drilling and milling used for sale

Radial Drilling GSP 49S22 Spindle: Ø 125 mm Cone CM6 Spindle exit: 600 mm Spindle speed: from 17 to 1050 RPM Arm travel: 1800 mm Maxi height column travel: 1800 mm Column diameter: 600 mm Total column height: 3000 mm Spindle motor: 11 kW Drilling/tapping function Mechanical locking of the column Hydraulic locking of the trolley Auto descent Delivered with one cube dimensions: L 800 x W 560 x H 600 mm Table size: L 3300 x W 1400 x H 320 mm Voltage: 380 V Total weight: 12 T

Magnetic drilling machine, magnetic drilling machine Core hole drilling machine, Metal core hole drilling machine DR. BENDER Type EK 323 Masch No. 180543 Year of construction approx. 1988 Drilling capacity 23 mm Spindle holder MK 2 Spindle speed 160 / 400 / 1250 rpm. Magnet 215 x 105 mm Drilling unit 220 Volt, 50 Hz, 1025 Watt E-magnet 220 Volt, 50 Hz, 65 Watt - Spindle speed via 3 gear stages - Left and clockwise rotation - E-magnet KOCH, type KL32/6 - Drill head height adjustment guided in a linear guide - manual expulsor - Drill stand rotatable on magnetic base, clamping via toggle screw Dimensions L x W x H 680 x 380 x 630 mm Weight 35 kg good condition; used

Boom drilling machine KNUTH type KAB16 Masch. No. 44715 Year of construction 1987 Drilling capacity in steel 16 mm Drilling capacity max. 23 mm Spindle holder MK 2 Pinol stroke 80 mm Projection 550 mm Spindle speed 290 - 2330 rpm 12 steps Clamping surface 650 x 310 mm Distance between drilling spindle Clamping surface max. 890 mm Column diameter 102 mm Motor power 0.55 kW Mains connection 400 volts, 50 Hz Spindle speed via 12 V-belt steps - Drill head height adjustment via hand crank - Drill head swivels +/- 90- Drill head rotatable on the column and on the boom arm Space requirement L x W x H 1030 x 400 x 1000 mm Weight 140 kg very good condition; used

Drilling machine, column drilling machine, pillar drilling machine, pillar drilling machine, multi-spindle head, multi-spindle drilling head, drilling gear -with two-spindle drilling head Manufacturer Sigloch Schrieder Type: V602 -Drive power: 1.02/0.88 kW -Drill distance adjustable: 18-110 mm -Max. Drill: 2x Ø 6 mm -Table size: 275 mm -Spindle mount: MK3 -Projection: 220 mm -Speeds: 100-2900 rpm -Columns: Ø 100 mm -Spindle stroke: 75 mm -Transmission -Dimensions: 900/400/H1910 mm -Weight: 230kg

bore capacity in steel (diameter): 30 mm x-travel: 850 mm y-travel: 435 mm Control: HEIDENHAIN TNC 150 total power requirement: 16 kW weight of the machine ca.: 3500 kg dimensions of the machine ca.: m F E H L M A N N (Switzerland) CNC-Controlled High Precision Drilling and Milling Machine with HEIDENHAIN CNC-Control Model TNC 150 Model PICOMAX 100 CNC – 2 + A Year 1985 Serial No. 16 085 109 _______________________________________________________________ Table travel: Longitudinal ( X-Axis) 850 mm Cross (Y-Axis) 435 mm Milling/Boring head travel vertical ( Z-Axis) 210 mm Table size /Clamping area 500 x 1.570 resp. 390 x 1.280 mm Mounting height below spindle, approx. 140 / 690 mm Height adjustment of Milling head max. 540 mm Distance between spindle and column 450 mm Spindle tape ...

Description: Table lathes with drilling and milling unit - 3-axis LCD digital display system - Longitudinal feed. - 3-jaw chuck 125 mm. - 4-way steel holder. - Chip tray, bulkhead - Hardened bed tracks. - Emergency stop switch - Lining protection drilling and milling unit incl. - Quick chuck 1-16mm - Tightening spindle for milling tools - Lining protection - Emergency stop switch - Tool box, instruction manual. Turning diameter over bed 250 mm Turning diameter over support 145 mm Turning length 550 mm Speed 50 - 2000 rpm Center height 125 mm Spindle bore 26 mm Tailstock quill holder MK 2 MK Connection voltage 230 V Drilling capacity in steel 16 mm Projection 169 mm Quill stroke 50 mm Speed range - drilling 50 - 2250 rpm Spindle motor 0.5 kW Total power requirement 0.75 kW Machine weight approx. 0.175 t Space requirement approx. 1.3 x 0.65 x 1.3 Approx. Onsite Dimension. (l x w x h): 1,30 ...

Radial drilling machine used for drilling and milling Manufacturer: COLLET & ENGELHARD GmbH Type: BUV 1600 Year of construction: 1976 horizontally and vertically swivelling head Drilling capacity: 50 mm Travel arm: approx. 800 mm max column travel: 1000 mm Speed: 14 to 710 rpm Spindle stroke approx. 300 mm 380 V Dimensions: approx. 2600 x 1300 x 3000 mm Changes and errors in the technical data, information and prices as well as prior sale reserved.

BALESTRINI TEAM automatic CUTTING , END MILLING and DRILLING MACHINE machine for joining parts of chairs, living rooms, furniture, etc. the TEAM machine is made up of 3 operating units: 1st unit: circular saw for cutting workpieces to length 2nd unit: spindle moulder for milling 3rd unit: drilling unit with multiple center distance head . there are 9 work programs that can be choiceed and they consist of the possible combinations of use of the 3 operating units. only 2 can be used , or 1 , or even the 3 operating units can work in different sequences . all units are operated by a hydraulic pump to obtain adjustable and smooth movements Technical data : - Cutting unit (circular saw) diam.mm.400. engine power Hp 3 - Moulding unit (spindle moulder) shaft diameter mm.30 . motor power Hp 5.5 max. tool dimensions mm.160, H=mm.120 - Boring unit . engine power Hp 3 . max. depth ...

Description: Drilling and milling machine: - Digital Depth Gauge - Adjustable guides by gibs - Big 12 stage speed range 75-3200 rev / min - Quiet operation due to hardened and ground gears in oil bath - Forward and reverse running - Prismatic guides in all axes - Gear head pivots through 90 ° - Chip guard with safety circuit - Threading attachment - Bellows cover Y + Z-axis, - ISO 40 Drill chuck Without an under-table, is available as an option. Drilling capacity in steel 40 mm Projection 290 mm Drilling stroke 130 mm Spindle taper SK 40 Spindle speeds 75-3200 U / min Millinghead vertical adjustable 350 mm Table adjustment across 230 mm Table adjustment along 520 mm Table area 730 x 210 (800x2 mm Supply voltage 400 V Total power requirement 1,5 kW Machine weight about 0.32 t Space needs about 1.1 x 0.86 x 1.15 m Approx. Onsite Dimension. (l x w x h): 1,100 x 860 x 115 mm, weight approx. ...

Description: Drilling and milling machine with Powerful 2-speed motor. Recording MC 3 - B16. Drill chuck 3 - 16 mm. Left/right switch. Spindle protection. Fine tuning. ejection wedge. Clamp the threaded rod for the tool Related tools. Drilling capacity in steel 32 mm Projection 200 mm Drilling stroke 70 mm Capacity of the end mill 16 mm Spindle mount MK3 Spindle speeds 50 - 3000 rpm Table adjustment transversely 220 mm Table adjustment lengthwise 425 mm Table clamping surface 700 x 210 mm Connection voltage Vmax. Distance between work table and spindle nose 470 mm Total power requirement 1.5 kW Machine weight approx. 230 kg Space requirement approx. 0.75 x 1.05 x 1.2 m Approx. Onsite Dimension. (l x w x h): 750 x 1,050 x 1,200 mm, weight approx.: 230 kg

Description: Drilling and milling machine with - Variable spindle speed - Digital depth display - Left / right switch - Cross Support - swivel spindle head - Feeds via hand crank - Tool case with content Drilling capacity in steel 13 mm Projection 170 mm Drilling stroke 50 mm Capacity end mill 13 mm Spindle mount MK 2 Spindle speeds 50 - 3000 rpm Table adjustment across 220 mm Table adjustment along 160 mm Table clamping surface 500 x 140 mm Connection voltage 230V Total power requirement 0.5 kW Machine weight approx. 0.06 t Space required approx. 0.6 x 0.45 x 0.76 m Attention: machine is without digital display Approx. Onsite Dimension. (l x w x h): 600 x 450 x 760 mm, weight approx.: 60 kg

Description: Drilling and milling machine with - Cross Support - Feed via hand crank - Chip protection - 16mm drill chuck - mechanical MK tool clamping Drilling capacity in steel (diameter) 16 mm Projection 180 mm Drilling stroke 85 mm Spindle mount MK 2 Spindle diameter 47 mm Spindle speeds 320 - 3300 rpm Table adjustment across 230 mm Table adjustment along 100 mm Table mounting surface 420 x 155 mm Connection voltage 230V Total power requirement 0.75 kW Approx. Onsite Dimension. (l x w x h): 900 x 600 x 300 mm, weight approx.: 80 kg

Description: Drilling and milling machine with large table Digital display SINO 3-axis. Digital display quill stroke. 2 speed levels. Left/Right switch Pan head left/right 90° spindle protection. incl. tool box with various tools Drilling capacity in steel 25 mm Projection 175 mm Drill stroke 50 mm Capacity end mill 16 mm Spindle mount ISO 30 Spindle speeds 50 - 3000 rpm Table adjustment across 380 mm Table adjustment longitudinal 175 mm Table clamping area 700 x 180 mm Connection voltage 230 V max. distance between work table and spindle nose max. 320 mm Total power requirement 0.75 kW Machine weight approx. 130 kg Space requirement approx. 670 x 550 x 910 m Approx. Onsite Dimension. (l x w x h): 670 x 550 x 910 mm, weight approx.: 130 kg

Description: Machine number: 811012 Spindle speed range: 50 - 2520 rpm Table dimensions: approx. 670 x 240 mm With swivel drilling and milling head With machine vice Jaw width: approx. 100 mm With various machine accessories as shown in the pictures, including twist drills in various lengths and diameters, a drill chuck, a dividing head (diameter: approx. 200 mm) and various other accessories Approx. Onsite Dimension. (l x w x h): 1,300 x 1,200 x 1,800 mm, weight approx.: 320 kg

bore capacity in steel (diameter): 50 mm throat: 360 mm bore stroke: 150 mm spindle turning speed range: 120 - 3000 U/min spindle taper: SK 40 : 650 mm : 320 mm vertical adjustment: 500 mm table surface area: 1000 x 300 mm connected load frequency: 400 V diameter of hob: max. 80 mm total power requirement: 2,2 kW weight of the machine ca.: 0,85 t dimensions of the machine ca.: 1,25 x 1.5 x 2,3 m New Model Industrial Drilling and Milling Machine with Manual Transmission and High Speed Range. The prism guide in the Z-axis ensures a high degree of precision even in the most difficult milling jobs. Domestic equipments: • automatic feed in X-axis • 3-axis digital display • motorized Z-axis • Feed in quill • Left-right-run high • tapping attachment • Gear head swiveling • Coolant system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 45 mm throat: 230 mm bore stroke: 125 mm spindle taper: ISO 30 spindle turning speed range: 75 - 1600 U/min max. milling cutter diameter: 80 mm : 560 mm : 230 mm table surface area: 800 x 240 mm max. distance between table and spindle-nose: 460 mm connected load frequency: 230 V total power requirement: 1,1 kW weight of the machine ca.: 320 Kg dimensions of the machine ca.: 1,0 x 0,8 x 1,45 m Drilling and milling machine - Cross Support - Cabinet - Swivel spindle head left / right 90 ° - Feed via hand crank The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: Drilling and milling machine with - variable spindle speed - cross support - rotating spindle head left/right 90° - Feed via hand crank Drilling capacity in steel 16 mm projection 185 mm Drill stroke 50 mm Capacity end mill 20 mm Spindle mount MT 2 Spindle speeds 100-1500 / 200-3 rpm Table adjustment across 175 mm Table adjustment longitudinal 280 mm Table clamping area 500 x 180 mm Connection voltage 230 V Total power requirement 0.85 kW Machine weight approx. 0.12 t Space requirement approx. 0.86 x 0.6 x 0.9 m Approx. Onsite Dimension. (l x w x h): 860 x 600 x 900 mm, weight approx.: 120 kg

bore capacity in steel (diameter): 30 mm throat: 198 mm bore stroke: 75 mm : 16 mm spindle taper: MK3 spindle turning speed range: 95 - 2840 U/min : 320 mm : 190 mm table surface area: 700 x 190 mm connected load frequency: 400 V max. distance between table and spindle-nose: 55 - 405 mm total power requirement: 1,1 kW weight of the machine ca.: 180 Kg dimensions of the machine ca.: 0,75 x 1,05 x 1,3 m Drilling and milling machine with - variable spindle speed - Digital depth display - Left / right switch - Cross support - swiveling spindle head - Feeds via hand crank - Tool case with content but without digital display The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 25 mm throat: 170 mm bore stroke: 50 mm : 16 mm spindle taper: MK 2 spindle turning speed range: 50 - 3000 U/min : 280 mm : 155 mm table surface area: 500 x 180 mm connected load frequency: 230 V max. distance between table and spindle-nose: max. 320 mm total power requirement: 0,8 kW weight of the machine ca.: 150 Kg dimensions of the machine ca.: 670 x 550 x 910 m Drilling and milling machine with - variable spindle speed - Digital depth display - Left / right switch - Cross support - swiveling spindle head - Feeds via hand crank - Tool case with content but without digital display The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 25 mm throat: 175 mm bore stroke: 50 mm : 16 mm spindle taper: ISO 30 spindle turning speed range: 50 - 3000 U/min : 380 mm : 175 mm table surface area: 700 x 180 mm connected load frequency: 230 V max. distance between table and spindle-nose: max. 320 mm total power requirement: 0,75 kW weight of the machine ca.: 150 Kg dimensions of the machine ca.: 670 x 550 x 910 m Drilling and milling machine with large table Digital display SINO 3-axis. Digital display quill stroke. 2 speed levels. Left/Right switch Pan head left/right 90° spindle protection. incl. tool box with various tools The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 30 mm throat: 200 mm bore stroke: 70 mm : 16 mm spindle taper: MK3 spindle turning speed range: 50 - 3000 U/min : 565 mm : 220 mm table surface area: 840 x 210 mm connected load frequency: 400 V max. distance between table and spindle-nose: max. 470 mm total power requirement: 1,1 kW weight of the machine ca.: 230 Kg dimensions of the machine ca.: 0,75 x 1,05 x 1,3 m Drilling and milling machine with large table Digital display SINO 3-axis. Digital display quill stroke. 2 speed levels. Left/Right switch Pan head left/right 90° Recording MC 3 - B16. Drill chuck 3 - 16 mm. spindle protection. Machine stand. incl. tool box with various tools The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 32 mm throat: 200 mm bore stroke: 70 mm : 16 mm spindle taper: MK3 spindle turning speed range: 50 - 3000 U/min : 220 mm : 425 mm table surface area: 700 x 210 mm connected load frequency: V max. distance between table and spindle-nose: 470 mm total power requirement: 1,5 kW weight of the machine ca.: 230 Kg dimensions of the machine ca.: 0,75 x 1,05 x 1,2 m Drilling and milling machine with - variable spindle speed - Digital depth display - Left / right switch - Cross support - swiveling spindle head - Feeds via hand crank - Tool case with content The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: neu : ca. 8 Wochen ab Auftragse : Spanien : 47270 € : 959.58 € : 35 mm : MK 4 : 390 mm : 94- 2.225 (16) 50 Hz 113 U/min : M35 : 1660 mm : 1510 mm : 2600 mm : 910 kg : 180 mm : 190 - 650 mm : 1310 mm : 125 mm : 400 x 420 mm : 0,10 - 0,18 - 0,24 (3) mm/min : 750 - 1.500 U/min ERLO (MADE IN SPAIN) FOR DEMANDING WORKSHOP USE drilling and milling machine automatic feed precision electromagnetic clutches geared drive cross table fixed base and displaceable headstock control panel cooling equipment with electric motor pump hand wheel for fine tuning clamping device for tools adjustable stop drill guard The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 16 mm throat: 170 mm bore stroke: 50 mm : 16 mm spindle taper: MK2 spindle turning speed range: 50 - 2250 U/min : 320 mm : 145 mm table surface area: 500 x 140 mm connected load frequency: 230 V total power requirement: 0,5 kW weight of the machine ca.: 90 Kg dimensions of the machine ca.: 0,5 x 0,45 x 0,84 m Drilling and milling machine with - variable spindle speed - Digital depth display - Left / right switch - Cross support - swiveling spindle head - Feeds via hand crank - Tool case with content but without digital display The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 40 mm throat: 290 mm bore stroke: 115 mm spindle taper: SK 40 spindle turning speed range: 70 - 3200 U/min : 350 mm : 130 mm table surface area: 590 x 190 mm connected load frequency: 400 V diameter of hob: max. 80 mm feed: 0,1 - 0,18 - 0,26 mm/U total power requirement: 1,1 kW weight of the machine ca.: 0,4 t dimensions of the machine ca.: 0,7 x 0,95 x 1,75 m Drilling and milling machine - Cross Support - Cabinet - Swivel spindle head left / right 90 ° - Feed via hand crank The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 40 mm throat: 275 mm bore stroke: 120 mm spindle taper: MK 4 turning speed range: 75 - 3200 U/min : 190 mm : 490 mm table surface area: 700 x 210 mm connected load frequency: 400 V diameter of hob: max. 80 mm total power requirement: 1,1/1,5 kW weight of the machine ca.: 0,35 t dimensions of the machine ca.: 0,8 x 0,75 x 1,85 m Drilling and milling machine - Cross Support - Cabinet - Swivel spindle head left / right 90 ° - Feed via hand crank The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 40 mm throat: 275 mm bore stroke: 120 mm spindle taper: MK 4 turning speed range: 75 - 3200 U/min : 190 mm : 490 mm table surface area: 730 x 210 mm connected load frequency: 400 V boring feeds:: 0,1 - 0,18 - 0,26 mm/U total power requirement: 1,1/1,5 kW weight of the machine ca.: 0,35 t dimensions of the machine ca.: 0,8 x 0,75 x 1,85 m Drilling and milling machine - Cross Support - Cabinet - Swivel spindle head left / right 90 ° - Feed via hand crank The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Manufacturer Heckler & Koch Model AM 444 A Power consumption: 5.5 KW Voltage: 380/400 Volts Spindle holders for vertical and horizontal spindles: 40 Slide movement x = 410nn y = 350mm z = 400mm Vertical clamping table 850 x 255 mm Feed range 0-1500 mm/min Sliding gearbox 12-stage Speed: 63-2800 rpm Step jump 1.4 CNC control CNC 783/m Dimensions (HxWxD) 1.800x2.400x1.700mm Weight 1,500 kg Ref.Nr PLW18 Mistakes reserved!

Drilling capacity in steel: 32 mm Drilling capacity in cast: 40 mm Cutter head milling max.: 80 mm Projection: 220 mm Spindle speed: (12) 75-3200 RPM Spindle retainer: MK 4 Quill stroke: 125 mm Table size: 800 x 240 mm Travel (x / y): 555 / 225 mm Milling head swiveling: - 90 ° to + 90 ° Distance from spindle / table: 60-485 mm Head height: 425 mm T - slot size: 14 mm S1 motor power output 100%: 1,1 / 1,5 kW (400 V) Motor power S6 40%: 1.5 / 2.2 kW (400 V) Machine dimensions (W x D x H) : 1140 x 770 x 1500 mm Approximate weight: 287 kg without stand Features: Quick and easy change of speed using the gear selector switch Versatile application possibilities such as drilling, milling, thread cutting, … High running smoothness by polished, running in an oil bath gear gears Right - and the link run device for thread cutting Quill adjustment by means of ...

Standard ALB ear performance: 30 mm Thread cutting performance: M 20 (option) Thread: M 12 Spindle: MK 3 or SK 30 (option) Quill stroke: 100 mm Longitudinal / cross travel: 350/160 mm Distance spindle/cross table: 80 to 450 mm Table area: 600 x 240 mm Column diameter: 110 mm Total height: Max 1,920 mm Weight: 340 kg Motor pole shift bar: 0.8/1.5 kW Spindle speeds, continuous, selectable: 10 spindle speeds: 80-1,400 rpm 10 spindle speeds: 120-2,160 rpm 10 spindle speeds: 160-2,800 RPM Facilities: A versatile, accurate and handy drilling milling machine. The quiet-running drive and a perfect clamping of Quill guarantee good surfaces when milling. The headstock can be swung out. The stage is precise and precisely adjustable. Pitch 0.05 mm. clamping device for both axes. Full motor protection. Machine incl. Cabinet.

Accessories available. Fehlmann stage KS 240 Drilling tailstock digitized Table size 530 240 mm Route x 280 mm Y way 180 mm Speeds, electronic, adjustable with potentiometer 132-4500 RPM

-Turret fence -Thread cutter table 600 x 320 mm Speed 40-3600 RPM Spindle diameter 65 mm Recording Aciera quick-change system Spindle stroke 120 mm Dimension WxDxH 90 x 130 x 185 cm Weight 800 kg

-Turret fence -Thread cutter table 600 x 320 mm Speed 40-3600 RPM Spindle diameter 65 mm Recording Aciera quick-change system Spindle stroke 120 mm Dimension WxDxH 90 x 130 x 185 cm Weight 800 kg

UWM BORING MILLING MACHINE TYPE 40A -MK4 -75/1600 t/m -Draait right en linksom -Tapfunctie -Boorgedeelte is in hoogte verstelbaar -Boorgedeelte is kantelbaar -Tandwielaangedreven -Beschermkap -Noodstop -Boorkop Zelfspannende -Documentatie -400V PRICE is plus VAT DUTCHMACH Metal working machinery ENSCHEDE - NETHERLANDS (3 km from the German border)

Control: HEIDENHAIN TNC 124 Traverse path x/Y/Z 500/ 250 / 160 mm Travel W 480 mm Size (L x W) 885 x 320 mm Maximum table load 250 kg Distance from table - spindle nose 0-605 mm Speed x/Y 1-2000 mm / min Feed speed Z 1-1200 mm / min Tool - quick change system SF 32 RPM infinitely 9200 RPM 5 kW Dimensions (W x D x H) 1850 x 2550 x 2400 mm

Special price for stock goods! Only while stocks last! Drilling-milling machine: Bernardo Type/Model: FM 45 HSV with digital display Condition: new Drilling capacity in steel: 32 mm Drilling capacity in cast iron: 40 mm Knife head milling cutter max.: 80 mm Projection: 220 mm Spindle speed: (12) 75 – 3200 rpm Spindle holder: MK 4 Pinole stroke: 120 mm Pinole feed: (3) 0.10 / 0.18 / 0.26 mm/U Table size: 800 x 240 mm Travel (x / y): 555 / 205 mm Milling head swivel: -60° to +60° Distance spindle / table: 60 – 485 mm Height adjustment milling head: 425 mm T-slot size: 14 mm Motor output power S1 100%: 1.1 / 1.5 kW (400 V) Motor input power S6 40%: 1.5 / 2.2 kW (400 V) Machine dimensions (W x D x H): 1140 x 770 x 1500 Weight approx.: 308 kg without base Characteristics: - High-torque 2-stage motor, speed range 75 - 3200 rpm - Double-sided swivelling m ...

Digital display Heidenhain Thread cutting device Automatic pinole feed Electr. adjustable head (height) Coolant pump Table size 600 x 250 mm Recording MK 3 Speed Continuous

MOVING COLUMN MILLING-BORING MACHINE Condition Used Very good condition Control type Selca S4060-D Table length 2.800 mm Table width 1.100 mm Table height 210 mm T-slot dimensions Centre 22H7 - Others 22 H8 Number of T-quarries n. 7 T-slot spacing 160 mm Max. permissible weight 10.000 Kg X axis stroke 2.500 mm Y-axis stroke 1.675 mm Z axis stroke 1.250 mm Fast 30.000 mm/min Axle motor torque 58 Nm Automatic head Axis A 2,5° - Axis B 1° Spindle cone ISO 50 DIN 69871 Rotational speed 5,000 rpm Spindle power 17 Kw Tool change 40 positions N. 2 constant power speeds I range 250-1250 rpm - II range 1000-5000 rpm Clamping system BERG pliers Selbox S2 remote flyer

X travel: 6300 mm vertical travel Z: 1700 mm transversal travel RAM Y: 1000 mm Ortogonal head, 2 spindles Automatic head rotation 1°/1° with hirt spindle taper ISO 50 CNC Heidenhain Machine in good working conditions

bore capacity in steel (diameter): 30 mm x-travel: 250 mm y-travel: 350 mm z-axis: 350 mm table-size: 240 x 800 mm spindle turning speed - stepless: 115 - 1750 U/min spindle taper ISO: 40 upper slide-adjustment: 500 mm : 200 -700 mm head swivability: 2 x 45 ° distance spindle /table: 60 - 390 mm feed - longitudinal/cross: total power requirement: 1,5 kW weight of the machine ca.: 1050 kg dimensions of the machine ca.: 1,28 x 1,10 x 1,92 m Coolant System: Digital Read Out: The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 500 mm y-travel: 360 mm z-travel: 400 mm Control: Siemens 810 tool taper: SK 40 table surface area: 800x390 mm T-slot - width: 14H7 mm number of T-slots: 6 T-slot - distance: 63 mm turning speeds: 20-4000 U/min transmission ratio: 4 Feed: 1-2000 mm/min rapid traverse: 5 m/min total power requirement: 9 kW weight of the machine ca.: 2 t dimensions of the machine ca.: 2,5x2,9x1,9 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 40 mm throat: 290 mm bore stroke: 130 mm spindle taper: SK 40 spindle turning speed range: 70 - 3200 U/min : 520 mm : 230 mm table surface area: 730 x 210 mm connected load frequency: 400 V total power requirement: 1,1/1,5 kW weight of the machine ca.: 0,32 t dimensions of the machine ca.: 1,1 x 0,9 x 1,15 m domestic equipments • Digital depth gauge • Adjustable guides with wedges • Large 12-speed range from 75 to 3200 rpm • Smooth running due to hardened and ground gears running in an oil bath • • Right-left rotation • Prismatic guides in all axes • Gear head can be swiveled 90 ° • Chip protection with safety circuit Machine base optional. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 25 mm throat: 185 mm bore stroke: 50 mm spindle taper: MK 3 spindle turning speed range: 50 - 2500 U/min : 178 mm : 480 mm table surface area: 700 x 180 mm connected load frequency: 230 V total power requirement: 0,75 kW weight of the machine ca.: 160 t dimensions of the machine ca.: 0,75 x 0,8 x 0,9 m domestic equipments • Digital depth gauge • Adjustable guides with wedges • Large 12-speed range from 75 to 3200 rpm • Smooth running due to hardened and ground gears running in an oil bath • • Right-left rotation • Prismatic guides in all axes • Gear head can be swiveled 90 ° • Chip protection with safety circuit Machine base optional. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 13,0 mm x-travel: 300 mm y-travel: 130 mm turning speeds: 100 - 2500 U/min throat: 165 mm spindle taper MT: 3 MK table-size: 490 x 120 mm diameter of hob: 30,0 mm motor: 230 Volt total power requirement: 0,75 kW weight of the machine ca.: 50 kg. dimensions of the machine ca.: 520x500x740 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 40 mm throat: 290 mm bore stroke: 130 mm spindle taper: SK 40 spindle turning speed range: 75 - 3200 U/min : 500 mm : 230 mm table surface area: 720 x 210 mm connected load frequency: 400 V diameter of hob: max. 80 mm total power requirement: 1,1 kW weight of the machine ca.: 0,35 t dimensions of the machine ca.: 1,1 x 0,9 x 1,2 m domestic equipments • Digital display • Digital depth gauge for quill • Adjustable guides with wedges • Large 12-speed range from 75 to 3200 rpm • Smooth running due to hardened and ground gears running in an oil bath • • Right-left rotation • Prismatic guides in all axes • Gear head can be swiveled 90 ° • Chip protection with safety circuit Machine base optional. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 32 mm x-travel: 510 mm y-travel: 240 mm table-size: 210 x 730 mm spindle taper MT: 3 mx. distance bet.vert. milling head and table: 450 mm bore depth: 120 mm max. distance between table and spindle-nose: 450 mm spindle turning speed - stepless: 0-2500 U/min transmission ratio: 12R/12L head swivability: 45L / 90R ° : 400 V total power requirement: 0,75 kW weight of the machine ca.: 420 kg dimensions of the machine ca.: 870 x 890 x 1920 mm ?solid column to avoid vibration ?gear wheels in oil bath ?left and right turning ?precision setting for milling depth ?with drawbar (M12) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1170 mm y-travel: 500 mm z-travel: 370 mm table load: 2 t spindle turning speed range: 25 - 2500 U/min feeds: 4 - 2000 mm/min rapid traverse:: 4000 mm/min taper ISO: 40 total power requirement: 12,5 KVA weight of the machine ca.: 4 t dimensions of the machine ca.: 2,3 x 1,9 x 1,75 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
