fully hydraulic circular shears , capacity 6 mm ,
FASTI Manual Circular Scissors Size 2 Power : up to 2mm ( 400 N/mm²) cutting diameter : 1000 mm Projection: approx. 280 mm Very good stable construction, operation by hand crank. Machine with base
sheet thickness: 2 mm steel blank diameter: 1000 mm Motorized drive via foot switch
shear power: 4 mm steel blank diameter: 1000 mm Min. blank diameter: 180 mm Cutting speed: 36/72 mm Automatic sequence with start via 2-hand operation Pneumatically ramp-up material stop Operating instructions Weight: approx. 1000 kg
High-quality, PLC-controlled circular shears / circular, blank and flange ring shears with punching device used - refurbished PLC – Control for 120 cutting programs with 30 program sets each Projection in tailstock 1,000 mm Automatic tailstock clamping Outreach in the shear station 400 mm Shear performance 0.5 to 5 mm sheet steel 400 N/mm² 0.5 to 3 mm stainless steel sheet 650 N/mm² Largest shearable disc diameter Ø 1,400 mm for rectangular starting material Ø 1,800 mm for octagonal starting material Smallest shear diameter 150 mm Diameter Ø shear knife 100 mm Shear rate up to 35 m/min punching diameter at S = 2 mm sheet steel 400 N/mm² - Ø 25 mm at S = 3 mm sheet steel 400 N/mm² - Ø 17 mm Drive power 7 KW Weight 1.300 kg Dimensions 2.7 x 1.8 m x H 1.7 m Optionally available with a flanging device – Maximum board height 20 mm ...
PLC - controlled round and flange ring shears (circular scissors) This can also be expanded into a combined circular scissors - flange machine. We supply the machine in semi-automatic design and as a fully automated production island. Rounds and flanges (sheet rings) made of steel sheet, VA stainless steel sheet, aluminium and non-ferrous metal sheet can be cut, maximum shear performance for sheets with a tensile strength of 400 N/mm2 - 0.5 mm to 12 mm, smallest / largest cutable circular board 500 mm to 2,200 mm – cutting speed up to 25 m/min, drive power 15 kW, weight of the base machine
We supply round and flange ring shears (circular shears) in two sizes - 3/1300 and 5/1800 Our KS circular shears are PLC - controlled hydraulic - electromechanical machines designed for the production of rounds and flanges made of steel sheet, VA stainless steel sheet, Aluminium and non-ferrous metal sheet, maximum shearing performance for sheets with a tensile strength of 400 N/mm2 - 0.5 mm to 3 mm or 0.5 mm to 5 mm, smallest / largest cutable circular board 150 mm / 1,300 mm or 1,800 mm respectively – cutting speed up to 35 m/min, drive power 5 kW or 7.5 kW, weight approx. 2,000 kg and 3,000 kg
