cnc horizontal table used for sale

cutting diameter: 260 mm saw band length: 2880 x 27 x 0,9 mm cutting width: 300 mm band speed: 35 / 70 m/min : 260 mm : 185 mm : 300 x 185 mm : 240 mm : 185 mm : 185 x 110 mm capacity 60 degrees: round: mm capacity 60 degrees: flat: 105 mm capacity 60 degrees: square: 105 mm work height max.: 900 mm total power requirement: 1/1,4 kW weight of the machine ca.: 285 kg dimensions of the machine ca.: 1840 x 1680 x 1990 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cutting diameter: 330 mm saw band length: 3870 x 34 x 1,1 mm cutting width: 360 mm band speed: 15 - 90 m/min : 360 x 250 mm cutting capacity - round: 330 bei 90° mm : 250 x 150 mm cutting capacity - round: 250 bei 45° mm work height max.: 850 mm cutting capacity - square: 320 bei 90° mm cutting capacity - square: 240 bei 45° mm coolant tank: 40 l Control: total power requirement: 5,67 kW weight of the machine ca.: 1450 kg dimensions of the machine ca.: 1930 x 2070 x 200 mm Fully automated CNC band saw is generally suitable for cutting big series in the heaviest and non-stop operating plants, and also for cutting heavy workpieces of larger cross-sections. Compared to ARG 250 and 300 CF-NC using blade 27 x 0.9 mm, this model is fitted with the saw band 34 x 1.1 mm, which greatly increases the productivity of the machine and the accuracy of the cut, especially when cutting larger cross ...

cutting diameter: 540 mm saw band length: 6000 mm cutting width: 750 mm table height: 695 mm cutting speed: 20 - 100 m/min : 540 mm : 540 x 540 mm Capacity 90° rectangular: 750 x 540 mm : 540 mm : 540 mm : 600 x 540 mm : 510 mm : 450 mm Capacity 45° rectangular: 450 x 540 mm capacity 60 degrees: round: 270 mm capacity 60 degrees: square: 250 mm capacity 60 degrees: flat: 250 x 540 mm total power requirement: 4 kW weight of the machine ca.: 2,45 t dimensions of the machine ca.: 3,0 x 1,3 x 2,13 m Horizontal band saw. The bow is made of heavy steel and the two pillars constitute a strong and rigid saw frame. This ensures high accuracy when cutting. The machines are fitted with an integrated coolant pump that supplies oolant to both guide assemblies. Blade guides with rollers and carbide pads provide precise support for the blade. The machines switch off automatically at the end of the cu ...

pressure: 150 t stroke: 450 mm throat: 350 mm work speed: 2 m/min ajustment speed: 10 mm/sec return speed: 16 mm/sec pressure: 320 bar diameter of piston: 50 mm opening stroke: 700 mm table-size: hinten / back 2000 x 500 mm Table dimensions: Main500 x 500 mm total power requirement: 4 kW weight of the machine ca.: 6,7 t dimensions of the machine ca.: 2,95 x 2,0 x 850 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cutting diameter: 260 mm saw band length: 2880 x 27 x 0,9 mm cutting width: 300 mm band speed: 35/70 m/min : 300 x 200 mm cutting capacity - round: 260 bei 90° mm : 190 x 100 mm cutting capacity - round: 175 bei 45° mm work height max.: 910 mm total power requirement: 1/1,4 kW weight of the machine ca.: 475 kg dimensions of the machine ca.: 1860 x 1680 x 1980 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 220 t stroke: 450 mm throat: 375 mm work speed: 2,2 m/min ajustment speed: 10 mm/sec return speed: 18 mm/sec pressure: 320 bar diameter of piston: 60 mm opening stroke: 800 mm table-size: hinten / back 2500 x 600 mm Table dimensions: Main 600 x 600 mm total power requirement: 5,5 kW weight of the machine ca.: 12,15 t dimensions of the machine ca.: 3,25 x 2,5 x 0,90 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cutting diameter: 230 mm saw band length: 2720 x 27 x 0,9 mm cutting width: 130 mm cutting capacity - flat: 90° / 320 x 130 mm cutting capacity - round: 90° / 230 mm cutting capacity - square: 90° / 230 x 230 mm cutting capacity - flat: 45° / R 220x60 /L 230x140 mm cutting capacity - round: 45° / R 180 / L 220 mm cutting capacity - square: 45° / R 150 / L 190 mm cutting capacity - flat: 60° / 120 x 105 mm cutting capacity - round: 60° /120 mm cutting capacity - square: 60° / 105 mm speed: 35 - 70 m/min total power requirement: 1,0 - 1,5 kW weight of the machine ca.: 410 t dimensions of the machine ca.: 1,35 x 0,9 x 1,3 m The BMSY 230 DG is a popular sawing machine and is heavily sold, due to its favourable price-quality relation. With adjustable sawing pressure, coolant pump with reservoir and electrical-mechanical saw blade tension adjustment, this machine is ideal for large wo ...

cutting diameter: 320 mm saw band length: 3660 x 27 x 0,9 mm cutting width: 350 mm cutting capacity - round: 90° / 320 mm cutting capacity - flat: 90° / 350 x 320 mm cutting capacity - square: 90° /320 mm speed: 20 - 100 m/min : 260 mm capacity 45 degrees: flat: 250 x 180 mm : 180 mm : 160 mm : 150 x 150 mm : 150 mm total power requirement: 1,5 kW weight of the machine ca.: 1,1 t dimensions of the machine ca.: 1900 x 1200 x 1350 m 280G,320G and 320GL are durable and stably laid out for universal separetion from full materials,pipes and profiles.A fast and precise mitre adjustment is characteristic within the range of 90 deg to 30 deg.The sawing property is situated in-line and becomes manuel strained in the angle of 90 deg. The machines are fitted with a removable coolant tank incorporating a submerged electric coolant pump which supplies coolant to both guide assemblies. These models ...

cutting diameter: 300 mm saw band length: 3270 x 27 x 0,9 mm cutting width: 420 mm feed per cut: 800 mm band speed: 35-70 m/min quick change toolholder: 300 capacity 90 degrees: square: 240 x 240 mm Capacity 90° rectangular: 420 x 200 mm : 240 mm : 230 mm Capacity 45° rectangular: 270 x 140 mm capacity 60 degrees: round: 165 mm capacity 60 degrees: square: 170 mm capacity 60 degrees: flat: 170 x 170 mm total power requirement: 0,9-1,5 kW weight of the machine ca.: 1090 kg dimensions of the machine ca.: 2800 2050 x 1900 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

cutting diameter: 440 mm saw band length: 5200 mm cutting width: 695 mm : 440 mm Capacity 90° rectangular: 610 x 440 mm : 4409 x 440 mm capacity 45 degrees: round: 410 mm : 440 x 440 mm Capacity 45° rectangular: 410 x 440 mm : 440 mm : 440 x 440 mm : 500 x 440 mm capacity 60 degrees: round: 320 mm capacity 60 degrees: square: 250 x 250 mm capacity 60 degrees: flat: 250 x 440 mm table height: mm band speed: stufenlos 20-100 m/min total power requirement: 3,62 kW weight of the machine ca.: 1,54 t dimensions of the machine ca.: 2,8 x 1,21 x 1,87 m Horizontal band saw with linear guideways, ideal for mitre cuts between 90° and +30°. Auto height adjustment sensors ensure that the bow can approach the material at high speed. The hydraulic cutting control allows the bow rise up again after a cut has been made. This process is controlled by digital counter on the control panel. The bow angle ...

cutting diameter: 270 mm saw band length: 3160 x 27 x 0,9 mm cutting width: 350 mm cutting capacity - flat: 90° / 350 x 220 mm cutting capacity - round: 90° / 270 mm cutting capacity - square: 90° / 260 x 260 mm cutting capacity - flat: 45°/ R 180x180/ L 240x160 mm cutting capacity - round: 45° / R 210 / L 240 mm cutting capacity - square: 45° / R 180 / L 240 mm cutting capacity - flat: 60° / 150 x 150 mm cutting capacity - round: 60° /160 mm cutting capacity - square: 60° / 150 mm speed: 34 x 68 U/min total power requirement: 1,5 kW weight of the machine ca.: 430 kg dimensions of the machine ca.: 31 m The HU 230 DG is a popular sawing machine and is heavily sold, due to its favourable price-quality relation. With adjustable sawing pressure, coolant pump with reservoir and electrical-mechanical saw blade tension adjustment, this machine is ideal for large workshops and small pro ...

Drilling capacity: 0 mm Drilling depth: 0 mm Spindle taper: 0   Number of heads: 0   CNC Brand: 0 CNC Model: 0 Control: FANUC 0i-MC Technical data Number of drill spindles: 1 Max. drill depth: 1200 mm Drill capacity in steel: from diameter: 3 mm up to diameter: 32 mm Table length: 1200 mm Table width: 1000 mm Max. loading: 5000 kg Travels: X axis: 1000 mm Y axis: 800 mm Z axis: 1200 mm W axis: 400 mm Spindle speeds: stepless from: 60 rpm up to: 6000 rpm Voltage 50 Hz 3x: 380 Volt Spindle motor: 11 kW Power: 34 kW Machine´s weight about: 12000 kg Overall dimensions machine: Length: 7000 mm Width: 4500 mm Height: 3200 mm

Drilling capacity: 0 mm Drilling depth: 0 mm Spindle taper: 0   Number of heads: 0   CNC Brand: 0 CNC Model: 0 Control: IXION Technical data Number of drill spindles: 1 from diameter: 3 mm up to diameter: 25 mm Table length: 1375 mm Table width: 700 mm Max. loading: 2000 kg Travels: X axis: 1000 mm Y axis: 800 mm Z axis: 1000 mm Spindle speeds: stepless from: 100 rpm up to: 4000 rpm Spindle nose SK: 40 Power: 7.5 kW Machine´s weight about: 8000 kg Overall dimensions machine: Length: 6600 mm Width: 4000 mm Height: 2300 mm Various accessories: Coolant system Chip conveyor

Drilling capacity: 0 mm Drilling depth: 0 mm Spindle taper: 0   Number of heads: 0   CNC Brand: 0 CNC Model: 0 Technical data Number of drill spindles: 2 Drill capacity in steel: from diameter: 15 mm Centre height: 200 mm Table length: 700 mm Table width: 380 mm Longitudinal travel (X-axis): 400 mm Spindle speeds: number (steps): 9 from: 1500 rpm up to: 12600 rpm Voltage 50 Hz 3x: 380 Volt Power: 3.2 kW Overall dimensions machine: Length: 3000 mm Width: 1600 mm Height: 1800 mm Various accessories: Loader

Honing diameter maximum: 0 mm Honing diameter minimum: 0 mm Stroke length: 0 mm Number of honing heads: 0   CNC Brand: 0 CNC Model: 0 Technical data Min. diameter: 1.5 mm Max. diameter: 140 mm Max. honing length: 406 mm Spindle speeds: number (steps): 12 from: 200 rpm up to: 2500 rpm Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.37 kW Machine´s weight about: 400 kg Various accessories: Coolant system Automatic workpiece honing unit

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 1520 mm Table width: 300 mm Number of T-channels: 3 T-channel width: 14H7 mm Distance of the T-slots: 80 mm Clamping surface Length Grinding length: 1200 mm Grinding width: 400 mm Execution: hydraulic Max. distance from table to spindle-centreline: 500 mm Longitudinal travel (X-axis): 1280 mm Transversal travel (y axis): 350 mm Automatic cross-feed: stepless from: 0 m/min up to: 7 m/min Table speeds: stepless from: 0.3 m/min up to: 30 m/min Automatic vertical feed: from: 0.0001 mm up to: 0.0010 mm Diameter of grinding wheel: 400 mm Width of the grinding wheel: 80 mm Wheel int. diameter: 127 mm Grinding wheel speeds: from: 1480 rpm Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 7.5 kW Machine´s weight about: 3700 kg Overall dimensions mach ...

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Control: FANUC Series 21i-MB Technical data Table length: 3200 mm Table width: 1500 mm Longitudinal travel (X-axis): 3300 mm cross travel (Z-axis): 1680 mm Max. distance from table to spindle centreline: 1155 mm Table load max.: 6000 kg Passage between the columns: 2000 mm Grinding wheel: Diameter: 500 mm Width: 120 mm Bore: 203.2 mm Noise level: 70 dB (A) Voltage 50 Hz 3x: 400 Volt Grinding spindle motor: 32 kW Total power required: 66 kW Machine´s weight about: 32400 kg Overall dimensions machine: Length: 11030 mm Width: 6075 mm Height: 4450 mm Various accessories: Coolant system Paper filter facility Oil mist extractor Magnetic plate: Length: 3200 mm Width: 1500 mm Lamp Handwheel electroinic Status light

Key data: 700

Grinding length: 700 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 400 mm Technical data Table length: 750 mm Table width: 240 mm Grinding length: 700 mm Grinding width: 300 mm Execution: hydraulic Max. distance from table to spindle-centreline: 600 mm Transversal travel (y axis): 270 mm Automatic cross-feed: stepless from: 0.200 m/min up to: 7.00 m/min Table speeds: stepless from: 3.00 m/min up to: 30.0 m/min Automatic vertical feed: from: 0.0010 mm up to: 0.012 mm Vertical rapid traverse: 0.30 m/min Diameter of grinding wheel: 400 mm Width of the grinding wheel: 500 mm Grinding wheel speeds: number (steps) up to: 2200 rpm Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 5.00 HP Total power required: 20.00 HP Machine´s weight about: 3000 kg Various accessories: Coolant system Magnetic plate: Length: 700 mm Width: 250 mm

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 170 mm Wheel diameter: 350 mm Technical data Table length: 275 mm Table width: 110 mm Grinding height: 170 mm Execution: hydraulic Diameter of grinding wheel: 350 mm Width of the grinding wheel: 12 mm Voltage 50 Hz 3x: 380 Volt Various accessories: Magnetic plate: Length: 240 mm Width: 125 mm Dust extraction

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 200 mm Technical data Table length: 450 mm Table width: 180 mm Max. distance from table to spindle-centreline: 400 mm Longitudinal travel (X-axis): 550 mm cross travel (Z-axis): 200 mm Table speeds: stepless from: 0.10 m/min up to: 30.0 m/min Diameter of grinding wheel: 200 mm Width of the grinding wheel: 25 mm Grinding wheel speeds: from: 2800 rpm Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 3.00 HP Machine´s weight about: 1000 kg Overall dimensions machine: Length: 1800 mm Width: 1600 mm Height: 1800 mm Various accessories: Coolant system

cutting diameter: 320 mm saw band length: 4160 mm cutting width: 610 mm : 320 x 320 mm Capacity 90° rectangular: 450 x 320 mm dimensions of saw-band: 4160 x 34 x 1,1 mm : 320 mm : 320 x 320 mm Capacity 45° rectangular: 280 x 200 mm : 320 mm : 320 mm : 420 x 320 mm speeds steplessly adjustable: 20 - 100 m/min table height: 860 mm total power requirement: 2,69 kW weight of the machine ca.: 1,03 t dimensions of the machine ca.: 2,23 x 1,15 x 2,14 m DG series horizontal bandsawing machines are ideal models for angle cutting of materials with varying number of cuts.It is possible to cut at variable angles between +45° and -60° by giving angle to the upper body of the machine.That machine makes the cutting hydraulically and automatically going up to the height after the cutting.The material is fed manually to the lenght stop and the cut is repeated. Standard Features: Saw Blade 34 Inverter ...

cutting diameter: 330 mm saw band length: 4160 x 34 x 1,1 mm cutting width: 610 mm : 330 mm : 330 mm Capacity 90° rectangular: 610x 310 mm : 320 mm : 320 x 320 mm capacity 45 degrees: flat: 460 x 180 mm speed: 20 - 100 m/min total power requirement: 2,69 kW weight of the machine ca.: 773 t dimensions of the machine ca.: 2,1 x 0,85 x 1,3 m Our semi automatic horizontal bandsaw machine is suitable to cut full materials as pipe, steel cating, steel etc. By turning the vice jaws 0-45 degree cut can be processed. On semi automatic models, after finishing the cut, sawframe is lifted hydraulically up to the adjusted level. After finishing the cut, sawframe is lifted hydraulically up to the adjusted level. Metal sawblade and material roller table are supplied as standart. Standard Features: Blade Brash Coolant Pump Control Panel Hydromechnic Blade Tension Inverter Heavy Duty Gearbox Height Adju ...

Water tanks and extinguishing water tanks USED & REFURBISHED Muensterlandtanks.de Container and tank trade Call us: 0162 1341979 Extinguishing water tank Extinguishing water tank Storage tank Cistern AHL ASL Tank Underground tank Slurry tank Polyester tank GRP tank PE tank Ferric chloride tank Iron III water tank Steel tank Molasses tank By-product tank Oil tank Pressure tank Irrigation Irrigation Riding arena irrigation ebb and flow system Sports field irrigation Diesel tank Fuel oil tank Yard filling station Tank water facility Water tank Service water extinguishing tank Buffer buffer tank Extinguishing water tank Water tank A used GRP tank in the size of 50,000 litres is offered. Volume: 50,000 Ltr. Material: GRP plastic Tank shape: cylindrical, lying in galvanized iron shells Diameter 3.0 m, L approx. 7.0 m Exits: cathedral and exits at the top Ventilation DN 100  ...

Horizontal tank made of stainless steel. The equipment was used as a recovery of mother water from a centrifuge. General characteristics: Material Stainless steel With manually folding lid, clamp and tube at the top and clamp discharges (1 in each bottom). Transport dimensions: Height: 900 mm Diameter: 600 mm Length: 1900 mm

cutting diameter: 440 mm saw band length: 5200 x 41 x 1,3 mm cutting width: 640 mm : 440 x 440 mm Capacity 90° rectangular: 640 x 440 mm capacity 45 degrees: round: 440 mm : 400 x 400 mm Capacity 45° rectangular: 400 x 440 mm : 440 mm : 440 x 440 mm : 510 x 440 mm capacity 60 degrees: round: 250 mm capacity 60 degrees: square: 250 x 250 mm capacity 60 degrees: flat: 250 x 440 mm table height: 850 mm cutting speed: 20 - 100 m/min dimensions of saw-blade: 3,1 x 1,2 x 1,91 m total power requirement: 4,67 kW weight of the machine ca.: 1,78 t dimensions of the machine ca.: 2,85 x 1,3 x 1,8 m Product Description Capacity of the machine is 440/640 and projected for fast cuttings straight or with angle . Sensetivity of the machine lets cutting with percentage angles. BMSY 440CDGH has automatic control system and open to future developments. Rollers on the table are designed for easy movement o ...

:::TECHNICAL SPECIFICATIONS::: CNC Model: Fanuc CNC Version: 0i-TC Main spindle nose: ASA 6 Main spindle self-centering diameter: 250mm Main spindle bar passage: 65mm Turning diameter: 280mm Turning length: 550mm Number of turns main spindle: 4000 Number of Tool Towers: 1 Number of tool places first turret: 12 Number of motorized first turret: 12 First turret tool attachment type: VDI 30 X axis travel first turret: 245mm Z axis stroke first turret: 600mm Rapid advances linear axes X Y Z: 36m/min Tailstock: yes Barrel stroke: 190mm Chip evacuator: carpet Number of motorized tool holders supplied: 2 Number of fixed tool holders supplied: 10 :::D IMENSIONS AND WEIGHT::: Length: 3415mm Width: 1786mm Height: 1780mm Weight: 3900Kg

Key data: 1180 °C

AMP VBF-60/60/100-1.5 horizontal vacuum furnace was manufactured in Poland in 2012. The machine, which has a horizontal construction with a large cylindrical heating chamber, is designed for, among others, annealing, degassing, brazing and hardening of long workpieces with a maximum weight of 600 kg, without the risk of deformation. The AMP vacuum furnace ensures that a constant temperature of 1180°C is maintained throughout the treatment, due to the insulation inside the heating chamber in the form of a graphite mat fixed to the chamber casing by molybdenum rods with graphite composite pads. The capacious heating chamber also contains heating elements, charge holding supports and cooling nozzles through which cooling gas flows during the cooling cycle. All parameters, such as vacuum, temperature course and cooling gas pressure, are programmed in a special controller, installed in a  ...

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 800 mm Table width: 600 mm Axial motion: Longitudinal travel (X-axis): 900 mm cross travel (Z-axis): 560 mm vertical travel (Y-axis): 550 mm Grinding length: 800 mm Grinding width: 600 mm Grinding wheel: Diameter: 400 mm Bore: 127 mm max. width: 80 mm Grinding wheel speeds: from: 1000 rpm Table speeds: stepless from: 0.3 m/min up to: 30 m/min Automatic cross feed: stepless from: 0.04 mm/min up to: 4 mm/min Automatic vertical feed: from: 40 mm/min up to: 3750 mm/min Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 11.4 / 15 kW Machine´s weight about: 6000 kg Overall dimensions machine: Length: 3000 mm Width: 2500 mm Height: 2500 mm

Pallet length: 0 mm Pallet width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Number of pallets: 0   Positions ATC: 0   CNC Brand: 0 CNC Model: 0 Control: HEIDENHAIN iTNC 530 Technical data Number of axis simultaneous: 3 Number of tables: 1 Number of spindles: 1 Table length: 800 mm Table width: 600 mm Distance of the T-slots: 63 mm T-channel width: 14H7 mm Table load max.: 500 kg Longitudinal travel (X-axis): 600 mm Transversal travel (y axis): 600 mm Vertical travel (z axis): 500 mm Tool changer: Number of tools: 60 Tool diameter max.: 80 mm Diameter with free adjacent pockets: 130 mm Tool lenght: 300 mm Max. tool-weight: 6.5 kg Spindle nose: HSK-A: 63 Spindle speeds: stepless from: 0 rpm up to: 20000 rpm Rapid traverse: long.: 40 m/min Rapid traverse: transversal: 40 m/min Rapid traverse: vertical: 30 m/min Air connect: 6 bar Voltage 50 Hz 3x: 400 Volt Machine´s ...

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Control: FANUC Technical data Table length: 800 mm Table width: 300 mm Number of T-channels: 1 T-channel width: 14 mm Axial motion: Longitudinal travel (X-axis): 710 mm cross travel (Z-axis): 300 mm vertical travel (Y-axis): 400 mm Max. distance from table to spindle centreline: 360 mm Table load max.: 250 kg Grinding wheel: Diameter: 355 mm Width: 31 mm Bore: 127 mm Grinding wheel speeds fix: 1710 rpm Table speeds: stepless from: 3 m/min up to: 25 m/min Automatic cross feed: stepless from: 25 mm/min up to: 500 mm/min Grinding spindle motor: 3.7 kW Machine´s weight about: 2600 kg Overall dimensions machine: Length: 2300 mm Width: 2000 mm Height: 2600 mm Various accessories: Touch screen Coolant system Paper filter facility Electrical magnetic chuck Length: 600 mm Width: 300  ...

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 760 mm Table width: 300 mm Number of T-channels: 3 T-channel width: 17 mm Distance of the T-slots: 100 mm Table load max.: 420 kg Longitudinal travel (X-axis): 750 mm Transversal travel (y axis): 400 mm Cutting speed: 35 m/s Diameter of grinding wheel: 355 mm Width of the grinding wheel: 50 mm Wheel int. diameter: 127 mm Grinding wheel speeds fix: 1500 rpm Voltage 50 Hz 3x: 380 Volt Total power required: 7.5 kVA Machine´s weight about: 2500 kg Overall dimensions machine: Length: 2800 mm Width: 1900 mm Height: 1760 mm Various accessories: Paper filter facility Electrical magnetic chuck Length: 600 mm Width: 300 mm Digital readout number of axis:: 2 Lamp

Capacity: 0 t Stroke: 0 mm Length of sleeve maximum: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Pressure: 5 to Execution supports Table length: 150 mm Table width: 120 mm Fixed stroke: 30 mm Distance from table to slide: min.: 25 mm max: 145 mm Machine´s weight about: 51 kg Overall dimensions machine: Length: 350 mm Width: 250 mm Height: 550 mm

Pallet length: 0 mm Pallet width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Number of pallets: 0   Positions ATC: 0   CNC Brand: 0 CNC Model: 0 Control: SIEMENS SINUMERIK 810 M Operating hours: 15198 Technical data Number of axis total: 3 Table length: 2280 mm Table width: 450 mm Number of T-channels: 3 Distance of the T-slots: 150 mm T-channel width: 18 mm Longitudinal travel (X-axis): 2000 mm Transversal travel (y-axis): 400 mm Vertical travel (z axis): 425 mm Tool changer: Number of tools: 20 Tool diameter: 65 mm Diameter with free adjacent pockets: 180 mm Tool lenght: 220 mm Max. tool-weight: 8 kg Spindle nose SK: 40 DIN 69871 Vertical spindle speeds: stepless from: 20 rpm up to: 10500 rpm Feeds: Air connect: 6 bar Voltage 50 Hz 3x: 400 Volt Spindle motor: 18 kW Total power required: 31 kVA Machine´s weight about: 7200 kg Overall dimensions machine: Length: ...

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Voltage 50 Hz 3x: 400 Volt Total power required: 40 kW Machine´s weight about: 22000 kg

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 450 mm Table width: 180 mm Execution: hydraulic Max. distance from table to spindle-centreline: 400 mm Longitudinal travel (X-axis): 550 mm Transversal travel (y axis): 200 mm Table speeds: stepless from: 0.10 m/min up to: 30.0 m/min Automatic vertical feed: Diameter of grinding wheel: 200 mm Width of the grinding wheel: 25 mm Grinding wheel speeds: from: 2800 rpm Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 3.00 HP Machine´s weight about: 1000 kg Overall dimensions machine: Length: 1800 mm Width: 1600 mm Height: 1800 mm Various accessories: Coolant system Electrical magnetic chuck Length: 450 mm Width: 200 mm Wheel truieng attachment hydraulic Dust extraction Digital readout number of axis:: ELESTA (1 x trans.) Set of flanges

Honing diameter maximum: 0 mm Honing diameter minimum: 0 mm Stroke length: 0 mm Number of honing heads: 0   CNC Brand: 0 CNC Model: 0 Technical data Min. diameter: 1.5 mm Max. diameter: 102 mm Spindle speeds: stepless from: 200 rpm up to: 3000 rpm Total stroke: 6 - 170 mm Stroke speed: from: 60 s/min up to: 500 s/min Voltage 50 Hz 3x: 400 Volt Spindle motor: 4.1 kW Compressed air from: 5.5 bar Machine´s weight about: 725 kg Overall dimensions machine: Length: 1600 mm Width: 1200 mm Height: 1900 mm

Honing diameter maximum: 0 mm Honing diameter minimum: 0 mm Stroke length: 0 mm Number of honing heads: 0   CNC Brand: 0 CNC Model: 0 Technical data Min. diameter: 1.5 mm Max. diameter: 102 mm Spindle speeds: stepless from: 200 rpm up to: 3000 rpm Total stroke: 6 - 170 mm Stroke speed: from: 60 s/min up to: 500 s/min Voltage 50 Hz 3x: 400 Volt Spindle motor: 4.1 kW Compressed air from: 5.5 bar Machine´s weight about: 725 kg Overall dimensions machine: Length: 1600 mm Width: 1200 mm Height: 1900 mm

Honing diameter maximum: 0 mm Honing diameter minimum: 0 mm Stroke length: 0 mm Number of honing heads: 0   CNC Brand: 0 CNC Model: 0 Technical data Min. diameter: 1.5 mm Max. diameter: 102 mm Spindle speeds: stepless from: 200 rpm up to: 3000 rpm Total stroke: 6 - 170 mm Stroke speed: from: 60 s/min up to: 500 s/min Voltage 50 Hz 3x: 400 Volt Spindle motor: 4.1 kW Compressed air from: 5.5 bar Machine´s weight about: 725 kg Overall dimensions machine: Length: 1600 mm Width: 1200 mm Height: 1900 mm

Honing diameter maximum: 0 mm Honing diameter minimum: 0 mm Stroke length: 0 mm Number of honing heads: 0   CNC Brand: 0 CNC Model: 0 Technical data Min. diameter: 1.5 mm Max. diameter: 102 mm Spindle speeds: stepless from: 200 rpm up to: 3000 rpm Total stroke: 6 - 170 mm Stroke speed: from: 60 s/min up to: 500 s/min Voltage 50 Hz 3x: 400 Volt Spindle motor: 4.1 kW Compressed air from: 5.5 bar Machine´s weight about: 725 kg Overall dimensions machine: Length: 1600 mm Width: 1200 mm Height: 1900 mm

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 900 mm Table width: 250 mm Grinding length: 650 mm Grinding width: 375 mm Grinding height: 300 mm Table load max.: 280 kg Execution: hydraulic Longitudinal travel (X-axis): 700 mm Transversal travel (y axis): 350 mm Automatic cross-feed: stepless from: 3 mm/stroke up to: 50 mm/stroke Table speeds: stepless from: 2 m/min up to: 30 m/min Diameter of grinding wheel: 300 mm Width of the grinding wheel: 50 mm Wheel int. diameter: 76.2 mm Grinding wheel speeds: number (steps): 2 from: 1500 rpm up to: 3000 rpm Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 3.7/4.5 kW Machine´s weight about: 4000 kg Overall dimensions machine: Length: 2800 mm Width: 2300 mm Height: 2400 mm Various accessories: Coolant system Magnetic separator Electrical magnetic ...

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Grinding length: 1100 mm Grinding width: 600 mm Grinding height: 600 mm Table load max.: 950 kg Execution: hydraulic with automatic cycle: NC-K Max. distance from table to spindle-centreline: 400 mm Longitudinal travel (X-axis): 1300 mm Automatic cross-feed: up to: 1.2 m/min Automatic vertical feed: up to: 180 mm/min Diameter of grinding wheel: 400 mm Width of the grinding wheel: 100 mm Wheel int. diameter: 127 mm Grinding wheel speeds: from: 1500 rpm up to: 3000 rpm from: 2 m/min up to: 32 m/min Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 11 kW Total power required: 20 kVA Machine´s weight about: 7400 kg Overall dimensions machine: Length: 3600 mm Width: 2300 mm Height: 2750 mm Various accessories: Coolant system Electrical magnetic chuck Length: 1 ...

Honing diameter maximum: 0 mm Honing diameter minimum: 0 mm Stroke length: 0 mm Number of honing heads: 0   CNC Brand: 0 CNC Model: 0 Technical data Min. diameter: 1.5 mm Max. diameter: 165 mm Max. honing length: 406 mm Spindle speeds: number (steps): 12 from: 200 rpm up to: 2500 rpm Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.73 kW Machine´s weight about: 600 kg Overall dimensions machine: Length: 1400 mm Width: 1200 mm Height: 1600 mm Various accessories: Coolant system Automatic workpiece honing unit

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 650 mm Table width: 300 mm Grinding length: 600 mm Min. grinding length: 300 mm Table load max.: 420 kg Longitudinal travel (X-axis): 750 mm Cross travel (z-axis): 340 mm Transversal travel (y axis): 360 mm Table speeds: stepless from: 0.3 m/min up to: 25 m/min Grinding wheel speeds fix: 1500 rpm Diameter of grinding wheel: 355 mm Width of the grinding wheel: 38 mm Drilling cap. of grind.wheel: 127 mm Voltage 50 Hz 3x: 400 Volt Grinding spindle motor: 3.7 kW Total power required: 10.8 kVA Machine´s weight about: 2500 kg Overall dimensions machine: Length: 2740 mm Width: 2100 mm Height: 1800 mm Various accessories: Coolant system Paper filter facility Electrical magnetic chuck Length: 600 mm Width: 300 mm Vice: width: 125 mm Lamp Set of grindi ...

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Control: SEIMENS 810 Technical data Table length: 5150 mm Table width: 800 mm Max. permitted table load: 1500 kg/m Grinding length: 5000 mm Grinding height over table: 700 mm Passage between the columns: 1000 mm Grinding wheel: Diameter: 457 mm Width: 75 mm Bore: 203 mm Grinding wheel speeds fix: 1200 rpm Table speeds: stepless from: 1 m/min up to: 40 m/min Automatic cross feed: stepless from: 5 mm/min up to: 1500 mm/min Feed motor: 11 kW Machine´s weight about: 26500 kg Overall dimensions machine: Length: 12700 mm Width: 3960 mm Height: 3600 mm Various accessories: Oil mist extractor Magnetic plate: Length: 5000 mm Width: 800 mm Lamp

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Control: DGT Plus Technical data Table length: 1200 mm Table width: 400 mm Axial motion: Longitudinal travel (X-axis): 1340 mm Cross travel (z-axis): 530 mm vertical travel (Y-axis): 645 mm Grinding length: 1000 mm Grinding width: 660 mm Grinding height over table: 550 mm Grinding wheel: Diameter: 400 mm Width: 100 mm Bore: 127 mm Grinding wheel speeds: from: 1400 rpm Table speeds: stepless from: 1 m/min up to: 4 m/min Voltage 50 Hz 3x: 400 Volt Grinding spindle motor: 25 kW Total power required: 20 kVA Machine´s weight about: 6700 kg Overall dimensions machine: Length: 4500 mm Width: 2500 mm Height: 3500 mm Various accessories: Coolant system Paper filter facility Dust extraction Oil mist extractor: LOSMA Magnetic plate: Length: 1000 mm Width: 500 mm Wheel trueing attac ...

Drilling capacity: 0 mm Drilling depth: 0 mm Spindle taper: 0   Number of heads: 0   CNC Brand: 0 CNC Model: 0 Technical data Number of drill spindles: 1 Max. drill depth: 1250 mm Drill capacity in steel: from diameter: 15 mm up to diameter: 63 mm Voltage 50 Hz 3x: 380 Volt Overall dimensions machine: Length: 3500 mm Width: 2000 mm Height: 1900 mm Various accessories: Coolant system Set of drills Set of drill heads Tool cabinet Magnetic chip conveyor Status light

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Grinding length: 1015 mm Grinding width: 405 mm Grinding height: 350 mm Table speeds: stepless from: 5 m/min up to: 25 m/min Diameter of grinding wheel: 355 mm Width of the grinding wheel: 50 mm Wheel int. diameter: 127 mm Total power required: 3.7 kW Machine´s weight about: 3600 kg Overall dimensions machine: Length: 3500 mm Width: 1700 mm Height: 2000 mm Various accessories: Coolant system Electrical magnetic chuck Length: 1000 mm Width: 400 mm Wheel trueing attachment Lamp Switch cabinet Air conditioner

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 650 mm Table width: 160 mm Execution: hydraulic Max. distance from table to spindle-centreline: 330 mm Longitudinal travel (X-axis): 483 mm Transversal travel (y axis): 171 mm Table speeds: stepless from: 1.50 m/min up to: 18.0 m/min Automatic vertical feed: from: 0.0010 mm Diameter of grinding wheel: 178 mm Width of the grinding wheel: 13 mm Grinding wheel speeds: from: 2880 rpm Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 2.00 HP Machine´s weight about: 850 kg Overall dimensions machine: Length: 1600 mm Width: 800 mm Height: 1700 mm Various accessories: Coolant system Magnetic plate: Length: 350 mm Width: 160 mm

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 610 mm Table width: 200 mm Grinding length: 500 mm Grinding width: 200 mm Grinding height: 300 mm Execution: hydraulic Max. distance from table to spindle-centreline: 412 mm Longitudinal travel (X-axis): 530 mm Transversal travel (y axis): 220 mm Automatic cross-feed: stepless up to: 9 m/min Table speeds: stepless up to: 21 m/min Creep feed:: Blockierung Quer (Y) Diameter of grinding wheel: 225 mm Width of the grinding wheel: 25 mm Grinding wheel speeds: from: 2700 rpm Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 2.5 HP Machine´s weight about: 800 kg Overall dimensions machine: Length: 1000 mm Width: 700 mm Height: 1500 mm Various accessories: Coolant system Electrical magnetic chuck: feinpolig Length: 500 mm Width: 200 mm

Honing diameter maximum: 0 mm Honing diameter minimum: 0 mm Stroke length: 0 mm Number of honing heads: 0   CNC Brand: 0 CNC Model: 0 Technical data Min. diameter: 1.52 mm Max. diameter: 80 mm Spindle speeds: stepless from: 250 rpm up to: 1000 rpm Voltage 50 Hz 3x: 380 Volt Spindle motor: 0.40 kW Machine´s weight about: 300 kg Overall dimensions machine: Length: 1100 mm Width: 920 mm Height: 1400 mm Various accessories: Coolant system
