coordinate used for sale

Coordinate switch, joystick, control switch, without switching contacts CEMA P9MMN4H ( P9MMN4H ) 184724 4 directions, 1x latching Joystick length: 55 mm hole diameter: Ø 22.5 mm coordinate switch set consists of 5 coordinate switches ! Inclusive 5x Flange P9ACFS5 ! New ! Dimensions(single): 45 x 30 x 100 mm Dimensions (packaging): 130 x 90 x 120 mm

DEA GLOBAL S 07.05.05 coordinate measuring machine was manufactured in Italy in 2004. The machine performs fast and highly accurate measurements of workpieces with complex shapes using the contact or non-contact method, represented as a set of coordinate points. The excellent quality and precision of the process is guaranteed thanks to the mounted in the DEA GLOBAL S 07 05 05 CMM machine an indexable RENISHAW PH10MQ measuring head with a RENISHAW SP25M scanning probe, performing measurements in the X,Y,Z axes with feeds of 700 mm (X axis), 500 mm (Y axis) and 500 mm (Z axis). The DEA GLOBAL Status 07.05.05 measuring machine is also equipped with the highly advanced metrology software PC-DMIS 2019 R1, performing detailed geometric measurements. Technical specifications of the DEA GLOBAL S 07.05.05 measuring machine - maximum permissible error of length measurement MPEe: ± 2.3 + 3L/10 ...

Description: The used PMM-F is specially designed for testing medium-sized components and gears. This 3D measuring machine has an overhead design and serves as a coordinate measuring machine, gear measuring centre, form tester and roughness measuring machine. Area of application: Inspection of medium-sized components and gears Design: Overhead design Functions: Coordinate measuring machine, gear measuring centre, form tester, roughness measuring machine Measuring range: approx. 3,000 x 2,000 x 1,600 mm Resolution: 5 nm Equipment: Various measuring probes Accessories: Work table, mobile container, chair Control desk: Equipped with a Dell PC The PMM-F offers a precise and versatile solution for measuring and testing components and gears in medium dimensions. z-motion: 1,000 mm, x-motion: 3,000 mm, y-motion: 2,000 mm, table surface area l x w : 3000x2000 mm, weight approx.: 32,000  ...

CNC double-staender coordinate drilling rig with deep drilling support Kolb KBN G 120 year 1984 / Converted to Heidenhain TNC 426 in 2006 table size 4250 x 2200 mm Table load 14 t Table laengsweg X 3000 mm Main Spindle crosspath Y 2180 mm deep drilling spindle crossing path A - 2000 mm spindle vertical path 500 mm Distance between the stems 2640 mm; spindle - table 100 - 1300 mm; spindle diameter 224 mm Spindle drive power 46 kW spindle speeds 14 - 1400 rpm spindle holder ISO 50 Drilling in steel ST60: 100 mm diameter; drill up to 300 mm; threaded cutting up to M 125 x 3; frard power 730 cm3r/min.; SECOND SUPPORT SUPPORT: spindle speeds at BTA and ELB drilling 315 - 3150 rpm high high pressure oil Offer number V(B)-5234; Very good

CNC Double column Coordinate Boring Machine with Deep Hole Drilling Support Kolb KBN G 120 Year of manufacture 1984 / Retrofitted with Heidenhain TNC 426 in 2006 Table size 4250 x 2200 mm Table load max. 14 t Table longitudinal travel X 3000 mm Main spindle cross travel Y 2180 mm Deep hole drilling support cross travel A - 2000 mm Spindle vertical travel Z 500 mm Distance between the columns 2640 mm; Spindle to table 100 - 1300 mm; Spindle diameter 224 mm Spindle drive motor rating 46 KW Spindle speeds 14 - 1400 rpm Spindle taper ISO 50 Drilling in steel ST60 : 100 mm diameter; Boring to 300 mm; Threading to M 125 x 3; Milling capacity 730 cm³/min.; Second support for Deep Hole Drilling Spindle speeds for BTA and ELB boring 315 - 3150 rpm High pressure cutting oil delivery to spindle Chip- and oil collection and separation via Centrifuge. Very good condition P ...

Leitz Coordinate Measuring Machine Leitz PMM-G 50.30.20 Dimesnion: 5000x3000x2000 Machine is in excellence working condition.

table length: 1160 mm table width: 710 mm daylight: 650 mm Control: WENZEL ME 5007 total power requirement: kW weight of the machine ca.: 800 kg dimensions of the machine ca.: m 3-D-coordinate measuring machine with METROLOG II-Software The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1500 mm y-travel: 800 mm z-travel: 600 mm total power requirement: kW weight of the machine ca.: 2,7 t dimensions of the machine ca.: 2,66 x 1,60 x 3,10 m Installation and calibration of the machine can be supplied by the manufacturer MDM at site of installation at extra costs. CNC-controlled Coordinate Measuring Machine for fully automatic measuring of workpieces. Incl. Measuring Software MDM Metrosoft Level 2 for measuring of: - Points, surfaces, circles, cylinders, cones, distances and angles. - SPC software for statistic evaluation of the measurements The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

No. 5104: 1 gebr. Coordinate measuring machine / CMM - Hobbyist device / ET carrier - Fabr. WENZEL / NUMEREX, Type 1318-10 Mnl, Bauj. 1987 Arb.-Ber.: 330 x 440 x 180 mm, Other: Space requirement approx. 1 x 1 x 1.5 m Weight approx. 300 kg

DEA SCIROCCO 151310 coordinate measuring machine built in 1997 in Italy, is used to make fast and highly accurate measurements of workpieces with complex shapes. Workpiece measurements are taken using contact or non-contact methods, which are then represented as a set of point coordinates. The dimensions of the measured workpiece are taken using the RENISHAW TP7M measuring probe, which is installed on the RENISHAW PH10MQ indexing head. The measuring probe uses strain gauge technology to eliminate granularity errors and achieve the highest measurement quality in the X,Y,Z axes with feeds of 1500 mm (X axis), 1300 mm (Y axis) and 1000 mm (Z axis). The measuring machine is offered with a wide range of equipment, including an advanced PC-DMIS package for Windows, performing detailed geometric measurements. The total weight of the machine is 3650 kg. Technical data of the DEA SCIROCC ...

Coordinate Measuring Machine STIEFELMAYER - No 1 1 arm type C100 413514 Longitudinal arm travel: 1250 mm Arm travel in height: 1500 mm Electronic command GRUNDIG Marble dimensions: 3000 x 1500 x 350 mm Height on feet: 600 mm (with 6 feet) Weight: approx 4 T 2 same machines available

3-D coordinate measuring machine ZEISS NUMEREX Granite measuring plate, granite measuring plate, measuring table Model No. 3648-18, Serial. No. X-1019, year of construction approx. 1986 Measuring range X = approx. 1250 mm, Y = approx. 900 mm, Z = approx. 400 mm Measuring plate L x W 1525 x 1435 mm Usable area 1525 x 1100 mm Measuring plate thickness 305 mm Passage width in the portal 1100 mm Probe holder 9.5 mm Compressed air connection 6 bar Mains connection 230 Volt, 50 Hz. - Granite plate with steel inserts with internal thread - Axis adjustment with pneumatic sliding guide for X, Y and Z-axis - Plate on base frame with 5 pieces of adjustable feet, 3 pieces support plate for the adjustable feet - Computer and software missing (not available and not included) Space requirement of the measuring machine L x W x H 1600 x 1850 x 2200 mm Weight of the machine approx. 2.8 ton. Plate damage ...

Coordinate measuring machine MITUTOYO BH 305 measuring area: approx. 650 x 500 mm untested ! without measurement technology, computer, software, buttons ! Dimensions: 1090 x 840 x 1900 mm

Ref. -No.: 10157 Manufacturer: CARL ZEISS Year of construction: 1997 Type of control: HP 9000 Serie 700 Control: Betriebsystem HP-UX.9.05 Storage location: Halberstadt Country of origin: Deutschland Turntable: 1000x2100 mm Machine weight: 4.800 kg Machine Height: 3050 mm Table height above the floor: 850 mm X-Axis: 850 mm Y-Axis: 1800 mm Z-Axis: 600 mm Further information: Three coordinate measuring machine Microcomputer control X-axis as a longitudinally movable portal Y-axis cross slide in the portal Z-axis as measuring head quill (vertical) Passage between the portal approx. 1,000 / 1080 mm Passage in height approx. 750 mm

Controls: Heidenhain TNC 360 (1992) Table size: 1,000 x 1,000 mm Table size with extension: 1,345 x 1,000 mm Table load max.: 2,000 kg Distance between the s distance Spindle to table top: 0 - 1,100 mm Travel distances: X 1400 mm Y 900 mm Z 850 mm W 370 mm spindle holder: MK 5 spindle drive power: 6 kW spindle speeds: 30 - 1,500 rpm Drilling spindle diameter: 82 mm drill diameter: 2 - 70 mm Drilling tools Diameter: 17 - 450 mm Drilling capacity to full ST60: 45 mm Drilling capacity to full GG: 70 mm Zubehoer: drills; tools; usw. machine was rebuilt in 1992 and !; Very good

Control: Heidenhain TNC 360 (1992) Table size: 1000 x 1000 mm Table size with front extension: 1345 x 1000 mm Table load max.: 2000 kg Distance spindle centre to column min/max.: 270 ~ 1270 mm Distance spindle nose to table min/max.: 0 - 1100 mm Distance between the upright columns: 1855 mm Table longitudinal travel : 1400 mm Boring ram carriage cross travel: 900 mm Crossrail vertical travel: 850 mm Boring spindle travel: 370 mm Spindle motor rating: 6 KW Spindle speed range: 30 - 1500 rpm Boring spindle diameter: 82 mm Spindle taper: MK 5 Borer diameter: 2 - 70 mm Boring tool diameter: 17 - 450 mm Boring diameter in solid ST 60: 45 mm Boring diameter in solid Cast iron: 70 mm Equipped with: Tooling; Accessories Machine overhauled and retrofitted in 1992 !; Very good

Nibbling machine trump, unloading 1000 mm, copying device, cutting, nibbling, slits, gills, beading, etc.

The OPTIV REFERENCE 763 DUAL Z combines a tactile and optical measurement. The Data acquisition via a switching/measuring switch laser as well as white light sensor (chromatic white light sensor/CWS). Measuring range: 600 x 600 x 300mm. Maximum workpiece weight: 150 kg, when using the Glass plate / transmitted light measurement: 50 kg. Accuracy depending on the measuring procedure: 0.5 -. 1, 3μm. machine weight: 3 000 kg. Dimensions (Lxwxh) machine: 1.805 x 1,918 1,890 mm. service area of min. 600 mm. The machine is active and can by arrangement rootstyle are. If you are interested we can provide the entire machine data to the Available.

Control UCC lite-2 Measuring range 700 x 450 x 350 mm Measuring heads (MH20i, PH1, PH6) Various touch probes

Technical data Table length: 550 mm Table width: 320 mm Longitudinal travel (X-axis): 400 mm Transversal travel (y-axis): 250 mm Vertical travel (z axis): 400 mm Table load max.: 400 kg Drill capacity in steel: 20 mm Taper in spindle: MT: 2 Stroke of drilling spindle (Z-axis): 130 mm Bore diameter max.: 75 mm Distance table to spindle: 590 mm Spindle speeds: stepless from: 60 rpm up to: 3000 rpm Feeds: Drill spindle slide: number (steps): 2 from: 0.03 mm/r up to: 0.06 mm/r Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.80 HP Machine´s weight about: 1100 kg Overall dimensions machine: Length: 1200 mm Width: 1150 mm Height: 1650 mm Various accessories: Lamp

Stand unit with steel plate with C99 control Measuring ranges: x=5000 mm, y=2600 mm, z=2100 mm Measuring plate: 6000 mm x 3000 mm Rotary swivel head RDS for TP Control panel Dynalog Travelling control unit on the stand, opto-coupler, screen, keyboard, mouse Active vibration damping Without software and hardware. We reserve the right to make changes and errors in the technical data as well as to make the interim sale. Price plus transport and installation.

table length: 200 mm table width: 200 mm daylight: 200 mm Control: MAHRSOFT total power requirement: kW weight of the machine ca.: 300 kg dimensions of the machine ca.: 1000 x 1000 x 1950 mm Measuring Machine with optical-, Laser and Mechanical Feeler The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 280 mm y-travel: 460 mm table-size: 280x610 mm table movement: 280x460 mm spindle turning speed range: 40-2500 U/min spindle diameter: mm grinding range: 5,0-125 mm grinding depth: 0,4-5 mm stroke length max.: 92 mm total power requirement: kW weight of the machine ca.: 1,8 t dimensions of the machine ca.: 2x1,5x2,8 m Single Column Jig Grinder, conventional, DRO, accessories The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 125 mm x-travel: 710 mm y-travel: 400 mm z-travel: 200 mm table-size: 1000x630 mm turning speeds: 0-2240 U/min power capacity: 5,5 kW total power requirement: kW weight of the machine ca.: 5 t dimensions of the machine ca.: 3,0x2,5x2,7 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 400 mm y-travel: 250 mm workpiece height: 500 mm grinding diameter max.: 220 mm table surface area: 600 x 320 mm throat: 310 mm range of angles: 12 grad grinding spindle slide - vertical movement: 110 mm stroke speeds: 0 - 6 m/min. grinding spindle speed: bis 50.000 U/min. peripheral speed: max. 35 m/sec capacity: ca. 7 kVA power capacity: 6 kW weight of the machine ca.: 2 t dimensions of the machine ca.: 3 x 3 x 3 m Frequence converter make LANDERT, type SGU 160 - range : 150 - 1330 Hz, feed motion in the table The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 105 mm x-travel: 1200 mm y-travel: 1000 mm z-travel: 325 mm adjustment of cross-rail: 785 mm distance between columns: 1600 mm distance spindle - column min./max.: 215 / 1100 mm spindle feeds - stepless: 1 - 6000 mm/min spindle taper: ISO 40 spindle turning speed - stepless: 40 - 1800 U/min table surface area: 900 x 1500 mm workpiece weight: 2000 kg spindle drive: 5 kW total power requirement: KVA weight of the machine ca.: 6 t dimensions of the machine ca.: 3,3 x 3,0 x 2,8 m dimensions of the machine ca.: 3,3 x 3,0 x 2,9 m • with RENISHAW -detector OMP 40, • mechanical refurbishing and new control HEIDENHAIN TNC 410 in year 2002 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Distance between the columns: 1700mm, table dimensions: 1000x1180mmm, max. load: 3t, length: 2600mm, width: 1900mm, height: 2660mm, weight: 10t, including documentation.

Light barriers: Sick 14-FGS, inverter/ control: HWS 2102, control: Siemens Simatic OP37/Pro.

X-travel: 700mm, y-travel: 450mm, z-travel: 450mm, max. load: 500kg, table dimensions: 1100x820mm, connected load: 1500VA, weight: 1.02t, with documentation.

X-travel: 2500mm, y-travel: 1000mm, z-travel: 1200mm, software: Metrosoft CM.

Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Table length: 0 mm Table width: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 1100 mm Table width: 842 mm Longitudinal travel (X-axis): 1000 mm Transversal travel (y-axis): 795 mm Vertical travel (z axis): 800 mm Table load max.: 800 kg Drill capacity in steel: 55 mm Taper in spindle: MT: 4 Stroke of drilling spindle (Z-axis): 250 mm Bore diameter max.: 300 mm Spindle speeds: number (steps): 18 from: 40 rpm up to: 2000 rpm Feeds: Table: stepless up to: 300 mm/min Drill spindle slide: number (steps): 6 from: 0.04 mm/r up to: 0.35 mm/r Rapid traverse: Table:longitudinal: 2500 mm/min transversal from: 2500 mm/min Distance between columns: 1100 mm Distance between spindle and table: 900 mm Voltage 50 Hz 3x: 380 Volt Spindle motor: 4.00 HP Total power required: 8.0 HP Machine´s weight about: 7500 kg Overall dimensions ma ...

Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Table length: 0 mm Table width: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 400 mm Table width: 300 mm Longitudinal travel (X-axis): 200 mm Transversal travel (y-axis): 200 mm Verticla travel (W-axis): 250 mm Drill capacity in steel: 10 mm Drill depth (spindle stroke): 70 mm Distance table to spindle: 320 mm Spindle speeds: stepless from: 150 rpm up to: 3000 rpm Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.5 HP Machine´s weight about: 700 kg Overall dimensions machine: Length: 1200 mm Width: 1000 mm Height: 1800 mm Various accessories: Digital readout number of axis:: 2 Drill chuck Centering microscop Set of collets

Without software, documentation available.

Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Table length: 0 mm Table width: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 400 mm Table width: 300 mm Longitudinal travel (X-axis): 200 mm Transversal travel (y-axis): 200 mm Verticla travel (W-axis): 250 mm Drill capacity in steel: 10 mm Drill depth (spindle stroke): 70 mm Distance table to spindle: 320 mm Spindle speeds: stepless from: 150 rpm up to: 3000 rpm Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.5 HP Machine´s weight about: 700 kg Overall dimensions machine: Length: 1200 mm Width: 1000 mm Height: 1800 mm Various accessories: Digital readout number of axis:: 2 Manufacturer: HEIDENHAIN Rotary table diameter: 300 mm Drill chuck Boring head Microscope Centering divice with dial indicator Set of collets Lamp

Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Table length: 0 mm Table width: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 550 mm Table width: 320 mm Longitudinal travel (X-axis): 400 mm Transversal travel (y-axis): 250 mm Vertical travel (z axis): 400 mm Drill capacity in steel: 20 mm Taper in spindle: MT: 2 Stroke of drilling spindle (Z-axis): 130 mm Bore diameter max.: 75 mm Distance table to spindle: 600 mm Spindle speeds: stepless from: 120 rpm up to: 3000 rpm Feeds: Drill spindle slide: number (steps): 2 from: 0.03 mm/r up to: 0.06 mm/r Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.75 HP Machine´s weight about: 1500 kg Overall dimensions machine: Length: 1400 mm Width: 1500 mm Height: 2100 mm Various accessories: Tool cabinet Drill chuck Set of drills Set of milling cutters

Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Table length: 0 mm Table width: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 400 mm Table width: 300 mm Longitudinal travel (X-axis): 200 mm Transversal travel (y-axis): 200 mm Vertical travel (z axis): 250 mm Drill capacity in steel: 10 mm Taper in spindle: MT Drill depth (spindle stroke): 70 mm Distance table to spindle: 320 mm Spindle speeds: stepless from: 150 rpm up to: 3000 rpm Feeds: Drill spindle slide: from: 0.015 mm/r Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.5 HP Machine´s weight about: 700 kg Overall dimensions machine: Length: 1200 mm Width: 1000 mm Height: 1800 mm Various accessories: Digital readout number of axis:: 2 Manufacturer: PHILIPS Drill chuck Set of boring head Centering microscop Set of drills Device for laying out

Max. workpiece height: 200mm, max. load: 150kg, length: 1300mm, width: 1274mm, height: 1940mm, weight: 1.1t.

Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Table length: 0 mm Table width: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 400 mm Table width: 300 mm Longitudinal travel (X-axis): 200 mm Transversal travel (y-axis): 200 mm Vertical travel (z axis): 250 mm Drill capacity in steel: 10 mm Taper in spindle: MT: 0 Drill depth (spindle stroke): 70 mm Distance table to spindle: 320 mm Spindle speeds: stepless from: 150 rpm up to: 3000 rpm Feeds: Drill spindle slide: from: 0.015 mm/r Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.5 HP Machine´s weight about: 700 kg Overall dimensions machine: Length: 1200 mm Width: 1000 mm Height: 1800 mm Various accessories: Digital readout number of axis:: 2 Manufacturer: ELESTA Rotary table diameter: (Ref. 0330.2) Ø 300 mm Drill chuck Set of boring head Microscope Centering microscop Centering divice with dial indicator Set of collet ...

Y-travel: 500mm, z-travel: 450mm, including measuring probes and documentation, software is faulty, machine cannot be started properly.

Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Table length: 0 mm Table width: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 550 mm Table width: 320 mm Longitudinal travel (X-axis): 400 mm Transversal travel (y-axis): 250 mm Vertical travel (z axis): 400 mm Table load max.: 400 kg Drill capacity in steel: 20 mm Taper in spindle: MT: 2 Stroke of drilling spindle (Z-axis): 130 mm Bore diameter max.: 75 mm Distance table to spindle: 590 mm Spindle speeds: stepless from: 60 rpm up to: 3000 rpm Feeds: Drill spindle slide: number (steps): 2 from: 0.03 mm/r up to: 0.06 mm/r Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.80 HP Machine´s weight about: 1100 kg Overall dimensions machine: Length: 1200 mm Width: 1150 mm Height: 1650 mm Various accessories: Lamp

Technical data Table length: 550 mm Table width: 320 mm Longitudinal travel (X-axis): 400 mm Transversal travel (y-axis): 250 mm Vertical travel (z axis): 400 mm Drill capacity in steel: 20 mm Taper in spindle: MT: 2 Stroke of drilling spindle (Z-axis): 130 mm Bore diameter max.: 75 mm Distance table to spindle: 600 mm Spindle speeds: stepless from: 120 rpm up to: 3000 rpm Feeds: Drill spindle slide: number (steps): 2 from: 0.03 mm/r up to: 0.06 mm/r Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.75 HP Machine´s weight about: 1500 kg Overall dimensions machine: Length: 1400 mm Width: 1500 mm Height: 2100 mm Various accessories: Digital readout number of axis:: 2 Manufacturer: ACU RITE III Rotary table diameter

X-travel: 300mm, y-travel: 490mm, z-travel: 290mm, with software and documentation.

Technical data Table length: 550 mm Table width: 320 mm Longitudinal travel (X-axis): 400 mm Transversal travel (y-axis): 250 mm Vertical travel (z axis): 400 mm Table load max.: 400 kg Drill capacity in steel: 20 mm Taper in spindle: MT: 2 Stroke of drilling spindle (Z-axis): 130 mm Bore diameter max.: 75 mm Distance table to spindle: 590 mm Spindle speeds: stepless from: 60 rpm up to: 3000 rpm Feeds: Drill spindle slide: number (steps): 2 from: 0.03 mm/r up to: 0.06 mm/r Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.80 HP Machine´s weight about: 1100 kg Overall dimensions machine: Length: 1200 mm Width: 1150 mm Height: 1650 mm Various accessories: Digital readout number of axis:: 3 Manufacturer: PHILIPS Rotary table diameter: 380 mm

Control: CNC 314 / POSELESTA II / (X, Y, Z, W) Operating hours: 13000 Technical data Table length: 600 mm Table width: 380 mm Longitudinal travel (X-axis): 400 mm Transversal travel (y-axis): 250 mm Vertical travel (z axis): 450 mm Table load max.: 300 kg Drill capacity in steel: 30 mm Taper in spindle: ISO: 30 Stroke of drilling spindle (Z-axis): 140 mm Bore diameter max.: 220 mm Distance table to spindle: 0 - 550 mm Spindle speeds: stepless from: 30 rpm up to: 4000 rpm Feeds: from: 500 mm/min up to: 1000 mm/min Drill spindle slide: number (steps): 4 from: 0.01 mm/r up to: 0.23 mm/r Voltage 50 Hz 3x: 380 Volt Machine´s weight about: 3500 kg Overall dimensions machine: Length: 1900 mm Width: 1700 mm Various accessories: Manufacturer: ELESTA Visulesta II

Table size 2500x1500 mm X Travel 1200 mm Y Travel 1800 mm Z Travel 1000 mm Measuring head VAST XT

X-travel: 300mm, y-travel: 200mm, z-travel: 200mm, operating system: Windows 7, software: WinWerth 8.40, weight: 1.5t.

Measuring range: 400x200mm, with Instruction Manual, the PC needs to be replaced.

X-travel: 700mm, y-travel: 1000mm, z-travel: 660mm, resolution: 0.039μm, max. load: 900kg, measuring plate height: 600mm, weight: 1.255t, operational hours counter: ca. 10,000h, with documentation.

X-travel: 400mm, y-travel: 500mm, z-travel: 300mm, max. workpiece weight: 50kg, resolution: u1=(3.4+L/200)µm, touch probe: PH6/TP2, software: U-Soft 9.04, operational hours: unknown, with documentation, without accessories, has been regularly maintained and calibrated.

X-travel: 300mm, y-travel: 300mm, z-travel: 200mm, accuracy: E1 = (2.0 + L/300) μm mm, E2 = (3.0 + L/300) μm mm, E3 = (3.9 + L/300) μm mm, magnification: 1.5x, connected load: 1kW, in 2020 the machine has received a current version of the measuring software SaPHIR and Windows 10, after 2021 the machine has been used only rarely and has not undergone any maintenance/calibration, the Z-axis needs lubrication.
