cnc gantry type used for sale

Description: plasma cutting system possible welding processes: plasma cutting with standard gases plasma cutting with oxygen (fine cutting technique) -autogen-burning cutting cutting speed: per sheet metal base up to 8m/min cutting length (x-axis):4300mm cutting width (y-axis):2100mm cutting thickness for plasma cutting: -for stainless steel=max.130mm;for normal steel (liquid steel)=max.40mm -for light metals/ Alloys=max.150mm burner adjustment distance: 250mm Plasma power source: 1. Nertajet 320-640 (2x parallel) Insulation class H; Protection class IP 23; 30Hz 2. Nertajet 120H-Autonom Road dimensions: 6400x400x550mm cutting table Ground: 4500x2600x670mm Equipment: Smoke extraction via suction table Smoke disposal by filter system Cooling of Et Scheid IK-V 18 Plasma cutting torch Autogen cutting torch roadway (rail) length 6400mm cutting table length 4500mm To ...

Plasma cutting system with possible welding processes: plasma cutting, firing joints; TIG (TIG) on all metals and alloys; MIG on light metals and alloys and heavy metals and arc welding Source: Nertajet HP 120 (220V,24V,380V,415V,440V,500V) Multiple frequencies 50/60Hz burner: CPM 250 (flat electrode) cutting process under water Plasma cutting cutting speed approx. 8m/min. Marking via compressed air driven drills Equipment: rails; Control cabinet; Cutting portal; Tub; Burning pads; 1x Torch Machine dimensions: cutting system: L:4,40xB:2,30xH:1,80m Cutting tables: L:8,44xB:3,31xH:0,85m 2 pcs. Plasma generator connected in parallel Nertajet HP 120: L:0,83xB:0,65xH:1.3 3m Track 1: L:10,650xB:0,25xH:0,92m Left Side Track 2: L:10,650xB:0.25xH:0.57m Right Side Factory conditions:L:3,120xB:1,36xH:0,14m (5 pcs. for cutting table) Water tank: D=1100mm H=2000mm / 1 pc. storage pl ...

Aufspannflaeche 3,000 x 2,000 mms table height 1,150 mms

CNC-controlled flatbed cutting machine Satronik DS 2500 double-sided. synchronized rack-and-pinion pinion drive in laeng axle game-free timing belt drive in transverse axis, drive system with 3 drive motors working width: 2500 mm Total width: 4000 mm feed: 0 -12000 mm/min 1 x Autogen 1 x Plasma (option) CNC 801 CNC web control CNC 801 - driving control unit/user interface SATO PLC - 80486 Simple and over-the-top menu for programming control panel with large-scale touch switches for all machine functions CPU 80486 DX4 32 Bite CPU/75MHz 10.4 LCD screen Essi format (ISO 6582) Floppy drive 3.5, 1.44 MB (default) 2 pcs. Interfaces V 24 (RS 232C) Flash memory for operating system and 512K for user programs 4 MB memory function list (excerpt) 54 Standard shapes Graphically underscored part programming Programmable cutting joint display of the plate sizesize plate r ...

MicroStep CNC guide machine AQUACUT 3001.15 W working area (3000mm x 1500 mm) high pressure pump: KMT Streamline Pro I 60 S, 6200 bar cutting up to 300mm only 4 000 operating hours Including osmosis water treatment system (12,000,- Euro) The AQUACUT is a robust and very practical CNC guide machine in portal construction, specially developed for continuous use in water jet cutting. The high dynamics of the system are overpowered by a low-set machine portal, digital DC servo motors with play-free transmission and practical, stainless linear guides in all three axes. In combination with an HD pump, the AQUACUT can be used to cut solid metals, hard rock, marble, armoured glass, ceramics, plastics, corrugated board, foams, as well as composite materials. assembly and commissioning on request. ; ready for immediate use

Aggregate for 4-Achs CNC to the extension for the 5-th axis

Pierce Control Automation RUR 2500 P working range: 2.1 m x 6.1 m control: Burny 10 LCD Completely welded portal construction without screwed connections o linear guide in the transverse axis o AC servomotors (12 000 mm/min.) o Digital synchronization on the laeng axis o CNC control system BURNY 10 LCD Plus with touch screen o membrane keyboard o flyingmounted cutting buttons o Automatic initial adjustment of the plasma torch o voltage monitoring of the plasma torch height o 1 torch parking lot outside the cutting area o circuit breaker at the end of all axes 1 x Plasma Kjellberg 160i with manual gas console cutting up to 25mm qualifying cut Optional autogencan Completely factory-assembled machine assembly and commissioning ready for use

Tischaufspannflaeche Max Tischbelastung 25 to . groove distance 180 mms table movement 1,000 mms table rotation B axis 360? Aufspannflaeche 1600 x 2,500 mms number of the grooves 9 table overtakes completely in 2012 anew SIEMENS impulses, new MOOR GROVE graduations

Bed feeding machine - Universal AUERBACH FBE 2000 Bearing No. 1105-01972 Category Bed frit machine - Universal Make Auerbach Type 2000 FBE Built in 1996 Condition Used machine Control CNC Heidenhain TNC 415 Storage location FRANCE Country of origin Germany Delivery time by appointment Freight base from stock Technical details x-way 2000 mm y-way 900 mm z-way 900 mm Table size 2100 x 800 mm Tool holder SK 50 Spindle speed: 30 - 3500 rpm Control Heidenhain TNC 415 Spindle drive 29/22 kW Feed speed 1 - 6000 mm/min Rapid speed 15 m/min Total power requirement 42 kVA Machine weight approx. 12.5 t Room requirement approx. 7.7 x 5.5 x 3.0 m Description 3-axis bed-feeding machine With MANUELER two-axle universal head , - vertical level 360 x 1 degree - 45" level 360 x 1 degree

The CNC-controlled autogen/plasma cutting machine RUR 2500GP is a completely welded portal construction without screwed connections with linear guides in the transverse axis and digital synchronization in the laeng axis. The HPR260XD plasma system is suitable for use in sheet thicknesses up to 64 mm. The system delivers a high-quality cutting quality, high productivity and reliance with low operating costs. Equipment: ? CNC control system Pierce-19 with 19 touchscreen ? Energy chains with cables and loops ? A motorized plasma torch with automatic initial setting and burner ? Pneumatic anti-collision system ? Plasma cutting unit HPR260XD for cutting structural steel up to a material thickness of 64 mm, hole piercing up to 38 mm, beard-free cut up to 32 mm, manual gas console ? Two three-burner autogenschraegschneidkoepfe with electrical finishing and burner attachment control for  ...

The CNC-controlled autogen/plasma cutting machine RUR 2500GP is a completely welded portal construction sizing without screwed connections with linear guides in the transverse axis and digital synchronization in the laeng axis. The HiFocus 280i plasma system is suitable for use in the sheet thickness range of 0.5 - 50 (70) mm. As a soft switch inverter, HiFocus 280i offers a fully electronic power source for the power range up to 280 A. The system provides the best cutting results in the field of laser-like cuts and offers a higher service life of the wear parts. Equipment: ? CNC control system Pierce-19 touchscreen ? Energy chains with cables and loops ? A motorized plasma torch with automatic initial setting and burner ? Pneumatic anti-collision system ? Plasma cutting unit HiFocus 280i for cutting structural steel with recommended material thickness of 0.5 - 50 mm, punching up  ...

The CNC-controlled plasma cutting machine RUR 2500P is a completely welded portal construction without screwed connections with linear guides in the transverse axis and digital synchronization in the laeng axis. The HiFocus 161 i plasma system from Kjellberg with Contour Cut is suitable for use in the sheet thickness range of 0.5 - 40 (50) mm. As a soft switch inverter, HiFocus 161 i offers a fully electronic power source for the power range up to 160 A. The system is the multi-talent of plasma cutting technology for marking and cutting construction blades, alloyed steels, aluminium and all electrically conductive materials. (see Pdf ) Equipment: ? CNC control system Pierce 19 with touchscreen ? A motorized torch with automatic initial setting and burner ? Plasma cutting unit HiFocus 161 i for cutting structural steel with recommended material thickness of 0.5 - 38 mm, hole bars up  ...

- Arbeitsbereich X - Achse 1300 mm - Arbeitsbereich Y - Achse 2500 mm - Arbeitsbereich Z - Achse 300 mm - Frässpindel luftgekühlt HITECO / Italy 9.5 kw, HSK 63F - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler 8-fach, seitlich - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren Delta / YASKAWA - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 40 m/min - max. Arbeitsgeschwindigkeit 20 m/min - Arbeitsgenauigkeit 0.05 mm - Vakuum - Rastertisch mit 4 Sektionen und T-Nuten - BECKER Vakuumpumpe trockenlaufend, luftgekühlt, Leistung 129 m3/h - Werkstückpositionierung, pneumatisch absenkbare Anschläge je 2 Stück in X und Y - Werkzeuglängen Sensor - CAD/CAM Software VECTRIC CUT 2D PRO (NESTING Inclusive) - Steuerung OSAI/ Italy - Schnittstelle Ethernet/USB/CompactFlash Card - Elektroanschluss 3 ...

- Arbeitsbereich X - Achse 2100 mm - Arbeitsbereich Y - Achse 3000 mm - Arbeitsbereich Z - Achse 300 mm - Frässpindel luftgekühlt HITECO/ Italy 9.5 kw, HSK 63 F - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler,Karusell 8-fach, mitfahrend - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren Delta / YASKAWA - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 40 m/min - max. Arbeitsgeschwindigkeit 20 m/min - Arbeitsgenauigkeit 0.05 mm - Vakuum - Rastertisch mit 4 Sektionen - BECKER Vakuumpumpe trockenlaufend, luftgekühlt, Leistung 2 x 129 m3/h = 258 m3/h - Werkstückpositionierung, pneumatisch absenkbare Anschläge je 2 Stück in X und Y - Werkzeuglängen Sensor - CAD/CAM Software VECTRIC CUT 2D PRO (NESTING Inclusive) - Steuerung OSAI / Italy - Schnittstelle Ethernet/USB/CompactFlash Card - Ele ...

Technische Daten: - Verfahrbereich X - Achse 3700 mm - Verfahrbereich Y - Achse 1600 mm - Verfahrbereich Z - Achse 200 mm - Arbeitsbereich X - Achse 3685 mm - Arbeitsbereich Y - Achse 1550 mm - Arbeitsbereich Z - Achse 70 mm - Lade- Entladegeschindigkeit 15 m/min - Frässpindel luftgekühlt HSD / Italy 9.6 kw, HSK 63 (Option 11 kW HSK 63F) - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler,Karusell 8-fach, mitfahrend - Bohraggragat VERTIKAL 5 + 4 FAM / Italian 5 Spindeln in Y-Richtung, Bohrabstand 32 mm 5 Spindeln in X-Richtung, Bohrabstand 32 mm - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren YASKAWA - hochgenaue THK Linearführungen mit Langzeitschmiereinheit in X, Y, Z Achse - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 80 m/min - max. Arbeitsgeschwindigkeit 25 m/min - Arbeitsgenaui ...

- Arbeitsbereich X - Achse 1500 mm - Arbeitsbereich Y - Achse 3000 mm - Arbeitsbereich Z - Achse 300 mm - Frässpindel luftgekühlt HITECO / Italy 9.5 kw, HSK 63F - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler 8-fach, seitlich - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren Delta / YASKAWA - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 40 m/min - max. Arbeitsgeschwindigkeit 20 m/min - Arbeitsgenauigkeit 0.05 mm - Vakuum - Rastertisch mit 4 Sektionen und T-Nuten - BECKER Vakuumpumpe trockenlaufend, luftgekühlt, Leistung 129 m3/h - Werkstückpositionierung, pneumatisch absenkbare Anschläge je 2 Stück in X und Y - Werkzeuglängen Sensor - CAD/CAM Software VECTRIC 2D PRO (NESTING Inclusive) - Sicherheitslichtschranke Vorschrift nach EN 848-3 (Optional einseitig, zweiseitig oder dreise ...

- Arbeitsbereich X - Achse 1300 mm - Arbeitsbereich Y - Achse 2500 mm - Arbeitsbereich Z - Achse 400 mm -B- Achse Frässpindel ist +/- 90C parallel zu X-Achse schwenkbar - Frässpindel luftgekühlt 5,5 kw - Spindel Drehzahl stufenlos 18.000 rpm - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren Delta / YASKAWA - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 40 m/min - max. Arbeitsgeschwindigkeit 20 m/min - Arbeitsgenauigkeit 0.05 mm - Vakuum - Rastertisch mit 4 Sektionen und T-Nuten - BECKER Vakuumpumpe trockenlaufend, luftgekühlt, Leistung 129 m3/h - Werkzeuglängen Sensor - CAD/CAM Software DDX EasyWOOD Standard - Steuerung OSAI - Schnittstelle Ethernet/USB/CompactFlash Card - Sicherheitslichtschranke Vorschrift nach EN 848-3 (Optional einseitig, zweiseitig oder dreiseitig je nach Aufstellungsgeg ...

Technische Daten: - Verfahrbereich X - Achse 2900 mm - Verfahrbereich Y - Achse 2160 mm - Verfahrbereich Z - Achse 200 mm - Arbeitsbereich X - Achse 2850 mm - Arbeitsbereich Y - Achse 2130 mm - Arbeitsbereich Z - Achse 70 mm - Lade- Entladegeschindigkeit 15 m/min - Frässpindel luftgekühlt HSD / Italy 9.6 Kw HSK 63 (Option 11 kW HSK 63F) - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler,Karusell 8-fach, mitfahrend - Bohraggragat VERTIKAL 5 + 4 FAM / Italian 5 Spindeln in Y-Richtung, Bohrabstand 32 mm 5 Spindeln in X-Richtung, Bohrabstand 32 mm - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren YASKAWA - hochgenaue THK Linearführungen mit Langzeitschmiereinheit in X, Y, Z Achse - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 80 m/min - max. Arbeitsgeschwindigkeit 25 m/min - Arbeitsgenauig ...

- Arbeitsbereich X - Achse 1300 mm - Arbeitsbereich Y - Achse 1300 mm - Arbeitsbereich Z - Achse 200 mm - Arbeitsgenauigkeit -+0,04/300 mm - Vakuum - Rastertisch mit 4 Sektionen und T-Nuten inklusive Vakuumpumpe - Max. Verfahrgeschwindigkeit 10000 mm/min - Max. Arbeitsgeschwindigkeit 6000 mm/min - Frässpindel Motor 2,2 kW / ISO 20, Wassergekühlt - Werkzeugwechsler 6-fach, seitlich - Spannzangen Werkzeugaufnahme Durchmesser 3, 6, 8,10,12 mm - Drehzahl Frässpindel 6000-18000 U/min. - Antriebsmotoren Schrittmotoren - Spannung 400 V/50Hz - Führung in X,Y Richtung Linearführung + Zahnstange - Führung in X, Z-Richtung Linearführung + Kugelrollspindel - Befehlssprache G-code - DSP Steuerung NK 105 (Option: Mach3 Steuerung, PC und Monitor) - CAD/CAM Software Vectric CUT2D PRO (NESTING Inclusive) - Werkstückpositionierung, pneumatisch absenkbare Anschläge 1 x Stück in X ,2 Stück in Y  ...

- Arbeitsbereich X - Achse 1300 mm - Arbeitsbereich Y - Achse 2500 mm - Arbeitsbereich Z - Achse 300 mm - Frässpindel luftgekühlt 5,5 kw, ER 32 - Spindel Drehzahl stufenlos 18.000 rpm - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren Step Motoren - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 22 m/min - max. Arbeitsgeschwindigkeit 15 m/min - Arbeitsgenauigkeit 0.05 mm - Vakuum - Rastertisch mit 4 Sektionen und T-Nuten - BECKER Vakuumpumpe trockenlaufend, luftgekühlt, Leistung 129 m3/h - Werkstückpositionierung, pneumatisch absenkbare Anschläge je 2 Stück in X und Y - Werkzeuglängen Sensor - Steuerung DSP (OPTION MACH3) - Schnittstelle USB - CAD/CAM Software VECTRIC CUT2D PRO (NESTING Inclusive) - Elektroanschluss 3 Phasen 400 V, 50 Hz - Betriebsumgebungstemperatur 0-45CC - Abmessungen Breite 2100 mm - Abmes ...

Technische Daten: - Schnittlänge 3200 mm - Schnittbreite 1250 mm - Schnitthöhe 90C 130 mm - Schnitthöhe 45C 90 mm - Sägeblatt 45C schwenkbar - max. Sägeblattdurchmesser 400 mm - Durchmesser Ritzsägeblatt 120 x 20 mm - Drehzahl Hauptsägeblatt 3000 / 4000 / 5000 Upm. - Drehzahl Ritzsägeblatt 8000 Upm. - Motor 7,5 kW / 400 V - Motor Vorritzer 0,75 PS - Schiebetischprofil Breite 420 mm - Gusstisch 1020 x 690 mm - Absaugstutzen 90 mm und 100 mm - Platzbedarf L=6700, B=3350, H=1500 mm - Transportabmessungen L=2300, B=1200, H=910 mm                                                L=3600, B=505, H=280 mm -Gewicht 1000 kg Inklusive: - Sägewagen mit wartungsarmer Rundstangenführung - bedienfreundliche CNC Steuerung von 3-Achsen - motorische Höhenverstellung mit digitaler Anzeige im Monitor - motorische Schwenkverstellung mit digitaler Anzeige Monitor - motorische  ...

Technische Daten: - Verfahrbereich X - Achse 900 mm - Verfahrbereich Y - Achse 1300 mm - Verfahrbereich Z - Achse 180 mm - max. Werkstückabmessungen 2500 x 900 x 60 mm - min. Werkstückabmessungen 280 x 75 x 10 mm - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren Delta / YASKAWA - Luftkissentisch für leichte Bewegung und Schonung der Werkstückoberfläche - Frässpindel luftgekühlt HITECO / Italy 9.0 kw, HSK 63F - Spindel Drehzahl stufenlos 24.000 Upm - Bohraggregat - Bohraggregat mit 9 Spindeln vertikal + 6 Spindeln horizontal + Nutsägeaggregat - Verfahrgeschwindigkeit X - Achse 25 m/min - Verfahrgeschwindigkeit Y - Achse 45 m/min - Verfahrgeschwindigkeit Z - Achse 25 m/min - Steuerung OSAY / Italy - Schnittstelle Ethernet/USB/CompactFlash Card - Werkstückpositionierung, pneumatisch absenkbare Ansch ...

Technische Daten: - Verfahrbereich X - Achse 1260 mm - Verfahrbereich Y - Achse 2500 mm - Verfahrbereich Z - Achse 200 mm - Arbeitsbereich X - Achse 1240 mm - Arbeitsbereich Y - Achse 2440 mm - Arbeitsbereich Z - Achse 150 mm - Frässpindel luftgekühlt 5,5 kw / 6,0 kW - Spindel Drehzahl stufenlos 18.000 rpm - doppelter Arbeitstisch 1228 x 2440 mm (Pendelbetrieb) - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren YASKAWA - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 40 m/min - max. Arbeitsgeschwindigkeit 18 m/min - Arbeitsgenauigkeit 0.05 mm - Vakuum - Rastertisch mit 8 Sektionen - BECKER Vakuumpumpe trockenlaufend, luftgekühlt, 2 x Leistung 129 m3/h = 258 m3/h - Werkstückpositionierung, pneumatisch absenkbare Anschläge je 4 Stück in X und Y - Werkzeuglängen Sensor - CAD/CAM Software Vectric  ...

Technische Daten: - min. / max. Werkstückbreite 10 - 120 mm - min. / max. Werkstückdicke 10 -50 mm - min. / max. Zapfentiefe 5 - 45 mm - min. / max. Bohrtiefe 5 - 45 mm - Werkzeug Drehzahl 9000 - 12.000 Upm - Motor Frässpindel 5,5 kW - Spindel Durchmesser 30 mm - Werkzeug Abmessungen Durchmesser 130 x 90 mm - Werkzeugaufnahme ER 25 - min. / max. Bohrerdurchmesser 4 - 16 mm - Bohrerdrehzahl 12.000 - 18.000 Upm - Motor Bohrspindel 3,7 kW - Servo Motor X-Achse 1,0 kW - Servo Motor Y-Achse 1,0 kW - Servo Motor Z-Achse 0,75 kW - Gesamtleistung 12 kW - Antrieb über Kugelumlaufspindel - Linearführungen - Maschinenständer aus solidem Grauguss - Betriebsdruck 6 bar - Absaugstutzen 2 x 100 mm - Abmessungen L=2160, B=1080, H=1650 mm - Gewicht 1500 kg

Technische Daten: - schwingungsfreier Marmor-Granit Ständer garantiert für höchste Präzision - Arbeitsbereich X - Achse 2500 mm - Arbeitsbereich Y - Achse 1300 mm - Arbeitsbereich Z - Achse  200 mm - Frässpindel luftgekühlt HSD / Italy 9.5 kw, ISO 30 - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler 8-fach, seitlich - Verfahrsystem (X & Y Achse) Kugelrollspindel - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren YASKAWA - Linearführungen in X, Y und Z Achse 30 mm - max. Verfahrgeschwindigkeit 40 m/min - max. Arbeitsgeschwindigkeit 20 m/min - Arbeitsgenauigkeit 0.05 mm - Vakuum - Rastertisch mit 4 Sektionen und T-Nuten - Vakuumpumpe trockenlaufend,Leistung 5,5 kW - Werkzeuglängen Sensor - CAD/CAM Software VECTRIC CUT 2D PRO (NESTING Inclusive) - Steuerung WEIHONG inklusive CNC Handrad - Schnittstelle Ethernet/USB/CompactFlash Card - Elektroansch ...

CNC Boring Machine Table Type UNION Model: BFT 110 Manufacturer: UNION - Germany Model: BFT 110 Condition: very good, complete, no missing or broken parts CNC Control: HEIDENHAIN 150 Technical details: Spindle diameter: 110 mm Spindle taper: ISO 50 Table size: 1400 x 1600 mm X axis travel: 1985 mm Y axis travel: 1620 mm Z axis travel: 1960 mm W axis travel: 710 mm U axis travel: 250 mm

Technische Daten: - Verfahrbereich X - Achse 2500 mm - Verfahrbereich Y - Achse 1260 mm - Verfahrbereich Z - Achse 200 mm - Arbeitsbereich X - Achse 2440 mm - Arbeitsbereich Y - Achse 1220 mm - Arbeitsbereich Z - Achse 70 mm - Lade- Entladegeschindigkeit 15 m/min - Frässpindel luftgekühlt HSD / Italy 9.0 kw, ISO 30 (Option 11 kW HSK 63F) - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler,Karusell 8-fach, mitfahrend - Bohraggragat VERTIKAL 5 + 4 FAM / Italian 5 Spindeln in Y-Richtung, Bohrabstand 32 mm 5 Spindeln in X-Richtung, Bohrabstand 32 mm - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren YASKAWA - hochgenaue THK Linearführungen mit Langzeitschmiereinheit in X, Y, Z Achse - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 80 m/min - max. Arbeitsgeschwindigkeit 25 m/min - Arbeitsgenaui ...

CNC Boring Machine SKODA Model: W 160 Year of manufacture: 1968 Condition: very good, complete, in 2008 completely modernized with ball screws,linears, control system and full machine review - geometry CNC Control: CNC SIEMENS 840 Equipment: Universal head, Rotary table, additional equipment Technical details: Table size: 11 025 x 4 000 mm Working travel: X axis travel: 10 000 mm Y axis travel: 3 150 mm Z axis travel: 1 600 mm B axis travel: 360 Rotary table: 2 000 x 2 000 mm Max weight on rotary table: 20 000 kg Spindle diameter: 160 mm Spindle r.p.m: 800 r.p.m Tool shank: MORSE'A 6 with reduction on ISO 50 Machine weight: 80 000 kg

Technische Daten: - Arbeitsbereich X - Achse 1300 mm - Arbeitsbereich Y - Achse 2500 mm - Arbeitsbereich Z - Achse 300 mm - Frässpindel wassergekühlt je 4,5 kW, ER 25   mit Kühlaggregat CHILLER CW 3000 - Spindel Drehzahl stufenlos 22.000 rpm - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren Step Motoren - max. Verfahrgeschwindigkeit 22 m/min - max. Arbeitsgeschwindigkeit 15 m/min - Arbeitsgenauigkeit 0.05 mm - Vakuum - Rastertisch mit 4 Sektionen und T-Nuten - Vakuumpumpe 5,5 kW trockenlaufend, luftgekühlt - Werkzeuglängen Sensor - Steuerung DSP Typ NK 105 (OPTION MACH3) - Schnittstelle USB - CAD/CAM Software Vectric Cut2D PRO (NESTING Inclusive) - Elektroanschluss 3 Phasen 400 V, 50 Hz - Betriebsumgebungstemperatur 0-45CC - Abmessungen Breite 2100 mm - Abmessungen Länge 3300 mm - Gewicht 1500 kg

Machine number: 3728-87 Grinding length 2000 mm (Roll grinding machine)

CNC Portal plasma cutting machine Manufacturer: Messer Griesheim Type: Cortina DS2600 Year of construction: 1997 CNC control: KS30 Cutting area: 1. 5 m x 3 m Vacuum table: Size 1.5 x 3 m 2 Plasma torch Power source: Hypertherm MAX 100 d Filter system Cutting software IBE CNC cut

- X: 1050 mm - Y: 920 mm - Z: 110 mm - table size: 1000 x 1000 mm - speed range: 18.000 rpm - taper fixture: SK 25 - tool changer: 6-station - max. workpiece dimension: Ø 65 mm, hight 65 mm - control: Bosch CC 120 - total power: 12 kW - weight of machine: 900 kg - space requirement (W x D x H): 1,7 x 1,9 x 2,0 m Details milling motor power 4 kW vacuum pump 25 m³ / h very good condition, immediately ready for use servo motors in the axes has run less than single-shift accessories 6 units with collets 14 collets vacuum pump suction with 4 m suction hose machine feet documentation tool presetting device with depth gauge PAV Vario

Manufacturer: KRAMATORSK Model: 1A 660 Condition:Very good, complete. Year of manufacture: 1987 Control: CNC BOSCH M5 Distance between centers: 11.500mm Turning diameter Over bed: 1650mm Over cross slide: 1340mm Workpiece weight: max 25T Spindle bore: 105mm Spindle speed range: 0,5-250rpm Cross slide travel: 735mm Spindle stock pinol travel: 260mm Threads Meter: 1-96mm/r Whitworth: 20-3/8 Module thread D-P thread Size: Length: 17.100mm Width: 2.800mm Height: 2.000mm Weight: 46,5T

Hartford PRO 1000 A machining center The article has been checked for function, the technical condition is perfect. Optical wear exist, the exact state of the article can be found in the article images. Qk0270k Workspace: X 1,020 mm, y axis 520 mm, Z axis 550 mm Accessories and details: HEIDENHAIN control iTNC 530 Ceramic bearing spindle 12000 RPM. Coolant d. spindle (20 bar) HEIDENHAIN Handwheel 24 - specialized magazine Vises and tools do not belong to the auction/scope of delivery! If you are seriously interested, appointments are welcome. Interested parties are always welcome. If you have questions, I am like available.

Controls: Heidenhain TNC 360 (1992) Table size: 1,000 x 1,000 mm Table size with extension: 1,345 x 1,000 mm Table load max.: 2,000 kg Distance between the s distance Spindle to table top: 0 - 1,100 mm Travel distances: X 1400 mm Y 900 mm Z 850 mm W 370 mm spindle holder: MK 5 spindle drive power: 6 kW spindle speeds: 30 - 1,500 rpm Drilling spindle diameter: 82 mm drill diameter: 2 - 70 mm Drilling tools Diameter: 17 - 450 mm Drilling capacity to full ST60: 45 mm Drilling capacity to full GG: 70 mm Zubehoer: drills; tools; usw. machine was rebuilt in 1992 and !; Very good

5-axis controlled milling centre Control: E 160 CNC Work piece clamping: 2 axis cradle type with tool-taper clamping Indexing of work piece cradle (A/B) full rotary and tilting controlled Traverses: X 1050 mm Y 420 mm Z 420 mm Spindle motor rating: 9 kW Spindle speeds to: 4000 rpm Gear steps 2 Torque: 450 Nm Pick up magazine tool positions: 15 with 2 places for extra large tools Tool taper: ISO 40 Equipped with: 2 Axis clamping system for parts, taper ISO 50; Vertical milling head ISO 40; Full guarding; Pick up magazine for 15 tools; VERY LITTLE USAGE AND ONLY WITH CUTTING OILS; Excellent

Control Siemens

CNC carousel lathe FKD 30 CNC control: Siemens 840D sl Machining-range: diameter 3500mm Working height: 3000mm Workpiece weight: max. 25 tons Driven tools: speed 0-3000 rpm Tool holder: ISO 50 for milling and drilling, Capto C8 for turning Faceplatespeed: 0 - 150 rpm Pickup station: 5 places. Filter system: 3000 liters incl. high-pressure pump 25 bar Chip conveyors: 3 items Remark: 2column carousel vertical lathe with traversing cross beam (W-axis adjustable) Support (X-axis) with one ram (Z-axis, ram 300mm x 300mm) for turning and milling with driven tools C-axis (faceplate) with master-slave bracing – zero backlash Manufactured in the EU

Pierce control automation RUR 2500 P Work area: 2.1 m x 6.1 m Control: Burny 10 LCD Fully welded Portal construction without bolted connections o LM Guide in the transverse axis o AC servo-motors (12 000 mm / min.) o Digital synchronization on the longitudinal axis o CNC control system BURNY 10 LCD Plus with touch screen o Membrane keyboard o 'Flying' bearing inserts o Automatic initial setting of the plasma torch o Voltage monitoring of plasma torch height o 1 burner parking outside the cutting area o Circuit breaker at the end of all axes 1 x plasma Kjellberg 160i with manual gas console Cut quality cutting up to 25 mm Optional autogen retrofittable Completely Factory reconditioned machine Installation and commissioning on request

Manufacturer: Expert Systemtechnik GmbH Make: cutEXPERT Type: Variojet Year of manufacture: 2009 Features: single table with the dimensions: length = 6500mm; Width = 3300 mm; Height = 1850mmGewicht: 1500kg Power consumption: 7,0 kW Cutting head number 2 manufacturer: AllfiType: V high SpeedHochdruckpumpe : Manufacturer: UhdeTyp: HP19/37-SBaujahr: 2009 Capacity 3, 8 l / min Design pressure: 4000 bar Motor power: 37kW Weight: 1450kg Single table, work room (cutting edge) dimensions: Length = 2200 mm; Width = 1300 mm; Height = 200 mm Special features: · Programmatically, motorized adjustment of the head distance. No tedious, manual adjustment necessary. Minimization of set-up time and avoid errors · Machine designed for high workpieces (up to 200 mm). Ideal for the cutting of foam materials. · Ergonomic software: simple and very fast creating of cutting programs, tak ...

CNC flatbed portal cutting machine with web control CNC 3000. plasma system Fabr. KJELLBERG HiFocus 160i and filter system Fabr. KEMPER. Working range: 2000mm x 4000mm portal bridge with double-sided, synchronised rack/pinion drive in longitudinal axis / play-free timing belt drive in transverse axis / guide track with cover and high-precision linear guide system on torsion stiffener aluminium profile / trolley with precision profile rollers / 3 pieces digital AC drive motors / switch gear control for the switch gear CNC control under Windows with 32bit processor, color screen 12.1 LCD TFT, interfaces V24 + USB, SATRONIK PLUS CAD/CAM programming software with all geometry functions (e.g. point, arc, circle, rectangle, long hole, etc.), functions (e.g. moving adjustment, stretching, chamfering, etc.), manipulations (e.g. turning, mirroring, etc.), SATOMATIC HV 150 PT arc height scan  ...

Replacement TFT monitor for MAHO machines with control of Philips CNC 432. Suitable for MAHO CNC 432/10 Philips control machines. Front panel aluminum black powder coated High quality anti-reflective glass Dimensions 400 x 308 mm front panel Technical data: TFT-LCD monitor 12.1 inch Display/Aufloessung 800 x 600 pixel brightness 400 cd/m2 Contrast ratio 500:1 Response time 8 ms Frequency 60 hz Display area 246 x 185 mm External power supply 12V Operating temperature-10 ° c + 60 ° c Power consumption of 30 W Max D-Sub 9pin connector. 2 row OSD control brightness, contrast ratio, auto adjustment Install phase position, clock, language, reset Included accessories: power adapter, Achschlusskabel 15-pol. D-Sub 24 months warranty!

Work area: 1.5 x 3 m or 2 x 4 m Standard equipment: self-focusing cutter 2 kW laser cooling unit, astringent and purifying air system, security, automatic twin transfer table, CAD/CAM software (Metalix, Lantek, Almacam) control unit with 15 "-touch screen, conveyor belt, warning light, nozzle set All CAD/CAM programs such as Lantek, Metalix and Almacam are usable. Options: Linear drive technology, laser light source optionally available with 3, 4 or 6 KW Sampling device, safety light barrier, air conditioning for automation Panel. 24 months warranty The price refers to a 1.5 x 3 m facility with 2 KW

-Spindle diameter 160 mm -Spindle SK 50 DIN 69871 - spindle power 90 kW -X-axis 16,000 mm -Y-axis 4.455 mm -W-axis 900 mm -Z-axis 800 mm

BySprint Fiber 3 x 1.5 m with 4.0 kW year 11/2016 cutting hours approx. 620 h Location : Baden-Wuerttemberg New price : approx. 600,000 EUR Available immediately Equipment: BySprint Fiber 3015 4,000 W Special position of the control cabinet Automatic duesen changer 40 compartment parts and cross-foerderin in the cutting area Inclusive: Incl. installation incl. system documentation incl. instruction training BySprint Fiber 4 days after commissioning Insurance 6 months manufacturer's service within Germany machine is still in use and can be inspected by arrangement. Excerpt from the then product brochure in the appendix. If you are interested, further pictures can be requested.

BySprint fiber 3 x 1.5 m with 4.0 kW built 10/2016 Cutting hours approx. 500 h Location: Baden-Württemberg Original price: EUR593.300 Available from about week 32/2017 Facilities: BySprint 3015 fiber 4,000 W Special position of the control cabinet Automatic nozzle changer 40 specialist Parts and cross conveyors in the cutting area Included: Incl. mounting Incl. plant documentation Including induction training BySprint fiber 4 days after commissioning Incl. transportation / insurance 12 months manufacturer warranty within Germany Machine is currently still in use, and can be viewed by appointment. Excerpt from the former product brochure in the annex. If you are interested, more pictures can be requested.

Cortina DS 3100, working range: 8,000 x 2,000 mm, year of construction Dec. 2004 CNC-controlled cutting machine with robust bridge suspension, form-fitting longitudinal drives and precisely machined guide profiles, Connection voltage: 400 V 50 Hz, TN-S mains (A/PE/N) track width: 3100 mm working width: 2000 mm dead length: 1500 mm Total width: 3525 mm Operating side: left power supply: right fuel gas: propane incl.: OmniCom Explorer C drive 15 m/min DC dual-sided Longitudinal drive on rail feet machine cutting torch ALFA (with internal ignition) OmniFlow automotive supply (gas quantity control up to 6 burners) OmniFlow Control torch suspension OmniLift 200 SensoMat ALFA SensoMat ARC/SR Plasma SetControl, tactile first height detection interlock for a maximum of 2 systems HT 4400 HySpeed fine beam plasma cutting system cutting up to 50mm energy supply via energy chain (autogen/plasma) cu ...

Excellent general condition. Used in plastic mold makers mainly for 3D graphite-carbon tool models and engraving work. Low cutting strengths, low machine load... Travel x=1200 y=800 z=500 Spindle speed 0 - 8000 rpm / Drive power main spindle 11 kW feed speed 0 - 30 m/min / table dimensions 1320 x 800mm Table load max. 2,000kg / 20-fold tool changer / max wzg diameter 63mm / WZG Long 200mm / tool holder SK 40 / 3D probe, Fabr. Heidenhain, type TS 220 / Cooling agent equipment / Spaenefoerderer / Suction (optional) Complete enclosure Heidenhain Control type TNC 426 PB digital / Electronic handwheel Heidenhain HR 410

Cortina DS 3100, working range: 8,000 x 2,000 mm, built in Dec. 2004 CNC controlled cutting machine with sturdy bridge suspension, interlocking longitudinal drives and precise machined leadership profiles, supply voltage: 400 V 50 Hz, TN-S Network (§ / PE/N) Track width: 3100 mm Working width: 2000 mm Dead length: 1500 mm Total width: 3525 mm Operating side: left Power supply: right Fuel: Propane Including: OmniCom Explorer C drive 15 m / min DC Carrier for double-sided longitudinal drive on Schienenfüßen Machine cutting torch ALFA (with internal ignition) OmniFlow autogen supply (gas volume control up to 6 burner) OmniFlow control Burner suspension OmniLift 200 SensoMat ALFA SensoMat ARC/SR Plasma SetControl, tactile initial height determination Interlock for maximum of 2 plants HT 4400 HySpeed fine beam plasma cutting system Cutting up to 50mm power supply thro ...
