Base frame with adjustable base made of stainless steel
Unwinding device for sleeve rollers with pull-off motor
Sleeveformer and transport with servo motor and control
Sleeve cutting device by means of rotating knives
Sleeve lift device with sleeve holder
Photocell control for product recognition
Print Mark Recognition
Complete Siemens control panel with control panel (touch panel)
Pneumatic safety protection machine
Sleeve Roll Monitoring
Sleeve Roll End Monitoring
Pneumatic connection 6 bar 1/2"
E-connection 400 V, 50 Hz, 2 kW
Maximum flow height for products 400mm
Double sleeve roll unwinding with cutting and joining table
Piece of sleeve storage (80 m)
Product separation and product orientation
Flail motor station for positioning the sleeve
Needle system tor Sleeve
Running sleeve holding station
Platform with steps and railing for ergonomic operation of the sleeve
machine
Sleeve monitoring by means of h6136623 sensor and rejection
Adhesive tape detection
(
Splice) by means of sensor and rejection
Heat Shrink Tunnel with Dry Steam Type BH-10-5000
Drying tunnel ABS-1800
Berning Conveyor Belt Infeed Conveyor for Blow-Off
Berning Conveyor Belt Sleeve Line
Storage tape for upright ejection
Berning Conveyor Belt Tunnel Belt
Berning Conveyor Belt Discharge Belt for Blow-off
Berning Conveyor Belt Overfeed Belt
