double mitre used for sale

Pressure:1600 t distance between columns:4100 mm slide stroke:1450 mm Distance table/ram, stroke up:2750 mm distance table/blank holder, stroke up:2200 Table surface area:4000 x 2200 mm ram pressure:1000 t Pressure of blank holder:600 t stroke of blankholder:1000 mm blank holder surface:4050 x 2200 mm Ram surface:3200 x 1650 mm pressure of drawing cushion in table:360 t Die cushion stroke in table:300 mm die cushion area:3500 x 1600 mm Side window:1100 mm Oil volume:9000 l Power capacity:390,0 kW Weight:250,0 t Dimensions (WxDxH):5,95 x 4,3 x 10,5 m Height above floor:8,6 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable

Pressure:800 t distance between columns:3250 mm stroke:1100 mm Distance table/ram, stroke up:1900 mm Table surface area:3100 x 1900 mm pressure of drawing cushion in table:300 t Die cushion stroke in table:300 mm Die cushion area in table:2500 x 1800 mm Die cushion pressure in ram:80 t Die cushion stroke in ram:200 mm Die cushion area in ram:2200 x 1000 mm Ram surface:3100 x 1900 mm Side window:900 mm Oil volume:4700 l Power capacity:200,0 kW Dimensions (WxDxH):4,95 x 3,3 x 10,2 m Height above floor:7,05 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable cutting impact absorption:hydraulic

Pressure:800 t distance between columns:2560 mm stroke:1050 mm Distance table/ram, stroke up:1870 mm Table surface area:2500 x 1730 mm pressure of drawing cushion in table:300 t Die cushion stroke in table:395 mm Die cushion area in table:2300 x 1300 mm Ram surface:2500 x 1730 mm Die cushion pressure in ram:63 t Die cushion stroke in ram:150 mm Side window:1000 mm Oil volume:4300 l Power capacity:200,0 kW Dimensions (WxDxH):4,1 x 2,8 x 10,0 m Height above floor:7,0 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable

Pressure:600 t distance between columns:2600 mm stroke:900 mm Distance table/ram, max. stroke up, adjustment up:1600 mm Table surface area:2500 x 1730 mm pressure of drawing cushion in table:250 t Die cushion stroke in table:400 mm Die cushion area in table:2300 x 1300 mm Die cushion pressure in ram:63 t Die cushion stroke in ram:160 mm Die cushion area in ram:1900 x 1300 mm Ram surface:2500 x 1730 mm Side window:1100 mm Oil volume:3500 l Power capacity:200,0 kW Dimensions (WxDxH):4,1 x 2,8 x 9,6 m Height above floor:6,4 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable cutting impact absorption:hydraulic

Pressure:800 t distance between columns:3550 mm stroke:1100 mm Distance table/ram, max. stroke up, adjustment up:1900 mm Table surface area:3500 x 1800 mm pressure of drawing cushion in table:350 t Die cushion stroke in table:280 mm Die cushion pressure in ram:80 t Die cushion stroke in ram:160 mm Ram surface:3500 x 1800 mm Side window:1900 mm Weight:100,0 t Floor Space (WxD):5,3 x 4,3 m Height above floor:7,3 m Height below floor:5,0 - 6,0 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable cutting impact cushioning:hydraulic sliding table:without rails for moving table

pressure:500 t stroke:fix 300 mm no. of strokes:20 - 70 Hub/min distance between columns:3100 mm side window:1400 mm distance table/ram, max. stroke up, adjustment up:1000 mm Table area:2800 x 1600 mm ram surface:2800 x 1450 mm ram adjustment:100 mm power requirement:90,0 kW weight:100,0 t Dimensions (WxDxH):5,75 x 3,2 x 7,8 m height above floor:6,4 m height beneath floor:1,4 m clutch:pneumatic; Ortlinghaus ram adjustment:motoric overload protection in ram:hydraulic ram counterbalance:pneumatic

pressure:160 t distance between columns:1360 mm stroke:300 mm Distance table/ram, max. stroke up, adjustment up:620 mm table surface area:1300 x 900 mm table height over floor:950 mm side window:640 mm ram surface:1300 x 900 mm power requirement:45,0 kW weight:16,0 t Dimensions (WxDxH):2,5 x 2,1 x 4,1 m cutting impact cushioning:hydraulic

pressure:600 t distance between columns:3640 mm stroke:350 mm no. of strokes:11 - 44 /min Distance table/ram, max. stroke up, adjustment up:1550 mm table surface area:3600 x 2500 mm sliding table:3600 x 2500 mm ram surface:3600 x 2500 mm Side window:2200 mm ram adjustment:400 mm material width coil line:500 - 1950 mm Material thickness at 1200 mm material width:0,6 - 2,5 mm Material thickness at 1850 mm material width:0,6 - 2,0 mm Material thickness at 1950 mm material width:0,6 - 1,75 mm Coil weight:35,0 t coil internal diameter:610 mm coil external diameter:900 - 1900 mm no. of straightening rolls:13 straightening roll diameter:50 mm Stack height:400 mm stacking dimensions - station 1+2 (L x W):150-2000 x 250-2000 mm stations:2 power requirement:112,0 + 35,0 kW Weight:390,0 t Dimensions (WxDxH):7,3 x 5,1 x 15,0 m Height above floor:9,1 m Height below floor:5,9 m clutch-/ brake combinat ...

pressure:315 t distance between columns:1290 mm stroke:700 mm distance table/ram, max. stroke up, adjustment up:950 mm table surface area:1250 x 1100 mm pressure of drawing cushion in table:125 t stroke of drawing cushion in table:300 mm die cushion area:900 x 900 mm Capacity of ejector in ram:20 t Stroke of ejector in ram:250 mm table height over floor:800 mm ram surface:1250 x 1100 mm oil volume:1200 l power requirement:40,0 kW weight:22,0 t dimensions (WxDxH):2,6 x 1,6 x 5,2 m height over floor:4,05 m drawing cushion in table:hydraulic ejector in ram:hydraulic cutting impact cushioning:hydraulic

pressure:315 t distance between columns:2350 mm distance table/ram, max. stroke up, adjustment up:1200 mm distance between cutting impact cushioning:1600 mm Distance table/ram, stroke up:1200 mm stroke:800 mm table surface area:2060 x 1260 mm table height over floor:750 mm Die cushion pressure in table:100 t Die cushion stroke in table:400 mm die cushion area:1250 x 1000 mm side window:780 mm ram surface:2200 x 1500 mm Capacity of ejector in ram:63 t speed down:500 mm/s speed up:310 / 410 mm/s working speed:20 - 73 mm/s quantity of oil:3900 l power requirement:80,0 + 45,0 kW weight:55,0 t Dimensions (WxDxH):4,6 x 2,7 x 7,2 m Height above floor:6,0 m Height below floor:1,2 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 die cushion in table:hydraulic ejector in ram:hydraulic ram interlocking:hydraulic cutting impact absorption:hydraulic

Pressure total: 250 ton Ram stroke: 70 / 250 mm Slide adjustment: 160 mm Ejector in ram: 20 ton Ejector stroke in ram: 10 mm Shut height (stroke down, adjustment up): 520 mm Free lateral opening F-B: 1.300 mm Table surface area : 1.600 x 1.600 mm Slide area: 1.600 x 1.600 mm Number of strokes: 0 - 50 s.p.m. Required power: 33 kW Height over floor approx.: 5.500 mm Weight of machine approx.: 58 ton Roll feeder Material width: 1250 mm Material thickness: 0,3 - 1,6 mm Control: Siemens S7
