double column machining used for sale

IBARMIA double drilling machine model BP-50. Year of manufacture 2005. Serial number 043285. Equipped with two drilling heads for simultaneous operations. Pneumatic workpiece clamping system. Integrated cooling system (coolant). Motor power 4.2 kW. Working speeds 750 / 1500 rpm. Electrical connection 380 V / 50 Hz. Acoustic level 78 dB(A). Machine with CE marking. Ideal configuration for series production and repetitive operations. Robust industrial construction on common base. The dimensions are approximate. Auction-ID: A7-44864-2

Travel X/Y/Z: 2200mm/520mm/510mm, rapid traverse X/Y/Z: 40m/min, number of spindles: 2, speed: 10000rpm, spindle power: 22kW, spindle bearing: 95mm, max. torque: 300Nm, tool holder: HSK A100, max. milling capacity: 500cm³, max. drilling diameter: 50mm, max. thread diameter: M36. Table dimensions X/Y: 2x 1250mm/250mm, spindle table distance min./max.: 250mm/760mm, max. workpiece weight: 2x 1500kg, max. tool length: 320mm, tool positions: 2x 21, tool clamping: 45000N. Dimensions X/Y/Z: approx. 4000mm/6500mm/3800mm, weight: approx. 11000kg, operating hours: 37771h. Including sheet metal technology SHA KMB 900, volume: 900l, and magnetic plate. Documentation available.

CNC Double column Coordinate Boring Machine with Deep Hole Drilling Support Kolb KBN G 120 Year of manufacture 1984 / Retrofitted with Heidenhain TNC 426 in 2006 Table size 4250 x 2200 mm Table load max. 14 t Table longitudinal travel X 3000 mm Main spindle cross travel Y 2180 mm Deep hole drilling support cross travel A - 2000 mm Spindle vertical travel Z 500 mm Distance between the columns 2640 mm; Spindle to table 100 - 1300 mm; Spindle diameter 224 mm Spindle drive motor rating 46 KW Spindle speeds 14 - 1400 rpm Spindle taper ISO 50 Drilling in steel ST60 : 100 mm diameter; Boring to 300 mm; Threading to M 125 x 3; Milling capacity 730 cm³/min.; Second support for Deep Hole Drilling Spindle speeds for BTA and ELB boring 315 - 3150 rpm High pressure cutting oil delivery to spindle Chip- and oil collection and separation via Centrifuge. Very good condition P ...

PRESS FOR PRODUCTION ALUMINIUM TRAYS FOR ALIMENTARY USE COMPLETE WITH DOUBLE IMPRESSION MOULD-1100 CC. COMPOSED OF: A LUBRICATION UNIT 4-COLUMN MOLDING UNIT TOW-SCRAP CONTROL PANEL. 55 STROKES/MINUTE DEPENDING ON THE MOULDS. PASS COLUMNS FOR MOULDS UP TO 800 MM

Double column press with 200 T output, Idle speed 45 mm/sec Opening speed 60 mm/sec Starting press speed 9 mm/sec Table size 2000x600mm Plunger size 2000x600mm OIL temperature monitoring Manual lubrication Free positioning of the plunger ( adjustable via adjustable sensors ) PILZ photoelectric sensors 14.1 mm on front and back Circulatory oil cooling Pressure retaining valve 0 to 600 sec. Mechanical plunger protection at the upper breakpoint T-grooves according to DIN, and according to customer requirements Pressure adjustment from 40 T to 200 T (adjustable via rotary knob) Travel limitation optionally via pressure or position Set-up operation, single stroke ( adjustable via key switch ) Two-hand operation Construction, commissioning, instruction against separate calculation Design Press design double column press Therma ...

Passage width 2500 mm Stroke 900 mm Total power requirement 62 kW Machine weight ca. 27,5 t Dimensions L x W x H approx. 3950 x 2200 x 4850 mm Retraction force 40 t Master cylinder 2 pieces Column diameter 220 mm Installation height 1300 mm Table size 2500 x 1600 mm Ram size 3100 x 16000 mm Table height above floor approx. 900 mm Flow speed 200 mm/sec Return speed 200 mm/sec Working speed 5 - 15 mm/sec Oil tank 1500 l Oil quantity 1200 l Pressure control adjustable from up to 50 - 400 t Thermoforming cushion 1400 x 800 mm Deep-drawing unit capacity 30 - 60 t Deep-drawing cushion stroke 250 mm Deep-drawing cushion speed 5 - 80 mm/sec robust machine body with solid welded construction low-maintenance and reliable Piston rod with induction hardening and chrome cladding T-slots according to customer requirements, if not specified 22mm according to DIN CE Certific ...

300 t , Stand distance 1.800 , with rope passage , Installation height 1.000 , Table 1.800 x 1.000 , Ram 1.800 x 1.000 , Hub 600 , Rapid traverse to + From 414 mm/sec. , ram speed 10 - 50 mm/sec. , retraction force 380 kN , table cushion 800 kN , 90 kW , Weight 43.000 kg , ground-level installation

Here are the technical data of the offered machine: Technical data + information: • No-load speed up to 40 mm/sec • Opening speed up to 40 mm/sec • Starting press speed 5–15 mm/sec • Table size/heating plate size 600 × 600 mm • Plunger size/heating plate size 600 × 600 mm • 2 heating plates, electrically heated, up to 250 degrees – as OPTION • Total size approx. 2000 × 1000 × 2800 mm height • OIL temperature monitoring • Automatic lubrication • Free positioning of the plunger • SICK/LEUTZE light barriers 14.1 mm on the front • Circulating oil cooling • Pressure holding valve 0 to 1800 sec. • Rear monitored door • Pressure adjustment from 30 T to 120 T • Travel limitation either by pressure or position • Programming set-up mode, single stroke (adjustable via rotary switch) • Control panel permanently installed in the wall  ...

Inv. Num. : 6701 Type: 4000 kN Producer: Hydraulico Created: 1977 Parameters: Control system: SIEMENS SIMATIC OP Compressive force: 4000 kN Stroke: 800 mm Table height: 680 mm

Inv. Num. : 6700 Type: 3000 kN Producer: Loire Created: 1992 GO 2008 Parameters: Control system: SIEMENS SIMATIC OP17 Compressive force: 3000 kN Table length: 2495 mm Table width: 1505 mm Maximum distance between the table and the ram (when the ram is low): 1200 mm Stroke: 800 mm Working speed: 64 mm/s

Profile Machining Center Machining length approx. 8,500 mm, max. profile size 300 x 200 mm, Travel XYZ = 9,300 x 1,000 x 800 mm, Sawing unit (mitre cuts), 4-axis drilling/milling unit (16 kW, 18,000 rpm), tool changer 24-fold option pendulum operation, option Clamping element displacement, preparation Flowdrill, , safety enclosure, BECKHOFF control panel (programming software CamQuix), refrigeration unit IDEA 16CCM-50-A-F-3 (No. C2019010009, year of construction 2019), Control cabinet, machine under power in production use Original price 176.500 EUR

Key data: 400 t, 800 mm

Oil-hydraulic double-column press 400 T with sliding table Press type: Double column press Thermally neutral 80 – 120 °C Number of operating pages 1 page Forces Pressing force max. 4000 kN Free tear-off force max. 400 kN Print build-up time Closed tool steel on steel Max. 4 sec. Dimensions: 3,800 mm long and 4,475 mm wide Max. opening width 800mm Stroke 800mm Table height above floor 1100mm Height above ground (height) approx. 4300 mm Hall height min. 5500 mm Parallel deviation at 20°C +/- 0.1 mm Deflection Determined at max. clamping force with 70% occupancy < = 0.2 mm/m Weight Total weight of the press without consumables and table top approx. 28 tons Press table Table size 1500x1500 mm Velocities Quick closing at 100 mm sec. Pressing speed 8 – 3 mm sec. Acoustic pressure Sound pressure level, measured at a height of 1.5m on the control pane ...

pressure:60 t distance between columns:650 mm stroke:220 mm distance table/ram, max. stroke up, adjustment up:410 mm table surface area:600 x 525 mm hole in the table:110 mm table height over floor:900 mm side window:200 mm ram surface:560 x 490 mm power requirement:15,0 kW dimensions (WxDxH):1,9 x 1,3 x 2,7 m foundation pit:not necessary

pressure:250 t distance between columns:1110 mm stroke:250 mm Distance table/ram, max. stroke up, adjustment up:500 mm Table surface area:1100 x 900 mm Table height above floor:950 mm Side window:690 mm Ram surface:1100 x 900 mm Oil volume:730 l Power capacity:56,0 kW Dimensions (WxDxH):2,3 x 1,55 x 3,96 m

pressure:300 t distance between columns:1800 mm stroke:1000 mm Distance table/ram, max. stroke up, adjustment up:1300 mm Table surface area:1600 x 1200 mm Table height above floor:1080 mm Ram surface:1600 x 1200 mm Weight:24,0 t Dimensions (WxDxH):2,8 x 2,1 x 6,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

Pressure total: 140 ton Stroke: 800 mm Daylight: 1.004 mm Free frontal opening L-R: 2.060 mm Table surface area : 2.000 x 520 mm Slide area: 2.040 x 520 mm Working speed: 4 -20 mm / sec Rapid travel: 135 mm / sec Return speed: 120 mm / sec Weight of machine approx.: 14 ton Height over floor approx.: 4.810 mm Oil volume: 700 l

Key data: 30 t

Hydraulic press can be used in a variety of ways as an assembly press, small series press, manual insert press or heating press in double-column presses Design (H-press) A tour of the press is possible at the Ennepetal camp. It is a 2.5-year-old, unused press with no operating hours, which is sold with a full warranty. List price: 45,000 Technical details: Robust machine frame Capacity: 30 tons – at 300 bar Pump ASC: 28.5 liters/min. Engine: 11 kW – 15 hp Oil tank: 600 × 450 × 500 mm – with approx. 100 litres Cylinder piston: Ø 110 mm Cylinder inside: Ø 70 mm Stroke: 500 mm Fast forward: 45 mm/s Return: 55 mm/s Guides: Ø 50 mm Table top: 800 × 550 mm – with T-slots Plunger plate: 700 × 500 mm – with T-slots Total weight: 2000 kg Valves from BoschRexroth Control cabinet technology from renowned manufacturers Press table size 700 × 500 × 7 ...

faceplate diameter: 3100 mm swing diameter: 3600 mm turning height: 3600 mm control: Fagor 8035 table load: 35 t turning speeds: 0,32 - 40 U/min max. ram stroke: 3000 mm table load: 35 t turning speeds: 0,32-40 U/min total power requirement: 70 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 1645 t stroke: 1000 mm dayligth: 3000 mm Control: down speed: 280 mm/sec return speed: 275/346 mm/sec distance between columns: 2520 mm total power requirement: kW weight of the machine ca.: t the machine is in very good condition optional you can buy a shifting table as well The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 200 t stroke: 150 mm table surface area: 850x650 mm ram surface: 730x560 mm weight of the machine ca.: 8 t dimensions of the machine ca.: BxTxH 2000x2500x3600mm m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 25 t distance between columns: 580 mm stroke: 150 mm dayligth: 370 mm table surface area: 560x400 mm ram surface: 400x350 mm hole in the table: 80 mm weight of the machine ca.: 2,5 t dimensions of the machine ca.: 1500x500x2500 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 200 t distance between columns: 500 mm stroke: 150 mm ram surface: 320 mm table surface area: 470x400 mm weight of the machine ca.: 12 t dimensions of the machine ca.: 2000x2000x2700 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 160 t distance between columns: 850 mm stroke: 400 mm ram surface: 800x700 mm : 300 mm pressure of ejector: 20 t table surface area: 800x700 mm total power requirement: kW weight of the machine ca.: 12 t dimensions of the machine ca.: 1800x1800x4200 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 360 t stroke: 60 mm table surface area: 525x430 mm no. of strokes: 60 Hub/min : 40 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Pressure total: 80 - 800 ton Ram stroke: 1600 mm Free frontal opening L-R: 2850 mm Free lateral opening F-B: 1000 mm Daylight: 1900 mm Table surface area : 2800 x 2000 mm Slide area: 2800 x 2000 mm Die cushion capacity in table: 32 - 320 ton Die cushion stroke: 400 mm Die cushion pad area: 2500 x 1700 mm Approach speed: 400 mm / sec Working speed: 5 -42,7 mm / sec Return speed: 420 mm / sec Required power: 246 kW Height over floor approx.: 7785 mm Weight of machine approx.: 100 ton No. of moving bolster: 1 pcs.

Pressure total: 140 ton Stroke: 800 mm Daylight: 1.004 mm Free frontal opening L-R: 2.060 mm Table surface area : 2.000 x 520 mm Slide area: 2.040 x 520 mm Working speed: 4 -20 mm / sec Rapid travel: 135 mm / sec Return speed: 120 mm / sec Weight of machine approx.: 14 ton Height over floor approx.: 4.810 mm Oil volume: 700 l

Pressure total: 1400 ton Stroke: 950 mm Daylight: 2000 mm Table surface area : 3600 x 2500 mm Slide area: 3600 x 2500 mm Die cushion capacity in table: 400 ton Die cushion stroke: 500 mm Die cushion pad area: 3060 x 1860 mm Approach speed: 400 mm / sec Working speed: 40 / 80 mm / sec Return speed: 400 mm / sec Oil volume: 5000 l Required power: 450 kW Weight of machine approx.: 240 ton

Pressure total: 500 ton Stroke: 1100 mm Daylight: 1500 mm Table surface area : 2000 x 1250 mm Slide area: 2000 x 1250 mm Die cushion capacity in table: 160 ton Die cushion stroke: 300 mm Approach speed: 650 mm / sec Required power: 55 kW Weight of machine approx.: 50 ton

Double Column - Hydraulic Press RASTER ZEULENRODA (WALTER) Type WUP S 60Masch. No. 136 / 7 (156-165) Year of manufacture 1999Basic machine from 1987, in 1999 Overhauled with new controlPressure capacity 60 ton. Stand width 1090 mmStand passage laterally 265 mm (one-sided) Plunger area 650 x 300 mmAdditional plate on ram 990 x 550 x 60 mmTable area 990 x 550 mmPlunger stroke max. 320 mmInstallation height 330 or 390 mmTable height above floor 980 mmHydraulics Operating pressure 320 barRapid traverse downward 75

pressure: 63 t distance between columns: 650 mm stroke: 200 mm total power requirement: 30 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Pressure total: 315 ton Stroke: 1100 mm Daylight: 2200 mm Table surface area : 2500 x 1000 mm Slide area: 2500 x 1000 mm Die weight at the ram max.: 6000 kg Approach speed: 600 mm / sec Working speed: 32 - 230 mm / sec Return speed: 600 mm / sec Required power: 158 kW Weight of machine approx.: 44 ton Height over floor approx.: 6175 mm

pressure: 3 t throat: 0 mm stroke: 200 mm total power requirement: 15 kW weight of the machine ca.: 4 t dimensions of the machine ca.: m Fully Automatically Straightening Press, 3 Stations,parts turning, (bolts) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 160 t no. of strokes: 40 - 120 Hub/min sheet width: mm total power requirement: 40 kW Pressing capacity 160 ton Table clamping area 1,100 x 1,280 mm Ram clamping area 850 x 890 mm Distance between guides 1,120 mm Distance between columns (below guide ways) 1,350 mm Distance between Table and ram in upper position approx. 400 mm No. of strokes 40 - 120 /min Adjustment of stoke 67 / 115 / 160 mm Ram adjustment, motor driven 125 mm Ejector travel 50 mm Total electrical load, approx. 40 kW - 500 V - 50 Hz Weight, approx. 24,000 kg Accessories / Special Features WEINGARTEN Sheet Metal Uncoiler with overhead loop control (space saving because it does not need a loop-pit). Strip width 375 mm. The loop control guides the strip-material from the uncoiler to the machine thru a straightening device with automatic supervision. 8-track slide bearing guide. Automatic oil-circulation lubr ...

pressure: 10 t distance between columns: 500 mm stroke: 200 mm total power requirement: 10 kW weight of the machine ca.: 4.500 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 125 t distance between columns: 1050 mm stroke: 250 mm total power requirement: 40 kW weight of the machine ca.: 8,5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 2800 mm swing diameter: 3200 mm turning height: 1500 mm slide adjustment: 1200 mm turning speeds: 50 U/min Control: Sienens 840 D side head - cross travel: 900 mm power capacity: 55 kW : workpiece weight: 16 t total power requirement: kW weight of the machine ca.: 50 t dimensions of the machine ca.: m The engine was rebuilt in 2008/2009 to CNC control Siemens 840 D. The right support is operated CNC and the face plate. The left side of the support and assistance are conventional. Acu Rite Digital Display The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling  ...

pressure: 500 t column daylight: 2600 mm stroke: 800 mm table surface area: 6000 x 3000 mm : max. 800 mm adjustment of press crosshead: 5200 mm slide adjustment -horizontal: 1800 mm Capacity: 162 l/min feed down: 9 mm/sec feed up: 14 mm/sec total power requirement: 45 kW weight of the machine ca.: 50 t - Hydraulics : Rexroth - Controls : Tailor - Cylinder chromed - Operation via remote control & joystick - Stroke length adjustable via sensors - Pressure adjustable via PLC The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Pressure total: 400 ton Ram stroke: 500 mm Slide adjustment: 350 mm Daylight: 1250 mm Table surface area : 2500 x 1500 mm Slide area: 2500 x 1500 mm Number of strokes: 15 - 30 s.p.m. Die weight at the ram max.: 4000 kg Required power: 70 kW Height over floor approx.: 8000 mm Weight of machine approx.: 150 ton

Pressure total: 400 ton Ram stroke: 500 mm Slide adjustment: 350 mm Daylight: 1250 mm Table surface area : 2500 x 1500 mm Slide area: 2500 x 1500 mm Die cushion capacity in table: 80 ton Die cushion stroke: 250 mm Number of strokes: 15 - 30 s.p.m. Die weight at the ram max.: 4000 kg Required power: 70 kW Height over floor approx.: 8000 mm Weight of machine approx.: 150 ton

Key data: 300 t, 800 mm

Hydraulic Press Emanuel 300 ton Year of construction: 1989 Dimension table: 1600 x 1300 mm Light max: 1130 mm Light min: 350 mm Slide stroke: 800 mm Cushion stroke: 400 mm Side upright clearance: 640 mm

Key data: 800 t, 1350 mm

Hydraulic Press Gigant 800 ton Year of construction: 1997 Dimension table: 3200 x 2200 mm Light max: 1800 mm Light min: 450 mm Slide stroke: 1350 mm Cushion stroke: 510 mm Side upright clearance: no

Key data: 1200 t, 1000 mm

Hydraulic Press Gigant 1200 ton Year of construction: 1993 Dimension table: 3700 x 2700 mm Dimension lower table: 3700 x 2700 mm removable Light max: 1590 mm Light min: 610 mm Slide stroke: 1000 mm Cushion stroke: 400 mm Side upright clearance: no

Offer 25461 Technical data: - Max. pressing force 30 t - Press pressure regulation - Stroke infinitely adjustable up to 200 mm - Lifting speed adjustable - Max. installation height 450 mm - Machine table with T slots W 800 x D 500 mm - Penetration between the columns 600 mm - Usable table surface W 800 x D 500 mm - Drive 400 V / 11 kW - Space requirement approx. W 1000 x H 2300 x D 1600 mm - Weight approx. 2500 kg
