dmg 300 used for sale

X : 1035 mm Y : 560 mm Z : 510 mm Control : Siemens 840 d Number of working hours : 4000 Chip conveyor

X : 750 mm Y : 600 mm Z : 520 mm 12000 rpm Control unit : Heidenhain Renishow tool and part measuring Coolant through spindle Axis measurement scales Number of spindle hours : 9400 Machine is in excellent condition

DMG Deckel Maho HSC 20 Linear 5 axis machining center Machine has been recently serviced Machine is in very good condition

X : 1050 mm Y : 530 mm Z : 510 mm Machine is in excellent condition

DMG Mori CMX 70 U 5 axis Machining Center Machine has been installed December 2019! Multimaster spindle

DMG Mori Milltap 700 Vertical Machining Center 700x420x380 10.000 rpm Siemens 840d Sl kontrol unit Preperation of 4th axis

Maximum machining diameter : 20 mm Maximum spindle speed : 10.000 rpm Fanuc control unit Iemka bar feeder 8+2 axis

DMG CTX 310 eco CNC Lathe with C axes Working hours: 50110-24500 Control Unit : SIEMENS Model 810D z ShopTurn Chip conveyor Live tools are included Hydraulic chuck All maintenance has been done DMG All documents are available

DMG lasertec 40 is a three-axis laser engraving machine intended for micro-engraving. Above all, it is intended for the production of demanding stamps and logos on 3D shapes of workpieces.

Tool changerType of gripperDouble gripper Tool changer planevertical Number of tools90 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmWorking area 1Longitudinal735 mmCross650 mmVertical560 mmTechnical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minGeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Floor space/WeightWeight approx.12400 KgNC swivel rotary table integrated in rigid tableType of Measuring system Direct measuring systemTable surface 800 x 650 (Ø 650) mmRotation Speed 5. Axis 20 rpm5. Axes (swivelling range) +120/-120 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between T-Slots 63 mmNumber of Slots 9Slot wi ...

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool diameter with occupied adjacent pockets80 mmMax. tool length315 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.12600 KgNC swivel rotary table integrated in rigid tableType of Measuring system Direct measuring systemTable surface 800 x 650 (Ø 650) mmRotation Speed 5. Axis 20 rpm5. Axes (swivelling range) +120/-120 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between T-Slots 63 mmNumber of Slots 9Slot width 1 ...

GeneralUniversal Machining Centre in monoBLOCK construction - MPC Machine Protection Control; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal750 mmCross650 mmVertical560 mmTechnical DataDrive power (100% DC)25 kWDrive power (40% DC)35 kWTorque (100% DC)86 NmTorque (40% DC)130 NmSpeed range- 20000 rpmSpindle taperHSK-A 63 Feed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minTool changerType of gripperDouble gripper Tool changer planevertical Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmMiscellaneousClamping SystemHSK-A 63 Floor space/WeightWeight approx.12300 KgNC swivel rotary tableTable surface 800 x 650 (Ø 650) mmCentre bore 50h6 mmMaximum load (table centre) 600 KgSlot width 14 mmDirect mea ...

Generalin travelling column construction NEW DMG MORI Design swivel head (B-axis) speed range 20 up to 10,000 rpm motor spindle with 52/42 kW (40/100%DC) tool taper HSK-A100 DIN 69893 tool clamping according to DIN 69872; Control: CELOS with Siemens 840D sl Operate Working area 1Cross1100 mmLongitudinal2600 mmVertical900 mmTechnical DataFeed rate longitudinal/transverse/vertical80000/80000/80000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight12 KgMax. tool length500 mmMax. tool diameter with occupied adjacent pockets115 mmMax. tool dia. with free neighbouring pockets160 mmDirect measuring systemDirect path measuring systemCabineFull protection cabinDynamic package for DMF 260 linear (Y1100)Dynamic package for DMF 260 linear (Y1,100 mm) linear drive X-axis with 80 m/min // ...

Generalin travelling column construction NEW DMG MORI Design swivel head (B-axis) tool clamping according to DIN 69872; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal2600 mmCross1100 mmVertical900 mmTechnical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical80/60/60 m/minTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight15 KgMax. tool length500 mmMax. tool diameter with occupied adjacent pockets115 mmMax. tool dia. with free neighbouring pockets160 mmDirect measuring systemDirect path measuring systemCabineFull protection cabinDynamic package for DMF 260 linear (Y1100)Dynamic package for DMF 260 linear (Y1,100 mm) linear drive X-axis with 80 m/min // 262.48 ft/min rapid move XYZ 80/60/60 m/min // 262.48/196.86 ft/min, Acceleration XYZ 5/6/6 m/s² //  ...

Generalin travelling column construction NEW DMG MORI Design swivel head (B-axis) tool clamping according to DIN 69872; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal2600 mmCross1100 mmVertical900 mmTechnical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical80/60/60 m/minTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight15 KgMax. tool length500 mmMax. tool diameter with occupied adjacent pockets115 mmMax. tool dia. with free neighbouring pockets160 mmDirect measuring systemDirect path measuring systemCabineFull protection cabinDynamic package for DMF 260 linear (Y1100)Dynamic package for DMF 260 linear (Y1,100 mm) linear drive X-axis with 80 m/min // 262.48 ft/min rapid move XYZ 80/60/60 m/min // 262.48/196.86 ft/min, Acceleration XYZ 5/6/6 m/s² // 16.4/ ...

GeneralUniversal machining centre New DMG MORI Design; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal400 mmCross400 mmVertical375 mmTechnical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmFloor space/WeightWeight approx.6800 KgDimensions (L x W x H)6,21 x 6,58 x 2,69 (6,21 x 7,38 x 2,69) mSpindle speed 28.000 rpm HSK-A63Spindle speed 20 up to 28.000 U/min Motor spindle with shaft cooling power 30/20 kW // 40.23hp/ 26.82 hp (40/100% DC) torque 40/27 Nm (40/100% DC) tool clamping HSK 63 according to DIN69893 (different from standard)Chain-type tool magazine 60 po ...

GeneralHorizontal machining center; Control: Control M730BM CharacteristicsSpeed max.15000 rpmDimensions (L x W x H)2,72 x 4,22 x 2,52 mSpindle taperBT 40 Tool Magazine with40 PositionsRapid feed X / Y / Z60/6060 m/minMovement X / Y / Z560/560/660 mmPalett changer with2 PalletMaximum load (table centre)400 KgSwivelling range360 x 0,001 degreeTable size400x400 mmDrive power (100% DC)18,5 kWWeight approx.7600 Kg(For Europe) European Edition(For Europe) European Edition (NHC4000) Full 4th axis rotary table Interface for Through-spindle coolant system (7.0 MPa, Variable Pressure Steps) (KNOLL) Coolant gun for setup station side In-machine measuring system (spindle) optical signalInterface for Through-spindle Coolant System (7.0 MPa, Variable Pressure Steps) (KNOLL/ Interlit)Interface for Through-spindle Coolant System (7.0 MPa, Variable Pressure Steps) (KNOLL/ Interlit) Interface for mountin ...

GeneralHorizontal machining center; Control: Control M730BM CharacteristicsSpeed max.15000 rpmDimensions (L x W x H)2,72 x 4,22 x 2,52 mSpindle taperBT 40 Tool Magazine with40 PositionsRapid feed X / Y / Z60/6060 m/minPalett changer with2 PalletMovement X / Y / Z560/560/660 mmMaximum load (table centre)400 KgSwivelling range360 x 0,001 degreeTable size400x400 mmDrive power (100% DC)18,5 kWWeight approx.7600 Kg(For Europe) European Edition(For Europe) European Edition (NHC4000) Full 4th axis rotary table Interface for Through-spindle coolant system (7.0 MPa, Variable Pressure Steps) (KNOLL) Coolant gun for setup station side In-machine measuring system (spindle) optical signalInterface for Through-spindle Coolant System (7.0 MPa, Variable Pressure Steps) (KNOLL/ Interlit)Interface for Through-spindle Coolant System (7.0 MPa, Variable Pressure Steps) (KNOLL/ Interlit) Interface for mountin ...

GeneralHorizontal machining center; Control: Control M730BM CharacteristicsSpeed max.15000 rpmDimensions (L x W x H)3,1 x 4,86 x 2,84 mSpindle taperBT 40 Tool Magazine with40 PositionsRapid feed X / Y / Z60/6060 m/minMovement X / Y / Z730/730/880 mmPalett changer with2 PalletMaximum load (table centre)500 KgSwivelling range360 x 0,001 degreeTable size500x500 mmDrive power (100% DC)18,5 kWWeight approx.11100 Kg(For Europe) European(For Europe) European Edition (NHC5000) Full 4th axis rotary table Interface for Through-spindle coolant system (7.0 MPa, Variable Pressure Steps) (KNOLL) Coolant gun for setup station side In-machine measuring system (spindle) optical signal transmissioInterface for Through-spindle Coolant System (7.0 MPa, Variable Pressure Steps) (KNOLL/ Interlit)Interface for Through-spindle Coolant System (7.0 MPa, Variable Pressure Steps) (KNOLL/ Interlit) Interface for mou ...

GeneralHorizontal 5-axis universal machining centre; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal850 mmCross900 mmVertical1150 mmCabineFull protection cabinMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Taper cleaning brushesTaper cleaning unit with rotating brushes for spindle taper HSKNC swivel rotary table DirectDrive CNC swivel rotary table direct drive C-axis with pallet carrier Permissible load: 800 kg / 1,760 lbs C-axis: 80 min-1 direct drive A-axis: 15 min-1 single drive Rotation C axis: endlessly turning Swivel range A axis: +120°/-120° (replacement of base machKi ...

GeneralTurning Center; Control: Control M730UM CharacteristicsMax machining diameter366 mmDimensions (L x W x H)3,84 x 2,36 x 1,80 mDrive power tool spindle7,5/5,3/3,7 kWDrive power main spindle22/11 kWRapid feed X / Z30/30 m/minInput precision of C-axis on Mainspindle0,001 degreeMovements X / Z250/1143 mmRotary tool spindle speed6000 rpmNumber of tool stations12 Speed max.4500 rpmBar diameter max.65 mmSpindle bore73 mmSwing- Ø, max.760 mmMax. Turning Length1085 mmWeight approx.6500 KgSLIMlineSLIMline DMG MORI operating system equipped with MAPPS. The large 15-inch display can reduce the number of switching of the screen as it provides the four-way split screen and allows user to see more information at once. It is also possible to customi(Spindle 1) 22/15/11 kW,4,500 min-1 (Standard)(Spindle 1) Standard Spindle 22/15/11 kW (30/20/15 HP), 4,500 min-1 The ALX2000 adopts a highly reliable ...

GeneralMilling Specification; Control: Control M730UM with CELOS CharacteristicsMax machining diameter278 mmDimensions (L x W x H)2,82 x 2,09 x 2,15 mDrive power tool spindle5,5/5,5/3,7 kWDrive power main spindle11/15/15 kWRapid feed X / Z30/30 m/minInput precision of C-axis on Mainspindle0,001 degreeMovements X / Z260/590 mmRotary tool spindle speed10000 rpmNumber of tool stations12 Speed max.6000 rpmBar diameter max.52 mmSwing- Ø, max.755 mmMax. Turning Length192 mmWeight approx.4900 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and pHigh-output spindle (Left Spindle) 15/ 11 kW, 6,000 min-1(Left Spindle) High-Output Spindle 15/11 kW (20/15 HP), 6,000 min-1 The NLX ...

GeneralCNC Turning Centre with C axis and tool drive; Control: Control M730UM with CELOS CharacteristicsMax machining diameter356 mmDimensions (L x W x H)2,82 x 2,09 x 2,15 mDrive power tool spindle5,5/5,5/3,7 kWDrive power main spindle15/22/22 kWRapid feed X / Z30/30 m/minInput precision of C-axis on Mainspindle0,001 degreeMovements X / Z260/590 mmRotary tool spindle speed10000 rpmNumber of tool stations12 Speed max.-5000 rpmBar diameter max.65 mmSwing- Ø, max.755 mmMax. Turning Length510 mmWeight approx.5000 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and pHigh-output spindle (spindle 1) 22/ 15 kW, 5,000 min-1The NLX 2000 adopts a highly reliable main spindle de ...

GeneralCNC Turning Centre with C axis and tool drive; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways700 mmTurning diameter410 mmTransverse stroke300 mmLongitudinal stroke850 mmMax. Turning Length800 mmClamping chuck diameter max.315 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)33 kWC-Axis Speed-200 rpmSpeed range20 - 4000 rpmTorque (100% DC)580 NmTorque of C-Axis (holding torque)225 NmAccuracy at point stopping0,01 degreeTool holder 1Shank diametre according to DIN 6988040 mmNumber of tool stations12 Number of driven tools12 Speed max.-4000 rpmPower max. (40% DC)11,3 kWFloor space/WeightWeight approx.6500 KgDimensions (L x W x H)3,99 x 2,69 x 1,99 mTechnologie cycle alternating speedTechnology cycle for the  ...

GeneralUniversal Machining Centre in monoBLOCK construction - MPC Machine Protection Control - Chip trough; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal750 mmCross650 mmVertical560 mmTechnical DataDrive power (100% DC)25 kWDrive power (40% DC)35 kWTorque (100% DC)86 NmTorque (40% DC)130 NmSpeed range- 20000 rpmSpindle taperHSK-A 63 Clamping SystemHSK-A 63 Feed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minTool changerTool changer planevertical Type of gripperDouble gripper Number of tools120 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.12300 KgMiscellaneousClamping SystemDIN 69872 NC swivel rotary tableTable surface Ø 650 mm5. Axes (swivelling range) +/- 120 degree4. Axes (swivel ...

GeneralUniversal Machining Centre Vertical headstock Tool change system double gripper NC-Swivel rotary table with pallet carrier 3 pallets 500 mm x 500 mm / 19.7 in x 19.7 in T-slots according to DIN 55201-A2 linear pallet changer coolant tank 500 l / 132 gallon chip conveyor with netting band filter integrated, coolant ring jet; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmFloor space/WeightWeight approx.18300 KgDirect measuring systemDirect path measuring systemCabineFull protection cabinNC swivel rotary table with pallet carrierTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 500 KgMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000  ...

GeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Working area 1Longitudinal700 mmCross420 mmVertical380 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMain driveDrive power (100% DC) 6 kWDrive power (40% DC) 8,5 kWTorque (100% DC) 41 NmSpindle taper BT 30Speed range 20 - 15000 rpmTorque (40% DC) 48 NmClamping System ISO 7388-3 - JD30ToolchangertoolchangerType of magazine DiskNumber of tools 25Integrated swivel rotary table simultaneousIntegated swivel rotary table 5-Axis simultaneous mode! Torque drives incl. direct measuring in A- and C-Axis Swivel range A-Axis -120 / + 100 degrees Max. load C-axis 100kg Table diameter C-Axis d290mm Rotary joint, 4-channels Inclusive Software packageProduction package band filter ICS 40ba ...

GeneralCNC Turning Centre with C axis and tool drive; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways700 mmTurning diameter410 mmTransverse stroke300 mmLongitudinal stroke850 mmMax. Turning Length800 mmClamping chuck diameter max.315 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)33 kWSpeed range20 - 4000 rpmC-Axis Speed-200 rpmTorque (100% DC)580 NmTorque of C-Axis (holding torque)225 NmAccuracy at point stopping0,01 degreeTool holder 1Number of driven tools12 Shank diametre according to DIN 6988040 mmSpeed max.-4000 rpmNumber of tool stations12 Power max. (40% DC)11,3 kWFloor space/WeightWeight approx.6500 KgDimensions (L x W x H)3,99 x 2,69 x 1,99 mTechnologie cycle alternating speedTechnology cycle for the  ...

GeneralCNC Turning Centre with C axis and tool drive; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways700 mmTransverse stroke300 mmTurning diameter410 mmMax. Turning Length800 mmLongitudinal stroke850 mmClamping chuck diameter max.315 mmBar diameter max.65 mmMain drive 1Drive power (100% DC)25 kWSpeed range25 - 5000 rpmTorque (100% DC)280 NmC-Axis Speed-200 rpmTorque of C-Axis (holding torque)225 NmAccuracy at point stopping0,01 degreeWork spindle (left)Diametre of spindle nose170h5 mmSpindle noseFlat flange Spindle bore87 mmSpindle diametre on front bearing130 mmFloor space/WeightDimensions (L x W x H)4,46 x 1,88 x 2,30 mWeight approx.6500 KgTool holder 1Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.-4000 rpmPower max. (40% DC)11,3 kWTechnologie cycle alternating speedTechnology cycle for the  ...

GeneralTurn- mill machining centre; Control: Siemens sl Operate3G without ShopTurn appr 2 channel Tool magazineNumber of tools38 Max. tool length250 mmMax. tool diameter70 mmMax. tool weight3 KgB-axis Turning-milling spindleSwivelling range+/- 120 degreeSpeed range B3100 rpmAngular value, min.1 degreeTurning-milling spindleSpindle taperCapto C5 Drive power (100% DC)5,5 kWSpindle speed-20000 rpmDrive power (40% DC)7,5 kWTorque (100% DC)22 NmTorque (40% DC)30 Nmangular value, min.5 degreelocking moment700 NmB-axis counter spindlePositioning angle B3-axis, in 5 degree steps0 - 225 degreeSpeed range B340 rpmSlide 3Longitudinal stroke665 mmRapid traverse Z36 m/minSlide 1Longitudinal stroke454 mmTransverse stroke380 mmRapid traverse in X40 m/minY axis, vertical+/- 105 mmRapid traverse in Z50 m/minRapid traverse in Y40 m/minHeadstock, rightClamping chuck Ø140 mmSpindle bore38 mmSpindle diametr ...

General2-Axes Universal Turning Center with driven tools, C-axis, Y-axis and counter spindle - Direct measuring system for X / Y axis; Control: DMG MORI SLIMline® multi-touch control Working areaSwing diameter over guide ways700 mmSwing diameter over transverse guideway370 mmTurning diameter400 mmBar diameter max.80 mmSlide 1Longitudinal stroke755 mmTransverse stroke276 mmY axis, vertical+/- 60 mmRapid traverse in X30 m/minRapid traverse in Z30 m/minRapid traverse in Y22,5 m/minWork spindle (left)Spindle noseA2-8 Bar diametre80 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)17 kWDrive power (40% DC)25,5 kWSpeed range- 4000 rpmTorque (100% DC)283 NmMax. torque (40% DC)426 NmC-Axis Speed-200 rpmTorque of C-Axis (holding torque)426 NmWork spindle (right)Spindle noseA2-6 Bar diametre50 mmSpindle diametre on front bearing100 mmMain drive 2Drive power (40% DC)14 kWD ...

General2-Axes Universal Turning Center with driven tools, C-axis, Y-axis and counter spindle - Direct measuring system for X / Y axis; Control: DMG MORI SLIMline® multi-touch control Slide 1Longitudinal stroke755 mmTransverse stroke276 mmY axis, vertical+/- 60 mmRapid traverse in X30 m/minRapid traverse in Z30 m/minRapid traverse in Y22,5 m/minWorking areaSwing diameter over transverse guideway370 mmTurning diameter400 mmSwing diameter over guide ways700 mmBar diameter max.80 mmMain drive 1Drive power (100% DC)17 kWDrive power (40% DC)25,5 kWSpeed range- 4000 rpmTorque (100% DC)283 NmMax. torque (40% DC)426 NmC-Axis Speed-200 rpmTorque of C-Axis (holding torque)426 NmWork spindle (left)Spindle noseA2-8 Bar diametre80 mmSpindle diametre on front bearing130 mmMain drive 2Drive power (100% DC)13 kWDrive power (40% DC)14 kWSpeed range- 5000 rpmTorque (100% DC)171 NmMax. torque (40% DC)192 N ...

General2-Axes Universal Turning Center with driven tools, C-axis, Y-axis and counter spindle - Direct measuring system for X / Y axis; Control: DMG MORI SLIMline® multi-touch control Working areaSwing diameter over guide ways700 mmSwing diameter over transverse guideway370 mmBar diameter max.80 mmTurning diameter400 mmSlide 1Longitudinal stroke755 mmTransverse stroke276 mmY axis, vertical+/- 60 mmRapid traverse in X30 m/minRapid traverse in Z30 m/minRapid traverse in Y22,5 m/minMain drive 1Drive power (100% DC)17 kWDrive power (40% DC)25,5 kWSpeed range- 4000 rpmTorque (100% DC)283 NmMax. torque (40% DC)426 NmC-Axis Speed-200 rpmTorque of C-Axis (holding torque)426 NmWork spindle (left)Spindle noseA2-8 Bar diametre80 mmSpindle diametre on front bearing130 mmWork spindle (right)Spindle noseA2-6 Bar diametre50 mmSpindle diametre on front bearing100 mmMain drive 2Drive power (100% DC)13 kW ...

General2-Axes Universal Turning Center with driven tools, C-axis, Y-axis and counter spindle - Direct measuring system for X / Y axis; Control: DMG MORI SLIMline® Multi-Touch control Working areaSwing diameter over transverse guideway370 mmSwing diameter over guide ways700 mmTurning diameter400 mmBar diameter max.80 mmSlide 1Transverse stroke276 mmLongitudinal stroke755 mmY axis, vertical+/- 60 mmRapid traverse in X30 m/minRapid traverse in Z30 m/minRapid traverse in Y22,5 m/minMain drive 1Drive power (100% DC)17 kWDrive power (40% DC)25,5 kWSpeed range- 4000 rpmTorque (100% DC)283 NmMax. torque (40% DC)426 NmC-Axis Speed-200 rpmTorque of C-Axis (holding torque)426 NmWork spindle (left)Spindle noseA2-8 Bar diametre80 mmSpindle diametre on front bearing130 mmMain drive 2Drive power (100% DC)13 kWDrive power (40% DC)14 kWSpeed range- 5000 rpmTorque (100% DC)171 NmMax. torque (40% DC)192 N ...

GeneralUniversal milling and turning machining centre with duoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal800 mmVertical850 mmCross1050 mmTool changerApplicationUniversal Type of magazineWheel Tool changer planehorizontal Type of gripperDouble gripper Number of tools123 NC mill-turn table with palletNC mill-turn table with pallet number of T-slots: - 1x cross slot 14 H7 / 0.55 H7 - 12x star slots 14 H12 / 0.55 H11 / 22.5° max. table speed milling operation: 30 rpm turning operation: 800 rpm integrated balancing sensor Pallet changer for 2 palletsType of Measuring system Direct measuring systemTable surface Ø 800 x 630 mmCentre bore 50 mmMaximum load (table centre) 1400 Kg4. Axes (swivelling range) 360  ...

GeneralUniversal milling and turning machining centre with duoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal800 mmCross1050 mmVertical850 mmTool changerApplicationUniversal Type of magazineWheel Tool changer planehorizontal Type of gripperDouble gripper Number of tools123 NC mill-turn table with palletNC mill-turn table with pallet number of T-slots: - 1x cross slot 14 H7 / 0.55 H7 - 12x star slots 14 H11 / 0.55 H11 / 22.5° max. table speed milling operation: 30 rpm turning operation: 800 rpm integrated balancing sensor Pallet changer for 2 palletsType of Measuring system Direct measuring systemTable surface Ø 800 x 630 mmCentre bore 50 mmMaximum load (table centre) 1400 Kg4. Axes (swivelling range) 360  ...

GeneralTwo- Spindle Turning Centre; Control: Sinumerik 840C Tool holder 2Shank diametre according to DIN 6988030 mmNumber of tool stations12 Number of driven tools12 Speed max.-4000 rpmPower max. (100% DC)5 kWPower max. (40% DC)6,5 kWTool holder 1Number of tool stations12 Shank diametre according to DIN 6988030 mmNumber of driven tools12 Speed max.-4000 rpmPower max. (100% DC)5 kWPower max. (40% DC)6,5 kWSlide 3 (Spindle 2)Longitudinal stroke600 mmRapid traverse Z30 m/minFeed rate torque (100% DC) in Z700 daNSlide 2Longitudinal stroke555 mmTransverse stroke190 mmRapid traverse X20 m/minRapid traverse Z30 m/minSlide 1Longitudinal stroke555 mmTransverse stroke190 mmY axis, vertical+/- 40 mmRapid traverse in X20 m/minRapid traverse in Z30 m/minRapid traverse in Y7,5 m/minFeed rate torque (100% DC) in X/Y/Z400/700/700 daNMain drive 2Type of main driveAC Drive power (100% DC)14 kWDrive power  ...

GeneralIntegrated Mill Turn Center; Control: Control F31iB5 with CELOS CharacteristicsSwing- Ø, max.700 mmSpeed max.12000 rpmSlewability of B-Axis±120 degreeMovements X / Z / Y675/1562/300 (±150) mmMilling spindle upper side1 Bar diametre80 mmMax. Turning Length1530 mmSpeed max.4000 rpmMax machining diameter670 mmDrive power tool spindle5,5/3,7 kWDrive power milling spindle28/23 kWDrive power main spindle18,5/15 kWMovements X / Z200/1542 mmLower Turret10 PositionsNumber of Toolmagazine positions38 Weight approx.18500 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and p(Left Spindle) through-spindle hole dia. 91 mm, 4,000min-1 (STD)(Left Spindle) Through-spindle Hol ...

DMG Mori CMX 70 U 5 axis machining center Spindle has been replaced with new one recently Probe X : 750 mm Y : 600 mm Z : 520 mm Machine is in excellent condition

Machine Details Warehouse number 1105-03530 Machine Type Machining Center - Vertical Make DECKEL MAHO Type DMC 103 V Year of construction 2000 Control type CNC Control HEINDENHAIN TNC 426 Storage location FRANCE Country of origin Germany Delivery time ON REQUEST Freight base freely loaded Trucks, from location Price Technical details x-travel 1000 mm y-travel 600 mm z-travel 600 mm Control HEINDENHAIN TNC 426 Table clamping surface 1200 x 600 mm Table load 0.8 t Rapid traverse 30 m/min Speed range 8000 rpm Torque at the spindle 90 Nm Drive power - milling spindle 13 kW Number of tools in the magazine 24 pieces Tool holder SK 40 Information CNC HEIDENHEIN TNC 426 - electronic handwheel - Synchronized tapping - RS 232 interface

x-travel: 640 mm y-travel: 600 mm z-travel: 500 mm CNC-control: iTNC 530 HEIDENHAIN table-size: 850 x 630 mm max. table load: 600 kg spindle taper: SK 40 spindle turning speed range: 12.000 U/min feed stepless: 40.000 mm/min rapid traverse: 60 m/min drive capacity - spindle motor: 18,0 kW tool change unit: 30 Pos. voltage: 400 V total power requirement: 42 kVA weight of the machine ca.: 6,5 t dimensions of the machine ca.: 3,45 x 2,35 x 2,90 m chip conveyor: 3,50 x 1,20 x 1,60 m coolant: 1,70 x 1,20 x 1,60 m - serial-no.: 29100004772 - Machine ON: 69,044 h - spindle ON: 34,493 h - Control: HEIDENHAIN iTNC 530 - autom. tool measurement BLUM-MICRO - Infrared 3D measuring probe - electr. handwheel - ICZ - Chip conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

For DMG HSC 75

Machine Details Warehouse number 1105-03531 Machine Type Machining Center - Vertical Make DMG DECKEL-MAHO Type DMC 64 V linear Year of construction 2002 Control type CNC Storage location FRANCE Country of origin Germany Delivery time immediately Freight base from stock Technical details x-travel 640 mm y-travel 600 mm z-travel 500 mm Table size 850 x 600 mm Spindle holder ISO 40 Speed range 0 - 12000 rpm Rapid traverses - longitudinal/transverse/vertical 30 m/min Number of tool magazine slots 30 Information CNC control heidenhain tnc 530 30X SK 40 MAGAZINE ELECTRONIC HANDWHEEL MACHINE IN GOOD CONDITION WITH SPAENEFOERDERER

Vertical machining center DMU 60 :::TECHNICAL SPECIFICATIONS::: CNC Model: Heidenhain CNC version: iTNC 530 Tool connection: HSK 63 Spindle power: 12Kw Number of Spindle Revolutions: 12000 Number of tools: 24 ( 12 x 2 ) X Axis Travel: 630mm Y Axis Travel: 560mm Z Axis Travel: 560mm Rapid linear axis feeds X Y Z: 20m/min Table dimensions: 1000 x 600mm Table capacity: 500Kg Guides: roller High refrigerant pressure: yes Chip evacuator: carpet operated :::D IMENSIONS AND WEIGHT::: Length: 3500mm Width: 2700mm Height: 2210mm Weight: 6500Kg

GeneralTwo spindle turning/milling centre with - Main and counter spindle; Control: CELOS with Siemens 840D sl Operate Tool holder 2Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.4000 rpmPower max. (40% DC)10 kWTool magazineNumber of tools24 Max. tool length230 mmMax. tool diameter80 mmMax. tool weight7 KgTurning-milling spindleSpindle taperHSK-A 63 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22,5 kWTorque (100% DC)85 NmTorque (40% DC)120 Nmlocking moment1000 NmSwivelling range+/-110 degreeSlide 2Longitudinal stroke1200 mmTransverse stroke195 mmSlide 3Longitudinal stroke1200 mmSlide 1Longitudinal stroke1200 mmTransverse stroke490 mmY axis, vertical+/- 100 mmHeadstock, rightClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWDri ...

GeneralTwo spindle turning/milling centre with - Main and counter spindle; Control: CELOS with Siemens 840D sl Operate Tool holder 2Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.4000 rpmPower max. (40% DC)10 kWTurning-milling spindleSpindle taperHSK-A 63 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22,5 kWTorque (100% DC)85 NmTorque (40% DC)120 Nmlocking moment1000 NmSwivelling range+/-110 degreeTool magazineNumber of tools24 Max. tool length230 mmMax. tool diameter80 mmMax. tool weight7 KgSlide 3Longitudinal stroke1200 mmSlide 2Longitudinal stroke1200 mmTransverse stroke195 mmSlide 1Longitudinal stroke1200 mmTransverse stroke490 mmY axis, vertical+/- 100 mmHeadstock, rightClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWDri ...

GeneralUniversal Milling Machine; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal650 mmCross520 mmVertical475 mmFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgTechnical DataType of main driveAC Drive power (100% DC)30 kWDrive power (40% DC)46 kWSpeed range20 - 15000 rpmSpindle taperHSK-A 63 Clamping SystemHSK-A 63 Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minSpindle speed 15,000 rpm, 200NmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 15,000 min-1 Output 46 kW / 30 kW (62 hp / 40 hp) Torque 200 Nm / 130 Nm (148 ft lbs / 96 ft lbs) (40 / 100 % duty cycle)NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 630 x 500mm / 24.8 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring sy ...

GeneralUniversal machining centre; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minWorking area 1Longitudinal600 mmCross500 mmVertical500 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmDie and Mold Package linear incl. B-/C-TorqueDie and Mold Package linear incl. B-/C-Torque Dynamic package V-type Eagle timing belt for Z axis Torque table B-/C-axis including ATC AVD - Heidenhain or MVC - Heidenhain (starting NC 340590 11) APC and Top Speed - Siemens High End cooling unit for machiSpindle speed 20.000 rpm, HSK-A63Motor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20,000 min- ...

Longitudinal X: 2600 mm Cross Y: 700 mm Vertical Z: 700 mm Positions ATC: 12   CNC Brand: Heidenhain CNC Model: iTNC 530 X – Travel:               2.600mm Y – Travel:               700mm Z – Travel:               700mm A – Axis:                 360000° B – Axis:                 +/- 110 ° Table Length:             2.900mm Table Width:              700mm Table load:               2.150Kg Table  Ø:                 750mm Feed rate X-Axis:         40.000mm/min. Feed rate Y-Axis:&n ...

Tool changer for DMC60 U with 120 tools. . Probably also fits DMU 60P, 80P, DMU 125.
