cnc 4 axis used for sale

Universal CNC Milling Machine CNC MAHO MH 400 E Travel X: 400 mm Travel Y: 375 mm Travel Z: 250 mm Numerical Command CNC PHILIPS 432 Table: 700 x 270 mm Cone: SA40 Spindle speed: from 80 to 4000 RPM Year of construction: 1987 Central lubrication Manually swivel head Supplied with doc + machine parameters Voltage: 380 V Width: 2200 mm Depth: 2000 mm Total height: 2000 mm Weight: approx 1,5 T

CNC lathe Gildemeister Twin 42 RG2 Year of Make: 2004 Control Siemens 840D Powerline Turning diameter 145 mm Max. bar passage 45 mm Spindle Head Flat Flange 120 h5 Chuck 130 / 140 mm Main spindle speed 20–7,000 min⁻¹ Main spindle power 28 / 22 kW (40/100 % ED) Torque main spindle 180 / 140 Nm Sub-spindle Yes, same performance X-axis 220 mm Z-axis 320 mm Y-axis ±30 mm Rapid traverse X/Y/Z 30 / 15 / 30 m/min Turret 2 × 12 stations Tool holder VDI 25 Machine weight approx. 5,300 kg Connected load approx. 40 kVA Type 60° inclined bed, linear guides Chip conveyor Bürener type SPE 63/30- 250 Z60 Tool monitoring system Artis type CTM Tailstock mounted on sub-spindle carriage, tailstock stroke = 230mm Tailstock force = 300 daN Centrifuge MK3 Overload clutch for the X and Z axes of slides 1 and 2 Bar machining package consisting of: Workpiece collection device  ...

CNC control, operator panel, logic unit, path control -Manufacturer: Heidenhain, logic unit path control from CNC machining center Mikron VC500D -Type: LE 407 A 264 430 99 -Individual components: see photos -Dimensions: 475/325/H140 mm -Weight: 9.4 kg

CNC Lathe Manufacturer: Gildemeister Type: CTX 410 V3 Machine No.: 0136004581 Year of Make: 2006 Control: Siemens 840D ShopTurn Circumferential diameter: 505 mm Chuck diameter: 210 Spindle passage: 65 mm Drive power: 40/ 100%ED 21/28 KW Speed range from – to: 25-5000 Dimensions approx.: 4300x2000x1800 Weight approx.: 5600 Kg - 12-speed revolver - VDI 40 - C-axis - Powered tools 12 stations - Package bar machining - Chip conveyors - Tailstock - SMW Autoblok 210BB - Driven tool holders 3x axial - Driven tool holders 2x radial - Various other tool holders - New engine for revolver Errors excepted

Laser source: Bystronic BLT 3500 Turbo, laser power: 3500W, wavelength: 10600nm, max. sheet weight: 160kg/m². Base machine weight: approx. 7000kg, laser source weight: approx. 1600kg. Documentation available. An on-site inspection is possible.

Stock number: 3951 PROCESSING Manufacturer: Haas, Type: VF-6B/40HE Machines NO.: 29222, Year of manufacture: 2002 Specifications: Table size 1626x711 mm Longitudinal movement (X) 1650 mm Transverse movement (Y) 800 mm Vertical movement (Z) 762 mm Spindle cone ISO 40 Spindle speeds 10000 rpm Controlled in axes 3 Operating hours spindle 17652 hours Accessories: Cooling by spindle Chip conveyance. Tool Measuring Length: 4000mm, Height: 3150mm, Width: 3000mm, Weight: 9800 kg

Two Willemin-Macodel W 408 and four Willemin-Macodel W 408S are available, year of manufacture W 408: 1997, 2002, year of manufacture W 408S: 2005, 2006, 2007, 2008, an on-site inspection is possible.

UNION BIELEFELD WSF 41300 Find more here - .ucymachines/ Contact us at - sales@ucymachines

Machine type : Flame cutting system Manufacturer: ESAB Model : SXE-P1 4500 RH Year of manufacture : 1999 Dimensions, Weights, and Power Supply: - Track Height: 500 mm - Track Length: 14,000 mm - Cutting Length: 12,000 mm - Cutting Thickness: 150 mm - Machine Height: 1,900 mm - Machine Length: 2,250 mm - Height of Cutting Table: 700 mm - Machine Width: 5,270 mm - Cutting Width: 3,000 mm - Maximum Machine Speed: 12,000 mm/min - Machine Weight: 2,500 kg - Maximum Number of Single Torches: 2 x 381 + 1 - Fuel Gas: Acetylene - Voltage: 230 V / 50 Hz - Power Consumption: 2 KVA Find more here - .ucymachines/ Contact us at - sales@ucymachines

Key data: 420 mm, 1524 mm, 3300 1/min

Stock number: 3963 CNC LATHE Manufacturer: MAZAK, Type: INTEGREX 400 III-S Machine NO.: 173882, Year of manufacture: 2005 Specifications: Max. circumferential diameter 420 mm dia. Max. turn. About Bed 850 mm Dia. Turning length 1524 mm Main motor power 30 kw Main spindle speed range 3300 rpm Drilling through drawing tube 102 mm dia. C axis - head spindle movement 0.001 degrees Y axis +/- 115 mm B Axis Movement -30/+195 degrees B axis spindle speed 12000 rpm B axis spindle effect 18.5 B axis tool system Capto C6 Sub-spindle C axis - counter pindle movement 0.001 degrees Engine power sub-spindle 26/22 Kw Total Power Consumption 99.9 kva Control Mazatrol 640 Fabr. Spindle Hours 7167 Hours Controlled in 6 Axes Accessories: ATC Tool magazine with 40 stations Hydr. Chuck main spindle 300 mm dia Hydr. Chuck Subspindle 300 mm dia  ...

Specifications: Working length: 4100 mm Stand width: 3650 mm Press force: 220 to CNC control: OPERATOR OPII graphic Color Screen Size: 14" Controlled axes: Y1/Y2; X1/X2; R1/R2; Z1/Z2 Mot. adjustable back gauge Projection: 420 mm Stroke: 180 mm Auto. Crowning Laser monitoring Motor power: 17 kW CE mark Dimensions (length x width x height): approx. 4800 x 2300 x 2900 mm Weight: approx. 16 tons Accessories: various tools

Spindle nose: A11, turret: VDI60, voltage: 380V, rated current: 153A, fuse protection: 160A, control: Philips B2T, one tool position for boring bars is defective, no driven tools, without chuck, with documentation and maintenance records, the machine was mechanically overhauled in 2010. An on-site inspection is possible, available from mid-December 2026.

A Spinner CNC lathe in need of repair is offered. Control: FANUC Series 31i-A, spindle operating hours: approx. 36824h. The lower turret is locked but incorrectly indicates unlocked status. A broken spring is suspected as the cause. Documentation available. Inspection by appointment possible.

Specifications: Working length: 6200 mm Pressing force: 400 tons CNC control: CYBELEC ModEva 10S Number of controlled axes: 7 Controlled axes: Y1/Y2; X/1; R; Z1/Z2 Stroke: 315 mm Projection: 410 mm Crowning Motor power: 75 kW Tool clamping at the top and bottom Laser monitoring: FIESLER Dimensions (length x width x height): approx. 6300 x 2500 x 3850 mm Weight: approx. 40,5 tons Accessories: many tools Zustand / condition: very good condition

Specifications: Working length: 4100 mm Stand width: 3650 mm Press force: 170 to CNC control: OPERATOR II grafic Controlled axes: Y1/Y2; X1/X2; R1/R2; Z1/Z2 Mot. adjustable back gauge Projection: 300 mm Stroke: 200 mm Crowning Working height: 960 mm Motor power: 13 kW Dimensions (length x width x height): approx. 4500 x 2200 x 2900 mm Weight: approx. 14 tons Accessories: 1 set of tools

turning diameter: max. 420 mm turning length: 1250 mm control: INDEX, C 200-4 D swing diameter: 630 mm travel x1: 320 mm travel z1: 1250 mm travel x2: 170 mm travel z2: 1250 mm travel x3: 320 mm travel z3: 1250 mm main spindle speed: max. 3000 U/min main spindle drive: 53 kW spindle passage: 102 mm spindle head: DIN 55026 Gr. 11 max. torque on the spindle: 675 Nm sub spindle - spindle speed range: max. 3000 U/min sub spindle drive: 53 kW sub spindle - spindle passage: 102 sub spindle - spindle head: DIN 55026 Gr. 11 sub spindle - spindle torque: 675 Nm travel sub spindle: 1250 mm feed power: X1 14000/Z1 14000 N rapid traverse: X1 20/Z1 40 m/min feed power: X2 8600/Z2 14000 N rapid traverse: X2 20/Z2 40 m/min feed power: X3 14000/Z3 14000 N rapid traverse: X3 20/Z3 40 m/min numbers of turret head positions: Rev. 1 = 12 numbers of turret head positions: Rev. 2 = 10 numbers of turret head p ...

new CNC Nestingmachine, Brand: INFOTEC Type: 4621 EVO GO Technical data: Working range X axis: 2150 mm working range Y axis: 4600 mm Working range Z axis: 250 mm X / Y axes speed: 60 m/min Z axis speed: 12m/min Drill head grid 32 12 vertical spindles 8 horizontal spindles 1,7 kW System INFOTEC - EVO GO Automation of horizontal drilling in 18 mm panels (patent pending) Lateral drilling zone (requires drilling unit 12/8/2 LL) - Special unit for the C axis, which allows the transfer of the cut workpieces to the drilling zone. Can be rotated 0-90 degrees. (C-axis required) Optional: - Extension of the working area in the Y-axis up to 4600 mm. (Total length of the machine set with unloading table for EVO GO is: 9100mm). - Lateral drilling range: X: 2150 mm, Y:1300 mm Dimensions of side drilling elements: - 1600 x 600 x 18 mm - maximum, - 500 x 80 x 18 m ...

CNC shearing machine manufactured in 2023. This Durma VS 4006 features a cutting length capacity of 4100 mm and can handle a maximum sheet thickness of 6 mm for structural steel. It includes a powerful 11 kW motor and a rear stop/back gauge range of 1000 mm. If you are looking to get high-quality shearing capabilities, consider the Durma VS 4006 machine we have for sale. Contact us for further details.

BYSTRONIC ByStar 4020 laser cutting machine was built in 2011 by the renowned Swiss brand BYSTRONIC. The machine, designed to meet the highest industrial standards, is used for precision cutting and engraving of workpieces with a maximum thickness of 25 mm. Materials made of e.g. steel or aluminium are machined using a laser beam with a maximum power of 6 kW and a thickness of just a few μm. It ensures extremely precise workpiece edges, which are characterised by unprecedented smoothness and absence of irregularities. The offered ByStar 4020 laser cutting machine is also extremely easy to operate. The process parameters are programmed in the intuitive ByVision CNC control, which allows the creation of advanced machining programmes in just a few steps. All this makes the BYSTRONIC laser the perfect choice for any industrial plant. Technical specification of the BYSTRONIC ByStar 402 ...

turning diameter:360 mm turning length:520 mm total power requirement:20 kW weight of the machine ca.:3,8 t dimensions of the machine ca.:3 x 2 x 2 m

Inv. Num. : 8329 Type: KMX 413 Producer: MANURHIN Created: 2018 Parameters: Control system: FANUC Hours: 9473 h Max. rod diameter: 16 mm Number of axles: 4 plus 2 pieces Maximum spindle speed: 12000 1/min Spindle bore: 19 mm Spindle stroke: 130 mm Equipment: Collets Bar Feeder Spindle adjustment for 16 mm rod without adjusting the rod end

Circulation/rotation Ø over bed: 475 mm Rotation/rotation Ø via cross slide: 260 mm Sledge path plan: 260 mm centre distance: 1000 / 1500 / 2000 mm power capacity: 22 kW Gear stages. m= manual / e= electric.: 2 e Spindle head DIN 55026 / DIN 55027: A6 / 6 Spindle Ø in front bearing: 115 mm spindle bore: 78 / 70 mm turning speed range (V-constant): 1 - 3.000 U/min feed range flat: 1µ - 1.000 mm/U feed range lengthwise and thread: 1µ - 2.000 mm/U Rapid traverse plan/longitudinal: 5 / 10 m/min diameter of quill: 70 mm quill travel: 120 mm quill inner cone: 5 MK This machine is used for the production of individual parts and small batches from simple to the most complex contours. It is characterised by: --> Ease of operation Precision Working range

Key data: 4000 mm, 2000 mm, 10000 W

4000 x 2000mm with Bytrans Extended

A Gildemeister CNC double-spindle turning and milling center including coolant system and chip conveyor is available. Turning diameter over bed: 640mm, machining diameter: 400mm, center distance: 1930mm, travel X/Z: 550mm/1585mm, travel Y: +/-110mm, B-axis: +/-120° (interpolating), C-axis: 360°. Main spindle: power: 36kW/45kW, speed: 4000rpm, torque: 600Nm-730Nm, bore: 107mm. Milling spindle: Speed: 12000rpm, power: 13.2kW/22kW, torque: 100Nm. Tool places: 60, carrier: turret 12-fold star SW 380, machine dimensions X/Y/Z: approx. 9300mm/4600mm/3100mm, weight: approx. 20000kg, control: Siemens Sinumerik 840D powerline. Documentation available. On-site inspection is possible.

BYSTRONIC ByStar 4400 laser cutting machine was built in 2006 by the Swiss brand BYSTRONIC. The machine, designed for precision cutting and engraving of sheet metal, is an excellent choice for any industrial plant. The machining process is performed using a stable 4.4 kW laser beam, which is generated by a resonator of the highest energy efficiency. As a result, the edges of the machined workpieces stand out for their unprecedented smoothness and lack of unevenness. ByStar 4400 laser cutting machine is offered with a range of equipment, including among others an intelligent CNC control and a KELLER industrial dust collector. The machine has undergone regular inspections and is ready for further use. BYSTRONIC laser weighs 13500 kg. Technical specifications of the BYSTRONIC ByStar 4400 laser cutting machine - CNC controller: BYSTRONIC ByVision - laser power: 4.4 kW (4400 W) - max ...

A centerless CNC cylindrical grinding machine Tschudin is available. Workpiece diameter min./max.: 1.5mm/100mm, max. grinding length: 250mm, grinding wheel diameter outside/inside: 400mm/203.2mm, grinding wheel peripheral speed: 50m/s, grinding wheel power: 11kW, control wheel diameter outside/inside: 225mm/127mm, speed: 265rpm, inclination: +/-5°, power: 3.7kW. Machine dimensions X/Y/Z: approx. 2000mm/2400mm/1900mm, weight: approx. 6000kg, control: Fanuc 21i-MB. Including Knoll Micro Pur 240 F ultra-fine filter, Streuli SHSRT300-TL142/180 lifting station and Kraft & Bauer FB703S-UV3-TFM70° fire extinguishing system. Documentation available. On-site inspection is possible.

A CNC fine milling machine Iselautomation KG with defective spindle is available. Travel X/Y: 400mm/200mm, machine dimensions X/Y/Z: approx. 1200mm/900mm/1600mm, weight: approx. 500kg. On-site inspection is possible.

Inv. Num. : 8514 Type: CLX 450 TC Producer: DMG Created: 2022 Parameters: Switch-on hours: 13312 h Hours: 8547 h Maximum spindle speed: 5000 1/min X-axis travel: 750 mm Y-axis travel: 200 mm Travel Z axis: 1000 mm Max. workpiece diameter: 400 mm Maximum length of the workpiece: 1100 mm Machine weight: 9200 kg

Turning diameter: 320mm, turning length: 1000mm, spindle clearance: 80mm, speed: 3150rpm, travel X/Z: 265mm/1000mm. Machine dimensions X/Y/Z: approx. 5500mm/2400mm/2400mm, weight: approx. 7000kg, control: Traub System TX-8. Including a tool set, three-jaw chuck and bar chuck with collets. Documentation available. On-site inspection is possible.

A CNC gantry flame cutting machine ESAB is available. Track width: 4000mm, cutting dimensions X/Y: 3000mm/6000mm, track length: 8000mm, track height: 465mm, table height: 700mm, cutting speed: 24m/min, flame cutting table dimensions X/Y: 3100mm/6180mm. Cutting process: Oxyfuel/plasma, Torch: Cooljet-Pro, Plasma source: m3 202 EPP 202 GEN 2, Plasma torch: PT-36. Filter capacity: 9000m³/h, Filter area: 180m², Particle size: 0.1µm. The plasma source cooling system must be repaired. Documentation available. On-site inspection is possible.

Key data: 160 t, 4000 mm

160 ton x 40000mm Multi Axis CNC

A CNC 6-axis laser precision machine for non-contact laser processing and measurement of complex geometries, particularly in the tool and mould making industry, is available. Travel X/Y/Z: 300mm/400mm/500mm, table dimensions X/Y: 300mm/400mm, axes mechanical/optical: 3/3, measurement system: non-contact SI sensor, measurement accuracy: +/-0.01mm, surface finish: Ra under 1µm, operating hours: 21045h, processing hours: 6549h. The laser (Prisma) is defective. Documentation available. An on-site inspection is possible.

The machine is in good technical condition, after prior agreement it is possible to test it. Control system: Fanuc Max. turning diameter: ø65mm Max. workpiece length: 300mm Turret head: 2x12 driven positions Bar feeder: IEMCA master 880 MP Cooling + chip conveyor

X-axis: 320mm, Y-axis: 400mm, Z-axis: 90mm. No defects known, regularly maintained, without accessories or spare parts. The machine has already been dismantled. An on-site inspection is possible, not under power.

pressure: 400 t chamfer lenght: 4100 mm distance between columns: 3550 mm column arm: 510 mm ram stroke speed: 110 mm/sec work speed: 8.4 mm/sec return speed: 130 mm/sec work stroke: 375 mm dayligth: 650 mm table height: 1000 mm table width: 240 mm back stop - adjustable: max. 800 mm oil volume: 400 ltr. voltage: 400 Volt total power requirement: 30.0 kW weight: 26409 kg range L-W-H: 5450 x 2650 x 3470 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 ...

x-travel: 400 mm y-travel: 375 mm z-travel: 250 mm table-size: 600 x 300 mm spindle taper ISO: 40 quill stroke: 50 mm spindle turning speed range: 50-400 , 400 - 3150 U/min CNC-control: TNC 135 voltage: 380 V / 50 Hz feeds: X+Z = 5 -1000 mm/min rapid traverse: X+Z = 2,4 m/min feeds: Y = 5 -670 mm/min rapid traverse feeds: Y = 1,6 m/min measuring system resolution capability: 0,005 mm total power requirement: 3,7 kW weight of the machine ca.: 0,9 t dimensions of the machine ca.: 1,9 x 1,8 x 1,70 m • HEIDENHAIN TNC 135 control, The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CNC Lathe Manufacturer: Gildemeister Type: CTX 420 linear V3 Year of Make: 2003 Control: Heidenhain Plus IT Circumferential diameter over bed: 680 mm Circumferential diameter over face slide: 565 mm Plan travel: 260 mm Longitudinal travel: 635 mm Drive power: 40/ 100% 25/37 kW Speed range from – to: 20 – 5000 rpm Weight approx.: 6500 Kg Equipment: Driven tools: 12 stations Tool carrier: 12-cavity Sauter revolver VDI 30 Partial hollow clamps Tailstock Quill stroke automatic Quill holder: Mk 5 Conveyor Measuring arm Oil mist extraction Errors excepted

Heckert CWK 400 Built in 1995 Control Siemens 840 Travel X/Y/Z 650/650/680 mm Spindle speed up to 10,000 rpm HSK 40 Tool Changer Rotary table 400 x 500 mm, Conveyor Weight 12.5 t.

DMG MORI NEF 400 CNC turning center was built in 2009 in Poland by FAMOT Pleszew S.A. The machine, distinguished by its compact design and high efficiency, is used for precision machining of workpieces with a maximum diameter of 350 mm. The machining process is performed inside a fully illuminated workspace by means of a high-speed spindle and precision cutting tools taken from a 12-position turret. The extremely rigid design eliminates any vibration and oscillation, ensuring maximum process stability during even the most intense challenges. All these features make the DMG NEF 400 the best choice for any industrial plant. The GILDEMEISTER NEF 400 CNC lathe was used for prototyping and worked for a total of 6492 hours. The offer also includes extensive equipment, consisting of, among others, an advanced HEIDENHAIN CNC control, driven tools and a chip conveyor. Technical specificatio ...

Stock number: 4001 PROCESSING Manufacturer: MAZAK, Type: VCN 410A-II Year of Make: 2009 Specifications: Table size 900 x 410 mm Longitudinal movement (X) 560 mm Transverse movement (Y) 410 mm Vertical movement (Z) 510 mm CAT 40 spindle cone Infinitely variable spindle speeds 12000 rpm Spindle motor 11/7.5 Kw Tool changer 30 places Control Mazak Matrix Fabr. Controlled in axes 3 Operating hours spindle 7746 hours Accessories: Cooling by spindle 15 bar Chip conveyance. Tool Measuring Length: 2600 mm, Height: 2800 mm, Width: 2000 mm, Weight: 5010 KG

Laser cutting machine Type: MSF 4001.20Ltk+T500 4kW IPG Manufacturer: MicroStep Year: 2016 Working area: 4000 x 2000mm + space for pipe cutting Laser: 4000 W IPG Linear guides Rexroth Gear racks Precision helical gears ATLANTA on all axes, double-sided driven portal STOBER gearboxes Drives maintenance-free, processor-controlled AC-servos Panasonic Max. positioning speed 130 m/min - one axis, 180 m/min simultaneously 2 axes. Acceleration 10 m/s2 Z-axis positioning speed 50 m/min Z-axis travel 150 mm Z-axis acceleration 0.75 G Position deviation Pa 0.07 mm in accordance with VDI/DGQ 3441 Repeat return accuracy Ps 0.03 mm in accordance with VDI/DGQ 3441 Ambient operating temperature +10 °C to +35 °C Relative humidity 0 to 90 % Machine in very good condition, under power Find more here - .ucymachines/ Contact us at - sales@ucymachines

Key data: 4230 mm, 2100 mm, 850 mm

X-axis: 4,230 mm Y-axis: 2,100 mm Z-axis: 850 mm CNC control: Heidenhain TNC 530 Spindle mount: ISO 50 Spindle speed: 6,000 rpm Tool changer: 30 places Table dimensions: 4,000 x 1,650 mm Stand spacing: 2,300 mm Equipped with: - Angle milling head - Touch probe button - Inner spindle cooling - Double chip conveyors - Cooling system -Operating instructions Country of origin: Taiwan Machine LxWxH: 9,000 x 3,500 x 4,000 mm +/- Machine weight: 30,000 kg

Key data: 650 mm, 1500 mm

Year of construction 2014, commissioning 2017 OSP P300S Controller Travel: X1/X2 axle: 695/235 mm Y-axis: 300 mm Z1/Z2 axle: 1,600/1,461 mm B-axis: -30° to +210° Max. turning diameter: 650 mm Big Bore main spindle 32/22 kW, spindle nose A2-11, max. speed: 3,000 rpm, Max. torque: 955 Nm, bore 112 mm Hollow Clamping Cylinder SMW VNK320-127, Bore 127 mm 3-jaw chuck Forkardt 3QLK 315-88 Z11 Pressure reducing valve 8-70 bar Milling spindle 22 kW, max. speed: 12,000 rpm Tool magazine with 40 tool positions, HSK-A63 Lower turret with 12 tool stations Self-centered bezel on the lower turret Hydraulic bezel SMW SLU-X-3.2-ZS, clamping range: 50-200 mm Programmable tailstock Renishaw RMP Probes Drum trough filter TMF300 with 980 L tank 8 bar circulation pump 70 bar high pressure pump Hinge belt chip conveyor Tool monitoring system for tool life and breakage Tool measur ...

Universal CNC lathe INDEX G 400 RATIO Line Hersteller [manufacturer]: INDEX Type [ type]: G 400 Control unit: Siemens C200-4D incl. milling of cylindrical tracks Incl. handwheel Baujahr[construction year]: 10/2004 Turning length 1250 Main spindle D102 with swing-in gear 1700 Nm Size 11 Hollow Clamping Cylinder 102 ARB-SPI ALIGNMENT. AND SWITCHING DEVICE TOOL CARRIER 1 COMPL. AXES X,Y,Z,B with turning/milling operation Disc turret VDI40 10 stations MILLING SPINDLE HSK A63 Tool carrier axles 2 XZ Disc turret VDI40 10 stations SUB-SPINDLE D102 DIRECT DRIVE 1300Nm Size 11 Hollow Clamping Cylinder 102 ARB-SPI ALIGNMENT. AND SWITCHING DEVICE DISC MAGAZINE ON THE LEFT OF THE HSK63 SINGLE-SWING GEARBOX WITH 32 TOOL HOLDERS DISC MAGAZINE RIGHT COMPL. M.32 TOOL HOLDERS HSK 63A Travel path: X= 320mm Z=1250mm Displacement measuring system X-axis glass mast. (abs) Fe ...

Key data: 660 mm, 983 mm

CONTROL PANEL FANUC F31-IA5 AXIS MOVEMENT X 750 MM / Y ± 210 MM / MM / Z 1.220 MM ROTARY AXIS MOVEMENT B + / - 120 ° / C 360 °/ 0.001 ° MAX. TURNING DIAMETER 660 MM MAX. TURNING LENGTH 983 MM SPINDLE - 1 CHUCK SPİNDLE SPEED 3.000 MIN/-1 CHUCK DIAMETER 12 INC / 315 MM BAR CAPACITY 90 MM TOOL SPINDLE SPEED ( S1 ) 12.000 MIN/-1 TOOL HOLDERS CAPTO C6 NUMBER OF TOOL POSITION 100 SPINDLE - 2 SPİNDLE SPEED RANGE SUP SPİNDLE 3.000 MIN/-1 CHUCK DIAMATER SUP SPINDLE 12 INC / 315 MM WEIGHT OF THE MACHINE 22.300 KG DIMENSIONS OF THE MACHINE 5.33 X 3.27 X 2.93 M

turning length: 4.500 mm greates pass round over bed: 810 - 760 mm swing diameter over slide rest: 740 mm control: SIEMENS - 840 C max. turning diameter: 800 mm turning diameter over slide: 740 mm travel -x2 axis: 875 mm travel -z2 axis: 5.200 mm CNC Turning- and Milling Center | NILES-SIMMONS - N40 MCT 4500 equipped with a turret for driven tools as well as NC steady rest and tailstock. Additional equipment: - Centering points, - Jaw sets, - Clamping jaws, The machine is in a well-maintained condition and can be inspected at any time under power. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: N-40 | N 40 | N40MCT4500 | N40MCT The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
