compensation used for sale

Specifications: Uniform spindle spacing: 32 mm Number of spindles: 23 Distance between the first and last spindle on the drill head: 672 mm drilling depth: 80 mm Table size: approx. 900 x 545 mm size of the workpiece: 800 x 2500 x 100 Working pressure: 0.6 MPa Air consumption: 10 NL/cycle Voltage, frequency: 400 V/50 Hz Spindle speed / min.l: 2800 rpm. Motor power: 1.5 kW Weight ca: 400 kg Dimensions: 1220 x 1065 x 1400 mm Patented spiral system Programming and adjustment devices of horizontal and vertical Drilling depth. Pneumatic drill head shears Drill head frame of 0-90 degrees with blocking in any position and reference switching angle with each angle Head with quick-connect spindles (the quick-release buckets are a Zubehoer). 5 quick-release buckets are standard. 2 patented pneumatic pressure devices accident-protected. 2 side connectors on the table ...

Generalin travelling column construction NEW DMG MORI Design swivel head (B-axis) tool clamping according to DIN 69872; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal2600 mmCross1100 mmVertical900 mmTechnical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical80/60/60 m/minTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight15 KgMax. tool length500 mmMax. tool diameter with occupied adjacent pockets115 mmMax. tool dia. with free neighbouring pockets160 mmDirect measuring systemDirect path measuring systemCabineFull protection cabinDynamic package for DMF 260 linear (Y1100)Dynamic package for DMF 260 linear (Y1,100 mm) linear drive X-axis with 80 m/min // 262.48 ft/min rapid move XYZ 80/60/60 m/min // 262.48/196.86 ft/min, Acceleration XYZ 5/6/6 m/s² // 16.4/ ...

belt width: 150mm; belt length: 3000mm; table size: 960mm x 350mm; table for rounds: 330mm x 330mm; veneer grinding unit: ja; oszillation: ja; grinding unit tiltable: ja 90° - 45°; suction connection: 120mm; motor power: 3 kW; machine length: 1910mm; machine width: 840mm; weight: 330kg; properties Heavy machine stand in torsion and vibration-free design, extremely stable Grooved feed ruler, ideal for grinding veneer supernatants Double-sided suction connection 80/100 mm for optimum chip removal Oscillating sanding belt ensures a high removal rate and a clean sanding pattern Maintenance-free grinding belt oscillation with separate gearmotor, optionally switchable Height-adjustable sanding table for utilization of the entire sanding belt Standard veneer edging device with fine adjustment Fast conversion from veneer to solid wood sanding possible Height adjustment of the  ...

Complete sprinkler system manufacturer R-CON, Sweden The plant is in very good condition as only one annual test run was carried out. Service documents available, including all components. incl. safety tank for water 200 m3 (for compensation in case of external water interruption) 552 sprinklers 1.3 km water pipes 2-3 m distance between sprinklers New safety engines

GeneralUniversal machining centre New DMG MORI Design; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal400 mmCross400 mmVertical375 mmTechnical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmFloor space/WeightWeight approx.6800 KgDimensions (L x W x H)6,21 x 6,58 x 2,69 (6,21 x 7,38 x 2,69) mSpindle speed 28.000 rpm HSK-A63Spindle speed 20 up to 28.000 U/min Motor spindle with shaft cooling power 30/20 kW // 40.23hp/ 26.82 hp (40/100% DC) torque 40/27 Nm (40/100% DC) tool clamping HSK 63 according to DIN69893 (different from standard)Chain-type tool magazine 60 po ...

GeneralHorizontal Machining Centre in travelling column construction; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical100000/100000/100000 mm/minRapid traverse longitudinal/transverse/vertical100/100/100 m/minWorking area 1Longitudinal630 mmCross800 mmVertical750 mmIntegrated motor spindle speedMASTER®Drive power (100% DC) 30 kWDrive power (40% DC) 46 kWTorque (100% DC) 130 NmTorque (40% DC) 200 NmSpeed range - 15000 rpmSpindle taper HSK-A 63CabineFull protection cabinDirect measuring systemDirect path measuring systemNC swivel rotary tableNC swivel rotary table with pallet carrier max. table load: 400 kg / 882 lbs rotation B axis: 360° swivel range A axis: 25° / -200° range X / Y / Z - axis 630 x 800 x 750 mm/24.8 x 31.5 x 29.5 in axis kinematics A / B (basic machine without NC rotaryClamping hydraulics 2/4 channels f. working tabl ...

Kallfass Universa 400 with shrink tunnel and grab section Kallfass Universa 400 NT Year of construction 2003 The system is immediately available. The Universa 400 is included in the price of the complete system. The machine is technically overhauled and is in very good condition. Technical data: - Length of cross welding punch: 450mm - Welding punch passage: max. 200mm - Min. product length: 80mm - automatic length compensation to reduce the punch gap - Welding punch monitoring - Side sweat monitoring - Foil holding plate Pwq9ya - Control: Siemens S7-300 - Operating terminal with Sütron BT20 - Welding punch with replaceable welding strip - Side welding wheel-knife combination, can also be exchanged for a knife system - Processable films PE and PO - Year of construction 2003 - Shrink tunnel Kallfass Standard - Gripper section with inline belt - Curved band can be ...

Kallfass Universa 400 with shrink tunnel and grab section Kallfass Universa 400 Year 2006 The system is immediately available. The Universa 400 is included in the price of the complete system. The machine is technically overhauled and is in very good condition. Technical data: - Length of cross welding punch: 450mm - Welding punch passage: max. 200mm - Min. product length: 80mm - automatic length compensation to reduce the punch gap - Welding punch monitoring - Control: Siemens S7-300 - Operating terminal with Siemens touch panel - Welding punch with replaceable welding strip - Side welding knife combination, can also be exchanged for a wheel knife system - Processable films PE and PO - Year of construction 2006 - Kallfass Compact 450 SO shrink tunnel - Gripper section with inline belt - Book magazine on gripper section - Ionization for blocking loose leaves - Cur ...

Single stand - eccentric press KRUPP type PEKRD 125 h Masch. No. 2861 Year of construction 1977 Compressive force 125 ton. Projection 400 mm Table size 950 x 750 mm Ram surface 800 x 540 mm Table opening 100 x 250 mm Stroke adjustment 8 to 160 mm Ram adjustment 100 mm Installation height largest stroke top max. 550 mm Number of strokes 60 strokes/min. Table height above corridor 800 mm Motor power 10 kW Mains connection 380 Volt, 50 Hz - Hydraulic overload in the tappet - Compressed air Clutch-brake combination ORTLINGHAUS - Ram weight compensation cylinder - Motorized ram position - Table top with ball rollers - Two-hand operation - Grease central lubrication HELIOS- Stroke counter - UVV 7n 5.1 §4a, paragraph 2 No. 3b for manual insertion work Space requirement L x W x H 2300 x 1800 x 3200 mm Weight approx. 10 tons. good condition (very little used); used

Roller feed, feeder Roller width: 50 mm Roller diameter: 80 mm Shaft diameter at feed: 22mm with keyway - 2 pieces feed rollers with rubber coating - top roller is driven - Stroke movement of the lowest roller via 2 pneumatic cylinders - 2 pieces pneumatic short stroke cylinder - 4 column guides for the lower movable feed roller - Coupling with flex oscillating element for torsion-free drive and axle compensation between drive motor and roller feed coupling 22 mm on motor shaft 30 mm with keyways Dimensions L x W x H: 200 x 140 x 320 mm Weight: 30 kg good condition; used

Single Stand - Eccentric Press PELS - RICHTER Type PEKR 125 Masch. No. 20684 Year of construction 1967 Compressive force 125 ton. Projection 430 mm Table size 1100 x 750 mm Ram surface 890 x 650 mm Table opening 400 mm Stroke adjustment 6 to 115 mm Ram adjustment 100 mm Installation height largest stroke above max. 450 mm Clamping pin bore 50 mm Stroke rate 60 strokes/min. Table height above corridor 900 mm Motor power 7.5 kW Mains connection 380 volts, 50 Hz - Overload protection by crushing plate in the plunger - Compressed air Clutch-brake combination DESCH- Plunge weight compensation cylinder - Manual ram position - Two-hand operation - Cam switchgear - Grease central lubrication Vögele - Stroke counter Space requirement L x W x H 2300 x 1450 x 3030 mm Weight approx. 10 ton. good condition; used

GeneralUniversal Machining Centre in monoBLOCK construction - MPC Machine Protection Control - Chip trough; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal750 mmCross650 mmVertical560 mmTechnical DataDrive power (100% DC)25 kWDrive power (40% DC)35 kWTorque (100% DC)86 NmTorque (40% DC)130 NmSpeed range- 20000 rpmSpindle taperHSK-A 63 Clamping SystemHSK-A 63 Feed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minTool changerTool changer planevertical Type of gripperDouble gripper Number of tools120 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.12300 KgMiscellaneousClamping SystemDIN 69872 NC swivel rotary tableTable surface Ø 650 mm5. Axes (swivelling range) +/- 120 degree4. Axes (swivel ...

Standard configuration Machine ? Stable C-frame for easy access ? Coordinate guide for high-precision machining ? Linear magazine, 3 clamps ? Maintenance free drives ? Repositioning device with programmable presser foot ? Parts chute 500 x 500 mm ? Good parts container ? Swarf bucket Cutting head ? Hydraulic punching head ? Single tool adapter ? 360? rotation of all tools ? Programmable presser foot ? Tool length compensation ? Spray lubrication for punches ? Vacuum slug removal ? Forming Control ? Open control system based on BOSCH ? Control panel with TFT colour screen 12.0? ? Program management ? Online-help ? Integrated technology data ? Diagnostic functions ? Teleservice Programming ? Machine-oriented shopfloor programming Data transmission ? Disc drive and network connection Safety ? CE marking ? Light barriers ? Rapid hydraulic shutdown Additional equipment ? Function Mul ...

Standard configuration Machine ? Stable C-frame for easy access ? Coordinate guide for high-precision machining ? Linear magazine with 17 tool stations, 2 clamps ? Drives with maintenance free 3-phase servo motors ? Repositioning unit with programmable stripper ? Ball tables ? Parts chute 180 x 150 mm ? Swarf bucket ? Punching head ? Hydraulic punching head ? Rotatable single tool adapter ? 360? rotation of all tools ? Programmable presser foot ? Tool length compensation ? Spray lubrication for punches ? Vacuum slug removal ? Forming Control ? Controller based on Bosch PNC-P ? Control panel with 15 TFT color touch screen ? Easy to use ? Online-help ? Integrated USB interface ? RJ 45 network connection ? Diagnostic functions Safety ? CE marking ? Light barriers ? Rapid hydraulic shutdown Additional equipment ? Function Multitool ? Function MultiShear ? Function Roller Technology ?  ...

GeneralUniversal Machining Centre Vertical headstock Tool change system double gripper NC-Swivel rotary table with pallet carrier 3 pallets 500 mm x 500 mm / 19.7 in x 19.7 in T-slots according to DIN 55201-A2 linear pallet changer coolant tank 500 l / 132 gallon chip conveyor with netting band filter integrated, coolant ring jet; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmFloor space/WeightWeight approx.18300 KgDirect measuring systemDirect path measuring systemCabineFull protection cabinNC swivel rotary table with pallet carrierTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 500 KgMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000  ...

GeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Working area 1Longitudinal700 mmCross420 mmVertical380 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMain driveDrive power (100% DC) 6 kWDrive power (40% DC) 8,5 kWTorque (100% DC) 41 NmSpindle taper BT 30Speed range 20 - 15000 rpmTorque (40% DC) 48 NmClamping System ISO 7388-3 - JD30ToolchangertoolchangerType of magazine DiskNumber of tools 25Integrated swivel rotary table simultaneousIntegated swivel rotary table 5-Axis simultaneous mode! Torque drives incl. direct measuring in A- and C-Axis Swivel range A-Axis -120 / + 100 degrees Max. load C-axis 100kg Table diameter C-Axis d290mm Rotary joint, 4-channels Inclusive Software packageProduction package band filter ICS 40ba ...

GeneralUniversal milling and turning machining centre with duoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal800 mmVertical850 mmCross1050 mmTool changerApplicationUniversal Type of magazineWheel Tool changer planehorizontal Type of gripperDouble gripper Number of tools123 NC mill-turn table with palletNC mill-turn table with pallet number of T-slots: - 1x cross slot 14 H7 / 0.55 H7 - 12x star slots 14 H12 / 0.55 H11 / 22.5° max. table speed milling operation: 30 rpm turning operation: 800 rpm integrated balancing sensor Pallet changer for 2 palletsType of Measuring system Direct measuring systemTable surface Ø 800 x 630 mmCentre bore 50 mmMaximum load (table centre) 1400 Kg4. Axes (swivelling range) 360  ...

GeneralUniversal milling and turning machining centre with duoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal800 mmCross1050 mmVertical850 mmTool changerApplicationUniversal Type of magazineWheel Tool changer planehorizontal Type of gripperDouble gripper Number of tools123 NC mill-turn table with palletNC mill-turn table with pallet number of T-slots: - 1x cross slot 14 H7 / 0.55 H7 - 12x star slots 14 H11 / 0.55 H11 / 22.5° max. table speed milling operation: 30 rpm turning operation: 800 rpm integrated balancing sensor Pallet changer for 2 palletsType of Measuring system Direct measuring systemTable surface Ø 800 x 630 mmCentre bore 50 mmMaximum load (table centre) 1400 Kg4. Axes (swivelling range) 360  ...

-Load capacity: adjustable from 600 – 3000 kg -Effective height : from 1300 – 2000 mm -Tine length : 1000 mm Fvmfedlvq -Tine cross-section : 120 x 50 mm -Total height: 1720 – 2420 mm -Net weight : 260 kg These crane forks are equipped with adjustable tines, height adjustment and automatic weight compensation. In the case of self-balancing forks, the support tines tilt upwards when the load is lifted. This prevents the load from slipping out unintentionally. The suspension eyelet is movably mounted via a subframe. The automatic self-balancing is carried out by a gas pressure spring when the fork is loaded. This ensures that the suspension point is always in the centre of gravity of the fork and that the load picked up is transported absolutely safely.

Standard configuration ? Stable C-frame ? Coordinate guide with integrated linear magazine, 18 tool stations, automatic tool changer, 3 clamps ? Automatic parts chute 500 x 500 mm ? Parts container ? Drives: Maintenance-free, three-phase servo motors ? Programmable presser foot for repositioning ? Punching head: Hydraulic single tool adapter, 360? rotation of all tools, automatic tool length compensation, spray tool lubrication, 2nd lubricant container, programmable stripper movement, vacuum slug removal, swarf bucket ? Control: 32 bit microprocessor control TRUMAGRAPH CC 220 S, 10.4 color screen, programmable logic controller, easy to use, diagnostic functions, graphic programming TRUMAGRAPH, integrated 3.5 disk drive, RJ45 network connection ? Safety: CE marking, multi-beam light barriers, rapid hydraulic shutdown Additional equipment ? Function MultiTool ? Pneumatic repositioning  ...

Standard configuration Machine ? Stable C-frame for easy access ? Coordinate guide for high-precision machining ? Linear magazine, 21 tool stations, 3 clamps ? Drives with maintenance free 3-phase servo motors ? Repositioning unit with programmable stripper ? Ball tables ? Sensor-monitored parts chutes 500 x 500 mm for punching and laser station, ejection cylinder on the laser chute ? 2 Good parts containers ? AutoLas TRUMPF Laser ? Laser unit: TruFlow 2700 CO2-Laser ? Radio-frequency excitation ? Chiller unit ? Laser control: TASC 3 ? Encapsulated beam delivery Cutting head ? Cutting head with 5.0 and cutting head with 7.5 lens focal length ? Cutting head quick-change device ? Programmable cutting gas pressure ? DIAS ? ContourLas Punching head ? Hydraulic punching head, 360? rotation for all tools ? Programmable presser foot for repositioning ? Tool length compensation ? Vacuum slu ...

GeneralUniversal Milling Machine; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal650 mmCross520 mmVertical475 mmFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgTechnical DataType of main driveAC Drive power (100% DC)30 kWDrive power (40% DC)46 kWSpeed range20 - 15000 rpmSpindle taperHSK-A 63 Clamping SystemHSK-A 63 Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minSpindle speed 15,000 rpm, 200NmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 15,000 min-1 Output 46 kW / 30 kW (62 hp / 40 hp) Torque 200 Nm / 130 Nm (148 ft lbs / 96 ft lbs) (40 / 100 % duty cycle)NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 630 x 500mm / 24.8 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring sy ...

GeneralTravelling column machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal3000 mmCross1100 mmVertical1050 mmFeed drives:Feed rate X / Y / Z80000/80000/80000 mm/minRapid feed X / Y / Z80/80/80 m/minNC-swivel head (B-axis)Controlled NC-swivel milling head (B-axis) with clamping in position. Continuously positioning NC swivel milling head with integrated motor spindle for 4/5 axes positioning and simultaneous machining. Swivel torque: 3,300 / 2,300 Nm // 2,433 / 1,696 ftDynamic package for DMF 300|11 linearDynamic package for DMF 300|11 linear Linear motor X-axis with 80 m/min // 262.48 ft/min Rapid speed XYZ 80 m/min // 262.48 ft/min Acceleration XYZ 8 m/s² // 26.25 ft/s² Active cooling for Linear motorPackage Mill / Turn 12,000 rpm, HSK-A100Package Mill / Turn, 12,000 rpm HSK-A100 (Only available for Siemens 840D solutionline) NC-Mill-Turn-table d 1,050 mm  ...

GeneralUniversal machining centre; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minWorking area 1Longitudinal600 mmCross500 mmVertical500 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmDie and Mold Package linear incl. B-/C-TorqueDie and Mold Package linear incl. B-/C-Torque Dynamic package V-type Eagle timing belt for Z axis Torque table B-/C-axis including ATC AVD - Heidenhain or MVC - Heidenhain (starting NC 340590 11) APC and Top Speed - Siemens High End cooling unit for machiSpindle speed 20.000 rpm, HSK-A63Motor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20,000 min- ...

Standard Configuration ? Stable C-frame ? Coordinate guide with integrated linear magazine, 19 tool stations,2 clamps ? Drives: Maintenance-free, three-phase servo motors ? Programmable presser foot for repositioning with preselectable pressing force ? Sensor-monitored part chutes 500 x 500 mm for punching and laser station, ejection cylinder on the laser chute ? 2 good parts containers ? Laser unit: CO2 laser TLF2700, radio-frequency excited, insulated against vibrations, integrated in machine frame, incl. chiller, and laser control DIAS 3 ? High speed processing with SprintLas ? ContourLas for producing small holes ? Programmable cutting gas pressure setting ? Punch stroke / thread counter ? Laser cutting head: 5? lens, quick-change device, height regulation APC ? Additional laser cutting head with 7.5? lens ? Punching head: Hydraulic single tool adapter, 360? rotation of all tools,  ...

: neu : ca. 6 Monate ab Auftragse : Taiwan : 70300 € : 1406 € : 620 mm : 1.000 x 400 mm : 1.015 x 405 x 610 mm : 1015 mm : 400 x 1.000 mm : 1050 mm : 1100 mm : 5 - 25 m/min : 0 - 2,250 mm/min : 3 - 32 mm : 420 mm : 0.001 : 3.7 kW : 1.5 kW : 1 kW : 1 kW : 6,3 kW : 4280 mm : 1730 mm : 2080 mm : 3500 kg : 355 x 50 x 127 mm : 1.450 U/min : 0,001 - 0,04 mm : 675 mm/min : 0,001 mm 10,4", grafic NC-control on swiveling arm with touch screen for: - seletion of working mode, program creation, graphic condition control, alarm list aut. vertical feed servo drive for grinding wheel feed and table cross feed hardened slide ways in all 3 axes with needle rollers electro-magnetic chuck coolant equiptment with aut. paper filter and magnetic separator autom. dressing attachment with diamond, with compensation device grinding wheel grinding wheel flange grinding wheel balancing scale balance arbor ...

x-travel: 8.000 mm y-travel: 3.800 mm z-travel: 2.100 mm Control: HEIDENHAIN iTNC-530 table-size: 8.500 x 2.500 mm distance between columns: 3.100 mm rapid travel x/y/z: 15/12.000 mm/min feed: 5.000 m/min milling head: Automatisch Drehung 4/5 number of spindle speeds: 4.000 U/min/rpm spindle drive: 37 kW transmission ratio: 2 Stufen table weight: 35.000 Kg distance spindle /table: 500-1.750 mm rapid travel x/y/z: 10.000/12.000 mm/min feeds:: 7.000 mm/min dimensions of the machine ca.: 19.370 x 5.850 x 5.970 mm tool change unit: 30 pos. weight of the machine ca.: 93 t - 5 AXIS BRIDGE TYPE MILLING MACHINES Max height table to underside bridge 2.100 mm Min/max distance table to spindle 500-1.750 mm Rapid Feed (X Axis) 10.000 mm/min Rapid Feed (Y,Z Axis) 12.000 mm/min Max. Working Feed 7.000 mm/min Automatic head C5 E INCLUDED B-Axis head swivel ± 190º C Axis head rotation ± 360º ...

CNC vertical machining center HERMLE C 42 V With path control Heidenhain iTNC 530 Year of construction: 2016 Travel : X 800 Y 800 Z 550 Speed range: 20 – 42,000 rpm continuously variable (HSK 40) With the following accessories: Rigid angle table 1050 mm x 805 mm clamping surface Vertical tool changer with 42 magazine slots ( HSK 40) Linear axis dynamics , remote maintenance Blow-off device Coolant equipment , Chip tray Manual cabin door , Manual cabin roof Polycarbonate safety glazing Electronic heat compensation iTNC 530 Electr. Manual operating module HR 410 BLUM Laser A1 rigid table , mod. BLUM A1 with optics BL 104 3 D touch probe Heidenhain Control cabinet cooling unit ( RITTAL) Status light 7-fold media connection rigid table 4 pieces of height-adjustable machine shoes Operating instructions THE MACHINE ONLY MILLED BRASS PARTS Absolutely MINT C ...

diameter: 400 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m 1 piece 3-jaw power chuck make FORKARDT type 3WF 400 K15 S23 Ø 400 mm with centrifugal force compensation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

working width: 1000 mm workpiece width - max.: 0,5 - 50 mm sandingbelt width: -- mm weight of the machine ca.: 2,5 t With the SBM-L 1000 G1S2, which works in the dry process, in alternating operation Steel, stainless steel and aluminum can be machined. She deburrs and rounds the edges on the outer and inner contours of punched, laser, fine plasma or water jet cut workpieces with a thickness of up to 50 mm on both sides in just one operation. Two sanding units, 1 each on the top and bottom, remove spatter and slight burrs on outside and inside edges of sheet metal. A total of four sanding belts, 2 each on the top and bottom Underside, process the sheets on both sides at the same time. here All edges are softened or rounded, depending on the tool settings. Machining on both sides saves time-consuming turning of the workpieces and edit twice. All pairs of aggregates can be switched on/o ...

DENER SERVOBRAKE 4015 CNC press brake which was built in Turkey in 2016, guarantees the highest quality of workpiece machining with simultaneous low energy consumption and low operating costs. Distinguished by its sturdy construction and state-of-the-art technology, the machine is equipped with a powerful electric drive based on servomotors and belts with a multi-belt system. Replacing the standard hydraulic system with an electric drive makes the SERVOBRAKE DENER DDM 4015 servo press brake much easier to maintain and faster than conventional hydraulic presses. This is possible because the machine is free of hydraulic oil, filters, seals and other hydraulic components. The electric drive also eliminates the occurrence of the so-called deflection arrow and its compensation through even force distribution on the slider. The DENER servo electric press brake is also equipped with an in ...

T60C sliding table saw in CE equipment • Control 3.5" in control panel at eye level included • Handwheel for adjusting the parallel stop from operating position, digital display included • Cutting width 1,350 mm included Trimming table length 3.3 m Cutting width 1,350 mm "2-axis scoring unit, electric Scratch position left/right and scratch height can be positioned via control while the scoring saw is running, electronic display of the adjustment paths; automatic adjustment of the scoring system to each main saw blade; Blade change with ProLock; pneumatically liftable / lowered, separately from the main saw blade can be switched on / off; 0. ...

Brand Martin Type T75PreX Year of construction: 2021 New exhibition MA7502050 sliding table saw T75 PreX with large screen 10.4" touchscreen T75P05-b "Option package 2, consisting of: Infinitely variable speed control 9.5 kW T7503-a Electromotive positioning of the parallel fence T7511-a Scoring system ""PreX"" 3-axis - scoring unit T7523-a" T7503-a engine power 9.5 kW (13 hp) S6-60%, with infinitely variable speed control for the main saw blade, adjustable from 2,000 - 6,000 rpm; modern, maintenance-free passive cooling of the inverter T7508/4-a: trolley: 3,300 mm T7509/3-a cutting width: 1350 mm T7511-a "Electromotive positioning of the parallel fence Measurement specification and digital dimension display in the control system; Ruler can be folded, position queried via sensor; complete in ...

CHP basic module agenitor 212 (fully mounted on steel frame with vibration decoupling) - Motor with accessories - Gas controlled system - Gas mixer -Generator -Voltage regulator - Cos-phi regulator -Clutch - Switchgear and control system - Exhaust silencer made of stainless steel CHP power field - Separate control cabinet with load switch and mains monitoring Heat exchanger cabinet, pre-piped mounted in steel frame - Heat extraction / hydraulic system - 3-way mixer emergency cooling circuit - electric circulating pump, mixture cooler - 3-way mixer mixture cooling circuit - Pressure compensation tank - Plate heat exchanger as transfer heat exchanger - electric circulating pump heating side - 3-way mixer return temperature increase Mixture cooler as table cooler Emergency cooler as table cooler to dissipate excess thermal energy. The entire thermal energy fro ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS with Siemens Sinumerik ONE Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minIntegrated motor spindle speedMASTER®Drive power (100% DC) 25 kWDrive power (40% DC) 35 kWTorque (100% DC) 86 NmTorque (40% DC) 130 NmSpeed range - 20000 rpmSpindle taper HSK-A 63 DIN 69893Clamping System HSK-A 63NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and working plane transformationClamping pneumatic, two circuitsClamping pneumatics, 2 clamping circuits for standard machineTool clamping for HSK-A63Tool clamping HSK-A63 accordi ...

Spot welding equipment, Power: 70kVA at 50%, with electronic control SERRATRON 1B that allows: 127 welding programs Integrated programming unit Full Ethernet+TCP/IP connectivity at 10/100 Mbps Wide range of welding functions: ON/OFF, SEQUENCE... Proportional valve control Sequence with 3 welding times Electrode wear compensation

DMG DMC 160U DUOBLOCK WITH 6 PALLET CHANGER Manufacturer DMG Model DMC 160U duoBLOCK Year 2008 CNC SIEMENS 8400 Powerline 3D Table Rotary pallet changer INCLUDED Rotary pallet storage RS4 – 4 pallets + 2 pallets in machine INCLUDED Total pallets 6 Pallet surface 1.250×1.000 mm. T Slots DIN 55201-A2 Table turning range (C Axis) 0,001 º (Continuous) Travels and feeds Longitudinal travel (X Axis) 1.600 mm. Cross travel (Y Axis) 1.250 mm Vertical travel (Z Axis) 1.000 mm. Main Spindle Automatic swivel milling head 0.001 º (Continuous) Rapid Traverse 60.000 mm/min Spindle taper HSK-A 63 DIN 69893 Spindle speed 20-30.000 rpm Main spindle power 85/65 kW Main spindle torque 40/32 Nm Automatic tool changer Type Horizontal double gripper ATC positions 120 Equipment Internal Coolant 50 bar INCLUDED Coolant deposit capacity 980 l. Oil and emulsion mist separ ...

CHP basic module agenitor 206 / 220kw/el. (fully mounted on steel frame with vibration decoupling) - Motor with accessories - Gas controlled system - Gas mixer -Generator -Voltage regulator - Cos-phi regulator -Clutch - Switchgear and control system - Exhaust silencer made of stainless steel CHP power field - Separate control cabinet with load switch and mains monitoring Heat exchanger cabinet, pre-piped mounted in steel frame - Heat extraction / hydraulic system - 3-way mixer emergency cooling circuit - electric circulating pump, mixture cooler - 3-way mixer mixture cooling circuit - Pressure compensation tank - Plate heat exchanger as transfer heat exchanger - electric circulating pump heating side - 3-way mixer return temperature increase Mixture cooler as table cooler Emergency cooler as table cooler to dissipate excess thermal energy. The entire thermal ...

wheel alignment scissor lift 5t, galvanized, Specifications: Stroke underfloor 1,800mm, stroke above-ground 2,160 mm Overall length 5,200 mm, overall width 2,300 mm, ramp height 360 mm, platform length 5,200 mm, Platform width 729 mm, motor power 3 kW, electrical connection 230/400V, 50 Hz, compressed air connection 6-8 bar, Lifting time 45 sec., lowering time 45 sec. Characteristics: Electro-hydraulic drive,2 maintenance-free hydraulic cylinders, No mechanical connections between the rails,Maintenance-free roller lafers, HD unit integrated in the control panel, operation via push buttons with integrated storage option, Integrated hand pump and emergency lowering in case of power failure, Hydraulic synchronization system with automatic level compensation (master-slave system)Pneumatic set-down device with automatic pressure system. Unlocking, non-contact inductive proximity swit ...

Table length: 630 mm Table width: 500 mm Longitudinal X: 730 mm Cross Y: 850 mm Vertical Z: 560 mm Positions ATC: 80   Positions APC: 2   CNC Brand: Mazatrol Renishaw OMP 60 3D Taster ikz 15 Bar Double chip conveyor EUCHNER toolmanagment prepared Pallet changer 2 position Extended 80 Position ATC Synchronized threat cutting EIA Dynamic 5 Axis compensation Directl availebel X - Travel:               730mm Y - Travel:               850mm Z - Travel:               560mm A - Axis:                 -120 to +30° B - Axis:                 360000° Table Length:             630mm Table Width:             ...

dimensions of saw-blade: 350 x Ø 40 x 3 mm cutting range: 120 mm capacity 90 degrees: square: 100 x 100 mm capacity 90 degrees: flat: 170 x 100 mm capacity 45 degrees: round: 120 mm capacity 45 degrees: square: 95 x 95 mm capacity 45 degrees: flat: 120 x 100 mm capacity 60 degrees: round: RE 100 mm capacity 60 degrees: square: RE 85 x 85 mm capacity 60 degrees: flat: RE 85 x 100 mm work height max.: 900 mm saw blade turning speeds: 17 / 34 U/min compressed air: 6,0 - 8,0 bar total power requirement: 1,4 / 1,9 kW weight: 340 kg range L-W-H: 1010 x 765 x 2175 mm Furnishing : - semi-automatic vertical cold circular saw - Pneumatic quick clamping device - Infinitely adjustable saw blade feed - Convenient miter adjustment - Convenient stroke adjustment of the saw unit via clamping levers - Generously dimensioned gears - with Eisele rotation compensation for a long saw blade service life - Co ...

Number of tool places: 12, controls: Fanuc 32iTB, operating hours: 3611h, with bar feeder IRCO Breuning MUK 7012, standard equipment for TA series: interpolating and bidirectional compensation of mechanical errors by laser measurement, main spindle: oil-cooled main spindle unit, foot pedal for opening and closing the chuck, load indicator for main spindle motor, safety device against chuck opening in case of hydraulic pressure drop.

pressure: 20,0 t chamfer lenght: 850 mm distance between columns: 850 mm back stop - adjustable: 375 + 400 mm stroke of upper beam: 196 mm dayligth: 470 mm ajustment speed: 200 mm/sec table height: ca. 900 mm total power requirement: 5,0 kW weight of the machine ca.: 2500 kg dimensions of the machine ca.: 1800 x 1600 x 2000 mm New price ~ 85.000 euros well-kept / very good condition () with electromechanical direct drive (servo motor + ball screws) Machine is operated without hydraulic oil Description : High performance, fast travel speeds and the best ergonomics this bending machine to a perfect tool in terms of productivity and Accuracy. This allows an unrivaled high productivity in the field of small and middle bending parts can be achieved, since even complicated bending sequences several stations can be processed very quickly. A large number of different and universally divided  ...

CNC vertical machining center HERMLE C 22 U With path control Heidenhain iTNC 530 Year of construction: 2014 Travels : X 450 Y 600 Z 330 Speed range : 20 – 18,000 rpm infinitely variable (HSK 63) With the following accessories: NC swivel rotary table 450 mm x 360 mm clamping surface Vertical tool changer with 55 magazine slots (HSK 63) Linear axes standard version Internal coolant supply (IKZ 80 bar) Scraper belt conveyor left Chip wagon 450 l Coolant device Chip flood gun Oil mist extraction Manual Cabin Door , Automatic Cabin Roof Laminated glass safety pane Rotating transparent window (Rotoclear) Electr. Heat compensation iTNC Electr. Handwheel 3D probe Heidenhain BLUM Wz-bruch/ Vermessung 4 pieces Height adjustable machine shoes Operating instructions

KRÜSI chalet construction machine / log cabin production system type CM 40 Manufacturer: Krüsi Krüsi Maschinenbau AG CH-9105 Schönengrund AR Year of construction: 1996 S/N 431 Condition: good, technically checked and cleaned / ready for use Machine description / equipped with: 1. Sawing unit: Hand feed Spindle adjustment with analogue dimension display 2. CM milling unit: Hydropneumatic feed Spindle adjustment with digital dimension display 3. Drilling unit: Hand feed Spindle adjustment with analogue dimension display 4. End milling unit Hydropneumatic feed Spindle adjustment with digital dimension display Specifications Workpiece Cutting height max. 200nn Cutting width max. 250mm Working table height 900mm Sawing unit Saw blade Ø max. / bore ø 400 / 30 mmm Tungsten carbide equipped with chip depth limiter (synchronization)  ...

Working width: 3000mm, weight: 1.95t, with wheel loader attachment quick change attachment with rollers level compensation, water spray device 400l complete with 12V pressure pump and on/off switch, pressure pump 24V for water spray device, water spray device for side brush, flag holder incl. warning flags and warning marking and LED lighting device according to StVZO, the machine has not been used.

Tecna 3484 Universal spot welding system 8 kVA Universal welding station 8 kVA, hand-operated gun, double program. Simultaneous connection of two tools with automatic recall of the corresponding welding program, which saves time and avoids errors in terms of a simple and safe workflow. Body repairs: resistance spot welding of sheet metal, smoothing with dent spotter (nails and washers), local heating (carbon electrode), screw and rivet welding, denting of stainless steel sheet. Synchronous SCR welding control, adjustment of welding time in cycles and pulses, adjustment of welding current and compensation function. Power supply: 400V Mains frequency: 50 / 60 Hz Fuse: 25 A Rated power at 50 %DC: 8 kVA Max. welding power: 35 kVA Max. secondary current: 6.4 kA Heat flow 100 %: 0.88 kA Year: 2014 Weight: 85 kg More items - new and used - can be found in our shop! Interna ...

CNC Plasma Cutter, Plasma Cutting System, Portable Plasma THC, Large Format portable plasma cutting system / oxyfuel cutting machine large format Working area 3000x1500mm without plasma cutter With height compensation THC Software StarCAM Machine Voltage Signal phas 220V ,50HZ Plasma power Voltage 380V 3 Phase,50HZ Cutting mode Plasma+Flame Effective cutting range(mm) 1500mm×3000mm Cutting speed(mm/min) 50-3500mm/min Rotational Speed 0-5000mm/min Plasma cutting thickness According to models Moving precision ±0.2mm/m Cutting system Fangling F2100B THC Fangling F1620 Software StarCAM Total weight(kg) 150kg Emergency stop Yes Working temperature -5~45°C Relative humidity

CNC vertical machining center HERMLE C 600 U With path control Heidenhain TNC 430 Year of construction: 2001 Travel: X 600 Y 450 Z 450 Speed range: 0 – 16,000 rpm infinitely variable (SK 40) With the following accessories: NC swivel rotary table 0 450 mm ( 370 mm x 370 mm) Vertical tool changer with 30 magazine slots (SK 40) Table switch for tool measurement (BLUM) Electronic handwheel Electronic heat compensation IKZ 40 bar Conveyor Chip flood gun Closed cabin roof section Coolant device Enclosure cooling unit (RITTAL) 3 pcs height-adjustable machine shoes Operating instructions

capacity 90 degrees: round: 305 mm capacity 90 degrees: square: 260 mm : 350x200 saw band length: 3375x27x0,9 mm band speed: 18 - 100 m/min table height: 880 mm total power requirement: 1,5/1,8 kW weight of the machine ca.: 0,84 t dimensions of the machine ca.: 1,85 x 1,9 x 2,0 m Demonstration system for a SPECIAL PRICE Fully automatic miter band saw • miter left 45° automatic operation • miter left 60° semi-automatic operation (cuts without programming) • Material height sensor (automatic cut start recognition) • Frame and gear made from one piece, very quiet cut and very low vibration • Removable chip tray (disinfection) • Shockproof and ergonomic control panel with oil-resistant EPDM cover • Top access to the saw, material and feed unit • Hinged safety cover • Fine feed adjustment • Semi-auto. Cut! • Optimize work processes with CNC control Possibility to ente ...
