Max Diameter Bar Capacity.. 2" Max Swing Over Bed / Carriage... 23.2" / 6.7" Max Turning Diameter (Max / Std)... 9.84" / 6.7" Max Machining Length. 20.1" Main Motor... 20 / 15 HP Tools 12 / 24 Spindle Speed. 60 - 6000 RPM Spindle Bore 2.4" Milling Motor 5 HP Milling Speed.. 6000 RPM Rapid Traverse Rates (X / Z).. 1181 / 1417 IPM X-Axis Travel 17.7" Z-Axis Travel ...13" C-Axis Index... .001 Degrees Turret Index (Single Step). 0.15 Seconds Tailstock Taper.. MT#4 Machine Dimensions (L x W x H) 144" x 63" x 65" Machine Weight 7275 lbs. FEATURES: FANUC i Series 10.4" Color LCD PC / MCIA Interface C-Axis Milling Capability 6" Samchully MH-206 Hydraulic Chuck
x-travel: 7000 mmy-travel: 3000 mmz-travel: 1200 mmW-axis (spindle longitudinal): 500 mmspindle diameter: 150 mmquill:: 380 x 380 mmPlate dimensions: 4x 5000 x 2000 mmpowered rotary table: 1600 x 1600 table load of rotary table max.: 10 ttravel on the bed: 1500 mmtool taper: SK 50 turning speeds: 2,5 - 1000 U/minpower capacity - milling spindle: 30 kWdimensions: mweight of the machine ca.: 62 tused manual horizontal borer with plate field- digital scale- tailstock- moveable vertical milling head- movable turn tableThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Model: Super Mini Mill 2 HAAS Three-Axis CNC Vertical Machining Center, S/N: 1088948 (New 2011) Specifications: Table size.14" x 40" Maximum table load capacity.500 Lbs. Travels: X-axis..20" Y-axis..16" Z-axis..14" Minimum/Maximum distance from spindle to table4"/18" Spindle taperCAT 40 Spindle speed range0-10,000 R.P.M Rapid feed rates, all axes..1,200 I.P.M. Maximum cutting rate...833 I.P.M. Table size Maximum table load capacity Travels, X-axis Y-axis Z-axis Minimum/Maximum distance from spindle to table Spindle taper Spindle speed range Rapid feed rates, all axes Maximum cutting rate 14" x 40" 500 Lbs. 20" 16" 14" 4"/18" CAT 40 0-10,000 R.P.M. 1,200 I.P.M. 833 I.P.M. Equipped With: HAAS three-axis CNC with 15" color LCD, USB, and RS-232 serial ports Brushless servo motors and servo amplifiers on all axes (24) Station side-mounted automati ...
table length: 2000 mmtable width: 2000 mmtable load: 25 ttable rotating: 360 °Control: total power requirement: 4 kWweight of the machine ca.: 8,2 tdimensions of the machine ca.: 3 x 2,9 x 0,9 mBoring mill table Skoda E25A- Boring mill table Skoda E25A- Dead weight: 8,2t- Max. Clamping weight. 25t- First commissioning: 1996- Decommissioned and stored since 2014- All axes are electrically controllable and ready for operation- 360° rotary drilling table ready for operation- Dimensions: see data sheet- Heidenhain rotation measuring system with digital display ready for operation- Heidenhain linear measuring system with digital display ready for operation- Boring mill table fully functionalThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
spindle diameter: 160 mmx-travel: 10.000 mmy-travel: 3.000 mmControl: total power requirement: 120/63 spindel kWweight of the machine ca.: 63 tdimensions of the machine ca.: 15x3.85x7.36 mStocknumber 1210057Type of machine CNC Floortype boring machineMake WOTANType Rapid 5CBuild in 2004Type of control HEIDENHAIN iTNC 530Spindle diameter 160 mmX-stroke (mm) 10.000Y-stroke (mm) 3.800Z-stroke (mm) 700W-stroke 700 mmTool Taper Iso 50Speeds (Rpm) 1,25 - 1250Feeds (mm/R) 1 - 5000 mm/min Rapid feeds 5 mtr/min.Total Power (KW) 120 /spindel 83Lenght (mm) 14.500Width (mm) 3.850Height (mm) 7.360Weight 62.300 kg Additional informationcompletely overhould in 2004 and retrofitted by Dorries Scharmann with CNC control HEIDENHAIN iTNC 530- 4 different angular milling heads- hydrostatic spindle bearing- aerostatic guideways- coolant device- chi ...
Scharmann - WB 80 / Heidenhain Digital Display -Travel X/Y/Z 1300x1200x1200mm -Heidenhain digital display -Rotary table - 1200x1200mm -Table load max. 5 to. -Spindle holder MK5 -Automatic feeds 0.053-6.35mm -Rapid traverses -Spindle speeds 24-2880 rpm -Coolant device -Various accessories / tool holders etc.
spindle diameter: 110 mmx-travel: 4000 mmy-travel: 2000 mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: m Stocknumber 1210014Type of machine Floortype Boring MachineMake PEGARDType AF11Type of control ConventionalSpindle diameter 110 mmX-stroke (mm) 4000Y-stroke (mm) 2000Z-stroke (mm) 300/750Table dimensions (mm) 1200 x 1600 mmTable rotation (degrees) 360 Tool Taper Iso 50Speeds (Rpm) 4 - 1000The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Key data: 105 mm, 2500 mm, 1850 mm
CNC Heidenhein TNC 124 table 1750 mm x 2000 mm spindle dia. 105 mm x - 2500 mm, y - 1850 mm, z- 1400 mm, w - 700 mm
Machine : Tools for boring mill / radial drilling machine Type: MK5 5 drill rods φ 40 , 30, .. L- 280 – 400mm 3 extensions MK5 – MK4 , L-400-520mm 1 boring tool Oerlikon MK5, φ 70, 6-260 5 top-mounted milling mandrels MK5 - φ 16, 22, 27,32,40mm 2 Clarkson clamp chucks 1 MK5 boring tool, adjustable, φ 60mm 2 Shots 2 milling cutters: End mill roughing/plain φ 56x100mm, / groove milling cutter 4 milling cutters: 2 roughing/plain φ 40x12o, 2 roughing cutters 1 Reduction from MK5 to SK40 Weight: approx. 70kg kg PRICE : € 600,- ex works ! A - T-slot size: approx. 21.5mm, B-35, thread M20 16 T-slot nuts 20 pcs threaded rods M20, L-120 – 400mm 3 x 2 pcs clamping claws 4 nuts long, 6 nuts, washers 2 blocks for adjustment with adjustment screw 4 blocks 80 x 60 x40mm ( underlay )
HBM type Knuth BO110,Table size: 1100 mm x 960 mm with tail stock and face chuck
Key data: 110 mm
HBM HWCa-110, new in 1965
Boring mill Manufacturer: TOS Type: WHQ 13.8 CNC Year of Make: 2000 CNC control: Heidenhain iTNC 530 Completely overhauled in 2022 Report available Travel: X/Y/Z: 3,500 x 2,500 x 1,250 mm Table length: 2,200 mm Table width: 1,800 mm Max. workpiece weight: 1,200 kg Spindle Ø: 130 mm Spindle speed max.: 3,000 rpm Spindle motor power: 37 kW Dimensions: LxWxH approx.: 7,500 x 6,950 x 4,000 mm Weight: 40 tons.
Key data: 150 mm, 13500 mm, 3500 mm
Floor Type Horizontal Milling and Boring Machine Model : BF-150B with Fanuc series 311 — Model A CNC Controller in perfect working condition to be inspected in power YOM 2012 CNC Fanuc 31i Inspection Under power X - cross 13,500 mm Y - vertical . 3,500 mm W - boring ... 1,000 mm Z - quill ... 450 mm Spindle Taper ... No 50 Spindle Motor ... 26/ 22 kW 2 Angle Heads ATC 60 2 Rotary Tables 2m x 3m
DEFUM WFM-100 boring machine was built in 1984 in Poland by the Dąbrowska Fabryka Obrabiarek DEFUM. The machine is designed for precision machining of workpieces with complex geometry and high weight. All machining processes, i.e. drilling, milling, boring and thread cutting, are performed on a stable work table by means of a powerful spindle with a diameter of 100 mm. The WFM 100 horizontal boring machine weighs 11000 kg. Technical specifications of the DEFUM WFM-100 drilling and milling machine - feed in the X/Y/Z axis: 1200/1000/600 mm - work table dimensions (L x W): 1100 x 1100 mm - maximum workpiece weight: 3000 kg - maximum spindle rotational speed: 1600 rpm - spindle diameter: 100 mm - spindle drive power: 18.5 kW - dimensions (L x W x H): 4610 x 3620 x 3110 mm - weight of the DEFUM machine: 11000 kg
Union boring mill CBFK 150/2 from 1990 for sale. Is currently still in use,. Technical details / accessories / addition: x-travel 3000 mm y-travel 2000 mm z-travel 1600 mm Spindle diameter 150 mm Spindle holder ISO 50 Spindle stroke 700 mm Spindle speeds - infinitely variable 5 - 2500 rpm Rapid traverses 10000 mm/min Table clamping area 1600 x 2000 mm Workpiece weight approx. 20 t Spindle drive motor 50 kW Feeds x/y/z - infinitely variable 1 - 9999 mm/min Table positioning 360,000 ° Total power requirement approx. 70 kW Machine weight approx. 40 t Dimensions approx. 6.0 x 8.0 x 4.5 m In 2005: new 5-axis CNC control Dr. Heidenhain TNC 430 - electron. Handwheel HR 410 for all axles with V24 interface, punched tape reader, new electrics, new hydraulics, new servo motors, 60-speed chain tool change magazine model WM III k02 B-axis (round table adjustment) 360,000 ...
TOS HULIN WD 130A – Universal Plate Boring Mill Year of construction : 1998 Spindle : 130 mm ( Ø ) ISO 50 X : 6,000 mm Y : 2,500 mm Z : 1,000 mm (spindle box) W : 800 mm ( spindle ) B : 360° (turntable) Z1: 1,500 mm (table) Universal Rotary Table : 2,200 x 2,200 mm – 25 T Spindle speed : 900 rpm Spindle motor : 37 kW Total power : 60 kW Machine weight : 36 T (approx.) Digital Display : Yes Angle plate : 2,000 x 500 mm (2 pieces) Vertical milling head : 90° Face Slider
Year of manufacture: 1992 / G: 2025 Spindle diameter ... 100mm Axis X ... 1500mm Axis Y ... 1250mm Spindle speed ... 7-1120 rpm Axis W Axis Z ... 1800mm ISO 50 Turntable diameter ... 1200x1200mm The machine is in good condition, possible to test under power.
SKODA WD160B floor type boring mill X Axis 3150 mm Y Axis 2500 mm Z Axis 1600 mm Table 2000x2000 mm Piece weight 20000 kg Spindle diameter 160 mm Max. spindle speed 800 rpm Spindle motor power 75 kW Length x width x height 10000.0 × 5250.0 × 6365.0 Weight 50000 kg New control.
HBM WHN 13.8 B, new 1986, CNC control system Heidenhain
Key data: 100 mm, 1600 mm, 1250 mm
DRO , TABLE 1250 X 1250
Key data: 102 mm, 1600 mm, 1250 mm
Spindle diameter Ø 102 mm Taper ISO 50 Horizontal spindle travel 710 mm Cross travel (X) 1,600 mm Vertical Travel headstock (Y) 1,250 mm Longitudinal travel (Z) 1,500 mm Table 1,250 x 1,400 mm Table load 5 ton R.P.M. 4 – 1,250 (18x) kW 23 Volts 380 Cycles 50
Key data: 102 mm, 1600 mm, 900 mm
Spindle diameter Ø 102 mm Taper ISO 50 Horizontal spindle travel 710 mm Cross travel (X) 1,600 mm Vertical Travel headstock (Y) 900 mm Longitudinal travel (Z) 1,520 mm Table 1,250 x 1,400 mm R.P.M. 8 – 1,600 (18x) kW 11 Volts 380 Cycles 50 Including: 3-axis Digital readout with point to point control Heidenhain 310
Key data: 102 mm, 1530 mm, 900 mm
Spindle diameter Ø 102 mm Taper ISO 50 Horizontal spindle travel 710 mm Cross travel (X) 1,530 mm Vertical Travel headstock (Y) 900 mm Longitudinal travel (Z) 1,500 mm Table 1,250 x 1,400 mm R.P.M. 8 – 1,600 (18x) kW 11 Volts 380 Cycles 50 Including: Digital readout
spindle diameter 130 mm - ISO 50 tool - rated power of the spindle rotation motor 18.5 kW - installed power 4 0kW - spindle drive motor speed range 722-1455 rpm - spindle rotation range 2.25-900 rpm, 27 degrees - disc rotation range 2.25-180 rpm, 18 degrees - X axis feed speed range 0-5000 mm/min, stepless - Y axis feed speed range 0-5000 mm/min, stepless - Z axis feed speed range 0-3150 mm/min, stepless - B axis feed speed range 0-4000 mm/min, for Ø1m, steplessly Bg2Ltmk8Gq - machine weight 30 t
Inv. Num. : 7631 Type: F80 Produzent: Pfeifer Erzeugt: 1976 Parametern: Maximale Drehzahl der Spindel: 1000 1/min Verfahrwege X-Achse: 1700 mm Verfahrwege Y-Achse: 1800 mm Verfahrwege Z-Achse: 1800 mm Verfahrwege W-Achse: 710 mm Spindeldurchmesser: 80 mm
Horizontal Boring Machine CORNAC C100 Travel X: 1000 mm Travel Y: 1000 mm Travel Z: 1260 mm ixed table Cone SA 50 Spindle: Ø 100 mm Spindle exit: 550 mm Rotation: from 10 to 1250 RPM Table size: 1550 x 980 mm Surfacing plate: Ø 520 mm Spindle motor: 9,5 kW Scale 3 axes HEIDENHAIN Automatic Feeds: X - Y - Z Supplied with a set of cones Voltage: 380 V Dimensions (L x W x H): 4500 x 2100 x 2450 mm Weight: approx 8 T
Key data: 80 mm, 1700 mm, 1800 mm
Spindle Diameter: 80 mm Spindle Adapter: SK50 Spindle speeds: 11 - 1000 rpm. X-axis: 1700 mm Y-axis: 1800 mm Z-axis: 1800 mm Spindle off (W-axis): 710 mm Table dimensions: 1100 x 900 mm Elbo Digital Readout: On Y-axis and Z-axis Equipped with: -Turntable - Some tool containers Spindle motor: 7.5 KW Machine LxWxH: 5100 x 2650 x 3300 mm Machine Weight: 10 Ton
Table capacity 80 TONS Clamping plate width mm 3550 length mm 4000 Carriage travel V mm 2000 Heidenhain scale Rotary axe B ROD 700 Table height mm 1460 Table weight kg 52000
W160HC with ISO 50 y.m. 1987 xtravel 4000mm y travel 3150mm rotary table S35C load 35tons, 3150 x 2800mm milling heads, tools
Key data: 130 , 3500 , 2000
CNC SIEMENS 840D X-axis (longitudinal) 3500 mm Y-axis (transverse) 2000 mm Z-axis (vertical) 1250 mm Table length 1800 mm Table width 1800 mm Maximum workpiece weight 12000 kg Spindle diameter 130 mm Maximum spindle speed 800 rpm Magazzino utensili 52 posti Spindle motor 37 kW Year of revision 2005 ------------------- Length x width x height 7200 × 7800 × 4900mm Weight 32000 kg
Key data: 130 mm, 4000 mm, 2500 mm
TOSHIBA BP-130R22 Year 2007 SPINDLE DIAMETER 5.12" (130mm) TAPER IN SPINDLE #50 VERTICAL TRAVEL, Y-AXIS 100" (2500mm) CROSS TRAVEL, X-AXIS 160" (4000mm) SPINDLE TRAVEL, Z-AXIS 28" COLUMN TRAVEL, W-AXIS 60" TABLE SIZE (BUILT IN B-AXIS) 86.6" X 70.8" TABLE LOAD CAPACITY 44,000 LBS TABLE INDEXING B-AXIS 0.001 DEGREE SPINDLE SPEEDS (3-RANGES) 5-2500 RPM EQUIPPED WITH: TOSNUC 888 CNC CONTROL 60-STATION AUTOMATIC TOOL CHANGER THROUGH SPINDLE COOLANT CHIP & SPLASH ENCLOSURE CHIP CONVEYOR 40/30 HP SPINDLE MOTOR NOTES: INSPECT IN PLANT UNDER POWER
Specifications: X-axis 2,750 mm Y-axis 2,500 mm Z-axis 2,320 mm W-axis 700 mm Spindle power 50 kW Spindle diameter 130 mm Spindle speed 1.6 – 1,600 rpm. Tool holder SK 50 Control: CNC HEIDENHAIN TNC426 Table dimensions 2,000 x 1,800 mm max. table load 8 tons B-axis 360 A° Weight approx. 37,000 kg
UNUSED: Facinghead of a Wotan BF 160 Horizontal borer.
Code 71144 Description Horizontal table borer Make PFEIFER Model F 80 / 100 Serial number 2342 Year 1982 Spindle 100 mm Spindle taper 50 ISO Spindle out (W) 500 mm Table 1000 x 850 mm Cross (X) 1200 mm Longitudinal (Z) 800 mm Vertical (Y) 800 mm Distance table-spindle 0 x 800 mm Speeds 18 steps Spindle speeds 14 – 1500 rpm 16 Feeds 0,03 – 6,0 mm/rev Rapids 2500 mm/rev Rapids all directions ( X-Y-Z-W-B) Motor 7,5 kW 380 Volts Accessoiries X-Y-Z axis are BALLSCREWS Tool clamping Pendant control Condition Machine is in very good condition
Code 61080 Description Horizontal table borer Make UNION Model BFT 90/3 at Serial number 25 742 Year 1979 ( 1980 in use ) Control Heidenhain TNC 121 Spindle 102 mm Spindle taper ISO 50 Spindle out (W) 710 mm Table 1400 x 1250 mm Cross (X) 1000 mm Longitudinal (Z) 1600 mm Vertical (Y) 1000 mm Distance table-spindle 0 – 1000 mm Weight on table 3000 kg 24 Spindlespeeds 8 - 1600 rpm Feeds 1 - 3000 mm/min Rapids 3 m/min. Motor 11 kW 380 Volts Accessoiries 3 x DRO Heidenhain ( X-Y-Z ) Tool clamping Guideway protection Pendel control Cooling equipment Option ( extra price ) Universal millinghead with 600 mm gap
Code 71145 Description Horizontal table borer Make UNION Model BFT 80 / 3-1 Serial number 18301 / 34 Year 1986 Spindle 80 mm Spindle taper ISO 40 Spindle out (W) 710 mm Table 1120 x 1000 mm Cross (X) 1000 mm Longitudinal (Z) 1600 mm Vertical (Y) 1000 mm Distance table-spindle 0 – 1000 mm 24 Spindlespeeds 8 - 1600 rpm Feeds 1 - 2500 mm/min Rapids 3 m/min. Motor 11 kW 380 Volts Size L x W x H 5500 x 3200 x 2800 mm Weigth 9 ton Accessoiries Facing head Ø 460 mm with 180 mm stroke 3 x DRO Heidenhain ( X-Y-Z ) Tool clamping Guideway protection Pendel control Cooling equipment Option ( extra price ) Universal millinghead Condition Machine is in good condition
Horizontal borer Wotan B105Y Spindle: 120 mm Travels: -X: 3000 mm -Y: 1450 mm -Z: 1280 mm Table: -1400 x 3000 mm -Rotating part: 1130 x 1500 mm (manually rotated to any degrees) -Max load: 7 tn Machine weight: about 25 ton
W100A Parameters 100mm, 1600mm Diameter of working spindle 100 mm Taper in spindle morse 6. Longitudinal adjustment of table (z) 1450 mm Cross adjustment of table (x) 1600 mm Motion of work head on frame (y) 1120 mm Slip out of working spindle (w) 900 mm Clamping area of table 1250 x 1250 mm Dimensions l x w x h 6710 x 3450 x 3000 mm Machine weight 14 000 kg Accessories: face plate, tail stock
W 200G with Siemens AC main motor. modernized the main drive by instalation of Siemens AC motor with SIMODRIVE 611. Original built ISO 60 taper and 630 rpm Main data: X=8000 mm Y=4150 mm Z =1600 mm W=2000 mm Spindle dia 200mm ISO 60 spindle speed max 800 rpm Accessories: DRO Philips available as original rotary table E 20 extra cost milling head IFH 1 and IV25, IFW 1, IFW2 IFW 3 NO floor plates
Skoda W 160 H/NR CNC Travel x= 14.500mm (bed is for the travel 18,500mm) Travel Y= 3.150mm Travel Z= 1.600mm Travel W= 1.250mm Spindle diameter 160mm Machine with ball screw Many accessories available: CNC control Siemens SINUMERIC 850 Rotary table ISO 16 2.200 x 2.200mm, capacity 16 ton included Chip conweyor : 19.000 mm + 12.000 mm Floor plates
Technical data Spindle dia 125mm ISA 50 taper stroke of the spindle 800 mm cross travel of table X 1200 mm vert. travel of headstock Y 1400 mm longit. ztravel of the table Z 1620 mm spindle speed infinitely variable 3,5-700 rpm table size 1200 x 1400 mm table load 6000 kg main motor DC 19 kw total input 22,79 kW spindle feed inf. variable 0 - 1,25 mm/rot working feeds inf. variable 0,3 - 1700 mm/min rapid traverse 2250 mm/min fine feed 3mm/min dimension LxWxH 7,4 x 4,8 x 3,6 m weight of the machine 21000 kg DRO Heidenhain
TOS WHN 130 MC used machine Specifications System Heidenhain TNC 426 Working range Spindle diameter 140 [mm] Taper in the spindle ISO 50 Table transverse adjustment (X) 3000 [mm] Vertical headstock adjustment (Y) 2000 [mm] Vertical travel (Z) 1250 [mm] Spindle stroke (W) 560 [mm] 2X Clamping surface 1800 x 1600 [mm] Speed range 10 - 2500 [rpm] Main motor output 37,0 [kW] Max. workpiece weightƒ 8000 [kg] Accessories Tool changer for 60pcs Tool cooling Chip conveyor
Control system Heidenhain TNC 415 Spindle diameter 130 mm Tapered hollow spindle ISO 50 Spindle speed range 10 to 1500 rpm Table transverse (X): 3500 mm Rolling headstock stand for (Y): 2000 mm Longitudinal displacement rack (W): 1250 mm Eject working spindle (Z): 800 mm Table load 12 000 kg Machine weight: 36 000 kg
