dimeco decoil straight used for sale

Description: .DIMECO R 693 J+ sheet metal straightening machine y.o.m 2020! - Number of straightening rollers 17 - Number of pull rollers 2 - Pull rollers diameter 180 mm - Number of support rollers 147 - Largest roller distance 200 mm The machine is equipped with: - Control cabinet with drive outlets for height adjustment on the inlet/outlet side of the straightening cassette as well as for the two main drives connected in parallel - Hydraulic unit for the hydr. Movements of the infeed table and the delivery of the infeed driver - Support rollers firmly installed at the top and bottom - Documentation, digital only! - Additional, unused straightening roll cassettes with 17 straightening rolls and intermediate rolls at the top and bottom. The machine was until lately integrated into a fully automatic punching line, therefore it is necessary to complete the control system. There is al ...

material width:500 mm material thickness:0,6 - 1,6 mm no. of straightening rolls:7 straightening roll diameter:60 mm number of draw-in rolls:2 + 2 inlet roll diameter:60 mm max. material thickness:2,0 mm material thickness at 150 mm material width:2,0 mm material thickness at 500 mm material width:1,6 mm weight:0,5 t dimensions (WxDxH):0,8 x 1,0 x 1,2 m

material width:550 mm material thickness:0,4 - 1,6 mm no. of straightening rolls:11 straightening roll diameter:60 mm number of draw-in rolls:4 diameter of draw-in rolls:60 mm band speed:4 - 50 m/min power capacity:3,0 kW weight:1,7 t Dimensions (WxDxH):2,5 x 2,0 x 1,7 m

sheet width - max.: 750-900 mm coil weight: 3,50 - 4,00 t coil internal dia.: 400 - 500 mm coil outside - diam. ca.: 1500 mm total power requirement: kW weight of the machine ca.: 1,90 t dimensions of the machine ca.: 1,50 x 1,90 x 2,30 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width - max.: 0250 mm coil weight: 0,500 t coil internal dia.: 250 - 550 mm coil outside - diam. ca.: 1150 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

material width:300 mm material thickness:0,6 - 2,5 mm no. of straightening rolls:7 straightening roll diameter:60 mm number of draw-in rolls:2 + 2 diameter of draw-in rolls:60 mm max. material thickness:3,5 mm material thickness at 30 mm material width:3,0 mm material thickness with 300 mm material width:2,5 mm weight:0,3 t Dimensions (WxDxH):0,9 x 1,0 x 1,1 m

material width:400 mm material thickness:0,6 - 2,8 mm no. of straightening rolls:5 straightening roll diameter:40 mm no. of pulling rolls:2 + 2 material thickness at 400 mm material width:1,8 mm material thickness at 65 mm material width:2,8 mm power capacity:3,0 kW weight:0,45 t Dimensions (WxDxH):0,8 x 1,8 x 1,35 m

material width coil line:600 mm coil weight:2 x 3,5 t coil internal diameter:460 - 530 mm coil external diameter:1500 mm material thickness coil line:0,5 - 3,0 mm no. of straightening rolls:7 no. of rolls at in- and outlet:4 roll diameter:80 mm feed length:0 - 500 mm power requirement:10,0 kW weight:10,0 t dimensions of the coil line:8,8 x 4,0 x 2,55 m straightening machine:Dimeco, 1676 EV double decoiler:2382 FFPS lag brake:pneumatic electronic roll feed:Microfeed

Pivatic perforating and bendingline Line is manufactured 1999 and it has worked very well for us 20 years. Line is bending line with perforation unit and single press unit 35 tn. In line is separate punching unit so you can perforate material and cut it to separate ballet. Also you can use separate press toll in line. This press unit we have not used, because we other presses. FORSTNER coil cradle Weingarten Decoiler Dimeco Coil feeding line decoiler - straightener feeder Automatic Flexible punching and rollforming line for C and sigma profiles with centralized adjustment”, from Dimeco (Spain), installed/commissioned in 2019 Dimeco Coil feeding line PIVATIC coil punching line FIMI Slit Coil Decoiler and reel winder tunçman Extrusion - Single screw extruder LEMO INTERMAT Thermoforming - Automatic Roll-Fed Machine Uhlmann Blister machine Accela-Cota 170 l Tablet c ...

material width:320 mm coil weight:2,6 t material thickness:0,5 - 2,0 mm coil internal diameter:400 - 510 mm coil external diameter:1200 mm no. of straightening rolls:7 straightening roll diameter:50 mm number of draw-in rolls:2 band speed:0 - 30 m/min power capacity:1,5 kW weight:1,5 t

material width:300 mm coil weight:0,5 t material thickness:0,4 - 3,0 mm coil internal diameter:420 - 520 mm coil external diameter:1200 mm no. of straightening rolls:9 straightening roll diameter:50 mm number of draw-in rolls:2 diameter of draw-in rolls:50 mm power requirement:1,5 kW weight:1,55 t dimensions (WxDxH):2,5 x 1,2 x 1,8 m

material width: 350 mm coil weight: 500 kg material thickness: mm coil external diameter: 1000 mm no. of straightening rolls: 9 straightening roll diameter: 45 mm speed: m/min power requirement: 9 kW Weight: - t Dimensions (WxDxH): - m Decoiler and straightener on one base plate - Straightening machine - decoiler - Control panel The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: mm coil weight: 4 t coil internal dia.: mm material width: 300 mm material thickness: 0,4 - 2,0 mm total power requirement: 8,5 kW weight of the machine ca.: t dimensions of the machine ca.: m Conveyor system consisting of: ALBA decoiler EHA-4-300 and elec.-hydr. Leveler RMS EM 2/6-120/45-300 B, year of manufacture 99 coiler: bundle weight 4000 kg, coil inside diameter 460-620 mm, External coil diameter 1600, dimensions 1500x1140x2300 mm, weight approx. 2000kg Straightening machine: feed rollers number 2 - diameter 120 mm, straightening rollers number 6 - diameter 45 mm, center distance 80 mm, take-off speed 5-20 m/ min, Deduction height above floor 1500 mm, dimensions 1100x740x1800 mm, weightapprox. 600 kg ARKU roll feed, Servomaster 300, year 94 passage width 300 mm, roller diameter 100 mm, max. cross-section 1000 mm², Material thickness 0.1-5mm, feed accuracy better than ...

material width:500 mm coil weight:2 x 2,0 t material thickness:1,0 - 6,0 mm coil internal diameter:350 - 420 mm coil external diameter:1600 mm no. of straightening rolls:9 straightening roll diameter:50 mm number of draw-in rolls:2 speed:0 - 40 m/min material thickness at 500 mm material width:3,5 mm power requirement:17,5 kW Dimensions (WxDxH):2,3 x 4,2 x 2,4 m straightening machine:RM 5050.4/9 double decoiler:AH 2000/2/M snubber roll:pneumatic interchangeable jaws:130 mm expansion of the inner diameter

material width:800 mm coil weight:12,0 t coil internal diameter:470 - 520 mm coil external diameter:1500 mm material thickness:0,4 - 2,5 mm no. of straightening rolls:8 straightening roll diameter:53 mm number of draw-in rolls:2 inlet roll diameter:160 mm speed:35 m/min material thickness at 150 mm material width:2,5 mm material thickness at 650 mm material width:1,5 mm material thickness at 800 mm material width:1,0 mm straightening machine:RM 8-53/160-800 decoiler:HE 200-1000

material width:250 mm coil weight:2,5 t coil internal diameter:430 - 520 mm coil external diameter:1650 mm material thickness:0,5-6 mm no. of straightening rolls:7 straightening roll diameter:60 mm number of draw-in rolls:2 weight straightener:1,2 t weight decoiler:1,4 t dimensions straightener (WxDxH):1,2 x 1,2 x 2,0 m dimensions decoiler (WxDxH):1,8 x 1,8 x 2,3 m expansion:hydraulic

material width:450 mm material thickness:1,0 - 14,0 mm coil weight:10,0 t coil internal diameter:470 - 520 mm coil external diameter:1100 - 2000 mm no. of straightening rolls:12 straightening roll diameter:2x70 / 2x96 / 8x127 mm number of draw-in rolls:2 inlet roll diameter:160 mm min. material width:100 mm speed:15 m/min power requirement:75,0 kW weight of decoiler:6,4 t weight of straightening machine:12,8 t dimensions decoiler (WxDxH):3,1 x 1,4 x 3,7 mm dimensions straightener (WxDxH):2,5 x 3,4 x 2,7 mm straightening machine:RMS-Vario-12-70/96/127-0450 infinitely variable drive:insert drive upper straightening part:hydraulic liftable loop bridge:hydraulic driven threading wedge:hydraulic decoiler:HES 12-650 infinitely variable drive:insert drive lag brake:pneumatic snubber roll:hydraulic; motoric driven expansion:hydraulic coil lifting device:hydraulic cropping shears:HS-150-0450

material width coil line:600 mm coil weight in kg:2 x 3000 kg coil internal diameter:460 - 630 mm coil external diameter:1500 mm material thickness coil line:0,5 - 3,0 mm Number of Straightening rolls:9 roll diameter:30 mm material cross-cut:1200 mm² weight:9,5 t Dimensions (WxDxH):4,3 x 2,6 x 2,6 m straightening machine:30.600/9 double decoiler:Kohler, 3000.2 ausiliary drive:hydraulic lag brake:pneumatic expansion:hydraulic snubber roll:hydraulic; motoric driven

pressure:200 t distance between columns:2900 mm stroke:800 mm dimensions of the machine ca.:3300 x 2700 x 3100 mm Table dimensions:2500 x 2000 mm :4000 mm :33 mm/sec :33 mm/sec distance table - lower edge of ram:1100 mm table height over floor:750 mm :2300 mm return capacity:25 t total power requirement:15 kW Oil Cooling:1 kW stroke speed:18 mm/sec down speed:2 - 10 mm/sec :200 l table plate:100 mm distance between columns:2400 mm open height:1000 mm weight:9 t Table Height:750 mm :34 Lt./min. Impact leper extension removable (200 mm long):550 ? Table top flattened, with or without T-slots:7900 ?

pressure:200 t distance between columns:1550 mm stroke:400 mm dimensions:ca. 4400 x 3250 x 4100 mm Table dimensions:1500 x 1500 mm distance table - lower edge of ram:1590 mm return capacity:20 t total power requirement:20 kW Oil Cooling:1,5 kW stroke speed:25 mm/sec down speed:10 mm/sec :250 l table plate:120 mm Table cut-out:550, 450, 350 und 200 mm table speeds:30 mm/sec

pressure:400 t distance between columns:2500 mm stroke:600 mm Table dimensions:2500 x 2000 mm distance table - lower edge of ram:600 mm total power requirement:18 kW speed of forward flow:9 mm/sec Return Speed:19 mm/sec :67 Lt./min. Total weight, approx.:26 t

pressure capacity max.:50 t

pressure capacity max.:25 t

Straightener, strip straightener with variable gear motor LENZE Type 11.712.02.10 Output speed gear motor 12 to 72 rpm infinitely variable Torque 80 to 40 Nm Straightening roller speed 19 to 115 rpm. Straightening roller width 520 mm Straightening roller diameter 90 mm Number of straightening rollers Total 4 pieces Motor power 0.37 kW Mains connection 380 Volt, 50 Hz - infinitely variable speed adjustment via handwheel on gear motor - Drive via open gear drive straightening rollers Upper part mechanically for adjustment - on stable metal substructure straightening machine was used for cardboard Space requirement L x W x H 630 x 460x 1060 mm Weight approx. 160 kg good condition; used

Equipment consists out of: 1 - Three decoilers 2 - Sheetholder with three levels 3 - Fasti straightening unit 4 - Fasti shear Transversal cut to length line / Querteilanlage / installation de coupe en longueur

Line consists out of: 1 - Double head decoiler: - cap: 25 ton - max length of coil: 2 meter - max diameter of coil: 3 meter 2 - Pre-leveller/straightening + edge slitting unit - 2 slitting heads are movable to slit the edges of the sheet - variable from 400 to 2000 mm wide 3 - Ungerer leveller/straightening unit - 6 + 7 rolls - for fine levelling/straightening - max thickness: 4 mm 4 - Schröder shear - max cap: 2050 mm - max thickness: 4 mm 5 - feed-out table + sheet storage Workwidth x sheetthickness: 2050 x 4 mm Straightner: yes Shear: yes

Capacity 10 tons Maximum band width 180 cm Pressure roller, etc. Complete documentation more info on request

Technical data: -Weight of coil: to 3. -Strip width: 600 mm -hydr. Spreading -2,2 kW geared motor with controller 380 V, 50 Hz. -Loop control arm start-stop -Electrical cabinet forward / backward / stop -Steel segments -Expansion 475-525 mm -Speed 0-25 m / min. Coil outer diameter. 1500 mm

Technical data: -Coil weight: 3.000 kg -Strip width: 1,000 mm -hydr. Spreading -2,2 kW geared motor with controller 380 V, 50 Hz. -Loop control arm start-stop -Electrical cabinet forward / backward / stop -Steel segments -Expansion 475-525 mm -Speed 0-25 m / min. -Coil outer diameter. 1500 mm

Capacity 20 kN, band width 500 mm, coil inner diameter 445-530 mm Coil outer diameter 1300-1400 mm Drive power 1.1 kW Rolling speed 16 U/min Manual spreading of the reel Crown with hydraulic unit complete documentation, operating instructions and manual

Loading capacity: max. 300 Kg. Coil outsite diam.: max. 1.000 mm Coil inside diam. 240 - 560 mm Coil width: max. 180 mm; good

Loading capacity: max. 2.000 mm Coil Inside diam. max. 1.000 mm Coil Outside diam. max. 1.200 mm Coil width: max. 500 mm

Loading capacity: max. 2.000 Kg. Coil Inside diam. max. 1.000 mm Coil Outside diam. max. 1.200 mm Coil width: max. 500 mm; ready for operation

Federal load - 1500 kg Federal width - 500 mm Outer diameter - Max 1250 mm Spreader range without attachment segments 310-460 mm, 410-560 mm High of lateral ditches. Strip lines approx. 470 mm Bc9eg37hb2 Speed of the reel shaft - 16 U / min, power 0,55 kW Manual spreading, adjustable -Torque limiter, soft start, - band drain brake -with push segments -hydraulically actuated process equipment â completely. Hydraulic unit mass - L 3300 B 1500 H 1500 mm

Material width: 0300 mm Coil weight: 0.5 t Coil inner diameter: 270-360 mm Coil outside diameter: 1000 mm Speed: m/min Weight: 0,4 t JAWS: 200 mm extension of the diameter

• Bandwidth / strip width: 1,600 mm • Strip thickness / strip thickness: 0.4 - 2.0 mm • Coil inner / coil inner-a:390-420 mm • Coil outer / coil outer-a: 1,500 mm • Spreading/ spreading: hydraulic/hydraulic • Motor drive AC servo cooling • For invertrers • Speed: 15 m/min. • Attachment segments for 500 mm • Reel shift: 200 mm • Working method: from top and bottom • Hydraulic valves on board

Load capacity - 1000 kg Outer diameter - max. 1200 mm Spreading range 550 - 750 mm Bandwidth max. 350 mm Spreading process - manual Reel drive - three-phase motor 400 V / 50 Hz Unwindspeed max. 30 m / min

Key data: 300 , 1 , 1300

Payload 1000 - 1250 kg Band width 305 and 505 mm Spreading range - 375 -520 mm Coil outer diameter 1300 mm without cabinet and control

Coil weight: 0 kg Material width: 0 mm Coil diameter maximum: 0 mm Technical data Max. loading capacity: 2X200 kg Voltage 50 Hz 3x: 230 Volt Driving motor (motor power): 0.74 kW Overall dimensions machine: Length: 1800 mm Width: 1000 mm Height: 1700 mm

Coil weight: 2 x 2 ton Material width: 310 mm Coil exterior diameter: 1300 mm Expansion range: 380 - 460 mm Weight of machine approx.: 2,5 ton

Coil weight: 2 x 500 kg Material width: 300 mm Coil exterior diameter: 1200 mm Expansion range: 350 - 610 mm Weight of machine approx.: 2,2 ton

Coil weight: 500 kg Material width: 41 mm Coil exterior diameter: 1.000 mm Expansion range: 250 - 500 mm Speed: 20 m / min Required power: 0,5 kW Dimensions L x W x H: 1.000 x 850 x 1.700 mm Weight of machine approx.: 200 kg

Double mandrela coil weight each side: 1 ton Material width: 200 mm Coil exterior diameter: 2.050 mm Expansion range: 350 - 640 mm Speed: 40 s.p.m. Required power: 5,2 kW Weight of machine approx.: 2,2 ton

There are two identical machines available, band thickness: 0.1-4mm, band width: 10-150mm, weight: 100kg, year of construction machine 1/ 2: 2000/ 2006.

Coil inner diameter 460 - 560 mm Coil outer diameter. Max. - 1500 mm Bandwidth - 350 mm Payload 2 t without drive, adjustable. Disc brake btto - 640 kg more info on request

YOC 2009 Payload 1500 kg Coil inner diameter from 470 - 630 mm Coil outer diameter. 1600 mm Speed 12 rpm Frequency Dimensions - cca 1.7 x 1.4 x 1.7 m Btto - 850 kg More info on request

Key data: 450 , 1 , 1400

Payload 1200 kg Width 450 mm Coil external diameter - up to 1400 mm Motor 1.5 kW Speed adjustable by frequency conversion Btto 500 kg
