start page > keywords cup > results
435 items ordered by
post used machinery
No. Cat. Photo Manufacturer | Model
Type of machinery
Year Price Country Contact
 page 1  > 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
123774115 1101

DEUTZ MWM TBG616V08K for sale
Block combined heat and power stations


Pro2 container unit with 311kW el. Performance and complete heat recuperation system 400kW therm. -40 foot container completely overhauled in 2012, including engine and generator -Genset approximately 15,000 hours afte ...
used machine

Pro2 container unit with 311kW el. Performance and complete heat recuperation system 400kW therm.
-40 foot container completely overhauled in 2012, including engine and generator
-Genset approximately 15,000 hours after overhaul
-Heat extraction 90 / 70 °C with emergency cooling via dry cooler and exhaust gas flaps
-Oil station 2 x 1000 l
-Equipped completely with new TEM EVO control and new control wiring
-grid start device
-Turnkey container CHP solution

98,000 €
    request
123807282 702

DERBY Teigteilmaschine ab 7-reihig Derby for sale
divider-rounder, fabr. Winkler, Derby 8 rows


model 401, double excenter\r\ncap. max 10.000 pcs./h\r\ndistance between the cups 110 mm, width 900 mm\r\n


model 401, double excenter\r\ncap. max 10.000 pcs./h\r\ndistance between the cups 110 mm, width 900 mm\r\n

Price
    request
123768922 112

PFAUTER TYP RS2 rs2 for sale
Gear Milling Machines


Gear Hobber PFAUTER type RS2 Fabr. No. xxxxxxx Built 1952 Module size maximum Chapter 10 Gear diameter with thrust bearing Max 500 mm Gear diameter without bearing Max 1000 mm Tooth width of 375 mm Gear teeth numb ...


Gear Hobber PFAUTER type RS2
Fabr. No. xxxxxxx
Built 1952
Module size maximum Chapter 10
Gear diameter with thrust bearing Max 500 mm
Gear diameter without bearing Max 1000 mm
Tooth width of 375 mm
Gear teeth number 6 min
Axis distance workpiece tool 50-570 mm
Diameter of the clamping table 700 mm
Distance from the table to the top of the counter bearing 780 mm
Milling spindle mount Mt 5
Cutter dimensions Ã? 160 x 170 mm
Milling cutter speeds 35-180 RPM
Milling spindle adjustment 125 mm
Power 5,5 kW
Power supply 380 v, 50 Hz
-Bearing connected to the stand
-Constant velocity trimmer
-Transverse feed device
-Part Setup by hand
-1 piece tangential head
-Milling slide swivel through 180 ° for helical gears
-Cooling lubricant pump for circulating oil lubrication
-Change gears and differential change gear set in the adjoining storage cupboard
-15 piece hobbing cutter module 2 to module 8.5
-Post dollies
-multiple shots of workpiece
-Cabinet with electrical renewed a few years ago
-Manual
Dimensions L x W x H 2400 x 1400 x 2300 mm
Machine weight ton approx. 4.8.
good condition
TRUCK free loading
Board book with technical file

3,500 €
    request
123779123 205

WEEKE BHC 550 for sale
CNC Machining Center


serial number: 0-250-05-3328 Weight approx.: 5500 kgcontrol: Homatic 2000 IPC Dimensions (l x w x h) approx.: 800x2400x2400 mmc-axis: Ja/Yes setting measure approx (l x w x h): 7400 x 4130 x 2370 mmpacking measure approx ...
used machine

serial number: 0-250-05-3328
Weight approx.: 5500 kg
control: Homatic 2000 IPC
Dimensions (l x w x h) approx.: 800x2400x2400 mm
c-axis: Ja/Yes
setting measure approx (l x w x h): 7400 x 4130 x 2370 mm
packing measure approx (l x w x h): 8000x2400x2400 mm
software: Woodwop 4.5 Silverstone
working length x-axis: 4250 mm
working width y-axis: 1300 mm
working height y-axis: 100 mm
main spindle: 12 kW
tool changer: 2 x 8-fach / 2 x 8-fold
vacuum pump: 100 cbm/h
drilling head vertical x-axis: 9 piece
drilling head vertical y-axis: 8 piece
drilling head horizontal x-axis: 4 piece
drilling head horizontal y-axis: 2 piece
saw unit: ja/yes ( 100 mm) in X
travelling way X-axis: 4900 mm
travelling way Y-axis: 1635 mm
travelling way Z-axis: 380 mm
path-feed rate max. X-axis: 80 m/min
path-feed rate max. Y-axis: 60 m/min
path-feed rate max. Z-axis: 20 m/min
total power approx: 22 KW
Description: WEEKE BHC 550 CNC Machining Center Electronically controlled milling and drilling center for just­in­time production of furniture parts, solid wood or similar materials
TECHNICAL DATA:

? Workpiece length
- max. 4250 mm single occupancy
- max. 1300 mm with alternate operation

? Workpiece width
- max. 1340 mm for milling with cutter 20mm

? Main spindle
- 12,0 KW with C-axis
- Speed 1,250 - 24,000 rpm

? Boring head
- 19 spindeles for vertical drilling
- 9 spindles in X-direction, 8 spindles in Y-direction
- 6 spindles for horizontal boring ( 4 in X and 2 in Y)

? 2 x Plate changer:
- 8- fold for milling tools, in X and Y-moving
- 8-fold for milling tools and adapter in X- direction movin

? K working table:
- 8 consoles,
- 8 side mounted insertions aids

cross-hair laser for postioning vacuum pods
? 4-workpiece feet

2001
used machinery auction RESALE 16,000 €
  DE   request
123706177 401

DEEP DRAWING FILL. 9.000 E/H rectangular cups 40 g u. 75 g for sale
Aseptic Illig FFC-filling machine


D 102 1 aseptic filling deep drawing filling machine for rectangular cups 40 g and 75 g Manufacturer is Illig, Heilbronn 5 lanes Typ: FS 32 B Machine No. 212 Manufacturer year is 1991 Capacity by 75 g: approx ...
used machine

D 102

1 aseptic filling deep drawing filling machine
for rectangular cups 40 g and 75 g
Manufacturer is Illig, Heilbronn
5 lanes
Typ: FS 32 B
Machine No. 212
Manufacturer year is 1991
Capacity
by 75 g: approx. 9.000 cups single cups per hour
by 40 g: approx. 7.200 cups single cups per hour
The dosing system fill 15 cups per stroke with 1 product
Cup measurement:
by 75 g: 4,8 x 4,8 cm, High: 3,7 cm
with foil unroll device
with deept drawing heating device for rectangular cups
with a on the side standing dosing system
with a lid foil unrolling equipment with heat
electrode irradiation
Foil chad from the punching machine in
running direction of the machine: left side
The cup will be punched into single cups
With an A&F carton production machine,
cartons coming out of a magazine for flat cartons
with Nordson glue technology
with a pivoting control panel
15 single cups in 2 lanes = 30 single cups are
in 1 carton
outlet of the filled carton in running direction
of the carton production and filling machine:
left side
Capacity
3.600 cups = 240 cartons will by palletize
by hand on one Euro pallet.

Price up standing point: 58.000,00 Euro



1992
58,000 €
    request
123764757 209

DALMEC PRC for sale
Feeder / Stacker


Venturi-vacuumlifting and balancing system Max. capacity: 70 kg.Max. radius 2700 mm.Max usefull radius: 2490 mmworkpieces rotation around horizontal axis: 180°360° freedomVertical stroke: 1000 mm.Number of suction cups ...
used machine

Venturi-vacuumlifting and balancing system
Max. capacity: 70 kg.
Max. radius 2700 mm.
Max usefull radius: 2490 mm
workpieces rotation around horizontal axis: 180°
360° freedom
Vertical stroke: 1000 mm.
Number of suction cups: 4
Height needed: 3600 mm.
2000
Price
  BE   request
123706165 104

DELTA LB - 300 for sale
Surface Grinding Machines


POT GRINDER DELTA LB - 300 - 14-10-053 Shipping time: immediately Number: 14-10-053 Manufacturer: DELTA Type: LB - 300 MACHINE DATA Year of production: around 1995 L x W x h: approx. 800 x 800 x 1800 mm W ...
used machine

POT GRINDER DELTA LB - 300 - 14-10-053

Shipping time: immediately

Number: 14-10-053

Manufacturer: DELTA
Type: LB - 300

MACHINE DATA
Year of production: around 1995
L x W x h: approx. 800 x 800 x 1800 mm
Weight: approx. 400 kg

Very good condition - figure similar to

TECHNICAL DATA
Control: conventional

Loop scope:
Grinding length: 330 mm
Grinding width: approx. 140 mm
Grinding height: approx. 280 mm
Magnetic clamping surface: approx. 250 x 150 mm

Grinding spindle:
Grinding wheel dimensions: approx. Ã? 180 x 78 x 78 mm
Grinding spindle - speed: approximately 2840 RPM
Power: approx. 2,2 kW

Z - delivery: manual
Grinding movement: manual

ACCESSORIES
â?¢ Permanent - magnet
â?¢ Wet grinding device
â?¢ Machine housing
â?¢ Operating instructions
â?¢ Grinding wheels - protection
â?¢ Honing device
â?¢ Cup grinding wheel
â?¢ Various wrenches
â?¢ Machine feet

Other accessories on request
Price and other specifications on request
1995
Price
    request
123764889 201

HOLZMA - BARGSTEDT PROFI HPP23/65/65/X for sale
Automatic panel sizing beam saw, rear loading with


Cutting sizes: 6500 mm x 6500 mm.Sawblade projection: 140 mm.Main saw motor 18 kw / scoring motor 2,2 kwMain sawblade 520 x 4,8 x 60mmScoring sawblade 200 x 4,8-5,8 x 45 mm Feed speed of saw carriage: 5-100 m/min forward ...
used machine

Cutting sizes: 6500 mm x 6500 mm.
Sawblade projection: 140 mm.
Main saw motor 18 kw / scoring motor 2,2 kw
Main sawblade 520 x 4,8 x 60mm
Scoring sawblade 200 x 4,8-5,8 x 45 mm
Feed speed of saw carriage: 5-100 m/min forward, 100 m/min reverse
Feed speed of programmable fence: 80 m/min (limited to 25 m/min for safety reasons)
10 grippers
Max. gripper opening: 185 mm
Double sided aligning roller, min/max alignable panel width: 50 / 2200 mm
5 pcs air flotation tables in the front, each 2810 x 650 mm
Incorporated rotary platform with vacuum cups for doing head cuts
(limitation on the panel size in case of thin panels)
Automaic pusher for the evacuation of cut strips
Controlls: CADmatic
Hardware: Windows NT - 17 display
Lateral vacuum bridge making the panel stack to be cut
Roller conveyor transfer towards the rear of the saw (made by Bargstedt)
2004
Price
  BE   request
123705937 1406

A&F, Polycetting div. for sale
carton stacker, carton elevator, carton conveyor


A 4 800 Carton- and cup tray elevator with tray stacker machine coming out of an past Danone soft cheese production not dismantled, original standing place A 4 801 1 A&F carton and tray elevator with a t ...
used machine

A 4 800
Carton- and cup tray elevator with
tray stacker machine
coming out of an past Danone soft cheese production
not dismantled, original standing place


A 4 801
1 A&F carton and tray elevator with a tray stacker
Type 260-I
Fab.No 93063 D
manufacturer year is 1993
electronic program is Siemens S7
with inlet of filled trays into the tray stacker

The outlet of the elevator with actual 3,18 m
( bottom edge of the transport conveyor) can
change with a view to the free space of the feet
of the elevator at 32 cm.

After outlet of the tray elevator is installed a
1-lane roller conveyor.
The tray stacks are transport on this roller
conveyor without dynamic pressure
The length of the roller conveyor is 10 m
The length of a single role is 35 cm
Length of this double roller conveyor
to the wall breakthrough is 13 m
Roller conveyor frames are complete out of
Aluminium material.
The complete conveyor after outlet of the elevator
is hanging down from the ceiling.
manufacturer is Comp. Gerhard
manufacturer year is 1993
Price up standing point: 6.700,00 Euro


A 4 802
1 A&F carton and tray elevator with a tray stacker
Type 260-I
Fabr. No. 9306 E
manufacturer year is 1993
electronic program is Siemens S7
with inlet of filled trays into the tray stacker
The tray stacker can pile up 2 trays, with a program

The outlet of the elevator with actual 3,18 m
( bottom edge of the transport conveyor) can

After outlet of the tray elevator is installed a
1-lane roller conveyor.
The tray stacks are transport on this roller
conveyor without dynamic pressure
The length of the roller conveyor is 9 m
The length of a single role is 35 cm

After this roller conveyor is installed a tray pushing station
to a 2-lane roller conveyor, which is installed in a right angle
to the 9 m roller conveyor
Length of this double roller conveyor
to the wall breakthrough is 14 m
Roller conveyor frames are complete out of
Aluminium material.
The complete conveyor after outlet of the elevator
is hanging down from the ceiling.
manufacturer is Comp. Gerhard
manufacturer year is 1993

Price up standing point: 6.700,00 Euro


A 4 803
1 A&F carton and tray elevator without tray
stacker, because with elevator No. 803 had
have lifted trays with 12 x 500 g cups,.
Type 160-D-1
Fabr. No. 6483-1
manufacturer year is 1995
electronic program is Siemens S7
with inlet of full trays into the A&F tray elevator
The outlet of the elevator with actual 3,18 m
( bottom edge of the transport conveyor) can
change with a view to the free space of the feet
of the elevator at 32 cm.

1-lane roller conveyor.
The tray stacks are transport on this roller
conveyor without dynamic pressure
The length of the roller conveyor is 14 m
The length of a single role is 35 cm

After this roller conveyor is installed a tray pushing station
to a 2-lane roller conveyor, which is installed in a right angle
to the 9 m roller conveyor
Length of this double roller conveyor
to the wall breakthrough is 10 m
Roller conveyor frames are complete out of
Aluminium material.
The complete conveyor after outlet of the elevator
is hanging down from the ceiling.
manufacturer is Comp. Gerhard
manufacturer year is 1995

Price up standing point: 6.400,00 Euro

A 4 804
1 A&F carton and tray elevator with a tray stacker
Type 260-I
Fabr. No. 9306 E
manufacturer year is 1995
electronic program is Siemens S7
with inlet of filled trays into the tray stacker
The tray stacker can pile up 2 trays, with a program
changing are 3- or 4 trays possible, max 10 kg
After the tray stacker the tray stacks are transport into
the A&F tray elevator

The outlet of the elevator with actual 3,18 m
( bottom edge of the transport conveyor) can
change with a view to the free space of the feet
of the elevator at 32 cm.

After the outlet of the tray elevator the full tray stacks
would transport with a roller conveyor, installed in a
edge of 45° on a next roller conveyor.
Straight length 4,68 m.
After this is installed a tray pusher, which was shove
the trays on a 2-lane plastic transport conveyor.
The 2 lane transport conveyor has through a
wall breakthrough a length od 5 m.

After this 2-lane transport conveyor is installed in a right edge
a 2-lane roller transport conveyor about 18 m.

This 18 m roller transport conveyor are covered with a
transport conveyor tunnel”. Single roll have a length
of 35 cm.
The transport tunnel is standing on a stable frame with a
platform about the whole length of the transport tunnel.
The tunnel has installed a few of inspection windows
Free space between upper edge roller conveyor
to under edge of the tunnel ceiling is 60,50 cm.
manufacturer of the transport conveyor plant is
Comp. Polycetting
manufacturer year is 2006

Price up standing point: 8.600,00 Euro

single bying is possible
1993
28,400 €
    request
123764729 209

WEEKE BP 155 for sale
Machining center CNC (4 axis)


Table size in X : 4.250 mm, Y : 1.000 mm (1 m longer bed in X)Max. workpiece thickness: 100 Stroke in X/Y/Z: 4950 / 1790 /340 mm.Main routing motor: 7,5 / 10 kW, liquid cooled, Spindle HSK F63, integrated C-axisToolchang ...
used machine

Table size in X : 4.250 mm, Y : 1.000 mm (1 m longer bed in X)
Max. workpiece thickness: 100
Stroke in X/Y/Z: 4950 / 1790 /340 mm.
Main routing motor: 7,5 / 10 kW, liquid cooled, Spindle HSK F63, integrated C-axis
Toolchanger (chain type) moving along in X, 30 places
Vertical drills: 16 in X-direction, 15 in Y-direction
Horizontal drills in X : 4
Horizontal drills in Y : 2
Grooving saw in X, motor 1,5 kW
8 supports with vacuum cups (each 1300 mm length in stead of 1000 mm)
8 lifting rails for easy panel handling
8 extra fences in the front
Vacuumpump 100 m3/h
Controlls: Homatic 2000
Software: Woodwop 4.0
Required dust extraction min. 5000 m3/h
1998
Price
  BE   request
123600483 1101

DÜRR Eco+Energy ORC 300 HT module for sale
Generators


300 KW ORC - Waste Heat Electricity Generation Model: Eco+Energy ORC 300 HT module Module designed to run from the waste heat of a gas engine. New unused plant ready to operate. Heat Source: Gas Engine / Exh ...



300 KW ORC - Waste Heat Electricity Generation

Model: Eco+Energy ORC 300 HT module

Module designed to run from the waste heat of a gas engine.
New unused plant ready to operate.

Heat Source: Gas Engine / Exhaust gas
Admission temperature: 424°C No
Usable heat: (3 605 kWth/ Genset) 1,815 kWth
Price: On Application

The ORC process is a thermodynamic cycle which uses thermal energy to generate electricity.

Thermal oil as a heat source is led through the evaporator of the ORC module. The vapor of the working fluid flows under pressure into a turbo-generator sector, where some of the heat energy is converted into electricity. Subsequently, the working fluid is being liquefied in a water-cooled condenser, and again fed to the evaporator with a multi-stage feed pump. The condenser is executed as a double stage unit, consisting of a recuperator zone, used for preheating of the working fluid, and a condensing zone used for the above described cooling process. The extracted heat from the condensing process may be used for heating purposes.

Price
  UK   request
123738098 1300

PROBST SH 2500 UNI B for sale
Vacuum Lifting Unit


Weight approx.: 120 kgDimensions (l x w x h) approx.: 800 x 1200 x 800 mmDescription: Max. load capacity 2500 kg, including suction cup SPS 200 (130), max. load 200 kg, ATTENTION: device has an unknown defect!
used machine

Weight approx.: 120 kg
Dimensions (l x w x h) approx.: 800 x 1200 x 800 mm
Description: Max. load capacity 2500 kg, including suction cup SPS 200 (130), max. load 200 kg, ATTENTION: device has an unknown defect!
2011
used machinery auction RESALE 80 €
  DE   request
123600133 103

MAHO MH 700 C for sale
Universal Milling Machines


Milling machine - universal MAHO MH 700 C x path: 700 mm y travel: 450 mm z travel: 500 mm Table size: 950 x 600 mm Table load: 600 kg Spindle taper: SK 40 Speed: 20-3150 RPM Rapid traverse x/y/z: 6000 mm / min F ...
used machine

Milling machine - universal MAHO MH 700 C x path: 700 mm
y travel: 450 mm
z travel: 500 mm
Table size: 950 x 600 mm
Table load: 600 kg
Spindle taper: SK 40
Speed: 20-3150 RPM
Rapid traverse x/y/z: 6000 mm / min
Feed: 1-3000 mm / min
Tool changers: 14
Total power consumption: 36 kVa
Machine weight approx. 3000 kg
Space requirement approx.: 2,5 x 4,0 m
Built in 1986
Accessories:
Cup tool changer
Complete housing (chips, Splash Guard)
Full technical documentation
Expression of the machine constants
1986
Price
    request
123726343 2200

Old oak wardrobe cupboard


Old oak wardrobe cupboard 2 doors 3 shelves, 2 drawers Dimensions: 129 cm x 47 cm x 198 cm removable The lot is on the 1st floor




Old oak wardrobe cupboard

2 doors

3 shelves, 2 drawers

Dimensions: 129 cm x 47 cm x 198 cm

removable

The lot is on the 1st floor



used machinery auction RESALE 10 €
  BE   request
123583090 402

EFFE PACKAGING tm-xm for sale
Cup packaging machines


Effe pakaging machine Tray sealing machine Semi-automatic In very good working conditon


Effe pakaging machine
Tray sealing machine
Semi-automatic
In very good working conditon

Price
  GR   request
123727026 1108

Windshield Repair kit, Suction cups


Windshield repair kit Various accessories in box 4 double suction cups 2 simple suction cups 1




Windshield repair kit

Various accessories in box



4 double suction cups

2 simple suction cups

1


used machinery auction RESALE 20 €
  BE   request
123504113 1300

BRANCH OF BUSINESS for sale
Branch crushers and conveyor belts


Branch crushers and conveyor belts March 13, 15 hours on sale next to Bergamo For more information, contact us at 0307751645, view detailed catalogue and expertise The business unit consists of: Technical manuals of  ...


Branch crushers and conveyor belts
March 13, 15 hours on sale next to Bergamo
For more information, contact us at 0307751645, view detailed catalogue and expertise
The business unit consists of:
Technical manuals of installed systems, specifically:
-gearboxes, mills and crushers bars
-sorting, washing and crushing plant
-dryers and recuperatrici
-Vaglio taper tap
-electrical industrial plant documentation and datasheets scrapers that are specified in the catalogue
Inventories parts warehouse
-Belt scrapers
-Gear motors (Motovari, Vibrators, drum motors)
Scrap ready oven vari (hammer mill scale Tape, etc.)
Pumps, motors, Gearboxes, motors, Electric Vibrators, different sized flange Motors etc.
Cochlea, including: cylinders, pressure control valves, butterfly valves, actuators, damper, soft head, flange, reducer, motor and rotary valve VAMM
Inventories:
-supports (Ritto-flanged)
-elastic bands
-iron and rubber Cups

10,000 €
  IT   request
123726564 2200

Highchair and stools


1 high chair and 4 stools decoration 1 cupboard




1 high chair and 4 stools

decoration

1 cupboard



used machinery auction RESALE 15 €
  BE   request
123484222 409

TOSA 121 for sale
Pallet stretch wrapping machines


For sale, a used Tosa is 121 Rotary arm cupcake wrappers. The winder was overhauled and has a new S7 control as well as a new control panel. The scope of services also includes: -1 St related protection fence -2 St.  ...
used machine

For sale, a used Tosa is 121 Rotary arm cupcake wrappers.
The winder was overhauled and has a new S7 control as well as a new control panel.
The scope of services also includes:
-1 St related protection fence
-2 St. new safety light barrier Leuze
-1 St pallet conveyors in the diaper area

The machine can be visited like.
1997
20,000 €
    request
123726567 2200

Storage cupboard, crockery, kitchen utensils, cutl


Storage cabinet, dishes, kitchen utensils, cutlery Wardrobe: White wood Wooden green wooden seat 4 drawers Dimensions: 81 cm x 51 cm x 102 cm Dishes, cooking utensils, cutlery All in + - 10 mannes and cart ...




Storage cabinet, dishes, kitchen utensils, cutlery



Wardrobe:

White wood

Wooden green wooden seat

4 drawers

Dimensions: 81 cm x 51 cm x 102 cm



Dishes, cooking utensils, cutlery

All in + - 10 mannes and cartons



used machinery auction RESALE 15 €
  BE   request
 page 1  >
You didn't find your wanted machine?   to all dealers(no registration necessary)
sell machinery
Sell your machinery
to the price starting with only € 0.09 monthly per machine!
machinery sold
Find used machinery dealers in your country
