decoiler used for sale

Description: Max. Coil weight: 114 kg Max. Coil outer diameter: 762 mm Max. Material width: 152 mm Center diameter: 229-508 mm Maximum speed: 80 rpm weight approx.: 318 kg, Approx. Onsite Dimension. (l x w x h): 1,350 x 850 x 1,600 mm

Description: Diameter : 340 mm Clamping range: max 180 mm Material width: max 370 mm right and left rotation Manual spreading weight approx.: 488 kg, Approx. Onsite Dimension. (l x w x h): 1,450 x 1,000 x 1,100 mm

Description: Diameter : 510 mm Clamping range: max 160 mm Material width: max 500 mm Operating voltage: 220/380 V, 50 Hz power supply: 220 V weight approx.: 900 kg, Approx. Onsite Dimension. (l x w x h): 1,550 x 1,450 x 1,160 mm

Description: connected load: 400V max. coil width: 600mm mandrel diameter: 80mm weight approx.: 183 kg, Approx. Onsite Dimension. (l x w x h): 1,660 x 800 x 830 mm

Description: Inner diameter: 220 mm Inner belt width: 200 mm Load capacity per reel: 150 kg (reel must be bolted to the floor) , Incl. wiring diagram weight approx.: 450 kg, Approx. Onsite Dimension. (l x w x h): 1,240 x 1,120 x 2,200 mm

Description: Diameter : 300 mm Clamping range: max 180 mm Material width: max 530 mm right and left rotation Manual spreading weight approx.: 664 kg, Approx. Onsite Dimension. (l x w x h): 1,250 x 800 x 1,300 mm

Coiltech Decoiler and Feeder It is like new, only 1 month used Carrying capacity : 2500kg Steel width capacity : 40-400mm Steel thickness capacity : 0,5-5,0mm More details : https://www.coiltech.tr/ana-sayfa---eng.html

Decoiler / Recoiler / Rewinder Main chuck and counterpoint mounted on T-slot table Counterpoint is movable Main chuck can turn clockwise and anti-clockwise Variable speed Max distance between centers: 1900 mm Length : 4800 mm Wide: 1400 mm Hight: 1350 mm

Decoiler / Recoiler / Rewinder Main chuck and counterpoint mounted on T-slot table Counterpoint is movable Main chuck can turn clockwise and anti-clockwise Variable speed Max distance between centers: 1900 mm Length : 4800 mm Wide: 1400 mm Hight: 1350 mm

Line consists out of: 1 - Double head decoiler - max cap: 15 ton - max length: 1600 mm 2 - Edge slitting unit - variable width: 200 gt; 1500 mm - max thickness: 3 mm - including two scrap rewinders Max sheetwidth: 1500 mm Sheetstrip thickness : 3 mm

sheet width - max.: 0600 mm coil weight: 3,00 t coil internal dia.: 465 - 530 mm total power requirement: kW weight of the machine ca.: 2,45 t dimensions of the machine ca.: 2,72 x 1,70 x 2,40 m material width (previously) 400 mm mandrel length 630 (655) mm mandrel – Ø (expanding range) 465 – 530 mm height floor - middle of mandrel 1.450 mm height upper edge decoiler construction - middle of mandrel 1.050 mm working direction (previously) right - left accessories: construction 3-segment-construction decoiler movable on base frame hydraulically press arm hydraulically press roll not driven expanding process mechanically decoiler motor driven (via chain) power 3,0 kW no. – limiting arms 6 dimension – limiting arms (l x h) 410 x 180 mm valve components mounted at decoiler construction control unit (breaker unit) with cable hydraulic unit not available The data for this ad was cre ...

CINCINNATI ACW6 slitting line is used in the processing of thin steel sheets with a maximum thickness of 4 mm. The process consists in gradually unrolling the sheet coils towards cutting rollers with special roller knives with a thickness of 5 to 30 mm, and then passing the sheet between the rollers for precise slitting. After the slitting process, the sheet is wound onto coils ready for further processing. The ACW6 slitting line guarantees the highest product quality while making optimum use of the raw material. The CINCINNATI coil slitting line consists of: – sheet decoiler – sheet metal winder – roller knives (thickness 5 mm, 10 mm, 12 mm, 20 mm, 25 mm, 30 mm) – ejector spacers (width 10 mm, 12 mm, 20 mm, 25 mm, 30 mm) – slitting aggregate unit – brake Technical specifications of the CINCINNATI ACW6 slitting line - maximum sheet thickness: 4 mm - minimum shee ...

Straightening machine, wire straightening machine, decoiler Straightening machine combination, decoiler, wire decoiler -Wire straightener: combination of decoiler and straightener -Type: unfortunately no type designation / techn. documentation -Motor: Fukota 1.5 kw -Straightening rollers: for Ø 20 mm, see photos -Take-up rolls: Ø 152/215 x 1330 mm -Total dimensions: 3040/2450/H2525 mm -Weight: 2080 kg

Pivatic perforating and bendingline Line is manufactured 1999 and it has worked very well for us 20 years. Line is bending line with perforation unit and single press unit 35 tn. In line is separate punching unit so you can perforate material and cut it to separate ballet. Also you can use separate press toll in line. This press unit we have not used, because we other presses. FORSTNER coil cradle Weingarten Decoiler Dimeco Coil feeding line decoiler - straightener feeder Automatic Flexible punching and rollforming line for C and sigma profiles with centralized adjustment”, from Dimeco (Spain), installed/commissioned in 2019 Dimeco Coil feeding line PIVATIC coil punching line FIMI Slit Coil Decoiler and reel winder tunçman Extrusion - Single screw extruder LEMO INTERMAT Thermoforming - Automatic Roll-Fed Machine Uhlmann Blister machine Accela-Cota 170 l Tablet c ...

Pivatic perforating and bendingline Line is manufactured 1999 and it has worked very well for us 20 years. Line is bending line with perforation unit and single press unit 35 tn. In line is separate punching unit so you can perforate material and cut it to separate ballet. Also you can use separate press toll in line. This press unit we have not used, because we other presses. FORSTNER coil cradle Weingarten Decoiler Dimeco Coil feeding line decoiler - straightener feeder Automatic Flexible punching and rollforming line for C and sigma profiles with centralized adjustment”, from Dimeco (Spain), installed/commissioned in 2019 Dimeco Coil feeding line PIVATIC coil punching line FIMI Slit Coil Decoiler and reel winder tunçman Extrusion - Single screw extruder LEMO INTERMAT Thermoforming - Automatic Roll-Fed Machine Uhlmann Blister machine Accela-Cota 170 l Tablet c ...

material width:300 mm coil weight:2 x 1,25 t material thickness:0,4 - 1,2 mm coil internal diameter:320 - 420 mm coil external diameter:1300 mm no. of straightening rolls:9 straightening roll diameter:30 mm number of draw-in rolls:2 roll diameter:30 mm speed:3 - 30 m/min feed length:0 - 9999,9 mm power requirement:3,0 + 2,5 kW weight of decoiler:0,7 t dimensions decoiler (WxDxH):2,1 x 1,4 x 1,5 mm weight of straightening machine:0,45 t dimensions straightener (WxDxH):1,5 x 0,8 x 1,1 mm weight of the feeder:0,4 t dimensions feeder (WxDxH):1,2 x 0,8 x 1,1 mm universal straightening machine:SC 12-FQ double decoiler:2352 B-FPS expansion:hydraulic lag brake:pneumatic electronic roll feed:WAV-RDS-2Z, Modell 1082 B intermittant lifting:pneumatic control:Siemens S 5

material width:600 mm coil weight:5,0 t material thickness: - 5,0 mm coil internal diameter:360 - 660 mm coil external diameter:1500 mm no. of straightening rolls:9 straightening roll diameter:80 mm number of draw-in rolls:2 material cross-cut:1600 mm² weight of feeeder-straightener:2,5 t weight of decoiler:1,5 t dimensions feeder-straightener (WxDxH):1,7 x 1,7 x 2,6 mm dimensions decoiler (WxDxH):1,8 x 2,0 x 2,3 mm feeder-straightener:VCRL 650, Bj. 1994, GR 2001 height adjustment:motorisch alligator opening:hydraulisch decoiler:SHR 5000, Bj. 2000 expansion:hydraulisch

material width:500 mm coil weight:3,0 t material thickness:0,2 - 2,5 mm coil internal diameter:470 - 530 mm coil external diameter:1400 mm no. of straightening rolls:9 straightening roll diameter:40 mm number of inlet and outlet rolls:4 material cross-cut:1200 mm² speed:1,5 - 30 m/min dimensions decoiler (WxDxH):1,9 x 0,6 x 1,7 m weight decoiler:1,1 t dimensions straightener (WxDxH):3,3 x 1,3 x 2,7 m weight straightener:3,0 t straightening machine:RYD 40 x 500 decoiler:DY 500 x 3000 coil lifting device:hydraulic rool feed:elektronic; AESL 500-2,8 threading device:hydraulic expansion:hydraulic

Standing seam metal roof machine F3 Standing seam metal roof machine F3 with length measuring device was designed by our company to produce standing seam roofing panels for the installation of roofs and facades of various buildings and structures. Sheet metal blanks are passed through the forming rolls of the machine to get the desired shape of the standing seam panel. This method of production allows you to produce panels with a speed of about 10 meters per minute and fit any roofing companies. The machine is equipped with an easy width adjustment system, so it takes just a few minutes to readjust it from rolling one width to another. The F3 machine can work with panels from 200 to 700 mm wide. It is possible to work with metal sheets and coils made of galvanized steel, copper, zinc, aluminum, stainless steel, etc. Maximum metal thickness for work – 0.8 mm. Standing s ...

Technical data: Bandwidth / strip width min. 150mm Bandwidth / strip width max. 1,650 mm Strip thickness min. 0.4 mm Strip thickness max. 400 N/mm² 2.5 mm 300 N/mm² 3.0 mm Coil weight decoiler/ coil weight decoiler 12,000 kg Coil outer Ø / coil outer-Ø 1,600 mm

The Coiltech Decoiler Straightener Feeder System is a compact press feeding system. Belt width: 600mm, material thickness: up to 6.5mm, straightening rollers: 7x115mm, decoiler tonnage: 6000kg, diameter (inner), min-max: 470-520mm. Connected load: 7.5kW, with documentation.

Working width: 2000mm, max. sheet thickness: 13mm, can be used horizontally and vertically, with decoiler, decoiler driven and hydraulically adjustable to coil diameter.

sheet width - max.: 0340 mm coil weight: 1,00 t coil internal dia.: 265 - 565 mm total power requirement: kW weight of the machine ca.: 0,25 t dimensions of the machine ca.: 1,40 x 1,20 x 1,80 m construction: support segment – system no. - support segments 3 length – suppert segments 400 mm working direction left-right / right-left counter ring – Ø 1.600 mm shaft – Ø 70 mm height floor - middle of shaft 840 mm accessories: construction - pedestal construction - rectangular tube positioned under decoiler construction, to proceed the relocation by forklift or similar expanding process manually by bevel gear wheel brake system disc brake brake caliper pneumatically, manufacturer TWIFLEX counter ring 2 pc. option: decoiler equipped with shifting frame (by linear guiding) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Double reel, reel, decoiler, motorized reel for sheet metal processing, punching, eccentric press, hydraulic press, automatic punching machine, motor reel, winding reel, decoiler, sheet metal unwinder -Manufacturer: OBRU, reel height adjustable, with drive -Diameter / width: adjustable, see photos -Dimensions: 750/730 / H1130 mm -Weight: 114 kg

Double reel, reel, decoiler, motorized reel for sheet metal processing, punching, eccentric press, hydraulic press, automatic punching machine, motor reel, winding reel, decoiler, sheet metal unwinder -Manufacturer: OBRU, reel height adjustable, with drive -Speed: 17 rpm -Dimensions: 800/700 / H1140 mm -Weight: 125 kg

Description: AMBROGIO GALLI 40 GAMMA Eccentric Press Line Includes : - n.1 AMBROGIO GALLI 40 GAMMA Eccentric Press Pressure 40 TON Min/max stroke 9/100 mm No. of strokes 80/210 Motor power 2/6 HP Table size 750x450 mm Press size 1500x1500x2900 mm - ISOTEC soundproof cabin Dimensions 1900x1800x3100 mm - n.1 ELMEA decoiler Model SC18A71 production year 1972 Maximum coil size 300 mm Reel holder size 1600x1000x1600 - ELMEA decoiler Model MS10A production year 1997 maximum coil size 300 mm Reel holder size 1500x1300x1600 - Exit conveyor - Electrical panels for press - Protective grills NOT INCLUDED IN THE ITEM NOT INCLUDED : - N.2 feeders for eccentric press - N.1 control/vision for feeders , - No. 1 BRANKAMP process control system - N. 1 packaging exit conveyor weight approx.: 10,000 kg, Approx. Onsite Dimension. (l x w x h): 10,000 x 4,500 x 3,500 mm

band width:1050 mm plate thickness:8 mm number of rolls:8 DECOILER:. - design : single coil :. - sheet width max:1050 mm - sheet width (min):150 mm - max. weight of coil:22 to - max. diameter of coil:2000 mm - min. internal diameter of coil:570 mm FEEDERS:. - feeder: type : roll feeder :. - sheet width max:1050 mm - sheet thickness max:150 mm LEVELER UNIT:. - sheet width max:1050 mm - sheet width (min):150 mm - sheet thickness max:8 mm - sheet thickness (min):2.5 mm - number of leveler rolls:8 - diameter of leveler rolls:96 mm - distance between leveler rolls:104 mm - diameter of feed rolls:160 mm - feed velocity min.:2 m/min - feed velocity max.:43.5 m/min ELECTRICAL SPECIFICATIONS:. - mains voltage:400 V - mains frequency:50 Hz Technical description : Sheet metal unrolling and straightening system for thick sheet metal up to 8 mm, consisting of: - LAWECO COIL LOA ...

PRESS DESIGN   drive system: eccentric / crank   frame design: H-frame, monoblock   openings in uprights: yes   number of suspensions: 2   opening in table: yes   feedstock transport direction: left to right PRESS FORCES   total force (nominal): 350 to   nominal work capacity: 50 kNm PRESS TABLE   table surface (left-right): 1550 mm   table surface (front-back): 1300 mm   thickness of bolster plate: 250 mm   opening in bed (left-right): 1300 mm   opening in bed (front-back): 350 mm SLIDE   table surface (left-right): 1400 mm   table surface (front-back): 1100 mm   stroke: 200 mm   stroke rate (max.): 100 /min SLIDE (MECHAN. PRESS)   slide adjustment: 150 mm   stroke min.: 20 mm   stroke ma ...

CONTROLS   PLC SIEMENS S7 PRESS DESIGN   drive system: knuckle-joint   frame design: H-frame, monoblock   openings in uprights: yes   number of suspensions: 2   feedstock transport direction: left to right PRESS FORCES   total force (nominal): 315 to   nominal work capacity: 38 kNm PRESS TABLE   table surface (left-right): 2000 mm   table surface (front-back): 1200 mm   thickness of bolster plate: 200 mm SLIDE   slide force: 315 to   table surface (left-right): 1995 mm   table surface (front-back): 1100 mm   stroke: 160 mm   stroke rate (max.): 80 /min SLIDE (MECHAN. PRESS)   slide adjustment: 140 mm   stroke rate (min.): 20 /min   stroke rate (max.): 80 /min   main drive power: 90 kW TOO ...

PRESS DESIGN   drive system: eccentric / crank   frame design: H-frame, tie rod   openings in uprights: yes   table cushion: yes   feedstock transport direction: left to right PRESS FORCES   total force (nominal): 200 to PRESS TABLE   table surface (left-right): 1780 mm   table surface (front-back): 1300 mm   opening in bed (left-right): 1445 mm   opening in bed (front-back): 260 mm SLIDE   slide force: 200 to   table surface (left-right): 1500 mm   table surface (front-back): 1100 mm   stroke: 178 mm   stroke rate (max.): 120 /min SLIDE (MECHAN. PRESS)   slide adjustment: 150 mm   stroke rate (min.): 20 /min   stroke rate (max.): 120 /min DIE CUSHION (TABLE CUSHION)   number of cushions: 11  & ...

CONTROLS   PLC OVERALL SPECIFICATIONS (COIL LINES)   sheet width max.: 500 mm   sheet thickness max.: 4 mm   coil weight max.: 10.5 to   feedstock transport direction: right to left COIL CHAIR   coil weight max.: 10.5 to   stroke: 750 mm DECOILER   design: single reel   sheet width max.: 500 mm   sheet width (min): 150 mm   coil weight max.: 10.5 to   max. diameter of coil: 2020 mm   mandrel expansion range from: 470 mm   mandrel expansion range up to: 530 mm   feed velocity max.: 20 m/min CROP SHEAR   sheet thickness max.: 4 mm   working width max.: 530 mm   stroke rate (max.): 20 /min LEVELLER UNIT   sheet width max.: 500 mm   sheet width (min): 150 mm   sheet thickness max.: 4 ...

Qty. 1 Second-hand skin pass mill Mfc.: Mannesmann Demag Sack Built: 1980’s Modernised in 1986 & 1993 Type: Duo Cold Rolling Mill – Non-Rev. Dia. 330 x 500 mm Material: Carbon steel, cold rolled and annealed Strip width: 80 - 470 mm Thickness entry: 4.0 mm Exit: 0.2 mm Decoiler Modernised in 1986 ID: 400 with segments 500 & 600 mm Spreading range: 370 – 420 mm Strip tension: 1300 – 65 daN Braking system: Generator Braking torque: max. 1300 daNm De-coiling speed: 2.5 m/sec. Coil cross section: 20 – 1880 mm² Coil weight per mm strip width max.: 10 kg Coil weight: 5.0 T Coil ID: 400 & 500 mm Coil OD: 600 – 1400 mm Roll dia.: 300 – 330 mm Roll length: 500 mm Roll force: 1850 – 2400 kN Min. roll force: 150 kN Hydraulic roll adjustment Adjustment stroke: 80 mm Adjustment speed: 1 – 3 mm/sec. Rolling speed: 2.5 m/sec. (150 m/min.) PLC system: ...

Capacity: 0 t Table length: 0 mm Table width: 0 mm Stroke: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Pressure: 1600 kN Total stroke: 300 mm Execution: 4 columns Table surface: Length: 1000 mm Width: 850 mm Return power: 119 kN Depth of throat Passage between columns: longitudinal: 645 mm Lateral: 405 mm Slide clamping surface: Width: 1000 mm depth: 850 mm Close traverse speeds: Rapid traverse: 400 mm/s Press stroke: 10 - 60 mm/s Return traverse speeds: 400 mm/s Oil quantity: 350 l Voltage 50 Hz 3x: 380 Volt Motor power: 45 kW Machine´s weight about: 13000 kg Overall dimensions machine: Length: 2100 mm Width: 1200 mm Height: 3900 mm Various accessories: Security/savety device: SICK Roll-feed Useful cylinder length: 250 mm Decoiler: Manufacturer: DREHER 2380DM 400 mm Straithening device: DREHER 400 x 4 mm

Capacity: 12 t Table length: 2000 mm Table width: 0 mm Stroke: 2000 mm CNC Brand: _Unknown / Other CNC Model: Leonard en Bauer MAKE   ARKU Germany TYPE    VRM 200/7/2000 + AH 1200/2000/MSG-4Q YEAR   1990 SPECIFICATIONS Controll   Leonard + Bauer Throat     2000 mm Maximum sheet thickness Steel   6,3 mm DIMENSIONS Length   6000 mm Width     4500 mm Height    3000 mm ARKU De-Coil & Straightener 2000 x 6,3 mm   Make           : ARKU Germany Typ              : VRM 200 / 7 / 2000 Serial No    : WO 1576 Age              : 1989 in Work 1990  ARKU Precision s ...

Double standing seam roofing machine F3 is used for making double standing seam lock for the roofing panels that are used for installation of the double standing seam roofing. The double standing seam roofing is widely used because it’s impossible for the water to get under the closed double standing roofing panels in the places of their contact with each other, thanks to lock’s special shape. The special shape means that double standing seam panels cover each other in the places of their contact, and after their installation on the roof it will be closed using special double standing seam closing tools (manual tool for closing double standing seam lock and electric machine for closing double standing seam lock). The advantage of this Standing seam machine is possibility to change the width of the standing seam roofing panels in very simple way. There’s a special screw at th ...

1/ Straightener RSTM-SU-W 60/7/700 NIR Built in 1999, producer. PBK Automation GmbH Vöhringen, DE Direction of work - from left to right Passage width - 720 mm Belt width from 50-700 mm Strip thickness from 0.4-3.0 mm Strip cross-section max. 1750 mm2 Feed roller diameter - 80 mm Straightening and correction roll diameter. 60 mm Feed speed - max. 30 m/ min Feed rollers - 2 Straightening rollers 7 Correction roller - 1 Drive power 3 kW Colour RAL 6011 - lime green - Upper straightening head half can be folded up pneumatically in a V-shape for cleaning purposes - Infeed of the upper feed roller is also pneumatic - Adjustment of the straightening block is done via socket wrench Drive - via three-phase geared motor with frequency converter - Single-axis positioning control incremental CPS 20 Freely programmable CNC positioning control - Simodrive 611 Tech ...

a good blanking press Krupp Model PEKRD 250h, 250 tons, year 1980/2005, overhauled 2005, with infinitely variable drive system and Siemens S7 controls, feed system for material 0.5-6 mm, 500mm wide. With decoiler 6 tons. Built as a double-sided C-frame press so that in- and outfeed front-to-back is possible

Press type: PME 315 T Drive system: Eccentric Type of used tools Progressive Nominal force: 3150 kN Rating above BDC mm Material flow L->R - Maximum SPM: 75 1/min Minimum SPM: 20 1/min Maximum shut height: 525 mm Minimal shut heigh:t 325 mm Slide adjustment: 130 mm Maximum slide stroke: 210 mm Minimum slide stroke: 40 mm Bolster specification Bolster dimension: 2220 x 1225 mm T-slots in bolster: T28 H8 DIN650 - Draw cushion N/A - Draw cushion stroke: N/A mm Draw cushion force: N/A kN Draw cushon dimension: N/A mm Maximum weight: kg Ram specification Ram dimension: 2220 x 1225 mm T-slots in ram: T28 H8 DIN650 - Max. upper die weight: 3600 kg Tool manipulation Tool is manipulated by forklift - Max. tool weight: 5500 kg Forks size/pitch: 150x60/940 mm Lower die clamp height: 50 mm Upper die clamp height: 50 mm Tool locating (centering) stůl/bolster  ...

Unwinding reel / decoiler â?¢ Bandwidth / strip width max. 1,500 mm â?¢ Tape thickness / strip thickness (430 N/mm2) 0.5-2.0 mm â?¢ Coil outer diameter / coil outer - 1,300 mm â?¢ Coil inner diameter / coil inside - 470-520 mm â?¢ Coil weight / coil weight 10,000 kg â?¢ Side shift / side shift . . . . . . . . . . . . . . . . .

material width:150 mm coil weight:1,5 t coil internal diameter:500 mm coil external diameter:940 mm strip material:20 x 1,0 - 50 x 4,0 / 200 x 2,0 mm wire diameter:1,0 - 5,0 mm power requirement:0,7 kW weight:0,7 t Dimensions (WxDxH):1,0 x 1,7 x 2,0 m palett decoiler:motoric driven

Qty. 1 Second-hand cut-to-length line Mfc.: Ungerer Built: 1966 Material: Stainless steel Strip Width: 300 mm- 1500 mm Thickness: 1.5 mm (stainless steel) Cut length: 750 mm- 6000 mm Length adjustment: mechanical Coil weight: 9.000 kg Coil min/max inner Ø: 500 & 600 mm Shear Type: Rotary Hydraulic system Stacker capacity: 2000 ton PLC: Allen Bradley Scope of supply: Decoiler Crop shear Edge trimmer Leveller PVC film applicator Stacker Camera system

equipped with double crankshaft with rear gear transmission; incl. decoiler; bending machine for strip material; Sound-absorbing cabinet and outfeed belt

equipped with double crankshaft with rear gear transmission; incl. decoiler; bending machine for strip material; Sound-absorbing cabinet and outfeed belt

Max. thickness of material 2 mm; speed 30-60 stamps/min.; distance between the tools 220 mm; v.v. "Dreher" decoiler; type 2370D; Max. clamping diameter 500 mm; load 1500 kg; incl. sound-absorbing cabinet

v.v. 8 working levels; 1st level max. 90T; 2nd to 8th level; 80T (total 160T); Max. material thickness 3 mm; speed 25-50 strokes/min.; Distance between the tools 260 mm; incl. decoiler for strip material; soundproofing cabinet; "Siemens" digital control; type S7. Machine overhauled with completely new cabling and Siemens control

v.v. 8 working levels; 1st level max. 90T; 2nd to 8th level; 80T (total 160T); Max. material thickness 3 mm; speed 25-50 strokes/min.; Distance between the tools 260 mm; incl. decoiler for strip material; soundproofing cabinet; "Siemens" digital control; type S7. Machine overhauled with completely new cabling and Siemens control

Cut-to length slitting machine SM-1250х8 Cut-to-length slitting machine is used for longitudinal cutting of the metal sheets with maximum thickness 1mm, aluminum composite panels, paper, polycarbonate thanks to special cutting knives that are fixed on rolls of the slitting machine. This cut-to-length slitting machine lets you to cut the material into eight strips. The diameter of the rolls is 56 mm There are four types of the sheet metal cut-to-length machines we make: The manual cut-to-length slitting machine (cutting for 2 strips) The electric cut-to-length slitting machine (cutting for 3-4 strips) The electric cut-to-length slitting machine (cutting for 6-10 strips) The electric cut-to-length slitting machine (cutting for 12-20 strips) The operator of cut-to-length slitting machine can easily change the width of the strips and their numbers. There are special scr ...

v.v. 8 working levels; 9 tool positions; 1st level max. 100T; 2nd to 8th level 220T (total 500T); speed 15-50 strokes/min.; Max. material thickness 3 mm; distance between the tools 400 mm; incl. decoiler for strip material; soundproofing cabinet; conveyor belt installation; "Siemens" digital control; type S7

Sheet thickness: 0 mm Roller width: 0 mm Number of rolls: 0   Roller diameter: 0 mm Technical data Decoiler: Inner coil diameter: 460 - 520 mm Outer coil diameter: 1900 mm Max. Coil weight: 7500 kg Band thickness max.: 620 mm Coil straightening machine: Number of rolls: 9 Roll diameter: 50 mm Max. bandwidth: 620 mm Sheet thickness: from: 0.6 mm up to: 6.5 mm

CONTROLS   PLC SIEMENS S5 100 U DECOILER   sheet width max.: 120 mm LEVELLER UNIT   number of leveller rolls: 19 2 x machines
