dosing mixing used for sale

General SKU051G200 LocationBarneveld MakeWerkhuizen Schepens N.V. Dendermonde TypeMixing drum No.70-776-397 Main Features MaterialStainless steel Motor11 KW Inlet diameter1200 mm Specified Features - Miscellaneous mixer MaterialStainless steel 1.4306 (304L) Miscellaneous mixers Coating installationContinuous drum coater (1x) Pan diameter1200mm Cylindrical width6000mm, Adjustable inclination In-/OutletInlet 340x340mm, Outlet 400x600mm Motor11,0 KW, 380-415/660-720 Volt With spraying arm(nozzles are missing) Information Year of construction1998 Mounted on framecheck With switchgearcheck Floorspace9,0x2,6 M Total height2,1 M Weight8500 KG Extra SpecificationsMixing drum non perforatedButterfly mixersDiscountSchepensMixers > Miscellaneous mixers > Butterfly mixersDiscountBrand > Schepens What you can expect from Foeth: -- Machine is in working condition -- At a red ...

Small dosing accumulator with screw conveyor for cable recycling plants, wood chips, etc. Capacity approx. 650 litres or 400 - 500 kg of pre-shredded old cable Adjustable conveying speed with frequency converter/inverter 0 - 16 rpm Drive only 0.55 kW with reduction gear Discharge height approx. 750 mm Dimensions (LxWxH): 2,200 mm x 800 mm x 1,800 mm Mobile via large heavy-duty castors with brakes

Dosing container 10.5m³ capacity Steel grade S355 Overall channel low-stress annealed 10mm Hardox 450 wear protection in the gutter bottom 2 x Unbalance Motors Various hood options, possibly with extraction connections Electrically driven slide for dosing For material eg: copper and plastic according to photo, but with drive and painted Other options: 3-Sided Wrap Guard 400mm Hood according to drawing Control box for stand-alone operation, with FU without Hardox wear protection Channel without container, frame, etc., incl. drives Reserve drive

Dosing bunker incl. dosing roller Manufacturer: BOA / HUBER Type: 1500 H KTH 5700/ RH Year of Make: 2010 Technical data for the feed hopper (chain belt conveyor): Manufacturer: BOA Type 1500 H KTH 5700 Year of construction 2010 Length of feed belt 5700 mm Incline 0° Usable width 1400 mm Technical data of the dosing drum: Manufacturer: Huber Technik Fördersysteme Type RH Dosing Drum Year of construction 2010 Drive power 4 kW

Electronic water dosing device with temperature display Your advantages: fast and exact input of the water quantity Clear control panel with large, bright display compact and flour dust-proof stainless steel housing easy connection to an ice water system with Automatic Wiedehol Technical data Dosing volume range: 0.1 l - 999.9 l Temperature accuracy: display only Dosing accuracy from 1 l: +/- 0.1 l Water flow at 3 bar: up to 30 ltr./min Water connection: 3/4" external thread Power connection: 100 - 240V ; 50hz Dimensions W x H x D: 200 x 300 x 130 mm Visit our Milbrandt Outlet with many bakery machines and appliances!

- 5 aluminium silos with attachment filter incl. discharge screw with slide made of V2A - 4 aluminium silos for manual filling with discharge screws - 3 dosing scales - Optional with dust filter

Water mixing / dosing device Werner &, Pfleiderer WMD 152 Product description Manufacturer: Werner &, Pfleiderer Type: WMD 152 Condition: used, functional, bakery condition for water quantity and temperature control unit Current type: 1/N / 50 Hz Nominal voltage: 230 V Nominal operating current: 0.5 A Details see pictures

Cat. No. 13-0033 in a very good condition Typ: RF32DT71D4 Testing water by 22°C back pressure at 1 bar Pressure: 0,3 bar capacity: 5.100 litres/h Motor: 0,37 kW Connection: DN 40 - can be changed on request for an additional charge Measurements: with frame: pump: length: 33 cm 45 cm width: 20 cm 23 cm height: 84 cm 50 cm weight: 56 kg For more Information please contact us under: Phone +49(0)9353-909050 Fax: 09353-9090522, Mobile: 0171-6518248 Subject to prior sale. All prices are valid Ex-Works, excl.VAT. Freight Charges: depending on dimensions and destination.

Dosing station for lye Stabicip 0 X 1 380 V, 50 Hz; 6 bar 2 Piece Unit price 450,-both for 800,-

Dosing station for lye Stabicip 0 X 1 380 V, 50 Hz; 6 bar

Piston pump with drive 0.25 kW / 1.325 RPM, stroke length: 1 - 15 mm, stroke frequency: up to 110 rpm.

Type: ZSA 1500 Working width: 1500 mm Flight circle metering drum: Ø 1600 mm Motor power: 18,5 kW Length metering device: 7800 mm Width metering device: 1600 mm Volume metering device: approx. 25 m ³

dosing pump BRAN LUEBBE for premix performance 40,000 lt/h

Electro-mechanical scale for liquids, with Hottinger load cell, pressure control valve, pneumatic outlet valve and solenoid valve. In support frame with feet.

Dosing scale with precision spiral screw feeder in stainless steel version, with pre-container and weighing frame in frame, trough dimensions: 540 mm long x 370 mm wide x 320 mm high, with large loosening spiral in the trough, drive 0.47 kW via timing belt and Reduction gearbox, discharge pipe diameter: 50 mm.

Specifications: Dosiebunker DB 3000 Dimensions: 1.50 x 2.50 x 2.75 (L x W x H) Can be used in cable recycling for granulator filling, granulate processing, plastic films, wood chips, etc. Features -Content: 3 qbm -Ruehrwerk, drive: 5.5 KW -Fuellstand control sight glass -Adjustable machine feet -Dosing screw discharge 200 mm diameter, speed control of the screw via frequency control at the control cabinet via Poti, Drop height 700 mm, screw drive power: 0.75 KW Optional with conveyor belt for filling Dosing Bunker DB 3000 Dimensions: 1.50 x 2.50 x 2.75 (L x W x H) For Cable Recycling by the Cutting Mill filling, PVC Granulate, PP or PPE, and many more Amenities -3 qbm -Agitator, Drive: 5.5 KW -liquid level indicator -adjustable machin feed -metering device for the spiral conveyer, Diametre: 200 mm, speed control for the spiral conveyer by Frequen ...

Dosing pumps Elados EMP 12500P06 (2 stub) Elados EMP 13300P035 (1 piece) Elados EMP 14000P035 (1 piece)

see pdf attached

see pdf attached

Carbon black weighing scale 400l Description attached!

Piston metering pump, A 125N-38/116-19 DI Doseuro, used - overhauled Special price We still have several identical and other such devices, but the amount is ending. Buy more than 1 piece, there is still a great discount. If you have a VAT number, we will gladly issue you an invoice without VAT. Used and overhauled! The part was bought from a spare parts store of a company, was overhauled by a specialised company and is in a very good condition and fully functional. Technical data: - Manufacturer: Matricola / Doseuro - 1.660L/h, 100l/h, 9 bar, 0,18KW, - Material pump: stainless steel - 35 x 18 x 38cm high, 9kg, Function guarantee! For second hand parts, we can not accept any conventional guarantee and warranty. But we give you a functional guarantee. If the device does not work within 3 months after purchase you can return the goods and we will refund the purchase pr ...

Dosing with Endress and Hauser mass flow meter consisting of a cabinet (with Siemens plc and touch panel for dosage control and pneumatic valve Island) and two Endress and Hauser mass flow meters. Documentation including user's manual available

Epson G10-854SR Robot Screwdriving Station Dosing Station Assembly of parts for car radios and navigation systems and for testing them. The assembly station is designed as a closed aluminium frame with a steel welding frame inserted and has a very compact design. The control cabinets and valve terminals are integrated into the system. All movement processes during the operation of the system can be tracked on all sides through large windows and doors. Operation is via a touch screen. The assembly station is divided into substations 3.1 dosing area, 3.2 assembly area KK+SW and 3.3 mounting area front. (KK=heat sink, SW=bulkhead angle) The work steps according to these assembly areas are described below: St.3.1: Dosing range - a WT with attached chassis and printed circuit boards enters the dosing area via the transfer belt. - this is stopped at the stroke positioning ...

Description BINDER dosing machine is designed for dosing of liquid and pasty products to finished bags. Dosing machine automatically opens and fills the bag. Specification: Brand: BINDER Model: 871/1 Type: Filling Machine Size: 2200 x 1600 x 1300 (mm) Power supply: 400V 50 Hz 3N Power: 4kW Tank capacity: 75 l Tank pressure: 4 bar Max. temperature: 120 ° C Control: SIEMENS Control Panel Material: stainless steel/steel

Laboratory foam dosing station with foam mixer and applicator The system works in a similar way to the SUPRA MIX concept. Several chemicals are dosed and mixed with water and air in a controlled ratio. Recipes are stored on the controller and can be changed on the fly. Foam applicator with mixer • Dynamic foam mixer with online dosing of 5 products + water • 5 dosing pumps • A direct inlet for the mixture • Product monitoring for chemicals • Air dosing valve • Dynamic foam mixer with adjustable speed • PLC control • Foam applicator • For one-piece carpets up to 1 m wide Uses Stain Blocker Dirt, water and oil repellents Fluorocarbons Anti-Static Chemicals Plasticizer Flame retardant Antibacterial chemicals Moth and beetle repellents Pile stabilizers Anti-hair loss agent Resins for wrinkle prevention and dimensional stability Specificat ...

For sale is a workshop-overhauled and function-tested, free-standing VA diatomaceous earth dosing device. The device is immediately ready for use. Specifications: Manufacturer: Schenk Year of manufacture: unknown Type: DO-S-250 Boiler capacity: approx. 250 l (with lid almost 1/2 hinged with hinge) Hourly output for KG filtration: 200 hl for beer, wine and fruit juice Dimensions total: L max. = 1.20 m / W max = 0.80 m / H max. = 1.685 m Beer pipe: Input/outlet DN 50 KM/G - Dosing connection in the beer pipe DN 25 KM Connections in the boiler: 1 inlet at the top side DN 50 G with 90-degree bend (inside) downwards 1 remaining outlet DN 50 G with shaft closure and handle from above 1 connection DN 32 KM above 1 DN 50 KM connection at the bottom side with a 90 degree bend upwards - then reduced from DN 50 to DN 10 G Boiler dimensions: Diam. inside = 0.65 m ...

SAIP SE 15 polyurethane foam dispensing machine was built in 2015 in Italy by SAIP Equipment. The machine is used in the dispensing of all kinds of polyurethane foams in environmentally friendly conditions. The combination of high capacity (up to 15 kg/min) and the ability to adjust the mixing ratio of the components from 1:1 to 5:1 means that the machine can easily meet any production requirement. The SAIP polyurethane foam mixing machine is also incredibly easy to operate. Operating parameters can be entered and controlled from the reliable touchscreen control system. The PUR dispensing machine is fully complete and consists of the following components: – control panel – low-pressure mixing head – mixing head support beam – isocyanate and polyol storage and conditioning unit – isocyanate and polyol metering unit – mixing head solvent washing system Technical spe ...

Installation 2020 Plant shut down after 6 months and short test runs Original price 166.000,00 € Dosing and screening station Products - Product Name: Spices - Bulk density: approx. 0.4 - 0.7 kg/itr (AZO assumption) System characteristics Electrical characteristics Operating voltage: 230/400 V; 50 Hz. Control voltage: 24 VDC Degree of protection: IP 54 Compressed air characteristics Operating pressure: min. 5 bar /max. 6 bar Connections > 1/2" Compressed air quality class according to ISO 8573-1 Solid impurities: quality class 1 Humidity - at ambient temperature > 3°C: quality class 2/3 - at ambient temperature 10 mJ - KST value < 200 bar m/s - ignition temperature > 300 °C - Smoldering temperature > 275 °C - Contact Resistivity > 10° Ohmm

Dosing robot mta TR 300 BJ 2010

Pieces of dough: 10-300 gr. Power: 10-60 pieces/ min digital control Stainless steel cladding rollable on rolls

Gravimetry ConPro for Processing of up to 4 components Total capacity: approx. 300 kg/h GraviCon Type PP45-400/l – Basic Version Control terminal with 5'' colour screen (touch screen) Desk housing with stand Dimensions: H 430 mm x D 235 mm x W 245/340 mm 2 x hopper scale I-KTW F36 for components 1 + 2 Throughput: up to 250 kg/h (especially for fibrous materials and poorly free-flowing materials) Base frame Hopper without viewing window Load cell holder with platform load cell 2 x hopper scale I-KTW P3 for components 3 + 4 Throughput: up to 70 kg/h (for paint or aditive in powder form) Base frame Hopper without viewing window Load cell holder with platform load cell 2 x dosing unit type CP22 for components 3 + 4 with 1 set of screws and barrels each – version: 10/18 (min. 1 to max. 20 kg/h) incl. 2 x spec. Neckpiece incl. 2 x storage container type: VB1 ...

Many thanks for your interest on our second hand machines, please find follow our offer: manufacturer : Collmann Type : 2x Hydo 24 chocolate depositor 1x hydraulic unit included YOM : 2001 Output : up to 25 cycle/min We offer this machine in as-is where it is condition, without warranty, ex warehouse/location (Incoterms EXW), without packaging ex warehouse Hess. Lichtenau (EXW),unpacked

Glue dosing station MAYER AND MAYER DXR R2020R L-P-PUB PDX20 40-100 P manufactured in 2015 in Germany by MAYER & MAYER HANDELS GMBH. The station was in use for about 3 months in the process. After this time, it was shut down, cleaned and properly secured. All gaskets in the station were replaced with new ones. It is a charging station for manual dispensing / application guns for two-component adhesives. The gun is included for free. Spare parts are offered for the station. Price of the parts to be individually agreed.
