deep hole drill used for sale

Mixed lot of new and used deep hole drills gemaess list

Deep Hole Drilling Machines Kramatorsk KJ1910 used machine but very good mechanical condition. Machine can be inspected in our warehouse in Gussago BS (Italy) Deep hole boring machine - heavy duty deep hole boring machine Kramatorsk KJ 1910 Year of manufacture 1986 Maximum boring diameter, mm 600 Maximum use of lenght mm 10000 (10 meters) Max 25 ton Spindle diameter hole mm 700, Main motor power, kW 85 Counter rotation motor is 95kW Machine overall dimensions, mm 25550 x 3000 x 2290 Machine weight, kg 83000 Mimu machine tools (Italy) machine tools

right / left Number of spindles 4 Slide stroke 800 mm Drilling area in steel St-60 Full drilling dia. 15 mm Boring dia. 20 mm Drilling method Single-lip drill

The machine is completely overhauled and is then as good as new! The machine gets a completely new electric satisam with our control system. Technical specifications Drilling process: ELB Number of drilling spindles: 1 Min. Drilling diameter 4 mm Max. Drilling diameter 30 mm Max. Drilling depth 600 mm with drilling diameter 4mm / with larger drilling diameters max. Drilling depth 1000 mm Max. Rapid traverse speed X + Z axis 4000 mm / min Max. Rapid traverse speed y-axis 2000 mm Travels X-axis horizontal approx. 700 mm Y-axis vertical approx. 300 mm Z axis designed for max. Drilling depth 1000 mm

Kramatorsk KJ 1910 10-meter boring depth - Heavy duty: 25-ton workpiece >>> NOTE: MACHINE IS IN OUR WAREHOUSE IN ITALY < < < Heavy duty: Max. work-piece weight 25 tons Spindle motor kW 85 Counter rotation motor 90kW Spindle hole diameter mm 700 Max. boring diameter, mm 600 Center height over the bed, mm 670 Max. work piece external diameter, mm 1300 Work piece length range on one-sided machining, mm 1000...10000 Work piece diameter range, mm: - in chuck of faceplate 200...1100 - in open rest 400...900 - in closed rest 200...630 - in round rest 250...550 Spindle speeds range, rpm 2...200 Machine overall dimensions, approx mtrs 31 x 3 x 2,3 Machine weight, kg 90000 (approx)

TBT M1-4-320 4-Spindle deep hole boring machine, gundrilling interesting price Mimu Machine Tools (Italy) - Note: in our warehouse Mimu Machine Tools (Italy)

Giana lathe mod. GFP14 - 710x 5300 - year 2007, control FAGOR GFP14

Kramatorsk Model KJ1910 serial number 1913 Swing Over Bed: 1600mm Maximum Workpiece Length: 6300mm Maximum Drilling Diameter: 991mm Spindle power: 125.00kW Spindle Speed: 1 - 320 RPM Infinitely Variable power Existing Additional Chuck workholding range: 200 - 1250mm diameter, workpiece weight capacity using two open roll supports: 60,000kg, size range in closed backrest: 200 - 800mm, size range in open backrest: 630 - 1380mm, pressure head speed range: .125 - 500 infinitely variable, pressure head spindle bore diameter: 182 mm, pressure head motor power: 75kW DC, headstock speed ranges: 3, pressure head speed ranges: 2 Machine Length: 22950mm Machine Width: 4375mm Machine height: 2670mm Weight: 101091kg Condition Good

3-spindle deep hole drill -without electrics- Year of construction 1998 / rebuilding 2014

Machine Details Warehouse number 1105-03722 Machine type Deep hole drilling machine Make IXION Type TL 500 SVA Year of construction 1985 Control type CNC Control CNC Bosch Alpha Storage location HAGUENAU Country of origin GERMANY Delivery time immediately Freight base from stock Technical details Core drilling diameter - max. 1.5 - 18 mm Drilling depth 600 mm Clamping table, rigid 700 x 1,350 mm Clamping surface of the rotary table 1,000 x 500 mm Longitudinal movement of the table 600 mm Table displacement in drilling direction 400 mm Table rotatable 180 ° Vertical adjustment of the drill carriage 250 mm Drilling unit swivel +/- 15 ° Spindle cone MK 3 Number of speeds 8 Speed range 240 - 2,400 rpm Control CNC Bosch Alpha Motor power 1.0 / 1.6 kW Total power requirement 10 kVA Machine weight approx. 1.35 t Space requirement approx. 2.0 x 1.5 x 1.8 m Infor ...

Sell a TBT quill block, Condition new. Pinol block has never been installed. Original price is 30.800,00 Euro net. .VB

Continuous/normal drilling capacity 18/20 mm Threading capacity M12 (depending on pitch) Lockers MK II Drilling depth 100 mm Projection 240 mm Column diameter 82 mm Usable work surface W x L 340 x 280 mm T-slot size (arm), distance (mm), dimension width (mm) Number 2, 125, 13/26 Speed indicator: Digital Drilling depth indicator: Digital Drilling depth stop: quickly adjustable stop ring Manual drill feed Table height adjustment with rack Motor three-phase current – frequency-controlled, 230 V, 0.75 kW Spindle speeds infinitely variable 30 – 3000 1/min Table work surface: 155 - 415 mm Footwork: 155 – 550 mm Machine dimensions: 355 x 705 x 1065 mm Weight: 170 kg Optional accessories: Drill package 3: with [felix] 2.0 100 Machine vice Flott [felix] 100, Quick-change drill chuck 3-16 mm (accuracy 0.17 mm), Kegeldorn MK 2 B18 and reducing sleeve MK 2 to Mk 1 � ...

Specifications Power: 129kW Control: Siemens NC control Speed range (stepless): 2 - 300 rpm Feed range (in steps): 3 - 4500 mm/min Capacity oil plant: 20,000 liters Maximum flow rate: 1500 l/min Swing diameter in bezel: 1100mm Swing diameter over bed: 1250mm Center distance: 11000mm Clamping diameter face plate: up to 1100mm Max. workpiece weight with one setting stick: 10t Clamping range of the two bezels: 150 - 1100mm Clamping range BOZA: 1 = 200 - 400mm 2 = 400 - 800mm Dimension Min. outer diameter: 406 mm Max. outer diameter: 850mm Wall thickness: 10150mm Max. workpiece length: 11000mm Max. workpiece weight: 10 t Max. strength: 800 N/mm² Specific cutting resistance (Ks): 20002100 N/mm² Machine data Machine length: 28.800mm Center height: 560mm Swing diameter over bed: 1120mm Solid drilling diameter: 200mm Core drilling diameter: 350mm Boring d ...

Ref. -No.: 10142 Manufacturer: TIBO Year of construction: 2002 Type of control: CNC Control: Siemens Sinumerik 802D Storage location: Halberstadt Country of origin: Deutschland Drilling diameter: 1-13 mm Bore Depth: 250 mm Drilling spindle speed: 11.000 RPM X-Travel: 300 mm Y-Travel: 210 mm Z-Travel: 250 mm Machine weight: 2,5 t Further information: - With equipment

Drilling diameter 3-25 mm in ELB Drilling depth in one stroke (mm) 810 with resetting 1,200 Tapping up to M20 – larger by milling Manual tool changer Spindle holder SK 40 altv. HSK 63 Drive power 5.5 kW / ED 100 Travel X (longitudinal) 1,050 mm Travel Y (vertical) 800 mm Table load up to 2,500kg Table size 1,000 x 1,500 mm CNC rotary table 0-360° manual

Max Drilling diameter : 46 mm Max Drilling depth: 1000 mm Table dimensions: 1200 x 700 mm x mm Spindle speed 4000 rpm Spindle power: 7.5 kw

machine ready for transport and to be assessed on viewing day

Inv. Num. : 7365 Type: B3N-6000 Producer: TBT Tiefbohrtechnik Created: 1991 Parameters: Control system: Siemens Maximum turning diameter: 8.5-63.5 mm Spindle power: 270 kW Bed length: 17000 mm Maximum drilling length: 8000 mm

MECOF CS 88 G CUTTER - INSTALLATION YEAR 1990 - SELCA 4045 D steering unit - remote handwheel - x-axis stroke 6300 - Y-axis stroke 950 - Z-axis stroke 1800 - table 8000 x 1000 -n 2° screwed cubes 1500x1000 - spindle motor power 18 Kw - spindle speed 10-1600 with 2 ranges - spindle attachment ISO 50 DIN 2080 - indexed front platform rotation 1 degree - supplied with manual bi-rotary head ISO 50 DIN 2080 connection - fence with gates equipped with microswitch only on 2 sides

The deep hole drilling machine is in very good condition! Deep hole drilling machine type TBM 120-2000 BTA drilling system Drilling range full drilling 30-130 mm Max. boring 200 mm B8Uwbfcphz Max. drilling depth 2000 mm Drilling spindle box with two-stage gearbox electr. Switchable. Optionally rotating / standing tool Main spindle box ( tailstock ) with two-stage gearbox electr. switchable Tailstock with counter-rotation Optionally with or without counter-rotation Hydr. Cheek chuck We will be happy to send you more pictures on request. We also see ourselves as a competent partner in the field of deep hole drilling in contract work. We would be happy to make you an offer!

Key data: 30 mm, 1500 mm, 1

Deep hole drilling machine SIG

Drilling method ELB Full drilling 4-33mm Drilling depth max 737mm Spindle antrib 7,5 kw Spindle speed 550-6400rpm Working feed 35-320mm/min Rapid traverse 3500mm/min Coolant High Pressure Pump, Paper Filter, Chip Conveyor, Magnetic Separator Connection 20 KW Dimensions 4100 x 1650 x 1850mm Weight 3500 KG

Boring power: 70-550 mm bore depth: 10000 mm table load: 10 t turning speeds: 35-92 + 92-595 U/min transmission ratio: 2 clamping diameter max.: 1000 mm workpiece weight: 10000 kg chip conveyor: coolant: total power requirement: 37 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

core drilling diameter max.: 50-355 mm bore depth: 4000 mm swing diameter: 1000 mm centre height: 500 mm full boring: 18-100 mm main spindle bore: 163 mm turning speeds: 56-710 U/min workpiece weight: 6,3/10 t Tailstock: 70-600 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Drill pipes, guide block, drill head, rolling steady rest, support bearing drill heads, jaws 21- 240 mm, Holder, tools, shelves, cupboards The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

core drilling diameter max.: 50-600 mm bore depth: 6000 mm table load: 6 t turning speeds: 50-600 U/min clamping diameter max.: 650 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Deep Hole Drills, Gun Drills with Internal Cooling GÜHRING ZL-TLB-1-R U ZFX 54,02 20 diameter: Ø 8.0 mm Total length: 700 mm groove length: 620 mm Shank diameter: Ø 25 mm Shank length: 80 mm New ! Dimensions: 700 x 25 x 25 mm

Deep hole drills, gundrilling drills with internal cooling PAGUS TBT Ø 10,000 15 x 480 ( TBTØ10,15x480 ) K15 C40 51/07 Diameter: Ø 10,15 mm Total length: 490 mm Groove length: 400 mm Shank diameter: Ø 16 mm Shaft length: 50 mm New ! Dimensions: 490 x 16 x 16 mm

A Heyligenstaedt deep-hole drilling machine is available. Speed: 1120 rpm, turning diameter: 282 mm. The wedge bar chuck is of high quality and relatively new. An on-site inspection is possible.

Travel X/Y/Z: 700mm/300mm/1000mm, rapid traverse X/Y/Z: 4000mm/4000mm/2000mm /min, drilling method: ELB, number of drilling spindles: 1, min./max. drilling diameter: 4mm/30mm, max. drilling depth: 1000mm, table dimensions X/Y: approx. 850mm/750mm.

core drilling diameter max.: 18 mm bore depth: 320 mm swing diameter: mm total power requirement: 33 kW weight of the machine ca.: 6 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

core drilling diameter max.: 25 mm bore depth: 1000 mm swing diameter: mm total power requirement: 25 kW weight of the machine ca.: 12,5 t dimensions of the machine ca.: m T B T (Germany) CNC-Controlled Horizontal Deep Hole Drilling Centre Model BWP 250 Year 1996, but reconditioned mechanically and electrically in 2006 ______________________________________________________________________ _____________ Working range: X Axis, machine column cross 2,000 mm Z Axis, drilling slide horizontal 1,200 mm Drilling depth 1.000 mm Y Axis, drilling slide vertical 1,100 mm Table clamping area 1,200 x 2,000 mm Drilling capacity in solid material, approx. 4 - 25 mm Tool holder taper HSK 50 Spindle speeds 1.260 - 15,000 rpm Feed rates / quickfeed, XYZ, infinitely variable 100 - 10,000/15.000 mm/min. Force rate of feed  ...

core drilling diameter max.: 50 mm bore depth: 2000 mm swing diameter: mm drilling capacity diameter max.: 110 mm total power requirement: 30 kW weight of the machine ca.: 10 t Drilling Ø, approx. 2 - 50 mm Boring Ø, approx. 100 mm Drilling depth, max. (see stroke / mounting length) 1,600 - 2,000 mm Stroke of drilling slide, approx. 4,000 mm Distance between the two spindle heads 5,000 mm Height of centres above guideways 350 / 450 mm Drilling feed of drilling slide, infinitely variable 20 - 200 mm/min Quick feed of drilling slide 2,500 mm/min Spindle speeds via belt disks 260 - 650 / 650 - 1,625 rpm Workspindle drive 24 kW Drive of coolant pumps 1 x 7.5/15 kW and 1 x 15/28 kW Total electrical load, approx. 60 kW - 380 V - 50 Hz Total length of machine / guideways 7,500 / 5,000 mm Weight, approx. 10,000 kg Accessories / Special Features Machine consists of the following elements:  ...

(showroom machine) Main Technical Data Number of Spindles: 4 spindles Gundrilling Diameter Range: 4 - 20mm Working Method of Tool: Rotating Working Method of workpiece: Rotating Clamping Method: Clamping Cone Max. Drilling Depth: 800mm Workpiece Max.Outer Diameter: 300mm Drilling Feedrate: 1-180mm/min Spindle Center Height: 220mm Spindle Distance: 158.75mm Control System: SIEMENS 828Dsl A.C. Spindle Motor Power: 2×15 kW Spindle Speed (Infinitely Variable): Max.5000 RPM Tailstock Spindle Speed: 70rpm Rapid Traverse Speed: 6000mm/min High Pressure Pump Motor Power: 4×7.5 kW Coolant Flow Rate: 4×46 L/min Filter accuracy: 20µm Max.Coolant Pressure: 100 bar Oil Tank: 1200L Weight of Machine: 10000 Kg. Electrical Supply:  ...

The machine is completely overhauled and therefore as good as new! Technical data Drilling method: Lip drilling Number of spindles 1 Drilling range in steel D= 1-6 mm Drilling depth 400 mm Max. workpiece length 400 mm Manufacturer: TBT / SFT New electrics and new CNC control Siemens! We see ourselves as a competent partner in the field of deep hole drilling. You are also welcome to send us inquiries in the contract processing of deep hole drilling work.

Technical data: - min . Drilling diameter 16 mm - Max. drilling diameter 35 mm - Boring diameter 65 mm - Max. drilling depth 1,400 mm in the ELB / BTA method - Machine space requirement approx. 6100 x 3100 mm - max. height of the machine 2400 mm - 2 separate drilling units, built on a basic machine bed spindle spacing 600 mm - Flat web guides - Feed drive via ball screw and feed gear - Rapid traverse speed 4000 mm/min. - Feed speed max. 230 mm/min. - Drive power 2 pieces drilling spindle 11 kw - Speed infinitely variable max. 6000 rpm - Hydr. Attachable tailstock with counter-rotation - Tailstock can be moved manually on base plate with length grooves - Cladding with sliding doors - 1 piece of bezel each - 1 piece each rotating tension bell holder Basic recording - 2 pieces of pre-centering each - Drilling depth control via cam and limit switch - CNC control SFT and  ...

Year of construction 2000 Control Siemens CNC 840D Drilling capacity 2.8 - 25 mm max. drilling depth 700 mm Clamping table 600 x 800 mm with hole grid Drill carriage: torque 20 Nm Travel distance 1000 mm Feed rate 0 - 15,000 mm Coolant frequency-controlled Ring Compact Filter 120l/min Accessories: Cantilever belt conveyor Weight approx. 3000 kg

: 414312067 voltage: 380 V frequency: 50 Hz rated capacity: 13 kVA The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

WORKING RANGE, Longitudinal (X) 1250 mm, Vertical (Y) 1000 mm, Transversal (Z) thread axis 380 mm, Drilling depth (V) 1000 mm, Drilling head inclination ( C) +/-20 °, Table rotation (B) 360,000x0.001 °, Workpiece approach (W) 500 mm, CNC, Measuring system optical scales, CNC SELCA 4040D, DRILLING UNIT, Min-max diameter from solid 5-40 mm, Spindle power 10 Kw, Rotation speed 4.200 Rpm, Drilling type gundrill, Drilling head inclination ( C) 40 (+/-20) °, FEEDS, X rapid 10 m/min, Y rapid 10 m/min, Z rapid 10 m/min, V rapid 10 m/min, TABLE, Surface 1000x800 mm, Resolution (B axis) 0.001 °, Tilting +/- 22,5°, Capacity 4.000Kg / d, COOLANT SYSTEM, Tank capacity 650 l, EXTRA, Total installed power 30 Kw, Machine weight 17.500 Kg, Machine dimensions 5000x2600x3300 mm, Information about technical data are not binding., Machine available subject to prior sale.

Key data: 80 mm, 1500 mm

Stock number: 4025 Full boron capasitet 10-80 mm Drilling depth 1500 mm Max. workpiece 500 mm Total power 67 kW Accessories: Tool Holder Pcs Length: 6500 mm, Height: 2000 mm, Width: 2100 mm, Weight: 8500 kg

Drilling diameter: 3-25mm, drilling depth: 1000mm, connected load: 36kW, control: EST, 99 drilling memory positions per program, grinding and coordinate programming, plain text programming via input mask. Accessories: paper band filter, coolant cooling system, 4-door control cabinet, high-pressure pump up to 150bar, oil tank, 1 steady rest for smaller diameters at large drilling depths, direction-adjustable holder for drill bushing holders, various drill bushing holders, long clamping table for 0-height, tailstock stop and base plate for machine vice freely movable on the additional table, matching precision machine vice optionally available. Speed, high pressure, Z-axis (feed), X/Y-axes, and W-axis (approach slide) programmable via control. CPU and card rack defective (fan fault), machine therefore not operational, drives and guideways were fully functional until last operation. An on-s ...

WORKING RANGE, Longitudinal (X) 1250 mm, Vertical (Y) 1000 mm, Transversal (Z) thread axis 380 mm, Drilling depth (V) 1000 mm, Drilling head inclination ( C) +/-20 °, Table rotation (B) 360,000x0.001 °, Workpiece approach (W) 500 mm, CNC, Measuring system optical scales, CNC SELCA 4040D, DRILLING UNIT, Min-max diameter from solid 5-40 mm, Spindle power 10 Kw, Rotation speed 4.200 Rpm, Drilling type gundrill, Drilling head inclination ( C) 40 (+/-20) °, FEEDS, X rapid 10 m/min, Y rapid 10 m/min, Z rapid 10 m/min, V rapid 10 m/min, TABLE, Surface 1000x800 mm, Resolution (B axis) 0.001 °, Static capacity 4.000Kg / dynamic 8.000 Kg, COOLANT SYSTEM, Tank capacity 650 l, EXTRA, Total installed power 30 Kw, Machine weight 17.500 Kg, Machine dimensions 5000x2600x3300 mm, Information about technical data are not binding., Machine available subject to prior sale.

FUJII SEIKI Heavy Duty Lathe (Japanese Origin) Technical Specifications: • Turning length: 2,000 x 26,000 mm • Modular bed • Capacity between centers: 60 tons • Drilling attachment included • Drilling tool length capacity: 12,000 mm Condition: Available Location: South America Machine suitable for heavy-duty machining of long shafts and large industrial components.

IXION AUERBACH TL 1004 deep hole drilling machine was built in 2004 in Germany by Ixion Auerbach Maschinenfabrik GmbH. The machine is designed for precision drilling of deep holes with a maximum depth of 1000 mm. Workpieces made of various types of material are machined fully automatically by means of precisely guided tools, which keeps the hole perfectly straight. All machining parameters are programmed in an advanced control system with many useful functions. The offer also includes an extensive equipment, consisting of, among others, a measuring probe, gun drills and a chip conveyor. The IXION TL1004 deep hole drilling machine weighs 3500 kg. Technical specifications of the IXION AUERBACH TL 1004 deep hole drilling machine - maximum drilling depth: 1000 mm - maximum hole diameter: 32 mm - minimum hole diameter: 6 mm - drilling capacity in 1.2312 steel (carbide gun drill): fi 25 ...

of various diameters and lengths approx. 100 pieces, approx. 1,300 mm long Auction-ID: A1-44702-153

Coolant system with belt filter, chip conveyor, control Heidenhain Auction-ID: A1-44702-119

full boring: 150 mm bore depth: 13000 mm full boring: 150 mm workpiece weight: 80 t control: Siemens type: S 7 workpiece dia.: 1250 mm 0: 2000 mm borehole diameter: 450 mm total power requirement: kW weight of the machine ca.: 160 t dimensions of the machine ca.: m Headstock adjustment 10,000mm Headstock bed bed width 1600mm, guideway width 360 Center height of headstock 1600 mm Face plate 1750 mm Drive 60 KW Speed 2.62-200 rpm Bed for drilling unit Bed length 27,000 mm Bed width 1320 mm Guideway width 290 mm height of the bed 670 mm Drill motor 60 KW Drilling unit Sph 920 mm The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories ...

machine ready for transport and to be assessed on viewing day Auction-ID: A1-44905-73

IXION TL 500 SVA Deep Hole Drilling Machine Manufacturer: IXION Model: TL 500 SVA Year of Manufacture: 1985 Serial Number: 113178 Origin: Germany Drilling Capabilities: Drilling diameter: 1.5 – 18 mm Advertised drilling depth: 600 mm Table and movements: Fixed table: 700 × 1,350 mm Circular tabletop: 1,000 × 500 mm Longitudinal stroke: 600 mm Stroke in the direction of drilling: 400 mm Swivel table: 180° Drilling unit: Vertical carriage stroke: 250 mm Unit orientation: ±15° Spindle Taper: CM3 Spindle and control: Number of speeds: 8 Speed range: 240 – 2,400 rpm CNC Control: Bosch Alpha Digital display: Heidenhain 3-axis Power and Size: Engine power: 1.0 / 1.6 kW Installed power: 10 kVA Dimensions (L × W × H): 2,000 × 1,500 × 1,800 mm Weight: approx. 1,350 kg Auction-ID: A1-44765-265

CNC Deep Hole Drilling Machine Shinil (Korea) Year: 2009 Control: Fanuc Oi-TD Key Technical Specifications • Drilling diameter (solid): Ø 50 – 200 mm • Counter boring max: 500 mm • Trepanning max: 500 mm • Max drilling depth: 6000 mm (6 meters) Workpiece & Motion • Z-axis stroke (tool free): 6000 mm • Work spindle stroke (max): 4000 mm • Z-axis rapid feed: 5000 mm/min • Z-axis cutting feed: 0 – 1000 mm/min • Control axis: Z-axis CNC controlled Spindle & Speed Range • Headstock rotation: 5 – 30 rpm • Tool holder spindle speeds: • 50 – 500 rpm • 25 – 250 rpm • 16.6 – 166 rpm • 8.3 – 83.3 rpm Cooling & Drives • Coolant pump control: Inverter-driven • Motor control: NC controlled spindle & tool rotation Power & Installation • Total power: approx. 335 kW • Power supply: AC 440V / 60Hz  ...

IXION TL 500 SVA Deep Hole Drilling Machine Manufacturer: IXION Model: TL 500 SVA Year of Manufacture: 1985 Serial Number: 113178 Origin: Germany Drilling Capabilities: Drilling diameter: 1.5 – 18 mm Advertised drilling depth: 600 mm Table and movements: Fixed table: 700 × 1,350 mm Circular tabletop: 1,000 × 500 mm Longitudinal stroke: 600 mm Stroke in the direction of drilling: 400 mm Swivel table: 180° Drilling unit: Vertical carriage stroke: 250 mm Unit orientation: ±15° Spindle Taper: CM3 Spindle and control: Number of speeds: 8 Speed range: 240 – 2,400 rpm CNC Control: Bosch Alpha Digital display: Heidenhain 3-axis Power and Size: Engine power: 1.0 / 1.6 kW Installed power: 10 kVA Dimensions (L × W × H): 2,000 × 1,500 × 1,800 mm Weight: approx. 1,350 kg
