Controlled turret punching machine, used controlled turettpunching machine, used Fabr.: EDEL Model: MICROMAT 207 HS Control/ control: LOGO 2000 (with workpiece graphics / with workpiece graphics) Built / year: 1997 Force/punching force: 20 t Maximum sheet thickness/ max. thickness: 0.5 ... 5 mm Travel in X-axis/ travel in X : 1250 mm (expandable to / enlargeable to 2000 mm) Travel in Y-axis / travel in Y axis: 750 mm (expandable to / enlargeable to1000 mm) Punching speed / number of strokes: 20 per min Stroke stroke infinitely adjustable up to / stroke: 40 mm Punching example for steel punching 100 mm 1.5 mm ( punch diam. and thickn.) 50 mm 3.5 mm 16 mm 12.0 mm Machine weig ...
sheet width: 2525 mmplate length: 1250 mmplate thickness: 6,40 mmx-travel: 2525 mmy-travel: 1250 mmPunching capacity: 200 kNcontrol: FANUC 180 i positioning speed: X = 83 m/minpositioning speed: Y = 73 m/minpositioning accuracy: +/- 0,1 mmrepeating accuracy: +/- 0,05 mmtool changing time: 0,9 - 1,6 sec.number of tools: 30 Stk.oil volume: 284 ltotal power requirement: 18,5 kWweight of the machine ca.: 17,0 tdimensions of the machine ca.: 5,8 x 5,3 x 2,5 m- Number of tools Station A (up to 12.7mm) = 8 pieces- Number of tools Station B (up to 31.7mm) = 16 pieces- Number of tools Station C (up to 50.8mm) = 2 pieces- Number of tools station D (up to 88.9mm) = 1 piece- Number of tools Rotatable stations (index) D (up to 88.9mm) = 3 pieces- Number of hydraulic and programmable clamps = 3- Max sheet weight to max. Speed and brush table = 45 kg- Max sheet weight to max. Speed and ball tables = 93 ...
