dm used for sale

Deckel Maho 4-axis CNC milling machine DMC 64 V linear Working Range: - X-axis: 640 mm - Y-axis: 600 mm - Z-axis: 500 mm - With 520 Heidenhain control - With coolant system + paper filter - Probe preparation, but probe is missing - Few operating hours - Machine is first owned - from the production of individual parts of precision parts - All 4 axes can be moved, only the transmitter of the main spindle is defective Good condition, fully functional, can be viewed and tried out on site. Shipping also abroad. Viewing: Basically, I would like to point out that the article can be viewed and tested under power before purchase in order to rule out misunderstandings. Please ask questions before purchasing to avoid confusion. If you have any general questions or would like to make an appointment for a viewing, I can be reached at any time on the telephone number below or ...

Key data: 950 mm, 850 mm, 650 mm

CNC Universal Machining Center DECKEL MAHO DMU 95 monoBlock NEW DMG Design With track control Heidenhain TNC 640 Year of construction: 2024 Travel: X 950 Y 850 Z 650 Speed range: 0 – 20000 rpm infinitely variable (HSK 63) With the following accessories: NC swivel rotary table 1000 mm x 750 mm clamping surface 3 D Probe Heidenhain TS 460 Vertical tool changer with 120 magazine positions (HSK 63) Tool breakage detection Chip flushing in workroom door Chip rinsing gun with pump 1 bar/40 l min Blowing air d.d. spindle center Accuracy Package Application Tuning Cycle MPC Machine Protection Control Net Service App, Service Agent Operating mode 3 + 4 Electronic handwheel IKZ 40 bar with paper belt filter Chip conveyor Rotoclear Coolant Setup Spindle Oil Cooler Oil mist extraction 3-Piece Height Adjustable Machine Shoes Control cabinet cooling unit (Rittal)  ...

This DECKEL MAHO DMF 250 linear machining center from 2006 features a HEIDENHAIN iTNC530 controller and 4-axis capability with a B-axis tilting ±105°. The machine offers generous travels of 2,500 mm (X), 920 mm (Y), and 820 mm (Z), combined with a robust 3,100x900 mm table supporting up to 3,000 kg workpiece load. Equipped with an HSK-A63 spindle delivering 35 kW power and speeds from 20 to 18,000 rpm, it handles demanding milling and drilling operations efficiently. A 120-position tool magazine ensures flexible production. Rapid traverse rates reach 100 m/min on the X-axis. Available now through MBR Machinery—contact us for detailed specifications and viewing.

This used DECKEL MAHO DMC 60 U machining center, manufactured in 2002, is equipped with a Siemens SINUMERIK 840D (3D-Bahnsteuerung) controller. The machine offers 5-axis simultaneous machining with travels of 600 x 700 x 600 mm. It features a Schwenkfraeskopf (B-axis -7 / +180 degrees) and an NC-Rundtisch (C-axis 360 degrees). The spindle reaches 12,000 rpm with 28 kW power and 121 Nm torque. The setup includes an APC with 2 pallets (630 x 500 mm), a 60-position tool magazine with a horizontal double-arm changer, and IKZ Form AD (Innenkuehlmittelzufuhr).

A Deckel Maho 5-axis CNC milling machine in need of repair is offered. Travel X/Y/Z: 1080mm/710mm/710mm, NC-mounted rotary table C-axis X/Y: 800mm/620mm, swiveling milling head B-axis: 90°, max. spindle speed: 12000rpm, tool taper: SK40, tool positions: 32, control: Heidenhain iTNC 530, control-on hours: 75100h, program run hours: 24720h. Equipped with internal air blast supply, external coolant supply, Heidenhain infrared touch probe, Heidenhain electronic handwheel, Rotoclear rotating inspection window, chip conveyor, oil mist extraction system, coolant system with paper band filter, chip flushing gun, work area light and clamping support next to the mounted rotary table for longer workpieces. The milling head clamping system is leaking, but the machine is still operational. An on-site inspection is possible.

x-travel: 1040 mm y-travel: 600 mm z-travel: 500 mm Control: Heidenhain iTNC 530 table surface area: 1250 x 600 mm table load: 600 kg tool taper: SK 40 spindle turning speed range: 1 - 8000 U/min max. torque on the spindle: (S1/S6) 140/200 Nm feed range: 40000 mm/min rapid power traverse in X-and Z direction: 70 m/min rapid motion - y-axis: 40 m/min spindle drive: (100/40 % ED) 13/19 kW total power requirement: 39 kVA weight of the machine ca.: 8,9 t dimensions of the machine ca.: m Operating hours 70294 Spindle hours 23335 Please note the enclosed geometry measurement report with the tool pull-in force measurement. Equipment: CNC control Heidenhain iTNC 530 Electronic handwheel Heidenhain HR 410 Motor spindle with increased torque Direct path measuring system in Y-Z axis Preparation for measuring probe 30-station tool changer, tool diameter 100/140 mm, length 300, weight 7 kg ROTOCLEAR ...

DMG MORI EcoTurn 310 ist eine CNC-Drehmaschine hoher Präzision, ausgelegt für hohe Genauigkeit und Zuverlässigkeit. Arbeitsumfang: 3 Achsen; Schwingdurchmesser über Bett 330 mm, über Kreuzschlitten 260 mm; max. Drehdurchmesser 200 mm; Stangendurchlass 51 mm; Verfahrwege Z 455 mm, X 182,5 mm; Eilgang X/Z 30 m/min. Technische Daten: Revolver 12 Positionen mit 12 angetriebenen Werkzeugen; Drehzahl 4.500 min-¹ (stufenlos bis 5.000 min-¹); Spindelaufnahme VDI 30; Morsekonus 4 CM; Gesamtleistung 21 kVA; Gewicht ~3.400 kg; Abmessungen L4400×B2400×H2100 mm. Zubehör: 3-Backenfutter, Satz Spannzangen REGO-FIX ER25, Lampe, Kühlmitteleinrichtung. Eignet sich für enge Toleranzen in Automotive, Luftfahrt, Medizintechnik, Uhrenindustrie und Maschinenbau. Technische Daten ohne Gewähr

x-travel: 1.000 mm y-travel: 1.000 mm z-travel: 1.000 mm Control: HEIDENHAIN iTNC 530 rapid travel x/y/z: 60.000 mm/min feed: 10.000 mm/min NC table: numbers of pallets: 2 Stück size of pallet: 1.000 x 800 mm weight with floor-plates: 1,5 t c-axis: Tisch 0.001º 0 table speeds: 10.3 m/min spindle: kW a-axis: 0,001 ° tool adaptor: HSK 63 spindle drive: 26,9 kW spindle turning speed range: 24.000 U/min tool change unit: 120 pos Internal cooling system: 80 bar chip conveyor: Inkl handwheel: Inkl total power requirement: 69 kVA weight of the machine ca.: 24 t dimensions of the machine ca.: 5.351 x 4.378 x 3.400 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

DMG Mori CMX 600V CNC Bearbeitungszentrum (2018) Hersteller: DMG Mori Typ: CMX 600V CNC Bearbeitungszentrum Baujahr: 2018 Zustand: gebraucht, unter Produktion Einschaltstunden: 514h Spindelstunden: 142h Weitere Informationen folgen

x-travel: 500 mm y-travel: 400 mm z-travel: 400 mm Control: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

DMG DMU 40 eVo ist ein vertikales Bearbeitungszentrum mit hoher Präzision, Genauigkeit und Zuverlässigkeit. Arbeitsfähigkeiten: Tisch 480x400 mm, 5 T-Nuten (63 mm Abstand, 14H7), Zentrierbohrung 30H6, max. Tischlast 250 kg; Wege X400 Y400 Z375 mm, B -5/+110°, C 360°, Tischdrehzahl 60 t/min. Technische Hauptdaten: Leistung 50 kW, Spindel HSK-A63 bis 24000 min-¹ (stufenlos), Drehmoment 130/86 Nm, Spindelleistung 35/25 kW, Vorschub 0-80000 mm/min, Druckluft 6 bar, 3x400V 50Hz, Abmessungen L2960xB2620xH2530 mm, Gewicht ~7150 kg. Zubehör: FANUC Lade-Roboter, Kühlmittel/IKZ 40/80 bar, TRS2 Werkzeugbruchkontrolle, Laser-Werkzeugvermessung, Späneförderer, Nebelabsaugung, Spülpistole, rotierendes Sichtfenster, Schaltschrank-Klimagerät. Erreicht enge Toleranzen; typische Branchen: Automotive, Luftfahrt, Medizintechnik, Uhrmacherei, Werkzeugbau. Technische Daten ohne Gewähr

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872

x-travel: 1.035 mm y-travel: 560 mm z-travel: 510 mm CNC-control: HEIDENHAIN TNC620 table-size: 1200 x 560 mm max. table load: 1000 kg spindle taper: SK 40 spindle turning speed range: 10.000 U/min drive capacity - spindle motor: 13 kW feed stepless: 20.000 mm/min rapid traverse: 25 m/min tool change unit: 20 Pos. coolant: IKZ 20 bar voltage: 400 V total power requirement: 17 kVA weight of the machine ca.: 4,1 t dimensions of the machine ca.: 2,55 x 2,30 x 2,25 m chip conveyor: 3,90 x 0,95 x 1,60 m coolant tank: - Serial No.: 1539000377A - Machine ON: 21.689 h - Program Run: 9.021 h - CNC-Control: Heidenhain TNC620 - elektronic hand wheel - chip conveyor - coolant through spindle 20 bar The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)4th Axis package4th Axis package Option includes: - rotary table type EA-510.L NE with indirect measuring system - electrical and pneumatic preparation - software preparation to work with rotary table - cycle TRACYL which allows to define contour on the cylinder - swSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872

Key data: 640 mm, 600 mm, 500 mm

CNC Vertical Machining Center DECKEL MAHO DMC 64 V linear With track control Heidenhain iTNC 530 Year of Make: 2004 Travel: X 640 Y 600 Z 500 Speed range: 0 – 12,000 rpm infinitely variable With the following accessories: Rigid angle table 850 mm x 600 mm clamping surface Vertical tool changer with 30 magazine positions 3D Probe Renishaw Electronic handwheel Full protection cabin with sliding doors and interior lighting Operating mode 3 + 4 IKZ 40 bar Chip conveyor Swarf Spray Gun Spiral chip auger Coolant Setup 3 Height Adjustable Machine Shoes Operating instructions

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Air coolant external and internalAir coolant external and internal (through spindle centre) switchable via M-FunctionElectronic HandwheelExternal electronic Handwheel

2005Siemens 840D Powerline ShopMillØ630 x 500 mm200 kg115° (-5°/+110°)500 mm450 mm400 mm20-10,000 rpm9 kW13 kW82 Nm0.010 mm0.01 mm24 m/min20 m/minChain magazine with double gripper, 30 positions SK40 (DIN 69871)80-130 mm (speed dependent)290 mm6 kg80 l17 kW4,860 x 4,350 x 2,424 mm2,210 x 2,120 x 2,150 mm4.05 t35,880 h9,609 h400 V / 50 HzDirect linear encoders (X/Y/Z)Heidenhain TS641 (infrared)

x-travel: 2500 mm y-travel: 920 mm z-travel: 820 mm Control: Heidenhain iTNC 530 table surface area: 3100 x 900 mm table load: 3,0 t tool taper: HSK-A63 spindle turning speed range: 20 - 18000 U/min rapid traverse: (X,Y,Z) 100 / 60 / 60 m/min main drive: (S1/S6) 35 / 25 kW total power requirement: 92 kVA weight of the machine ca.: 25,6 t dimensions of the machine ca.: 10,3 x 6,2 x 3,3 m Operating hours: 113520 h Total spindle hours: 58190 h (date: 3rd September 2026) In April 2026, a new milling spindle from DMG-MORI was installed. Since then only 25 running hours ! 4-axes controlled CNC control HEIDENHAIN iTNC 530 Autom. swivel-type milling head (B-axis) +/- 105 deg. 120-station ATC Chip conveyor Tool measuring device (laser) Electronic handwheel Control cabinet with air conditioning Machine will be sold without clamping devices, vise, and tools. The data for this ad was creat ...

Working areaSwing diameter over guide ways580 mmClamping chuck diameter max.250 mmWork spindle (left)Spindle bore73 mmBar diametre65 mmSpindle diametre on front bearing120 mmMain drive 1Drive power (100% DC)11 kWDrive power (40% DC)16,5 kWSpeed range- 5000 rpmTorque (100% DC)112 NmMax. torque (40% DC)168 NmC-Axis Speed-100 rpmTorque of C-Axis (holding torque)168 NmGeneral2-Axes Universal Turning Center with driven tools, C-axis, Y-axis and counter spindle; Control: DMG MORI SLIMline® multi-touch control Work spindle (right)Spindle diametre on front bearing90 mmSpindle bore45 mmMain drive 2Drive power (100% DC)12,6 kWDrive power (40% DC)16,2 kWSpeed range- 5000 rpmTorque (100% DC)48 NmMax. torque (40% DC)62 NmC-Axis Speed-300 rpmTorque of C-Axis (holding torque)62 NmSlide 1Longitudinal stroke465 mmTransverse stroke185 mmY axis, vertical+/- 40 mmTool holder 1Number of tool stations12 Shan ...

General2-Axes Universal Turning Center with driven tools, C-axis, Y-axis and counter spindle; Control: DMG MORI SLIMline® Multi-Touch control Working areaSwing diameter over guide ways580 mmClamping chuck diameter max.250 mmWork spindle (left)Spindle bore73 mmBar diametre65 mmSpindle diametre on front bearing120 mmMain drive 1Drive power (100% DC)11 kWDrive power (40% DC)16,5 kWSpeed range- 5000 rpmTorque (100% DC)112 NmMax. torque (40% DC)168 NmC-Axis Speed-100 rpmTorque of C-Axis (holding torque)168 NmWork spindle (right)Spindle bore45 mmSpindle diametre on front bearing90 mmMain drive 2Drive power (100% DC)12,6 kWDrive power (40% DC)16,2 kWSpeed range- 5000 rpmTorque (100% DC)48 NmMax. torque (40% DC)62 NmC-Axis Speed-300 rpmTorque of C-Axis (holding torque)62 NmSlide 1Longitudinal stroke465 mmTransverse stroke185 mmY axis, vertical+/- 40 mmTool holder 1Number of tool stations12 Shan ...

Deckel-Maho DMU50 X: 500 - Y: 400 - Z: 400 mm CNC Max longitudinal travel X-axe: 500 mm Max cross-travel Y-axe: 400 mm Max travel Z-axe: 400 mm Power on spindle: 13 kW Admission in boring head (ISO): BT 40 Spindlespeeds: 20 > 9000 rpm Table size: 700 x 500 mm Control: Heidenhain TNC 426 Length: 2700 mm Depth : 2700 mm Height: 2500 mm Weight: 3,5 ton Toolholder: yes Number of tools: 16 positions

5-axis machining center, year 2007, 20070 operating hours, CNC iTNC 530. Used machine. More info & price on IndustrialBuyer.

Year of manufacture 2010 TOP condition! Siemens Control Spindle 18000 rpm 10610 Spindle hours Tool changer for 30 tools IKZ el. Handwheel Chip conveyor

Used machine DMF200/8 Machine type: Universal milling center Model No.:DMF200/8 Manufacturer: DMGMORI Control: CELOS with Siemens 840D sl Operate Year of manufacture: 2023 Location:Germany Equipment: - Travelling column milling machine DMF 200/8 - NC swivel milling head (B-axis) - Motor spindle speedMASTER® - Tool holder SK40 DIN - Spindle speed 20 - 15,000 rpm 21 kW/16 kW - Chain magazine for 40 tools, - Chip conveyor (scraper belt) - Fixed table with integrated rotary table - Internal coolant supply 40 bar/600ll with paper belt filter - Oil and emulsion mist separators - Blowing air through the spindle center - Infrared probe PP60 optical - 3D quickSET - Laser tool measurement Blum LC50 Technical data Travel range X-axis approx. 2000 mm Y-axis approx. 800 mm Z-axis approx. 850 mm B-axis (head) +-120° ° Rotary table in table 800 mm Table size appro ...

This 3-axis DECKEL MAHO DMC 65 V was manufactured in 2003. It features a spindle speed of 18,000 rpm and a tool changer capacity of 30 positions, enhancing its operational efficiency. The machine is equipped with a Heidenhain TNC 426 control system and optional equipment such as tool measurement and an automatic 3D probe. If you are looking to get high-quality machining capabilities, consider the DECKEL MAHO DMC 65 V vertical machining centre we have for sale. Contact us for further details.

x-travel: 630 mm y-travel: 560 mm z-travel: 560 mm Control: total power requirement: --- kW weight of the machine ca.: 6,8 t dimensions of the machine ca.: --- m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Machine Type: CNC Turning Center Model: CTXbeta500V4 Manufacturer: DMGMORI Control: Siemens 840D si Operate solutionsline Year of Make: 2014 Location: EU (#301336) Facilities • Main spindle 34/25 kw rpm 5000 • Hydraulic 3-jaw chuck 250 mm • Manual tool measuring device • 12 VDI 40 station turrets • Tool drive for all stations • C-axis • Y-axis • Scale X • Chip conveyor • 12 bar / coolant system • Coolant spray gun incl. documentation if available Technical data Turning diameter max. approx. 410 mm Turning diameter standard approx. 270 mm Rod diameter max. approx. 65 mm X-axis approx. 300 mm Z-axis approx. 550 mm Y-axis approx. +/- 60 mm Spindle speed 1 approx. 5000 rpm Speed milling pindle approx. 4,000 rpm Rapid traverse X/Y/Z approx. 30/22.5/30 m/min Power spindle 1 approx. 34/25 kW Footprint L x W x H approx. 5.3 x 3.0 x 2.1 m  ...

Used machine DMU 40eVo linear Machine Type: CNC 5-Axis Milling Center Model: DMU 40eVo linear Manufacturer: DMGMORI Control:CELOS Siemens 840D sl Operate Year of Make: 2022 #001431 Location: Germany Technical data Travel range X-axis approx. 400 mm Y-axis approx. 400 mm Z-axis approx. 375 mm C-axis 360° B-axis -5/+110 ° Workpiece diameter approx. 450 mm Workpiece weight max. approx. 250 kg Speed max. approx. 20,000 rpm Spindle motor approx. 35/25 KW Number of tool positions approx. 120 Rapid traverse approx. 80 m/min Pick-up taper approx. HSK63 Additional axles approx. 2 4th/5th Compressed air bar,L/min approx. 5, 300 bar,L/min Power consumption approx. 32 kVA Footprint L x W x H approx. 2.05x2.85x2.53 m (without pallet pool) Machine weight approx. 7,500 kg Facilities Dynamic Package for DMU 40 eVo linear - Motor Spindle speedMASTER® HSK-A63 RPM 20-20,0 ...

The machine is in good technical condition; testing is possible by prior arrangement. A probe is included.

The machine is in good technical condition; it can be tested by prior arrangement.

Used machine NLX2000SY with loading magazine Machine Type: Turning Center Model No.:NLX2000SY Manufacturer: DMGMORI Control: CELOS Year of construction/IB: 2021/2022 Location:: Germany - Main spindle 15/11 KW - Chuck for main spindle - Automatic path control of the clamping cylinder for the main spindle. - Sub-spindle 11/7.5kw - Chuck for sub-spindle - Automatic path control of the clamping cylinder for the sub-spindle - Double footswitch for HSp and GSp - Coolant shower on lining - Spindle 2 tailstock specification - 20 Station turret - Milling drive for all stations 10,000 min-1 - Direct position measuring system X-Y-Z axis - Y-axis - Chip conveyors - Coolant pump 8bar - Bar feeder IF - Parts catcher conveyor belt for parts - Irco Bar Loading Magazine MUK 7012 III - Workpiece ejector (headstock 2) - Oil separator - Alternating speed - Spindle orientation ...

Key data: 1800 mm, 2100 mm, 1250 mm

We hereby offer you a 5-axis machining centre from DMG as follows: Basic machine data Make: DMG Type: DMU 210 P Year of construction: First commissioning June 2017 Condition: very good – machine set to half tolerance Control: Name: Heidenhain iTNC 530 HSCI Handwheel: Heidenhain HR 520 FS Technical data: • Spindle: 20-12000 rpm // 457 Nm – spindle with increased torque • CNC rotary table Ø 1700 mm • Table load: 8000 kg • B-axis (infinitely variable) • 120x WZW • HSK-A 100 interface • IKZ (internal coolant supply) 80 bar – frequency-controlled • 980 l coolant tank with paper belt filter • Zero-point clamping system incl. extensive accessories – pots, spigots, matching clamping plates, etc. • Chip conveyor • Rinsing gun • Infrarottprobe • Blumlaser • MPC – Machine Protection Control The machine is in very good con ...

5-axis CNC machining center Type: DMU 40 eVo Manufacturer: DMG MORI Year: 2013 Control: Heidenhain iTNC 530 X: 400 mm Y: 400 mm Z: 375 mm B: -5•/+110• C axis Spindle speed: 18000 rpm Spindle taper: HSK 63 Max work diameter: 450 mm Max work height: 460 mm Max work weight: 250 kg Machine weight: 6900 kg Chip conveyor Machine in good condition, fully functional, under power Find more here - .ucymachines/ Contact us at - sales@ucymachines

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic Handwheel

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.14500 KgDirect measuring systemDirect path measuring systemCabineFull protection cabinPackage Mill / Turn HSK-A 63Package Milling / Turning: Upgrade NC-swivel rotary table to Milling - Turning / direct drive Table plate C-axis d 680 mm / 26.8 in Speed C-axis 1.000 min-1 Integrated balancing sensor Motor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20 ...

GeneralUniversal Milling Machines; Control: 3D-control Heidenhain TNC 620 Working area 1Longitudinal500 mmCross450 mmVertical400 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minFloor space/WeightDimensions (L x W x H)3,15 x 2,86 x 2,71 (4,14 x 3,56 x 2,71) mWeight approx.5000 KgSwivel Rotary Table Powered B/C AxesSwivel Rotary Table Powered B/C Axes with automatic hydraulic clamping Electronic angle indication (B&C Axes) and Working Plane transformation For positioning only!Type of Measuring system Direct measuring systemMode for positioning only5. Axes (swivelling range) -5/+110 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeDistance between T-Slots 63 mmNumber of Slots 7Slot width 14 mmMaximum load (table centre) 200 KgTable surface Ø 630 x 500 mmDirect measuring system X,Y,ZDire ...

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsTorque (100% DC)43 NmMax. torque64 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.10000 rpmWeight approx.5600 KgSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872

Key data: 800 mm, 800 mm, 800 mm

DMG MORI DMC 80H duoBLOCK – 4-Axis Horizontal Machining Center with Interchangeable Table – Used For sale is a used DMG MORI DMC 80H duoBLOCK horizontal machining center. The machine is currently still in productive use and is reliably used in series production. It is mainly used for processing steel and cast iron. Condition: Fully functional and operational. Viewing under power possible by arrangement. Equipment: 4-axis machining Horizontal design for efficient chip removal Changing table (pallet changer) for reduced non-productive times duoBLOCK design for high stability and precision Tool Changer Generous working space for complex components Further details on the equipment are available on request Control manufacturer: Siemens Control model: Sinumerik 840D Workpiece weight (max.): 1,200 kg Total height: 3,100 mm Overall length: 4,850 mm Overall  ...

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)4th Axis package4th Axis package Option includes: - rotary table type EA-510.L NE with indirect measuring system - electrical and pneumatic preparation - software preparation to work with rotary table - cycle TRACYL which allows to define contour on the cylinder - swSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Air coolant external and internalAir coolant ex ...

Manufacturer DMG-MORI Model DMF 260 Year 2011 CNC SIEMENS SINUMERIC 840D Table Table surface 2,900 x 700 mm. Maximum weight on table 2,150 kg. Routes and advances Longitudinal (X-axis) 2,600 mm Transverse (Y-axis) 700 mm Vertical (Z-axis) 700 mm Fast forward of the axes (X,Y,Z) 40 m/min Working progress of the axes (X,Y,Z) 40 m/min Axle acceleration 4 m/s2 Head Revolutions 14,000 mm/min SK 40 Head Cone DIN 69872 Main engine power 18.4 / 14 kW Automatic tool loader No. of Charger Tools 30 Maximum tool length 300 mm Maximum tool weight 6 kg. Maximum tool diameter with adjacent free positions 130 mm Maximum tool diameter without adjacent free positions 80 mm Equipment Refrigeration 40 Bar / 600 l. INCLUDED Longitudinal chip evacuator INCLUDED Coolant cleaning gun INCLUDED Portable steering wheel INCLUDED Direct Measurement System INCLUDED Machine hours  ...

CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgGeneralVertical Machining Center; Control: Control SIEMENS 828D Mechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Air coolant external and internalAir coolant external and internal (through spindle centre) switchable via M-FunctionElectronic HandwheelExternal electronic Handwheel

x-travel: 935 mm y-travel: 850 mm z-travel: 650 mm control: Heidenhain TNC 640 Main spindle:: turning speed range - main spindle: 20000 min/-1 power capacity - main spindel: 35 kW tool taper: SK 40 work table:: table surface area: 1000 x 750 (dia 850) mm max. table load: 1500 kg tool magazin:: number of toolpositions: 60 pos. tool taper: SK40 feeds:: feed speeds: 40.000 mm/min rapid traverse: 40 m/min Accelaration: 5 m/s² c-axis: 360 ° A-Axis: +/- 120 ° total power requirement: 46 kVA weight of the machine ca.: 14 t dimensions of the machine ca.: 3,1 x 4,4 x 3,2 m 5-axis universal machining centre equipped with: - Heidenhain TNC 640 CNC control - 60-position ATC (SK 40) - Heidenhain TS 460 touch probe - Chip conveyor with coolant - Paper belt filter - IKZ 40 bar - Blum laser tool measurement system - NC swivelling rotary table, diameter 850 x 750 mm 16,800 spindle hours and 48,00 ...

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic Handwheel

Universal Milling Machine Deckel Maho DMU 50 BJ 2004

CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgGeneralVertical Machining Center; Control: Control SIEMENS 828D Mechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic Handwheel

Rema DMMC sliding table saw Manufacturer: Rema Type: DMMC40 Year M. Nr: 1995 Main saw: max. max. ø400 mm, max Sawheight: 130 mm, Saw tilting: 0° – 45° Scorer: Yes RPM: 2.800/4.000/5.500 RPM Motor: 5,5 KW Sliding Table: 3.000 mm Parallel fence Positioning: 1.250 mm Cross cut fence: 2.200-3.300 mm 2-point fence Sidetable: with fixed positions for most used angles Dust extraction: Top: ø80 mm, Bottom: ø140 mm Weight: 900 KG

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmSpeed max.12000 rpmDrive power (100% DC)9 kWDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)Tool Clamping BT 40Tool Clamping BT 40 for pull-studs DIN 69872 (differently from standard)Electronic HandwheelExternal electronic Handwheel

x-travel: 500 mm y-travel: 450 mm z-travel: 400 mm Control: total power requirement: --- kW weight of the machine ca.: 4,5 t dimensions of the machine ca.: --- m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsSpeed max.12000 rpmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperBT 40 Tool Magazine with24 PositionsTorque (100% DC)57 NmMax. torque83 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWTable surface850 x 650 mmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)Tool Clamping BT 40Tool Clamping BT 40 for pull-studs DIN 69872 (differently from standard)Electronic HandwheelExternal electronic Handwheel

Year of construction: 2019 CNC controller: FS-31iB (MAPPS IVB) Axes X-axis travel mm: 1540 Y-axis travel mm: 760 Z-axis travel mm: 660 Rapid traverse m/min: 20 Worktable Table dimensions mm: 1700x760 Max. workpiece weight kg: 2000 Spindle Spindle speed rpm: 20000 Spindle drive power kW: 18,5/15/11 (10 min./30 min./cont) Spindle torque Nm: 81 (10%ED) Cooling Cooling through the Spindle Center bar: 70 Tool system Tool holder: BT 40 Tool magazine slots: 60 With free neighboring places mm: 125 With occupied neighboring places mm: 95 Max. Tool Length mm: 450 Max tool weight kg: 12 Tool-to-tool time s: 2.1 Equipment Electronic Handwheel Internal cooling lubricant supply Rinsing gun Signal lamp Tool measuring arm Mist collector Heat compensator Program restart Paper band filter Machine running times Under power: 35557 Spindle Working: 27278 Rated power kVA:  ...
