and T - Groove set. Option: spindle stop and chip fracture module 690 EUR DELIVERY: free House including packaging NOT THE RIGHT MACHINE? WE DO ALSO OTHER AFLOAT PRODUCTS - ASK FOR A QUOTE! FLOTT BASE PARTNER .
Drilling depth and speed display - digital Thread cutting device M30 (depending on elevation) R1 spindle speed with continuous transmission speed series 100-2000 1 / min R2 spindle speed with continuous transmission speed range 70-1400 1/min Drilling capacity 35/40 mm Spindle MK 4 Drilling depth 160 mm Throat depth 300 mm Usable surface (pivoting) 590 x 450 mm Feed by hand Table height with rack and pinion Machine dimensions (W x D x H) 610 x 850 x 1920 mm Motor three-phase 400 V pole changing bar 1,5/3,0 kW Weight 420 kg Including drilling package consisting: taper mandrel, Chuck, Vice and T - Groove set. DELIVERY: free House including packaging NOT THE RIGHT MACHINE? WE DO ALSO OTHER AFLOAT PRODUCTS - ASK FOR A QUOTE! FLOTT BASE PARTNER .
Thread cutting device Freischneiden Setup Drilling depth shut off programmable Drilling depth and speed display - digital Thread cutting device M30 (depending on elevation) R1 spindle speed with continuous transmission speed series 100-2000 1 / min R2 spindle speed with continuous transmission speed range 70-1400 1/min Drilling capacity 35/40 mm Spindle MK 4 Drilling depth 160 mm Throat depth 300 mm Usable surface (pivoting) 590 x 450 mm Feed 0-300 mm / min stepless Table height with rack and pinion Machine dimensions (W x D x H) 610 x 850 x 1920 mm Motor three-phase 400 V pole changing bar 1,5/3,0 kW Weight 420 kg Including drilling package consisting: taper mandrel, Chuck, Vice and T - Groove set. Option: spindle stop and modulus of rupture of chip 660 EUR DELIVERY: free House including packaging NOT THE RIGHT MACHINE? WE DO ALSO OTHER AFLOAT PRODUCTS - ASK ...
Technical data: -Drilling capacity approx. 30 mm - spindle mount MT 3 -Spindle speeds in 2 steps continuously variable 80-1400 RPM -Table surface 390 x 420 mm -Drill unit by hand crank height adjustment -min / max distance table / spindle 220 / 580 mm -Drilling spindle stroke 150 mm -Spindle projection powered 280 mm â 400 V / 1.3 / 2.3 kW -Space requirement approx. B 480 x H 880 - H 1200 X 1050 mm -Weight approx. 250 kg -Table base with storage space B 600 x h. 910 x H 800 mm -Weight 200 kg
Duration / ALB ear power 35/40 mm Thread cutting capacity Max M30 (Steigungsabhängig) Hand-reversing switch for forward link. Undervoltage, thermal overload protection, Spindle MK 4 Drilling depth 160 mm Throat depth 300 mm 2johiqzz Column diameter 110 mm Usable surface [BxL] 420 x 340 mm Speed display scale Drilling depth indicator scale Drilling depth stop with fine adjustment Table height with rack and pinion Motor three-phase 400 V pole changing bar 1.5/3 kW Spindle speeds with continuously variable transmission 100-2000 1 / min Machine size (WxDxH) 610 x 850 x 1920 mm Weight 420 kg Including drilling package consisting: taper mandrel, Chuck, Vice and T - Groove set. Warranty: 3 years Shipping time: immediately, free loaded DELIVERY: free House including packaging NOT THE RIGHT MACHINE? WE DO ALSO OTHER AFLOAT PRODUCTS - ASK FOR A QUOTE! FLOTT BASE ...
right / left Number of spindles 4 Slide stroke 800 mm Drilling area in steel St-60 Full drilling dia. 15 mm Boring dia. 20 mm Drilling method Single-lip drill
VR 4A/1250 Producer Mas Max. drilling diameter 50 mm Max. vertical arm adjustment 750 mm Taper in spindle 4 Morse Main motor output 4 kW Dimensions l x w x h 2250x1055x2970 mm Machine weight 2700 kg
MIKROMAT Model / type:BKoE 630x1000 Technical data: > Mikromat BKoE 630 x 1000 > table clamping surface 1000 x 630 mm > longitudinal travel of the table 710 mm > cross travel of the table 700 mm > travel of headstock 630 mm > spindle stroke 200 mm > distance between spindle nose and table 20-850 mm
BKOZ 900x1400 spindle taper MK IV sleeve stroke 250mm table size 900x1400mm longitudinal 1000mm cross 750mm vertical movement by the head of main spindle 600mm spindle speeds 28-1400 Upm spindle feeds 0,02-0,8mm/U scales wreaths for all directions of motion hydr. clamping system coolant system sep. control cabinet Motor: 230/380V 50HZ 8KW dimensions base: 3.300 x 2.400mm height: 2.500mm weight: 7.500 kg
Fitting drill Ganner L x W x H: 1.20 x 0.80 x 1.40 m + stops Weight approx. 400 kg Built in 1987 The machine is in good condition, ready for operation. Changes, errors, intermediate sale reserved ! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system + technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Tel. 0041 62 966 18 32 Fax 0041 62 966 21 12
Continuous drilling capacity: 25 mm Normal drilling capacity: 30 mm Thread cutting power: M 16 Spindle: MK 3 Drilling depth: 135 mm Spindle speeds infinitely variable: 150 - 3000 rpm Table size: 460 x 360 mm Weight: 225 kg Mains connection: 400 volts, 50 Hz Facilities: - Thread cutting device - Digital display for speed as standard - Coolant device - LED machine light - Stepless speed adjustment - 24 V Electric - Base plate with T-slots - Drilling table adjustable via rack and worm gear and swivelled around column - Emergency-off-strike button - Motor full protection - Star handle - CE compliant
Drilling capacity max.: 30 mm Thread cutting: M 14 Tool rear ham: MK 3 Spindle speeds, infinitely variable: 150 - 2500 rpm Extension: 265 mm Drilling depth: 150 mm Pinole feed: 0.05 / 0.1 / 0.2 mm/U Column diameter: 92 mm Table size / T-slot size: 500 x 400 mm / 14 mm Engine power: 1.5 kW Machine dimensions (W x D x H): 640 x 850 x 1850 mm Weight approx.: 265 kg Characteristics: - Vario drive for infinitely variable adjustment of the desired speed - Pinole delivery either by hand or by mechanical feed - Set speed by means of digital display quickly and easily readable - Stable casting table with T-slots and coolant gutter - Adjustable drilling depth stop, drilling depth can be read by scale - Thread cutting device - CE / IEC, German documentation and German service Delivery: - Quick-clamp chuck 1 - 16 mm / B 18 - Drill chuck mandrel MK 3 / B 18 - Coolant dev ...
Drilling capacity max.: 35 mm Thread cutting: M 24 Tool rear ham: MK 4 Spindle speeds, infinitely variable: 65 - 2000 rpm Extension: 265 mm Drilling depth: 150 mm Pinole feed: 0.05 / 0.1 / 0.2 mm/U Column diameter: 115 mm Table size / T groove size: 685 x 485 mm / 14 mm Engine power: 1.5 kW Machine dimensions (W x D x H): 950 x 580 x 2000 mm Weight approx.: 385 kg Characteristics: - Vario drive for infinitely variable adjustment of the desired speed - Pinole delivery either by hand or by mechanical feed - Set speed by means of digital display quickly and easily readable - Stable casting table with T-slots and coolant gutter - Adjustable drilling depth stop, drilling depth can be read by scale - Thread cutting device - Gearbox pre-bed - CE / IEC, German Documentation and German Service Delivery: - Table clamping and height adjustment from the front - Quick-clam ...
Type: MZ73031A Number of spindles 3 Distance between first and last spindle 50 mm Adjustable drilling speed Height of the working table 820 mm Table dimensions 735×440 mm Number of clamps 2 Motor power 1,5 kW 400 V Motor r.p.m. 2800 r.p.m Working air pressure 6-8 bar Weight 75 kg Transporting dimensions 900x700x1500 mm
ID3737 Nordmeyer on Unimog Well drilling rig, Nordmeyer? on Unimog, single-stage pump, equipment overhauled in the last 3 years for approx. €40,000 (power swivel, hydraulic pumps, main gearbox for engine overhauled, new flushing pump), everything works, drilled with it so far: 100 m depth - 152 mm, 60 m depth - 325 mm Well drilling rig, Nordmeyer? on Unimog, single-stage pump, equipment overhauled the last 3 years for about 40,000 euros (power turntable, hydraulic pumps, main gearbox for engine overhauled, new mud pump), everything works, drilled with it so far: 100 m depth - 152 mm, 60 m depth - 325 mm
Continuous/normal drilling power (mm) R1 (gemes. Drehmom. Nm) 30/35 (in E3335/ST60) (135) R2 (gemes. Drehmom. Nm) 27/32 (in E335/ST60) (90) Thread cutting performance max. (slope-dependent) R1 M30x3.5 R2 M24x3 Spindle MK IV Drilling depth (mm) 160 Extension (mm) 300 Column diameter (mm) 140 Usable table area (W x D) (mm) 590 x 450 Speed display digital Drilling depth display digital Drilling depth stop with fine adjustment Table height adjustment with rack Spindle/table (mm) 150-700 Machine dimensions without VP (mm) 610 x 900 x 1,980 mm Machine dimensions with VP (mm) 670 x 1,100 x 2,200 mm Motor rotary current 400V with frequency inverter (kW) 4.0 Spindle speeds infinitely variable R1 (1-stage) 0-1000 rpm R2 (1-stage) 0-1600 rpm Feed by hand Weight (kg) 400 Optional (780 EUR) drilling package 5,beststretched from: Vice [felix] 125 Cone mandrel MK III/B ...
Woelfel B100/S used machine Spindle dia 125mm MK 6 Ram dia 165 mm with stroke 200 mm Spindle speed in 24 steps from 30 - 1200 rpm Vert. travel of headstock 1250 mm Bed clamping surface 870 x 700 mm Additional table 710 x 560mm height 500 mm Height between bed and spindle nose 1460 mm
20-90-542 Multeosill Drilling Machine WOODLAND MACHINERY (new) Type: BM21S Number of shafts 21 Adjustable drilling angle Working width 700 mm Table Dimensions 1000 × 900 mm Additional support Ruler 3000 mm Number of Pressers 2 Engine power 1.5 kW 380 V 50 Hz Required Air Pressure 8 bar Drilling Step 32 mm Weight 150 kg Transport Dimensions 1200x1000x1300 mm
used
GeneralCTX beta 1250 4A Two spindle turning centre with - partial hollow clamping device for main spindle and counter spindle internal diameter of draw tube Ø67 mm (2.63 in) x 700 mm (27.55 in) deep - 2 C-axes and spindle brakes (hydr.) - 2 12 fold Sauter star turrets reception VDI 40, DIN 69880-40 with precision interface (Trifix) and tool drive connection/drive acc. DIN 5480 - Y-axis, slide I - counter spindle slide; Control: CELOS X with Siemens 840D SL Operate Headstock, leftClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWTorque (100% DC)280 NmSpeed range0-5000 rpmC-Axis Speed2000 rpmHeadstock, rightClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWC-Axis Speed2000 rpmTorque (100% DC)280 NmSlide 1Longitudina ...
CATALOG NUMBER M0252 PRODUCT FEATURES The main features of the machine: - Single-head drilling machine for drilling in the range of 0 - 90 ° - Pivoting angle of the head adjusted pneumatically - Possibility to set lateral supports with an accuracy of 0.1 mm - Safety holders allow quick adjustment of panels without adjustment - Spindles adapted for quick couplers - Patented pneumatic clamps of the material - MDF work table - Quick and accurate adjustment - Precise drilling - Italian production Standard equipment of the machine: - 2 aluminum rulers with a length of 1.5 m (right and left) with four stopwatches - 5 quick connectors - Wooden box securing the machine in transport. ADVANTAGES - vertical / horizontal / angled drilling - multi-spindle - new machine - CE certificate - solid - professional TECHNICAL DATA - number of spindles 23 - dista ...
